COLOUR TELEVISION INSTRUCTIONS
ENGLISH
AV-28F3SJ

ENGLISH - 1 -
Contents
Safety Precautions .................................................. 1
Warning ..................................................................... 2
Guidelines for safe operation ................................ 2
Remote Control Buttons ......................................... 3
Control Panel Buttons............................................. 4
Antenna Connections .............................................. 4
Preparation ...............................................................
Features .......................................................................... 5
Before Switching on your TV .................................
Power connection ............................................................. 5
Aerial Connections ........................................................... 5
How to connect the external equipments .......................... 5
Inserting batteries in the remote control handset .............. 5
Switching the TV ON/OFF .......................................
o switch the V on.......................................................... 5
o switch the V off .......................................................... 5
Initial Settings ..........................................................
-V LINK .......................................................................... 6
Operating with the onset buttons ...................................... 7
Operating with Remote Control ......................................... 7
Menu System ............................................................ 7
Sound Menu ..................................................................... 7
Picture Menu ................................................................... 8
Feature Menu ................................................................. 10
Install (Installation) Menu................................................ 10
Using the Decoder (EX -2) function ................................ 11
Program (Programming) Menu ....................................... 12
o start AU O PROGRAM (AU OS ORE) ..................... 12
Other Features ....................................................... 12
Sound Mute ................................................................... 12
Stereo / Bilingual ............................................................ 12
Information on Screen .................................................... 12
o Display the ime........................................................ 13
Picture ........................................................................... 13
VCR / DVD Control Buttons and VCR / / DVD Switch13
Teletext ................................................................... 13
o operate eletext ......................................................... 13
o select a page of eletext ............................................ 13
o Select Index Page ..................................................... 13
Searching for a teletext page while watching V ............. 13
o Select Double Height ext ......................................... 13
o Reveal concealed Information .................................. 14
o Stop Automatic Page Change .................................... 14
o Select a Subcode Page ............................................. 14
o exit eletext ............................................................... 14
Fastext and optext ....................................................... 14
Connect the External Equipments ....................... 14
Via the Euroconnector .................................................... 14
-V LINK compatible VCR .............................................. 14
RGB mode ..................................................................... 14
EX -2S Mode ................................................................. 14
Via the RCA jacks .......................................................... 14
Via the AN (aerial) socket ............................................. 14
V and Video Recoder (VCR) ......................................... 14
N SC Playback ............................................................. 16
Copy Facility .................................................................. 16
Connecting Headphones ................................................ 16
Tips .......................................................................... 16
Specifications ......................................................... 16
Safety Precautions
1. Power Source
he receiver should be operated only from a 220-240V AC,
50 Hz. outlet. Ensure you select the correct voltage setting
for your convenience.
2. Power Cord
he power supply cord should be placed so that they are not
likely to be walked on or pinched by items placed upon them
or against them. Pay particular attention to cord where they
enter the plug, power outlet, and the point where they exit
from the receiver.
3. Moisture and Water
Do not use this equipment in a humid and damp place (avoid
the bathroom, the sink in the kitchen, and near the washing
machine). Do not expose this equipment to rain or water and
do not place objects filled with liquids on it as this may be
dangerous.
4. Cleaning
Before cleaning, unplug the receiver from the main supply
outlet. Do not use liquid or aerosol cleaners. Use with soft
and dry cloth.
5. Ventilation
he slots and openings on the receiver are intended for venti-
lation and to ensure reliable operation. o prevent overheat-
ing, these openings must not be blocked or covered in any-
way.
6. Lightning
In case of storm and lightning or when going on holiday, dis-
connect the power cord from the wall outlet.
7. eplacement Part
When replacement parts are required, be sure the service
technician has used replacement parts which are specified
by the manufacturer or have the same specifications as the
original one. Unauthorized substitutions may result in fire,
electrical shock, or other hazards.
8. Servicing
Please refer all servicing to qualified personnel. Do not re-
move cover as this may result in electric shock.
9. Flame sources
Do not place naked flame sources on the apparatus.
10. Stand-By
Do not leave your V stand-by or operating condition when you
leave your house.
Warning!
Any intervention contrary to regulations, in particular, any
modification of high voltage or a replacement of the picture
tube may lead to an increased concentration of x-rays. Any
television modified in this way no longer complies with li-
cense and must not be operated.
Instructions for waste disposal:
Packaging and packaging aids are recyclable and should
principally be recycled. Packaging materials, such as foil
bag, must be kept away from children.
Batteries, including those which are heavy metal-free, should
not be disposed of with household waste. Please dispose of
used batteries in an environmentally sound manner. Find out
about the legal regulations which apply in your area.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:001

