COMPACT COMPONENT SYSTEM
MB707<Rev.002>20102SERVICE MANUAL
NX-T10E, NX-T10EN, NX-T10EV,
NX-T10UG
COPYRIGHT © 2010 Victor Company of Japan, Limited
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
SP-NXT10FSP-NXT10F SP-NXT10WCA-NXT10
Except UG

1-2 (No.MB707<Rev.002>)
SPECIFICATION
Designs & specifications are subject to change without notice.
Main unit-CA-NXT10
Input/output
HDMI input HDMI IN 1, HDMI IN 2
HDMI output HDMI MONITOR OUT
USB terminal USB MEMORY REC/PLAY
Analog audio input AUDIO IN 500 mV/50 kΩ
Digital audio input DIGITAL IN (OPTICAL) -21 dBm to -15 dBm (660 nm ±30 nm)
Analog video output VIDEO OUT Color system PAL (E, EN, EV) : NTSC/PAL (UG)
VIDEO Composite video, 1 V(p-p)/75 Ω
COMPONENT Component video (interlaced/progressive)
(Y): 1 V(p-p)/75 Ω
(PB/PR): 0.7 V(p-p)/75 Ω
Tuner
FM tuning range 87.50 MHz - 108.00 MHz
Disc player
Playable disc DVD Video/CD/VCD/SVCD
CD-R/CD-RW (CD/SVCD/VCD/MP3/WMA/JPEG/MPEG-1/MPEG-2/DivX format)
DVD-R/-RW (DVD Video/DVDVR/MP3/WMA/JPEG/MPEG-1/MPEG-2/DivX format)
+R/+RW (DVD Video/MP3/WMA/JPEG/MPEG-1/MPEG-2/DivX format)
Dynamic range 80 dB
Horizontal resolution 500 lines
Wow and flutter Immeasurable
USB
Playable files MP3/WMA/JPEG/MPEG-1/MPEG-2/DivX format
CD recording format MP3
USB specification Compatible with USB 2.0 Full Speed
Compatible device Mass storage class
Compatible system FAT16, FAT32
Bus power supply DC 5 V 500 mA
HDMI
Video resolution 576p, 720p, 1080i, 1080p
Output power (HDMI MONITOR OUT) DC 5 V 55 mA
General
Mass (approx.) 2.3 kg (without the stand)
Dimensions (approx.) Placed vertically (1): 240mm, (2): 420mm, (3): 64mm, (4): 70mm, (5): 134mm
Placed horizontally (1): 420mm, (2): 70mm, (3): 240mm
(3) (4)
(5)
(1)
(2)
(1)
(3)
(2)

(No.MB707<Rev.002>)1-3
Designs & specifications are subject to change without notice.
Subwoofer-SP-NXT10W
Output power Front 160 W (80 W + 80 W) at 4 Ω(10% THD)
Surround 160 W (80 W + 80 W) at 4 Ω(10% THD)
Subwoofer 200 W at 6 Ω(10% THD)
Speaker Bass reflex type
16 cm cone ×1
Power handling capacity 200 W
Frequency range 42 Hz - 150 Hz
Sound pressure level 75 dB/W ·m
Power requirements AC 230 V , 50 Hz (E, EN, EV) : AC110V - 240V , 50Hz/60Hz (UG)
Power consumption 80 W (at operation of the System) for E, EN, EV : 95W (at operation of the System) for UG
0.85 W (at standby)
Mass (approx.) 10 kg
Dimensions (approx.) 231 mm ×393 mm ×370.5 mm (W/H/D)
Speakers-SP-NXT10F
Speaker 1 way bass reflex type (magnetically shielded)
Front 8 cm cone ×1
Surround 5.5 cm cone ×1
Impedance 4 Ω
Power handling ca-
pacity
Front 80 W
Surround 80 W
Frequency range Front 80 Hz - 20 kHz
Surround 125 Hz - 20 kHz
Sound pressure level Front 80 dB/W ·m
Surround 71 dB/W ·m
Mass (approx.) 1.3 kg each
Dimensions (approx.) 100 mm ×240 mm ×128 mm (W/H/D)

