JVC KW-V960BW User manual

Hi-Res Audio logo and Hi-Res Audio
Wireless logo are used under license
from Japan Audio Society.
IM405_ref_K_En_11 (K)© 2020 JVCKENWOOD Corporation
MONITOR WITH DVD RECEIVER
KW-V960BW
MONITOR WITH RECEIVER
KW-M865BW
INSTRUCTION MANUAL
• Updated information (the latest Instruction Manual, system updates, new
functions, etc.) is available from
<https://www.jvc.net/cs/car/>.

2
Important Notice on Software
Ñ Software License on This
Product
The software embedded in this product
comprises a number of independent software
components, each of which is copyrighted by
JVCKENWOOD Corporation or by a third party.
This product uses software components that
are based on an End-User License Agreement
(hereinafter called “EULA”) stipulated by
JVCKENWOOD Corporation and by third parties.
The EULA dictates the availability of the source
codes of free-software components as a
prerequisite to distributing them in executable
form under the terms of the GNU General
Public License or the Lesser General Public
License (hereinafter called “GPL/LGPL”). To get
information about the software components
that are subject to the terms of the GPL/LGPL,
please visit the following Website:
Website URL https://www3.jvckenwood.com/
english/download/gpl/
Queries concerning the contents of the source
code or the like will not be accepted.
Please note that software components based
on a EULA that is not subject to the terms of the
GPL/LGPL or those that have been developed
or created by JVCKENWOOD Corporation will
be excluded from the scope of source code
disclosure.
Because licenses to use software components
distributed under the GPL/LGPL are offered to
the customers for free of charge, no warranty is
granted to the customers, whether explicitly or
implicitly, to the extent of the applicable laws.
Unless otherwise stipulated by the applicable
laws or agreed upon in writing, the copyright
holders or those who are entitled to modify
and redistribute the software components are
not held responsible for any and all damages
resulting from their use or from inability to use
them. For more information about the terms of
use of the software components, required items
of compliance and so on, please refer to the
GPL/LGPL.
Customers wishing themselves to use a software
component that is subject to the GPL/LGPL
embedded in this product are encouraged to
read the terms of the corresponding license
before use. Because each individual license
is prescribed by a third party other than
JVCKENWOOD Corporation, the original (English)
of the license is presented.
EULA
Ñ Software License Agreement
JVCKENWOOD Corporation (hereinafter called
“Licensor”) holds either the copyright to the
embedded software or the right to sublicense it.
This agreement establishes the conditions under
which the customer uses this “Licensed Software.”
The customer shall agree to the terms of this
license agreement before proceeding to use
Licensed Software.
This agreement is deemed to have taken effect
when the customer (hereinafter called“User”)
has used a product implementation of Licensed
Software.
The Licensed Software may contain software
Licensor has been licensed to use by third parties
directly or indirectly. Some third parties may
have terms of use prescribed for their customers,
apart from this Software License Agreement. This
agreement does not apply to such software. Be
sure to consult“Important Notice on Software”as
presented separately.
Article 1 (General)
Licensor grants to User a non-exclusive, non-
assignable right of use Licensed Software
within the country where the User purchases
the Product (hereinafter the "Country") (except
for the exception provided for in Paragraph 1,
Article 3).
Article 2 (Right of Use)
1. The rise of use granted under this agreement
is the right to use Licensed Software in this
product.
2. User may not duplicate, copy, modify, add to,
translate or otherwise alter, or loan licensed
Software and the associated literature in
whole or in part.
3. Use of Licensed Software is limited to a private
extent , and Licensed Software may not be
distributed, licensed or sublicensed for any
purposes whatsoever, including commercial
use.
4. User shall use Licensed Software as per the
instruction manual or instructions given in the
help file and may not use or duplicate data in
violations of the regulations of the Copyright
Law or other governing laws by using
Licensed Software in whole or in part.

