JVC KD-HDR44 User manual

2011 JVC Product Tech Guide
AV Receivers Specification
C M Y K
Specifications
SubwoofersAV Navigation AV Headunits Headunits Speakers
Sample Systems
Specs Specs
Amplifiers
2-DIN AV Receivers 1-DIN AV Receiver
KW-AVX840 KW-AVX740 KW-AVX640 KW-AVX77
CD Player
MP3/WMA/WAV Compatible with Tag ✔✔✔✔
AAC Compatible* ✔
JPEG/MPEG1, 2 Compatible ✔✔✔✔
CD-R/RW Compatible ✔✔✔✔
CD Text ✔✔✔✔
* Not compatible with DRM-protected music purchased from iTunes Store.
DVD Player
DVD-R/-RW, +R/+RW Compatible ✔✔✔✔
Video DAC 108MHz/12-bit 108MHz/12-bit 108MHz/12-bit 108MHz/12-bit
GIGA MP3 MULTI ✔✔✔✔
AAC Compatible* ✔
JPEG/MPEG1, 2 Compatible ✔✔✔✔
DivX®Compatible ✔✔✔
Dolby Pro Logic II ✔
Dolby Digital 2 ch 2 ch 2 ch 5.1 ch
Dual-Zone ✔✔
Video CD Playback ✔✔✔✔
Frequency Response 16 - 22,000Hz (DVD fs=48/96kHz) 16 - 22,000Hz (DVD fs=48/96kHz) 16 - 22,000Hz (DVD fs=48/96kHz) 16 - 22,000Hz (DVD fs=48kHz)
16 - 44,000Hz (DVD fs=96kHz)
16 - 20,000Hz (CD fs=44.1kHz) 16 - 20,000Hz (CD fs=44.1kHz) 16 - 20,000Hz (CD fs=44.1kHz) 16 - 20,000Hz (CD)
Dynamic Range 93dB (fs=48kHz) 93dB (fs=48kHz) 93dB (fs=48kHz) 93dB (fs=48kHz)
Signal-to-Noise Ratio 95dB (at 1kHz, fs=48kHz) 95dB (at 1kHz, fs=48kHz) 95dB (at 1kHz, fs=48kHz) 95dB (fs=48kHz)
Channel Separation 95dB (fs=48kHz) 95dB (fs=48kHz) 95dB (fs=48kHz) 85dB (at 1kHz, fs=48kHz)
Wow & Flutter Less than measureable limit Less than measureable limit Less than measureable limit Less than measurable limit
* Not compatible with DRM-protected music purchased from iTunes Store.
Bluetooth Control*1
Bluetooth Control ✔*2✔*2Ready*4✔
Compatibility Check Function ✔✔
Hands Free Call ✔✔✔*4(Redial) ✔
Audio Streaming & Control (A2DP1.2, AVRCP1.3) ✔✔✔*4✔
Text Message Display ✔*3✔*3✔*3
Voice Recognition Dialing ✔✔✔*4✔
Phone Book Access Profile (PBAP1.0) ✔✔
Phonebook Transfer Manual (400 Max.) Manual (400 Max.) Manual (100 Max.)
Mic Unit ✔✔✔*4✔
*1Available functions depend on cell phone. *2Bluetooth Adapter included *3Receipt notification only *4KS-BTA100 required
iPod/iPhone Control
iPod Control ✔(USB) ✔(USB) ✔(USB) ✔(USB/J-BUS*3)
iPhone Control ✔(USB) ✔(USB) ✔(USB) ✔(USB)
Battery Charge ✔(USB) ✔(USB) ✔(USB) ✔(USB/J-BUS*3)
iPod/iPhone Video File Playback ✔*2✔*2✔*2✔*2
2-Way Control for iPod/iPhone*1(Headunit/iPod or iPhone Mode) ✔(USB) ✔(USB) ✔(USB) ✔(USB)
External Mode for iPod/iPhone ✔(USB) ✔(USB) ✔(USB)
*1Compatibility with 2-way control for iPod/iPhone differs by model. *2KS-U30 required for iPod/iPhone video playback. Compatibility depends on iPod/iPhone. *3KS-PD100 required
USB
Position Rear (Cable) Rear (Cable) Rear (Cable) Rear (Cable)
MP3/WMA/WAV Compatible with Tag ✔✔✔✔
AAC Compatible*1✔
JPEG/MPEG1, 2 Compatible ✔✔✔✔
DivX®Compatible*2✔✔✔
iPod/iPhone Video Playback ✔(AV Plug*3) ✔(AV Plug*3) ✔(AV Plug*3) ✔(AV Plug*3)
iPod/iPhone Audio Playback ✔✔✔✔
*1Not compatible with DRM-protected music purchased from iTunes Store. *2DivX®files must be less than 2Mbps for playback on USB. *3KS-U30 required for iPod/iPhone video playback. Compatibility depends on iPod/iPhone.