ENGLISH - 2 -
Warning
DO NOT cut off the mains plug from this
equipment.
If the plug fitted is not suitable for the power points in your
home or the cable is too short to reach a power point, then
obtain an appropriate safety approved extension lead or adap-
tor or consult your dealer.
If nonetheless the mains plug is cut off, remove the fuse and
dispose of the plug immediately, to avoid a possible shock
hazard by inadvertent connection to the mains supply.
If a new mains plug has to be fitted, then follow the instruc-
tion given below:
Important
Do not make any connection to the larger terminal which is
marked with the letter E or by the safety earth symbol   or
coloured green or green-and-yellow.
he wires in the mains lead on this product are coloured in
accordance with the following code:
Blue: Neutral
Brown: L ve
As these colours may not correspond with the coloured
marking identifying the terminals in your plug proceed as fol-
lows:
he wire which is coloured blue must be connected to the ter-
minal which is marked with the letter N or coloured black.
he wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
When replacing the fuse only a correctly rated approved type
should be used and be sure to re-fit the fuse cover.
If in doubt  consult a competent electrician.
How to replace the fuse
Open the fuse compartment with a blade screwdriver, and re-
place the fuse.
Guidelines for safe operation
his equipment has been designed and manufactured to
comply with international safety standards.
However, as with any electrical appliance, care must be tak-
en to ensure optimal results and operational safety.
 Before attempting to use this equipment, read the operating
instructions thoroughly.
 Ensure that all electrical connections (including the mains
plug, extension leads, etc.) have been made in accordance
with the manufacturers instructions.
 If ever in doubt about the installation, operation or safety of
this equipment, consult your dealer.
 Handle all glass panels or covers with care.
 Never operate this equipment if it appears damaged or oper-
ates abnormally. urn the power off, disconnect the main
power plug and consult your dealer.
 Never remove any affixed panels or covers. Doing so may
result in electrical shock.
 Never leave this equipment operating unattended unless
otherwise specifically stated that it is designed to do so or
in standby mode. Only use the designated power switch to
turn off the power and ensure that all potential users are in-
structed how to do so. Make special arrangements for in-
firm or handicapped persons.
 Never listen to headphones at high volume. Doing so may
damage your hearing.
 Never obstruct the ventilation of this equipment. Doing so
may cause overheating and result in a malfunction or dam-
age.
 Never use makeshift stands or attempt to affix legs with
wood screws. When using a manufacturers approved stand
or legs, use only the fixtures provided and follow the instal-
lation instructions.
 Never allow this equipment to be exposed to rain or mois-
ture.
 Never allow anyone, especially children, to insert anything
into an opening in the case. Doing so may result in a fatal
electrical shock.
 Never guess or take chances with electrical equipment of
any kind. It is better to be safe than sorry.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:002

ENGLISH - 3 -
Remote Control Buttons
= Stand By / Power
0 - 9 = Direct Program
Yellow Button / Factory Settings in Picture Menu
Blue Button
PICTURE = Picture Mode Change
( ) = Programme Up (Cursor Up)
MENU = Menu Button
( ) = Cursor Right / Volume +
( ) = Programme Down (Cursor Down)
eletext / VCR /DVD Control Buttons
= Stereo / Bilingual Button
= VCR / / DVD Switch
= Information Button / -V Link in Program Menu
( ) = Cursor Left / Volume -
AV = AV Button
= eletext Button
£Ç
ZOOM = Zoom (Picture Size) Change / Red Button
£n
= Hyper Sound / Green Button
£
= Mute
CAUTION
RISK OF ELECTRIC SHOCK
he lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk
of electric shock of persons.
he exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.
£Î
£{
{
x
È
Ç
n

£ä
££
£Ó
£
Ó
Î
£x
£È
£Ç
£n
£
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:003

ENGLISH - 4 -
Control Panel Buttons
Antenna Connections
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:004

ENGLISH - 5 -
Preparation
Place V on a solid surface.
For ventilation, leave a space of at least 10 cm free all around
the set. o prevent any fault and unsafe situations, please do
not place any objects on top of the set.
Use this apparatus in tropical and moderate climates.
Features
 It is a remote controlled colour television.
 100 programmes from VHF, UHF bands or cable channels
can be preset.
 It can tune cable channels.
 Controlling the V is very easy by its menu driven system.
 It has three Euroconnector sockets for external devices
(such as video recorder, video games, audio set, etc.)
 Front AV (EX -4) Input available.
 Stereo sound systems (Nicam) are available.
 Full function eletext (Fastext, optext).
 It is possible to connect headphone.
 Direct channel access.
 AU O PROGRAM (Automatic Programming System).
 All programmes can be named.
 Forward or backward automatic tuning.
 Sleep timer.
 Child Lock.
 Blue Background.
 Panoramic Mode.
 Comb Filter : Digital circuitry to make adjustments provid-
ing outstanding picture quality with sharp, crisp edges,
while virtually eliminating dot crawl.
 C I : (Colour ransient Improvement) Improvement of hori-
zontal transitions of chrominance (colour) signals.
 -V Link.
 Automatic sound mute when no transmission.
 When no valid signal is detected, after 5 minutes the V
switches itself automatically to stand-by mode.
 WSS (Wide Screen Signaling).
 N SC Playback.
Before S itching on your TV
Power connection
Important: he V set is designed to operate on 220-240 V
AC, 50 Hz.
 After unpacking, allow the V set to reach the ambient
room temperature before you connect the set to the mains.
Aerial Connections
 Connect the aerial plug to the aerial input socket located at
the back of the V.
How to connect the external equipments
See Connect the External Equ pments on page 15.
 See the instruction manuals provided with the external de-
vices too.
Inserting batteries in the remote control handset
 Remove the battery cover located on the back of the hand-
set by gently pulling upwards from the indicated part.
 Insert two AA (R6) or equivalent type batteries inside.
 Replace the battery cover.
NOTE: emove batteries from remote control handset when it
is not to be used for a long period. Otherwise it can be damaged
due to any leakage of batteries.
S itching the TV ON/OFF
You can operate your TV either using the remote control
handset or directly using the TV onset buttons
To switch the TV on
Your V will switch on in two steps:
1- Press the power button located on the front of the V.
hen the V switches itself to standby mode and the RED
LED located below the V turns on.
2- o switch on the V from stand-by mode either:
Press a digit button on the remote control so that a program-
me number is selected,
or,
Press Standby / Power Button or Programme Up and Down
buttons on the V or on the remote control respectively, so
the V will switch on and the RED Led will turn GREEN.
To switch the TV off
 Press the stand-by button on the remote control, so the V
will switch to stand-by mode and the GREEN LED will be-
come RED, or,
 Press the power button located on the front of the V.
Initial Settings
he message PLEASE CHECK ANTENNA CABLE AUTO.
PROGRAMMING SYSTEM will be displayed when you turn
on your V for the first time.
1- Select LANGUAGE with   or   button, then
press the   or   button to select a menu language.
2- Select COUNTRY with   or   button, then press
the   or   button to select the country you are now lo-
cated.
3- Select START with   or   button, then press the
right button to start AUTO PROGRAM.
AUTO PROGRAM, (Automatic Programming System) auto-
matically programmes the received channels in your Vs
programme numbers. During AUTO PROGRAM, AUTO
PROGRAM IS RUNNING PLEASE WAIT will be displayed.
After AUTO PROGRAM is finalized, the PROGRAM menu
appears.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:005

