SERVICE MANUAL
Regarding service information other than these sections, refer to the service manual No. 82963 (HR-V200EZ,HR-V205EK,HR-
V500EZ,HR-V505EK,HR-V505EZ). Also, be sure to note important safety precautions provided in the service manual.
Specifications shown are for SP mode unless specified otherwise.
E. & O.E. Design and specifications subject to change without
notice.
GENERAL
Power : 200 V – 240 V d , 50 Hz/60 Hz
Power consumption
Power on : Approx. 12 W
Standby mode : 3.0 W
Video Head system
HR-V505/V506/
V507E : DA4 (Double Azimuth) head helical
scan system
HR-V205/V206E : Rotary two-head helical scan system
Tape speed
(SP) : 23.39 mm/sec
(LP)* : 11.69 mm/sec
* HR-V505/V506/V507E only
* HR-V505/V506/V507E only
Tape format : Tape width 1/2"
(12.7 mm high density VHS tape)
Maximum recording time
(SP) : 240 min. with E-240 video cassette
(LP)* : 480 min. with E-240 video cassette
Rewind time : Approx. 180 sec. with E-180 cassette
Dimensions (W x H x D) : 360 mm x 94.5 mm x 270 mm
Weight : 4.0 kg
Operating temperature : 5°C to 35°C
Operating humidity : Less than 80 %
Timer : 24 hours display type
VIDEO
Signal system : PAL-type colour signal and CCIR
monochrome signal, 625 lines
50 fields
Recording Format : PAL/MESECAM
RF reception : PAL (B/G)/SECAM (B/G)
RF OUT : PAL G
RF modulator : UHF channels 22 – 68 (Adjustable)
Input level : VIDEO IN (SCART type)
1.0 Vp-p, 75 ohm, unbalanced
Output level : VIDEO OUT (SCART type)
1.0 Vp-p, 75 ohm, unbalanced
Signal-to-noise ratio : More than 43 dBm
AUDIO
Input level : AUDIO IN (SCART type)
–6.0 dBm, more than 10 kΩ
Output level
HR-V505/V506/
V507E : AUDIO OUT (SCART, RCA type)
–6.0 dBm, less than 1 kΩ
HR-V205/V206E : AUDIO OUT (SCART type)
–6.0 dBm, less than 1 kΩ
Audio track
HR-V505/V506/
V507E : Mono track and Hi-Fi track
HR-V205/V206E : Mono track
Audio frequency response
Normal audio : 100 Hz to 10,000 Hz
(–6/+3 dBm)
Hi-Fi audio* : 20 Hz to 20,000 Hz
(–3/+3 dBm)
Audio signal to noise ratio [HR-V505/V506/V507E only]
Hi-Fi audio : More than 70 dB (JIS A filter)
Audio dynamic range [HR-V505/V506/V507E only]
Hi-Fi audio : More than 85 dB (JIS A filter)
ACCESSORIES
Provided accessories : RF cable,
Infrared remote control unit,
“CR 2032” battery x 1
* HR-V505/V506/V507E only
No.82965
2003/05
HR-V205EF, HR-V206EL,
HR-V206E X , HR-V206E Y , HR-V505EF
HR-V205EF, HR-V206EL, HR-V206EX, HR-V206EY, HR-V505EF, V16A1,D1-
VIDEO CASSETTE RECORDER
SPECIFICATIONS (The specifications shown pertain specifically to the model HR-V205E, HR-V206E, HR-V505E, HR-V506E and HR-V507E.)

1
The following table indicate main different points between models HR-V200EZ,HR-V205EF,HR-V206EL,HR-V206EX,HR-
206EY,and HR-V505EF.
TABLE OF CONTENTSTABLE OF CONTENTS
TABLE OF CONTENTSTABLE OF CONTENTS
TABLE OF CONTENTS
DIFFERENT LIST .............................................................................................................................................................................................. 1
REPLACEMENT PARTS LIST
5.1 EXPLODED VIEW .................................................................................................................................................................................... 5-1
5.1.1 PACKING AND ACCESSORY ASSEMBLY <M1> ............................................................................................................................. 5-1
5.1.2 FINALASSEMBLY <M2> ................................................................................................................................................................... 5-2
5.1.3 MECHANISM ASSEMBLY <M4> ....................................................................................................................................................... 5-3
5.2 PARTS LIST.............................................................................................................................................................................................. 5-4
PACKING AND ACCESSORY PARTS LIST<M1> ...................................................................................................................................... 5-4
FINAL PARTS LIST<M2>............................................................................................................................................................................ 5-4
MECHANISM PARTS LIST<M4>................................................................................................................................................................ 5-4
MAIN BOARD ASSEMBLY<03> ................................................................................................................................................................. 5-5
DIFFERENT LISTDIFFERENT LIST
DIFFERENT LISTDIFFERENT LIST
DIFFERENT LIST
DIFFERENT TABLE OF FEATUREDIFFERENT TABLE OF FEATURE
DIFFERENT TABLE OF FEATUREDIFFERENT TABLE OF FEATURE
DIFFERENT TABLE OF FEATURE
Notes: Mark is same as left.
MODEL HR-V200EZ
ITEM
BROADCASTING STANDARD PAL B/G,D/K PAL B/G, SECAM L PAL B/G PAL B/G,SECAM L
AUDIO MONO HiFi
VIDEO HEAD 2 4
TAPE SPEED SP SP/LP
SHOWVIEW/VIDEOplus+ NOT USED SHOWVIEW
FRAME ADVANCE NOT USED USED
SLOW(FORWARD) NOT USED USED
DIGITAL SHUTTLE NOT USED USED
HiFi AUDIO OUT(RCA) NOT USED USED
AV2 CONNECTOR NOT USED USED
HR-V206ELHR-V205EF HR-V206EYHR-V206EX HR-V505EF

VICTOR COMPANY OF JAPAN, LIMITED
12,3-chome,Moriya-cho,Kanagawa-ku,Yokohama,Kanagawa-prefecture,221-8528,JapanAV & MULTIMEDIA COMPANY.
Printed in Japan
0305 VP

5-1
SECTION 5
REPLACEMENT PARTS LIST
SAFETY PRECAUTION
Parts identified by the !symbol are critical for safety. Replace only with specified part numbers.
BEWARE OF BOGUS PARTS
Parts that do not meet specifications may cause trouble in regard to safety and performance. We recom-
mend that genuine JVC parts be used.
5.1.1 PACKING AND ACCESSORY ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.
5.1 EXPLODED VIEW
OPTIONAL PARTS
CABLE SET ASS'Y
(Optional parts)
810
BATTERY808
806
PLUG ASS'Y 2WAY
(Optional parts)
812
PLUG ASS'Y 1WAY
(Optional parts)
811
REMOCON900
PACKING (RF)803
PACKING (LF)803
BOX CARTON802
BAG. SOFR SHEET804
INSTRUCTION MANUAL801
NOTE) Refer to “SECTION REPLACEMENT PARTS LIST
NOTE) in order to look for the part number of each part.

5-2
5.1.2 FINAL ASSEMBLY <M2>
A46
260
452
330
323
TU701(TUNER)
2SCART
1SCART
457
320
452
A00
275
LED502(LED501)
457
457
A43
283
280
284
277
A42
A49
281
300
250
462
462
NOTE) Refer to “SECTION 5 REPLACEMENT
PARTS LIST” in order to look for the
part number of each part.