1-4 (No.MB707<Rev.002>)
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

(No.MB707<Rev.002>)1-5
1.5 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.5.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.6 Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a
time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1M
Conductive material
(conductive sheet) or iron palate
(caption)
Anti-static wrist strap

1-6 (No.MB707<Rev.002>)
1.7 Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
REPRODUCTION AND POSITION OF LABELS and PRINT
!Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
WARNING LABEL and PRINT

(No.MB707<Rev.002>)1-7
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.
SECTION 3
DISASSEMBLY
3.1 Main body (Used figure were NX-T10E)
3.1.1 Removing the DVD door
(1) Connect the Main unit and Subwoofer.
(2) Power to ON and then open the DVD door.
(3) Slid to front side and pull up the DVD door.
3.1.2 Removing the Top cabinet (See Fig.1, 2, 3, 4)
(1) Remove the six screws Aattaching the Top cabinet. (See
Fig.1)
(2) Disconnect the card wire from DVD MPEG board connect-
ed to connector CNC5 of the Connect board. (See Fig.1)
Fig.1
(3) Remove the four screws Battaching the Top cabinet. (See
Fig.2)
Fig.2
(4) Remove the three screws Cattaching the Top cabinet.
(See Fig.3)
Fig.3
(5) Disconnect the card wire from DVD MPEG board connect-
ed to connector CON401 of the Display board. (See Fig.4)
Fig.4
3.1.3 Removing the DVD mechanism (See Fig.5)
(1) Remove the four screws Dattaching the DVD mechanism.
(2) Remove the two screws Eattaching the Connect board.
Fig.5
3.1.4 Removing the DVD mechanism (See Fig.6)
(1) Remove the six screws Fattaching the Display board.
(2) Disconnect the card wire from Key board connected to con-
nectors CON402 and CON403 of the Display board.
Fig.6
AA
CNC5
B
C
CON401
D
D
DE
CON403
CON402
F
F

1-8 (No.MB707<Rev.002>)
3.1.5 Removing the DVD mechanism (See Fig.7, 8, 9)
(1) Remove the three screws Gand one screw Hattaching the
DVD MPEG board. (See Fig.7)
Fig.7
(2) Disconnect the card wire from DVD MPEG board connect-
ed to connector SCON3 of the UP GRADE board. (See
Fig.8)
(3) Remove the four screws Jattaching the DVD MPEG
board. (See Fig.8)
(4) Disconnect the connector wire from Main board connected
to connector CN100 of the DVD MPEG board. (See Fig.8)
(5) Disconnect the connector wire from DVCC board connect-
ed to connector CON1 of the DVD MPEG board. (See
Fig.8)
(6) Disconnect the card wire from Main board connected to
connector CN2 of the DVD MPEG board. (See Fig.8)
(7) Disconnect the earth wire from Main board connected to
post pin of the Main board. (see Fig.8)
(8) Disconnect the connector wire from USB board connected
to connector CN82 of the DVD MPEG board. (See Fig.8)
(9) Disconnect the card wires from Main board connected to
connectors CN8 and CN9 of the DVD MPEG board. (See
Fig.8)
Fig.8
3.1.6 Removing the USB board (See Fig.9)
(1) Disconnect the connector wire from USB board connected
to connector CON103 of the Main board.
(2) Disconnect the card wire from Main board connected to
connector CON504 of the USB board.
(3) Remove the two screws Kattaching the USB board.
Fig.9
3.1.7 Removing the UP GRADE board (See Fig.10)
(1) Disconnect the card wire from Main board connected to
connector SCON1 of the UPGRADE board.
(2) Remove the four screws Lattaching the UP GRADE board.
Fig.10
3.1.8 Removing the FM tuner module (See Fig.11, 12)
(1) Disconnect the card wire from FM tuner module connected
to connector CON603 of the Main board. (See Fig.11)
Fig.11
G H
SCON3
GND3
CN100 CN2 CN8 CN9
CN82
CON1
J
J
CON103
CON504
K
LL
SCON1
CON603