3
Article 3 (Terms of License)
1. In assigning this product, User may not retain
the original copy of the embedded Licensed
Software (including associated literature,
updates and upgrades) and any duplicates
and associated literature with regard to
the license to use Licensed Software. User
may transfer Licensed Software only to the
condition of binding the assignee to abide by
the terms of this Software License Agreement.
2. User may not reverse-engineer, disassemble,
decompile or otherwise analyze the source
code of Licensed Software.
Article 4 (Rights to Licensed Software)
All rights to Licensed Software and the
associated literature, including copyrights, shall
reside with Licensor or
the original right holder who has granted the
Right of Use and right to sublicense to Licensor
(hereinafter referred to as “Original Right
Holder”), and User does not have any rights
other than Right of Use granted hereunder
with regard to Licensed Software and the
associated literature.
Article 5 (Exemption Granted to Licensor)
1. Licensor and Original Right Holder do not
assume any responsibility for damages
caused to User or third parties resulting from
the exercise by User of the license granted
hereunder, unless otherwise provided by any
law to the contrary.
2. Licensor does not warrant Licensed Software
to be merchantable, compatible and fit for
specific purposes.
Article 6 (Responsibility for Third Parties)
If disputes over the infringement of third
parties’ intellectual property rights, such as
copyrights and patent rights, arise out of the
use of Licensed Software by User, User shall
resolve these disputes at User’s own expenses
while keep Licensor and Original Right Holder
harmless.
Article 7 (Secrecy Obligation)
User shall keep confidential Licensed Software
provided hereunder, information contained in
the associated literature or the like and those
provisions of this agreement not yet in public
knowledge and may not disclose or leak these to
third parties without prior written consent from
Licensor.
Article 8 (Cancellation of the Agreement)
Licensor reserves the right to cancel this
agreement forthwith and claim compensation
from User for the damages caused by such
cancellation when User:
(1) Breaches any of the provisions of this
agreement, or
(2) Has received a petition for seizure, provisional
seizure, provisional disposition or any other
kind of compulsory execution.
Article 9 (Destruction of Licensed Software)
If this agreement is terminated under the
provision of the foregoing paragraph, User
shall destroy Licensed Software, along with all
associated literature and its duplicates, within
two (2) weeks from the date of termination.
Article 10 (Copyright Protection)
1. Copyrights and all other intellectual property
rights relating to Licensed Software shall
reside with Licensor and Original Right Holder
and in no circumstances with User.
2. User shall abide by the laws relating to
copyrights and intellectual property rights in
using Licensed Software.
Article 11 (Export Control)
1. Licensed Software and the associated
literature or the like may not be exported
to places outside the Country (including
transmission outside the Country over the
Internet or the like).
2. User agrees that Licensed Software is subject
to export controls imposed by the Country
and the United States of America.
3. User agrees to comply with all the
international and domestic laws that apply
to this software (U.S. Export Administration
Regulations and regulations established by
the U.S., the Country and their governmental
agencies regarding usage by end users and
export destinations).
Article 12 (Miscellaneous)
1. Even if this agreement is invalidated in part by
law, all other provisions shall remain in effect.
2. Licensor and User shall consult each other in
good faith to resolve any matters not provided
for in this agreement or questions arising from
the interpretation of this agreement.
3. Licensor and User agree that this agreement
is governed by the law of Japan and that all
disputes involving claims and obligations that
may arise out of this agreement will be settled
by arbitration at the Tokyo District Court as the
court of first instance.

4
Contents
Before Use 6
Precautions................................................................... 6
How to read this manual ......................................... 7
Basic Operations 8
Functions of the Buttons on the Front Panel ... 8
Turning on the Unit ................................................... 9
Initial Settings.............................................................. 9
Adjusting the volume.............................................12
Touch screen operations .......................................12
Popup menu ..............................................................13
HOME screen descriptions....................................14
Source selection screen description..................14
Source control screen descriptions ...................17
List screen ...................................................................18
Widget 19
Widget Basic Operation .........................................19
Photo Frame Widget ...............................................19
Widget SETUP............................................................20
Disc 21
Playing a disc .............................................................21
DVD/VCD Basic Operation ....................................21
Music CD/Disc media Basic Operation .............23
File search Operation..............................................24
DVD Disc Menu Operation....................................25
DVD SETUP .................................................................26
APPS 27
Apple CarPlay Operation .......................................27
Android Auto Operation........................................30
Wireless Mirroring Operation...............................32
USB Mirroring Operation.......................................33
USB 35
Connecting a USB device ......................................35
USB Basic Operation................................................35
Search Operation......................................................37
iPod/iPhone 38
Preparation.................................................................38
iPod/iPhone Basic Operation ...............................39
Search Operation......................................................40
Tuner 41
Tuner Basic Operation ............................................41
Memory Operation ..................................................42
Selecting Operation ................................................42
Traffic Information ...................................................43
Tuner SETUP...............................................................43
SiriusXM® 44
SiriusXM® Basic Operation ....................................44
Storing Channels in Preset Memory..................46
Preset select ...............................................................46
Direct search ..............................................................46
Category/Channel search......................................47
Replay...........................................................................47
TuneMix™ ....................................................................48
SmartFavorites, TuneStart™ ..................................48
TuneScan™..................................................................48
Traffic & Weather Now™.........................................49
Content Alerts............................................................49
SportsFlash™ ..............................................................50
SiriusXM SETUP .........................................................50