Tuner
HD Radio Ready* Ready* Ready* Ready*
SAT Radio Ready ✔✔✔✔
Tuner Type HS-IVi HS-IVi HS-IVi HS-IVi
No. of Presets (AM + FM) 6 + 18 6 + 18 6 + 18 6 + 18
AM Frequency Range 530 - 1,700kHz 530 - 1,700kHz 530 - 1,700kHz 530 - 1,710kHz
Sensitivity 20µV 20µV 20µV 20µV
Selectivity 40dB 40dB 40dB 40dB
FM Frequency Range 87.9 - 107.9MHz 87.9 - 107.9MHz 87.9 - 107.9MHz 87.5 - 107.9MHz
Usable Sensitivity 9.3dBf (0.8µV/75Ω) 9.3dBf (0.8µV/75Ω) 9.3dBf (0.8µV/75Ω) 9.3dBf (0.8µV/75Ω)
50dB Quieting Sensitivity 16.3dBf (1.8µV/75Ω) 16.3dBf (1.8µV/75Ω) 16.3dBf (1.8µV/75Ω) 16.3dBf (1.8µV/75Ω)
Stereo Separation 40dB 40dB 40dB 40dB
* KT-HD300 required
Amplifier
Maximum Power Output 50W x 4 50W x 4 50W x 4 50W x 4
Continuous Power Output (RMS) 20W RMS x 4CH at 4Ω 1.0% THD* + N 20W RMS x 4CH at 4Ω 1.0% THD* + N 20W RMS x 4CH at 4Ω 1.0% THD* + N 20W RMS x 4CH at 4Ω 1.0% THD* + N
CEA-2006 Compliant
* Total Harmonic Distortion
MOS-FET Amp ✔✔✔✔
Audio DAC 192kHz/24bit 192kHz/24bit 192kHz/24bit 192kHz/24bi
Parametric iEQ 3-band 3-band 3-band
iEQ 7-band
HPF ✔✔✔✔
Headphone Surround ✔
AV Input ✔✔✔✔*
Front AUX Input ✔✔
Video Input (Camera) ✔✔✔
Line Pre-Output Terminals 3 (Front + Rear + Subwoofer) 3 (Front + Rear + Subwoofer) 3 (Front + Rear + Subwoofer)
5* (Front + Rear + Subwoofer + 2nd Audio for Dual Zone)
Center Channel Output ✔*
Second Audio Output ✔
Subwoofer Output with Level/Frequency Control ✔✔✔✔*
Composite Video Output ✔✔✔✔*
Frequency Response 40 - 20,000Hz 40 - 20,000Hz 40 - 20,000Hz 40 - 20,000Hz
Load Impedance 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable)
Pre-Output Level/Impedance 4.0V/20kΩ4.0V/20kΩ4.0V/20kΩ5.0V/20kΩ
Video Output 1.0Vp-p/75Ω1.0Vp-p/75Ω1.0Vp-p/75Ω1.0Vp-p/75Ω
Second Audio Output 1.1V/20kΩ2.5V/20kΩ
Video Input 1.0Vp-p/75Ω1.0Vp-p/75Ω1.0Vp-p/75Ω1.0Vp-p/75Ω
Audio Input 1.5V/20kΩ1.5V/20kΩ1.5V/20kΩ1.5V/20kΩ
* Gold-Plated Terminals
Monitor
Proximity Sensor ✔✔
Touch Panel ✔✔✔✔
Variable-Color Illumination ✔✔
TFT ON/OFF ✔✔✔✔
Multilingual Display ✔* ✔* ✔* ✔*
Portuguese Display ✔✔✔✔
Screen Size 7” wide 6.1” wide 6.1” wide Ultra wide (5.4” wide)
Number of Pixels 1,152,000 1,152,000 1,152,000 576,000
Color System NTSC/PAL NTSC/PAL NTSC/PAL NTSC/PAL
