JVC RX-7032VSL User manual

For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1007-006A[B]
INSTRUCTIONS
AUDIO/VIDEO CONTROL RECEIVER
RX-7032VSL
MASTER VOLUME
PUSH OPEN
SUBWOOFER OUT ON/OFF
SPEAKERS ON/OFF
PHONES
1
STANDBY
RX-7032V AUDIO/VIDEO CONTROL RECEIVER
BASS BOOST
ANALOG DIRECT
2
STANDBY/ON
TV SOUND/DBS
VCR
DVDDVD MULTI AMFMTAPE/CDRCD
SETTING ADJUST
QUICK SPEAKER
SETUP EXIT
SURROUND
DSP
SURROUND/ DSP
OFF
+
−
+
−
+
−
231
564
89
7/P
0+10
∗FRONT•L
MENU
ENTER
∗FRONT•R
TESTCDDISC
MIDNIGHT
∗CENTER
∗ SUBWOOFER
∗
DIGITALEQ
∗
SURR BACK
∗SURR•L ∗SURR•R
SOUND
CH/
∗
LEVEL TVVOL
MUTING
DIMMER
VOLUME
CATV/DBS
CONTROL
TAPE/CDR
CONTROL
VCR
CONTROL
TV/VIDEO
REC PAUSE
SLEEP
RETURN FMMODE 100+
REMOTE CONTROL RM-SRX7032R
CATV/DBS VCR TV AUDIO
DSP
OFF
DVDMULTI CD
ANALOG/DIGITAL
BASS BOOST
TAPE/CDR
FM/AM
TV/DBS VCR
SURROUND
EX/ES
SURR/DSP
A/V CONTROL RECEIVER
INPUT
MODE
DIRECT
ANALOG
DVD
10/0
/REW FF/
TA/NEWS/INFO
DISPLAY
MODE
Cover_7032[B]f.pm6 03.3.7, 0:43 PM1

G-1
Warnings, Cautions and Others
IMPORTANT for the U.K.
DO NOT cut off the mains plug from this equipment. If the plug
fitted is not suitable for the power points in your home or the
cable is too short to reach a power point, then obtain an
appropriate safety approved extension lead or consult your
dealer.
BE SURE to replace the fuse only with an identical approved
type, as originally fitted.
If nonetheless the mains plug is cut off ensure to remove the
fuse and dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the mains supply.
If this product is not supplied fitted with a mains plug then follow
the instructions given below:
IMPORTANT.
DO NOT make any connection to the terminal which is marked
with the letter E or by the safety earth symbol or coloured green
or green-and-yellow.
The wires in the mains lead on this product are coloured in
accordance with the following code:
Blue : Neutral
Brown : Live
As these colours may not correspond with the coloured
markings identifying the terminals in your plug proceed as
follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
Caution –– STANDBY/ON switch!
Disconnect the mains plug to shut the power off completely.
The STANDBY/ON switch in any position does not discon-
nect the mains line. The power can be remote controlled.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to get
out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must
be considered and local rules or laws governing the
disposal of these batteries must be followed strictly.
• Do not use this apparatus in a bathroom or places with
water. Also do not place any containers filled with water or
liquids (such as cosmetics or medicines, flower vases,
potted plants, cups, etc.) on top of this apparatus.
Safety-7032[B]f.pm6 03.3.6, 4:14 PM1

G-2
SAFETY INSTRUCTIONS
“SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT”
This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be
taken if you are to obtain the best results and safety is to be assured.
Do read the operating instructions before you attempt to use the equipment.
Do ensure that all electrical connections (including the mains plug, extension leads and interconnections between pieces of equipment) are
properly made and in accordance with the manufacturer’s instructions. Switch off and withdraw the mains plug when making or changing
connections.
Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
Do be careful with glass panels or doors on equipment.
DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way–switch off, withdraw
the mains plug and consult your dealer.
DON’T remove any fixed cover as this may expose dangerous voltages.
DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or has
a standby mode.
Switch off using the switch on the equipment and make sure that your family know how to do this.
Special arrangements may need to be made for infirm or handicapped people.
DON’T use equipment such as personal stereos or radios so that you are distracted from the requirements of traffic safety. It is illegal to watch
television whilst driving.
DON’T listen to headphones at high volume as such use can permanently damage your hearing.
DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings.
Overheating will cause damage and shorten the life of the equipment.
DON’T use makeshift stands and NEVER fix legs with wood screws — to ensure complete safety always fit the manufacturer’s approved
stand or legs with the fixings provided according to the instructions.
DON’T allow electrical equipment to be exposed to rain or moisture.
ABOVE ALL
— NEVER let anyone, especially children, push anything into holes, slots or any other opening in the case -this could result in a fatal
electrical shock.;
— NEVER guess or take chances with electrical equipment of any kind — it is better to be safe than sorry!
Caution: Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage.
Locate the apparatus as follows:
Front: No obstructions open spacing.
Sides: No obstructions in 10 cm from the sides.
Top: No obstructions in 10 cm from the top.
Back: No obstructions in 15 cm from the back
Bottom: No obstructions, place on the level surface.
In addition, maintain the best possible air circulation as illustrated.
Wall or obstructions
Floor
Stand height 15 cm or more
Front
RX-7032VSL
Spacing 15 cm or more
Safety-7032[B]f.pm6 03.3.6, 4:14 PM2

