1-1
KD-SX883
SERVICE MANUAL
CD RECEIVER
No.49765
Nov. 2002
COPYRIGHT 2002 VICTOR COMPANY OF JAPAN, LTD.
KD-SX883
KD-SX883
Area Suffix
UF China
Contents
Safety precaution
Preventing static electricity
Location of main parts
Disassembly method
Adjustment method
1-2
1-3
1-4
1-5
1-10
Flow of functional
operation unit TOC read
Maintenance of laser pickup
Replacement of laser pickup
Description of major ICs
1-11
1-13
1-13
1-14~28

1-2
KD-SX883
!Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
Safety precaution
!Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.

1-3
KD-SX883
Front bracket
CD mechanism
control board
Damper bracket
CD mechanism ass’y
FD screw
Feed motor ass’y
FD gear Pickup unit
Preventing static electricity
1.Grounding to prevent damage by static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged,
can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
2.About the earth processing for the destruction prevention by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
Be careful to use proper grounding in the area where repairs are being performed.
2-1 Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over
it before placing the traverse unit (optical pickup) on it.
2-2 Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
3. Handling the optical pickup
1. In order to maintain quality during transport and before installation, both sides of the laser diode on the
replacement optical pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
2. Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power
source can easily destroy the laser diode.
4.Handling the traverse unit (optical pickup)
1. Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
2. Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific
details, refer to the replacement procedure in the text. Remove the anti-static pin when replacing the traverse
unit. Be careful not to take too long a time when attaching it to the connector.
3. Handle the flexible cable carefully as it may break when subjected to strong force.
4. It is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it
Conductive material
(conductive sheet) or iron plate
(caption)
Anti-static wrist strap
Soldering
Attention when traverse unit is decomposed
1.Solder is put up before the card wire is removed from connector on
the CD substrate as shown in Figure.
(When the wire is removed without putting up solder, the CD pick-up
assembly might destroy.)
2.Please remove solder after connecting the card wire with
when you install picking up in the substrate.
*Please refer to "Disassembly method" in the text for pick-up and how to
detach the substrate.

1-4
KD-SX883
SEL
Location of main parts
Control unit
Main unit
CD mechanism
Main board
16 pin connector
Power IC
Main board assembly
Loading motor
Damper
Damper
Damper
Spindle motor
Feed motor
Optical
pick up unit
Mechanism relay board
RCA jack
Connector to front PCB
Antenna
jack
Changer control
connector
Front PCB
Display
Tuner
pack

1-5
KD-SX883
Disassembly method
Removing the front chassis
(See Fig.1)
1. Remove two screws A and insert a screwdriver to the
joints a on the side of the front chassis and two joints b
on the right side, then detach the front chassis toward the
front side.
Removing the heat sink (See Fig.2 )
1. Remove the three screws B attaching the heat sink on
the left side of the body, and remove the heat sink.
Removing the bottom cover (See Fig.3 )
1.
2.
Turn the body upside down.
Insert a screwdriver to the two joints c and two joints d on
both sides of the body and the joint e on the back of the
body, then detach the bottom cover from the body.
Fig.1
Fig.2
Front chassis
b
a
a
b
Heat sink
B
B
B
Fig. 3
Regulator board
ed
c
A
A

1-6
KD-SX883
Removing the main amplifier board assembly
(See Fig.4 and 5)
1.
2.
3.
4.
5.
Remove the front chassis.
Remove the bottom cover.
Remove the two screws C attaching the main amplifier
board assembly on the bottom of the body.
Remove the three screws D attaching the main amplifier
board assembly on the back of the body.
Disconnect connector CN501 on the main amplifier board
assembly from the CD mechanism assembly.
Removing the CD mechanism assembly
(See
Fig.6 )
1.
2.
3.
4.
Remove the front chassis.
Remove the bottom cover.
Remove the main amplifier board assembly.
Remove the three screws E attaching the CD mechanism
assembly from the top cover.
Removing the control switch board
(See
Fig.7 and 8 )
1.
2.
3.
Remove the front chassis.
Remove the four screws F attaching the rear cover on the
back of the front panel unit.
Remove the control switch board from the front panel
unit.
Fig.4
Fig. 5
D
D
CD mechanism assembly
E
EE
Top cover
Fig. 6
C
C
CN501
Main amplifier board
F
F
F
F
Fig. 7
Fig. 8
Control switch board