ENGLISH - 6 -
o cancel AUTO PROGRAM, press the PICTURE button.
You can delete a channel, insert a channel into a programme
number, or re-start AUTO PROGRAM with the PROGRAM
menu. For details, see PROGRAM (Programm ng) menu
on page 11.
4- If you do not have a -V LINK compatible VCR, press
PICTURE button to exit the menu.
If you have a -V LINK compatible VCR connected to the
EXT.2 terminal, press   button to display T-V LINK
menu. hen follow the operating procedure Download ng
data to VCR in the following T-V LINK section.
If the message PLEASE CHECK ANTENNA CABLE AUTO.
PROGRAMMING SYSTEM does not appear, or if you want
to modify the settings later, you can do manually with the
FEATURE, INSTALL and PROGRAM menus.
For users in the UK:
If you have any problems setting up your new V,
please call the JVC Helpline on 0870 330 5000.
For users in the epublic of Ireland:
If you have any problems setting up your new V,
please contact your local JVC dealer.
T-V LINK
When a -V LINK compatible VCR is connected to the EXT.2
erminal on the V, it is easier to set up the VCR and to view
videos. -V LINK uses the following features:
To use T-V LINK functions:
A T-V LINK compat ble VCR means a JVC video cassette
recorder with the -V LINK logo, or with one of the following
logos. However, these VCRs may support some or all of the
features described earlier. For details, see your VCR instruc-
tion manual.
Q-LINK (a trademark of Panasonic Corporation)
Data Log c (a trademark of Metz Corporation)
Easy L nk (a trademark of Phillips Corporation)
Megalog c (a trademark of Grundig Corporation)
SMARTLINK (a trademark of Sony Corporation)
Downloading data to VCR:
he VCR will automatically download the registered data on
the V channels from the V. his means you do not need to
set up the programme channels on your VCR manually.
he T-V LINK menu will be displayed when you press the
 button while PROGRAM menu is displayed, or when-
ever the INSTALL menu operations are performed.
Press   button to start downloading data to VCR.
 If you do not want to do, press the PICTURE button to
exit the menu.
When FEATURE NOT AVAILABLE... is displayed:
If FEATURE NOT AVAILABLE... is displayed, the download
was not performed correctly. Before trying to download again,
check that:
 he VCR power is turned on
 he VCR is -V LINK compatible
 he VCR is connected to the EX .2 terminal
 he SCAR cable is fully wired.
Direct Rec:
What You See Is What You Record
You can easy record to VCR the images that you are watch-
ing on the V. For details, read the manual for your VCR,
Use your VCR controls. You cannot carryout Direct Rec us-
ing your Vs control.
79 /,1. 79  9&5
9&5 ,6 5(&25',1*

When the VCR is not ready (for example when there is no
tape inserted), NO RECORDING is displayed.
In the following situations, the VCR will stop recording if the
V is turned off, if the V channel or input is changed, or if
the menu is displayed on the V:
 When recording images from an external device connected
to the V. (For example a camcorder)
 When recording a V channel after it has been un-
scrambled on a decoder.
 When recording a V channel by using the Vs output be-
cause the VCRs own tuner cannot properly receive that
channel.
TV auto power on/VCR image view:
When the VCR starts playing, the V automatically turns on
and the images from EXT.2 (EXT-2) terminal appear on the
screen.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:006