5English
Other External Components 56
View Camera ..............................................................56
External audio/video players (AV-IN).................58
OEM Features Operation .......................................59
Bluetooth Control 60
Information for using Bluetooth® devices.......60
Register the Bluetooth device .............................60
Bluetooth Setup........................................................62
Playing the Bluetooth Audio Device .................64
Using the Hands-Free Unit....................................66
Hands-Free Setup.....................................................71
Setup 72
Monitor Screen Setup.............................................72
System Setup .............................................................72
User Interface Setup................................................73
Special Setup .............................................................75
Display Setup.............................................................76
AV Setup ......................................................................78
Controlling Audio 79
3-way speaker system setup ................................79
Speaker / X’over setup............................................80
Controlling General Audio....................................82
Equalizer Control ......................................................82
Volume Offset............................................................83
Zone Control ..............................................................84
Sound Effect...............................................................85
Listening Position / DTA.........................................86
Audio Setup memory .............................................88
Remote control 89
Battery Installation...................................................89
Functions of the Remote control Buttons.......89
Connection/Installation 91
Before Installation ....................................................91
Installing the unit .....................................................93
Troubleshooting 98
Problems and Solutions.........................................98
Error Messages ..........................................................99
Appendix 101
Playable Media and Files..................................... 101
Region Codes in the World ................................ 103
DVD Language Codes.......................................... 104
Specifications.......................................................... 105
About this Unit....................................................... 108

Before Use
6
Before Use
Precautions
#WARNINGS
Ñ To prevent injury or fire, take
the following precautions:
• To prevent a short circuit, never put or leave
any metallic objects (such as coins or metallic
tools) inside the unit.
• Do not watch or fix your eyes on the unit’s
display when you are driving for any extended
period.
• If you experience problems during installation,
consult your JVC dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories,
check with your JVC dealer to make sure that
they work with your model and in your area.
• You can select a language to display menus,
audio file tags, etc. See User Interface Setup
(P.73).
• The Radio Data System or Radio Broadcast
Data System feature won’t work in areas
where the service is not supported by any
broadcasting station.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ball point pen or
similar tool with a sharp tip.
Ñ Cleaning the unit
• If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe it with
a cloth moistened with neutral cleaner, then
wipe it again with a clean soft dry cloth.
NOTE
• Applying spray cleaner directly to the unit
may damage its mechanical parts. Wiping the
faceplate with a hard cloth or using a volatile
liquid such as thinner or alcohol may scratch the
surface or erase the screened print.
Ñ Lens fogging
When you turn on the car heater in cold
weather, dew may form on the lens in the
disc player of the unit due to condensation.
This condensation on the lens (also called lens
fogging) may not allow discs to play. In such a
situation, remove the disc and wait for the dew
to evaporate. If the unit still does not operate
normally after a while, consult your JVC dealer.
Ñ Precautions on handling discs
• Do not touch the recording surface of the disc.
• Do not stick tape etc. on the disc, or use a disc
with tape stuck on it.
• Do not use disc type accessories.
• Clean the disc from the center toward the
outside rim.
• When removing a disc from this unit, pull it out
horizontally.
• If the disc center hole or outside rim has burrs,
use the disc only after removing the burrs with
a ballpoint pen etc.
• Discs that are not round cannot be used.
• 8-cm (3 inch) discs cannot be used.
• Discs with coloring on the recording surface or
discs that are dirty cannot be used.
• This unit can only play the following types of
CDs.
• This unit may not correctly play discs which do
not have the mark.
• You cannot play a disc that has not been
finalized. (For the finalization process, see
your writing software and your recorder's
instruction manual.)

