PORTABLE CD PLAYER XL-PM6S/XL-PR70B
INSTRUCTIONS
Thank you for purchasing this JVC product. Please read these instructions carefully before starting
operation to be sure to obtain optimum performance and a longer service life from the unit.
Only compact discs bearing this mark can be used ith this unit.
Ho ever, continued use of irregular shape CDs (heart-shape, octagonal, etc.) can damage
the unit.
If moisture has formed on a disc
When moisture has formed because the
disc as brought suddenly into a arm
room from a cold environment, ipe off
the moisture using a soft dry cloth.
When storing discs
Avoid locations hich are
• Exposed to direct sunlight.
• Susceptible to high levels of humidity or
dust.
• Directly exposed to heat from a heating
appliance.
• On top of a car dashboard or near the
rear indo .
Handling precautions
• On the label side (the side ith riting)
Do not rite anything using a pencil,
ball-point pen, etc. Do not use adhesive
paper or labels.
• On the disc (shiny) side
Handle this side carefully to keep it free
from fingerprints or scratches. Do not
use record cleaners, solvents, etc.
• Do not attach labels or stickers to CDs.
Do not use CDs ith exposed adhesive
from tape or left over peeled off stickers.
• Do not use scratch-proof protectors or
covers other than those specified for use
ith this unit.
If the disk surface is dirty
Wipe it ith a damp cloth and then ipe dry.
Wipe from the center to ard the outer edge.
How to hold a disc
LVT1297-001A [J,C,UJ]
CD-R and CD-RW discs recorded ith the audio
CD format can be played back, though some may
not be played back because of the disc character-
istics or recording condition.
Play surface (shiny surface)
For Customer Use:
Enter belo the Model No. and Serial
No. hich are located on back of the lid.
Retain this information for future
reference.
Model No.
Serial No.
EN
0205SKMCREORI
©2005 Victor Company of Japan, Limited
Power Supply Preparations
The illustration of the grip band is omitted.
Using dry-cell batteries
(not supplied)
Caution:
Do not forcibly open the battery lid too ide.
Battery indicator
This indicator appears hen the batteries are almost out of po er.
Po er ill be cut off a short hile later.
Note:
Turning off the Anti-Shock Protection EX ill save the battery po er
more or less. For details, see “Anti-shock Protection EX” on page 7.
(Available for an Audio CD only)
Battery indicator
Using the AC adaptor (not supplied)
Notes:
• Even if the unit is turned off, small po er is consumed as long
as the AC adaptor is connected to the AC po er outlet.
• When you ant to purchase the AC adaptor, see page 4.
AC po er outlet
T o “AA” (LR6) alkaline batteries.
AC adaptor
AC adaptor (for multi voltage area only)
(not supplied)
Before use
Make sure the present voltage of your AC adaptor fits to your lo-
cal voltage before plugging it into the AC po er outlet. If it
doesn’t, shift the AC line-voltage selector ith a scre driver so
that it corresponds to your local voltage.
VOLTAGE
ADJUSTOR
AC 110V
~127V
AC 220V
~240V
If the po er plug ill not fit your socket, use the AC plug adaptor.
How to use the AC plug adaptor (not
supplied)
Note:
When you ant to purchase the AC adaptor and the AC plug
adaptor, see page 4.
Precautions
Safety
1. Care of AC adaptor - The cord of the AC adaptor should be
routed so that they are not likely to be alked on or pinched
by items placed upon or against them. Never take hold of the
AC adaptor if your hand is et, and al ays grasp the plug
hen connecting or disconnecting it.
2. Disconnect when not in use - When not in use, be sure to
disconnect the AC adaptor from the AC po er outlet.
3. Batteries - If the unit is not used for a long period of time or is
used only from an AC po er source, remove all the batteries
to prevent potential damage due to battery leakage. Do not
mix (old and ne ) batteries or different types of batteries.
Installation
■ Environment
1. Condensation - Moisture may form on the lens in the follo -
ing conditions…
• immediately after a heater has been turned on.
• in a steamy or very humid room.
• hen the unit is suddenly moved from a cold environment
to a arm one. If moisture forms inside this unit, it may not
operate properly. To correct this problem ait about one
hour for the moisture to evaporate.
■ Placement
1. Foreign Material - Care should be taken so that objects do not
fall into and liquids are not spilled into the unit. Do not subject
this unit to excessive smoke, dust, mechanical vibration, or
shock.
2. Magnetism - The unit should be situated a ay from equipment
or devices that generate strong magnetic fields.
3. Stacking - Do not place any objects on top of the unit.
Maintenance
(See page 2 for details.)
Clean the cabinet, panel and controls ith a soft cloth lightly
moistened ith mild detergent solution.
Do not use any type of abrasive pad, scouring po der or solvent
such as alcohol or benzine.
Service
1.Damage Requiring Service - The unit should be serviced by
qualified service personnel hen:
(a) The AC adaptor is damaged; or
(b) Objects have fallen or liquid has been spilled into the unit; or
(c) The unit has been exposed to rain; or
(d) The unit does not appear to operate normally or exhibits a
marked change in performance; or
(e) The unit has been dropped, or the enclosure damaged.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
CAUTION!
This equipment has been tested and found to comply ith
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance ith the
instructions, may cause harmful interference to radio com-
munications. Ho ever, there is no guarantee that interfer-
ence ill not occur in a particular installation. If this
equipment does cause harmful interference to radio or televi-
sion reception, hich can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one of the follo ing measures:
• Reorient or relocate the receiving antenna.
• Increase the separation bet een the equipment and re-
ceiver.
• Connect the equipment into an outlet on a circuit different
from that to hich the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Any unauthorized changes or modifications to this equip-
ment ould void the user’s authority to operate this device.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
VARNING: Synlig Och
osynlig laserstrålning när
den öppnas och spärren är
urkopplad. Betrakta ej
strålen. (s)
CAUTION: Visible and invisible
laser radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE TO
BEAM. (e)
ADVARSEL: Synlig og usynlig
laserstråling når maskinen er
åben eller interlocken fejle.
Undgå direkte eksponering
til stråling. (d)
VARO: Avattaessa ja
Suojalukitus ohitettunatai
viallisena olet alttiina näkyvälle
ja näkymättömälle lasersäteilylle.
Vältä säteen kohdistumista
suoraan itseesi. (f)
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are
no user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation
when open and interlock failed or defeated. Avoid
direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL,
PLACED OUTSIDE THE UNIT.
CAUTION:
• Do not block the ventilation opening or holes. (If the venti-
lation openings of holes are blocked by a ne spaper or
cloth, etc., the heat may not be able to get out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must
be considered and local rules or la s governing the dis-
posal of these batteries must be follo ed strictly.
• Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled ith liquids, such as vases,
shall be placed on the apparatus.
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
INFORMATION (For Canada)
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus as set out in the
interference-causing equipment standard entitled “Digital
Apparatus”, ICES-003 of the Department of Communications.
THE FOLLOWING NOTICES ARE APPLIED ONLY FOR THE U.S.A.:
Cautions
Listening precautions
Do not play your headphones or earphones at a high volume.
Hearing experts advise against continuous extended play.
If you experience a ringing in your ears, reduce volume or discon-
tinue use.
Do not use hile operating a motorized vehicle. It may create a
traffic hazard and is illegal in many areas.
You should use extreme caution or temporarily discontinue use
in potentially hazardous situations.
Even if your headphones or earphones are an open-air type de-
signed to let you hear outside sounds, don’t turn up the volume
so high that you can’t hear hat’s around you.
Sound can be deceiving. Over time your hearing “comfort level”
adapts to higher volumes of sound. So hat sounds “normal” can
actually be loud and harmful to your hearing.
Guard against this by setting your equipment at a safe level BE-
FORE your hearing adapts.
To establish a safe level:
• Start your volume control at a lo setting.
• Slo ly increase the sound until you can hear it comfortably and
clearly, and ithout distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Rechargeable batteries
• Rechargeable batteries (not supplied) can be used.
• To use the rechargeable batteries, follo the instruction manual
attached to the rechargeable batteries and charger (not sup-
plied).
Dry cell batteries
To prevent damage to the batteries and electrolyte leakage, heed
the follo ing points.
• Align the , and . polarities properly hen inserting the bat-
teries.
• Do not mix different types or makers of batteries or old and
ne batteries.
• Remove the batteries if you do not plan to use the unit for a
long period of time.
• Do not thro batteries into a fire, and do not short-circuit, dis-
assemble or subject them to excessive heat.
• Do not attempt to recharge dry cell batteries.
Carrying dry cell batteries around
When putting dry cell batteries in a pocket or bag, ensure that no
other metal objects such as a necklace are placed together ith
them. Contact ith metal may cause short-circuiting hich, in
turn, may cause a fire.
AC adaptor
• Handle the AC adaptor carefully. Improper handling is dan-
gerous.
• Do not touch it ith et hands.
• Do not place heavy objects on top of it.
• Do not forcibly bend it.
• Be sure to connect only the specified AC adaptor ith the unit.
• Disconnect the AC adaptor from the po er outlet if the unit is
not going to be used for a long time.
Unit
No altering or remodeling
This can cause malfunctioning.
No dropping or strong impacts
This may damage the unit.
Locations to be avoided
Avoid using the unit in the follo ing locations since they can
cause malfunctioning.
1. Bathrooms and other moisture-prone places.
2. Warehouses and other dusty places
3. Very hot places near heating appliances, etc.
Do not leave the unit exposed to direct sunlight for
long periods of time
This may deform or discolor the cabinet and may also cause
malfunctioning.
When purchasing AC adaptor /
AC plug adaptor
Be absolutely sure to purchase the AC adaptor designed espe-
cially for this unit.
AC adaptor: AA-R4513 (for the U.S.A. and Canada)
AA-R4518 (for multi voltage area)
AC plug adaptor: QAM0060-001 (for multi voltage area)
For details, check ith your dealer.
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
•
A
S
S
O
C
I
A
T
I
O
N
•
EST. 1924
Put the grip band on your hand
Adjust the grip band to your hand size.
Portable CD player
Type : Compact disc player
Signal detection system : Non-contact optical pickup (semiconductor laser)
Pickup system : 3 beam laser
Number of channels: : 2 channels (stereo)
Frequency response : 20 Hz to 20 kHz
Wo & flutter : Unmeasurable
Output : Headphones (3.5 mm dia. stereo × 1)
9 mW/ch at 10 % THD/16 Ω matching impedance (16 Ω to 1 kΩ)
FM tuning range : 87.5 MHz - 108.0 MHz
(XL-PR70B only)
Duration of battery : Approx. 20 hours hen using t o alkaline batteries (LR6)
( ith Anti-Shock
Protection EX OFF)
Po er requirements : DC 3 V (“AA” or “LR6” size battery × 2)
DC 2.4V (rechargeable battery × 2)
DC IN 4.5 V
Dimensions (W×H×D) : 138 mm ×26 mm ×138 mm (5- 7/
16” × 1- 1/ 16” × 5- 7/ 16”)
(Excluding buttons and controls)
Mass : XL-PM6S 250 g (0.56 lbs)
XL-PR70B 260 g (0.58 lbs)
( ith grip band, ithout batteries)
AC adaptor (not supplied)
Input po er source : AC 120 V, 60 Hz (for the U.S.A. and Canada)
AC 110V - 127V/220 V - 240V, 50/60 Hz (for multi voltage area)
Output voltage : DC 4.5 V, 600 mA
• Design and specifications are subject to change ithout notice.
Specifications
Unit
Wipe the unit ith a soft cloth. Remove stubborn dirt using a cloth hich has been dipped in ater
or soapy ater and rung out, and then ipe dry.
• If you intend to use a chemically treated cleaning cloth, read its directions first.
• Do not use alcohol or paint thinners.
Lens
Maintenance
Air blo er for
camera lens
Lens
Troubleshooting
If the remedies indicated in the chart do not solve the problem, refer to the directory of Autho-
rized Service Centers (enclosed ith this unit) to locate a convenient service center, or consult
your dealer for instructions.
Problem
Poor tuner reception
Does not turn on.
Cannot close the lid.
Cannot play discs.
Cannot hear music—too
noisy.
TV picture is distorted.
Other radio reception is
noisy.
“DISC”or “Er”is displayed
when a disc is in the
player.
Check this
• Extend the headphone cord (antenna) to improve reception.
• Is the AC adaptor securely connected?
• Is the HOLD s itch set to OFF position?
Is the disc properly secured in place?
• Is the disc properly secured in place?
• Is there moisture condensation on the lens?
(Wait for about an hour and then try again.)
• Are MP3/WMA files recorded on the disc?
• Do MP3/WMA files have the extension code—.mp3 or
. ma?
• Are MP3/WMA files recorded in the format compliant
ith ISO 9660?
• Is the headphone plug inserted all the ay?
• Is the plug dirty? (Wipe a ay dirt on the plug.)
• Are you playing a compatible disc? While playing a non-
MP3/WMA file, you ill hear a noise. (Note it may not be
an MP3/WMA file although it has the extension code—
.mp3. or . ma)
Are you using the unit too near a TV or tuner? (If the TV or
tuner is connected to a simple indoor antenna, connect it to
an outdoor antenna.)
• Is the disc damaged?
• Is the disc playable on this player?
• Has the disc been inserted upside do n?
The Non-DVD side of a “DualDisc” does not comply ith the “Compact Disc Digital
Audio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product may
not be recommended.
• Microsoft and Windo s Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
* Only XL-PR70B supports WMA
*