OPTIONAL PARTS

5-3
5.1.3 MECHANISM ASSEMBLY <M4>
401
402
001
008
011
031
079
017
032 024 406
020
021
028
019 018
029
030
026
A03 A04
A01
002
002A
025
027
022
003
004
006
007
010
405
014
015
009
409
013
023 016
405
012
402
OPTIONAL PART
A22
109
054
054A
117
103
105 117
100
106
107 A21
114
113
112
110
115
A24
116
102
A23
100A
100B
051
052
517
061
056
058
518 052A
055
060
410
070
069
076
032
077
068
064
066
065
067
A11
078
A12
OPTIONAL PART
[TOP VIEW]
[BOTTOM VIEW]

#REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP #REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP
5-4
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
******************************
PACKING AND ACCESSORY PARTS LIST <M1>
801 LG-3835RP0095K INSTRUCTION ASSEMBLY VCR FCJ209P.NA8SJJB B
801 LG-3835RP0095T INSTRUCTION ASSEMBLY VCR FCJ904NS.NA3FJJS A E
801 LG-3835RP0095W INSTRUCTION ASSEMBLY VCR FCJ909NP.NA3GJJS C
801 LG-3835RP0096B INSTRUCTION ASSEMBLY VCR FCJ909NP.NA8SJJS D
802 LG-3890R-H784S BOX FCJ909NP NA3GJJG SW3-A 0.849 1 ABCDE
803 LG-3920R-0067A PACKING AF999NS 0.02 65 EPS 12 1190 23 ABCDE
804 LG-292-053A BAG SOFT(VCP) A E NSP
804 LG-3880R-H001A BAG HDPE 500 500 0.03 VCR MIDI BCD NSP
808 QAB0022-001 BATTERY,LITHIUM CR2032 PANASONIC PANASONIC 3.0 ABCDE
810 LG-6851R-0012B CABLEASSEMBLY RF-CABLE DOUBLE SHIELD PAL LGE ABCDE
900 LG-6711R2P041A REMOTE CONTROLLER ASSEMBLY JVC FCJ909NP LP21138-006 W/SHO A E
900 LG-6711R2P041C REMOTE CONTROLLER ASSEMBLY JVC FCJ909NP LP21138-007 W/SHO BCD
******************************
FINAL PARTS LIST <M2>
A43 LG-3721R-F313B PANELASSEMBLY,FRONT VCR FCJ204S NA3FJJS HR-V205 A
A43 LG-3721R-F313E PANELASSEMBLY,FRONT VCR FCJ209P NA3GJJB BK BCD
A43 LG-3721R-F313G PANELASSEMBLY,FRONT VCR FCJ904NS NA3FJJS E
A46 LG-3501R-7803J BOARD ASSEMBLY VCR JVC PAL SCART E
A46 LG-3501R-7803L BOARD ASSEMBLY VCR JVC PAL SCART C
A46 LG-3501R-7803M BOARDASSEMBLY VCR JVC PAL SCART B
A46 LG-3501R-7803N BOARD ASSEMBLY VCR JVC PAL SCART D
A46 LG-3501R-7803T BOARD ASSEMBLY VCR JVC PAL SCART A
250 LG-3110R-0128C CASE TOP(Q280G:B/K),SIDE BCDE
250 LG-3110R-0223G CASE VCR - TOP(0128A288G SIDE SCRE A
260 LG-3210R-0023B FRAME MAIN (VII-PJT, 60HR) BCD NSP
260 LG-3210R-0023F FRAME VCR - MAIN (VII-PJT, 60HR,8657 A E NSP
280 LG-3720R-F702A PANEL,FRONT FRONT(JVC EVNT) A E NSP
280 LG-3720R-F702B PANEL,FRONT VCR FCJ209P NA3GJJB OTHER BK BCD NSP
283 LG-3580R-V031A DOOR,CASE VCR - CST (VCR) (MONO-B589G-SI A
283 LG-3580R-V031B DOOR,CASE VCR - CST (VCR) (MONO-Q280G-B. BCD
283 LG-3580R-V031C DOOR,CASE VCR - CST (VCR) (HIFI-B589G-SI E
284 LG-442-681A SPRING DOOR ABCD
284 LG-442-681A SPRING DOOR E
300 LG-6410RCHP02Z POWER CORD HIT-102/H03VHH2-F (ST-HS:80MM) ABCDE
320 LG-3720R-D020B PANEL DISTRIBUTOR (PAL-SCART MONO) ABCD
320 LG-3720R-D020C PANEL VCR - DISTRIBUTOR (PAL-2SCART E
330 LG-3550R-0210A COVER BOTTOM(LARGE) ABCDE
452 LG-353-051A SCREW SPECIAL ABCDE
457 LG-353-051E SCREW SPECIAL (3X12) ABCDE
462 LG-353-136A SCREW SPECIAL(FBK) (353S353A) BCD
462 LG-353-136D SCREW,DRAWING + 2 D4.0 L12.5 MSWR3/FN A E
******************************
MECHANISM PARTS LIST <M4>
A00 LG-6721RF0700D DECK ASSEMBLY,VIDEO D35(N) DI(2HD, SP ONLY, NP, AH ABCD NSP
A00 LG-6721RF0750D DECK ASSEMBLY,VIDEO D35(N) DI (4HF, PAL, AHC(X), B E NSP
A01 LG-6723R-0401A DRUM(CIRC) ASSEMBLY D35-2CH SP ONLY (8P2) ABCD
A01 LG-6723R-0403C DRUM(CIRC) ASSEMBLY D35-6CH PAL (8P6C) E
A04 LG-4811RF0038A BRACKETASSEMBLY L/D(S) ABCDE
A11 LG-4471R-0005A GEAR ASSY P3 ABCDE
A12 LG-4471R-0004A GEAR ASSY P2 ABCDE
A21 LG-4931R-0047A HOLDER ASSY CST ABCDE
A22 LG-4471R-0006A GEAR ASSY RACK F/L ABCDE
A23 LG-4261R-0023A ARM ASSY F/L ABCDE
A24 LG-4510R-0046A LEVER ASSY SWITCH ABCDE
001 LG-6723R-0304A DRUM(CIRC)ASSEMBLY SUB D35-2CH (8P2) ABCD NSP
001 LG-6723R-0306C DRUM(CIRC)ASSEMBLY SUB D35-6CH (8P6C) E NSP
002 LG-4680R-B005A MOTOR(MECH) DRUM I2OAL05 SEJIN-SANKYO ICLE ABCDE
002A LG-5202R00002C BRUSH,CARBON ASSY D33 (TIP+2 SPRING) 1.4, ABCDE
003 LG-4930R-0284A HOLDER FPC(6CH) E
003 LG-4930R-0286A HOLDER FPCB(2CH) ABCD
004 LG-5006R-0034A CAP FPC ABCDE
008 LG-6850R-HG18Z CABLE,FLAT P=1.25 FFC UL2896(0.05X0.8) 7 ABCDE
009 LG-4260R-0038A ARM T/UP(D35) ABCDE
010 LG-4810R-0125A BRACKET CHASSIS ABCDE
011 LG-4261R-0022A ARM ASSY TENSION(D35) ABCDE
012 LG-3041R-0037A BASE ASSY P2 ABCDE
013 LG-3041R-0038A BASE ASSY P3 ABCDE
014 LG-3041R-0039A BASE ASSY P4 ABCDE
015 LG-5870R-0005A OPENER LID(D35) ABCDE
016 LG-3041R-0036A BASEASSEMBLY A/C HEAD (ALPS) ABCDE
017 LG-4408R-0003A REEL S ABCDE
018 LG-4970R-0140A SPRING COIL RS D35 ABCDE
019 LG-4421R-0008A BRAKE ASSEMBLY RS E
020 LG-4970R-0128A SPRING COIL D35 (TB) ABCDE
021 LG-4421R-0006A BRAKE ASSY T ABCDE
022 LG-6520D00002A HEAD(CIRC) D35 FE ST FE HEAD ABCDE
023 LG-3040R-0057A BASE LOADING ABCDE
024 LG-4261R-0029A ARM ASSEMBLY IDLER (N) ABCDE
025 LG-4810R-0118A BRACKET L/D(S) ABCDE NSP
026 LG-4680R-D002A MOTOR(MECH) LOADING MDB2B66 SANKYO D35 ASP ABCDE NSP
027 LG-4470R-0093A GEAR WHEEL ABCDE NSP
028 LG-4408R-0004A REEL T ABCDE
029 LG-4261R-0019C ARM ASSEMBLY DECK/MECHA PINCH ABCDE
030 LG-4510R-0043A LEVER T/UP ABCDE
031 LG-4970R-0123A SPRING COIL TENSION(D35) ABCDE
032 LG-3141R-0040A CHASSIS ASSY D35 ABCDE NSP
051 LG-4400R-0005A BELT CAPSTAN ABCDE
052 LG-4680R-A007A MOTOR(MECH) CAPSTAN F2QVB06 SANKYO D35 ASR ABCDE
052A LG-4980R-0023A SUPPORTER CAPSTAN(D35) ABCDE
054 LG-4470R-0100A GEAR RACK F/L ABCDE
054A LG-4970R-0124B SPRING COIL D35 (RACK F/L) ABCDE
055 LG-4470R-0097A GEAR DRIVE(D35) ABCDE
056 LG-4470R-0096A GEAR CAM(D35) ABCDE
058 LG-4421R-0007A BRAKE ASSY CAPSTAN ABCDE
060 LG-4510R-0040A LEVER F/R(D35) ABCDE
061 LG-4265R-0006A CLUTCH ASSEMBLY D35 (N) ABCDE
064 LG-4470R-0098A GEAR SECTOR(D35) ABCDE
065 LG-4261R-0021A ARM ASSY P3 ABCDE NSP
066 LG-4970R-0122A SPRING COIL D35 ABCDE NSP
067 LG-4470R-0095A GEAR P3 ABCDE NSP
068 LG-4470R-0094A GEAR P2 ABCDE NSP
069 LG-4970R-0122A SPRING COIL D35 ABCDE NSP
070 LG-4261R-0020A ARM ASSY P2 ABCDE NSP
076 LG-4510R-0047A LEVER SPRING ABCDE
077 LG-3300R-M116A PLATE SLIDER ABCDE
078 LG-4510R-0041A LEVER TENSION ABCDE
079 LG-3040R-0056A BASE TENSION(D35) ABCDE
100 LG-3301R-M022A PLATE ASSEMBLY TOP ABCDE
100A LG-3300R-0184A PLATE GND ABCDE
100B LG-3300R-M118A PLATE TOP(D35) ABCDE
102 LG-4970R-0130A SPRING COIL D35 (STOPPER) ABCDE
103 LG-4930R-0276A HOLDER SIDE(L) ABCDE NSP
105 LG-4930R-0274A HOLDER CST ABCDE NSP
106 LG-4930R-0275A HOLDER SIDE(R) ABCDE NSP
107 LG-4510R-0044A LEVER STOPPER ABCDE NSP
109 LG-5870R-0004A OPENER DOOR ABCDE
110 LG-4260R-0035A ARM F/L(L) ABCDE NSP
112 LG-3070R-0002A BODY F/L ABCDE NSP
113 LG-4970R-0127A SPRING COIL D35 (F/L(R)) ABCDE NSP
114 LG-4260R-0036A ARM F/L(R) ABCDE NSP
115 LG-4510R-0042A LEVER SWITCH ABCDE
116 LG-4970R-0138A SPRING COIL D35 SWITCH ABCDE
117 LG-3300R-M137A PLATE SPRING CST ABCDE
401 LG-1MEC0261518 SCREW MACHINE,PAN HEAD SPR W D2.6 L4.5 MSWR3/FZY ABCDE
402 LG-1MPC0261418 SCREW MACHINE,PAN HEAD D 2.6 L 4.0 MSWR3/FZY ABCDE
405 LG-1SZZR-0031B SCREW,DRAWING + 1 D2.6 L5.8 SWRCH16A/FZYTAP ABCDE
406 LG-1MEC0302018 PAN HEAD MACHINE SCREW S/W + D 3.0 L 6.0 MSWR3/FZY ABCDE
409 LG-1SZZR-0032B SCREW,DRAWING + 1 D2.6 L5.0 SWRCH18A/FZYTAP ABCDE
410 LG-1APF0262218 SCREW TAP TITE(B),PAN HEAD D2.6 L6.8 MSWR3/FZY ABCDE
517 LG-1WZZR-0004D WASHER STOPPER ABCDE
518 LG-1WZZR-0004A WASHER STOPPER ABCDE
MODEL MARK MODEL MARK MODEL MARK
HR-V205EF A HR-V206EL B HR-V206EX C
HR-V206EY D HR-V505EF E
5.2 REPLACEMENT PARTS LIST NSP:Not Service Parts

#REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP #REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP
5-5
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
******************************
MAIN BOARD ASSEMBLY <03>
IC101 LG-0IPMGSK003A IC,POWER MANAGEMENT STR-A6351 SANKEN 8 DIP ST SMPS ABCDE
IC102 PZ0ILI817000B SENSOR LTV-817B,PHOTO COUPLER(LITEON) ABCDE
IC103 LG-0IKE431000A IC,KEC KIA431 3 PIN TP ABCDE
IC201 LG-0ILNRSA007A IC,LINEAR LA70100M SANYO 30 SOP ST SECAM A E
IC301 LG-0ILNRSA005B IC,LINEAR LA71750EM SANYO 100PIN QFP TRA ABCDE
IC501 LG-0IMCRHI027A IC,MICRO CONTROLLER HD64322197SA19F HITACHI 112PIN ABCDE
IC503 LG-0IAL241600B IC,ATMEL AT24C16 - - - - ABCD
IC503 LG-0ICS241600B IC,CATALYST CAT24W16P 8P DIP ST 16K SERIAL E
IC504 LG-0IKE703100A IC,KEC KIA7031P 3P 3.1V RESET(TAPING) ABCDE
IC505 LG-0IKE704200B IC,KEC KIA7042P 3P 4.2V RESET(TAPING) ABCDE
IC506 LG-0ILNRPY001A IC,LINEAR PT6955 PTC 24P SOP ST LED DRIV ABCDE
IC751 LG-0IIT341700B IC,ITT MSP3417D-QG QFP44 BK NICAM+A2 E
IC7V1 LG-0ILNRMN001A IC,LINEAR SDA5650 MICRONAS 14 DIP ST VPS BCD
IC801 LG-0IPH960500A IC,PHILIPS TDA9605H QFP44 BK HIFI AMP+HIF E
IC901 MM1231XF-X IC,PERIPHERALS MM1231XF MITSUMI 16PIN SOP ST ABCD
D102 LG-0DD010009CA DIODE,RECTIFIER EG01CW(R-FORM 5MM) TP SANKEN ABCDE
D103 LG-0DR180209AA DIODE,RECTIFIER ERA18-02KFRB TP FUJI DO204AL 2 ABCDE
