JVC TK-C553U - Fixed Color Dome Camera User manual

FIXED COLOR DOME CAMERA
TK-C553U (AC 24 V/DC 12 V)
Cost-effective, Compact Programmable Color
Dome Camera with Digital Zoom
R
䡲Variable Focal-Length Lens (f=2.6 to
6 mm)
䡲1/4-inch 380,000 Pixel CCD
䡲High Sensitivity — 4 Lux (with
cover), 1.5 Lux (without cover)
䡲Digital 2X Zoom — Auto Pan, Tilt,
Scroll and Preset Sequence (Auto
Patrol) Mode
䡲6 Preset Positions
䡲One-push Auto White Balance
䡲Programmable Backlight
Compensation
䡲RS-422A and RS-485 Control Signals
䡲Compact, Space-saving Design
CCTV Camera

Fully Programmable, Compact Dome Camera Captures
Top-Quality Pictures in an Expandable System
Packing all the advanced image-gathering technologies needed to
operate flexibly in a wide range of environments, the TK-C553U
comes in an exceptional economical package. It lets you build a
surveillance system that can be easily expanded as your needs
grow — one that is virtually maintenance free and can be
operated easily by anyone.
With its fully programmable Auto Patrol function, JVC’s
TK-C553U can pan and tilt to monitor up to six positions in a
sequential or random pattern. A wide-aperture, wide-angle lens
with zoom further boosts coverage. Images are captured by a JVC
1/4-inch CCD with 380,000 pixels, which delivers 470 TV lines for
crisp pictures at light levels down to 1.5 Lux (without cover).
Yet, despite featuring some of the most advanced video-
capturing technologies, the TK-C553U is remarkably compact.
Its surveillance capabilities far exceed those of conventional fixed
cameras, letting you cover a larger area with fewer cameras —
another major cost saving.
@@@@@@@@e?
@@@@@@@@e?
@@h?
@@h?
@@h?
@@h?
@@h?
@@h?
@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?
@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?
@@@@@@@@
@@@@@@@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
?@@
?@@
?@@
?@@
?@@
?@@
?@@@@@@@@
?@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@
@@g
@@g
@@g
@@g
@@g
@@g
@@@@@@@@
@@@@@@@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
1/4-INCH 380,000 PIXEL CCD
RS-422A/RS-485 CONTROL SIGNALS
1.5 LUX HIGH SENSITIVITY

䡲Simple Menu-driven Parameter
Setting
Easy-to-use menu-driven operation lets
you set a host of parameters including
IRIS level, ENHANCE level, ATW/MANU,
AGC ON/OFF, Super AGC ON/OFF, L.L.
phase, digital zoom, and preset mode.
The menu operation can be performed
through the menu control on the camera
unit or the RM-P2580U JVC Dome
Controller.
䡲Preset Sequence (Auto Patrol)
Mode
Using the powerful Auto Patrol function
you can program the camera to monitor
up to six preset positions, remaining at
each position for a preset time. Pan, tilt,
and scroll are all fully automated.
Coverage of an area by panning can be
random or sequential, with the user
programming the TK-C553U to suit local
operating conditions.
䡲Wide Angle Adjustment Range
The camera angle is adjustable over a
wide range to ensure comprehensive
coverage of the area under surveillance —
horizontal: 90°, vertical: 130°, and Tilt: 30°.
䡲Crisp Pictures Down to 1.5 Lux
The TK-C553U features a 1/4-inch CCD
with 380,000 pixels, which delivers 470 lines
of horizontal resolution. Sensitivity is
excellent — the TK-C553U can capture top-
quality pictures in ambient light down to 4
Lux with cover on. Careful attention to dome
design also eliminates optical distortion.
䡲Lens and Digital Zoom
The professional-quality large aperture lens
of the TK-C553U features a 2X digital zoom
ratio and zoom can be smoothly and easily
operated from the controller, which gets you
close to the action fast. To further enhance
versatility, the lens has a variable focal
length (2.6 to 6.0 mm) to keep subjects,
near and far, in sharp focus at all times.
䡲RS-422A/RS-485 Interfaces
The distance of the camera and controller
is a maximum of 4,000 feet (1.2 km). The
TK-C553U accepts RS-422A/RS-485
control signals, allowing both point-to-
point and multi-drop control of cameras
from a single controller.
䡲ID Capability
The ability to assign an ID to individual
cameras means you can quickly and
simply configure a remotely controlled,
multi-camera surveillance system.
䡲Easy Installation and Wide
Coverage
Compact and lightweight, the TK-C553U
is designed for easy installation on a
ceiling. Its wide-angle lens and clever
dome design also mean that the
TK-C553U can cover an area that would
require a number of conventional
cameras, further reducing installation
time and cost.
䡲Full Auto White Balance
You can adjust white balance manually or
automatically for light within a color
temperature range of 2,500°K to
8,000°K.
䡲Camera Text
Text of up to twenty-four characters can
be input and set for each camera. The
text appears at the bottom of the monitor
screen and lets the user instantly know
the location of the camera.
䡲Backlight Compensation
The powerful Backlight Compensation
function provides a sense of depth
around a subject in the foreground by
filling the background, which prevents
silhouetting.
CCTV Camera
–– ETUP MENU––S
VIDE ADJUST. .O
MODE S E L EC T . .
COMM N I CA T I ON . .U
END MEMORY
–– IDEO ADJUST––V
IRIS LEVEL NORMAL
NORMA L
NORMA L
COLO LEVELRU
ENHA CE LEVELN
AGC ODE 20dBM
SUPE AGC OF FR
BLC. OFF.
AVER GE:PEAK 8 : 2A
END
WH I T B A L ANC E A T WE
–– ODE SELECT––M
CAME A TEXT OF FR
V.PH SE 128A
AUTO START . . OF F
END
––CO MUNICATION––M
MODE POI NT t o PO I NT
STYLE DUPLE X
ID 1
END
SETUP MENU SCREEN VIDEO ADJUST SCREEN MODE SELECT SCREEN COMMUNICATION SCREEN FUNCTION SCREEN
–FUNCTION–––
POS I I ON TEX T ED I T . .T
POS . EX T LOC . UP – LT
AUTO PATROL . .
AUTO PAN MODE PAN
ALM. EXT SIZE DOUBLET
END
W82.3°
T35.4°
90°
W82.3°
T35.4°
Panning Direction
Tilting Direction
80°
W59.7°
T26.4°
50°
W59.7°
T26.4°
This screen is only displayed
when the controller is connected.
OFF
Light
metering
area
Light
metering
area
Light
metering
area
Light
metering
area
Light
metering
area
AREA 1 AREA 2 AREA 3 AREA 4 EDIT 1 EDIT 1 EDIT 2 EDIT 2
Light
metering
area
Light
metering
area