1-7
KD-SX883
Unsolder the part aand bon the CD mechanism
control board.
Remove the stator fixing the CD mechanism control
board and the damper bracket (To remove the stator
smoothly, pick up the center part).
Remove the screw Aattaching the CD mechanism
control board.
Remove the CD mechanism control board in the
direction of the arrow while releasing it from the two
damper bracket slots dand the front bracket slot e.
Disconnect the flexible wire from connector on the
pickup unit.
1.
2.
3.
4.
5.
Removing the CD mechanism control
board (See Fig.1 and 2)
Turn the FD gear in the direction of the
arrow to move the entire pickup unit to
the appropriate position where the
flexible wire of the CD mechanism unit
can be disconnected easily.
(Refer to Fig.2)
ATTENTION:
Prior to performing the following procedure, remove
the CD mechanism control board.
Remove the two springs fattaching the CD
mechanism assembly and the front bracket.
Remove the two screws Band the front bracket
while pulling the flame outward.
Remove the belt and the screw Cfrom the loading
motor.
1.
2.
3.
Removing the loading motor
(See Fig.3 to 5)
<CD mechanism section>
Fig.2
Fig.3
Fig.4
Shift the lock
Flexible wire
Pickup unit
FD gear
CD mechanism control board
Loading motor Front bracket
Front bracket Pull outward
Pull outward
Flame
f
B
f
B
Fi
g
.5
C
Loading motor
Belt
Fig.1
Front bracket
CD mechanism
control board
Damper bracket
h
c
d
b
a
DD
D
CD mechanism assembly
A
e
h

1-8
KD-SX883
Prior to performing the following procedure, remove
the CD mechanism control board and the front
bracket (loading motor).
Remove the three screws Dand the damper
bracket.
Raise the both sides fix arms and move the fix plates
in the direction of the arrow to place the four shafts g
as shown in Fig.8 and 9.
Remove the CD mechanism assembly and the two
springs hattaching the flame.
Remove the two screws Eand both sides rear
damper brackets from the dampers. Detach the CD
mechanism assembly from the left side to the right
side.
1.
2.
3.
4.
Removing the CD mechanism assembly
(See Fig.1, 6 to 9)
The CD mechanism assembly can be
removed if only the rear damper
bracket on the left side is removed.
ATTENTION:
Fig.6
Fig.7
Fig.8
Fig.9
Rear damper bracket
Fix arm (R)
Damper
DD
Damper bracket
CD mechanism
assembly
Flame h
h
D
D
Fig.1
Front bracket
CD mechanism
control board
Damper bracket
h
c
d
b
a
DD
D
CD mechanism
assembly
Ae
Fix plate (L)
g
g
Rear damper bracket
Fix arm (L)
Damper
E
Fix plate(R)
E
g
g
h

1-9
KD-SX883
Prior to performing the following procedure, remove
the CD mechanism control board, the front bracket
(loading motor) and the CD mechanism assembly.
Remove the two screws Fand the feed motor
assembly.
1.
Removing the feed motor assembly
(See Fig.10)
Prior to performing the following procedure, remove
the CD mechanism control board, the front bracket
(loading motor), the CD mechanism assembly and
the feed motor assembly.
Detach the FD gear part of the pickup unit upward.
Then remove the pickup unit while pulling out the
part iof the FD screw.
1.
Remove the screw Gattaching the nut push spring
plate and the pickup mount nut from the pickup unit.
Pull out the FD screw.
2.
Removing the pickup unit
(See Fig.10 and 11)
When reattaching the pickuap unit,
reattach the part jof the pickup unit,
then the part iof the FD screw.
ATTENTION:
Prior to performing the following procedure, remove
the CD mechanism control board, the front bracket
(loading motor), the CD mechanism assembly and
the feed motor assembly.
Turn up the CD mechanism assembly and remove
the two springs kon both sides of the clamper arms.
Open the clamper arm upward.
Turn the turn table, and remove the two screws H
and the spindle motor.
1.
2.
Removing the spindle motor
(See Fig.12 and 13)
Fig.10
Fig.11
Fig.12
Fig.13
Spindle motor
kk
Pickup unit
Part i
FD screw
Feed motor assembly
FD gear Pickup unit
Part j
F
Nut push spring plate
Pickup mount nut
Pickup unit
FD screw
G
H
H

