JVC KY-F70BU Installation guide

3-CCD SXGA Digital Imaging
R
1/2" C-MOUNT 3-CCD DIGITAL
CAMERA
KY-F70BU
High Resolution SXGA Digital Image
Capture with SCSI Output and Live
Color Preview
4.35 million Effective Square Pixels
SXGA Native Picture Resolution
1360 x 1024 Square Pixels per CCD with
Progressive Scanning
3-CCD Color Accuracy (Prism-separated
R, G and B)
C-mount
Live Color Preview on VGA Monitor
Direct Digital Interface to PC via SCSI-2
Designed to accommodate IR Applications
Long integration periods (Slow Shutter)
High Signal to Noise Ratio
IEC601-1 and UL-2601 Medical Approval
JVC Proprietary ‘KY-SCSI’ Bundled
Shown with optional lens
KY-F70BU.XPR101.6.55:27PMページ2

Whether used on a scope or with a lens
attached, the KY-F70BU delivers still images
with a level of resolution and a quality of
color which greatly surpass conventional
3-CCD video technology. The KY-F70BU
Digital Imaging System interfaces directly
to a PC via SCSI-2 and so can capture SXGA
resolution images directly without an image
capture board, while still offering motion live
color preview in real-time. Furthermore,
when interfaced with a PC capture board, it
can deliver SXGA resolution into an even
wider range of applications. For example, the
SCSI interface can be switched simply from
Slave to Master for connection directly to the
SCSI port of a printer or Zip* drive, thus
directly providing high resolution SXGA
images without the need of a PC.
‘Zip’ drive is a registered trademark of Iomega.
 KY-F70BU Actual Digital Image
Digital Image Capture: KY-F70BU via SCSI output
The KY-F70BU is an ultra-compact, multi-purpose 1360 x 1024 pixel
resolution device for digital image capturing of three dimensional objects seen
through scopes and lenses. Its C-mount attachment provides ready
attachment to a very wide range of industrial and medical scopes, as well as
lenses and other imaging apparatus. It has the convenience of internal frame
memory which means that the image transfer to PC, printer or storage device
can be either direct or selected from the frame memory.
Key Features
SXGA output available in both digital and analog forms for future-proofed
flexibility.
3-CCD prism system for separate processing of R, G and B for perfect
color rendition.
Square-pixel on-chip progressive scan CCDs, each with 1.45 million pixels,
totalling 4.35 million.
1360 x 1024 pixel resolution equates to 1,000 TVL in horizontal and vertical.
C-mount, half inch size fits a wide variety of scopes and lenses.
For applications using Infrared there is external access to IR cut filter for
replacement by special JVC quartz filter.
Extended integration up to 4 seconds. (Slow Shutter Mode)
Pixel masking algorithm for optimized image quality.
Special algorithm for improved S/N ratio.
User-selectable Syncs: either Separate Syncs or Sync on Green.
WYSIWYG live preview mode. (Live Color Preview on VGA Monitor)
External trigger function for Sensor or Flash Synchronization.
Internal Frame Memory holds up to four images in uncompressed data
format to avoid degradation.
IEC601-1 and UL-2601 Approval, using AA-P700, for use in certain medical
applications.
Shot & Print, Shot & Save capability through SCSI master mode.
JVC Proprietary Software Supplied as Standard
‘KY-SCSI’software package provides camera control and image capturing
direct to PC via SCSI-2.
TWAIN 32 driver for importation of images.