1
Introduction
We would like to thank you for purchasing one of our JVC products.
Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance
from your unit, and retain this manual for future reference.
Precautions
Power sources
• When unplugging the receiver from the wall outlet, always pull
the plug, not the AC power cord.
• Do not handle the AC power cord with wet hands.
• If you are not going to operate the receiver for an extended period
of time, unplug the AC power cord from the wall outlet.
Ventilation
High power amplifiers built in this receiver will generate heat inside
the cabinet. For safety, observe the following carefully.
• Make sure there is good ventilation around the receiver. Poor
ventilation could overheat and damage the receiver.
• Do not block the ventilation openings or holes. (If the ventilation
openings or holes are blocked by a newspaper or cloth, etc., the
heat may not be able to get out.)
Others
• Should any metallic object or liquid fall onto the unit, unplug the
unit and consult your dealer before operating any further.
• Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled with liquids, such as vases
shall be placed on the apparatus.
• Do not disassemble the unit since there are no user serviceable
parts inside.
If anything goes wrong, unplug the AC power cord and consult your
JVC dealer.
Features
Compatible with various audio formats including
DTS 96/24
RX-7032VSL allows you to enjoy a newly introduced audio
format such as Dolby Digital EX, Dolby Pro Logic II, DTS-ES,
DTS Neo:6, and DTS 96/24.
• This unit is also compatible with Dual Mono signals recorded in
Dolby Digital and DTS discs.
DAP (Digital Acoustic Processor)
Sound field simulation technology allows precise ambience
recreation of existing theaters and halls. Thanks to the high-
performance DSP (Digital Signal Processor) and high-capacity
memory, you can enjoy multi-channel surround sound by playing
2-channel or multi-channel software according to the speaker
setting.
Multi-channel headphone virtual surround
sound—3D HEADPHONE Mode
The built-in headphone virtual surround system is compatible with
Multi-channel software like Dolby Digital, DTS Surround, etc.
Thanks to the new signal processing algorithms used by the high-
performance DSP, you can enjoy a natural surround sound through
the headphones.
COMPU LINK remote control system
The COMPU LINK remote control system allows you to operate
other JVC audio components from this receiver.
01-13_7032[B]f.pm6 03.3.6, 4:14 PM1

2
Table of Contents
Basic Settings ........................................... 24
Setting the Speakers Configuration .......................................... 24
Basic Setting Items ................................................................... 25
Basic Procedure ........................................................................ 26
Setting the Speakers ........................................................... 26
Setting the Speaker Distance ............................................. 27
Setting the Bass Sounds ..................................................... 27
Selecting main or sub channel—DUAL MONO ............... 28
Setting the Digital Input Terminals .................................... 28
Memorizing the Volume Level for Each Source ................ 28
Adjusting Sound ........................................ 29
Basic Setting Items ................................................................... 29
Basic Procedure ........................................................................ 29
Adjusting the Equalization Patterns ................................... 30
Adjusting the Speaker Output Levels ................................ 30
Adjusting the Sound Parameters for the
Surround and DSP Modes ........................................... 31
Using the Surround Modes .......................... 32
Reproducing Theater Ambience ................................................ 32
Introducing the Surround Modes ............................................. 32
Surround Modes Applicable to the Various Software .............. 34
Activating the Surround Modes ............................................... 35
7Activating the EX/ES setting ................................................ 35
7Activating the Surround Modes ............................................ 35
Using the DSP Modes ................................ 36
Reproducing the Sound Field ................................................... 36
Introducing the DSP Modes ..................................................... 36
Activating the DSP Modes ....................................................... 37
Using the DVD MULTI Playback Mode .......... 38
Activating the DVD MULTI Playback Mode .......................... 38
COMPU LINK Remote Control System ......... 39
Operating JVC’s Audio/Video Components ... 40
Operating Audio Components .................................................. 40
Operating Video Components .................................................. 42
Operating Other Manufacturers’ Video
Equipment ............................................ 43
Troubleshooting ......................................... 47
Specifications............................................ 48
Description of the PTY codes ...................... 48
Parts Identification ...................................... 3
Remote Control .......................................................................... 3
Front Panel ................................................................................. 4
Rear Panel .................................................................................. 6
Getting Started ........................................... 7
Before Installation ...................................................................... 7
Checking the Supplied Accessories ........................................... 7
Putting Batteries in the Remote Control .................................... 7
Connecting the FM and AM (MW) Antennas ............................ 7
Connecting the Speakers ............................................................ 8
Connecting Audio/Video Components ..................................... 10
7Analog Connections ............................................................. 10
7Digital Connections .............................................................. 13
Connecting the Power Cord ..................................................... 13
Basic Operations ....................................... 14
Daily Operational Procedure .................................................... 14
Turning On the Power .............................................................. 14
Selecting the Source to Play ..................................................... 14
Adjusting the Volume ............................................................... 15
Selecting the Front Speakers .................................................... 16
Activating and Adjusting the Subwoofer Sound ...................... 16
Selecting the Analog or Digital Input Mode ............................ 16
Setting the Dynamic Range ...................................................... 17
Attenuating the Input Signal .................................................... 17
Turning Analog Direct On and Off .......................................... 18
Changing the Source Name ...................................................... 18
Reinforcing the Bass ................................................................ 19
Muting the Sound ..................................................................... 19
Changing the Display Brightness ............................................. 19
Using the Sleep Timer .............................................................. 19
Receiving Radio Broadcasts ........................ 20
Tuning in to Stations Manually ................................................ 20
Using Preset Tuning ................................................................. 20
Selecting the FM Reception Mode ........................................... 21
Receiving FM Stations with RDS ............................................ 21
Searching for a Program by PTY Codes .................................. 22
Switching to a Program of Your Choice Automatically ........... 23
This mark indicates that ONLY the remote control
CAN be used for the operation explained.
Remote
NOT
This mark indicates that the remote control
CANNOT be used for the operation explained.
Use the buttons on the front panel.
01-13_7032[B]f.pm6 03.3.6, 4:14 PM2