(No.MB707<Rev.002>)1-9
(2) Remove the one screw Mattaching the FM tuner module.
(See Fig.12)
Fig.12
3.1.9 Removing the Main board (See Fig.13, 14, 15)
(1) Remove the four screws Nattaching the Main board. (See
Fig.13)
Fig.13
(2) Disconnect the connector wire from DC motor connected to
connector MTCON1 of the Main board. (See Fig.14)
(3) Remove the four screws Pattaching the bracket. (See
Fig.14)
(4) Remove the two screws Qattaching the bracket. (See
Fig.14)
(5) Remove the three screws Rand two screws Sattaching
the Motor bracket. (See Fig.14)
Fig.14
(6) Remove the five screws Tattaching the Main board. (See
Fig.15)
Fig.15
3.2 Subwoofer (Used figure were SP-NXT10WE)
3.2.1 Removing the Power amp unit (See Fig.1, 2, 3)
(1) Remove the six screws Aattaching the Power amp unit.
(See Fig.1)
Fig.1
(2) Remove the three screws Battaching the Power amp unit.
(See Fig.2)
Fig.2
(3) Pull out the Power amp unit for half way; disconnect the
connector wire from Subwoofer speaker connected to con-
nector CN2 of the Power amp board. (See Fig.3)
Fig.3
M
N
MTCON1
P
P
Q
R
RS
T
T
A
A
B
CN2

1-10 (No.MB707<Rev.002>)
3.2.2 Removing the Power cover and Amp cover (See Fig.4,
5, 6, 7)
(1) Remove the five screws Cattaching the Cover. (See Fig.4)
Fig.4
(2) Remove the three screws Dattaching the Cover. (See
Fig.5)
Fig.5
(3) Remove the six screws Eattaching the Cover. (See Fig.6)
Fig.6
(4) Lift up the Power cover; remove the two screws Fattaching
the Amp cover. (See Fig.7)
Fig.7
3.2.3 Removing the Power board (See Fig.8)
(1) Disconnect the power cord connected to connector CN1 of
the Power board.
(2) Disconnect the connector wires from Amp board connect-
ed to connector CN2 and CN3 of the Power board.
(3) Remove the eight screws Gattaching the Power board.
Fig.8
3.2.4 Removing the Amp board (See Fig.9, 10)
(1) Remove the three screws Hattaching the Back plate. (See
Fig.9)
Fig.9
(2) Remove the four screws Jattaching the Amp board. (see
Fig.10)
Fig.10
C
D
E
F
G
G
GG
CN2 CN3
CN1
H
JJ

(No.MB707<Rev.002>)1-11
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.

(No.MB707<Rev.002>)
VSE
Printed in Japan
Victor Company of Japan, Limited
Home Entertainment Business Division Personal AV Operation 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan

SCHEMATIC DIAGRAMS
NX-T10E, NX-T10EN, NX-T10EV,
NX-T10UG
Contents
Block diagrams
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-18 to 22
DVD-ROM No.SML2009S2
COMPACT COMPONENT SYSTEM
No.MB707SCH<Rev.002>
2010/2
COPYRIGHT 2010 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
SP-NXT10FSP-NXT10F SP-NXT10WCA-NXT10
Except UG

In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.

