FIXING KIT PART No :
KIT T0343
GA40093-001A-U
IMPORTANT NOTES
THIS STAND MUST BE USED ONLY WITH THE TV WHICH IT SUPPLIED.
DO NOT USE ANY SCREWS OTHER THAN THOSE PROVIDED.
DO NOT USE SOLVENTS FOR CLEANING. USE A DAMP CLOTH TO REMOVE ANY HANDLING OR PACKAGING MARKS.
GLASS SUPPLIED HAS BEEN TOUGHENED TO TO BRITISH STANDARD BS 6206A - HANDLE WITH CARE.
DO NOT ATTEMPT TO MOVE THE ASSEMBLY WITH THE TV ATTACHED AS THIS MAY RESULT IN PARTS BEING DAMAGED.
TOOLS REQUIRED
RK - C37FS1 FLOORSTAND
ASSEMBLY INSTRUCTIONS
(TO BE RETAINED BY CUSTOMER)
FOOT SHORT EXTRUSION SPACER GLASS BASE WITH FEET TALL EXTRUSION GLASS SHELF TOP PLATE ASSEMBLY TV FIXING BRACKET REAR COVER
x2
x1 x1 x4 x1 x1 x1 x1 x1
Ax2
E
x4
B
x2
C
x2
D
x2
F
x2 x1
G
x2
H
x2
GA30102-001A-U GA20104-001A-U GA30103-001A-U GA10144-001A-U
GA20105-001A-U
GA10145-001A-U
GA20107-001A-U
GA20106-001A-U GA20108-001A-U
GA20109-001A-U

GH
+
7B
6
THESE CARDBOARD RECTANGLES ARE PART OF THE PACKAGING.
USE THEM TO SUPPORT THE GLASS SHELF DURING ASSEMBLY.
POSITION THEM ON THE GLASS BASE BEFORE LOWERING THE GLASS SHELF.
9
D
C
MAKE SURE THAT PARTS ‘D’ ARE
FULLY TIGHTENED.
REMOVE CARDBOARD RECTANGLES.
10
E
FIXING BLOCK
TV FIXING BRACKET
HOLD THE TV FIXING BRACKET IN THE MIDDLE AT THE TOP DURING ASSEMBLY.
MAKE SURE IT IS HORIZONTAL WITH THE FIXING BLOCK
12
F
FIX THE REAR COVER TO THE TV TO HIDE YOUR CABLES WHEN
YOU HAVE CONNECTED ALL YOUR AUDIO VISUAL UNITS.
GA10146-001A-U
MANT0343
8
IMPORTANT :
MAXIMUM WEIGHT ON SHELF
WHEN ASSEMBLED = 5 kg
FIT CABLE TIES ‘G’ AND ‘H’ TO THE UNDERSIDE OF THE GLASS SHELF
11
UNSCREW THESE PARTS FROM THE BACK OF THE TV.
WITH ASSISTANCE ALIGN THE TV AGAINST THE TV FIXING BRACKET.
REUSE THE PARTS TO SECURE THE TV TO THE BRACKET.
DO NOT OVERTIGHTEN SCREWS.