1-10
KD-SX883
Adjustment method
Test instruments required adjustment
1.Digital oscilloscope (100MHz)
2.AM Standard signal generator
3.FM Standard signal generator
4.Stereo modulator
5.Electric voltmeter
6.Digital tester
7.Tracking offset meter
8.Test Disc JVC : CTS-1000
9.Extension cable for check
Standard measuring conditions
Power supply voltage DC14.4V(10.5
–
16V)
Load impedance 4 (4 to 8 allowance)
How to connect the extension cable for adjusting
Standard volume position
Balance and Bass & Treble volume : Indication "0"
FM
MW
Dummy load
Exclusive dummy load should be used for AM,and FM.
For FM dummy load, there is a loss of 6dB between SSG output
and antenna input. The loss of 6dB need not be considered
since direct reading of figures are applied in this working
standard.
EXTGS004-26P
1 –3 87.5MHz –108.0MHz
531kHz –1602kHz
Frequency Band
Line-out Level / Impedance:
KD-SX975 : 4.0 V 20 k load (full scale)
KD-SX875 : 2.0 V 20 k load (full scale)
BBE:OFF
EXTGS004-26P

1-11
KD-SX883
When the pickup correctly moves
to the inner area of the disc
Microprocessor
commands
FMO
TC9462"53"
FEED MOTOR
+TERMINAL
IC581" 6 "
REST SW
When correctly focused
Focus Servo Loop ON
Power ON
Set Function CD
Disc inserted
Pickup feed to the inner area
YES
Laser emitted
Focus search
YES
Disc rotates
RF signal eye-pattern
remains closed
Tracking loop closed
RF signal eye-pattern
opens
TOC readout
Jump to the first track
Play
When the laser diode correctly
emits
Microprocessor
commands
SEL
TC9462
LD
CN501
"No disc"
display
When the disc correctly rotates
Microprocessor
commands
DMO
TC9462
Spindle
motor(-)
IC581" 5 "
Tracking Servo Loop ON
RF signal
Rough Servo Mode
CLV Servo Mode
(Program Area)
CLV Servo Mode
(Lead-In Area;
Digital: 0)
Flow of functional operation unit TOC read
$83 $82 $81
0V
6V
4V
2V
OFF
ON
5V
Hi-Z
FEO
TA2109 14
2.2V
$84
5V
0V
4V
0V
57
55
$84 $86 $ A200
5V
2.2V
0V
6V
3.2
2V
Rough
Servo
Acceleration Servo CLV
0.5 Sec0.5 Sec
1

1-12
KD-SX883
Feed section
Focus section
Spindle section
Tracking section
Is the voltage output at
IC521 pin "53" 5V or 0V?
Is the wiring for IC521
(90)~(100) correct?
Is 5V present at IC581
pin "20"?
Check CD 9V
and 5V.
Check the vicinity of
IC521.
Check the feed motor
connection wiring.
Is 6V or 2V present at
IC581 " 6 " and " 7 "?
Check IC581.
Is 4V present at both
sides of the feed motor?
Check the feed motor.
YES
YES
NO YES NO
YES
NO
NO
NO
NO
NO
NO
NO
NO
YES
YES YES
YES
YES
YES
YES
YES YES
YES
YES
When the lens is
moving:
4V
Does the S-search
waveform appear at
IC581 pins "8" and "9"?
Check the circuits in
the vicinity of IC501
pins "8","9"and"15".
Check the pickup and
its connections.
Is the disk rotated?
Does the RF signal
appear at TP1?
Is the RF waveform at TP1
distorted?
Proceed to the Tracking
section
Is 4V present at IC581
pins "4" and "5"?
Check the spindle motor
and its wiring
Check the circuits in the
vicinity of IC501 "19"~
"24" or the pickup
Is 4V present at IC521
pins "55" ?
Check IC501 and
IC521.
Check the vicinity of
IC581.
When the disc is rotated
at first:
Approx. 1.2V
Is the tracking error signal
output at IC501 "12"?
Check IC521.
Check the circuit in the
vicinity of IC501 pins
"2"~"12".
Check the pickup and
its connections.
NO