R
JVC PROFESSIONAL PRODUCTS COMPANY
DIVISION OF JVC AMERICAS CORP.
1700 Valley Road, Wayne, N.J. 07470
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
JVC CANADA INC.
21 Finchdene Square, Scarborough, Ontario M1X 1A7
TEL: [phone] FAX: [phone]
Internet Web Site http://www.jvcpro.com/
DISTRIBUTED BY Design and specifications subject to change without notice.
Printed in Japan
KCN-1776
CETKC553UKN2000.2
This catalog is printed on recycled paper.
Specifications
䡲CAMERA
Signal system NTSC
Image device 1/4"IT CCD
Effective picture element 380,000 pixels, 768 (H) x 494 (V)
Sync system Line lock/Internal
Video S/N 50 dB (typical)
Horizontal resolution 470 TV lines (typical)
Minimum illumination 4 lux (Full wide angle, AGC 20 dB, Y: 25%)
1.5 lux (Full wide angle, AGC 20 dB,
Y: 25%, no cover)
Camera ID 24 characters
White balance ATW/Manual/AWC
BLC Available by adjustment of light
metering area position
䡲LENS
Focal length 2.6 to 6 mm (variable)
Max. aperture ratio F1.2 to F1.8
Angle of vision:
f = 2.6 mm, 82° (H) x 59° (V)
f = 6 mm, 35° (H) x 26° (V)
䡲ANGLE ADJUSTMENT RANGE
Horizontal 90°
Vertical 130°
Tilt 30°
䡲GENERAL
Remote control input RS-422A or RS-485 (non-isolated)
Power requirement AC 24 V~, 50/60 Hz or DC 12 V
Power consumption Approx. 3.6 W
Operating temperature range 14°F to 122°F/-10°C to +50°C
(recommendation: 32°F to 104°F/0°C to +40°C)
Dimensions Approx. 4-7/16" (112 mm) diameter x 4-1/2"
(113 mm)
Weight Approx. 1.3 lbs. (570 g) with ceiling mount
Controls, connectors and indicators
Dimensions Unit: inches (mm) Basic system
4-1/2 (113)
SR52
ø4-7/16 (112)
ø4-3/8 (110)
ø4-3/16 (106)
1
TO CAMERATO CAMERA DATA I / O
RXRX+RXRX
-
TXTX+TXTX
-
COMCOM 1 2 3 4 5 6 7 8 COMCOM 9/1 10/2 11/3 12/4 13/5 14/6 15/7 16/8 COMCOM COMCOM COMCOM
CAMERACAMERA
SWSW
UNITUNIT
ALARMALARM AUTOAUTO
4312 875 6
2 3 4 5 6 7 8
1
MONITORMONITOR
OUTPUTOUTPUT MONITORMONITOR
SERIAL-2SERIAL-2SERIAL-1SERIAL-1
VIDEO INPUT
VIDEO OUTPUTVIDEO OUTPUT
OUTPUTOUTPUT
2
1
ONON
2 3 4 5 6 7 8
POWER
OFF
ON
AC INPUT
V.IN
MONITOR
OUTPUT 2
MONITOR
OUTPUT 1
CAM SW
OUT
VIDEO
IN
COM
CAMERA
SW
AC24V
AC24V
AC24V
TO
CAMERA
TIME-LAPSEVCR
RM-P2580
CAMERA 1
CAMERA 2
CAMERA 3
ID:1
ID:2
ID:3
MASTER MONITOR
Set Pin 1 to "OFF" for A Mode.
REC
REC STOP REC
CHECK EJECT OPERATE
OPERATE
䡲The Hachioji Plant of Victor Company of Japan, Ltd., has received ISO14001 Certification
under the global standard for environmental management.