* English, Spanish, French, German, Italian, Dutch, Portuguese, Swedish, Danish, Russian
General
Motorized Slide-Out Face ✔✔
Detachable Control Panel ✔✔✔✔
Carrying Case ✔✔✔✔
Wireless Remote Control Type Ready Ready Ready Easy-Grip
Steering Wheel Remote Ready ✔✔✔✔
Headunit Installation Size (W x H x D) 7 3/16” x 4 3/8” x 6 5/16” (182 x 111 x 160mm) 7 3/16” x 4 3/8” x 6 5/16” (182 x 111 x 160mm) 7 3/16” x 4 3/8” x 6 5/16” (182 x 111 x 160mm) 7 3/16” x 2 1/16” x 6 5/16” (182 x 52 x 160mm)
Panel Size (W x H x D) 7 7/16” x 4 5/8” x 7/16” (188 x 117 x 10mm) 7 7/16” x 4 5/8” x 7/16” (188 x 117 x 10mm) 7 7/16” x 4 5/8” x 7/16” (188 x 117 x 10mm) 7 7/16” x 2 5/16” x 1/2” (188 x 58 x 12mm)
Detachable Face Plate (W x H x D) 6 3/4” x 3 7/8” x 1 7/16” (171 x 97 x 35mm) 6 3/4” x 3 13/16” x 1 7/16” (171 x 96 x 35mm) 6 3/4” x 3 13/16” x 1 7/16” (171 x 96 x 35mm) 6 11/16” x 2 5/16” x 7/8” (169 x 58 x 22mm)
Weight 2.8kg (6.2 lbs.) 2.3kg (5.1 lbs.) 2.3kg (5.1 lbs.) 2.2kg (4.9 lbs.)
AV Receivers

2011 JVC Product Tech Guide
C M Y K
CD Receivers Specification
Specifications
NTK-0786-32-2
CD Receivers
2-DIN CD Receivers 1-DIN CD Receivers
KW-HDR720 KW-XR810 KW-XR610 KD-R820BT KD-R720 KD-HDR70 KD-HDR44 KD-R620 KD-R520 KD-R420 KD-R320
CD Player
MP3/WMA Compatible with ✔✔✔✔✔✔✔✔✔✔✔
ID3 Tag/WMA Tag
CD-R/RW Compatible ✔✔✔✔✔✔✔✔✔✔✔
CD Text ✔✔✔✔✔✔✔✔✔✔✔
Frequency Response 5 - 20,000Hz 5 - 20,000Hz 5 - 20,000Hz 5 - 20,000Hz 5 - 20,000Hz 5 - 20,000Hz 5 - 20,000Hz 5 - 20,000Hz 5 - 20,000Hz 5 - 20,000Hz 5 - 20,000Hz
Signal-to-Noise Ratio 98dB 102dB 98dB 102dB 102dB 98dB 98dB 98dB 98dB 98dB 98dB
Channel Separation More than 85dB More than 85dB More than 85dB More than 85dB More than 85dB More than 85dB More than 85dB More than 85dB More than 85dB More than 85dB More than 85dB
Wow & Flutter Less than Less than Less than Less than Less than Less than Less than Less than Less than Less than Less than
measurable limit measurable limit measurable limit measurable limit measurable limit measurable limit measurable limit measurable limit measurable limit measurable limit measurable limit
Bluetooth Control*1
Bluetooth Control Ready*2✔*3Ready*5✔*3✔*6Ready*2Ready*2Ready*2Ready*2Ready*2Ready*2
Compatibility Check Mode ✔✔✔*6
Connects 2 Phones ✔✔*6
Switching 2 Cell Phones ✔