2-1
Block Diagram
D11,D12
T1
POWER TRANS
D1
DIODE BRIDGE
RECTIFIER
CN3 CN2
CN5 CN6
D7,D8
U1
SMPS CONTROLLER
AC PLUG
U601
U602
U701
IC1,IC3
HP AMP
MCU
POWER AMP
E. VOLUME
CN2
SUBWOOFER
CON501
CON602
CON401
EEPROM
X602Q601
RESET 32.768K
CON504
CN82
J102
CN1 Speaker
USB
MIC1
HEADPHONE
D+/-
+5V_USB
HP L/R
MIC1 L/R
VFD_CLK
VFD_DATA
VFD_STB
Y/Pr/Pb
U6
MPEG
U10
SDRAM
U8
FLASH
U7
DRIVER
X1
27MHz
UD001
AC IN
TU L/R
TXD/RXD
TU_CLK
TU_DA
TU_RST
SMPS section
Audio Amp section
TU_DET
AMP_MUTE
VFD DISPLAY section
HP&MIC&USB section
D+/-
CN1
MIC2
MIC2 L/R
CON502
U502
MU501
SW501
VFD_MODE H/V
CON503
CN81
&LED
P1
J301
AUX IN
CON801
CON1
U801
U802
DC power supply PWB
J101
TUNER
MODULE
FM/RDS
CON201 CON103
CN101
CN102
TO NTC
TO FAN
VFD401
CON402 CON403
J2 J2
4KEY L4KEY R
IR401
IR402
IC1 IC1
MTCON1
CN7
SCON3
CNM1
MOTOR PWB
Software Upgrade PCB
SCON4
SCON2
CNC4
DVD
LOADER
MODULE
U201
DSP
U202
U203
L/R SL/SR
HPL/R
AUX L/R
Y/Pr/Pb
CVBS
I2S
+ 12V
U301
U302
PWR_ON
I2C
12V
L/R
SL/SR
IC4
POWER AMP
+/- 27V
Pre_OP
I2S
DVD 5V
U204
EEPROM
U205
I2C
Q303
Q301
Touch Touch
SUB
IC6
IC2
IC5
Q1,2,3,4,6
RX1OPT_IN
HDIM_IN1
J4
HDIM_IN2
HDIM_OUT J2
J3
U3
U1
U4
U2
LPF
UD005
EEPROM
T2
POWER TRANS
OSC
U8
5V
IC7
Q303
Q308
U303
U304
U3,U12
CVBS
MPEG rest
UM203
I2C
DSP+MCU
SECTION
SMPS CONTROLLER
12V 12V
Adder, LPL
HLP
Switch
U2
RECTIFIER
RECTIFIER
12V 5V +/- 27V
SWITCH
I2C
LPF
LPF
Regulator
DC/DC
DC/DC
Regulator
SWITCH
SWITCH
DSP
3V3
SWITCH
D304
D306
DC/DC
D305
VFD display
IR sensor
IR sensor
ENCODER ENCODER
MTQ1/Q2/Q3/Q4/Q5
MOTOR CONTROL
+1V8 Regulator
+3V3 Regulator
Main_MCU
HDMI_MCU
+5V_DVD
U14
Regulator SWITCH
+12V_MIC
+3V3STBY
+3V3STBY
+3V3STBY
+12V_MIC
+5V2
Q24
MIC+12V
NXP_5V
Y/Pr/Pb/CVBS
RX/TX_CEC_ I2C, etc
Control Bus
DVD+HDMI Repeater Section
DRIVER
Protection
Protection
Protection
transmitter
Receiver/Selector
U12
Translator
U11
CEC
U9
MCU
IC1
Selector
SEL1/SEL2
Eeprom
Eeprom
UD004
UD006
UD006
Eeprom
IC3, U17
Selector
USB501 MJK502 MJK501 HPJ501
Connecting PCB
CNC3
CNC5
CN10CN3
CNC2 CNC1
CON603
CON102
CN8 CN100
CON101
VFD+12V VFD-27V
VFD +5V/+5V
+3V3STBY
SCON1
CON604 CON601
CN9
U101,U102,U1