65
87
XL-PM6S/XL-PR70B / LVT1297-001A / J,C,UJXL-PM6S/XL-PR70B / LVT1297-001A / J,C,UJ
XL-PM6S/XL-PR70B / LVT1297-001A / J,C,UJXL-PM6S/XL-PR70B / LVT1297-001A / J,C,UJ
4
3
VOLUME
6
VOLUME
1
5
RL
OFF ON
HOLD
2
00102 53 01 00 1 02 53
MP3 WMA
Button
Operation
To pause
To stop
To turn off the
unit
Fast forward/
reverse
Group skip
(MP3/WMA only)
(XL-PR70B only)
To switch over
the mode from
FM to CD
Display/reference
00700 18 01 00400 07
01044 48 10035
Skip function
During play,
Search function
Keep depressed during play.
• Play stops automatically hen all the tracks have
been played.
• (XL-PR70B) Press this button again hen the FM
(Tuner) reception mode becomes active.
For your reference:
“DISC”
This indication appears if 3/8 is pressed hen no disc is loaded
or if the disc is not properly seated.
“READING”
Preparation period before playing the track.
Appears for several seconds after pressing 3/8 to play.
“OPEN”
This indication appears hen the lid is open.
Removing discs
Turn off the unit and, after the disc has stopped rotating, remove
the disc as sho n belo :
Auto power off
If the unit is left in stop mode for 30 seconds, the unit turns
itself off automatically to prevent the batteries from running
do n.
Auto po er off function does not ork hen the source is
FM.
Disc rotation noise
The portable CD player uses a po er-saving operation method
so that disc rotation noise ill intermittently be emitted. But, it
is not a failure.
• To skip back to the previous track, quickly press 4
t ice.
• During Program play, the button is used to fast for-
ard or back through the programmed sequence of
tracks.
• During Random play, the skip button cannot be used
to skip back to tracks that ere played previously in
the random sequence.
During play,
During play,
Reverse
Basic Play
Label side
Elapsed playing
time of each track
No indication
The illustration of the grip band is omitted.
WMA can be played back only with XL-PR70B.
Follow the steps in the numerical order.
Track number
in play
Firmly connect
Forward
While stopped,
Press again to restart play.
HBS
Lights hen a
MP3/WMA disc is
used
Group
number
Track number (in the group) in play
For MP3/WMAFor Audio CD
Elapsed playing time of
each track
Audio CD MP3/WMA
Total number of tracks
Total playing time
Total number of groups
Total number of tracks
Group number
02001
GROUP UP
GROUP DOWN
During play or hile stopped,
Intro play
You can successively play the first 10 seconds of every track.
1While stopped,
MODE
INTRO
2
To cancel
Press MODE repeatedly until “INTRO” goes out.
Notes:
• You can also select Intro play during playback.
In this case, Intro play ill start from the next track after the
current track has finished.
• You can also select Intro play during Program play mode.
Random play
During playback,
MODE
RND
After playing all tracks, the unit stops.
To cancel
Press MODE until “RND” goes out, or press 7 to stop the disc.
Notes:
• You can also select Random play in stop mode.
• During Program play, you can not select Random play.
Repeat play
You can repeat one track or all tracks.
During playback,
MODE
GRP
ALL
To cancel
Press MODE repeatedly until the repeat indicator goes out.
Notes:
• You can also select Repeat play during Program play.
• You can also select Repeat play hile stopped.
Program play
You can program up to 64 tracks in any desired order including
the same tracks.
For Audio CD, go to step 3.
Though the display differs a little, operation is the same.
1While stopped,
(MP3/WMA only)
00 000 P-01
PROGRAM
2(MP3/WMA only) Select the desired group
number. (e.g.02)
02 001 P-01
GROUP UP
GROUP DOWN
3
PROGRAM
02 001 P-01
4Select the desired track.
02 003 P-01
5
00 000 P-02
PROGRAM
PROG
The track is registered.
6 For MP3/WMA, repeat steps 2-5 to select other
tracks.
For Audio CD, repeat steps 4 and 5.
When you program exceeding 64 tracks, the program se-
quence number returns to “01” and ill over rite the previ-
ous setting.
7
•To confirm the program
While stopped, press PROGRAM repeatedly. At this time, you
can add and change the program, if required.
•To delete the entire program
• While stopped, press STOP.
• Turn off the unit.
• (XL-PR70B) Change the source to FM.
Hyper-Bass Sound effect
You can enjoy po erful bass sound.
OFF 21
HBS
Anti-Shock Protection EX
This function achieves excellent performance against sound inter-
ruption caused by vibrations. You ill be able to enjoy listening
to music during (not vigorous) jogging.
By utilizing the high-performance servo circuit, audio data ill be
stored in the memory ahead of time.
For Audio CD: Up to 40 seconds orth (Anti-Shock Protection
on/off selectable)
For MP3/WMA: Up to 100 seconds orth at 128 kbps (Anti-
Shock Protection is fixed to on.)
Normally, this function is in effect.
ASP
As the audio data is gradually stored, the indicator changes as follo s:
ASP ASP
To cancel
(Audio CD only)
A.S.P
The “ANTI SHOCK” indicator goes out.
To activate again (Audio CD only)
Press A.S.P.
Notes:
• During this operation, the disc rotates at a higher rate than usual
in order to collect extra audio data. This may cause the batteries
to run out faster and could result in a slight increase in disc rota-
tion noise.
• This function can be s itched ON and OFF during playback.
Ho ever, this may cause a slight interruption in the sound be-
cause the disc’s rotational speed changes.
Preventing Accidental Operation (Hold
mode)
This function causes the unit to ignore, accidental button presses.
Hold mode prevents the following:
• Po ering on the unit accidentally ( hich can cause the batter-
ies to go dead).
• Play being cut off unexpectedly.
To use the Hold mode
OFF ON
HOLD
• To prevent the unit from po ering on accidentally, set the
HOLD s itch to the ON position hile the unit is turned off.
• To prevent the unit from unexpected operation during play, set
the HOLD s itch to the ON position after you starts playing
the disc.
• When the unit is in Hold mode, ”HOLD” and “ ” light as
follo s.
Po er on : “ ” stays lit.
Po er off : “HOLD” and “ ” light up for a fe seconds
hen 6 is pressed.
Notes:
• Before turning on the unit, be sure that HOLD is OFF.
Other ise, you cannot turn on the unit.
(Repeatedly)
Other Play Methods
(Repeatedly)
(Repeatedly)
Program sequence number
Track number
Group number
ANTI SHOCK
indicator
[Fully stored]
Tuner Operation (XL-PR70B only)
You can listen to FM stations by tuning in manually, automati-
cally, or using preset memory.
For best reception, extend the headphone cord (antenna).
Manual/Auto tuning
1
FM
107.0MHz
When the po er is turned on and you ant to change the mode
from CD to FM, keep the button depressed.
When the po er is turned off, press the button.
If the CD mode becomes active, keep the button depressed to
s itch over the mode to FM.
2Select a station.
Manual tuning
Press ¢ or 4 repeatedly to select a station you ant.
Auto tuning
Hold do n ¢ or 4 for a hile and then release it. The fre-
quency automatically changes up or do n to find the next station.
Presetting stations
You can preset up to 20 stations (frequencies).
1Select the station you want to preset.
Use Manual or Auto tuning mentioned earlier.
2
PROG
PRESET FM
PROGRAM
1107.0MHz
3Select the preset number (01~20) you want.
PROG
PRESET FM
8107.0MHz
GROUP/PRESET
UP
DOWN
4Press PROGRAM.
Preset tuning
Select the preset number you want in the FM
reception mode.
GROUP/PRESET
PRESET FM
8107.0MHz
UP
DOWN
Preset number
“MONO” appears.
Preset number
Preset station
Changing the FM reception mode
When a broadcast is in stereo, “ST.” lights up and you can hear
stereo effects. Ho ever, if an FM stereo broadcast is hard to re-
ceive or noisy, you can select monaural (MONO) mode. Recep-
tion improves, but you lose the stereo effect.
To select the monaural mode
FM MONO
107.0MHz
MODE
To cancel the monaural mode
Press MODE once again. “MONO” ill go out.
The monaural mode is cancelled also by changing the frequency.
Turning off the unit
MP3/WMA File Compatibility
• This player can read MP3/WMA files that are recorded in the format that is compliant ith ISO
9660.
• The player can read or play an MP3 file ith the extension code —“.mp3” and a WMA file ith the
exrension code — “. ma”.
• Track title can be displayed.
• ID3* tags can be sho n on the display.
* An MP3/WMA file can contain file information called “ID3 Tag” here its album name, artist, title,
etc. are recorded.
Playing order of MP3/WMA files
The illustration belo sho s the normal playing order of the MP3/WMA files. You ill see that the
MP3/WMA files are played back in the order from the higher hierarchy to the lo er one.
3
4
9
8
10
6
7
1
2
5
About MP3/WMA files
Hierarchy
Reverse
Forward
1 track repeat 1 group repeat
(MP3/WMA only)
All track repeat
Group
MP3/
WMA file
(ID3 tag)
In FM mode,