RS-232C camera control software
JVC’s KY-F70BU: the answer to digital photographic r
KY-F70BU.XPR101.6.55:28PMページ3

AC ADAPTER AA-P700
ON
OFF
POWER
POWER
ALARM SHEET PAPER DATA
OPEN
CP700DSA MITSUBISHI
ONLINECOPY&CUTPAPERFEED
]
AA-P700
AC adapter
Zip or MO
disk drive
Printer
AC
MONITOR VIDEO IN
Connect to
the power
supply
Preview (VGA) monitor
Adapters
Connect
the Zip or MO
drive unit
Connect
the printer
SCSI-2
DC IN
KY-F70
CAMERADIGITAL
C-MOUNT
(Compatibility: Mitsubishi
CP700DSU/DSE
and CP800DW)
AC ADAPTER AA-P700
ON
OFF
POWER
AA-P700
AC
KY-F70
CAMERADIGITAL
C-MOUNT
PC monitor
PC
Capture board
AC adapter
Analog RGB, WEN, Hs, Vs
RS-232C
Direct Digital Connection for Printing or
Storage
This system does not require a PC. Live color
preview on the monitor allows selection of the
images to be captured to Printer or Zip drive
(or MO).
PC System Using Capture Board
Via the 15-pin RGB port, SXGA resolution images
may be captured with an appropriate Image
Digitising Board. Live color preview is available on
the PC screen and captured images can be
verified at their full resolution.
SYSTEM CONFIGURATIONS
AC ADAPTER AA-P700
ON
OFF
POWER
AA-P700
AC
SCSI-2
SCSI-2
DC IN
Trigger in
Flash
Trigger out
KY-F70
CAMERADIGITAL
C-MOUNT
Both preview and capture
with PC
Lenses or
adapters
AC ADAPTER AA-P700
ON
OFF
POWER
AA-P700
AC
SCSI-2
SCSI-2
RGB, Hs, Vs
DC IN
Trigger in
Flash
Trigger out
KY-F70
CAMERADIGITAL
C-MOUNT
RS-232C
PC
capture
Separate
preview (VGA)
monitor
Lenses or
adapters
Direct PC ‘KY-SCSI’ Capturing System
Via the SCSI terminal, high resolution SXGA images
can be captured directly to a PC.
The camera can be controlled via the PC. In this
system the PC is the SCSI host and
the camera is the SCSI peripheral.
Images captured to a PC may be processed and
manipulated in application software JVC
‘KY-SCSI’(bundled).
 JVC ‘KY-SCSI’provides all control for KY-F70BU.
 The Preview Mode is live color but without full
motion.
Direct PC ‘TWAIN32’Capturing System
Via the SCSI terminal, high resolution SXGA images
can be captured directly to a PC. Separate VGA
monitor preview allows selection of the images.
The camera can be controlled via the PC. In this
system the PC is the SCSI host and the camera is
the SCSI peripheral.
Images captured to a PC may be processed and
manipulated in application software such as
Photoshop®.
To run this system, the JVC camera remote
control software and the TWAIN 32 capture
software need to be installed in the PC.
 Live preview available in full motion color via VGA
screen.
ographic requirements in industry and medicine.
Optionally Designed to
Accommodate IR Applications
The IR cut filter for use with
the KY-F70BU is easily detachable
if required. The JVC-supplied
special quartz filter used in place of
the IR cut filter permits black-and-
white photography in the IR
(Infrared) region. This is JVC's
answer for applications requiring
ultra low illumination photography.
KY-F70BU.XPR101.6.55:28PMページ4

3
Printed in Japan
KCN-1791
CEKYF70BUNK0106
■The Hachioji Plant of Victor Company of Japan, Ltd., has received ISO14001 Certification
under the global standard for environmental management.
Image device 1/2-inch Interline Transfer CCD x 3 in co-site array
Scanning Progressive
Total pixels 4.35 million (3 x 1.45 million) pixels
Effective pixels for CCD 1.45 million pixels (H: 1,392 x V: 1,040)
Output pixels 1360 x 1024 square pixels
Aspect ratio 4:3
Lens mount 1/2-inch C mount
Output signal (Analog and SCSI) SXGA 1360 x 1024 pixels 7.5 frames/sec.
Preview Modes (Analog) VGA: 640 x 480 pixels 60 frames/sec.
(Image refresh rate 7.5 frames/sec.)
VGA: 640 x 480 pixels 60 frames/sec.