D104 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D105 LG-0DR104009BA DIODE,RECTIFIER RL104F TP RECTRON NON 400V 1A ABCDE
D106 LG-0DR158220AA DIODE,RECTIFIER 1N5822 BK RECTRON DO201AD 40V ABCDE
D109 LG-0DR202000AB DIODE,RECTIFIER HER202 BK RECTRON NON 100V 2A ABCDE
D155 2A02DIODE,RECTIFIERS 2A07 2A RECT(T/S)P=12.5 F DELT ABCDE
D156 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D159 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D160 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D301 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D502 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D509 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D901 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D902 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D903 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D9M1 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
D9M2 1SS133-T2 DIODE,SWITCHING 1SS133 DETECT,SW TP ABCDE
Q151 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABCDE
Q152 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABCDE
Q154 LG-0TR126809BA TRANSISTOR,BIPOLARS KTA1268-BL TP KEC ABCDE
Q155 LG-0TR320509AB TRANSISTOR KTC3205-TP-Y (KTC2236A)KEC ABCDE
Q157 LG-0TR120309AE TRANSISTOR SRC1203 TPAUK TO92 22K,22K ABCDE
Q162 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q163 LG-0TR120109AC TRANSISTOR SRC1201 TPAUK TO92 4.7K,4.7K ABCDE
Q164 LG-0TR120309AE TRANSISTOR SRC1203 TPAUK TO92 22K,22K ABCDE
Q165 LG-0TR220309AF TRANSISTOR SRA2203 TP AUK TO92 22K,22K ABCDE
Q166 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABCDE
Q301 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q302 LG-0TR198009CA TRANSISTOR 2SA1980G TPAUK TO92 ABCDE
Q303 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q304 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q305 LG-0TR198009CA TRANSISTOR 2SA1980G TPAUK TO92 ABCDE
Q306 LG-0TR534409AA TRANSISTOR 2SC5344Y TP ABCDE
Q307 LG-0TR198009CA TRANSISTOR 2SA1980G TPAUK TO92 ABCDE
Q308 LG-0TR198009CA TRANSISTOR 2SA1980G TPAUK TO92 ABCDE
Q309 LG-0TR198009CA TRANSISTOR 2SA1980G TPAUK TO92 ABCDE
Q501 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q502 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q503 LG-0TR127309AA TRANSISTOR KTA1273-TP-Y (KTA966A)KEC ABCDE
Q504 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q514 LG-0TR120309AE TRANSISTOR SRC1203 TPAUK TO92 22K,22K ABCDE
Q515 LG-0TR120309AE TRANSISTOR SRC1203 TPAUK TO92 22K,22K ABCDE
Q5S1 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q7S1 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 A E
Q901 LG-0TR120309AE TRANSISTOR SRC1203 TPAUK TO92 22K,22K ABCDE
Q902 LG-0TR220309AF TRANSISTOR SRA2203 TP AUK TO92 22K,22K ABCDE
Q903 LG-0TR120309AE TRANSISTOR SRC1203 TPAUK TO92 22K,22K ABCDE
Q906 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q9M1 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
Q9M2 LG-0TR534309BA TRANSISTOR 2SC5343-L TPAUK TO92 ABCDE
C101 LG-624-088L CAPACITOR,DRAWING 435D SUNIL ELECTRONICS 0.1UF/2 ABCDE
C102 LG-624-088L CAPACITOR,DRAWING 435D SUNIL ELECTRONICS 0.1UF/2 ABCDE
C103 LG-0CE476CU611 CAPACITOR,AL.ELECTROLYTIC 47UF SHL,SD 400V M FL BK7.5 ABCDE
C105 LG-0CQ1031Y519 CAPACITOR,POLYESTER 0.01UF D 630V K PE NI TP ABCDE
C106 LG-624-087B CAPACITOR HIGH-VOL 100P/1KV SMPS SAMHWA ABCDE
C109 QETC1HM-106Z CAPACITOR,FIXED ELECTROLYTIC 10M SRA50V M FM5 TP(5) ABCDE
C112 LG-0CG3320U630 CAPACITOR,SEMI CERAMIC 3300 PF 400V M E R(NK,AD,SD) ABCDE
C113 LG-0CG3310U510 CAPACITOR,FIXED CERAMIC(TEMP.C 330PF D 400V 10% B(Y5P) R ABCDE
C114 LG-0CQ4732K409 CAPACITOR,FIXED FILM 0.047UF S 50V J PE TP ABCDE
C115 LG-624-085D CAPACITOR CE 47UF/50V KME (SMPS) ABCDE
C116 LG-0CE108BF630 CAPACITOR,FIXED ELECTROLYTIC 1000UF KME 16V M FM5 BULK ABCDE
C117 LG-624-082H CAPACITOR CE 1000UF/10V SHL(10*12.5)T/P ABCDE
C120 LG-0CE477BH630 CAPACITOR,AL.ELECTROLYTIC 470UF KME TYPE 25V M FM5 BULK ABCDE
C121 LG-0CE227CH618 CAPACITOR,FIXED ELECTROLYTIC 220UF SHL,SD 25V 20% FLTP 5 ABCDE
C127 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABCDE
C135 LG-0CN4710K518 CAPACITOR TUBULA(HIGH DIELE) 470P 50V K B TA26 ABCDE
C153 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C190 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C201 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 A E
C202 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 A E
C203 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) A E
C204 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) A E
C205 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA A E
C206 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 A E
C207 QETL1HM-474 CAPACITOR,ELECTROLYTIC 0.47M SRA 50V M FM5 TP(5) A E
C208 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 A E
C209 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 A E
C210 QETL1HM-474 CAPACITOR,ELECTROLYTIC 0.47M SRA 50V M FM5 TP(5) A E
C211 LG-0CN2220F668 CAPACITOR,TUBULAR(HIGH DIELEC) 2200P 16V M X TA26 A E
C212 LG-0CN2220F668 CAPACITOR,TUBULAR(HIGH DIELEC) 2200P 16V M X TA26 A E
C213 QETC1HM-225Z CAPACITOR,FIXED ELECTROLYTIC 2.2UF SRA,SS 50V 20% FM5 TP 5 A E
C214 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 A E
C215 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) A E
C216 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 A E
C301 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABCDE
C302 QET61CM-226 CAPACITOR,ELECTROLYTIC 22M SRA 16V M FM5 TP(5) ABCDE
C303 LG-0CN1220F668 CAPACITORTUBULA(HIGH DIELE) 1200P 16V M X TA26 ABCDE
C304 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C305 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C306 LG-0CN1220F668 CAPACITORTUBULA(HIGH DIELE) 1200P 16V M X TA26 ABCDE
C307 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C308 LG-0CQ1532K409 CAPACITOR,FIXED FILM 0.015UF S 50V J PE TP ABCDE
C309 LG-0CN1210K518 CAPACITOR TUBULA(HIGH DIELE) 120P 50V K B TA26 ABCDE
C310 LG-0CQ1032K409 CAPACITOR,POLYESTER(MYLAR) 0.01UF S 50V J PE TP ABCDE
C311 LG-0CE4765K618 CAPACITOR,AL.ELECTROLYTIC 47UF SR,SV 50V M FL TP 5 ABCDE
C312 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C313 LG-0CQ2232L559 CAPACITOR,POLYESTER 0.022UF S 63V K PP NI TP5 ABCDE
C314 QET61CM-226 CAPACITOR,ELECTROLYTIC 22M SRA 16V M FM5 TP(5) ABCDE
C315 LG-0CE2253K636 CAPACITOR,FIXED ELECTROLYTIC 2.2UF SRE,SE 50V 20% FM5 BP(D) ABCDE
C316 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C317 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C318 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C319 LG-0CQ1032K409 CAPACITOR,POLYESTER(MYLAR) 0.01UF S 50V J PE TP ABCDE
C320 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C321 LG-0CX6800K408 CAPACITOR TUBULA(T.C) 68P 50V J SL TA26 ABCDE
C322 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C323 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C324 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABCDE
C325 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C326 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C327 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C328 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C329 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C330 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C331 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C333 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C334 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) ABCDE
C335 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C336 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C337 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C338 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) ABCDE
C339 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C340 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) ABCDE
C341 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABCDE
C342 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C343 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) ABCDE
C344 LG-0CN1010K518 CAPACITOR,TUBULAR(HIGH DIELEC) 100P 50V K B TA26 ABCDE
C345 LG-0CN3330K518 CAPACITOR,FIXED TUBULAR(High d 0.033UF 50V K B TA26 ABCDE
C346 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C347 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C348 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C349 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C353 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C355 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C356 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C357 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C358 LG-0CX6800K408 CAPACITOR TUBULA(T.C) 68P 50V J SL TA26 ABCDE