21
43
XL-PM6S/XL-PR70B / LVT1297-004A / BXL-PM6S/XL-PR70B / LVT1297-004A / B
XL-PM6S/XL-PR70B / LVT1297-004A / BXL-PM6S/XL-PR70B / LVT1297-004A / B
Stereo headphones .......................................................................................................................... 1 pc.
Supplied Accessories
Concerning Compact Discs
PORTABLE CD PLAYER XL-PM6S/XL-PR70B
INSTRUCTIONS
Thank you for purchasing this JVC product. Please read these instructions carefully before starting
operation to be sure to obtain optimum performance and a longer service life from the unit.
Only compact discs bearing this mark can be used with this unit.
However, continued use of irregular shape CDs (heart-shape, octagonal, etc.) can damage
the unit.
If moisture has formed on a disc
When moisture has formed because the
disc was brought suddenly into a warm
room from a cold environment, wipe off
the moisture using a soft dry cloth.
When storing discs
Avoid locations which are
• Exposed to direct sunlight.
• Susceptible to high levels of humidity or
dust.
• Directly exposed to heat from a heating
appliance.
• On top of a car dashboard or near the
rear window.
Handling precautions
• On the label side (the side with writing)
Do not write anything using a pencil,
ball-point pen, etc. Do not use adhesive
paper or labels.
• On the disc (shiny) side
Handle this side carefully to keep it free
from fingerprints or scratches. Do not
use record cleaners, solvents, etc.
• Do not attach labels or stickers to CDs.
Do not use CDs with exposed adhesive
from tape or left over peeled off stickers.
• Do not use scratch-proof protectors or
covers other than those specified for use
with this unit.
If the disk surface is dirty
Wipe it with a damp cloth and then wipe dry.
Wipe from the center toward the outer edge.
How to hold a disc
LVT1297-004A [B]
CD-R and CD-RW discs recorded with the audio
CD format can be played back, though some may
not be played back because of the disc character-
istics or recording condition.
Play surface (shiny surface)
EN
0505SKMCREORI
©2005 Victor Company of Japan, Limited
Power Supply Preparations
Using dry-cell batteries
(not supplied)
Caution:
Do not forcibly open the battery lid too wide.
Battery indicator
This indicator appears when the batteries are almost out of power.
Power will be cut off a short while later.
Note:
Turning off the Anti-Shock Protection EX will save the battery power
more or less. For details, see “Anti-shock Protection EX” on page 7.
(Available for an Audio CD only)
Battery indicator
Using the AC adaptor (not supplied)
Notes:
• Even if the unit is turned off, small power is consumed as long
as the AC adaptor is connected to the AC power outlet.
• When you want to purchase the AC adaptor, see page 4.
AC power outlet
Two “LR6” alkaline batteries.
AC adaptor
Precautions
Safety
1. Care of AC adaptor - The cord of the AC adaptor should be
routed so that they are not likely to be walked on or pinched
by items placed upon or against them. Never take hold of the
AC adaptor if your hand is wet, and always grasp the plug
when connecting or disconnecting it.
2. Disconnect when not in use - When not in use, be sure to
disconnect the AC adaptor from the AC power outlet.
3. Batteries - If the unit is not used for a long period of time or is
used only from an AC power source, remove all the batteries
to prevent potential damage due to battery leakage. Do not
mix (old and new ) batteries or different types of batteries.
Installation
■ Environment
1. Condensation - Moisture may form on the lens in the follow-
ing conditions…
• immediately after a heater has been turned on.
• in a steamy or very humid room.
• when the unit is suddenly moved from a cold environment
to a warm one. If moisture forms inside this unit, it may not
operate properly. To correct this problem wait about one
hour for the moisture to evaporate.
■ Placement
1. Foreign Material - Care should be taken so that objects do not
fall into and liquids are not spilled into the unit. Do not subject
this unit to excessive smoke, dust, mechanical vibration, or
shock.
2. Magnetism - The unit should be situated away from equipment
or devices that generate strong magnetic fields.
3. Stacking - Do not place any objects on top of the unit.
Maintenance
(See page 2 for details.)
Clean the cabinet, panel and controls with a soft cloth lightly
moistened with mild detergent solution.
Do not use any type of abrasive pad, scouring powder or solvent
such as alcohol or benzine.
Service
1.Damage Requiring Service - The unit should be serviced by
qualified service personnel when:
(a) The AC adaptor is damaged; or
(b) Objects have fallen or liquid has been spilled into the unit; or
(c) The unit has been exposed to rain; or
(d) The unit does not appear to operate normally or exhibits a
marked change in performance; or
(e) The unit has been dropped, or the enclosure damaged.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
VARNING: Synlig Och
osynlig laserstrålning när
den öppnas och spärren är
urkopplad. Betrakta ej
strålen. (s)
CAUTION: Visible and invisible
laser radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE TO
BEAM. (e)
ADVARSEL: Synlig og usynlig
laserstråling når maskinen er
åben eller interlocken fejle.
Undgå direkte eksponering
til stråling. (d)
VARO: Avattaessa ja
Suojalukitus ohitettunatai
viallisena olet alttiina näkyvälle
ja näkymättömälle lasersäteilylle.
Vältä säteen kohdistumista
suoraan itseesi. (f)
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are
no user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation
when open and interlock failed or defeated. Avoid
direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL,
PLACED OUTSIDE THE UNIT.
CAUTION:
• Do not block the ventilation opening or holes. (If the venti-
lation openings of holes are blocked by a newspaper or
cloth, etc., the heat may not be able to get out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must
be considered and local rules or laws governing the dis-
posal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled with liquids, such as vases,
shall be placed on the apparatus.
Cautions
Rechargeable batteries
• Rechargeable batteries (not supplied) can be used.
• To use the rechargeable batteries, follow the instruction manual
attached to the rechargeable batteries and charger (not sup-
plied).
Dry cell batteries
To prevent damage to the batteries and electrolyte leakage, heed
the following points.
• Align the ,and .polarities properly when inserting the bat-
teries.
• Do not mix different types or makers of batteries or old and
new batteries.
• Remove the batteries if you do not plan to use the unit for a
long period of time.
• Do not throw batteries into a fire, and do not short-circuit, dis-
assemble or subject them to excessive heat.
• Do not attempt to recharge dry cell batteries.
Carrying dry cell batteries around
When putting dry cell batteries in a pocket or bag, ensure that no
other metal objects such as a necklace are placed together with
them. Contact with metal may cause short-circuiting which, in
turn, may cause a fire.
AC adaptor
• Handle the AC adaptor carefully. Improper handling is dan-
gerous.
• Do not touch it with wet hands.
• Do not place heavy objects on top of it.
• Do not forcibly bend it.
• Be sure to connect only the specified AC adaptor with the unit.
• Disconnect the AC adaptor from the power outlet if the unit is
not going to be used for a long time.
Unit
No altering or remodeling
This can cause malfunctioning.
No dropping or strong impacts
This may damage the unit.
Locations to be avoided
Avoid using the unit in the following locations since they can
cause malfunctioning.
1. Bathrooms and other moisture-prone places.
2. Warehouses and other dusty places
3. Very hot places near heating appliances, etc.
Do not leave the unit exposed to direct sunlight for
long periods of time
This may deform or discolor the cabinet and may also cause
malfunctioning.
When purchasing AC adaptor
Be absolutely sure to purchase the AC adaptor designed espe-
cially for this unit.
AC adaptor: AA-R4515
For details, check with your dealer.
Portable CD player
Type : Compact disc player
Signal detection system : Non-contact optical pickup (semiconductor laser)
Pickup system : 3 beam laser
Number of channels: : 2 channels (stereo)
Frequency response : 20 Hz to 20 kHz
Wow & flutter : Unmeasurable
Output : Headphones (3.5 mm dia. stereo × 1)
9 mW/ch at 10 % THD/16 Ωmatching impedance (16 Ωto 1 kΩ)
FM tuning range : 87.50 MHz - 108.00 MHz
(XL-PR70B only)
Duration of battery : Approx. 20 hours when using two alkaline batteries (LR6)
(with Anti-Shock
Protection EX OFF)
Power requirements : DC 3 V ( “LR6” size battery × 2)
DC 2.4V (rechargeable battery × 2)
DC IN 4.5 V
Dimensions (W ×H×D) : 138 mm ×26 mm ×138 mm
(Excluding buttons and controls)
Mass : XL-PM6S 240 g
XL-PR70B 250 g
(without batteries)
AC adaptor (not supplied)
Input power source : AC 230V, 50 Hz
Output voltage : DC 4.5 V, 600 mA
• Design and specifications are subject to change without notice.
• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Specifications
Unit
Wipe the unit with a soft cloth. Remove stubborn dirt using a cloth which has been dipped in water
or soapy water and wrung out, and then wipe dry.
• If you intend to use a chemically treated cleaning cloth, read its directions first.
• Do not use alcohol or paint thinners.
Lens
Maintenance
Air blower for
camera lens
Lens
Troubleshooting
If the remedies indicated in the chart do not solve the problem, refer to the directory of Autho-
rized Service Centers (enclosed with this unit) to locate a convenient service center, or consult
your dealer for instructions.
Problem
Poor tuner reception
Does not turn on.
Cannot close the lid.
Cannot play discs.
Cannot hear music—too
noisy.
TV picture is distorted.
Other radio reception is
noisy.
“DISC” or “Er” is displayed
when a disc is in the
player.
Check this
• Extend the headphone cord (antenna) to improve reception.
• Is the AC adaptor securely connected?
• Is the HOLD switch set to OFF position?
Is the disc properly secured in place?
• Is the disc properly secured in place?
• Is there moisture condensation on the lens?
(Wait for about an hour and then try again.)
• Are MP3/WMA files recorded on the disc?
• Do MP3/WMA files have the extension code—.mp3 or
.wma?
• Are MP3/WMA files recorded in the format compliant
with ISO 9660?
• Is the headphone plug inserted all the way?
• Is the plug dirty? (Wipe away dirt on the plug.)
• Are you playing a compatible disc? While playing a non-
MP3/WMA file, you will hear a noise. (Note it may not be
an MP3/WMA file although it has the extension code—
.mp3. or .wma)
Are you using the unit too near a TV or tuner? (If the TV or
tuner is connected to a simple indoor antenna, connect it to
an outdoor antenna.)
• Is the disc damaged?
• Is the disc playable on this player?
• Has the disc been inserted upside down?
The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital
Audio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product may
not be recommended.
*Only XL-PR70B supports WMA
*
Listening precautions
• Do not play your headphones at a high volume. Hearing ex-
perts advise against continuous extended play.
• If you experience a ringing in your ears, reduce volume or dis-
continue use.
• Do not use while operating a motorized vehicle. It may create a
traffic hazard and is illegal in many areas.
• You should use extreme caution or temporarily discontinue use
in potentially hazardous situations.
• Even if your headphones is an open-air type designed to let you
hear outside sounds, don’t turn up the volume so high that you
can’t hear what’s around you.

