JVC UX-G45 User manual

MICRO COMPONENT SYSTEM
UX-G45
—Consists of CA-UXG45 and SP-UXG45
INSTRUCTIONS
LVT1520-001A
[B]
UX-G45[B].BOOK Page 1 Friday, February 10, 2006 1:03 PM

G-1
Warnings, Cautions and Others
IMPORTANT for the U.K.
DO NOT
cut off the mains plug from this equipment. If the
plug fitted is not suitable for the power points in your home
or the cable is too short to reach a power point, then obtain
an appropriate safety approved extension lead or consult
your dealer.
BE SURE
to replace the fuse only with an identical
approved type, as originally fitted.
If nonetheless the mains plug is cut off ensure to remove the
fuse and dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the mains supply.
If this product is not supplied fitted with a mains plug then
follow the instructions given below:
IMPORTANT:
DO NOT
make any connection to the terminal which is
marked with the letter E or by the safety earth symbol or
coloured green or green-and-yellow.
The wires in the mains lead on this product are coloured in
accordance with the following code:
Blue: Neutral
Brown: Live
As these colours may not correspond with the coloured
markings identifying the terminals in your plug proceed as
follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
CAUTION
•Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to get
out.)
•Do not place any naked flame sources, such as lighted
candles, on the apparatus.
•When discarding batteries, environmental problems must
be considered and local rules or laws governing the
disposal of these batteries must be followed strictly.
•Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
UX-G45[B].BOOK Page 1 Friday, February 10, 2006 1:03 PM

G-2
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the
unit; leave all servicing to qualified service personnel.
3. CAUTION: VISIBLE AND / OR INVISIBLE CLASS 1M LASER RADIATION WHEN
OPEN. DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT.
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm
or more.
About the cooling fan
A cooling fan is mounted on the rear panel of the unit to prevent abnormal temperature inside the unit, thus assuring normal
operation of the unit. The cooling fan automatically starts rotating to intake external cool air when the volume is increased up
to more than a certain level.
10 cm
15 cm
1 cm
15 cm
15 cm 1 cm 15 cm
15 cm
Front Side
SP-UXG45
CA-UXG45
SP-UXG45 CA-UXG45
UX-G45[B].BOOK Page 2 Friday, February 10, 2006 1:03 PM

G-3
SAFETY INSTRUCTIONS
“SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT”
This equipment has been designed and manufactured to meet international safety standards but, like any
electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.
Do read the operating instructions before you attempt to use the equipment.
Do ensure that all electrical connections (including the mains plug, extension leads and interconnections between
pieces of equipment) are properly made and in accordance with the manufacturer’s instructions. Switch off and
withdraw the mains plug when making or changing connections.
Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
Do be careful with glass panels or doors on equipment.
DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in
any way—switch off, withdraw the mains plug and consult your dealer.
DON’T remove any fixed cover as this may expose dangerous voltages.
DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is designed for
unattended operation or has a standby mode.
Switch off using the switch on the equipment and make sure that your family know how to do this.
Special arrangements may need to be made for infirm or handicapped people.
DON’T use equipment such as personal stereos or radios so that you are distracted from the requirements of
traffic safety. It is illegal to watch television whilst driving.
DON’T listen to headphones at high volume as such use can permanently damage your hearing.
DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings.
Overheating will cause damage and shorten the life of the equipment.
DON’T use makeshift stands and NEVER fix legs with wood screws—to ensure complete safety always fit the
manufacturer’s approved stand or legs with the fixings provided according to the instructions.
DON’T allow electrical equipment to be exposed to rain or moisture.
ABOVE ALL
–NEVER let anyone, especially children, push anything into holes, slots or any other opening in the case
—this could result in a fatal electrical shock.;
– NEVER guess or take chances with electrical equipment of any kind—it is better to be safe than sorry!
✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮✮
UX-G45[B].BOOK Page 3 Friday, February 10, 2006 1:03 PM