Before Use
7English
Ñ Acquiring GPS signal
The first time you turn on this unit, you must
wait while the system acquires satellite signals
for the first time. This process could take up
to several minutes. Make sure your vehicle
is outdoors in an open area away from tall
buildings and trees for fastest acquisition.
After the system acquires satellites for the first
time, it will acquire satellites quickly each time
thereafter.
Ñ About GLONASS
This unit uses Global Navigation Satellite System
(GLONASS) in addition to GPS.
Combining GPS and GLONASS can refine
positioning accuracy than using GPS only.
Ñ Caution for Smartphone Users
Simultaneously running multiple applications
on your smartphone while screen sharing places
heavy demand on the microprocessor of the
phone, potentially affecting communication and
performance.
For best results while pairing with your JVC
receiver, please be sure to close any unused
applications.
How to read this manual
• The screens and panels shown in this manual are
examples used to provide a clear explanation of
operations.
For this reason, they may be different from the actual
screens or panels, or some display patterns may be
different from the actual ones.
• Display language: English is used for the purpose
of explanation. You can select a display language
from the [SETUP]menu. See User Interface Setup
(P.73).

Basic Operations
8
Basic Operations
Functions of the Buttons on the Front Panel
KW-V960BW
1 2 3 4
KW-M865BW
1 3 4
NOTE
• The panels shown in this manual are examples used to provide a clear explanation of operations. For this reason,
they may be different from the actual panels.
Number Name Motion
1
–, +
(Volume)
• Adjusts the volume.
The volume will go up to 15 when you keep pressing [+]. (P.12)
2
Disc insert
slot
• A slot to insert a disc media.
3
FNC • Displays the popup menu screen.
• Pressing for 1 second starts the voice recognition function (P.68). While Apple
CarPlay or Android Auto is connected, starts the function on the Apple CarPlay or the
Android Auto screen.
• When neither Apple CarPlay, Android Auto, nor a Bluetooth Hands-Free phone is
connected, pressing and holding displays Bluetooth pairing waiting dialog. (P.60)
• When the power is off, turns the power on.
4
Remote
Sensor
• Receives the remote control signal.

Basic Operations
9English
Turning on the Unit
1
Press the [FNC]button.
 The unit is turned on.
NOTE
• If it is your first time to turn the unit on after
installation, it will be necessary to perform Initial
SETUP (P.9).
●To turn off the unit:
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
3
Touch [ ].
4
Touch [Power Off].
Initial Settings
Initial SETUP
Perform this setup when you use this unit first
time.
1
Set each item as follows.
■[Language]
Select the language used for the control
screen and setting items. Default is“American
English(en)”.
1Touch [Language].
2Touch [Language Select].
3Select the desired language.
4Touch [
].
For details, see User Interface Setup
(P.73).
■[Clock]
Sets the synchronization of the clock and
adjusts it.
For details, see Calendar/clock settings
(P.11).
■[Display]
Set the display dimmer mode.
If it is hard to see the image on the screen
even, adjust the viewing angle.
1Touch [Display].
2Touch [Viewing Angle].
3Select a viewing angle.
4Touch [
].
For details, see Display Setup (P.76).

Basic Operations
10
■[Camera]
Set the parameters for the camera.
1Touch [Camera].
2Set each item and touch [
].
For details, see Camera Setup (P.56).
■[OEM SETUP]
This function requires a commercial adaptor.
Consult your JVC dealer for details.
■[DEMO]
Set the demonstration mode. Default is “ON”.
2
Touch [Finish].
NOTE
• These settings can be made from the SETUP
menu. See Setup (P.72).
Security Code Setup
You can set up a security code to protect your
receiver system against theft.
When the Security Code function is activated,
the code cannot be changed and the function
cannot be deactivated. Note that the Security
Code can be set with a 4 to 8 digit number of
your choice.
Preparation
• Set [DEMO]to [OFF]in the Special screen.
(P.75)
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
3
Touch [ ].
4
Touch [Security].
 Security screen appears.
5
Touch [Security Code Set]on the Security
screen.
 Security Code Set screen appears.