ENGLISH - 7 -
Th s funct on does not happen f your TVs ma n power
s turned off. Set your TVs ma n power to on (standby
mode).
Operating with the onset buttons
Volume setting and programme selection can be made using
the buttons on the right side of the V.
Volume Sett ng:
 Press  - button to decrease volume or  + button to
increase volume, so a volume level scale will be displayed
on the screen.
Programme Select ng:
 Press P/Ch+ button to select next programme or P/Ch-
button to select the previous programme.
Enter ng Ma n Menu:
 Press MENU button to enter main menu. In the main
menu select submenu using P/Ch+ or P/Ch- button and
enter the submenu using  + or  - button. o learn
the usage of the menus, refer to Menu System on page 7.
Operating with emote Control
he remote control handset of your V is designed to control
all the functions of the model you selected. he functions will
be described in accordance with the menu system of your
V.
Functions which you can use out of menu system are de-
scribed below.
Volume Sett ng:
Press  button to increase volume.
Press   button to decrease volume.
Programme Select ng (Prev ous or next programme):
 Press   button to select the previous programme.
 Press   button to select the next programme.
Programme Select ng (d rect access):
Press digit buttons on the remote control handset to select
programmes between 0 and 9. V will switch to the selected
program after a short delay.
 For a two digit program number enter the second digit after
pressing the first digit within 2 seconds.
Menu System
Your V has been designed with a menu system. Display
MENU (main menu) and enter one of five menus (SOUND,
PICTURE, FEATURE, INSTALL and PROGRAM).
1- Press MENU button to display MENU (main menu).
he menu titles will be displayed in the main menu.
2- Press   or   button to select a menu title, then
press   or   button to enter the menu.
 o exit a menu, press PICTURE button.
 o go to the previous menu, press MENU button.
6281'
3,&785(
)($785(
,167$//
352*5$0
Sound Menu
To change sound settings:
 Press MENU button, now you are in main menu. In the
main menu, SOUND will be the first selected option. Enter
the sound menu pressing   or   button.
Setting Volume:
As you enter the sound menu, Volume will be the first select-
ed option.
 Press   button to increase volume.
 Press   button to decrease volume.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
Setting Bass Level:
 Using   or   button select Bass.
 Press   button to increase bass level.
 Press   button to decrease bass level.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
Setting Treble Level:
 Using   or   button select reble.
 Press   button to increase treble level.
 Press   button to decrease treble level.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:007

ENGLISH - 8 -
Setting Balance:
 Using   or   button select Balance.
 Press   button to change balance rightward.
 Press   button to change balance leftward.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
Hyper Sound:
You can use this feature to switch on or off Hyper Sound.
Pressing   or   button will turn on or off this feature. If the
current sound system is MONO and the Hyper Sound is set
ON, then the sound will be heard as if it is STEREO. If the
current sound system is STEREO, switching Hyper Sound
on will make the sound deeper. Switching it off will make no
change in MONO and STEREO.
92/80(
%$66
75(%/(
%$/$1&(
+<3(56281' 
21
Hyper Sound can be set On or Off also by GREEN button.
Picture Menu
To change picture settings:
 Press MENU button, now you are in main menu. In the
main menu, select PICTURE using   or   button,
then enter the picture menu pressing   or   button.
6281'
3,&785(
)($785(
,167$//
352*5$0
Note: When Picture Mode is not MANUAL, BRIGH NESS,
CON RAS and COLOUR options can not be reached by
 or   buttons.
Factory Settings:
In the Picture Menu if you press the YELLOW button the ad-
justments switches themselves to the factory settings.
Setting Brightness:
You can change Br ghtness only when Picture Mode is se-
lected MANUAL.
Using   or   button select Brightness.
 Press   button to increase Brightness.
 Press   button to decrease Brightness.
Setting Contrast:
You can change Contrast only when Picture Mode is select-
ed MANUAL.
 Using   or   button select Contrast.
 Press   button to increase Contrast level.
 Press   button to decrease Contrast level.
Setting Colour:
You can change Colour only when Picture Mode is selected
MANUAL.
 Using   or   button select Colour.
 Press   button to increase Colour level.
 Press   button to decrease Colour level.
Setting Sharpness:
 Using   or   button select Sharpness.
 Press   button to increase Sharpness level.
 Press   button to decrease Sharpness level.
Setting Tilt:
 Using   or   button select ilt.
 Press   button to increase tilt level.
 Press   button to decrease tilt level.
Setting Hue (In AV mode only) :
 Using   or   button select Hue.
 Press   button to increase Hue level.
 Press   button to decrease Hue level.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:008

ENGLISH - 9 -
Hue adjust is functional only when N SC 3.58/4.43 is applied
in AV mode. It does not appear when other colour systems
used.
Setting VCR Mode (In AV mode only) :
 Using   or   button select VCR MODE.
 When you watch a picture from your VCR and the picture is
unstable, you may improve it by changing the "VCR MODE"
setting from "ON" to "OFF".
Picture Mode:
his item is used to change the picture mode. By pressing
 or   button you may choose one of these options:
BRIGHT, STANDARD, SOFT, MANUAL.
Colour Temp:
his item is used to change the Colour emperature. By
pressing   or   button you may choose one of these op-
tions: COOL, WARM, NORMAL.
Zoom:
You can change the screen size according to the picture as-
pect ratio. Choose the optimum one from the following ZOOM
modes.
AUTO:
When a WSS (W de Screen S gnall ng) signal, which
shows the aspect ratio of the picture, is included in the
broadcast signal or the signal from an external device, the V
automatically changes the ZOOM mode to 16:9 ZOOM mode
or FULL mode according to the WSS signal.
If a WSS signal is not included, the picture is displayed in
the PANORAMIC mode.
 When the AUTO mode does not function correctly due to
poor WSS signal quality or when you want to change the
ZOOM mode, change to another ZOOM mode manually.
REGULAR:
Use to view a normal picture (4:3 aspect ratio) as this is its
original shape.
PANORAMIC:
his stretches the left and right sides of a normal picture (4:3
aspect ratio) to fill the screen, without making the picture ap-
pear unnatural.
 he top and bottom of the picture are slightly cut off.
14:9 ZOOM:
his zooms up the wide picture (14:9 aspect ratio) to the up-
per and lower limits of the screen.
16:9 ZOOM:
his zooms up the wide picture (16:9 aspect ratio) to the full
screen.
16:9ZOOM S:
his zooms up the wide picture (16:9 aspect ratio) with subti-
tles to the full screen.
FULL:
his uniformly stretches the left and right sides of a normal
picture (4:3 aspect ratio) to fill the wide V screen.
 For 16:9 aspect ratio pictures that have been squeezed into
a normal picture (4:3 aspect ratio), use the FULL mode to
restore the picture to its original shape.
Choose the ZOOM mode:
Press the   or   button to choose a ZOOM mode.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:009