2-2
NOTE)
With respect to risk of fire or
electrical shock.
Parts that are shaded are critical
Warning
Near D7(Detect D7
Temperature)
PC
HV
+28VA
INA
TL431
PD1
12V
TL432
INA
ECO
GND
12V
12VA
REFREF
REF
PGND
-28VA
AUX
AC1
+P
AC2
HV
HV
5V
PD1
HOT_GND
+
C16
470UF/35V
R44
4K7
R24 NC
R3
47K/2W
R13
2R/0.25W
CN1
AC_plug
N
L
U5 817
1
23
4
R5
0R56/2W
U3
817
1
23
4
+
C15
2200UF/35V
+
C8
1UF/50V
R32
100
+
C26
10UF/400V
R20
2K2/2W
D10
1N4148
R36
1K8
T2 EF20_NX-T10
4
3
2
18
7
6
5
P1
P2
HOT_GND
VCC +12V
+5V
GND
-33V
R29
3K3
+
C10
47UF/25V
T1 ER40_TRANSFORMER_
2
3
4
5
1
7
813
14
15
12
11
10
9
P1
P2
P3
P4
P5
HOT_GND
VCC -27VA
-27VB
PGND1
PGND2
PGND3
+27VA
+27VB
C4
471
CY3
222/250V_Y1
R11
2M/0.5W
C30
472/1KV
C29
0.1UF/275V
0.22UF/275V
+
C17
470UF/35V
R7
47
D12
1N5819
C3
R14
2R/0.25W
U1
NCP1216D65G2
1
2
3
45
6
7
8
ADJ
FB
CS
GND DRV
VCC
NC
HV
R27
10
D3
1N4007
0.22UF/275V
NTC
RT2
5R/4A
L4 10uH
R17 22/2W
D4
FR104
+C11
1UF/50V
t
RT1
PTC 95C
12
V4
2N5551
R45
241
VD1 12VR21
L2
10UH
U4
817
1
23
4
V3
S8050
L5
10uH
+
C27
1uF/50V
V5
S8050
+
C1
330UF/200V
R16
3K3
R33 1K
VD4
15V
HS1
HEATSINK
1 2
C5
471
R31
3K3
D15
FR107
+
C14
2200UF/35V
C6
104
D11SR3100
C12
472/630V
R46
241
R15
22
R22 22K
CY4 152/250V_Y1
L3
10UH
R9
10K
F1
T4AL250V
+C22
2200uF/25V
V2
8050
L6
40mH_0.55mm
D6
FR104
V1
SPA11N60C3
D7
UF803
+
C2
330UF/200V
C9
103
R34
3K3
U6
TL431
C20
104
HS2
HEATSINK
1 2
R48
47K/2W
U7
TL431
+
C24
100uF/16V
R23
CY2
152/250V_Y1
+
C28
10uF/50V
R10
1K
D2
FR157
R8
5K1
R25
10K
U2
ICE3B1565
1
2
3
45
6
7
8
RES
FB
S
DD
NC
VCC
GND
R4
0R51/2W
+
C7
47UF/25V
R1
2M/0.5W
D8
UF803
C13
472/630V
R28
1K
D5
1N4148
R19
2K2/2W
LF1
40mH_0.55mm
R18
22/2W
R47
3K3
R35
6K8
L1
1MH(0410)
R2
10K
+C21
2200uF/25V
+
C23
470uF/16V
D1
KB606
+
AC1
-
AC
CX2
472M/1KV NX-T10
2K2
2K2
CX1
Standard schematic diagrams
<SMPS Section 1>

2-3
12V
AGND
+28V
PGND
-28V
5VS
ECO
+P
AC1
AC2
+28VA
-28VA
12VA
GND
AUX
0
R49
22
VD2
7.5V
+
C33
100uF/35V
+
C34
100uF/35V
R42
12K
U8
C18
104
RL1
5A/250V 12V
3
4
2 1
R38
30K
D16
FR104
R39
6K8
V6
S8550
L9
33UH
V7
S8050
CN3
TJC3-6A
1
2
3
4
5
6
C19
104
+
C32
100uF/16V
L7
33uH
CN2
TJC1-4A
1
2
3
4
C25
104
R43
10/1W
R40
100K
R41
4K7
+
C31
47UF/25V
R37
2.2M/1W
VD3
12V
TL431
To Power Amplifier Section 1
(CN6)
To Power Amplifier Section 1
(CN5)
<SMPS Section 2>
NOTE)
With respect to risk of fire or
electrical shock.
Parts that are shaded are critical
Warning