1
Contents
Introduction .................................................... 2
Precautions...................................................................... 2
How to Read This Manual.............................................. 3
Getting Started ............................................... 4
Step 1: Unpack................................................................ 4
Step 2: Prepare the Remote Control ............................... 4
Step 3: Hook Up ............................................................. 5
Before Operating the System ........................ 8
Daily Operations—Playback ......................... 9
Listening to the Radio................................................... 10
Playing Back a Disc...................................................... 11
Playing Back from the USB Memory or
Digital Audio Player ................................................. 11
Playing Back Other Equipment .................................... 13
Quick Portable Link (QP Link) .................................... 13
Daily Operations—Sound &
Other Adjustments ................................... 14
Adjusting the Volume................................................... 14
Adjusting the Sound ..................................................... 14
Changing the Display Brightness—DIMMER............. 15
Setting the Clock .......................................................... 15
Turning Off the Power Automatically.......................... 16
Advanced Radio Operations ....................... 17
Receiving FM Stations with Radio Data System ......... 17
Searching for a Program by PTY Codes....................... 17
Switching Temporarily to a Program of
Your Choice Automatically ...................................... 18
Advanced Disc/USB Memory/
DAP Operations ........................................ 19
Programming the Playing Order—Program Play......... 19
Playing at Random—Random Play .............................. 20
Playing Repeatedly—Repeat Play................................ 21
Prohibiting Disc Ejection—Child Lock ....................... 21
Timer Operations ......................................... 22
Setting the Timer .......................................................... 22
Additional Information ............................... 24
Learning More about This System ............................... 24
Troubleshooting............................................................ 25
Maintenance.................................................................. 26
Specifications................................................................ 26
Parts Index .................................................................... 27
UX-G45[B].BOOK Page 1 Thursday, March 2, 2006 4:26 AM

2
Introduction
Thank you for purchasing the JVC Micro Component
System.
We hope it will be a valued addition to your home, giving
you years of enjoyment.
Be sure to read this instruction manual carefully before
operating your new stereo system.
In it you will find all the information you need to set up and
use the system.
If you have a query that is not answered by the manual,
please contact your dealer.
Precautions
Installation
• Install in a place which is level, dry and neither too hot nor
too cold—between 5°C and 35°C.
• Install the System in a location with adequate ventilation to
prevent internal heat buildup inside the System.
• Leave sufficient distance between the System and the TV.
• Keep the speakers away from the TV to avoid interference
with TV.
Power sources
• When unplugging the System from the wall outlet, always
pull on the plug, not the AC power cord.
Moisture condensation
Moisture may condense on the lenses inside the System in
the following cases:
• After starting to heat the room
• In a damp room
• If the System is brought directly from a cold to a warm
place
Should this occur, the System may malfunction. In this case,
leave the System turned on for a few hours until the moisture
evaporates, unplug the AC power cord, then plug it in again.
Internal heat
• A cooling fan is mounted on the rear panel to prevent heat
buildup inside the main unit (see page G-2).
Others
• Should any metallic object or liquid fall into the System,
unplug the AC power cord and consult your dealer before
operating any further.
• If you are not going to operate the System for an extended
period of time, unplug the AC power cord from the wall outlet.
If anything goes wrong, unplug the AC power cord and
consult your dealer.
DO NOT install the System in a location near
heat sources, or in a place subject to direct
sunlight, excessive dust or vibration.
DO NOT handle the AC power cord with wet
hands.
For safety, observe the following carefully:
• Make sure there is good ventilation around
the main unit. Poor ventilation could
overheat and damage the System.
• DO NOT block the cooling fan and the
ventilation openings or holes. If they are
blocked by a newspaper or cloth, etc., the
heat may not be able to get out.
DO NOT disassemble the System since there
are no user serviceable parts inside.
UX-G45[B].BOOK Page 2 Thursday, March 2, 2006 4:26 AM