Hands Free Call ✔*2(Redial) ✔✔*5✔✔*6✔*2(Redial) ✔*2(Redial) ✔*2(Redial) ✔*2(Redial) ✔*2(Redial) ✔*2(Redial)
Audio Streaming & Control ✔*2✔✔*5✔✔*6✔*2✔*2✔*2✔*2✔*2✔*2
(A2DP1.2, AVRCP1.3)
Text Message Display ✔*4✔*3*4✔*4✔*4*6
Voice Recognition Dialing ✔*2✔✔*5✔✔*6✔*2✔*2✔*2✔*2✔*2✔*2
Phone Book Access Profile (PBAP1.0) ✔✔✔*6
Phonebook Transfer ✔✔*5✔✔*6
Mic unit ✔*2✔✔*5✔✔*6✔*2✔*2✔*2✔*2✔*2✔*2
*1Available functions depend on cell phone. *2KS-BTA100 required *3USB Bluetooth Adapter included *4Receipt notification only *5KS-BTA200 required *6KS-BTA50 required
iPod/iPhone Control
iPod Control ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB)
iPhone Control ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB)
Battery Charge ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB)
2 Connections for iPod/iPhone ✔(USB) ✔(USB) ✔(USB)
2-Way Control for iPod/iPhone*1✔*2(USB) ✔(USB) ✔(USB) ✔(USB) ✔(USB) ✔*2(USB) ✔(USB) ✔(USB)
(Headunit/iPod or iPhone Mode)
iTunes Tagging ✔(USB) ✔(USB)
External Mode for iPod/iPhone ✔(USB) ✔(USB) ✔(USB/ ✔(USB/ ✔(USB) ✔(USB) ✔(USB)
Application Mode) Application Mode)
*1Compatibility with 2-Way Control for iPod/iPhone differs by model. *2Switching from headunit mode to iPod/iPhone mode will pause your iPod/iPhone. For playback, please press “play” on your iPod/iPhone.
USB
Position Front Front/Rear Front Front/Rear Front/Rear Front Front Front Front
MP3/WMA Compatible with ✔✔✔✔✔✔✔✔✔
ID3 Tag/WMA Tag
WAV Compatible ✔✔✔
iPod/iPhone Audio Playback ✔✔✔✔✔✔✔✔
Tuner
HD Radio Built-in Ready* Ready* Ready* Ready* Built-in Built-in
SAT Radio Ready ✔✔✔✔
Tuner Type DiAS II HS-IVi HS-IVi HS-IVi HS-IVi DiAS II DiAS II HS-IVi HS-IVi HS-IVi HS-IVi
No. of Presets (AM + FM) 6 + 18 6 + 18 6 + 18 6 + 18 6 + 18 6 + 18 6 + 18 6 + 18 6 + 18 6 + 18 6 + 18
AM Frequency Range 530 - 1,700kHz 530 - 1,710kHz 530 - 1,710kHz 530 - 1,700kHz 530 - 1,700kHz 530 - 1,700kHz 530 - 1,700kHz 530 - 1,700kHz 530 - 1,700kHz 530 - 1,700kHz 530 - 1,700kHz
Sensitivity 20µV 20µV 20µV 20µV 20µV 20µV 20µV 20µV 20µV 20µV 20µV
Selectivity 70dB 40dB 40dB 40dB 40dB 70dB 70dB 40dB 40dB 40dB 40dB
FM Frequency Range 87.9 - 107.9MHz 87.5 - 107.9MHz 87.5 - 107.9MHz 87.9 - 107.9MHz 87.9 - 107.9MHz 87.9 - 107.9MHz 87.9 - 107.9MHz 87.9 - 107.9MHz 87.9 - 107.9MHz 87.9 - 107.9MHz 87.9 - 107.9MHz