3
Parts Identification
1buttons (14, 42 – 46)
CATV/DBS , VCR , TV , AUDIO
2Source selection buttons (14, 15, 16, 18, 20, 21, 35, 37, 38)
DVD MULTI, DVD, CD*, FM/AM*, TV/DBS, VCR,
TAPE/CDR*
* When you press one on these source selection buttons on the
remote control, the receiver automatically turns on.
3• SURROUND button (35)
• DSP button (37)
• SURR (surround)/DSP OFF button (35, 37)
• EX/ES button (35)
4CD DISC button (41)
5MIDNIGHT MODE button (17)
6SOUND button (19, 30, 31)
7CATV/DBS CONTROL button (44)
8TV/VIDEO button (42, 43)
9VCR CONTROL button (42)
pTAPE/CDR CONTROL button (41)
qREC PAUSE button (41, 42, 45)
wSLEEP button (19)
eANALOG/DIGITAL INPUT button (17)
rANALOG DIRECT button (18)
t• 10 keys for operating the tuner (21)
• 10 keys for adjusting sound (19, 30, 31)
• 10 keys for operating audio/video components (40 – 46)
y• CH (channel) +/– buttons (42 – 45)
• *LEVEL +/– buttons (30, 31, 40)
The LEVEL +/– buttons function only after pressing SOUND
then 10 keys which are marked with an asterisk (*) on the
remote control.
uVOLUME +/– buttons (15)
iTV VOL (volume) +/– buttons (42, 43)
oMUTING button (19)
;• RDS operation buttons (22, 23)
TA/NEWS/INFO, PTY SEARCH, PTY9, (PTY,
DISPLAY MODE
• Operating buttons for audio/video components
(40 – 42, 45, 46)
3, 8, 7, 4/REW, FF/¢
aDIMMER button (19)
Remote Control
A/V CONTROL RECEIVER
+
−
+
−
+
−
231
564
89
7/P
0
+10
MENU
ENTER
TESTCD DISC ∗CENTER∗ SUB WOOFER
∗DIGITAL EQ ∗SURR BACK
CH/∗LEVEL TV VOL
/REW FF/
MUTING
DIMMER
VOLUME
CATV/DBS
CONTROL
VCR
CONTROL TAPE/CDR
CONTROL
TV/VIDEO
REC PAUSE
SLEEP
RETURN FM MODE 100+
REMOTE CONTROL RM-SRX7032R
CATV/DBS VCR TV AUDIO
DSP
OFF
DVD MULTI CD
TAPE/CDR
ANALOG/DIGITAL
FM/AM
TV/DBS VCR
SURROUND
EX/ES
SURR/DSP
INPUT
MIDNIGHT
MODE
DIRECT
ANALOG
DVD
u
i
2
3
8
9
p
q
w
t
a
10/0
y
1
SOUND
7
5
4
6
o
r
e
BASS BOOST
TA/NEWS/INFO
DISPLAY
MODE
;
01-13_7032[B]f.pm6 03.3.6, 4:14 PM3

4
Display Window
Front Panel
SUBWOOFER OUT ON/OFF
SPEAKERS ON/OFF
PHONES
1
STANDBY
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
BASS BOOST
ANALOG DIRECT
2
STANDBY/ON
SETTING ADJUST
QUICK SPEAKER
SETUP EXIT
SURROUND
DSP
SURROUND/ DSP
OFF
PUSH SET
MULTI JOG
MASTER VOLUME
12
oa u;
4 5 7
y i
p
9
3
TV SOUND/DBS
VCR
DVDDVD MULTI AMFMTAPE/CDRCD
PUSH –OPEN
Inside the front door
MIDNIGHT
MODEEX / ES
INPUT ATT
INPUT
ANALOG
INPUT
DIGITAL
r
eq w
FM/AM TUNING FM/AM PRESET FM MODE MEMORY
TUNER CONTROL
t
68
Front Panel
1STANDBY/ON button and STANDBY lamp (14)
2• SPEAKERS ON/OFF 1 button (16)
• SPEAKERS ON/OFF 2 button (16)
3• SURROUND button (35)
• DSP button (37)
• SURROUND/DSP OFF button (35, 37)
4Remote sensor
5Display window (14)
6Source selection buttons (14, 15, 16, 18, 20, 21, 35, 37, 38)
DVD MULTI, DVD, VCR , TV SOUND/DBS, CD,
TAPE/CDR, FM, AM
7MASTER VOLUME control (15)
8BASS BOOST button and lamp (19)
9SUBWOOFER OUT ON/OFF button (16)
pPHONES jack (16)
qEX/ES button (35)
w• INPUT ANALOG button (17)
• INPUT ATT button (17)
eMIDNIGHT MODE button (17)
rINPUT DIGITAL button (17)
tTUNER CONTROL buttons
• FM/AM TUNING 5/ ∞buttons (20)
• FM/AM PRESET 5/ ∞buttons (20, 21)
• FM MODE button (21)
• MEMORY button (20)
ySETTING button (26)
uQUICK SPEAKER SETUP button (24)
i• MULTI JOG control (24, 26, 29)
• PUSH SET button (24, 26, 29)
oEXIT button (26, 29)
;ADJUST button (29)
aANALOG DIRECT button and lamp (18)
01-13_7032[B]f.pm6 03.3.6, 4:14 PM4

5
Display Window
1DUAL indicator (33)
2ANALOG indicator (17)
3DIGITAL AUTO indicator (17)
496/24 indicator (33)
5MULTI indicator (38)
6RDS indicator (21)
7Program type (TA/NEWS/INFO) indicators (23)
8•PRO LOGIC indicator (32)
•PRO LOGIC II indicator (33)
9TUNED indicator (20)
0STEREO indicator (20, 21)
-NEO:6 indicator (33)
=AUTO MUTING indicator (21)
~VIRTUAL SB (Surround Back) indicator (32, 33)
!ONE TOUCH OPERATION indicator (28)
@SLEEP indicator (19)
#MIDNIGHT MODE indicator (17)
$DIGITAL EQ (equalization) indicator (30)
%Speaker and signal indicators (15)
^Digital signal format indicators (17)
&Main Display (14)
*DSP indicator (16, 36)
(3D-PHONIC indicator (36)
)HEADPHONE indicator (16, 36)
_SPEAKERS 1/2 indicators (16)
+INPUT ATT (attenuator) indicator (17)
¡VOLUME level indicator (14, 19)
™BASS BOOST indicator (19)
Display Window
DIGITAL EQ
INPUT ATT
SLEEP
VOLUME
ONE TOUCH OPERATION
3D - PHONIC
NEO:6 VIRTUAL SB MIDNIGHT MODE
TA
NEWS
AUTO MUTING
INFO
TUNED STEREO
RDS
LINEAR PCM
DIGITAL
L
SUBWFR
LS RS
CR
S
LFE
DUAL DIGITAL AUTO ANALOG 96/24 MULTI
PRO LOGIC
DSP
HEADPHONE SPEAKERS 1 2 BASS BOOST
SB
%^&¡
123457896 0=
-~! @
™
*()
$
#
_ +
Press down on PUSH-OPEN.
How to open the front door
01-13_7032[B]f.pm6 03.3.6, 4:14 PM5