3
How to Read This Manual
To make this manual as simple and easy-to-understand as
possible, we have adapted the following methods:
• Button and control operations are explained as listed in the
table below. In this manual, the operations using the
remote control is mainly explained; however, you can use
the buttons and controls on the main unit if they have the
same (or similar) name and marks.
• Some related tips and notes are explained later in the
sections “Learning More about This System” and
“Troubleshooting,” but not in the same section
explaining the operations.
If you want to know more about
the functions, or if you have a doubt about the functions, go
to these sections and you will find the answers.
Indicates that you press the button
briefly .
Indicates that you press the button
briefly and repeatedly until an option
you want is selected.
Indicates that you press one of the
buttons.
Indicates that you
press and hold the
button for specified seconds.
• The number inside the arrow
indicates the period of press (in this
example, 2 seconds).
• If no number is inside the arrow,
press and hold until the entire
procedure is complete or until you
get a result you want.
Indicates that you turn the control
toward the specified direction(s).
Indicates that this operation is only possible
using the remote control.
Indicates that this operation is only possible
using the buttons and controls on the main
unit.
2sec.
Remote
ONLY
Main Unit
ONLY
UX-G45[B].BOOK Page 3 Thursday, March 2, 2006 4:26 AM

4
Getting Started
Step 1: Unpack
After unpacking, check to be sure that you have all the
following items. The number in parentheses indicates the
quantity of each piece supplied.
• FM antenna (1)
• AM loop antenna (1)
• Remote control (1)
•Batteries(2)
If any item is missing, consult your dealer immediately.
Step 2: Prepare the Remote Control
Insert the batteries into the remote control by matching the
polarity (+ and –) correctly.
AM
EXT
GND
AM
LOOP
Step 1:Unpack the package and
check the accessories.
Step 2: Prepare the remote control.
Step 3: Hook up the components such
as AM/FM antennas, speakers,
etc. (see pages 5 to 7).
Finally plug the AC power cord.
Now you can operate the System.
• DO NOT use an old battery together with a
new one.
• DO NOT use different types of batteries
together.
• DO NOT expose batteries to heat or flame.
• DO NOT leave the batteries in the battery
compartment when you are not going to use
the remote control for an extended period of
time. Otherwise, the remote control will be
damaged from battery leakage.
3
2
1
R6(SUM-3)/AA(15F)
UX-G45[B].BOOK Page 4 Thursday, March 2, 2006 4:26 AM

5
Step 3: Hook Up
If you need more detailed information, see page 7.
For more detailed information on connecting external equipment, see page 13.
AM
EXT
GND
AM
LOOP
Illustrations of the input/output terminals below are typical
examples.
When you connect other components, refer also to their
manuals since the terminal names actually printed on the rear
may vary.
Turn the power off to all components before connections.
To a wall outlet
Plug the AC power cord only after all connections are complete.
Disconnect the supplied FM antenna, and connect to an outdoor FM antenna
using a 75 Ωwire with coaxial type connector (IEC or DIN45325).
Vynile-covered wire (not supplied)
Extend it horizontally.
AM loop antenna
Keep it connected.
For better FM/AM reception
Outdoor FM
antenna
(not supplied)
UX-G45[B].BOOK Page 5 Thursday, March 2, 2006 4:26 AM

6
AM
EXT
GND
AM
LOOP
FM antenna (supplied)
Extend it so that
you can obtain the
best reception.
AM loop antenna (supplied)
Turn it until the best reception is
obtained.
Non-striped
Black striped
UX-G45[B].BOOK Page 6 Thursday, March 2, 2006 4:26 AM

7
To assemble and connect the AM loop antenna
To assemble the AM loop antenna
To connect the AM loop antenna
Make sure to connect the wire correctly: The white end to
AM EXT, the black end to GND.
• If the AM loop antenna wire or speaker cords are covered
with vinyl, remove the vinyl to expose the tip of the
antenna by twisting the vinyl.
• Make sure the antenna conductors do not touch any other
terminals, connecting cords and power cord. Also, keep the
antennas away from metallic parts of the System,
connecting cords, and the AC power cord. This could cause
poor reception.
To connect the speaker cords
Make sure the both speakers are connected correctly and
firmly.
When connecting the speaker cords, match the polarity of
the speaker terminals: The cord with black stripe to (–), the
cord without stripe to (+).
• DO NOT connect more than one speaker to
each terminal.
• DO NOT allow the conductor of the speaker
cords to be in touch with the metallic parts of
the System.
1Hold
2Insert 3Release
1Hold
2Insert
3Release
UX-G45[B].BOOK Page 7 Thursday, March 2, 2006 4:26 AM