65
87
XL-PM6S/XL-PR70B / LVT1297-004A / B
XL-PM6S/XL-PR70B / LVT1297-004A / BXL-PM6S/XL-PR70B / LVT1297-004A / B
4
3
VOLUME
6
VOLUME
1
5
RL
OFF ON
HOLD
2
00102 53 01 00 1 02 53
MP3 WMA
Button
Operation
To pause
To stop
To turn off the
unit
Fast forward/
reverse
Group skip
(MP3/WMA only)
(XL-PR70B only)
To switch over
the mode from
FM to CD
Display/reference
00700 18 01 00400 07
01044 48 10035
Skip function
During play,
Search function
Keep depressed during play.
•Play stops automatically when all the tracks have
been played.
•(XL-PR70B) Press this button again when the FM
(Tuner) reception mode becomes active.
For your reference:
“DISC”
This indication appears if 3/8is pressed when no disc is loaded
or if the disc is not properly seated.
“READING”
Preparation period before playing the track.
Appears for several seconds after pressing 3/8to play.
“OPEN”
This indication appears when the lid is open.
Removing discs
Turn off the unit and, after the disc has stopped rotating, remove
the disc as shown below:
Auto power off
If the unit is left in stop mode for 30 seconds, the unit turns
itself off automatically to prevent the batteries from running
down.
Auto power off function does not work when the source is
FM.
Disc rotation noise
The portable CD player uses a power-saving operation method
so that disc rotation noise will intermittently be emitted. But, it
is not a failure.
•To skip back to the previous track, quickly press 4
twice.
•During Program play, the button is used to fast for-
ward or back through the programmed sequence of
tracks.
•During Random play, the skip button cannot be used
to skip back to tracks that were played previously in
the random sequence.
During play,
During play,
Reverse
Basic Play
Label side
Elapsed playing
time of each track
No indication
WMA can be played back only with XL-PR70B.
Follow the steps in the numerical order.
Track number
in play
Firmly connect
Forward
While stopped,
Press again to restart play.
HBS
Lights when a
MP3/WMA disc is
used
Group
number
Track number (in the group) in play
For MP3/WMAFor Audio CD
Elapsed playing time of
each track
Audio CD MP3/WMA
Total number of tracks
Total playing time
Total number of groups
Total number of tracks
Group number
02001
GROUP UP
GROUP DOWN
During play or while stopped,
Intro play
You can successively play the first 10 seconds of every track.
1While stopped,
MODE
INTRO
2
To cancel
Press MODE repeatedly until “INTRO”goes out.
Notes:
•You can also select Intro play during playback.
In this case, Intro play will start from the next track after the
current track has finished.
•You can also select Intro play during Program play mode.
Random play
During playback,
MODE
RND
After playing all tracks, the unit stops.
To cancel
Press MODE until “RND”goes out, or press 7to stop the disc.
Notes:
•You can also select Random play in stop mode.
•During Program play, you can not select Random play.
Repeat play
You can repeat one track or all tracks.
During playback,
MODE
GRP
ALL
To cancel
Press MODE repeatedly until the repeat indicator goes out.
Notes:
•You can also select Repeat play during Program play.
•You can also select Repeat play while stopped.
Program play
You can program up to 64 tracks in any desired order including
the same tracks.
For Audio CD, go to step 3.
Though the display differs a little, operation is the same.
1While stopped,
(MP3/WMA only)
00 000 P-01
PROGRAM
2(MP3/WMA only) Select the desired group
number. (e.g.02)
02 001 P-01
GROUP UP
GROUP DOWN
3
PROGRAM
02 001 P-01
4Select the desired track.
02 003 P-01
5
00 000 P-02
PROGRAM
PROG
The track is registered.
6 For MP3/WMA, repeat steps 2-5 to select other
tracks.
For Audio CD, repeat steps 4 and 5.
When you program exceeding 64 tracks, the program se-
quence number returns to “01”and will overwrite the previ-
ous setting.
7
• To confirm the program
While stopped, press PROGRAM repeatedly. At this time, you
can add and change the program, if required.
• To delete the entire program
•While stopped, press STOP.
•Turn off the unit.
•(XL-PR70B) Change the source to FM.
Hyper-Bass Sound effect
You can enjoy powerful bass sound.
OFF 21
HBS
Anti-Shock Protection EX
This function achieves excellent performance against sound inter-
ruption caused by vibrations. You will be able to enjoy listening
to music during (not vigorous) jogging.
By utilizing the high-performance servo circuit, audio data will be
stored in the memory ahead of time.
For Audio CD: Up to 40 seconds worth (Anti-Shock Protection
on/off selectable)
For MP3/WMA: Up to 100 seconds worth at 128 kbps (Anti-
Shock Protection is fixed to on.)
Normally, this function is in effect.
ASP
As the audio data is gradually stored, the indicator changes as follows:
ASP ASP
To cancel
(Audio CD only)
A.S.P
The “ANTI SHOCK”indicator goes out.
To activate again (Audio CD only)
Press A.S.P.
Notes:
•During this operation, the disc rotates at a higher rate than usual
in order to collect extra audio data. This may cause the batteries
to run out faster and could result in a slight increase in disc rota-
tion noise.
•This function can be switched ON and OFF during playback.
However, this may cause a slight interruption in the sound be-
cause the disc’s rotational speed changes.
Preventing Accidental Operation (Hold
mode)
This function causes the unit to ignore, accidental button presses.
Hold mode prevents the following:
•Powering on the unit accidentally (which can cause the batter-
ies to go dead).
•Play being cut off unexpectedly.
To use the Hold mode
OFF ON
HOLD
•To prevent the unit from powering on accidentally, set the
HOLD switch to the ON position while the unit is turned off.
•To prevent the unit from unexpected operation during play, set
the HOLD switch to the ON position after you starts playing
the disc.
•When the unit is in Hold mode, ”HOLD”and “ ” light as
follows.
Power on : “ ” stays lit.
Power off : “HOLD”and “ ” light up for a few seconds
when 6is pressed.
Notes:
•Before turning on the unit, be sure that HOLD is OFF.
Otherwise, you cannot turn on the unit.
(Repeatedly)
Other Play Methods
(Repeatedly)
(Repeatedly)
Program sequence number
Track number
Group number
ANTI SHOCK
indicator
[Fully stored]
Tuner Operation (XL-PR70B only)
You can listen to FM stations by tuning in manually, automati-
cally, or using preset memory.
For best reception, extend the headphone cord (antenna).
Manual/Auto tuning
1
FM
107.00MHz
When the power is turned on and you want to change the mode
from CD to FM, keep the button depressed.
When the power is turned off, press the button.
If the CD mode becomes active, keep the button depressed to
switch over the mode to FM.
2Select a station.
Manual tuning
Press ¢or 4repeatedly to select a station you want.
Auto tuning
Hold down ¢or 4for a while and then release it. The fre-
quency automatically changes up or down to find the next station.
Presetting stations
You can preset up to 20 stations (frequencies).
1Select the station you want to preset.
Use Manual or Auto tuning mentioned earlier.
2
PROG
PRESET FM
PROGRAM
1107.00MHz
3Select the preset number (01~20) you want.
PROG
PRESET FM
8107.00MHz
GROUP/PRESET
UP
DOWN
4Press PROGRAM.
Preset tuning
Select the preset number you want in the FM
reception mode.
GROUP/PRESET
PRESET FM
8107.00MHz
UP
DOWN
Preset number
“MONO”appears.
Preset number
Preset station
Changing the FM reception mode
When a broadcast is in stereo, “ST.”lights up and you can hear
stereo effects. However, if an FM stereo broadcast is hard to re-
ceive or noisy, you can select monaural (MONO) mode. Recep-
tion improves, but you lose the stereo effect.
To select the monaural mode
FM MONO
107.00MHz
MODE
To cancel the monaural mode
Press MODE once again. “MONO”will go out.
The monaural mode is cancelled also by changing the frequency.
Turning off the unit
MP3/WMA File Compatibility
•This player can read MP3/WMA files that are recorded in the format that is compliant with ISO
9660.
•The player can read or play an MP3 file with the extension code —“.mp3”and a WMA file with the
exrension code —“.wma”.
•Track title can be displayed.
•ID3* tags can be shown on the display.
* An MP3/WMA file can contain file information called “ID3 Tag”where its album name, artist, title,
etc. are recorded.
Playing order of MP3/WMA files
The illustration below shows the normal playing order of the MP3/WMA files. You will see that the
MP3/WMA files are played back in the order from the higher hierarchy to the lower one.
3
4
9
8
10
6
7
1
2
5
About MP3/WMA files
Hierarchy
Reverse
Forward
1 track repeat 1 group repeat
(MP3/WMA only)
All track repeat
Group
MP3/
WMA file
(ID3 tag)
In FM mode,