6
Rear Panel
FRONT SPEAKERS
VIDEO
RIGHT LEFT S-VIDEO
VIDEO
AUDIO
DIGITAL IN
DIGITAL 1 (DVD)
DIGITAL 2 (CD)
DIGITAL 3 (TV)
DIGITAL 4 (CDR)
PCM/ DOLBY DIGITAL
/ DTS
DIGITAL OUT
FM 75
COAXIAL
AM
EXT
AM
LOOP
RIGHT LEFT
+
–
+
–
12
CENTER
SPEAKER
SURROUND SPEAKERS
816
CAUTION : SPEAKER IMPEDANCE
MONITOR
OUT
SUBWOOFER CENTER
DVD
IN
SURR
(REAR)
TAPE
CDR
FRONT
TV SOUND
DBS
IN
VCR
IN
(PLAY)
IN
(PLAY)
OUT
(REC)
OUT
(REC)
CD
IN
RIGHT LEFT
DVD
IN ANTENNA
COMPU LINK-4
(SYNCHRO)
SURROUND BACK SPEAKERS
RIGHT LEFT RIGHT LEFT
RIGHT LEFT
CAUTION : SPEAKER IMPEDANCE
SINGLE USE
See Instruction
Manual For
Connection
1
OR 2 : 816
1 AND 2 : 16 32
SUBWOOFER
OUT
+ +
– –
12345 6 7
wq98 p e
Rear Panel
1DIGITAL IN terminals (13)
• Coaxial: DIGITAL 1 (DVD)
• Optical: DIGITAL 2 (CD), DIGITAL 3 (TV),
DIGITAL 4 (CDR)
2AUDIO input/output jacks (10 – 12)
• Input: DVD IN—FRONT, CENTER, SUBWOOFER,
SURR (REAR), TV SOUND/DBS IN,
VCR IN (PLAY), TAPE/CDR IN (PLAY), CD IN
• Output: VCR OUT (REC), TAPE/CDR OUT (REC)
3S-VIDEO and composite VIDEO input/output jacks (11, 12)
• Input: DVD IN, TV SOUND/DBS IN, VCR IN (PLAY)
• Output: VCR OUT (REC), MONITOR OUT
4FM/AM ANTENNA terminals (7, 8)
5SUBWOOFER OUT jack (9)
6COMPU LINK-4 (SYNCHRO) terminals (39)
7AC power cord (13)
8DIGITAL OUT terminal (13)
9SURROUND BACK SPEAKERS terminal (9)
pSURROUND SPEAKERS terminal (9)
qCENTER SPEAKER terminal (9)
wFRONT SPEAKERS 1terminals (9)
eFRONT SPEAKERS 2terminals (9)
01-13_7032[B]f.pm6 03.3.6, 4:14 PM6

7
FM 75
COAXIAL
AM
EXT
AM
LOOP
ANTENNA
FM 75
COAXIAL
ANTENNA
FM 75
COAXIAL
ANTENNA
Getting Started
This section explains how to connect audio/video components and speakers to the receiver, and how to connect the
power supply.
Before Installation
General Precautions
•Be sure your hands are dry.
•Turn the power off to all components.
•Read the manuals supplied with the components you are going to
connect.
Locations
•Install the receiver in a location that is level and protected from
moisture.
•The temperature around the receiver must be between –5˚C and
35˚C.
•Make sure there is good ventilation around the receiver. Poor
ventilation could cause overheating and damage the receiver.
Handling the receiver
•Do not insert any metal object into the receiver.
•Do not disassemble the receiver or remove screws, covers, or
cabinet.
•Do not expose the receiver to rain or moisture.
Checking the Supplied Accessories
Check to be sure you have all of the following items, which are
supplied with the receiver.
The number in the parentheses indicates quantity of the pieces
supplied.
• Remote Control (1)
• Batteries (2)
• AM (MW) Loop Antenna (1)
• FM Antenna (1)
If anything is missing, contact your dealer immediately.
Putting Batteries in the Remote Control
Before using the remote control, insert the two supplied batteries
first.
1. Press and slide the battery cover on the back of
the remote control.
2. Insert the batteries.
•Make sure to match the polarity: (+) to (+) and (–) to (–).
3. Replace the cover.
B
FM Antenna (supplied)
Outdoor FM Antenna Cable
(not supplied)
Extend the supplied FM antenna
horizontally.
A
If the remote control cannot transmit signals or operate the receiver
correctly, replace the batteries. Use two LR6(AM3)/L40(15A) type
dry-cell batteries.
Notes:
• Supplied batteries are for the initial setup. Replace the batteries for
continued use.
• After replacing the batteries, set the manufacturers’ codes again
(see pages 43 to 46).
CAUTION:
Follow these precautions to avoid leaking or cracking cells:
•Place batteries in the remote control so they match the polarity:
(+) to (+) and (–) to (–).
•Use the correct type of batteries. Batteries that look similar may
differ in voltage.
•Always replace both batteries at the same time.
•Do not expose batteries to heat or flame.
Connecting the FM and AM (MW)
Antennas
FM Antenna Connections
A. Using the Supplied FM Antenna
The FM antenna provided can be connected to the FM 75 Ω
COAXIAL terminal as temporary measure.
B. Using the Standard Type Connector (Not Supplied)
A standard type connector (IEC or DIN45325) should be
connected to the FM 75 ΩCOAXIAL terminal.
Note:
If reception is poor, connect the outdoor FM antenna (not supplied).
Before attaching a 75 Ω coaxial cable with a standard type connector
(the kind with a round wire going to an outdoor antenna), disconnect
the supplied FM antenna.
12
LR6(AM3)/
L40(15A)
3
01-13_7032[B]f.pm6 03.3.6, 4:14 PM7