ENGLISH - 10 -
 You can choose the ZOOM mode by pressing the ZOOM
(RED) button when no menu appears on the screen.
 he ZOOM mode may be automatically changed by the
control signal from an external device. When you want to
return the previous ZOOM mode, choose the ZOOM mode
again.
Adjusting the visible area of the picture:
If subtitles or the top (or bottom) of the picture are cut off,
you can adjust the visible area of the picture manually.
1. Press ZOOM button once.
he ZOOM mode indicator appears. he ZOOM mode will
not be changed.
2. While it is displayed, press   or   to change the
position of the picture.
 You cannot adjust the visible area in REGULAR or FULL
mode.
Feature Menu
 Press MENU button, now you are in main menu. In the
main menu, select FEATURE, using   or   button.
hen enter the feature menu pressing   or   button.
6281'
3,&785(
)($785(
,167$//
352*5$0
Sleep Timer:
he sleep timer is used to turn the V off after a defined peri-
od. Press   or   button to choose a period of time after
selecting this item. he timer can be programmed between
Off and 120 minutes in steps of 10 minutes. (OFF, 010, 020,
030, 040, ......... ,120.)
If sleep timer is activated, at the end of the selected the time,
the V goes automatically to stand-by mode.
6/((37,0(5
&+,/'/2&.
/$1*8$*(
(;7287387
%/8(%$&.*5281'
2))
2))
(1*/,6+
79
2))
Child lock:
You can disable the control panel buttons (except the POW-
ER button) with this item.
Press   or   button to change the setting to On or Off after
selecting this item.
When you set this item to On, the V can be operated only
by using the remote control handset.
6/((37,0(5
&+,/'/2&.
/$1*8$*(
(;7287387
%/8(%$&.*5281'
2))
2))
(1*/,6+
79
2))
Warn ng: If Child Lock item is set to ON, the V can not be
operated by VCR.
Language:
Menu Language can be selected by pressing   or   button
on Language item.
6/((37,0(5
&+,/'/2&.
/$1*8$*(
(;7287387
%/8(%$&.*5281'
2))
2))
(1*/,6+
79
2))
Setting External Source Output:
 You can use this menu to select the internal or external
source that will be output at EXT.2 terminal.
 In the FEATURE menu select EXT-2 OUTPUT using
 or   button. hen select the source you want to
be output at EXT.2 pressing   or   button (one of the
sources: TV, EXT-1, EXT-3 or EXT-4 (Front AV).
6/((37,0(5
&+,/'/2&.
/$1*8$*(
(;7287387
%/8(%$&.*5281'
2))
2))
(1*/,6+
79
2))
Blue Background During No-Signal:
he BLUE BACKGROUND feature can be set by   or  
button to either ON or OFF.
Install (Installation) Menu
You can store a channel manually, or modify the current set-
tings of a channel (for example, fine-tuning a channel).
You can also changing the colour system, or change the
DECODER(EXT-2) setting.
 Press MENU button to display the main menu.
 Press   or   button to select INSTALL item.
hen   or   button to display the INSTALL menu.
6281'
3,&785(
)($785(
,167$//
352*5$0
Note:
 If you want to modify the current settings of a channel, se-
lect the channel of which you want to modify the setting.
hen display the main menu on screen.
 In AV mode, you can change only the COLOUR SYSTEM
item.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:0010