21
43
XL-PM6S/XL-PR70B / LVT1297-014A / USXL-PM6S/XL-PR70B / LVT1297-014A / US
XL-PM6S/XL-PR70B / LVT1297-014A / USXL-PM6S/XL-PR70B / LVT1297-014A / US
Stereo headphones .......................................................................................................................... 1 pc.
AC adaptor (AA-R4518) ................................................................................................................. 1 pc.
AC plug adaptor (QAM0060-001) ................................................................................................ 1 pc.
Rechargeable Ni-MH batteries (BN-R1215) ............................................................................... 2 pc.
Supplied Accessories
Concerning Compact Discs
PORTABLE CD PLAYER XL-PM6S/XL-PR70B
INSTRUCTIONS
Thank you for purchasing this JVC product. Please read these instructions carefully before starting
operation to be sure to obtain optimum performance and a longer service life from the unit.
Only compact discs bearing this mark can be used with this unit.
However, continued use of irregular shape CDs (heart-shape, octagonal, etc.) can damage
the unit.
If moisture has formed on a disc
When moisture has formed because the
disc was brought suddenly into a warm
room from a cold environment, wipe off
the moisture using a soft dry cloth.
When storing discs
Avoid locations which are
• Exposed to direct sunlight.
• Susceptible to high levels of humidity or
dust.
• Directly exposed to heat from a heating
appliance.
• On top of a car dashboard or near the
rear window.
Handling precautions
• On the label side (the side with writing)
Do not write anything using a pencil,
ball-point pen, etc. Do not use adhesive
paper or labels.
• On the disc (shiny) side
Handle this side carefully to keep it free
from fingerprints or scratches. Do not
use record cleaners, solvents, etc.
• Do not attach labels or stickers to CDs.
Do not use CDs with exposed adhesive
from tape or left over peeled off stickers.
• Do not use scratch-proof protectors or
covers other than those specified for use
with this unit.
If the disk surface is dirty
Wipe it with a damp cloth and then wipe dry.
Wipe from the center toward the outer edge.
How to hold a disc
LVT1297-014A [US]
CD-R and CD-RW discs recorded with the audio
CD format can be played back, though some may
not be played back because of the disc character-
istics or recording condition.
Play surface (shiny surface)
EN
0405SKMCREORI
©2005 Victor Company of Japan, Limited
Precautions
Safety
1. Care of AC adaptor - The cord of the AC adaptor should be
routed so that they are not likely to be walked on or pinched
by items placed upon or against them. Never take hold of the
AC adaptor if your hand is wet, and always grasp the plug
when connecting or disconnecting it.
2. Disconnect when not in use - When not in use, be sure to
disconnect the AC adaptor from the AC power outlet.
3. Batteries - If the unit is not used for a long period of time or is
used only from an AC power source, remove all the batteries
to prevent potential damage due to battery leakage. Do not
mix (old and new ) batteries or different types of batteries.
Installation
■ Environment
1. Condensation - Moisture may form on the lens in the follow-
ing conditions…
• immediately after a heater has been turned on.
• in a steamy or very humid room.
• when the unit is suddenly moved from a cold environment
to a warm one. If moisture forms inside this unit, it may not
operate properly. To correct this problem wait about one
hour for the moisture to evaporate.
■ Placement
1. Foreign Material - Care should be taken so that objects do not
fall into and liquids are not spilled into the unit. Do not subject
this unit to excessive smoke, dust, mechanical vibration, or
shock.
2. Magnetism - The unit should be situated away from equipment
or devices that generate strong magnetic fields.
3. Stacking - Do not place any objects on top of the unit.
Maintenance
(See page 2 for details.)
Clean the cabinet, panel and controls with a soft cloth lightly
moistened with mild detergent solution.
Do not use any type of abrasive pad, scouring powder or solvent
such as alcohol or benzine.
Service
1.Damage Requiring Service - The unit should be serviced by
qualified service personnel when:
(a) The AC adaptor is damaged; or
(b) Objects have fallen or liquid has been spilled into the unit; or
(c) The unit has been exposed to rain; or
(d) The unit does not appear to operate normally or exhibits a
marked change in performance; or
(e) The unit has been dropped, or the enclosure damaged.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
VARNING: Synlig Och
osynlig laserstrålning när
den öppnas och spärren är
urkopplad. Betrakta ej
strålen. (s)
CAUTION: Visible and invisible
laser radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE TO
BEAM. (e)
ADVARSEL: Synlig og usynlig
laserstråling når maskinen er
åben eller interlocken fejle.
Undgå direkte eksponering
til stråling. (d)
VARO: Avattaessa ja
Suojalukitus ohitettunatai
viallisena olet alttiina näkyvälle
ja näkymättömälle lasersäteilylle.
Vältä säteen kohdistumista
suoraan itseesi. (f)
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are
no user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation
when open and interlock failed or defeated. Avoid
direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL,
PLACED OUTSIDE THE UNIT.
CAUTION:
• Do not block the ventilation opening or holes. (If the venti-
lation openings of holes are blocked by a newspaper or
cloth, etc., the heat may not be able to get out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must
be considered and local rules or laws governing the dis-
posal of these batteries must be followed strictly.
• Do not expose this apparatus and AC adapor to rain, mois-
ture, dripping or splashing and that no objects filled with liq-
uids, such as vases, shall be placed on the apparatus.
Cautions
Listening precautions
Do not play your headphones or earphones at a high volume.
Hearing experts advise against continuous extended play.
If you experience a ringing in your ears, reduce volume or discon-
tinue use.
Do not use while operating a motorized vehicle. It may create a
traffic hazard and is illegal in many areas.
You should use extreme caution or temporarily discontinue use in
potentially hazardous situations.
Even if your headphones or earphones are an open-air type de-
signed to let you hear outside sounds, don’t turn up the volume
so high that you can’t hear what’s around you.
Sound can be deceiving. Over time your hearing “comfort level”
adapts to higher volumes of sound. So what sounds “normal” can
actually be loud and harmful to your hearing.
Guard against this by setting your equipment at a safe level BE-
FORE your hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and
clearly, and without distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
•
A
S
S
O
C
I
A
T
I
O
N
•
EST. 1924
Portable CD player
Type : Compact disc player
Signal detection system : Non-contact optical pickup (semiconductor laser)
Pickup system : 3 beam laser
Number of channels: : 2 channels (stereo)
Frequency response : 20 Hz to 20 kHz
Wow & flutter : Unmeasurable
Output : Headphones (3.5 mm dia. stereo × 1)
9 mW/ch at 10 % THD/16 Ωmatching impedance (16 Ωto 1 kΩ)
FM tuning range : 87.50 MHz - 108.00 MHz
(XL-PR70B only)
Duration of battery : Approx. 20 hours when using two alkaline batteries (LR6)
(with Anti-Shock Approx. 5 hours when using two rechargeable batteries
Protection EX OFF) charged for 12 hours
Power requirements : DC 3 V (“LR6” size battery × 2)
DC 2.4V (rechargeable battery × 2)
DC IN 4.5 V
Dimensions (W ×H×D) : 138 mm ×26 mm ×138 mm
(Excluding buttons and controls)
Mass : XL-PM6S 240 g
XL-PR70B 250 g
(without batteries)
AC adaptor (not supplied)
Input power source : AC 110 V–127 V/220 V–240 V, 50/60 Hz
Output voltage : DC 4.5 V, 600 mA
• Design and specifications are subject to change without notice.
• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Specifications
Unit
Wipe the unit with a soft cloth. Remove stubborn dirt using a cloth which has been dipped in water
or soapy water and wrung out, and then wipe dry.
• If you intend to use a chemically treated cleaning cloth, read its directions first.
• Do not use alcohol or paint thinners.
Lens
Maintenance
Air blower for
camera lens
Lens
The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Au-
dio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product may not
be recommended.
*Only XL-PR70B supports WMA
*
Power Supply Preparations
Using rechargeable batteries
(supplied)
Be sure to recharge the rechargeable batteries before using them.
Recharging procedure
1Insert the rechargeable batteries.
Caution:
Do not forcibly open the battery lid too wide.
2Connect the AC adaptor (supplied).
3
Recharging starts.
C-- -C- --C
Recharging will be completed after 12 hours. After that, the in-
dicator goes out.
AC adaptor
4When recharging is complete, unplug the
AC adaptor from the AC power outlet and
the DC IN jack.
Notes:
• Rechargeable batteries have a service life of approximately
300 charge-discharge cycles. If the operating time on one full
charge becomes noticeably shorter than it used to be, the batter-
ies have reached the end of their service life and should be re-
placed.
• You can recharge the batteries only when the unit is turned
off.
• The AC adaptor and rechargeable batteries may become warm
while recharging is in progress. This is normal and is not a
malfunction.
Using the AC adaptor (supplied)
Connect the AC adaptor.
Refer to “Using rechargeable batteries” for connection instruc-
tions.
Note:
Even if the unit is turned off, small power is consumed as long as
the AC adaptor is connected to the AC power outlet.
Using dry-cell batteries (not
supplied)
After disconnecting the AC adaptor, insert two “LR6” alkaline
batteries.
The procedure for inserting and removing dry-cell batteries is
identical to that rechargeable batteries.
Battery indicator
This indicator appears when the batteries are almost out of power.
Power will be cut off a short while later.
Note:
Turning off the Anti-Shock Protection EX will save the battery power
more or less. For details, see “Anti-shock Protection EX” on page 4.
AC power outlet
Battery indicator
AC adaptor
Before use
Make sure the present voltage of your AC adaptor fits to your
local voltage before plugging it into the AC power outlet. If it
doesn’t, shift the AC line-voltage selector with a screwdriver
so that it corresponds to your local voltage.
VOLTAGE
ADJUSTOR
AC 110V
~127V
AC 220V
~240V
If the power plug will not fit your socket, use the AC plug adap-
tor.
How to use the AC plug adaptor (sup-
plied)
(Keep pressing the button for a few seconds)
(The indicator above is displayed in recharging)
Rechargeable batteries
• Only supplied battery can be recharged.
• If the power delivered by the batteries lasts for a very short
time after recharging, it means that the batteries’ service life is
over. Do not use them any more.
• Recharging already charged batteries will shorten their service life.
• When recharging batteries for the first time or when they have not
been used for a long period of time, the play time may be shorter
than usual. In a case like this, repeatedly recharge and discharge
the batteries. This will restore them to their regular state.
• Do not allow any metal objects to touch the terminals of rechargeable
batteries since this may cause short-circuiting which is dangerous.
• Do not peel off the plastic covering on the rechargeable batter-
ies. Short-circuiting may occur which is dangerous.
Notice about the rechargeable battery
The battery is designated recyclable.
Please follow your local recycling regulations.
Dry cell batteries/rechargeable
batteries
To prevent damage to the batteries and electrolyte leakage, heed
the following points.
• Align the ,and .polarities properly when inserting the bat-
teries.
• Do not mix different types or makers of batteries or old and
new batteries.
• Remove the batteries if you do not plan to use the unit for a
long period of time.
• Do not throw batteries into a fire, and do not short-circuit, dis-
assemble or subject them to excessive heat.
• Do not attempt to recharge dry cell batteries.
Carrying dry cell batteries/
rechargeable batteries around
When putting dry cell or rechargeable batteries in a pocket or bag,
ensure that no other metal objects such as a necklace are placed
together with them. Contact with metal may cause short-circuit-
ing which, in turn, may cause a fire.
AC adaptor
• Handle the AC adaptor carefully. Improper handling is dan-
gerous.
• Do not touch it with wet hands.
• Do not place heavy objects on top of it.
• Do not forcibly bend it.
• Be sure to connect only the specified AC adaptor with the unit.
• Disconnect the AC adaptor from the power outlet if the unit is
not going to be used for a long time.
• The adaptor is used as the disconnect device and it shall
remain readily operable. To be completely disconnect the
power input, the adaptor shall be disconnected form the
mains.
Unit
No altering or remodeling
This can cause malfunctioning.
No dropping or strong impacts
This may damage the unit.
Locations to be avoided
Avoid using the unit in the following locations since they can
cause malfunctioning.
1. Bathrooms and other moisture-prone places.
2. Warehouses and other dusty places
3. Very hot places near heating appliances, etc.
Do not leave the unit exposed to direct sunlight for
long periods of time
This may deform or discolor the cabinet and may also cause mal-
functioning.
When purchasing rechargeable batteries
As a safety precaution, the portable CD players made by JVC
have a construction designed to make it impossible to recharge
ordinary batteries.
To use rechargeable batteries, be absolutely sure to purchase the
rechargeable batteries designed especially for this unit.
For the part number, refer to “Supplied Accessories”.
For details, check with your dealer.
Special rechargeable batteries
Ordinary dry cell batteries/
rechargeable batteries
Troubleshooting
If the remedies indicated in the chart do not solve the problem, refer to the directory of Autho-
rized Service Centers (enclosed with this unit) to locate a convenient service center, or consult
your dealer for instructions.
Problem
Poor tuner reception
Does not turn on.
Cannot close the lid.
Cannot play discs.
Cannot hear music—too
noisy.
TV picture is distorted.
Other radio reception is
noisy.
“DISC” or “Er” is displayed
when a disc is in the
player.
Check this
• Extend the headphone cord (antenna) to improve reception.
• Is the AC adaptor securely connected?
• Is the HOLD switch set to OFF position?
Is the disc properly secured in place?
• Is the disc properly secured in place?
• Is there moisture condensation on the lens?
(Wait for about an hour and then try again.)
• Are MP3/WMA files recorded on the disc?
• Do MP3/WMA files have the extension code—.mp3 or
.wma?
• Are MP3/WMA files recorded in the format compliant
with ISO 9660?
• Is the headphone plug inserted all the way?
• Is the plug dirty? (Wipe away dirt on the plug.)
• Are you playing a compatible disc? While playing a non-
MP3/WMA file, you will hear a noise. (Note it may not be
an MP3/WMA file although it has the extension code—
.mp3. or .wma)
Are you using the unit too near a TV or tuner? (If the TV or
tuner is connected to a simple indoor antenna, connect it to
an outdoor antenna.)
• Is the disc damaged?
• Is the disc playable on this player?
• Has the disc been inserted upside down?