8
RIGHT LEFT
RIGHT LEFT
RIGHT LEFT
+
–
RIGHT LEFT
+
–
RIGHT LEFT
AM (MW) Antenna Connections
Turn the loop until you have the
best reception.
AM (MW) Loop
Antenna (supplied)
Snap the tabs on the loop into the slots
of the base to assemble the AM (MW)
loop.
Outdoor single vinyl-covered wire (not supplied)
Notes:
•If the AM (MW) loop antenna wire is covered with vinyl,
remove the vinyl by twisting it as illustrated.
•Make sure the antenna conductors do not touch any
other terminals, connecting cords and power cord. This
could cause poor reception.
•If reception is poor, connect an outdoor single vinyl-covered wire
(not supplied) to the AM EXT terminal. (Keep the AM (MW) loop
antenna connected.)
Connecting the Speakers
You can connect the following speakers:
•Two pairs of front speakers to produce normal stereo sound.
•One pair of surround speakers to enjoy the surround effect.
•One surround back speaker or one pair of surround back speakers
to enjoy to produce more effective surround effect.
•One center speaker to emphasize human voices.
•One subwoofer to enhance the bass.
CAUTION:
Use only the speakers of the SPEAKER IMPEDANCE indicated by
the speaker terminals.
•When connecting to both of the FRONT SPEAKERS 1and 2
terminals, use speakers with an impedance of 16 Ωto 32 Ω.
•When connecting to either the FRONT SPEAKERS 1or 2
terminals, use speakers with an impedance of 8 Ωto 16 Ω.
Basic connecting procedure
1 Twist and remove the insulation at
the end of each speaker signal cable
(not supplied).
2 Open the speaker terminal.
For FRONT SPEAKERS 2terminals
3 Insert the speaker signal cable.
4 Close the speaker terminal.
For each speaker (except for a subwoofer), connect the (+) and
(–) terminals on the rear panel to the (+) and (–) terminals
marked on the speakers.
Subwoofer
Speaker layout
Ideal speaker layout varies depending on the conditions of your
listening room. The diagram below is a recommended typical
example.
Left front speaker(s)
(L)
Right front speaker(s)
(R)
Center speaker
(C)
Surround back speakers (LSB/RSB)
Left surround
speaker (LS)
Right surround
speaker (RS)
+
–
RIGHT LEFT
FM 75
COAXIAL
AM
EXT
AM
LOOP
ANTENNA
23
1
01-13_7032[B]f.pm6 03.3.6, 4:14 PM8

9
Placing speakers
Front speakers and center speaker
•Place these speakers (position of the mid-range speaker units) at the same
height from the floor.
•Point these speakers aiming at the listener’s ears.
Surround and surround back speakers
•Place these speakers at a position which is 1 meter higher than the listener’s
ears.
•Point these speakers down aiming at the listener’s ears.
Subwoofer
•You can place it wherever you like since bass sound is non-directional.
Normally place it in front of you.
Note:
Ideal speaker layout requires that all speakers be placed at the same distance
from the listener. However, since in some places it may be difficult to fulfil this
requirement, this unit can adjust the delay time so that the sounds through all the
speakers reach the listener with the same timing. (See page 27.)
Subwoofer
IMPORTANT:
After connecting the speakers, set the speaker installation
information properly. You can use Quick Speaker Setup
for easy speaker installation information setting (see page
24).
•To obtain the best possible Surround/DSP effect, see
“Setting the Speakers”on page 26.
* When using only one surround
back speaker, connect the ª cord
to the RIGHT ª terminal and the
· cord to the LEFT · terminal.
Connecting the subwoofer speaker
You can enhance the bass by connecting a subwoofer.
Connect the input jack of a powered subwoofer to the rear
panel, using a cable with RCA pin plugs (not supplied).
C
LR
LS RS
LSB RSB
SB*
* When one surround back speaker is
connected.
Front speakers 1
Right / Left
Surround back speakers*
Right / Left
Front speakers 2
Right / Left
Center speaker
Surround speakers
Right / Left
RIGHT LEFT
+
–
+
–
12
CENTER
SPEAKER
SURROUND SPEAKERS
816
CAUTION : SPEAKER IMPEDANCE
SURROUND BACK SPEAKERS
RIGHT LEFT RIGHT LEFT
RIGHT LEFT
CAUTION : SPEAKER IMPEDANCE
SINGLE USE
See Instruction
Manual For
Connection
1
OR 2 : 816
1 AND 2 : 16 32
+ +
– –
FRONT SPEAKERS
SUBWOOFER
OUT
RIGHT LEFT
+
–
CAUTION : SPEAKER IMPEDANC
SURROUND BACK SPEAKERS
SINGLE USE
See Instruction
Manual For
Connection
01-13_7032[B]f.pm6 03.3.6, 4:14 PM9

10
Connecting Audio/Video Components
When connecting individual components, refer also to the manuals
supplied with them.
Analog Connections
If your audio components have digital audio output terminal,
connecting them using the digital cords explained in “Digital
Connections”(see page 13) will give you better sound quality.
Audio component connections
Use the cables with RCA pin plugs (not supplied).
•Connect the white plug to the audio left jack, and the red plug to
the audio right jack.
If your audio components have a COMPU LINK jack
See also page 39 for detailed information about the connection
and the COMPU LINK remote control system.
CAUTION:
If you connect a sound-enhancing device such as a graphic equalizer
between the source components and this receiver, the sound output
through this receiver may be distorted.
To audio output
To audio input
Cassette deck
CD player
To listen to the sound after connection, press CD.
To audio
output
CD player
TAPE
CDR
IN
(PLAY)
OUT
(REC)
R
L
R
L
Cassette deck
To listen to the sound after connection, press TAPE/CDR.
You can connect either a cassette deck or a CD recorder to the
TAPE/CDR jacks. When connecting an CD recorder to the TAPE/
CDR jacks, see below.
CD
IN
R
L
CD recorder
To listen to the sound after connection, press TAPE/CDR.
You can connect either a CD recorder or a cassette deck to the
TAPE/CDR jacks. When connecting a cassette deck to the TAPE/
CDR jacks, see above.
Note:
When connecting a CD recorder to the TAPE/CDR jacks, change the
source name to “CDR,”which will be shown on the display when it is
selected as the source. See page 18 for details.
To audio output
To audio input
CD recorder
TAPE
CDR
IN
(PLAY)
OUT
(REC)
R
L
R
L
01-13_7032[B]f.pm6 03.3.6, 4:14 PM10