C359 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C360 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C361 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABCDE
C362 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C363 LG-0CN1030F678 CAPACITORTUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C364 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C365 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C366 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C367 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
MODEL MARK MODEL MARK MODEL MARK
HR-V205EF A HR-V206EL B HR-V206EX C
HR-V206EY D HR-V505EF E
NSP:Not Service Parts

#REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP #REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP
5-6
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
C368 LG-0CQ8224K409 CAPACITOR,FIXED FILM 0.0082UF TE 50V 5% PE TP5 ABCDE
C369 LG-0CN1010K518 CAPACITOR,TUBULAR(HIGH DIELEC) 100P 50V K B TA26 ABCDE
C370 LG-0CN8200K418 CAPACITOR TUBULA(HIGH DIELE) 82P 50V J B TA26 ABCDE
C371 LG-0CN8200K418 CAPACITOR TUBULA(HIGH DIELE) 82P 50V J B TA26 ABCDE
C372 LG-0CN8200K418 CAPACITOR TUBULA(HIGH DIELE) 82P 50V J B TA26 ABCDE
C373 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C375 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C500 LG-0CE4775C638 CAPACITOR,FIXED ELECTROLYTIC 470UF SR,SV 6.3V 20% FM5 TP 5 ABCD
C500 LG-624-074A CAPACITOR,DRAWING SUPER CAP 0.047F/5.5V T/P S/S E
C501 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C502 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C503 LG-0CE2274C638 CAPACITOR,ELECTROLYTIC 220M SRA 6.3V M FM5 TP(5) ABCDE
C504 LG-0CE2274C638 CAPACITOR,ELECTROLYTIC 220M SRA 6.3V M FM5 TP(5) ABCDE
C505 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C506 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABCDE
C508 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C509 LG-0CC2200K415 CAPACITOR,CERAMIC(TEMP COMP) 22P 50V J NP0 TS ABCDE
C510 LG-0CE2274C638 CAPACITOR,ELECTROLYTIC 220M SRA 6.3V M FM5 TP(5) ABCDE
C511 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C512 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C513 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C514 LG-0CC1200K415 CAPACITOR,FIXED CERAMIC(TEMP.C 12PF 2012 50V 5% NP0 TR ABCDE
C515 LG-0CC1500K415 CAPACITOR,CERAMIC(TEMP COMP) 15P 50V J NP0 TS ABCDE
C516 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABCDE
C518 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C519 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C520 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C523 QETC1HM-225Z CAPACITOR,FIXED ELECTROLYTIC 2.2UF SRA,SS 50V 20% FM5 TP 5 ABCDE
C524 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C525 LG-0CE2274C638 CAPACITOR,ELECTROLYTIC 220M SRA 6.3V M FM5 TP(5) ABCDE
C526 LG-0CE4764J638 CAPACITOR,AL.ELECTROLYTIC 47UF SRA,SS 35V M FM5 TP 5 ABCDE
C527 LG-0CN2210K518 CAPACITOR TUBULA(HIGH DIELE) 220P 50V K B TA26 ABCDE
C533 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C534 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABCDE
C535 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABCDE
C543 LG-0CN2220F668 CAPACITOR,TUBULAR(HIGH DIELEC) 2200P 16V M X TA26 ABCDE
C544 LG-0CQ4732K409 CAPACITOR,FIXED FILM 0.047UF S 50V J PE TP ABCDE
C545 LG-0CN3330K518 CAPACITOR,FIXED TUBULAR(High d 0.033UF 50V K B TA26 ABCDE
C546 LG-0CE4764J638 CAPACITOR,AL.ELECTROLYTIC 47UF SRA,SS 35V M FM5 TP 5 ABCDE
C547 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C551 LG-0CQ3332K409 CAPACITOR,FIXED FILM 0.033UF S 50V J PE TP ABCDE
C552 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C561 LG-0CE2274C638 CAPACITOR,ELECTROLYTIC 220M SRA 6.3V M FM5 TP(5) ABCDE
C564 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C567 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C570 LG-0CC1500K415 CAPACITOR,CERAMIC(TEMP COMP) 15P 50V J NP0 TS ABCDE
C571 LG-0CC1500K415 CAPACITOR,CERAMIC(TEMP COMP) 15P 50V J NP0 TS ABCDE
C575 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C576 LG-0CC2700K415 CAPACITOR CERAMIC(TEMP COMP) 27P 50V J NP0 TP ABCDE
C577 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABCDE
C578 LG-0CN2220F668 CAPACITOR,TUBULAR(HIGH DIELEC) 2200P 16V M X TA26 ABCDE
C581 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C582 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C583 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C589 LG-0CQ2232K409 CAPACITOR,FIXED FILM 0.022UF S 50V J PE TP ABCDE
C596 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C5A3 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C5A4 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C5A5 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C5G1 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C5G2 LG-0CE1086C638 CAPACITOR,FIXED ELECTROLYTIC 1000000000 PF SMS,SG 6.3V M FM ABCDE
C5G3 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C5K1 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C5R1 QETA1CM-336 CAPACITOR,ELECTROLYTIC 33M SRA 16V M FM5 TP(5) ABCDE
C5R2 LG-0CN6810K518 CAPACITOR TUBULA(HIGH DIELE) 680P 50V K B TA26 ABCDE
C5S1 LG-0CX4300K408 CAPACITOR TUBULA(T.C) 43P 50V J SL TA26 ABCDE
C5S3 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S ABCDE
C701 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABCDE
C703 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) A E
C704 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) ABCDE
C705 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C706 LG-0CE4775C618 CAPACITOR,AL.ELECTROLYTIC 470UF SR,SV 6.3V M FL TP 5 ABCDE
C707 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C710 LG-0CN1210K518 CAPACITOR TUBULA(HIGH DIELE) 120P 50V K B TA26 A E
C710 LG-0CX6800K408 CAPACITOR TUBULA(T.C) 68P 50V J SL TA26 BCD
C711 LG-0CN8200K518 CAPACITOR TUBULA(HIGH DIELE) 82PF 50V K B TA26 A E
C711 LG-0CX3300K408 CAPACITOR TUBULA(T.C) 33P 50V J SL TA26 BCD
C712 LG-0CX5R60K508 CAPACITOR TUBULA(T.C) 5.6PF 50V K SL TA26 ABCDE
C713 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) BCD
C714 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 BCD
C751 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) E
C752 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 E
C753 LG-0CX5600K408 CAPACITOR,TUBULAR(T.C) 56P 50V J SL TA26 E
C754 LG-0CX5600K408 CAPACITOR,TUBULAR(T.C) 56P 50V J SL TA26 E
C755 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) E
C756 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 E
C757 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) E
C758 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C759 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C760 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 E
C761 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 E
C764 LG-0CN3920F668 CAPACITOR TUBULA(HIGH DIELE) 3900P 16V M X TA26 E
C765 LG-0CN1520F668 CAPACITOR,TUBULAR(HIGH DIELEC) 1500P 16V M X TA26 E
C766 QETF1HM-335Z CAPACITOR,FIXED ELECTROLYTIC 3.3UF SRA,SS 50V 20% FM5 TP 5 E
C769 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C770 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C771 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 E
C772 LG-0CC0500K015 CAPACITOR,CERAMIC(TEMP COMP) 5P 50V C NP0 TR E
C773 LG-0CC0800K015 CAPACITOR CERAMIC(TEMP COMP) 8P 50V C NP0 TS E
C790 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 ABCDE
C7M2 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) BCD
C7M6 LG-0CX2700K408 CAPACITOR TUBULA(T.C) 27P 50V J SL TA26 BCD
C7S1 QETA1CM-336 CAPACITOR,ELECTROLYTIC 33M SRA 16V M FM5 TP(5) A E
C7V1 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) BCD
C7V2 LG-0CN223AK948 CAPACITOR,TUBULAR(HIGH DIELEC) 0.022UF 50V Z F TA26 S BCD
C7V3 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) BCD
C7V4 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) BCD
C7V5 LG-0CN4730K948 CAPACITOR,FIXED TUBULAR(High d 0.047UF D 50V 80%,-20% F(Y5V) BCD
C805 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA E
C806 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 E
C807 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 E
C808 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA E
C809 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA E
C810 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C811 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C813 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C814 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C817 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C818 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 E
C819 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C820 LG-0CQ6822K409 CAPACITOR,POLYESTER(MYLAR) 6800PF S 50V J PE TP E
C821 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) E