65
87
XL-PM6S/XL-PR70B / LVT1297-014A / US
XL-PM6S/XL-PR70B / LVT1297-014A / USXL-PM6S/XL-PR70B / LVT1297-014A / US
4
3
VOLUME
6
VOLUME
1
5
RL
OFF ON
HOLD
2
00102 53 01 00 1 02 53
MP3 WMA
Button
Operation
To pause
To stop
To turn off the
unit
Fast forward/
reverse
Group skip
(MP3/WMA only)
(XL-PR70B only)
To switch over
the mode from
FM to CD
Display/reference
00700 18 01 00400 07
01044 48 10035
Skip function
During play,
Search function
Keep depressed during play.
• Play stops automatically when all the tracks have
been played.
• (XL-PR70B) Press this button again when the FM
(Tuner) reception mode becomes active.
For your reference:
“DISC”
This indication appears if 3/8is pressed when no disc is loaded
or if the disc is not properly seated.
“READING”
Preparation period before playing the track.
Appears for several seconds after pressing 3/8to play.
“OPEN”
This indication appears when the lid is open.
Removing discs
Turn off the unit and, after the disc has stopped rotating, remove
the disc as shown below:
Auto power off
If the unit is left in stop mode for 30 seconds, the unit turns
itself off automatically to prevent the batteries from running
down.
Auto power off function does not work when the source is
FM.
Disc rotation noise
The portable CD player uses a power-saving operation method
so that disc rotation noise will intermittently be emitted. But, it
is not a failure.
• To skip back to the previous track, quickly press 4
twice.
• During Program play, the button is used to fast for-
ward or back through the programmed sequence of
tracks.
• During Random play, the skip button cannot be used
to skip back to tracks that were played previously in
the random sequence.
During play,
During play,
Reverse
Basic Play
Label side
Elapsed playing
time of each track
No indication
WMA can be played back only with XL-PR70B.
Follow the steps in the numerical order.
Track number
in play
Firmly connect
Forward
While stopped,
Press again to restart play.
HBS
Lights when a
MP3/WMA disc is
used
Group
number
Track number (in the group) in play
For MP3/WMAFor Audio CD
Elapsed playing time of
each track
Audio CD MP3/WMA
Total number of tracks
Total playing time
Total number of groups
Total number of tracks
Group number
02001
GROUP UP
GROUP DOWN
During play or while stopped,
Intro play
You can successively play the first 10 seconds of every track.
1While stopped,
MODE
INTRO
2
To cancel
Press MODE repeatedly until “INTRO” goes out.
Notes:
• You can also select Intro play during playback.
In this case, Intro play will start from the next track after the
current track has finished.
• You can also select Intro play during Program play mode.
Random play
During playback,
MODE
RND
After playing all tracks, the unit stops.
To cancel
Press MODE until “RND” goes out, or press 7to stop the disc.
Notes:
• You can also select Random play in stop mode.
• During Program play, you can not select Random play.
Repeat play
You can repeat one track or all tracks.
During playback,
MODE
GRP
ALL
To cancel
Press MODE repeatedly until the repeat indicator goes out.
Notes:
• You can also select Repeat play during Program play.
• You can also select Repeat play while stopped.
Program play
You can program up to 64 tracks in any desired order including
the same tracks.
For Audio CD, go to step 3.
Though the display differs a little, operation is the same.
1While stopped,
(MP3/WMA only)
00 000 P-01
PROGRAM
2(MP3/WMA only) Select the desired group
number. (e.g.02)
02 001 P-01
GROUP UP
GROUP DOWN
3
PROGRAM
02 001 P-01
4Select the desired track.
02 003 P-01
5
00 000 P-02
PROGRAM
PROG
The track is registered.
6 For MP3/WMA, repeat steps 2-5 to select other
tracks.
For Audio CD, repeat steps 4 and 5.
When you program exceeding 64 tracks, the program se-
quence number returns to “01” and will overwrite the previ-
ous setting.
7
• To confirm the program
While stopped, press PROGRAM repeatedly. At this time, you
can add and change the program, if required.
• To delete the entire program
• While stopped, press STOP.
• Turn off the unit.
• (XL-PR70B) Change the source to FM.
Hyper-Bass Sound effect
You can enjoy powerful bass sound.
OFF 21
HBS
Anti-Shock Protection EX
This function achieves excellent performance against sound inter-
ruption caused by vibrations. You will be able to enjoy listening
to music during (not vigorous) jogging.
By utilizing the high-performance servo circuit, audio data will be
stored in the memory ahead of time.
For Audio CD: Up to 40 seconds worth (Anti-Shock Protection
on/off selectable)
For MP3/WMA: Up to 100 seconds worth at 128 kbps (Anti-
Shock Protection is fixed to on.)
Normally, this function is in effect.
ASP
As the audio data is gradually stored, the indicator changes as follows:
ASP ASP
To cancel
(Audio CD only)
A.S.P
The “ANTI SHOCK” indicator goes out.
To activate again (Audio CD only)
Press A.S.P.
Notes:
• During this operation, the disc rotates at a higher rate than usual
in order to collect extra audio data. This may cause the batteries
to run out faster and could result in a slight increase in disc rota-
tion noise.
• This function can be switched ON and OFF during playback.
However, this may cause a slight interruption in the sound be-
cause the disc’s rotational speed changes.
Preventing Accidental Operation (Hold
mode)
This function causes the unit to ignore, accidental button presses.
Hold mode prevents the following:
• Powering on the unit accidentally (which can cause the batter-
ies to go dead).
• Play being cut off unexpectedly.
To use the Hold mode
OFF ON
HOLD
• To prevent the unit from powering on accidentally, set the
HOLD switch to the ON position while the unit is turned off.
• To prevent the unit from unexpected operation during play, set
the HOLD switch to the ON position after you starts playing
the disc.
• When the unit is in Hold mode, ”HOLD” and “ ” light as
follows.
Power on : “ ” stays lit.
Power off : “HOLD” and “ ” light up for a few seconds
when 6is pressed.
Notes:
• Before turning on the unit, be sure that HOLD is OFF.
Otherwise, you cannot turn on the unit.
(Repeatedly)
Other Play Methods
(Repeatedly)
(Repeatedly)
Program sequence number
Track number
Group number
ANTI SHOCK
indicator
[Fully stored]
Tuner Operation (XL-PR70B only)
You can listen to FM stations by tuning in manually, automati-
cally, or using preset memory.
For best reception, extend the headphone cord (antenna).
Manual/Auto tuning
1
FM
107.00MHz
When the power is turned on and you want to change the mode
from CD to FM, keep the button depressed.
When the power is turned off, press the button.
If the CD mode becomes active, keep the button depressed to
switch over the mode to FM.
2Select a station.
Manual tuning
Press ¢or 4repeatedly to select a station you want.
Auto tuning
Hold down ¢or 4for a while and then release it. The fre-
quency automatically changes up or down to find the next station.
Presetting stations
You can preset up to 20 stations (frequencies).
1Select the station you want to preset.
Use Manual or Auto tuning mentioned earlier.
2
PROG
PRESET FM
PROGRAM
1107.00MHz
3Select the preset number (01~20) you want.
PROG
PRESET FM
8107.00MHz
GROUP/PRESET
UP
DOWN
4Press PROGRAM.
Preset tuning
Select the preset number you want in the FM
reception mode.
GROUP/PRESET
PRESET FM
8107.00MHz
UP
DOWN
Preset number
“MONO” appears.
Preset number
Preset station
Changing the FM reception mode
When a broadcast is in stereo, “ST.” lights up and you can hear
stereo effects. However, if an FM stereo broadcast is hard to re-
ceive or noisy, you can select monaural (MONO) mode. Recep-
tion improves, but you lose the stereo effect.
To select the monaural mode
FM MONO
107.00MHz
MODE
To cancel the monaural mode
Press MODE once again. “MONO” will go out.
The monaural mode is cancelled also by changing the frequency.
Turning off the unit
MP3/WMA File Compatibility
• This player can read MP3/WMA files that are recorded in the format that is compliant with ISO
9660.
• The player can read or play an MP3 file with the extension code —“.mp3” and a WMA file with the
exrension code — “.wma”.
• Track title can be displayed.
• ID3* tags can be shown on the display.
* An MP3/WMA file can contain file information called “ID3 Tag” where its album name, artist, title,
etc. are recorded.
Playing order of MP3/WMA files
The illustration below shows the normal playing order of the MP3/WMA files. You will see that the
MP3/WMA files are played back in the order from the higher hierarchy to the lower one.
3
4
9
8
10
6
7
1
2
5
About MP3/WMA files
Hierarchy
Reverse
Forward
1 track repeat 1 group repeat
(MP3/WMA only)
All track repeat
Group
MP3/
WMA file
(ID3 tag)
In FM mode,