11
Video component connections
Use the cables with RCA pin plugs (not supplied).
Connect the white plug to the audio left jack, the red plug to the
audio right jack, and the yellow plug to the video jack.
• If your video components have S-video (Y/C-separation)
terminals, connect them using an S-video cable (not supplied). By
using this jack, you can get better picture quality than Composite
video.
IMPORTANT:
This receiver is equipped with the following video jacks—composite
video and S-video jacks. You can use any of the two to connect a
video component.
However, the video signals from one type of these input jacks are
transmitted only through the video output jacks of the same
type.
Therefore, if a recording video component and a playing video
component are connected to the receiver through the video jacks of
different type, you cannot record the picture. In addition, if the TV and
a playing video component are connected to the receiver through the
video jacks of different type, you cannot view the playback picture on
the TV.
VCR
To listen to the sound after connection, press VCR.
ÅTo audio input
ıTo audio output
ÇTo S-video output
ÎTo composite video output
‰To S-video input
ÏTo composite video input
VCR
VCR
IN
(PLAY)
OUT
(REC)
A B DC E F
R
L
R
L
MONITOR
OUT
TV SOUND
DBS
IN
A
B
C
R
L
TV and/or DBS tuner
To listen to the sound after connection, press TV SOUND/DBS (or
TV/DBS on the remote control).
DBS tuner
ÅTo audio output
ıTo S-video input
ÇTo composite video input
When “TV” has
been assigned as
the source name
(see page 18), No
signal comes out of
these terminals.
ÅTo audio output
ıTo S-video output
ÇTo composite video output
Note:
When connecting a DBS tuner to the TV SOUND/DBS IN jacks,
change the source name to “DBS,” which will be shown on the display
when selected as the source. Otherwise you cannot view any picture
from DBS tuner. See page 18 for details.
Connect the TV to appropriate MONITOR OUT jacks to view
the playback picture from any other connected video
components.
TV
TV SOUND
DBS
IN
A
B
C
R
L
DBS
01-13_7032[B]f.pm6 03.3.6, 10:53 PM11

12
• When you connect a DVD player with its analog discrete
output (5.1-channel reproduction) jacks:
To listen to the sound after connection, press DVD MULTI.
ÅTo subwoofer output
ıTo center channel audio output
ÇTo S-video output
ÎTo composite video output
To left/right front channel audio output
ÏTo left/right surround channel audio output
DVD player
• When you connect a DVD player with stereo output jacks:
To listen to the sound after connection, press DVD.
ÅTo S-video output
ıTo composite video output
ÇTo left/right front channel audio output (or to audio-
mixed output if necessary)
DVD player
DVD player
DVD
VIDEO
RIGHT LEFT
S-VIDEO
VIDEO
AUDIO
SUBWOOFER CENTER
DVD
IN
FRONT
DVD
IN
SURR
(REAR)
RL
A
B
C
DVD
VIDEO
RIGHT LEFT
S-VIDEO
VIDEO
AUDIO
SUBWOOFER CENTER
DVD
IN
FRONT
DVD
IN
SURR
(REAR)
RL
RL
A
B
C
DE F
01-13_7032[B]f.pm6 03.3.6, 4:14 PM12

13
DIGITAL IN
DIGITAL 1 (DVD)
DIGITAL 2 (CD)
DIGITAL 3 (TV)
DIGITAL 4 (CDR)
PCM/ DOLBY DIGITAL
/ DTS
DIGITAL OUT
Digital Connections
This receiver is equipped with four DIGITAL IN terminals—one
digital coaxial terminal and three digital optical terminals—and one
DIGITAL OUT (optical) terminal on the rear.
IMPORTANT:
•When connecting a DVD player, digital TV broadcast tuner or DBS
tuner using the digital terminals, you also need to connect it to the
video jacks on the rear. Without connecting it to the video jacks, you
can view no playback picture.
•After connecting the components using the DIGITAL IN terminals,
set the following correctly if necessary.
–Set the digital input (DIGITAL IN) terminal setting correctly. For
details, see “Setting the Digital Input Terminals”on page 28.
–Select the digital input mode correctly. For details, see “Selecting
the Analog or Digital Input Mode”on page 16.
Notes:
•When shipped from the factory, the DIGITAL IN terminals have
been set for use with the following components:
–DIGITAL 1 (coaxial): For DVD player
–DIGITAL 2 (optical): For CD player
–DIGITAL 3 (optical): For digital TV broadcast tuner
–DIGITAL 4 (optical): For CD recorder
•When you want to operate the CD player or CD recorder, using the
COMPU LINK remote control system, connect the target
component also as described in “Analog Connections”(see pages
10).
Digital input terminals
You can connect any digital components having coaxial or optical
digital output terminal.
Digital output terminal
You can connect any digital components which have an optical
digital input terminal.
Digital coaxial cable (not supplied)
between digital coaxial terminals
Digital optical cable (not supplied)
between digital optical terminals
Before connecting a digital
optical cable, unplug the
protective plug.
When the component has a digital
optical output terminal, connect it to the
DIGITAL 2 (CD), DIGITAL 3 (TV) or
DIGITAL 4 (CDR) terminal, using a
digital optical cable (not supplied).
When the component has a digital
coaxial output terminal, connect it to
the DIGITAL 1 (DVD) terminal, using a
digital coaxial cable (not supplied).
When the digital recording
equipment such as an MD recorder
and CD recorder has a digital
optical input terminal, connecting it
to the DIGITAL OUT terminal
enables you to perform digital-to-
digital recording.
Digital optical cable (not supplied)
between digital optical terminals
Note:
The digital signal format transmitted through the DIGITAL OUT
terminal is the same as that of the input signal. This means that when
the DTS Digital Surround signals are input, the DTS Digital Surround
signals are transmitted.
Connecting the Power Cord
Before plugging the receiver into an AC outlet, make sure that all
connections have been made.
Plug the power cord into an AC outlet.
Keep the power cord away from the connecting cables and the
antenna. The power cord may cause noise or screen interference.
Note:
The preset settings such as preset channels and sound adjustment
may be erased in a few days in the following cases:
–When you unplug the power cord.
–When a power failure occurs.
CAUTIONS:
•Do not touch the power cord with wet hands.
•Do not pull on the power cord to unplug the cord. When unplugging
the cord, always grasp the plug so as not to damage the cord.
01-13_7032[B]f.pm6 03.3.6, 4:14 PM13