C822 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C823 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C824 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C825 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) E
C826 LG-0CQ6822K409 CAPACITOR,POLYESTER(MYLAR) 6800PF S 50V J PE TP E
C827 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C828 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) E
C829 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 E
C830 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA E
C831 LG-0CN1030F678 CAPACITOR TUBULA(HIGH DIELE) 0.01M 16V M Y TA26 E
C832 QET61CM-476 CAPACITOR,ELECTROLYTIC 47M SRA/SS 16V M FM5 TP(5) E
C835 QETL1HM-474 CAPACITOR,ELECTROLYTIC 0.47M SRA50V M FM5 TP(5) E
C8R1 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 E
C8R2 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 E
C901 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCD
C902 LG-0CE477CF638 CAPACITOR,AL.ELECTROLYTIC 470UF SHLTYPE 16V M FM5 TP 5 ABCDE
C903 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C904 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C909 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C911 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCD
C912 LG-0CE477CF638 CAPACITOR,AL.ELECTROLYTIC 470UF SHLTYPE 16V M FM5 TP 5 ABCDE
C914 LG-0CN1020K518 CAPACITOR TUBULA(HIGH DIELE) 1000P 50V K B TA26 ABCDE
C915 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C917 LG-0CX2700K408 CAPACITOR TUBULA(T.C) 27P 50V J SL TA26 ABCDE
C920 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C921 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C956 QETC1HM-105Z CAPACITOR,ELECTROLYTIC 1.0M SRA/SS50V M FM5 TP(5) ABCDE
C957 LG-0CX2700K408 CAPACITOR TUBULA(T.C) 27P 50V J SL TA26 ABCDE
C960 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCDE
C961 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCDE
C962 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C963 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) E
C9C1 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABCD
C9C2 LG-0CE4754K638 CAPACITOR,FIXED ELECTROLYTIC 4.7UF SRA,SS 50V 20% FM5 TP 5 ABCD
C9M1 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCD
C9M3 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCD
C9M4 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCD
C9M5 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCD
C9M6 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCD
C9M7 QET61CM-106Z CAPACITOR,ELECTROLYTIC 10M SRA 16V M FM5 TP(5) ABCD
C9M8 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCD
C9M9 LG-0CN1040K948 CAPACITOR,FIXED TUBULAR(High d 0.1UF D 50V 80%,-20% F(Y5V) TA ABCD
R101 LG-614-007A RESISTOR 2.7/2W CEMENT SMPS V ABCDE
R102 QRD161J-184Y RESISTOR,FIXED CARBON FILM 180K OHM 1/6 W 0.05 TA26 ABCDE
R103 LG-0RD0682F608 RESISTOR,FIXED CARBON FILM 68 OHM 1/6 W 5.00% TA26 ABCDE
R104 LG-0RS5602K619 RESISTOR,FIXED METAL OXIDE FIL 56K OHM 2 W 5.00% TR ABCDE
MODEL MARK MODEL MARK MODEL MARK
HR-V205EF A HR-V206EL B HR-V206EX C
HR-V206EY D HR-V505EF E
NSP:Not Service Parts

#REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP #REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP
5-7
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
R105 LG-0RF0101A619 RESISTOR,DRAWING 1 OHM 1/2 W(7.0) 5.00% TR ABCDE
R106 QRD161J-184Y RESISTOR,FIXED CARBON FILM 180K OHM 1/6 W 0.05 TA26 ABCDE
R109 LG-0RS0350K619 RESISTOR,FIXED METAL OXIDE FIL 0.35 OHM 2 W 5.00% TR ABCDE
R112 QRD161J-104Y RESISTOR,FIXED CARBON FILM 100K OHM 1/6 W 5% TA26 ABCDE
R116 QRD161J-221 RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5% TA26 ABCDE
R117 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5% TA26 ABCDE
R118 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R119 LG-0RN3301F408 RESISTOR,FIXED METAL FILM 3.3K OHM 1/6 W 1% TA26 ABCDE
R120 LG-0RN3001F408 RESISTOR,FIXED METAL FILM 3K OHM 1/6 W 1% TA26 ABCDE
R125 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R126 QRE141J-681Y RESISTOR,FIXED CARBON FILM 680 OHM 1/6 W 5% TA26 ABCDE
R151 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R152 QRE141J-331Y RESISTOR,FIXED CARBON FILM 330 OHM 1/6 W 5% TA26 ABCDE
R153 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R154 QRE141J-331Y RESISTOR,FIXED CARBON FILM 330 OHM 1/6 W 5% TA26 ABCDE
R155 QRD161J-332Y RESISTOR,FIXED CARBON FILM 3.3K OHM 1/6 W 5% TA26 ABCDE
R157 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R158 QRD161J-183Y RESISTOR,FIXED CARBON FILM 18K OHM 1/6 W 5% TA26 ABCDE
R159 QRD161J-471Y RESISTOR,FIXED CARBON FILM 470 OHM 1/6 W 5% TA26 ABCDE
R161 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R170 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5% TA26 ABCDE
R172 QRD161J-271Y RESISTOR,FIXED CARBON FILM 270 OHM 1/6 W 5% TA26 ABCDE
R173 QRD161J-271Y RESISTOR,FIXED CARBON FILM 270 OHM 1/6 W 5% TA26 ABCDE
R1B1 QRE121J-155Y RESISTOR,FIXED CARBON FILM 1.5M OHM 1/2 W 5.00% MF10 ABCDE
R201 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 A E
R202 QRD161J-274Y RESISTOR,FIXED CARBON FILM 270K OHM 1/6 W 5% TA26 A E
R204 QRE141J-473Y RESISTOR,FIXED CARBON FILM 47K OHM 1/6 W 5% TA26 A E
R301 QRD161J-563Y RESISTOR,FIXED CARBON FILM 56K OHM 1/6 W 5% TA26 ABCDE
R303 QRD161J-183Y RESISTOR,FIXED CARBON FILM 18K OHM 1/6 W 5% TA26 ABCDE
R304 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R305 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R306 QRD161J-223Y RESISTOR,FIXED CARBON FILM 22K OHM 1/6 W 5% TA26 ABCDE
R307 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5% TA26 ABCDE
R308 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R309 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R310 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R311 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R312 QRD161J-683Y RESISTOR,FIXED CARBON FILM 68K OHM 1/6 W 5% TA26 ABCDE
R313 QRD161J-2R2Y RESISTOR,FIXED CARBON FILM 2.2 OHM 1/6 W 5% TA26 ABCDE
R314 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R315 QRD161J-470Y RESISTOR,FIXED CARBON FILM 47 OHM 1/6 W 5% TA26 ABCDE
R316 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R317 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5% TA26 ABCDE
R318 LG-0RD3901F608 RESISTOR,FIXED CARBON FILM 3.9K OHM 1/6 W 5% TA26 ABCDE
R319 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 ABCDE
R320 QRE141J-151Y RESISTOR,FIXED CARBON FILM 150 OHM 1/6 W 5% TA26 ABCDE
R321 QRD161J-122 RESISTOR,FIXED CARBON FILM 1.2K OHM 1/6 W 5% TA26 ABCDE
R322 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R324 QRE141J-334Y RESISTOR,FIXED CARBON FILM 330K OHM 1/6 W 5% TA26 ABCDE
R325 QRD161J-471Y RESISTOR,FIXED CARBON FILM 470 OHM 1/6 W 5% TA26 ABCDE
R326 QRE141J-123Y RESISTOR,FIXED CARBON FILM 12K OHM 1/6 W 5% TA26 ABCDE
R327 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5% TA26 ABCDE
R328 QRD161J-271Y RESISTOR,FIXED CARBON FILM 270 OHM 1/6 W 5% TA26 ABCDE
R329 QRE141J-123Y RESISTOR,FIXED CARBON FILM 12K OHM 1/6 W 5% TA26 ABCDE
R330 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R331 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R334 QRD161J-272Y RESISTOR,FIXED CARBON FILM 2.7K OHM 1/6 W 5% TA26 ABCDE
R335 QRD161J-682Y RESISTOR,FIXED CARBON FILM 6.8K OHM 1/6 W 5% TA26 ABCDE
R336 QRD161J-104Y RESISTOR,FIXED CARBON FILM 100K OHM 1/6 W 5% TA26 ABCDE
R337 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5% TA26 ABCDE
R338 QRD161J-271Y RESISTOR,FIXED CARBON FILM 270 OHM 1/6 W 5% TA26 ABCDE
R339 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 ABCDE
R340 QRD161J-183Y RESISTOR,FIXED CARBON FILM 18K OHM 1/6 W 5% TA26 ABCDE
R342 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 ABCDE
R343 QRD161J-750Y RESISTOR,FIXED CARBON FILM 75 OHM 1/6 W 5.00% TA26 ABCDE
R344 QRD161J-471Y RESISTOR,FIXED CARBON FILM 470 OHM 1/6 W 5% TA26 ABCDE
R345 QRD161J-471Y RESISTOR,FIXED CARBON FILM 470 OHM 1/6 W 5% TA26 ABCDE
R346 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R347 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R349 QRD161J-182Y RESISTOR,FIXED CARBON FILM 1.8K OHM 1/6 W 5% TA26 ABCDE
R350 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R351 QRD161J-824 RESISTOR,FIXED CARBON FILM 820K OHM 1/6 W 0.05 TA26 ABCDE
R3A1 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R501 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R502 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R503 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R504 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R505 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R506 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R507 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R508 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5% TA26 ABCDE