1-13
KD-SX883
Maintenance of laser pickup
(1) Cleaning the pick up lens
Before you replace the pick up,please try to
clean the lens with a alcohol soaked cotton
swab.
(2) Life of the laser diode
When the life of the laser diode has expired,
the following symptoms will appear.
(1) The level of RF output (EFM output:ampli-
tude of eye pattern) will be low.
(3) Semi-fixed resistor on the APC PC board
The semi-fixed resistor on the APC printed
circuit board which is attached to the pickup
is used to adjust the laser power. Since this
adjustment should be performed to match the
characteristics of the whole optical block,
do not touch the semi-fixed resistor.
If the laser power is lower than the specified
value, the laser diode is almost worn out, and
the laser pickup should be replaced.
If the semi-fixed resistor is adjusted while
the pickup is functioning normally, the laser
pickup may be damaged due to excessive current.
Is RF output
1.3 0.4Vp-p?
YES
NO
O.K
Replace it.
Replacement of laser pickup
Turn off the power switch and,disconnect the
power cord.
Replace the pickup with a normal one.(Refer
to "Pickup Removal" on the previous page)
Plug the power cord in, and turn the power on.
At this time, check that the laser emits for
about 3seconds and the objective lens moves
up and down.
Note: Do not observe the laser beam directly.
Play a disc.
Check the eye-pattern at TP1.
Finish.

1-14
KD-SX883
Description of major ICs
VCC2
V05-
V05+
V04+
V04-
V03+
V03-
V02+
V02-
V01+
V01-
VCC1
VIN1
VIN1G
FR
REV
FWD
S-GND
VCONT
VIN4
VIN4G
VCC-S
VREF-IN
REG-OUT
REG-IN
VIN3G
VIN3
VIN2G
VIN2
FR
28
27
26
25
24
23
22
21
20
19
18
17
16
15
FR
1
2
3
4
5
6
7
8
9
10
11
12
13
14
FR
CH 3,4,5
Power supply
Output control
CH5
CH4
CH2
CH1
CH3
22K 11K
5VREG(PNPTr
The outside putting)
22K
22K
22K
11K
11K
11K
CH1,2
Power supply
LA6567H-X (IC581) : CD driver
1.Pin layout & Block diagram
Level shiftLevel shiftLevel shiftLevel shift
Thermal shutdown
Input
Signal system power supply

1-15
KD-SX883
2. Pin function
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Pin no. Symbol
CH3,4,5 Power supply( It is short with VCC1,VCC-S)
Loading output(-)
Loading terminal (+)
CH4 Output terminal(+)
CH4 Output terminal(-)
CH3 Output terminal(+)
CH3 Output terminal(-)
CH2 Output terminal(+)
CH2 Output terminal(-)
CH1 Output terminal(+)
CH1 Output terminal(-)
CH1,2(BTL) Power supply(It is short with VCC-S,VCC2)
CH1 Input terminal
CH1 Input terminal(For gain adjustment)
CH2 Input terminal
CH2 Input terminal(For gain adjustment)
CH3 Input terminal
CH3 Input terminal(For gain adjustment)
Regulator terminal(Outside putting PNP base)
Regulator terminal(Outside putting PNP collector)
Standard voltage input terminal
Signal system power supply(It is short with VCC1,VCC2)
CH4 Input terminal(For gain adjustment)
CH4 Input terminal
5CH(VLO) Output voltage set terminal
Signal system GND
5CH(VLO)Signal output switch terminal(FWD),Input of logic of loading part
5CH(VLO)Signal output switch terminal(REV),
Input of logic of loading part
Function
VCC2
V05-
V05+
V04+
V04-
V03+
V03-
V02+
V02-
V01+
V01-
VCC1
VIN1
VIN1G
VIN2
VIN2G
VIN3
VIN3G
REG-IN
REG-OUT
VREF-IN
VCC-S
VIN4G
VIN4
VCONT
S-GND
FWD
REV
LA6567H-X(2/2)
Frame(FR)at the center becomes system GND.
Please be short-circuited on the outside and use the terminal of the power supply system
and three teminals of VCC-S, VCC1,VCC2.