Usable Sensitivity 11.3dBf (1µV/75Ω) 9.3dBf (0.8µV/75Ω) 9.3dBf (0.8µV/75Ω) 9.3dBf (0.8µV/75Ω) 9.3dBf (0.8µV/75Ω) 11.3dBf (1µV/75Ω) 11.3dBf (1µV/75Ω) 9.3dBf (0.8µV/75Ω) 9.3dBf (0.8µV/75Ω) 9.3dBf (0.8µV/75Ω) 9.3dBf (0.8µV/75Ω)
50dB Quieting Sensitivity 19.3dBf (2.5µV/75Ω) 16.3dBf (1.8µV/75Ω) 16.3dBf (1.8µV/75Ω) 16.3dBf (1.8µV/75Ω) 16.3dBf (1.8µV/75Ω) 19.3dBf (2.5µV/75Ω) 19.3dBf (2.5µV/75Ω) 16.3dBf (1.8µV/75Ω) 16.3dBf (1.8µV/75Ω) 16.3dBf (1.8µV/75Ω) 16.3dBf (1.8µV/75Ω)
Stereo Separation 48dB 40dB 40dB 40dB 40dB 48dB 48dB 40dB 40dB 40dB 40dB
* KT-HD300 required
Amplifier
Maximum Power Output 50W x 4 50W x 4 50W x 4 50W x 4 50W x 4 50W x 4 50W x 4 50W x 4 50W x 4 50W x 4 50W x 4
Continuous Power Output (RMS) 20W RMS x 4CH at 4Ω 20W RMS x 4CH at 4Ω20W RMS x 4CH at 4Ω20W RMS x 4CH at 4Ω20W RMS x 4CH at 4Ω20W RMS x 4CH at 4Ω20W RMS x 4CH at 4Ω20W RMS x 4CH at 4Ω20W RMS x 4CH at 4Ω20W RMS x 4CH at 4Ω20W RMS x 4CH at 4Ω
CEA-2006 Compliant 1.0% THD* + N  1.0% THD* + N 1.0% THD* + N 1.0% THD* + N 1.0% THD* + N 1.0% THD* + N 1.0% THD* + N 1.0% THD* + N  1.0% THD* + N  1.0% THD* + N 1.0% THD* + N
* Total Harmonic Distortion
MOS-FET Amp ✔✔✔✔✔✔✔✔✔✔✔
24-bit DAC ✔✔*1✔✔*1✔*1✔✔✔✔✔✔
Loudness Control ✔✔(3 patterns) ✔✔✔✔✔✔✔✔✔
Parametric iEQ 3-band 3-band 3-band 3-band 3-band 3-band 3-band 3-band 3-band 3-band 3-band
HPF ✔✔✔✔✔✔✔✔✔✔
Line Pre-Output Terminals 3 3 2*23 2*23 2*22*22*21*21*2
(Front + Rear + Subwoofer) (Front + Rear + Subwoofer) (Front + Rear/Subwoofer) (Front + Rear + Subwoofer) (Front + Rear/Subwoofer) (Front + Rear + Subwoofer) (Front + Rear/Subwoofer) (Front + Rear/Subwoofer) (Front + Rear/Subwoofer) (Rear/Subwoofer) (Rear/Subwoofer)
Subwoofer Output with Level/ ✔✔✔*2✔✔*2✔✔*2✔*2✔*2✔*2✔*2
Frequency Control
AUX Input 2 (Front/Rear) 1 (Front) 1 (Front) 1 (Front) 1 (Front) 2 (Front/Rear) 2 (Front/Rear) 2 (Front/Rear) 2 (Front/Rear) 2 (Front/Rear) 2 (Front/Rear)
Load Impedance 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable) 4Ω(4 - 8Ωallowable)
Line Pre-Output Level 2.5V 2.5V 2.5V 2.5V 2.5V 2.5V 2.5V 2.5V 2.5V 2.5V 2.5V
Line Pre-Output Impedance Less than 600Ω1kΩ1kΩLess than 600ΩLess than 600ΩLess than 600ΩLess than 600ΩLess than 600ΩLess than 600ΩLess than 600ΩLess than 600Ω