R509 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5% TA26 ABCDE
R510 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5% TA26 ABCDE
R511 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R512 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R513 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R514 LG-0RD1203F608 RESISTOR,FIXED CARBON FILM 120K OHM 1/6 W 5% TA26 ABCDE
R515 QRD161J-271Y RESISTOR,FIXED CARBON FILM 270 OHM 1/6 W 5% TA26 ABCDE
R516 QRD161J-474Y RESISTOR,FIXED CARBON FILM 470K OHM 1/6 W 5% TA26 ABCDE
R517 QRD161J-471Y RESISTOR,FIXED CARBON FILM 470 OHM 1/6 W 5% TA26 ABCDE
R518 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R520 LG-0RD3901F608 RESISTOR,FIXED CARBON FILM 3.9K OHM 1/6 W 5% TA26 ABCDE
R521 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R522 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R523 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R524 QRE141J-220Y RESISTOR,FIXED CARBON FILM 22 OHM 1/6 W 5% TA26 ABCDE
R525 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5% TA26 ABCDE
R526 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5% TA26 ABCDE
R527 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R528 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R529 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R530 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R531 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R535 QRD161J-474Y RESISTOR,FIXED CARBON FILM 470K OHM 1/6 W 5% TA26 ABCDE
R542 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5% TA26 ABCDE
R543 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R544 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R546 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5% TA26 ABCDE
R547 QRE141J-123Y RESISTOR,FIXED CARBON FILM 12K OHM 1/6 W 5% TA26 ABCDE
R548 QRD161J-104Y RESISTOR,FIXED CARBON FILM 100K OHM 1/6 W 5% TA26 ABCDE
R550 QRD161J-221 RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5% TA26 ABCDE
R553 QRD161J-221 RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5% TA26 ABCDE
R555 QRD161J-221 RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5% TA26 ABCDE
R556 QRD161J-223Y RESISTOR,FIXED CARBON FILM 22K OHM 1/6 W 5% TA26 ABCDE
R557 QRD161J-273Y RESISTOR,FIXED CARBON FILM 27K OHM 1/6 W 5% TA26 ABCDE
R558 QRD161J-223Y RESISTOR,FIXED CARBON FILM 22K OHM 1/6 W 5% TA26 ABCDE
R559 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R55T2 QRE141J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5% TA26 ABCDE
R560 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R561 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 ABCDE
R562 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 ABCDE
R563 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5% TA26 ABCDE
R564 QRD161J-273Y RESISTOR,FIXED CARBON FILM 27K OHM 1/6 W 5% TA26 ABCDE
R566 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R567 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R568 QRD161J-683Y RESISTOR,FIXED CARBON FILM 68K OHM 1/6 W 5% TA26 ABCDE
R569 QRD161J-105Y RESISTOR,FIXED CARBON FILM 1M OHM 1/6 W 5% TA26 ABCDE
R570 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R575 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R576 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R577 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R578 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R579 QRD161J-563Y RESISTOR,FIXED CARBON FILM 56K OHM 1/6 W 5% TA26 ABCDE
R582 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R583 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R589 QRD161J-105Y RESISTOR,FIXED CARBON FILM 1M OHM 1/6 W 5% TA26 ABCDE
R591 QRD161J-104Y RESISTOR,FIXED CARBON FILM 100K OHM 1/6 W 5% TA26 ABCDE
R5A2 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R5A3 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R5A5 QRD161J-474Y RESISTOR,FIXED CARBON FILM 470K OHM 1/6 W 5% TA26 ABCDE
R5B3 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R5B4 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R5B5 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R5C1 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R5C5 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R5C6 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R5C7 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R5C9 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R5G1 QRE141J-473Y RESISTOR,FIXED CARBON FILM 47K OHM 1/6 W 5% TA26 ABCDE
R5G2 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R5G3 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R5G4 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 ABCDE
R5P2 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R5P3 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R5R7 QRE141J-331Y RESISTOR,FIXED CARBON FILM 330 OHM 1/6 W 5% TA26 ABCDE
R5R8 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R5S1 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5% TA26 ABCDE
R5T1 QRD161J-182Y RESISTOR,FIXED CARBON FILM 1.8K OHM 1/6 W 5% TA26 ABCDE
R5T10 QRE141J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5% TA26 ABCDE
R5T11 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R5T3 QRD161J-222Y RESISTOR,FIXED CARBON FILM 2.2K OHM 1/6 W 5% TA26 ABCDE
R5T4 QRD161J-272Y RESISTOR,FIXED CARBON FILM 2.7K OHM 1/6 W 5% TA26 ABCDE
R5T5 LG-0RD3901F608 RESISTOR,FIXED CARBON FILM 3.9K OHM 1/6 W 5% TA26 ABCDE
R5T9 QRD161J-182Y RESISTOR,FIXED CARBON FILM 1.8K OHM 1/6 W 5% TA26 ABCDE
R706 QRD161J-221 RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5% TA26 ABCDE
R707 QRD161J-221 RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5% TA26 ABCDE
R709 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R753 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 E
MODEL MARK MODEL MARK MODEL MARK
HR-V205EF A HR-V206EL B HR-V206EX C
HR-V206EY D HR-V505EF E
NSP:Not Service Parts

#REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP #REF No. PART No. PART NAME, DESCRIPTION SPECIFICATION ABCDE NSP
5-8
---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------ ---- ------- ----------------------- -------------------------------------- -------------------------------------- ------------------------
R754 QRD161J-332Y RESISTOR,FIXED CARBON FILM 3.3K OHM 1/6 W 5% TA26 E
R755 QRD161J-332Y RESISTOR,FIXED CARBON FILM 3.3K OHM 1/6 W 5% TA26 E
R758 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 E
R759 QRD161J-562Y RESISTOR,FIXED CARBON FILM 5.6K OHM 1/6 W 5% TA26 E
R7M1 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 BCD
R7M2 QRD161J-221 RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5% TA26 BCD
R7M3 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 BCD
R7M5 QRD161J-221 RESISTOR,FIXED CARBON FILM 220 OHM 1/6 W 5% TA26 BCD
R7S1 QRD161J-223Y RESISTOR,FIXED CARBON FILM 22K OHM 1/6 W 5% TA26 A E
R7V1 QRD161J-105Y RESISTOR,FIXED CARBON FILM 1M OHM 1/6 W 5% TA26 BCD
R7V2 QRD161J-104Y RESISTOR,FIXED CARBON FILM 100K OHM 1/6 W 5% TA26 BCD
R7V3 QRD161J-682Y RESISTOR,FIXED CARBON FILM 6.8K OHM 1/6 W 5% TA26 BCD
R7V4 QRD161J-564Y RESISTOR,FIXED CARBON FILM 560K OHM 1/6 W 5.00% TA26 BCD
R7V5 QRD161J-682Y RESISTOR,FIXED CARBON FILM 6.8K OHM 1/6 W 5% TA26 BCD
R7V6 QRD161J-564Y RESISTOR,FIXED CARBON FILM 560K OHM 1/6 W 5.00% TA26 BCD
R7V7 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 BCD
R7V8 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 BCD
R7V9 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 BCD
R801 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 E
R802 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 E
R817 QRD161J-335Y RESISTOR,FIXED CARBON FILM 3.3M OHM 1/6 W 5.00% TA26 E
R818 QRE141J-333Y RESISTOR,FIXED CARBON FILM 33K OHM 1/6 W 5% TA26 E
R819 QRD161J-272Y RESISTOR,FIXED CARBON FILM 2.7K OHM 1/6 W 5% TA26 E
R820 QRD161J-393Y RESISTOR,FIXED CARBON FILM 39K OHM 1/6 W 5% TA26 E
R821 QRD161J-272Y RESISTOR,FIXED CARBON FILM 2.7K OHM 1/6 W 5% TA26 E
R822 QRE141J-333Y RESISTOR,FIXED CARBON FILM 33K OHM 1/6 W 5% TA26 E
R823 QRD161J-471Y RESISTOR,FIXED CARBON FILM 470 OHM 1/6 W 5% TA26 E
R824 QRD161J-101Y RESISTOR,FIXED CARBON FILM 100 OHM 1/6 W 5% TA26 E
R825 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 E
R826 QRD161J-182Y RESISTOR,FIXED CARBON FILM 1.8K OHM 1/6 W 5% TA26 E
R827 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 E
R828 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 E
R830 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 E
R831 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 E
R8R1 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 E
R8R2 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 E
R901 QRD161J-750Y RESISTOR,FIXED CARBON FILM 75 OHM 1/6 W 5.00% TA26 ABCDE