1-16
KD-SX883
1.Block diagram
1~66
67~69
70
71
72
73
74
75
76
77
78
79
80
S3~S68
COM1~3
VDD
VDD1
VDD2
VSS
OSC
INH
CE
CLOCK
DI
DIMMER
NC
Segment Output.
Common Driver Output.
Power Supply Connection.
Used for applying the LCD drive 2/3 bias voltage externally.
Must be connected to VDD2 when a 1/2 bias drive scheme in used.
Used for applying the LCD drive 1/3 bias voltage externally.
Must be connected to VDD1 when a 1/2 bias drive scheme in used.
Power supply connection.
Oscillator connection. An oscillator circuit is formed by connecting an
external resistor and capacitor to this pin.
Display off control input.
Chip enable input.
Synchronization clock input.
Serial data input.
DIMMER Control signal output.
Non connect.
O
O
-
I
I
-
I/O
I
I
I
I
O
-
Pin No. Symbol Description
I/O
2.Pin functions
LC75873NW (IC601) : LCD driver
VDD1
VDD2
INH
OSC
VDD
VSS
COMMOM
DRIVER
CLOCK
GENERATOR
SEGMENT DRIVER
SHIFT REGISTER
ADDRESS
DETECTOR
COM3
COM2
COM1
S68
S67
S5
S4/P4
S3/P3
S2/P2
S1/P1

1-17
KD-SX883
2
1
11
12
10
15 13
14
5
4
6
3
8
9
7
ILM AJGND GND
C6
10u
C5
0.1u
C4
0.1u
C3
0.1u
AUDIO OUT
CD OUT
CTRL
ANT CTRL
EXT OUT
ANT OUT
VCC ACC
Surge Protector
BIAS TSD
C1
100u C2
0.1u
+B
ACC
BATT.DET OUT
COMPOUT
VDD OUT
SW5VOUT
ILMOUT
C7
0.1u
C8
0.1u
R1
UNIT R:
C:F
note1) TAB (header of IC)
connected to GND
HA13164A (IC961) : Regulator
1.Pin layout
2.Block diagram
3.Pin function
Pin No. Symbol Function
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
EXTOUT
ANTOUT
ACCIN
VDDOUT
SW5VOUT
COMPOUT
ANT CTRL
VCC
BATT DET
AUDIO OUT
CTRL
CD OUT
ILM AJ
ILM OUT
GND
Output voltage is VCC-1 V when M or H level applied to CTRL pin.
Output voltage is VCC-1 V when M or H level to CTRL pin and H level
to ANT-CTRL.
Connected to ACC.
Regular 5.7V.
Output voltage is 5V when M or H level applied to CTRL pin.
Output for ACC detector.
L:ANT output OFF , H:ANT output ON
Connected to VCC.
Low battery detect.
Output voltage is 9V when M or H level applied to CTRL pin.
L:BIAS OFF, M:BIAS ON, H:CD ON
Output voltage is 8V when H level applied to CTRL pin.
Adjustment pin for ILM output voltage.
Output voltage is 10V when M or H level applied to CTRL pin.
Connected to GND.
123456789101112131415
TAB

1-18
KD-SX883
11
6 20
1
4
10
15
25
13
14
16
12
9
8
5
7
2
22
17
19
18
21
23
24
3
-
+
-
+
-
+
-
+
-
+
-
+
-
+
-
+
IN 1
IN 2
ST BY
Vcc 1/2 Vcc 3/4
OUT 1+
OUT 1-
PWR GND1
OUT 2+
OUT 2-
PWR GND2
R.F
IN 3
IN 4
PRE GND
ON TIME C Muting &
ON Time Control
Circuit
Protective
circuit
Protective
circuit
Mute
circuit
Ripple
Filter
Stand by
Switch
N.C
+
+
0.22 F
2200 F 0.022
F
0.22 F
TAB
+5V
ST ON
+
+
+
+
47 F
0.22 F
0.22 F
22 F
+
Mute 10K
+
3.3 F
OUT 3+
OUT 3-
Low Level
Mute ON
PWR GND3
OUT 4+
OUT 4-
PWR GND4
LA4743K (IC351) : Power amp
1.Block diagram