8
Before Operating the System
The indications on the display teach you a lot of things while you are operating the System.
Before operating the System, be familiar with when and how the indicator illuminates on the display.
1Play mode indicators
• RAND (random): Lights when Random Play mode is
activated.
• PRGM (program): Lights when Program Play mode is
activated.
• : Lights when Repeat mode is activated.
– 1: Repeats the track.
– ALL: Repeats all the tracks.
– GR: Repeats all the tracks in the selected group (MP3
only).
2QP Link Indicator
• Lights when QP Link is activated.
3MP3 indicator
• Lights when an MP3 is detected.
4USB indicator
• Lights when USB MEMORY is selected.
5FM reception indicators
• MONO: Lights while the FM monaural mode is
activated.
• ST (stereo): Lights while an FM stereo station with
sufficient signal strength is tuned in.
6SOUND TURBO indicator
• Lights when the SOUND TURBO is activated (see
page 14).
7AHB PRO (Active Hyper Bass Pro) indicator
• Lights when the AHB PRO is activated.
8TA/Program type (PTY) indicator
–TA/News/Info: Lights to indicate the currently selected
program type for PTY Standby Reception.
–TA/News/Info: Flashes when a program is
automatically tuned in with PTY Standby Reception.
9Main display
pA.STBY(Auto Standby) indicator
• Lights when Auto Standby is activated.
• Flashes when disc playback stops with Auto Standby
activated.
qTimer indicators
• : Lights when Daily Timer stands by; flashes while
working.
• 1/2/3: Lights when a Daily Timer (1, 2, or 3) stands by;
flashes while being preset or working.
• SLEEP: Lights when the Sleep Timer is activated.
• While listening to radio:
Band Frequency
• While disc play is stopped:
Total track number Total playing time
Current track
number
Elapsed
playing time
CD:
MP3:
• While playing a CD:
* When you start playing an MP3 disc, the track number,
track name, (and ID3 Tag) will be shown before the
elapsed playing time appears.
Indications on the main display
• While playing an MP3*:
Total track number Total group
number
Total track
number
• While selecting AUX:
• While in “TRACK” mode: • While in “GROUP” mode:
12345 6 7
8911
10
Track number Elapsed
playing time
• While selecting USB MEMORY:
Elapsed playing time Current track number
Source name
When RESUME is ON, RESUME is shown on the
display. This also applies when the USB Memory or the
DAP is stopped.
UX-G45[B].BOOK Page 8 Thursday, March 2, 2006 4:26 AM

9
Daily Operations—Playback
1Turn on the power.
The STANDBY lamp on the main unit turns off.
• Without pressing STANDBY/ON , the System
turns on by pressing one of the source selecting
buttons in the next step.
2Select the source.
Playback automatically starts if the selected source is
ready to start.
• If you press AUX, start playback source on the
external component.
3Adjust the volume.
4Operate the target source as explained
later.
To turn off (stand by) the System
To turn off the clock indication to save the power
While the System is turned off...
2
1
3
2
1
VOLUME
STANDBY/ON
3
4
4/1,
7,¡/¢
SET/
RESUME
PRESET UP,
PRESET DOWN
QP LINK
FM MODE
Numeric
buttons
MP3 MODE
Radio Data
System
buttons
DISPLAY
DIMMER
The STANDBY lamp on the main unit
lights up.
• A small amount of power is always
consumed even while on standby.
• Press the button again, to display the
clock indication.
For private listening
Connect a pair of headphones to the PHONES jack on the
main unit. The sound will no longer come out of the
speakers. Be sure to turn down the volume before
connecting or putting the headphones.
• Disconnecting the headphones will activate the
speakers again.
DO NOT turn off (stand by) the System with
the volume set to an extremely high level;
otherwise, the sudden blast of sound can
damage your hearing, speakers and/or
headphones when you turn on the System or
start playback.
STANDBY/ON
DIMMER
UX-G45[B].BOOK Page 9 Thursday, March 2, 2006 4:26 AM