XL-PM6S / XL-PR70B / LVT1297-005A [E] / Cover
EnglishEspañolNederlands
INSTRUCTIONS
INSTRUCCIONES
GEBRUIKSAANWIJZING
XL-PM6S / XL-PR70B
PORTABLE CD PLAYER
LECTOR PORTÁTIL DE DISCOS COMPACTOS
PORTABLE DRAAGBARE CD-SPELER
LVT1297-005A [E]
✽Only XL-PR70B supports WMA / Sólo el XL-PR70B admite WMA / Alleen XL-PR70B ondersteunt WMA
✽

G-1
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RE-
SULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR
YOURSELF. REFER SERVICINGTO QUALIFIED
PERSONNEL.
WARNING:
TO REDUCETHE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
¡ADVERTENCIA!
ESTE APARATO UTILIZA UN LÁSER.
EL USAR LOS CONTROLES, HACER LOS
REGLAJES O LOS PASOS REQUERIDOS EN
FORMA DIVERSA DE LA AQUÍEXPUESTA PUE-
DE REDUNDAR EN EXPOSICIÓN PELIGROSA
A LA RADIACIÓN.
NO ABRA LAS TAPAS NI HAGA REPARACIO-
NES USTED MISMO. EN CASO DE PRODUCIR-
SE ANOMALÍAS SOLICITE AYUDA DE PERSO-
NAL CUALIFICADO.
AVISO:
PARA REDUCIR EL RIESGO DE INCENDIOS
O SACUDIDAS ELÉCTRICAS, NO LO EXPON-
GA A LA LLUVIA O HUMEDAD.
Warnings, Cautions and Others
Avios, precauciones y otras notas
Waarschuwingen, voorzorgen en andere mededelingen

G-2
XL-PM6S / XL-PR70B / LVT1297-005A [E] / Safety
CAUTION:
• Do not block the ventilation opening or holes. (If the venti-
lation openings of holes are blocked by a newspaper or
cloth, etc., the heat may not be able to get out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must
be considered and local rules or laws governing the dis-
posal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
WAARSCHUWING!
IN DIT APPARAAT WORDT EEN LASER GE-
BRUIKT. HET GEBRUIKVAN REGELAARS EN HET
MAKEN VAN AFSTELLINGEN OF BEDIENINGEN
DIE NIET IN DEZE GEBRUIKSAANWIJZING
STAAN BESCHREVEN, KAN LEIDENTOT BLOOT-
STELLING AAN GEVAARLIJKE STRALING.
MAAK HET APPARAAT NIET OPEN EN GA NIET
ZELF REPAREREN. LAAT HET ONDERHOUD
AAN ERKENDE VAKMENSEN OVER.
WAARSCHUWING:
TENEINDE HET GEVAAR VOOR BRAND OF
ELEKTRISCHE SCHOKKEN TE VERKLEINEN,
MAG DIT APPARAAT NIET WORDEN BLOOT-
GESTELD AAN REGEN OF VOCHT.
PRECAUCIÓN:
• No obstruya las rendijas o los orificios de ventilación.
(Si las rendijas o los orificios de ventilación quedan tapados con
un periódico, un trozo de tela, etc., no se podrá disipar el calor).
• No ponga sobre el aparato ninguna llama al descubierto, como
velas encendidas.
• Cuando tenga que descartar las pilas, tenga en cuenta los proble-
mas ambientales y observe estrictamente los reglamentos o las
leyes locales sobre disposición de las pilas.
• No exponga este aparato a la lluvia, humedad, goteos o
salpicaduras. Tampoco ponga recipientes conteniendo líquidos,
como floreros, encima del aparato.
VOORZICHTIG:
• Zorg dat u de ventilatieopeningen en -gaten niet afsluit.
(Als de ventilatieopeningen en -gaten worden afgesloten door
bijvoorbeeld papier of een doek, kan er hitte in het apparaat wor-
den opgebouwd.)
• Zet geen bronnen met open vuur, zoals brandende kaarsen, op
het apparaat.
• Wees milieubewust en gooi lege batterijen niet bij het huishou-
delijk afval. Lege batterijen dient u in te leveren met het KCA of
bij een innamepunt voor batterijen.
• Stel dit apparaat niet bloot aan regen, vocht, drupwater of spat-
water en plaats geen enkel voorwerp waarin zich een vloeistof
bevindt, zoals een vaas, op het apparaat.