2-4
J101-B
RCA - 214P - 02
RCA - 214P - 02
RCA - 414DB - 030
RCA - 414DB - 030
RCA - 414DB - 030
RCA - 414DB - 030
FFC 15P 1.0MM STRAIGHT
AUX_IN_L
AUX_IN_R
CVBS_OUT
Y_OUT
PB_OUT
PR_OUT
PR_OUT
PB_OUT
Y_OUT
CVBS_OUT
GND_V
GND
EEP_SEL
DOUT1
DOUTO
LRCLK
BCLK BCLK
MCLK MCLK
IPODR
GND_A
IPODL
FROM SUBWOOFER PWB(P1)
To DVD MPEG Section 3
(CN8)
To Power Amplifier Section 1
(P1)
To DVD MPEG Section 3
(CN100)
To DVD MPEG Section 3
(CON1)
J101-A
T62
3
4
1
2
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
D201
D202
R201
R202
D203
D204
GND_A
GND_V
GND_V
GND_V
GND_V
C202
C201 C203
C204
C104
C103
C102
C101
C331
C304
C303
C302
C320
C321
C322
D304
D305
R318
R329
R317
C330
R321
R311
Q301
Q304
R312
R319
Q303
R323
R324
PWR_ON
FB310
C334
FB311
FB308
FB309
FB313
+3V3STBY
+12V_MIC
CON103
To USB Section
(CON503)
1
1
2
2
3
4
5
6
7
8
9
T60
TV10
TV11
TV17
TV15
TV6
TV2
GND
GND
CON101
HOUSING 9P 2.0MM
2P 2.0MM 90 DEGREE
9950_RESET
9950_RESET
DVD_5V
IPOD_5V
IPOD_5V
GND
GND
+3V3STBY
+12V_MIC
+5V(CN)
+5V_DVD
TV5
+12VA
VFD+12V
+12V_MIC
TV4
DVD_PWR
+5V_DVD
Q302
TV9
VFD-27V
C323
C324
C305
C333
D307
C325
C326
D306
R316
R306
C315
R307
C318
C317
R308
D302
FB316
R309
R310
TV8 L302 W307
W308
Q308
R305
R313
Q307
3
3
3
3
3
3
4
4
4
4
5
4
TV14
C310 C306
C309
GND
W310
CABLE ASSY (W310-T0-W201)
U304
S
S
S
D
D
D
G
G
G
1
1
1
1
1
1
2
2
2
2
2
2
D303
LL4148
SS0520
SS0520 SS0520
+4V8_MCU
TV16
D311
TV13
+5V
+5V2
C5
C4
C3
GND_A
GND_A GND_V
GND
GND GND
C6
C2
C1
R304
D312 SS0520
FB315
TV3
TUNER+5V
VFD+5V
+3V3_DSP
+3V3STBY
C308
C307
FB314 TV12
U303
D308 D309
R333
C311
C312
C801 C803
C804 C805 C806
CON801
HOUSING 5P 2.0MM
DVD_+5V
DVD_+5V
VCC_1V9
VCC_3V3
GND-GND
GND-GND
C802
R801 R802
U801
U802
NOD
NOD
NOD
NOD
VIN
VIN
VIN
VIN
VOUT
VOUT
VOUT
VOUT
ADJ/GND
ADJ/GND
ADJ/GND
ADJ/GND
D801 D802 D803 D804
D805
SS12
SS12 SS12 SS12 1N4007
SS12
D806
C313 C327 C328
NC1
MASK MASK MASK MASK
NC2 NC3 NC4
R303
PWR_ON
W302
W303
W305
W306
W309
FB318
C319
C319B
C332
C319A
W301
C316
U302
SYNC
SYNC
EN
EN
IN
IN
BS
BS
SW
SW
FB
FB
COMP
COMP
GND
GND
FB317
D301
L303
L301
R320
R302
TV7
R332
C301 R322 U301
PWR_ON 7
7
2
2
1
1
3
3
3
3
2
2
2
3
3
1
1
1
2
2
1
1
3
5
5
6
6
4
4
8
8
CON102
D107
D108
D105
D106
D103
D104
D101
D102
C109
DOUT1
DOUT0
LRCLK
C110
C105 C107 R103
R101
R102
R301
FB307
FB303
FB304
FB305
FB306
FB301
FB302
C106
C335 C329
AUDIO-L-O
IPOD_L_IN
IPOD_R_IN
DSP_BUS
[4]
+12V
EEP_SEL
AUDIO-R-O
PWR_ON
AMP_MUTE
AUDIO-SL-O
AUDIO-SR-O
GND
GND
J301
GND_A
GND_A
C108 R104
C205
AUX_L
AUX_R
R205
R206
C206
T61
T4
T3
T2
T1
T5
T6
T14
T7
T8
T9
T10
TV19
T67
216510 914 13 15 12 11 8743TV1 +12V
T68
T69
T70
T65
T66
T11
TV18
J102-A
J102-B
J102-C
J102-D
<Main Section 1>