ENGLISH - 11 -
1. PROGRAMME will be the first selected item as you enter
the INSTALL menu. Pressing   or   button select the
programme number where you want to the tuned channel
to be stored. (You may also type the programme number
using the digit buttons.)
Note:
 Do not use PROGRAMME item when you modify the cur-
rent programme numbers setting. If you select other
programme number by mistake, the selected programme
numbers setting will be changed.
2. Press   or   button to select BAND. Using   or
 button to select the band in which you want to search
a channel.
3. Press   or   button to select SEARCH. Press
 or   button to start searching. (Press   button to
search forward. Press   to search backwards.)
 If the found channel is not the desired one, press   or
 button to start searching again.
 o stop searching before a channel is found, press the
reverse direction button. For example, when the V is
searching forward with   button, press   button to
stop searching.
 If you know the channel number which you want to find,
you can find the channel directly. Follow the step 4 to
select the correct standard, then press   or  
to select CHANNEL again, and press   or   button to
select the channel number, or enter the number with the
digit buttons.
4. If the picture is not clear or no colour appears, change the
colour system to display the picture normally. Press
 or   button to select COLOUR SYSTEM, then
press   or   button to choose the correct one.
 In V mode: PAL / SECAM
 In AV mode: AUTO / PAL / SECAM / NTSC 3.58 / NTSC 4.43
5. If the channel reception is poor, fine-tune the channel.
Press   or   to select FINE TUNING, then press
 or   button to fine-tune the channel.
6. After the all settings are completed, store the new
channels setting to the programme number which you se-
lected. Press   or   to select STORE, then
press   or   button to store it. T-V LINK menu will ap-
pear after the V stores the settings.
7. If you do not have a -V LINK compatible VCR, press
PICTURE button to exit the menu.
If you have a -V LINK compatible VCR connected to the
EX .2 terminal, follow the operating procedure Down-
load ng the data to VCR on page 6 to transmit the Pro-
gramme table data to the VCR.
To change the Colour system:
If the picture is not clear or no colour appears, choose the
correct colour system to display the picture normally.
1. Press   or   button to select COLOUR SYS-
TEM, then press   or   button to choose the correct
one.
 In V mode: PAL / SECAM
 In AV mode: AUTO / PAL / SECAM / NTSC 3.58 / NTSC 4.43
2. Press   or   to select STORE, then press   or
 button to store it.
3. When T-V LINK menu appears, follow the step 4.
4. If you do not have a -V LINK compatible VCR, press
PICTURE button to exit the menu.
If you have a -V LINK compatible VCR connected to the
EXT.2 terminal, follow the operating procedure Down-
load ng the data to VCR on page 6 to transmit the
Programme table data to the VCR.
Using the Decoder (EXT-2) function
If you have a decoder connected to a T-V LINK compatible
VCR, which in turn is connected to the EXT.2 terminal, use
DECODER(EXT2) to unscramble the scrambled V chan-
nels.
1. Exit the menu.
2. urn on the decoder power.
3. Display the scrambled V channel on the V. Even if the
decoder is working, a scrambled picture appears.
4. Display the INSTALL menu again.
5. Press   or   button to select DECODER(EXT-2),
then press   or   button to set to ON
6. Press   or   to select STORE, then press   or
 button to store it. T-V LINK menu will appear after the
V stores the setting.
7. Follow the operating procedure Download ng the data
to VCR on page 6 to transmit the revised programme
table data to the VCR.
 If you do not want to transmit, press PICTURE button
to exit the menu.
Note:
You can only use this item if you have a decoder connected
to a -V LINK compatible VCR to EX .2 terminal. Setting this
item to ON by mistake causes the picture/sound of a V
channel you are currently viewing to disappear.
If this item has been set to ON but the V channel cannot
be unscrambled, check the following:
 Has the decoder been connected to the VCR properly ac-
cording to the VCR and Decoder instruction manuals?
 Can the V channel be unscrambled with a decoder?
 Do you need to change the VCR settings in order to con-
nect the decoder? Confirm that the VCR is set properly by
rechecking the VCR instruction manual.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:0011

ENGLISH - 12 -
Program (Programming) Menu
You can use the PROGRAM (Programming) menu to delete
a channel, to change the programme number of a channel, to
give a channel name to a channel, and to start the AUTO
PROGRAM (AUTOSTORE) function.
 Press MENU button to display the main menu.
 Press   or   button to select PROGRAM item,
then   or   button to display the PROGRAM menu.
To choose a channel in the PROGRAM menu:
 Press   /  /   /   button. he programme num-
ber that you choose is high-lighted in the PROGRAM menu
and you can view the picture of that channel.
Caut on:
Using DELETE or INSERT function rewrite the current
channel list in the PROGRAM menu. herefore, the pro-
gramme numbers of some of channels will change.
When you complete the settings of PROGRAM
menu:
If you have a -V LINK compatible VCR, press the   but-
ton to display the -V LINK menu. hen follow the operating
procedure Download ng the data to VCR on page 6 to
transmit the Programme table data to the VCR.
If you do not have a -V LINK compatible VCR, press PIC-
TURE button to exit the menu.
To give a channel name (NAME):
1. Choose the channel you want to give a channel name.
2. Press the RED button to enter the NAME mode.
3. Press   or   button to choose the position, and press
 or   button to choose each character of chan-
nel name.
4. Press the RED button to store the channel name.
 o cancel the NAME mode, press the BLUE button.
To delete a channel (DELETE):
1. Choose the channel you want to delete.
2. Press the YELLOW button to enter the DELE E mode.
3. Press the YELLOW button to delete it.
 o cancel this DELE E mode, press the BLUE button.
To change the programme number of a channel
(INSERT):
1. Choose the channel you want to change the programme
number.
2. Press the GREEN button to enter the INSER mode.
3. Press   /   /   /   button to choose new
programme number.
4. Press the GREEN button to insert the channel to the cho-
sen programme number.
 o cancel this INSER mode, press the BLUE button.
To start AUTO P OG AM (AUTOSTO E)
AUTO PROGRAM Automatically programmes the received
channels in your Vs programme numbers.
1. Press the BLUE button to enter the AUTOSTORE mode.
A warning message appears.
 o cancel the AUTOSTORE mode, press the PIC-
TURE button.
2. Press   or   button to choose the COUNTRY,
then press   or   button the choose country you are
now located.
3. Press   or   button to choose the CONTINUE,
then press   button to start AUTO PROGRAM he fol-
lowing message appears.
 o cancel the AUTO PROGRAM, press the PICTURE
button.
4. After AUTO PROGRAM is finalized, the PROGRAM menu
appears again.
Other Features
Sound Mute
o cut off the sound of the V, press   button. he sound
will be cut off. o cancel mute, press   or   or   but-
ton. he volume level will be the same as the level before
mute when you cancel mute.
Stereo / Bilingual
 If the V channel you are watching broadcasts in two lan-
guages (e.g. Eurosport), you can select the dubbed or the
original language, pressing the   button.
 When the stereo broadcast is received poorly, you can
change from stereo to mono sound so that you can hear
the broadcast more clearly and easily.
Information on Screen
First pressing the   button displays the current status
Programme number, Stat on name and Sound sta-
tus.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:0012