(Image refresh rate 30 frames/sec.,
vertical resolution: 240 lines)
Digital interface SCSI-2 50P half-pitch SCSI connector
Analog output R/G/B 0.7 V(p-p) 75 ohms each
Sync output Hs/Vs 3 V(p-p) (low active)
Image memory 5 frames (4 frames in SXGA analog mode)
Sensitivity
ISO100 (Similar to 2000 lux F5.6 at 1/60 sec.
shutter speed)
Quantization 10 bit in 8 bit out
White balance Auto and manual
White paint Manual, flare compensation, dynamic shading
Gain ISO100, 200, 400 (0 dB, +6 dB, +12 dB)
Electronic shutter 4 secs to 1/2000th sec (in 16 steps), V.SCAN and EEI
Operating temperature 32 — 104°F (0 — 40°C)
Input voltage DC12V
Power consumption Approx. 15W
Weight Approx. 1.9 lbs. (850g)
Dimensions (W x H x D) 2-13/16 x 3-3/16 x 5-15/16 inches
70 x 80 x 150mm
Medical approval IEC601-1 Conformed with AA-P700EK/EG
UL-2601 Approved with AA-P700MDU
R
JVC PROFESSIONAL PRODUCTS COMPANY
DIVISION OF JVC AMERICAS CORP.
1700 Valley Road, Wayne, N.J. 07470
TEL: [phone]
FAX: [phone]
Internet Web Site http://www.jvc.com/pro
E-mail: [email protected]
JVC CANADA INC.
21 Finchdene Square, Scarborough, Ontario M1X 1A7
TEL: [phone] FAX: [phone]
Internet Web Site http://www.jvcpro.com/
DISTRIBUTED BY Design and specifications subject to change without notice.
KY-F70 CAMERADIGITAL
1/16
(1) 5-5/8 (142.5)
5-15/16 (150)
41.5 (1-11/16)
5/8 (14)
C-MOUNT
2-13/16 (70)
3-3/16 (80)
3-1/2 (88)
DIMENSIONS Unit: inches (mm)
OPTIONS
SYSTEM REQUIREMENTS FOR PC
SUPPLIED SOFTWARE
RECOMMENDED ACCESSORIES
SPECIFICATIONSMAIN PARTS AND FUNCTIONS
AA-P700
AC Power Adapter
AA-P700EK (IEC601-1 Conformed)
AA-P700EG (IEC601-1 Conformed)
AA-P700MDU (UL-2601 Approved)
AA-P700U (General use)
KM-F700U
SXGA Scan Rate
Converter
Printers:
 Mitsubishi CP800DW
 Mitsubishi CP700DSU/DSE
 Mitsubishi CP770DW
Photo: CP800DW
S14x7.3DA-D24
14:1 Power Zoom Lens
(Fujinon lens)
3
2
1
456
7
8
9
0
!
@
#
$
%
^
&
Ventilation hole
1Lens mount
2Camera mounting bracket
3Locking screws for the camera mounting bracket (M2.6 x 6mm, 3 units)
4MENU button
5SEND/UP button
6AW/SEL/DOWN button
7MODE/SET button
8REC mode lamp
9PLAY mode lamp
0FREEZE button
!MONITOR output terminal (D-sub 15-pin, female)
@LENS connection terminal
#POWER display lamp
$DC IN power input terminal (Mini DIN 8-pin, female)
%REMOTE terminal (Metal 10-pin, female)
^Dip switches
&SCSI terminal (Half-pitch 50-pin)
CPU: Pentium®166 MHz or faster
At least 20 MB of RAM
At least 10 MB of available hard-disk space
Serial port (RS-232C)
SCSI-2 board (Adaptec AHA-2940AU recommended)
VDU with 16,7 m colors
Floppy disk drive
Windows®95, Windows®98, Windows®NT 4.0
*Windows®95, Windows®98, Windows®NT 4.0, Adobe®Photoshop®and Pentium®are registered trademarks.
JVC Proprietary software:
SCSI Direct Control & Capture Software ‘KY-SCSI’(Bundled)
TWAIN 32 Capture Software (Bundled)
RS-232C Camera Control Software (Free software)