14
Basic Operations
The following operations are commonly used when you play any sound sources.
Operations hereafter will be explained using the buttons on the front panel.
You can also use the buttons on the remote control for the same functions if they have the same and similar names/marks.
Selecting the Source to Play
Press one of the source selection buttons.
The selected source name and the previously selected Surround/DSP
mode also appear on the display.
Selected source name and current
Surround/DSP mode appear
Note:
When connecting CD recorder (to the TAPE/CDR IN jacks) and a DBS
tuner (to the TV SOUND/DBS IN jacks), change the source names
shown on the display. For details, see page 18.
Daily Operational Procedure
1Turn on the power.
•See “Turning On the Power”below.
2Select the source.
•See “Selecting the Source to Play”to the right.
3Adjust the volume.
•See “Adjusting the Volume”on page 15.
4Select the surround or DSP modes.
•See “Activating the Surround Modes”(page 35) and
“Activating the DSP Modes”(page 37).
Turning On the Power
Press STANDBY/ON (or AUDIO on the remote
control).
The STANDBY lamp goes off. The name of the current source and
Surround/DSP mode appear on the display.
Current source name and Surround/DSP mode appear
Current volume level appears
To turn off the power (into standby mode),
press STANDBY/ON (or AUDIO on the remote control)
again.
The STANDBY lamp lights up.
Note:
A small amount of power is consumed in standby mode. To turn off
the power completely, unplug the AC power cord.
On the unit
On the remote
DVD MULTI CD
TAPE/CDR
FM/AM
TV/DBS VCR
DVD
TV SOUND/DBSVCR
DVDDVD MULTI AMFMTAPE/CDRCD
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
13
4
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
2
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
VOLUME
LINEAR PCM
L
SUBWFR
R
ANALOG
SPEAKERS 1
DIGITAL EQ
INPUT ATT
SLEEP
VOLUME
ONE TOUCH OPERATION
3D - PHONIC
NEO:6 VIRTUAL SB MIDNIGHT MODE
TA
NEWS
AUTO MUTING
TUNED STEREO
RDS
LINEAR PCM
DIGITAL
L
SUBWFR
LS RS
CR
S
LFE
DUAL DIGIGTAL AUTO ANALOG 96/24 MULTI
PRO LOGIC
DSP
HEADPHONE SPEAKERS 1 2 BASS BOOST
SB
INFO
14-19-7032[B]f.pm6 03.3.6, 4:14 PM14

15
Signal indicators
Speaker indicators
On the unit On the remote
Speaker and signal indicators on the display
By checking the following indicators, you can easily confirm which
speakers you are activating and which signals are coming into this
receiver.
What speaker indicators light depends on the speaker setting
(for details, see “Setting the Speakers”on page 26).
•The frames of “L,”“C,”“R,”“LS,”“RS, ”and “SB”light up,
when the corresponding speakers are set to “LARGE”or
“SMALL”and when the speaker is required for the Surround/DSP
mode currently selected.
•When “SUB WOOFER”is set to “YES,”
SUBWFR
lights up (see
page 26).
•All three frames on the row of “SB”are not used at the same time.
When “SBACK OUT”is set to “2SPK,”the left and the right ones
are used. When it is set to “1SPK,”the middle one is used (see
page 26).
The signal indicators light up to show the incoming signals.
L:•When digital input is selected: Lights up when the left
channel signal comes in.
•When analog input is selected: Always lights up.
R:•When digital input is selected: Lights up when the right
channel signal comes in.
•When analog input is selected: Always lights up.
C: Lights up when the center channel signal comes in.
LFE: Lights up when the LFE channel signal comes in.
LS: Lights up when the left surround channel signal comes in.
RS: Lights up when the right surround channel signal comes in.
S: Lights up when the monaural surround channel signal
comes in.
SB: Lights up when the surround back channel signal comes in.
Note:
When “DVD MULTI”is selected as the source, “L,”“C,”“R,”“LFE,”“LS,”
and “RS”light up.
AMFMTAPE/CDRCD
CD
TAPE/CDR
FM/AM
Adjusting the Volume
On the front panel:
To increase the volume, turn MASTER VOLUME clockwise.
To decrease the volume, turn it counterclockwise.
From the remote control:
To increase the volume, press VOLUME +.
To decrease the volume, press VOLUME –.
CAUTION:
Always set the volume to the minimum before starting any sources. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
Notes:
•The volume level can be adjusted within the range of “0”(minimum)
to “70”(maximum).
•If you set One Touch Operation to “ON”(see page 28), you do not
have to adjust the volume level each time you change the source. It
is automatically set to the stored level.
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
Selecting different sources for picture and
sound
While watching pictures from a video source, you can listen to
sound of an audio source.
•Once you have selected a video source, pictures of the selected
source are sent to the TV until you select another video source.
Press one of the audio source selection buttons while viewing the
picture from a video component such as the VCR or DVD
player, etc.
Ex. No sound comes out of the
center speaker and surround
back speakers though center
channel and surround back
channel signals are coming
into this receiver.
How to understand the speaker and signal indicator
illumination
SUBWFR
LCR
LS RS
LFE
LCR
SLS
SB
RS
SB
LFE SUBWFR
LCR
LS RS
SB
14-19-7032[B]f.pm6 03.3.6, 4:14 PM15