ENGLISH - 13 -
Pressing this button again displays the current time.
Pressing this button once more remove the on-screen dis-
play.
To Display the Time
 While watching a V programme with eletext transmission
press   button twice. he current time information, cap-
tured from eletext will be displayed at the upper left corner
of the screen.
 If the programme being watched does not have eletext
transmission, no time information will be displayed.
 he time information will disappear after pressing   but-
ton again.
You can change P cture Mode settings by pressing PIC-
TURE button when no menu appears.
VC / DVD Control Buttons and VC / / DVD
Switch
he buttons can be used to operate a JVC brand VCR or
DVD player. Pressing the button having the same appear-
ance as the original remote control button of a device makes
the function work in the same way as the original remote
control.
1. Set the VCR / / DVD Switch to the VCR or DVD posi-
tion.
VCR:
When you are operating the VCR, set the switch to the VCR
position.
DVD:
When you are operating the DVD player, set the switch to
the DVD position.
(Text):
When you are viewing eletext programmes, set the switch
to the ( ext) position.
2. Press the VCR / DVD Control Button to control your VCR
or DVD player.
Note:
 If your device is not made by JVC, these buttons cannot be
used.
 Even if your device is made by JVC, some of these buttons
or any one of the buttons may not work, depending on the
device.
 You can use the / buttons to choose a V channel
which the VCR will receive or choose the chapter which the
DVD player plays back.
 Some DVD player models use the / buttons for oper-
ating of Fast forward/backward functions and choosing the
chapter. In this case, the / the buttons do not
work.
Teletext
eletext is an information system that displays text on your
V screen. Using the eletext information system you can
view a page of information on a subject that is available in the
list of contents (index).
No on screen display will be available in text mode.
No contrast, brightness or colour control, but volume control
is available in text mode.
To operate Teletext
 Select a V station on which eletext is being transmitted.
 Press (teletext)   button. Usually the list of contents (in-
dex) is displayed on the screen.
 Set the VCR / / DVD switch to the ( ext) position.
To select a page of Teletext
 Press the appropriate digit buttons for the required eletext
page number.
he selected page number is displayed at the top left corner
of the screen. he eletext page counter searches until the
selected page number is located, so that the desired page is
displayed on the screen.
 Press   button to move the eletext screen forward
one page at a time.
 Press   button to move the eletext screen backward
one page at a time.
To Select Index Page
 o select the page number of the index (generally page
100), press   button.
Searching for a teletext page while watching TV
 In the eletext mode pressing   button will switch the
screen to the V mode. In the V mode enter a page num-
ber using digit buttons. As you enter last digit of page num-
ber,   sign will replace the page number and flash until
the entered page number is found. hen the page number
will replace   sign again. Now you can display this tele-
text page pressing   button.
To Select Double Height Text
 Press   button for the top half of the information page to
be displayed in double height text.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:0013

ENGLISH - 14 -
 Press   button again for the bottom half of the informa-
tion page to be displayed in double height text.
 Press   button once more for the full page of normal
height text.
To eveal concealed Information
 Pressing   button once will reveal answers on a quiz or
games page.
 Pressing   button again will conceal the revealed an-
swers.
To Stop Automatic Page Change
he teletext page you have selected may contain more infor-
mation than what is on the screen; the rest of the information
will be displayed after a period of time.
 Press   button to stop the automatic page change.
 Press   button again to allow the next page to be dis-
played.
To Select a Subcode Page
Subcode pages are subsections of long eletext pages that
can only be displayed on the screen one section at a time.
 Select the required eletext page.
 Press   button.
 Select the required subcode page number by pressing four
digit buttons (e.g. 0001).
 If the selected subcode page is not displayed in a short
time, press   button. V programme will be displayed on
the screen.
 eletext page number will be displayed on the upper left
corner of the screen when the selected page is found.
 Press   button to display the selected eletext page.
To exit Teletext
 Press   button. he screen will switch to V mode.
Fastext and Toptext
eletext mode will be selected according to transmission au-
tomatically.
Your C V supports the 7 page eletext system. When the
page number of any of the 7 pages in memory is entered, the
system will not search for the requested page; instead it will
display the page automatically.
 Press   button to move the eletext screen forward
one page at a time.
 Press   button to move the eletext screen backward
one page at a time.
For Fastext and Toptext
he subject-heading for the information may have a particular
colour or can be in a form located in a coloured box.
 Press an appropriate RED, GREEN, YELLOW or BLUE but-
ton in order to reach the relevant page quickly.
For TOPTEXT
If optext transmission is present, colour coded buttons will
appear in status row.
If optext transmission is not present, status row will not ap-
pear.
In optext mode the   or   commands will request
the next or previous page respectively. If optext transmis-
sion is not available, in case of operation of these com-
mands, wraparound occurs. For example page 100 appears
to be one greater than page 199.
Connect the External Equipments
Via the Euroconnector
Your V set has three Euroconnector sockets. If you want to
connect equipments (e.g. video recorder, decoder, etc.)
which have Euroconnectors, to your V, use the EXT.1
(EXT-1), EXT.2 (EXT-2) or EXT.3 (EXT-3) terminals.
If an external device is connected via Euroconnector sockets
V is switched to AV mode automatically.
T-V LINK compatible VC
Be sure to connect the -V LINK compatible VCR to the
EXT.1 terminal. If not, the -V LINK function will not work
properly.
 When connecting a -V LINK compatible VCR to the EX .1
terminal, be sure to connect the decoder to the VCR. If not,
the T-V LINK function may not work properly. And then set
the DECODER(EXT-2) function for the channel to ON to un-
scramble a scrambled channel. For details, see Us ng the
Decoder (EXT-2) funct on on page 11.
GB mode
If an equipment can output the RGB signals, connect it to
the EXT.1 (EXT-1) terminal.
EXT-2S Mode
If the equipment connected to your V set supports S-Video
(Y/C) output from Euroconnector, you can have a better pic-
ture quality by selecting EXT-2S mode and connecting your
equipment to the EXT.2 (EXT-2S) terminal of V. See your
equipment's booklet to check if your equipment has such
feature.
Via the CA jacks
If you have an equipment (such as a Camcorder) which has
the RCA jacks, connect it to the Front AV (EXT-4) terminal
with the video and audio cables.
Via the ANT (aerial) socket
If your equipment does not have an Euroconnector or RCA
jacks, connect it to the V with an aerial cable. For details,
see the manual provided with the equipment.
 o store the test signal that comes from the equipment,
see INSTALL Menu on page 10 and store it to the pro-
gramme number 0. You can watch images from that equip-
ment to select the programme number which you stored the
test signal.
TV and Video ecoder (VC )
 Connect the Video Recorder to the AN (antenna input)
socket of the V with the aerial cable.
 Connect the Video Recorder to the EXT.1 (EXT-1), EXT.2
(EXT-2) or EXT.3 (EXT-3) terminal with the SCAR cable, or
connect it to the Front AV (EXT-4) terminal with the audio
and video cables.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:0014