2-5
R637
R638 C611
R639
D602
Q601
R665
C618
R666
R656
R607
R623
R657
R632
R667
R608
X601
C603 C604
R677
R675
U602
1
2
3
4
8
7
6
5
C616
C609
REGC
+4V8_MCU
+4V8_MCU
+4V8_MCU
+4V8_MCU_VDD
RESET
FLMOD
BLNK_3KEY_2
PWR_ON
BLNK_4KEY_1
EXCLK
A0
A1
A2
GND
VCC
WP
SCL
SDA
R640
R668
R627
PCL0
14 11
15
16
17
19 20
21
22
23 24
25
26
SDA0
P62
P63
P77 P76
P75
P74
P73
P72
P71
P70
R625
R628
R622
R629
R658
C607
C606 C605
R613
R669
R647
R636
R648
R635
R670
R671
R672
R621
STB_R/B_LED_OFF
HDMI_ON
LOAD_UP_DOWN-
LOAD_UP_DOWN+
BLINK_4KEY_2
VFD_CLK
VFD_DATA
VFD_STB
VFD_V_H_MODE
BLINK_3KEY_1
TRIANGLE_LED_1/2
MCU_B(SW)_DETECT+ MCU_A(SW)_DETECT+
MCU_LOAD_DISC-
MCU_LOAD_DISC+
MCU_DOWN(SW)_DETECT-
MCU_UP(SW)_DETECT+
R633
R626
R650
R653
R624
R603
R645
R643
R642
R644
R649
R646
R634
48
52
51
50
49
47
46
45
44
43
42 41
40
P130
P00
P01
P02
P03
P20
P21
P22
P23
P24
P25
P26
P27
R602
R651
R601
R659
R610
R611
R612
R614
R615
R617
R618
R619
TU_RESET
HPD_TV
TRIANGLE_LED_ON
TU_I2C_DATA
TU_I2C_CLK
MCU_I2C_DATA
MCU_I2C_CLK
R641
CM1 CM2
HOUSING 2P 2.0MM
CNM1 MTCON1
2P 2.0MM 90 DEGREE
LOADER_UP_DOWN_MOTOR-
LOADER_UP_DOWN_MOTOR+
JVC NX-T10 MOTO PWB
LOADER_UP_DOWN MOTOR DRIVER CIRCUIT
MTD1
+12V_MIC
MTR14 MTEC2 MTEC1
DVD_PWR
MTQ1
3CA8550(TO-92) 3CA8550(TO-92)
SS8050(TO-92)
SS8050(TO-92) SS8050(TO-92)
MTR1 MTR2
MTQ2
R678
MTQ3
MTR10 MTR12
MTR9
MTR4
MTR3
MTR11
GND
GND
GND GND
MTR5 MTR7 MTR13
MTQ4
MODE_H_IN
MTQ5
T20
T59
MTC1
MTC2
2
2
2
2
2
2
2
3
3
3
3
3
1
1
1
1
1
1
1
MOTOR2
MOTOR2
MOTOR1
MOTOR1
TV21
C617
C615
FB608
9950_RESET
C602
X602
C601
R2 5 RESET AVR EF AV RE F
38
TV22
U601
+4V8_MCU
FB606
C608 C610
C619
R616
R661
R630
R680
R609
R652
R660
TUNER_NORMAL_PULSE
IR_IN
EEP_EN
9950_INT
R662
R620
R673
R674
R606
R605
R604 MPEG_CLK
MPEG_DATA
MPEG_STB
TXD
RXD
MCU-BUS
RXD
TXD
RESET
FLMDO
EXCLK
CON604
CON603
CON601
CON602
FFC 7P 1.0MM STRAIGHT
FFC 10P 1.25MM STRAIGHT
FFC 18P 1.0MM STRAIGHT
FFC 19P 1.0MM STRAIGHT
T50
T51 RXD
TXD
RESET
GND
FLMDO
EXCLK
TUNER_L
GND(CN)
TUNER_R
TU+5V
SCLK
SDIO
FROM TUNER MODULE
To UPGRADE PWB
TU_RESET(CN)
TU_I2C_CLK
TU_I2C_DATA
TU_RESET
9950_INT 9950_INT
MCU_I2C_DATA MCU_I2C_DATA(CN)
MCU_I2C_CLK MCU_I2C_CLK(CN)
TXD TXD
RXD RXD
MPEG_CLK MPEG_CLK(CN)
MPEG_STB MPEG_STB(CN)
MPEG_DATA MPEG_DATA(CN)
HDMI_ON HDMI_ON
MCU_LOAD_DISC+ MCU_LOAD_DISC+
MCU_LOAD_DISC- MCU_LOAD_DISC-
MCU_A(SW)_DETECT+ MCU_A(SW)_DETECT+
MCU_B(SW)_DETECT+ MCU_B(SW)_DETECT+
MCU_UP(SW)_DETECT+ MCU_UP(SW)_DETECT+
MCU_DOWN(SW)_DETECT- MCU_DOWN(SW)_DETECT-
EEP_EN EEP_EN
HPD_TV HPD_TV
FB607
FB609
FB610
FB611
FB612
FB613
FB614
FB615
FB604
FB618
FB603
FB602
R679
FB601
R676
C612
C614 FB605
TUNER_NORMAL_PULSE TYU_NO_PU
T52
T53
T54
T46
T48
TV20
T63
T64
T47
T45
T15
T17
T18
T19
T21
T22
T23
T24
T25
T26
T27
T28
T31
T32
T33
T34
T35 VFD_STB(CN)
VFD_STB
VFD_CLK(CN)
VFD_CLK
VFD_DATA(CN)
VFD_DATA
VFD-27V
VFD-27V
VFD+5V
VFD+5V
VFD+12V
VFD+12V
+3V3STBY
+3V3STBY
+5V
+5V
VFD_V_H_MODE
VFD_V_H_MODE
BLINK_4KEY_1
BLINK_4KEY_1
BLINK_4KEY_2
BLINK_4KEY_2
STB_R/B_LED_OFF
STB_R/B_LED_OFF
TRIANGLE_LED_ON
TRIANGLE_LED_ON
TRIANGLE_LED_1/2
TRIANGLE_LED_1/2
BLINK_3KEY_1
BLINK_3KEY_1
BLINK_3KEY_2
BLINK_3KEY_2
IR_IN
IR_IN
T36
T37
T38
T12
T13
T41
T42
T29
T30
T43
T44
GND
GND
GND
GND
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
5
5
5
5
6
6
6
6
7
7
7
7
8
8
8
9
9
9
10
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
18
19
TUNER_L
TUNER_R
GND_A
GND
C7
TUNER+5V
+4V8_MCU +4V8_MCU
AMP_MUTE
HP_DET
HP_MUTE
39
37
36
35
34
33
32
31
30
29
28
27
18
AVS S
P10
P11
P12
P13
P14
P15
P16
P17
P30
P31
P32
P33
FLMDO
P140
P41
P40
P120
VDD
VSS
8
1
3
4
6
7
9
10
2
13
12
R663
EEP_SEL
R631
C613 3
1
2
To DVD MPEG Section 3
(CN9)
To USB Section
(SCON1)
To Display Section
(CON401)
<Main Section 2>