Basic Operations
11English
6
Enter a security code with 4 to 8 digits
and touch [Enter].
7
Enter the same code again and touch
[Enter].
Now, your security code is registered.
NOTE
• Touch [BS]to delete the last entry.
• If you enter a different security code, the
procedure returns to step 6 (for first code entry).
• If you have disconnected the Receiver from the
battery, enter the correct security code as that
you have entered in step 6 and touch [Enter]. You
can use your receiver.
To change the security code:
1
Touch [Security Code Change]on the
Security screen.
 Security Code Set screen appears.
2
Enter the current registered security code
and touch [Enter].
3
Enter a new security code with 4 to 8
digit number and touch [Enter].
4
Enter the same code again and touch
[Enter].
The new security code is registered.
To clear the security code:
1
Touch [Security Code Cancellation]on
the Security screen.
 Security Code Set screen appears.
2
Enter the current registered security code
and touch [Enter].
The security code is cleared.
Calendar/clock settings
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
3
Touch [ ].
4
Touch [User Interface].
 User Interface screen appears.
5
Touch [Time Zone].
6
Select the time zone.
7
Set each item as follows.
Scroll the page to show hidden items.

Basic Operations
12
■[Time Format]
Select the time display format.
[12-Hour](Default)/[24-Hour]
■[Clock]
[GPS-SYNC ](Default): Synchronizes the clock
time with the GPS.
[Manual]: Set the clock manually.
■[Time Zone]
Select the time zone.
■[Clock Adjust]
If you select [Manual]for Clock, adjust the
date and time manually. (P.75)
NOTE
• Please set the date and time. If they are not set,
some functions may not work.
Adjusting the volume
You can adjust the volume (0 to 40).
Press [+]to increase, and press [–]to decrease.
Holding [+]increases the volume continuously
to level 15.
Touch screen operations
To perform operations on the screen, you need
to touch, touch and hold, flick or swipe to
select an item, display a setting menu screen
or change pages.
●Touch
Touch the screen gently to
select an item on the screen.
●Touch and hold
Touch the screen and keep
your finger in place until
the display changes or a
message is displayed.
●Flick
Slide your finger quickly
to the left or right on the
screen to change the page.
You can scroll a list screen
by flicking up/down on the
screen.
●Swipe
Slide your finger up or down
on the screen to scroll the
screen.
Gesture Touch Control:
You can also control playback by moving your
finger on the touch panel as follows (for some
sources, the gesture touch control function is
not available).
• Sliding the finger upward/downward:
Equivalent to the operation of pressing []/
[](Media). Tuner Preset broadcast stations
are switched.
• Sliding the finger leftward/rightward:
Equivalent to the operation of pressing [E]
/ [F].
• Moving your finger clockwise or counter-
clockwise: Increases/decreases the volume.
On the HOME screen, you can control the
widget by sliding two fingers. (P.19)

Basic Operations
13English
Popup menu
1
Press the [FNC]button.
 Popup menu appears.
2
Touch to display the popup menu.
KW-V960BW
2
1
KW-M865BW
2
The contents of the menu are as follows.
• Displays the HOME screen. (P.14)
• Switches between screens.
The screen to be switched to depends
on the [DISP Key]setting on the User
Interface screen. (P.73)
• Touch and hold to turns the screen off.
• Displays the Screen Adjustment screen.
(P.72)
• Touch to eject the disc.
• Touch for 2 seconds to forcibly eject
the disc and then touch [Ye s ]after the
message is displayed.
KW-V960BW only
• Close the popup menu.
KW-M865BW only
• Displays the Android Auto device list. This
icon appears only when Android Auto is
connected and two or more devices can
be used as Android Auto source.
1
• Function key1 to 3: The current screen
changes to the one you have set. The
function key1 and 2 are set to [Camera]
and [Audio]function as default. For the
function setting, refer to Customize
popup menu functions (P.74).
– [
]: Displays the view camera screen.
(P.56)
– [
]: Displays the Audio screen.
(P.79)
• Touch and hold to display the Customize
FNC Menu screen. (P.74)
2
• Short-cut source icons: The source
changes to the one you have set with a
short-cut. For the short-cut setting, refer
to Customize Short-cut source icons on
HOME screen (P.16).
Turn off the screen
1
Touch and hold [DISP]on the popup
menu.
NOTE
• Touch the display to turn on the screen.
• To display the clock while the screen is off, it is
necessary to set “OSD Clock” to “ON”. (P.76)