10
Listening to the Radio
To select the band (FM or AM)
You can also carry out the same operation using the FM or
AM buttons on the System.
To tune in to a station
While FM or AM is selected...
Frequency starts changing on the display.
When a station (frequency) with sufficient signal strength is
tuned in, the frequency stops changing.
• When you repeatedly press the button, the frequency
changes step by step.
To stop searching manually, press either button.
If the received FM station is hard to listen
To preset the stations
You can preset 30 FM and 15 AM stations.
1Tune in to a station you want to preset.
2Activate the preset number entry mode.
• Finish the following process while the indication on the
display is flashing.
3Select a preset number for the station you store.
• You can also use the PRESET UP/PRESET DOWN
buttons.
4Store the station.
memo
• If you preset a station set to MONO, the station is stored
with the MONO setting.
Remote control: Main unit:
MONO: Reception will improve though stereo
effect is lost. MONO indicator lights up.
STEREO: Normally select this. Stereo effect will
be resumed.
FM AM
1sec.
DOWN UP
1sec.
Remote
ONLY
FM MODE
MONO
STEREO
Examples:
To select preset number 5, press
5.
To select preset number 15, press
10 →1 →5.
To select preset number 30, press
10 →3 →0.
Remote
ONLY
SET/RESUME
1
4
7
0
2
5
8
3
6
9
10
=
>
=
>
SET/RESUME
UX-G45[B].BOOK Page 10 Thursday, March 2, 2006 4:26 AM

11
To tune in to a preset station
1Select a band (FM or AM).
2Select a preset number for the station you store.
Playing Back a Disc
This System can play back the following discs—regular CD
and CD-R/CD-RW (recorded either in the audio CD or MP3
format).
• Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore, the
use of Non-DVD side of a DualDisc on this product may
not be recommended.
To insert a disc
You can insert discs while playing another source.
To close the disc tray, press 0again.
• When the disc tray is open, pressing CD 6closes the tray
and the playback starts.
To select a track/group*
* For details about the group selection, see “For MP3
playback” on page 12.
To locate a particular portion
While playing a disc, press and hold until the portion you
want is reached.
No sound is played during this operation on MP3 sources.
To locate a track directly and
start play
Playing Back from the USB Memory or
Digital Audio Player
This System is equipped with a USB MEMORY terminal on
the front panel. You can connect your USB Memory or
Digital Audio Player (DAP) to this terminal and enjoy the
sound out of your USB Memory or DAP.
• Remember you cannot send any signal or data to your USB
Memory or DAP from this System.
• You can also use the
PRESET UP or
PRESET DOWN.
Disc Type Mark (logo)
Audio CD
CD-R
CD-RW
Remote
ONLY
FM AM
1
4
7
0
2
5
8
3
6
9
10
Main Unit
ONLY
To start: To pause: To stop:
To release, press again.
Examples:
To select track number 5, press 5.
To select track number 15, press
10 →1 →5.
To select track number 30, press
10 →3 →0.
(For MP3 sources with 100 or
more tracks)
To select track number 125, press
10 twice →1 →2 →5.
* For up to 99 tracks, you can press
10 twice to turn to the
condition before 10 is pressed.
Decreases the track/group*
numbers.
Increases the track/group*
numbers.
Fast-forwards the track.
Fast-reverses the track.
Remote
ONLY
1
4
7
0
2
5
8
3
6
9
10
=
>
=
>
=
>
=
>
=
>
UX-G45[B].BOOK Page 11 Thursday, March 2, 2006 4:26 AM