16
Activating and Adjusting the
Subwoofer Sound
You can cancel the subwoofer sound even though you have
connected a subwoofer and have set “SUB WOOFER”to “YES”
(see page 29). This is useful when enjoying surround sound at night.
Press SUBWOOFER OUT ON/OFF to cancel the subwoofer
sound output.
Each time you press the button, subwoofer sound output is
deactivated (“SUBWFR OFF”) and activated (“SUBWFR ON”)
alternately.
•When subwoofer sound output is activated, subwoofer output level
can be adjusted using the remote control.
1 Press SOUND.
2 Press SUBWOOFER.
3 Press LEVEL + or –to adjust the output level
(–10 dB to +10 dB)
Notes:
You cannot deactivate the subwoofer sound output when you set
“SMALL”for the front speakers on the speaker size setting (see page
26) or Quick Speaker Setup (see page 26).
Listening with headphones only:
Deactivate both sets of the front speakers, and connect headphones
to the PHONES jack.
You can enjoy the sound effects through the headphones when
Surround or DSP mode is activated—3D HEADPHONE
(3D H PHONE) mode.
•“3D H PHONE”appears on the display and the DSP and
HEADPHONE indicator lights up on the display. (For details, see
page 34.)
Note:
When you select “DVD MULTI”as the source or any one of the
Surround/DSP mode which activates the center and/or surround
speaker(s), you can use only one set of the speakers.
CAUTION:
Be sure to turn down the volume:
•Before connecting or putting on headphones, as its high volume can
damage both the headphones and your hearing.
•Before turning on speakers again, as its high volume may come out
of the speakers.
Selecting the Front Speakers
When you have connected two pairs of the front speakers, you can
select which to use.
To use the speakers connected to the FRONT SPEAKERS 1
terminals, press SPEAKERS ON/OFF 1 so that the SPEAKERS 1
indicator lights up on the display. Make sure that the SPEAKERS 2
indicator is not lit on the display.
To use the speakers connected to the FRONT SPEAKERS 2
terminals, press SPEAKERS ON/OFF 2 so that SPEAKERS 2
indicator lights up on the display. Make sure that the SPEAKERS 1
indicator is not lit on the display.
To use both sets of the speakers, press SPEAKERS ON/OFF 1 and
SPEAKERS ON/OFF 2 so that the SPEAKERS 1/2 indicators light
up on the display.
To use neither sets of the speakers, press SPEAKERS ON/OFF 1
and SPEAKERS ON/OFF 2 so that the SPEAKERS 1/2 indicators
go off from the display.
The HEADPHONE indicator lights up and “HEADPHONE”
appears on the display.
•Activating the speakers turns on the Surround and DSP modes
previously selected.
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
Selecting the Analog or Digital Input Mode
When you have connected digital source components using the
digital terminals (see page 13), change the input mode for these
components to the digital input mode.
Before you start, remember...
The digital input terminal setting should be correctly done for
the sources you want to select the digital input mode (see
“Setting the Digital Input Terminals”on pages 28).
1. Press one of the source selection buttons for which you
want to change the input mode.
* If “TAPE”has been assigned as the source name, digital input
mode is not available. To change the source name, see “Changing
the Source Name”on page 18.
1
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
2
Remote
NOT
Remote
NOT
TV SOUND/DBSVCR
DVDDVD MULTI AMFMTAPE/CDRCD
CD
TAPE/CDR TV/DBS
DVD
On the unit
On the remote
14-19-7032[B]f.pm6 03.3.6, 4:14 PM16

17
LINEAR PCM
DIGITAL
2. Press INPUT DIGITAL (or ANALOG/DIGITAL
INPUT on the remote control) to select “DGTL
AUTO.”
The DIGITAL AUTO indicator lights up on the display.
•When selecting “DIGITAL AUTO,”the following indicators
indicate the digital signal format of the incoming signal.
: Lights up when Linear PCM signals come
in.
: Lights up when Dolby Digital signals
come in.
: Lights up when DTS signals come in.
No indicator lights up when the receiver cannot recognize the
digital signal format of the incoming signals.
When playing software encoded with the Dolby Digital or DTS,
the following symptoms may occur:
•Sound does not come out at the beginning of playback.
•Noise comes out while searching for or skipping chapters or
tracks.
In this case, press INPUT DIGITAL repeatedly to select
“DGTL D.D”or “DGTL DTS”while “DGTL AUTO”
still remains on the display.
•As you press INPUT DIGITAL, the input mode changes as
follows:
When “DGTL D.D”or “DGTL DTS”is selected, the AUTO
indicator goes off, and the corresponding digital signal format
indicator lights up on the display.
•If the incoming signal does not match the selected digital signal
format, the frame of the selected indicator will flash.
Note:
When you turn off the power or select another source, “DGTL D.D”
and “DGTL DTS”settings are canceled and the digital input mode is
automatically reset to “DGTL AUTO.”
To select the analog input mode again
Press INPUT ANALOG (or press ANALOG/DIGITAL INPUT on
the remote control repeatedly until “ANALOG”appears on the
display). The ANALOG indicator lights up.
VOLUME
DIGITAL
L
SUBWFR
LS RS
CR
LFE
DIGITAL AUTO
SPEAKERS 1
DGTL AUTO DGTL D.D
DGTL DTS
(Dolby Digital)
(Digital)
VOLUME
LINEAR PCM
L
SUBWFR
R
ANALOG
SPEAKERS 1
VOLUME
DIGITAL
L
SUBWFR
LS RS
CR
LFE
DIGITAL AUTO
SPEAKERS 1
Setting the Dynamic Range
You can enjoy a powerful sound at night using the Midnight Mode.
Press MIDNIGHT MODE so that “MID NIGHT 1”or “MID
NIGHT 2”appears on the display.
The MIDNIGHT MODE indicator also lights up.
MID NIGHT 1: Select when you want to reduce the dynamic
range a little.
MID NIGHT 2: Select when you want to apply the compress
effect fully (useful at midnight).
MID NIGHT OFF: Select when you want to enjoy surround with
its full dynamic range (no effect applied).
Notes:
•If Analog Direct is in use, Midnight Mode is temporarily canceled.
•Midnight Mode is not valid for DVD MULTI playback mode.
Attenuating the Input Signal
When the input level of the analog source is too high, the sounds
will be distorted. If this happens, you need to attenuate the input
signal level to prevent the sound distortion.
•Once you have made adjustment, it is memorized for each analog
source.
Press and hold INPUT ATT (INPUT ANALOG) so that the
INPUT ATT indicator lights up on the display.
•Each time you press and hold the button, the input attenuator
mode turns on (“ATT ON”) or off (“NORMAL”).
Note:
This function is not valid when “DVD MULTI”is selected or when
Analog Direct is activated.
Remote
NOT
Remote
NOT
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
RX-7032V
AUDIO/VIDEO CONTROL RECEIVER
14-19-7032[B]f.pm6 03.3.6, 4:14 PM17