Basic Operations
14
HOME screen descriptions
Most functions can be performed from the
HOME screen.
1
1 13 4 5
12
1
• Short-cut playback source icons (P.15)
2
• Current source information.
• Touch to display the control screen of the
current source.
3
• Displays the source selection screen. (P.15)
4
• Widget (P.19)
– You can change the display to big or split
widget mode by sliding 2 fingers upward/
downward.
5
• Displays the SETUP screen. (P.72)
Display the HOME screen
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
Source selection screen
description
You can display icons of all playback sources
and options on the source selection screen.
To change pages, flick your finger leftward/
rightward on the screen.
2
3 4
1
1
• Changes playback sources.
For playback sources, see Select the
playback source (P.15).
2
• Page indication
3
• Returns to the previous screen.
4
• Displays the SETUP screen. (P.72)

Basic Operations
15English
Select the playback source
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
3
Touch [ ].
From the screen, you can select the
following sources and functions.
• Switches to the Apple CarPlay screen
from the connected iPhone. (P.27)
• Switches to the Android Auto
screen from the connected Android
smartphone. (P.30)
• Displays the Hands Free screen. (P.66)
When neither Apple CarPlay, Android
Auto, nor a Bluetooth Hands-Free phone
is connected, displays Bluetooth pairing
waiting dialog. *1(P.60)
• Switches to the Radio broadcast.
(P.41)
• Switches to the SiriusXM® satellite radio
broadcast. (P.44)
• Plays a Bluetooth audio player. (P.64)
• Plays a disc. *2(P.21)
• Plays an iPod/iPhone. (P.38)
• Plays files on a USB device. (P.35)
• Switches to an external component
connected to the AV-IN input terminal. *3
(P.58)
• Displays the Wireless Mirroring screen.
(P.32)
• Switches to the USB Mirroring screen
from the connected iPhone/Android
smartphone. (P.33)
• Displays the Audio screen. (P.79)
• Displays the screen you have set in the
Customize Favorite Key screen. (P.74)
• Touch and hold to display the Customize
Favorite Key screen. *4
• Turns off the AV source. (P.16)
• Turns off the unit. (P.9)
• For sources and information displayed when
an ADS adapter is connected, see OEM
Features Operation (P.59).
*1When connecting as Apple CarPlay or Android
Auto, it works as a phone provided in Apple
CarPlay or Android Auto. If Apple CarPlay or
Android Auto are connected during talking by
the Bluetooth device or iDatalink phone, the
current call will be continued.
*2KW-V960BW only
*3This can be selected when the AV-IN is set to
[NONE]on the Camera Assignment Setting
screen.
*4This function is enabled on the HOME screen.
To select the playback source on the
HOME screen
The 4 items displayed on the source selection
screen with large icons are shown on the
HOME screen.
You can change the items displayed on this
area by customizing the source selection
screen. (P.16)

Basic Operations
16
To select the playback source on the
source control screen
Display source selection keys by touching
[ ]/[ ] or flicking left or right on the source
control screen, then select a playback source.
To turn off the AV source
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
3
Touch [ ].
4
Touch [AV Off].
Customize Short-cut source icons
on HOME screen
You can arrange the positions of the source
icons as you like.
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
3
Touch [ ].
4
Touch and hold the icon which you want
to move in the customizing mode.
5
Drag the icon to the desired position.
Changes the page