12
To connect the USB Memory or DAP
Connect the DAP to the System using the USB cable
supplied with the DAP.
• Use a USB cable with a “series A” plug at the System end.
• When disconnecting the USB Memory or DAP, make sure
that playback is finished and that the System is in the stop
condition.
To play back sounds on the USB Memory or DAP
• The USB indicator on the display is lit while USB
MEMORY is selected.
To select a track/group*
* For details about the group selection, see “For MP3
playback” below.
•
IMPORTANT
• Always set volume to “VOL MIN” when connecting or
disconnecting the other equipment.
• Connect the USB Memory or DAP directly to the front
panel of the unit. Connecting via a USB hub may result
in malfunction.
• USB Memory and DAPs compatible with the USB
mass storage class specifications are connectable.
• Some DAPs are not compatible with the unit.
• Coded or encrypted tracks in a special method cannot be
played on the unit. Only MP3 is supported.
To start: To stop:
or
USB
MEMORY
Increases the track/group* numbers.
Decreases the track/group* numbers.
Resume Play for Audio CD/MP3/USB
Memory/DAP
If you press 7during playback, the position of the track
where you stopped playback will be memorized by the unit.
By pressing CD 6or USB MEMORY 6, you can
start playback again from the point where you stopped
it.
To activate/cancel resume play
When the source is CD or USB MEMORY...
memo
• Pressing 0or disconnecting the USB Memory/DAP
will erase the position of the track where you stopped
playback.
• To play back from the first track while resume play is
activated, press 7twice during playback then press
CD 6or USB MEMORY 6.
Remote
ONLY
SET/RESUME
RESUME ON
RESUME OFF
2sec.
For MP3 playback
According to the MP3 playback mode, 4/1/
¡/¢or number buttons work for the group
selection or the track selection.
Examples:
When the MP3 play back mode is “GROUP.”
You can change the MP3 playback mode
by pressing MP3 MODE.
• Each time you press the button, the MP3
playback mode changes as follows:
TRACK:
• Only tracks are detected (groups are ignored).
• 4/1, ¡/¢, and number buttons
work for the track selection of the MP3.
GROUP:
• Both groups and tracks are detected.
• 4/1, ¡/¢, and number buttons
work for the group selection of the MP3.
• Number buttons work for selecting the track
number within the group.
Total group number Total track number
GR (Group) indicator
MP3 MODE
TRACK GROUP
UX-G45[B].BOOK Page 12 Thursday, March 2, 2006 4:26 AM

13
Playing Back Other Equipment
To connect other equipment
By using an stereo mini plug cord (not supplied), you can
connect equipment with analog audio output jacks such as a
Digital Audio Player, or a TV, etc.
If the audio output on the other equipment is not stereo
mini plug type,
Use a plug adapter to convert the stereo mini plug to the
corresponding plug of the audio output.
Refer to the manuals supplied with the other equipment.
To adjust the sound input level from other
equipment
You can adjust the sound input level from the connected
equipment, if the incoming signal is too small or too large.
1Select AUX for the source.
2Adjust the input level.
AUX LVL 1: Ordinary input level (factory setting).
Suitable for equipment with low output level
(such as a portable audio device).
AUX LVL 2: Decreased input level.
Suitable for equipment with high output level
(such as a DVD player).
memo
• If you feel that the output level from the external
equipment is high, select AUX LVL2.
Quick Portable Link (QP Link)
If you connect other equipment such as a digital audio player
to the AUX terminal and play it back, the source
automatically changes to AUX.
The QP Link indicator is lit while QP Link is activated.
When QP Link is activated...
• If an audio input is received at AUX when the System is
turned on, the source automatically switches to AUX.
• If an audio input is received at AUX when the System is in
standby mode, the system automatically turns on and plays
the audio.
• You cannot change the source while audio input is being
received at AUX.
If you press another source button, the QP Link indicator
blinks several times.
memo
• While playback is going on the portable audio device, QP
Link may turn the System on even if the Sleep Timer turn
the System to standby or if you turn the System to standby.
In this case, deactivate QP Link or stop playback on the
device connected to the AUX jack.
• If the audio input received at AUX is small, the source may
not switch to AUX.
• The source may not switch to AUX depending on the
content of the music.
• It takes a second or two for the source to switch to AUX
after another equipment such as a digital audio player is
started and sound is output. This is due to the System
detecting the signal from the equipment.
• QP Link does not work, if the clock indication is turned off
at standby.
IMPORTANT
• Always set volume to “VOL-MIN” when connecting or
disconnecting the other equipment.
AUX
(front panel)
Stereo mini plug cord (not supplied)
Portable audio
device,
Game machine, etc.
SET/RESUME
AUX LVL 1
AUX LVL 2
2sec.
Remote
ONLY
QP LINK
(No indication)
QP Link
Canceled
UX-G45[B].BOOK Page 13 Thursday, March 2, 2006 4:26 AM