1-19
KD-SX883
2.Terminal layout
3.Pin function LA4743B
TAB
GND
OUTRR-
STBY
OUTRR+
VCC1/2
OUTRF-
GND
OUTRF+
RIPPLE
INRF
INRR
SGND
INLR
INLF
ONTIME
OUTLF+
GND
OUTLF-
VCC3/4
OUTLR+
MUTE
OUTLR-
GND
NC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
SymbolPin No. Function
Header of IC
Power GND
Outpur(-) for front Rch
Stand by input
Output (+) for front Rch
Power input
Output (-) for rear Rch
Power GND
Output (+) for rear Rch
Ripple filter
Rear Rch input
Front Rch input
Signal GND
Front Lch input
Rear Lch input
Power on time control
Output (+) for rear Lch
Power GND
Output (-) for rear Lch
Power input
Output (+) for front
Muting control input
Output (-) for front
Power GND
Non connection

1-20
KD-SX883
TA2109F-X (IC501) : RF amp.
1. Pin layout
2. Block diagram
3. Pin function
Pin function
24 13
112
1
2
3
4
5
6
7
8
9
10
11
12
-
I
I
I
I
I
O
I
I
O
I
O
Power supply input terminal
Main beam I-V amp input terminal
Main beam I-V amp input terminal
Sub beam I-v input terminal
Sub beam I-V input terminal
Monitor photo diode amp input terminal
Laser diode amp output terminal
Laser diode control signal input terminal
T. error balance adj. signal input terminal
Reference voltage output terminal
TE amp negative input terminal
TE error signal output terminal
Vcc
FNI
FPI
TPI
TNI
MDI
LDO
SEL
TEB
2VRO
TEN
TEO
12
11
10
9
8
7
6
5
4
3
2
1
13
14
15
16
17
18
19
20
21
22
23
24
SBAD
FEO
FEN
VRO
RFRP
RFIS
RFGO
RFGC
AGCI
RFO
GND
RFN
3.3k ohm 3.3k ohm
1.53k ohm
re=130 ohm
23.5k ohm 12k ohm
60k ohm
60k ohm
20k ohm
20k ohm
20k ohm
20k ohm
13k ohm
680 ohm
2.12k ohm
BOTTOM
PEAK
20k ohm
20k ohm
20k ohm
12k ohm 1.74k ohm
47k ohm
12k ohm
180k ohm
50uA
21k ohm
21k ohm
7.96k ohm
10k ohm
10k ohm
10k ohm
10k ohm
10pF
36pF
50k ohm
15k ohm 30k ohm 7.67k ohm
10k ohm
30k ohm
15k ohm
20uA
21k ohm 29k ohm
24k ohm 24k ohm
65uA
20pF
180k ohm
20pF
180k ohm
180k ohm
40pF
40pF
I-I
I-I
SW3
SW2
SW1
1k ohm
LDC
3 STATE
DET.
20pF
TEO
TEN
TEB
SEL
LDO
MDI
TNI
TPI
FPI
FNI
Vcc
2VRO
Pin
No.
Symbol I/O Pin function
13
14
15
16
17
18
19
20
21
22
23
24
O
O
I
O
O
I
O
I
I
O
-
I
Sub beam adder signal output terminal
Focus error signal output terminal
FE amp negative input terminal
Reference voltage (VREF) output terminal
Track count signal output terminal
RFRP detect circuit input terminal
RF gain signal output terminal
RF amplitude adj. control signal input terminal
RF signal amplitude adj. amp input terminal
RF signal output terminal
Ground terminal
RF amp negative input terminal
SBAD
FEO
FEN
VRO
RFRP
RFIS
RFGO
RFGC
AGCI
RFO
GND
RFN
Pin
No.
Symbol I/O
Other manuals for KD-SX883
1
Table of contents
Other JVC Car Receiver manuals

JVC
JVC CD Receiver KD-SHX701 User manual

JVC
JVC KD-R730BT User manual

JVC
JVC KS-FX281 User manual

JVC
JVC KW-R700BT User manual

JVC
JVC EXAD KD-LHX601 Guide

JVC
JVC KD-PDR41 User manual

JVC
JVC Arsenal KD-AHD39 User manual

JVC
JVC KD-A815 Guide

JVC
JVC KS-FX385 Administrator Guide

JVC
JVC KD-AHD59 - Radio / HD User manual