2-6
CNC2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
24
23
22
21
20
19
18
TO LOADER
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
26
25
CNC1
25
FCS-
FCS+
TRK+
TRK-
C
D
MSW
RF
A
B
F
GND-PD
VC
VCC
E
NC3
VR-CD
VR-DVD
CD-LD
PD
NC2
NC1
DVD-LD
GND-LD
FCS-
FCS+
TRK+
TRK-
C
D
MSW
RF
A
B
F
GND-PD
RFGND2
CNC3
CNC5
CNC4
1
1
3
5
7
9
11
2
2
4
1
3
5
2
4
6
8
10
3
4
5
6
SLED+
SLED-
HOME
RFGND2
SP+
SP-
SLED+
SLED-
HOME
RFGND2
SP+
SP-
RFGND3
RFGND3
LOAD+
LOAD+
LOAD-
LOAD-
TRAYOUT
TRAYOUT
TRAYIN
TRAYIN
RFGND3
VC
VCC
E
NC3
VR-CD
VR-DVD
CD-LD
PD
NC2
NC1
DVD-LD
GND-LD
JVC NX-T10 CONNECTOR PWB
26
To DVD MPEG Section 1
(CN3) To DVD MPEG Section 1
(CN10)
To LOADER
To LOADER
<Main Section 3>