14
Daily Operations—Sound & Other Adjustments
Adjusting the Volume
You can adjust the volume level from level 0 (VOL-MIN) to
level 31 (VOL-MAX).
To drop the volume in a moment
Adjusting the Sound
To emphasize the sound—SOUND TURBO
This function emphasizes the sound.
To reinforce the bass sound
—AHB PRO
You can reinforce the bass sound to maintain rich, full bass
at low volume.
To adjust the tone—BASS/TREBLE
You can adjust the bass and treble level from 0 to +5.
To adjust the bass
To adjust the treble
You can also carry out the same operation on the System.
When SOUND TURBO is ON, BASS/TREBLE is disabled.
Remote control
Main unit
SOUND
TURBO VOLUME
+/–
CLOCK/
TIMER
DIMMER
A.STANDBY
SLEEP
SOUND
TURBO
AHB PRO
SET/RESUME
CANCEL
DISPLAY
PRESET UP,
PRESET DOWN
FADE
MUTING
VOLUME
+/–
BASS/
TREBLE
BASS TREBLE
DIMMER
Remote control: Main unit:
To restore the volume, press again, or
adjust the volume level.
VOLUME
VOLUME
Remote
ONLY
FADE
MUTING
SOUND
TURBO
OFF
S-TURBO
(Canceled)
Remote
ONLY
AHB PRO
OFF
AHB PRO
(Canceled)
BASS/
TREBLE
VOLUME
Canceled
BASS TREBLE
BASS/
TREBLE
VOLUME
BASS TREBLE
Canceled
UX-G45[B].BOOK Page 14 Thursday, March 2, 2006 4:26 AM

15
Changing the Display Brightness—DIMMER
You can dim the display window.
Setting the Clock
Without setting the built-in clock, you cannot use the Daily
Timer (see page 22).
• To exit from the clock setting, press CLOCK/TIMER as
required.
• To go back to the previous step, press CANCEL.
1Activate the clock setting mode.
• If you have already adjusted the clock before, press the
button repeatedly until the clock setting mode (see
page 22) is selected.
2Adjust the hour.
3Adjust the minute.
“CLOCK OK” appears and the built-in clock starts
working.
To check the current time during play
If there is a power failure
The clock loses the setting and is reset to “0:00.” You need
to set the clock again.
DIMMER
DIM ON
DIM OFF
(Canceled)
Remote
ONLY
CLOCK
/TIMER
PRESET UP
PRESET DOWN
SET/RESUME
PRESET UP
PRESET DOWN
SET/RESUME
DISPLAY
Clock
Source information
UX-G45[B].BOOK Page 15 Thursday, March 2, 2006 4:26 AM

16
Turning Off the Power
Automatically
To turn off the System after playback is over—
Auto Standby
This function works only when the source is CD.
When Auto Standby is in use, the A.STBY indicator lights
on the display.
When the disc playback stops, the A.STBY indicator starts
flashing.
If no disc operation is done for about 3 minutes while the
indicator is flashing, the System turns off (stands by)
automatically.
To turn off the System after a certain period of
time—Sleep Timer
1Specify the time (in minutes).
2Wait until the set time goes off.
To check the time remaining until the shut-off time
• If you press the button repeatedly, you can change the shut-
off time.
Remote
ONLY
A.STANDBY
(No indication)
A.STBY
Canceled
SLEEP
10 20 30 60 90 120
OFF
(Canceled)
SLEEP
UX-G45[B].BOOK Page 16 Thursday, March 2, 2006 4:26 AM