G-3
XL-PM6S / XL-PR70B / LVT1297-005A [E] / Safety
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are
no user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation
when open and interlock failed or defeated. Avoid
direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL,
PLACED OUTSIDE THE UNIT.
BELANGRIJK VOOR LASERPRODUKTEN
1. KLASSE 1 LASERPRODUKT
2. VOORZICHTIG: Open de bovenste afdekking niet.
Er zijn geen door de gebruiker te repareren onder-
delen in het toestel; laat onderhoud en reparatie
over aan erkend onderhoudspersoneel.
3. VOORZICHTIG: Zichtbare en onzichtbare laser-
straling indien open en interlock defect of buiten
werking gesteld. Voorkom directe blootstelling aan
de straal.
4. REPRODUCTIE VAN LABEL: WAARSCHUWING-
SLABEL IN TOESTEL AANGEBRACHT.
IMPORTANTE PARA PRODUCTOS LÁSER
1. PRODUCTO LÁSER CLASE 1
2. PRECAUCIÓN: No abra la tapa superior. En el in-
terior de la unidad no hay piezas que pueda repa-
rar el usuario; encargue el servicio a personal
técnico cualificado.
3. PRECAUCIÓN: Radiación láser visible e invisible
en caso de apertura o con interbloqueo averiado o
defectuoso. Evite la exposición directa a los haces.
4. REPRODUCCIÓN DE LA ETIQUETA: ETIQUETA
DE PRECAUCIÓN, COLOCADA EN EL INTE-
RIOR DE LA UNIDAD.
VARNING: Synlig Och
osynlig laserstrålning när
den öppnas och spärren är
urkopplad. Betrakta ej
strålen. (s)
CAUTION: Visible and invisible
laser radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE TO
BEAM. (e)
ADVARSEL: Synlig og usynlig
laserstråling når maskinen er
åben eller interlocken fejle.
Undgådirekte eksponering
til stråling. (d)
VARO: Avattaessa ja
Suojalukitus ohitettunatai
viallisena olet alttiina näkyvälle
ja näkymättömälle lasersäteilylle.
Vältäsäteen kohdistumista
suoraan itseesi. (f)

1
EnglishEspañol
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
Stereo headphone .............................................................. 1 pc.
Supplied Accessories
Thank you for purchasing this JVC product. Please read these
instructions carefully before starting operation to be sure to ob-
tain optimum performance and a longer service life from the unit.
Table of Contents
Power Supply Preparations............................ 2
About MP3 / WMA files ................................... 4
Basic Play ........................................................ 5
Other Play Methods ........................................ 9
Tuner Operation (XL-PR70B only) ............... 13
Concerning Compact Discs ......................... 16
Cautions ......................................................... 17
Troubleshooting ............................................ 19
Specifications ................................................ 20
Maintenance .................................................. 20

2
English
Español
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
Power Supply Prepara-
tions
Using dry-cell batteries (not supplied)
Caution:
Do not forcibly open the battery lid too wide.
Two “R6”(LR6) alkaline batteries.
Battery indicator
This indicator appears when the batteries are almost out
of power. Power will be cut off a short while later.
Note:
Turning off the Anti-Shock Protection EX will save the battery
power more or less. For details, see “Anti-shock Protection EX”
on page 12.(Available for an Audio CD only)
Battery indicator

3
EnglishEspañol
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
Using the AC adaptor (not supplied)
Notes:
•Even if the unit is turned off, small power is consumed as long
as the AC adaptor is connected to the AC power outlet.
•When you want to purchase the AC adaptor, see page 18.
AC adaptor
AC power outlet
Preventing Accidental Operation
(Hold mode)
This function causes the unit to ignore, accidental but-
ton presses.
Hold mode prevents the following:
•Powering on the unit accidentally (which can cause
the batteries to go dead).
•Play being cut off unexpectedly.
To use the Hold mode
OFF ON
HOLD
•To prevent the unit from powering on accidentally, set
the HOLD switch to the ON position while the unit is
turned off.
•To prevent the unit from unexpected operation during
play, set the HOLD switch to the ON position after you
starts playing the disc.
•When the unit is in Hold mode, “HOLD”and “”light
as follows.
Power on : “”stays lit.
Power off : “HOLD”and “”light up for a few sec-
onds when 6is pressed.
Note:
Before turning on the unit, be sure that HOLD is OFF.
Otherwise, you cannot turn on the unit.

4
English
Español
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
3
4
9
8
10
6
7
1
2
5
About MP3 / WMA files
MP3 / WMA File Compatibility
•This player can read MP3/WMA files that are recorded in the
format that is compliant with ISO 9660.
•The player can read or play an MP3 file with the extension code
—“.mp3”and a WMA file with the exrension code —“.wma”.
•Track title can be displayed.
•ID3* tags can be shown on the display.
* An MP3/WMA file can contain file information called “ID3 Tag”
where its album name, artist, title, etc. are recorded.
Playing order of MP3 / WMA files
The illustration below shows the normal playing order of the
MP3 / WMA files. You will see that the MP3 / WMA files are
played back in the order from the higher hierarchy to the
lower one.
Hierarchy
Group
MP3 /
WMA file

5
EnglishEspañol
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
Basic Play
WMA can be played back only with XL-PR70B.
1
4,6
5
2
3
1
RL
2
3
OFF ON
HOLD
4
VOLUME
Firmly
connect
Label side
(To be continued on the next page)

6
English
Español
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
5
00102 53
01 00 1 02 53
MP3 WMA
•Play stops automatically when all the track have been
played.
•(XL-PR70B) Press this button again when the FM
(Tuner) reception mode becomes active.
Track number in play
For Audio CD
Elapsed playing time of
each track
Elapsed playing time of
each track
Group number
Lights when a
MP3 / WMA disc is used
Track number (in the
group) in play
For MP3 / WMA
6
VOLUME
(ID3 tag)

7
EnglishEspañol
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
To pause
During play,
For Audio CD
00700 18
For MP3 / WMA
01 00400 07
Press again to restart play.
To stop
During play,
For Audio CD
01044 48
For MP3 / WMA
10035
Total number of tracks
Total playing time
Total number of groups
Total number of tracks
For your reference:
“DISC”
This indication appears if 6is pressed when no disc
is loaded or if the disc is not properly seated.
“READING”
Preparation period before playing the track.
Appears for several seconds after pressing 6to play.
“OPEN”
This indication appears when the lid is open.
Removing discs
Turn off the unit and, after the disc has stopped rotating,
remove the disc as shown below:
Auto power off
If the unit is left in stop mode for 30 seconds, the unit turns itself
off automatically to prevent the batteries from running down.
Disc rotation noise
The portable CD player uses a power-saving operation
method so that disc rotation noise will intermittently be emit-
ted. But, it is not a failure.

8
English
Español
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
To turn off the unit
While stopped,
Fast forward/reverse
Skip function
During play,
Search function
Keep depressed during play.
•To skip back to the previous track, quickly press 4twice.
•During Program play, the button is used to fast forward or back
through the programmed sequence of tracks.
•During Random play, the skip button cannot be used to skip
back to tracks that were played previously in the random se-
quence.
Forward
Reverse
Group skip (MP3 / WMA only)
During play or while stopped,
GROUP UP
GROUP DOWN
02001
Group number
(XL-PR70B only) To switch over the mode
from FM to CD
In FM mode,
No indication Forward
Reverse

9
EnglishEspañol
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
Random play
During playback,
MODE
RND
After playing all tracks, the unit stops.
To cancel
Press MODE until “RND”goes out, or press 7to stop
the disc.
Notes:
•You can also select Random play in stop mode.
•During Program play, you can not select Random play.
(Repeatedly)
Other Play Methods
Intro play
You can successively play the first 10 seconds of every track.
1While stopped,
MODE
INTRO
2
To cancel
Press MODE repeatedly until “INTRO”goes out.
Notes:
•You can also select Intro play during playback.
In this case, Intro play will start from the next track after the
current track has finished.
•You can also select Intro play during Program play mode.
(Repeatedly)

10
English
Español
Nederlands
XL-PM6S/XL-70B / LVT1297-005A [E]
You can program up to 64 tracks in any desired order including
the same tracks.
For Audio CD, go to step 3.
Though the display differs a little, operation is the same.
1While stopped,
(MP3 / WMA only)
00 000 P-01
PROGRAM
2(MP3 / WMA only) Select the desired group
number. (e.g.02)
02 001P-01
GROUP UP
G
ROUP DOWN
Program play
Program sequence number
Group number
3
PROGRAM
02 001 P-01
4Select the desired track.
02 003 P-01
5
00 000 P-02
PROGRAM
PROG
The track is registered.
Track number