ENGLISH - 15 -
Connect the External Equipments
Before connecting anything
 Switch off all equipments including the V.
 Read the manuals provided with the equipments.
To select an AV mode
Pressing AV button on the remote control selects one of six AV modes (EXT-1, RGB, EXT-2, EXT-2S, EXT-3 or EXT-4)
 o return to the TV mode, repeatedly press AV button.
EXT.1 (EXT-1) term nal: Euroconnector (21-pin, SCAR )
 Video input, Audio L/R inputs and RGB inputs are available.
 V broadcast outputs (Video and Audio L/R) are available.
EXT.2 (EXT-2) term nal: Euroconnector (21-pin, SCAR )
 Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
 Video and Audio L/R outputs are available. (See Sett ng External Source Output on page 10.)
 -V LINK functions are available. (See T-V LINK compat ble VCR on page 14.)
EXT.3 (EXT-3) term nal: Euroconnector (21-pin, SCAR )
 V broadcast outputs (Video and Audio L/R) are available.
Front AV (EXT-4) term nal: RCA connectors x 3
 Video input and Audio L/R inputs are available.
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:0015

ENGLISH - 16 -
NTSC Playback
Connect a N SC video recorder to a terminal. hen press
AV button to select the corresponding AV mode.
NTSC 3.58/4.43 system is detected automatically in AV
mode.
Copy Facility
You can output the video and audio signals which inputs from
TV, EXT.1 (EXT-1) or EXT.3 (EXT-3) terminal to the video re-
corder connected to the EXT.2 (EXT-2) terminal.
 o select the output source, see Sett ng External Source
Output on page 10.
Connecting Headphones
Use the stereo headphone socket of your V, to connect
headphones.
Tips
Care of the Screen
Clean the screen with a slightly damp, soft cloth. Do not use
abrasive solvents as they may damage the V screen coat-
ing layer.
Poor Picture
Have you selected the correct V system? Is your V set or
house aerial located too close to the loudspeakers, non-
earthed audio equipment or neon lights, etc. ?
Mountains or high buildings can cause double pictures or
ghost images. Sometimes you can improve the picture quali-
ty by changing the direction of the aerial.
he picture quality may degrade when two peripherals are
connected to the V at the same time. In such a case, dis-
connect one of the peripherals.
No Picture
Is the aerial connected properly? Are the plugs connected
tightly to the aerial socket? Is the aerial cable damaged? Are
suitable plugs used to connect the aerial? If you are in doubt,
consult your dealer.
No P cture means that your V is not receiving any trans-
mission. Have you pressed the correct keys on the remote
control? ry once more.
Sound
Sound is coming from only one of the speakers. Is the bal-
ance set to one direction extreme? See SOUND menu.
emote Control
Your V no longer responds to the remote control. Perhaps
the batteries are exhausted. If so you can still use the local
buttons at the right side of your V.
Have you selected the wrong menu? Press PICTURE but-
ton to return to V mode or press MENU button to return to
the previous menu.
No solution
Switch your V set off and on. If this does not work, call the
service personnel; never attempt to repair it yourself.
Specifications
TV BROADCASTING
PAL I
RECEIVING CHANNELS
VHF (BANDI/III)
UHF (BAND U)
HYPERBAND
CABLE- V (S01-S41)
NUMBER OF PRESET CHANNELS
100
CHANNEL INDICATOR
ON SCREEN DISPLAY
RF AERIAL INPUT
75 Ohm Unbalanced
OPERATING VOLTAGE
220-240V AC, 50 Hz.
SOUND-MULTIPLEX SYSTEMS
Nicam Stereo
PICTURE TUBE
28 16:9
AUDIO OUTPUT POWER (WRMS.) (%10 THD)
2 x 10
POWER CONSUMPTION (W) (max)
145 Watt
DIMENSIONS (WxHxD) (mm)
: + ' :HLJKWNJ
   
',0(16,216
ENG-2826W-AK45-1512UK-16-9-BSI-(AV-28F3SJ)-50056683.p65 15.09.2004, 11:0016