R902 QRD161J-750Y RESISTOR,FIXED CARBON FILM 75 OHM 1/6 W 5.00% TA26 ABCDE
R903 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R904 QRE141J-473Y RESISTOR,FIXED CARBON FILM 47K OHM 1/6 W 5% TA26 ABCDE
R905 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 ABCDE
R906 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 ABCDE
R911 QRD161J-750Y RESISTOR,FIXED CARBON FILM 75 OHM 1/6 W 5.00% TA26 ABCDE
R912 QRD161J-750Y RESISTOR,FIXED CARBON FILM 75 OHM 1/6 W 5.00% TA26 ABCDE
R913 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 ABCDE
R914 QRD161J-561 RESISTOR,FIXED CARBON FILM 560 OHM 1/6 W 5% TA26 ABCDE
R943 QRE141J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5% TA26 ABCDE
R964 QRD161J-821Y RESISTOR,FIXED CARBON FILM 820 OHM 1/6 W 5% TA26 ABCDE
R965 QRE141J-102Y RESISTOR,FIXED CARBON FILM 1K OHM 1/6 W 5% TA26 ABCDE
R9C1 QRE141J-123Y RESISTOR,FIXED CARBON FILM 12K OHM 1/6 W 5% TA26 ABCDE
R9C2 QRE141J-103Y RESISTOR,FIXED CARBON FILM 10K OHM 1/6 W 5% TA26 ABCDE
R9C3 QRE141J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5% TA26 ABCD
R9C4 QRE141J-152Y RESISTOR,FIXED CARBON FILM 1.5K OHM 1/6 W 5% TA26 ABCD
R9M1 QRE141J-473Y RESISTOR,FIXED CARBON FILM 47K OHM 1/6 W 5% TA26 ABCD
R9M2 LG-0RD3901F608 RESISTOR,FIXED CARBON FILM 3.9K OHM 1/6 W 5% TA26 ABCD
R9M3 QRE141J-473Y RESISTOR,FIXED CARBON FILM 47K OHM 1/6 W 5% TA26 ABCD
R9M4 LG-0RD3901F608 RESISTOR,FIXED CARBON FILM 3.9K OHM 1/6 W 5% TA26 ABCD
R9M5 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
R9M6 QRD161J-472Y RESISTOR,FIXED CARBON FILM 4.7K OHM 1/6 W 5% TA26 ABCDE
RC501 LG-6712R1938GB REMOTE CONTROLLER RECEIVER TSOP2238WE1 VISHAY 37.9KHZ 19M ABCDE
RS501 LG-6500RAB003A SENSOR SG-260 KODENSHI D33 REEL SENSO ABCDE
RS502 LG-6500RAB003A SENSOR SG-260 KODENSHI D33 REEL SENSO ABCDE
L101 LG-636-004C FILTER(CIRC),EMC BEAD CORE BFS3550R2FD8,R T/P ABCDE
L102 LG-616-145H FILTER(CIRC) SHT LFS2020V4-04350 ABCDE
L103 LG-633-088G COIL,CHOKE CHOCK(22MH) 5MM TOKO TP ABCDE
L104 LG-633-088G COIL,CHOKE CHOCK(22MH) 5MM TOKO TP ABCDE
L106 LG-636-004C FILTER(CIRC),EMC BEAD CORE BFS3550R2FD8,R T/P ABCDE
L201 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP A E
L301 LG-0LR0102J0N5 INDUCTOR,RADIAL LEAD 10UH 5% TP 3X5 TR5 ABCDE
L302 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP ABCDE
L303 LG-0LR0102J0N5 INDUCTOR,RADIAL LEAD 10UH 5% TP 3X5 TR5 ABCDE
L304 LG-0LR0102J0N5 INDUCTOR,RADIAL LEAD 10UH 5% TP 3X5 TR5 ABCDE
L305 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP ABCDE
L307 LG-0LR0102J0N5 INDUCTOR,RADIAL LEAD 10UH 5% TP 3X5 TR5 ABCDE
L501 LG-0LA0122K018 INDUCTOR AXIAL LEAD 12M K 2.3X3.4 L5 TP ABCDE
L503 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP ABCDE
L504 LG-0LR0102J0N5 INDUCTOR,RADIAL LEAD 10UH 5% TP 3X5 TR5 ABCDE
L505 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP ABCDE
L506 LG-635-027C INDUCTOR,RADIAL LEAD EL0405RA SKI150G-3 K-TDK 15UH ABCDE
L5G2 LG-0LR1500K035 INDUCTOR RADIALLEAD 150M K 6X6 L5 TP ABCDE
L5S1 LG-0LA0332K018 INDUCTOR AXIAL LEAD 33M K 2.3X3.4 L5 TP ABCDE
L702 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP ABCDE
L703 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP ABCDE
L704 LG-0LA0821K018 INDUCTOR AXIAL LEAD 8.2M K 2.3X3.4 L5 TP ABCDE
L705 LG-0LR1000K035 INDUCTOR RADIAL LEAD 100M K 6X6 L5 TP BCD
L751 LG-0LR0102J0N5 INDUCTOR,RADIAL LEAD 10UH 5% TP 3X5 TR5 E
L753 LG-0LR0102J0N5 INDUCTOR,RADIAL LEAD 10UH 5% TP 3X5 TR5 E
L7V1 LG-0LR1000K035 INDUCTOR RADIALLEAD 100M K 6X6 L5 TP BCD
L801 LG-0LR0102J0N5 INDUCTOR,RADIAL LEAD 10UH 5% TP 3X5 TR5 E
L802 LG-0LR0102J0N5 INDUCTOR,RADIAL LEAD 10UH 5% TP 3X5 TR5 E
L8R1 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP E
L8R2 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP E
L901 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP ABCDE
L902 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP ABCDE
L904 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP ABCDE
L905 LG-636-004C FILTER(CIRC),EMC BEAD CORE BFS3550R2FD8,R T/P ABCDE
L906 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP ABCDE
L907 LG-636-004C FILTER(CIRC),EMC BEAD CORE BFS3550R2FD8,R T/P ABCDE
L911 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP ABCDE
L912 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP ABCDE
L914 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP ABCDE
L915 LG-0LA1000K018 INDUCTORAXIAL LEAD 100M K 2.3X3.4 L5 TP ABCDE
CS501 LG-6600M000002 SWITCH,PUSH MPU11810MLB0 MIC DC 5V 1MA D-3 ABCDE
CS501 LG-6600M000002 SWITCH,PUSH MPU11810MLB0 MIC DC 5V 1MA D-3 ABCDE
F101 LG-585-011T FUSE,SLOW BLOW 1600MA 250 V 5.2X20 CY/GL SEMK ABCDE
F102 LG-GIRH200000B IC,ROHM ICP-N20 T104 TP IC DETACT ABCDE
FL301 LG-633-032K COIL,IFT BIAC OSC,1CHIP 5V(KS-75M) KWAN ABCDE
JK801 LG-6612R-C002C JACK,RCA RCA-208C-06 YUQIU WH-RD E
JK901 LG-6620RM0002J JACK,SCART DSAM-0121 DOOWON 2F-21P(BL-BK) ABCDE
LD501 LG-4931R-0017C HOLDER ASSY LED(DI-CKD)LOCAL ABCDE
LED501 LG-6301R2U002D LED ASSY TOF-3462AGE-B OASIS UNIVERSAL ABCDE
MS501 LG-6600JB8005B SWITCH,MODE NON 5V 1MA VERTICAL -G ABCDE
S5T10 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABCDE
S5T12 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABCDE
S5T13 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABCDE
S5T14 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABCDE
SW5T1 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABCDE
SW5T3 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABCDE
SW5T4 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABCDE
SW5T5 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABCDE
SW5T6 LG-556-213C SWITCH,DETECTOR THVV951BAA POSTECH DC 12 V 5-0 ABCDE
T101 LG-642-015G TRANSFORMER,SMPS[COIL] SJE-015G/SHT-015G SJ/SH/CS/LSE ABCDE
TU701 LG-6700PFPL06A TUNER TADC-S401D(SECAM,LGIT) LG INOT A E
TU701 LG-6700PFPL06B TUNER TADC-G401D(BG,LGIT) LG INOTEK BCD
W588 LG-636-004C FILTER(CIRC),EMC BEAD CORE BFS3550R2FD8,R T/P ABCDE
X301 LG-6202R2443AC RESONATOR,CRYSTAL HC49U BUBANG 4-433709MHZ 15 ABCDE
X501 LG-6212AA2100C RESONATOR,CRYSTAL HC-49S BUBANG 10MHZ +/- 30 PPM ABCDE
X502 LG-6202R-DA01A RESONATOR,CRYSTAL CFS-308 CITIZEN 32-768KHZ ABCDE
X751 LG-529-021Q RESONATOR,CRYSTAL 49U BUBANG 18432000HZ 30PPM 16 E
ZD151 LG-0DZ130009AB DIODE,ZENERS MTZ13C TP ROHM-K ABCDE
ZD503 UZ6.2BSC-T DIODE,ZENERS UZ-6.2BSC 26MM PYUNG CHANG TP ABCDE
ZD801 LG-0DZ562609BB DIODE,ZENER UZ-5.6BSB 26MM TP PYUNG CHANG E
ZD802 LG-0DZ562609BB DIODE,ZENER UZ-5.6BSB 26MM TP PYUNG CHANG E
ZD803 MTZ13AT-77 DIODE,ZENER MTZ13ATP ROHM-K E
ZD804 MTZ13AT-77 DIODE,ZENER MTZ13ATP ROHM-K E
MODEL MARK MODEL MARK MODEL MARK
HR-V205EF A HR-V206EL B HR-V206EX C
HR-V206EY D HR-V505EF E
NSP:Not Service Parts
E. & O. E. No.82965
HR-V202EF,HR-V206EL,HR-V206EX,HR-V206EY,HR-V505EF (VP)-V16A1,D1-

COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD
SERVICE MANUAL
g e n e r a l
Power: 200 V – 240 V, 50 Hz/60 Hz
Power consumption : Power on : Approx. 12 W : tandby mode:3.0 W
Video Head system : DA4 (Double Azimuth) head helical scan system
Tape speed
( P) : 23.39 mm/sec
(LP) : 11.69 mm/sec
Tape format : Tape width 1/2" (12.7 mm high density VH tape)
Maximum recording time
( P) : 240 min. with E-240 video cassette
(LP) : 480 min. with E-240 video cassette
Rewind time : Approx. 180 sec. with E-180 cassette
Dimensions (W x H x D) : 360 mm x 94.5 mm x 270 mm
Weight : 4.0 kg
Operating temperature : 5 °C to 35 °C
Operating humidity : Less than 80 %
Timer: 24 hours display type
vi eo
ignal system: PAL-type colour signal and CCIR monochrome signal, 625 lines 50 fields
Recording Format : PAL I
RF reception : PAL I
RF OUT : PAL I
RF modulator: UHF channels 22 – 68 (Adjustable)
Input level : VIDEO IN ( CART type) 1.0 Vp-p, 75 ohm, unbalanced
Output level : VIDEO OUT ( CART type) 1.0 Vp-p, 75 ohm, unbalanced
ignal-to-noise ratio : More than 43 dBm
au io
Input level : AUDIO IN ( CART type) –6.0 dBm, more than 10 kΩ
Output level : AUDIO OUT ( CART, RCA type) –6.0 dBm, less than 1 kΩ
Audio track : Mono track and Hi-Fi track
Audio frequency response
Normal audio : 100 Hz to 10,000 Hz (–6/+3 dBm)
Hi-Fi audio : 20 Hz to 20,000 Hz (–3/+3 dBm)
Audio signal to noise ratio
Hi-Fi audio : More than 70 dB (JI A filter)
Audio dynamic range
Hi-Fi audio : More than 85 dB (JI A filter)
accessories
Provided accessories : RF cable, Infrared remote control unit, “CR 2032” battery x 1
pecifications shown are for P mode unless otherwise specified.
E.& O.E. Design and specifications subject to change without notice.
No.82963
2003/05
HR-V200EZ, HR-V205EK,
HR-V500EZ, HR-V505EK, HR-V505EZ
HR-V200EZ, HR-V205EK, HR-V500EZ, HR-V505EK, HR-V505EZ, V16A0,A1,D0,D1-
VIDEO CASSETTE RECORDER
S PECIFICATIONS (The specifications shown pertain specifically to the model HR-V505EK.)
PAL

Notes: Mark is same as left.