*1TI/Burr-Brown *2Rear/Subwoofer Selectable
Display
Separated Variable-Color ✔✔✔✔✔✔✔
Full Dot LCD ✔✔
Dimmer ✔✔✔✔✔✔✔✔✔✔✔
General
Detachable Control Panel ✔✔✔✔✔✔✔✔
Carrying Case ✔
Beep Tone Support ✔* ✔* ✔* ✔* ✔* ✔* ✔* ✔* ✔* ✔* ✔*
Wireless Remote Control Type Oval-Shaped Oval-Shaped Oval-Shaped Oval-Shaped Oval-Shaped Oval-Shaped Oval-Shaped Oval-Shaped Oval-Shaped Oval-Shaped Oval-Shaped
Rotary Encoder ✔✔✔✔✔✔✔✔✔✔✔
Steering Wheel Remote Ready ✔✔✔✔✔✔✔
Headunit Installation Size 7 3/16” x 4 3/8” x 6 5/16” 7 3/16” x 4 3/8” x 6 5/16” 7 3/16” x 4 3/8” x 6 5/16” 7 3/16” x 2 1/16” x 6 1/4” 7 3/16” x 2 1/16” x 6 1/4” 7 3/16” x 2 1/16” x 6 1/4” 7 3/16” x 2 1/16” x 6 5/16” 7 3/16” x 2 1/16” x 6 5/16” 7 3/16” x 2 1/16” x 6 5/16” 7 3/16” x 2 1/16” x 6 5/16” 7 3/16” x 2 1/16” x 6 5/16”
(W x H x D) (182 x 111 x 159.5mm) (182 x 111 x 159.5mm) (182 x 111 x 159.5mm) (182 x 52 x 158mm) (182 x 52 x 158mm) (182 x 52 x 158mm) (182 x 52 x 159mm) (182 x 52 x 158mm) (182 x 52 x 159mm) (182 x 52 x 159mm) (182 x 52 x 159mm)
Panel Size 7 7/16” x 6 5/8” x 15/16” 7 7/16” x 6 5/8” x 15/16” 7 7/16” x 6 5/8” x 15/16” 7 7/16” x 2 3/8” x 3/8” 7 7/16” x 2 3/8” x 3/8” 7 7/16” x 2 3/8” x 3/8” 7 7/16” x 2 3/8” x 3/8” 7 7/16” x 2 3/8” x 3/8” 7 7/16” x 2 3/8” x 3/8” 7 7/16” x 2 3/8” x 3/8” 7 7/16” x 2 3/8” x 3/8”
(W x H x D) (188 x 116.8 x 22.5mm) (188 x 116.8 x 22.5mm) (188 x 116.8 x 22.5mm) (188 x 59 x 8.5mm) (188 x 59 x 8.5mm) (188 x 59 x 8.5mm) (188 x 59 x 8.5mm) (188 x 59 x 8.5mm) (188 x 59 x 8.5mm) (188 x 59 x 8.5mm) (188 x 59 x 8.5mm)
Detachable Face Plate 6 3/4” x 1 13/16” x 7/8” 6 3/4” x 1 13/16” x 7/8” 6 3/4” x 1 13/16” x 7/8” 6 3/4” x 1 13/16” x 7/8” 6 3/4” x 1 13/16” x 7/8” 6 3/4” x 1 13/16” x 13/16” 6 3/4” x 1 13/16” x 13/16” 6 3/4” x 1 13/16” x 7/8”
(W x H x D) (170 x 46.4 x 20.5mm) (170 x 46.4 x 20.5mm) (170 x 46.4 x 20.5mm) (170 x 46.4 x 21.1mm) (170 x 46.4 x 20.5mm) (170 x 46.4 x 20.6mm) (170 x 46.4 x 20.6mm) (170 x 46.4 x 21.1mm)
Weight 1.81kg (4.0 lbs.) 1.9kg (4.2 lbs.) 1.8kg (4.0 lbs.) 1.3kg (2.9 lbs.) 1.3kg (2.9 lbs.) 1.27kg (2.79 lbs.) 1.23kg (2.75 lbs.) 1.21kg (2.7 lbs.) 1.21kg (2.7 lbs.) 1.21kg (2.7 lbs.) 1.23kg (2.75 lbs.)
* From Speakers