Basic Operations
17English
Source control screen
descriptions
There are some functions which can be
performed from most screens.
Indicators
5
6
7
8
1 2
3
4
Short-cut source icons
1
All sources icon
Displays the source selection screen. (P.15)
2
Secondary screen
• [
]/[ ] : The Secondary screen changes to
another one every time you touch it. You can
also change the Secondary screen by flicking
left or right on the screen.
• Indicators: Displays the current source
condition and so on.
– [ATT]: The attenuator is active.
– [DUAL]: The dual zone function is active.
– [LOUD]: The loudness control function is active.
• Short-cut source icons: The source changes to
the one you have set with a short-cut. For the
short-cut setting, refer to Customize Short-
cut source icons on HOME screen (P.16).
3
Content list
Displays the track/file/station/channel list.
4
Connected Bluetooth device information.
5
Artwork & information
You can select whether to display an artwork
and song information or only song information
in more detail.
Touching the artwork area switches to the VU
meter. (The Disc, USB, iPod, Bluetooth audio
sources only)
Change the text size of song information smaller
when the “Small Audio Text” is set to “ON” in the
User Interface screen. (P.73)
6
Function panel
Touch the left side of the screen to display the
function panel. Touch again to close the panel.
7
HOME key
Displays the HOME screen. (P.14)
8
Operation keys
You can operate the current source with these
operation keys. The available functions are
different depending on the source type.

Basic Operations
18
List screen
There are some common function keys in the
list screens of most sources.
(P.24, 37, 40, 66)
Display the list screen
For Disc media/USB/iPod:
1
Touch [1]or the item listed on the
information area in the source control
screen.
 The list screen appears.
For Bluetooth audio:
1
Touch [1].
 The list screen appears.
You can use following operation keys from this
screen.
61 2
3 4 5
1
Displays the list type selection window.
2
Displays a music/movie file list.
3
Text scroll
Scrolls the displayed text.
4
etc.
Keys with various functions are displayed here.
• : Plays all tracks in the folder containing
the current track.
• : Jumps to the letter you entered
(alphabetical search).
• : Moves to the upper hierarchy
level.
5
[ ] / [ ] / [ ] / [ ] Page scroll
You can change pages to display more items by
touching [
]/[ ].
• [
]/[ ] : Displays the top or bottom page.
6
Return
Returns to the previous screen.
NOTE
• Depending on the current source or mode, some
function key may not appear.

Widget
19English
Widget
Widget Basic Operation
Big widget
Split widget
Widget list
• Clock/Spectrum analyzer Widget
• Current source information Widget
• Compass Widget
• Climate/TPMS/Radar Widget *1
• VU meter Widget
• Photo Frame Widget
*1 Displayable widgets vary depending
on the type of the connected iDataLink
(commercially available) and the model of the
vehicle.
●To change the widget style
Touch the widget area. You can change the
displayed information or design.
●To change the widget
Slide two fingers leftward/rightward.
When the split widget mode is selected, you
should put the fingers on each of the windows
before slide.
●To change the widget format
Slide two fingers upward/downward to switch
between the big and the split widget mode.
Photo Frame Widget
You can display a slideshow of the image
files stored in the USB memory on the HOME
screen.
Ñ Preparation
• Select “ON” for Photo Frame Widget in the
Widget SETUP screen. (P.20)
●Acceptable Picture files
Max. Picture size
JPEG (.jpg, .jpeg) *25,000 × 5,000
PNG (.png) 1,000 × 1,000
BMP (.bmp) 1,000 × 1,000
• This unit can only play back files which are less
than 50 MB.
• The maximum number of files per device is
500.
• Picture files may not be played depending on
their condition.
*2 A progressive format is not supported.

Widget
20
Widget SETUP
Set up the widget on the HOME screen.
1 Press the [FNC]button.
 Popup menu appears.
2 Touch [ ].
 HOME screen appears.
3 Touch [ ].
 SETUP screen appears.
4 Touch [User Interface].
 User Interface screen appears.
5 Touch [Widget SETUP]in the User
Interface screen.
6 Set each item as follows.
■[Photo Frame Widget]
Determine whether to use the photo frame
widget.
"ON" (Default)/"OFF"
■[Photo Frame SETUP]
Make settings related to photo play display.
7 Touch [].
To Photo Frame Setup
1 Touch [Photo Frame SETUP]on the
Widget SETUP screen.
2 Set each item as follows.
■[Sort Order]
Specify a file sorting criterion.
"By Name(Ascending)"/
"By Name(Descending)"/
"By Date(Newest First)" (Default)/
"By Date(Oldest First)"
■[Slide Show Interval]
Specify the slideshow interval.
"5" (Default) to "30" seconds
■[Photo Frame is •••••]
Display help topics about the photo frame
widget.
3 Touch [].