MODEL HR-V200EZ
ITEM
BROADCASTING STANDARD PAL B/G,D/K PAL I PAL B/G,D/K PAL I PAL B/G,D/K
AUDIO MONO HiFi
STEREO DECODER NOT USED NOT USED NICAM, 2 Carrier NICAM NICAM,2 Carrier
VIDEO HEAD 2 4
TAPE SPEED SP SP/LP
SHOWVIEW/VIDEOplus+ NOT USED VIDEOplus+ NOT USED VIDEOplus+ SHOWVIEW
FRAME ADVANCE NOT USED USED
SLOW(FORWARD) NOT USED USED
DIGITAL SHUTTLE NOT USED USED
HiFi AUDIO OUT(RCA) NOT USED USED
AV2 CONNECTOR NOT USED USED NOT USED
POWER PLUG CEE BS CEE BS CEE
HR-V500EZHR-V205EK HR-V505EZHR-V505EK
TABLE OF CONTENTS
SECTION 1
SUMMARY
KEY TO ABBREVIATIONS . . . . . . . . . . . . . . . . 1-1
Important Safety Precautions
PROPOSAL FOR APPLYING SHORT
PROTECTION . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
SERVICE NOTICE ON REPLACING EEPROM . .1-5
SERVICE INFORMATION FOR EEPROM
IC SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . 1-8
SECTION 2
CABINET & MAIN CHASSIS
SERVICE METHOD . . . . . . . . . . . . . . . . . . . . . 2-1
Electrical Part . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
EXPLODED VIEWS . . . . . . . . . . . . . . . . . . . . . . 2-2
1. Cabinet & Main Frame Section . . . . . . . . . . . . . 2-2
2. Packing & Accessory Section . . . . . . . . . . . . . . 2-3
SECTION 3
ELECTRICAL
ELECTRICAL ADJUSTMENT POINTS
ARRANGEMENT . . . . . . . . . . . . . . . . . . . . . . . .3-1
ELECTRICAL ADJUSTMENT PROCEDURES . . 3-2
1. Servo Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
ELECTRICAL TROUBLESHOOTING GUIDE . . . 3-4
1. Power Circuit(SMPS) . . . . . . . . . . . . . . . . . . . . . 3-4
2. Servo Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
3. System & Front Panel Circuit . . . . . . . . . . . . . . .3-10
4. Y/C Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12
5. Tuner/IF Circuit . . . . . . . . . . . . . . . . . . . . . . . . .3-16
6. Hi-Fi Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-19
BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . .3-21
1. Power Block Diagram . . . . . . . . . . . . . . . . . . . .3-21
2. Tuner/IF, NICAM & A2 Block Diagram . . . . . . . .3-23
3. VPS Block Diagram . . . . . . . . . . . . . . . . . . . . . .3-24
4. Y/C Block Diagram . . . . . . . . . . . . . . . . . . . . . .3-25
5. Hi-Fi Block Diagram . . . . . . . . . . . . . . . . . . . . .3-26
6. System Block Diagram . . . . . . . . . . . . . . . . . . .3-27
CIRCUIT DIAGRAMS . . . . . . . . . . . . . . . . . . . .3-29
1. Power Circuit Diagram . . . . . . . . . . . . . . . . . . . .3-29
2. Tuner, NICAM/A2 Circuit Diagram . . . . . . . . . . .3-31
3. A/V, SECAM, VPS Circuit Diagram . . . . . . . . . .3-33
5.1 EXPLODED VIEW 5-1
5.1.1
PACKING AND ACCESSORY ASSEMBLY <M1> 5-1
5.1.2 FINAL ASSEMBLY <M2> 5-2
5.1.3 MECHANISM ASSEMBLY <M4> 5-3
5.2 REPLACEMENT PARTS LIST 5-4
PACKING AND ACCESSORY PARTS LIST<M1> 5-4
FINAL PARTS LIST<M2> 5-4
MECHANISM PARTS LIST<M4> 5-4
MAIN BOARD ASSEMBLY<03> 5-5
4. System Circuit Diagram . . . . . . . . . . . . . . . . . . .3-35
5. Hi-Fi, SCART Circuit Diagram . . . . . . . . . . . . . .3-39
• CIRCUIT VOLTAGE CHART . . . . . . . . . . . . . . . .3-41
• WAVEFORM & VOLTAGE SHEET. . . . . . . . . . . .3-37
PRINTED CIRCUIT BOARD DIAGRAMS . . . . .3-45
1. MAIN P.C.Board . . . . . . . . . . . . . . . . . . . . . . . .3-45
SECTION 4
MECHANISM
SECTION 5
REPLACEMENT PARTS LIST
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . .
. . . .
. . . . . . . . . . . . . .
NOTE) The table of contents for this section is edited
NOTE) separately.
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . . . . . .
.
The following table indicates main different points between models HR-V200EZ, HR-V205EK, HR-V500EZ, HR-V505EK and HR-V505EZ.

1-1
A AC :Alternating Current
ACC :Automatic Color Control
ACSS :Automatic Channel Setting System
ADJ :Adjust
A/E :Audio Erase
AFC :Automatic Frequency Control
AFT :Automatic Fine Tuning
AGC :Automatic Gain Control
A.H.SW :Audio Head Switch
ALC :Automatic Level Control
AM :Amplitude Modulation
AMP :Amplifier
ANT :Antenna
APC :Automatic Phase Control
ASS’Y :Assembly
AUX :Auxiliary
B B :Base
BGP :Burst Gate Pulse
BPF :Bandpass Filter
BS :Brodcasting Satellite
BW or B/W :Black and White
C C :Capacitor, Chroma, Collector
CAN :Cancel
CAP :Capstan
CAP.BRK :Capstan Brake
CAP.RVS :Capstan Reverse
CATV :Cable Television
CBA :Circuit Board Assembly
CCD :Charge Coupled Device
C.CTL :Chro Control, Capstan Control
CFG :Capstan Frequency Generator
CHROMA :Chrominance
CNR :Chroma Noise Redution
COMB :Combination
Comb Filter
COMP :Comparator
Composite
Compensation
CONV :Converter
C.ROT SW :Color Rotary Switch
CS :Chip Selcet
C.SYNC :Composite Synchronization
CTL DIV :Control Divide
CUR :Current
CYL :Cylinder
D D :Drum, Digital, Diode, Drain
D.ADJ :Drum Adjust
DC :Direct Current
D.CTL :Drum Control
DEMOD :Demodulator
DET :Detector
DEV :Deviation
DHP :Double High Pass
DIGITRON :Digital Display Tube
DL :Delay line
DOC :Drop Out Compensator
DUB :Dubbing
D.V SYNC :Dummy Vertical Synchronization
E E :Emitter
EE :Electric to Eletric
EMPH :Emphasis
ENA :Enable
ENV :Envelope
EP :Extended Play
EQ :Equalizer
EXP :Expander
F F :Fuse
FB :Feed Back
FBC :Feed Back Clamp
FE :Full Erase
FG :Frequency Generator
FL :Filter
FM :Frequency Modulation
F/R :Front/Rear
FS :Frequency Synthesizer
FSC :Subcarrier Frequency
F/V :Frequency Voltage
G GEN :Generator
H H :High, Horizontal
I IC :Integrated Circuit
IF :Intermediate Frequency
INS :Insert
L L :Low, Left, Coil
LD :LED
LD VTG CTL :Loading Voltage Control
LECHA :Letter Character
L.M :Level Meter
LP :Long Play
LPF :Low Pass Filter
M MAX :Maximum
MD :Modulator
MECHA.CTL :Mechanism Control
MIC :Microphone
MIN :Minimum
MIX :Mixer, Mixing
M.M. :Monostable, Multivibrator
MMV :Mono Multi Vibrator
MOD :Modulation, Modulator
MODEM :Modulator-Demodulator
MPX :Multiplex
N NR :Noise Reduction
O OSC :Oscillator
OSD :On Screen Display
P PB :Playback
PCB :Printed Circuit Board
P.CTL :Power Control
PRE-AMP :Preamplifier
P.F :Power Failure
PG :Pulse Generator
PLL :Phase Locked Loop
PREM.DET :Premire Detect
P.P :Peak-to-Peak
PS :Phase Shift
PWM :Pulse Width Modulation
PWR CTL :Power Control
Q Q :Transistor
QH :Quasi Horizontal
QSR :Quick Setting Record
QTR :Quick Timer Record
QV :Quasi Vertical
R R :Resistor, Right
RE(or RC) :Remocon, Receiver
REC :Recording
REC S ‘H’ :Record Start ‘Hight’
REF :Reference
REG :Regulated, Regulator
REMOCON :Remote Control(unit)
RF :Radio Frequency
R/P :Record/Playback
RTC :Reel Time Counter
S S :Serial
S.ACCEL :Slow Accel
SAOP :Second Audio Program
SC :Scart, Simulcast
S.DET :Secam Detect
SH :Shift
SHARP :Sharpness
SIF :Sound Intermediate Frequency
SLD :Side Locking
S/N :Signal to Noise Ratio
SP :Standard Play
ST :Stereo
SUB :Subtract, Subcarrier
SW or S/W :Switch
SYNC :Synchronization
SYSCON :System Control
T T :Coil
TP :Test Point
TR :Transistor
TRK :Tracking
TRANS :Transformer
TU :Tuner, Take-up
U UHF :Ultra High Frequency
UNREG :Unregulated
V V :Volt, Vertical
VA :Always Voltage
VCO :Voltage Controlled Oscillator
VGC :Voltage Gain Control
VHF :Very High Frequency
V.H.SW :Video Head Switch
VISS :VHS Index Search
VPS :Video Program System
VR :Variable Resistor or Volume
V-SYNC :Vertical Synchronization
VTG :Voltage
VV :Voltage to Voltage
VXO :Voltage X-tal Oscillator
W W :Watt
WHT :White
W/O :With out
X X-TAL :Crystal
Y Y/C :Luminance/Chrominance
YNR :Luminance Noise Reduction
Z ZD :Zener Diode
SECTION1 SUMMARY
KEY TO ABBREVIATIONS

Important Safety Precautions
Prior to shipment from the factory, JVC products are strictly inspected to conform with the recognized product safety and electrical codes
of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the
following precautions when a set is being serviced.
Fig.1
1. Locations requiring special caution are denoted by labels and
inscriptions on the cabinet, chassis and certain parts of the
product. When performing service, be sure to read and com-
ply with these and other cautionary notices appearing in the
operation and service manuals.
2. Parts identified by the symbol and shaded ( ) parts are
critical for safety.
Replace only with specified part numbers.
Note: Parts in this category also include those specified to com-
ply with X-ray emission standards for products using
cathode ray tubes and those specified for compliance
with various regulations regarding spurious radiation
emission.
3. Fuse replacement caution notice.
Caution for continued protection against fire hazard.
Replace only with same type and rated fuse(s) as specified.
4. Use specified internal wiring. Note especially:
1) Wires covered with PVC tubing
2) Double insulated wires
3) High voltage leads
5. Use specified insulating materials for hazardous live parts.
Note especially:
1) Insulation Tape 3) Spacers 5) Barrier
2) PVC tubing 4) Insulation sheets for transistors
6. When replacing AC primary side components (transformers,
power cords, noise blocking capacitors, etc.) wrap ends of
wires securely about the terminals before soldering.
Power cord
Fig.2
10. Also check areas surrounding repaired locations.
11. Products using cathode ray tubes (CRTs)
In regard to such products, the cathode ray tubes themselves,
the high voltage circuits, and related circuits are specified for
compliance with recognized codes pertaining to X-ray emission.
Consequently, when servicing these products, replace the cath-
ode ray tubes and other parts with only the specified parts.
Under no circumstances attempt to modify these circuits.
Unauthorized modification can increase the high voltage value
and cause X-ray emission from the cathode ray tube.
12. Crimp type wire connector
In such cases as when replacing the power transformer in sets
where the connections between the power cord and power
transformer primary lead wires are performed using crimp type
connectors, if replacing the connectors is unavoidable, in or-
der to prevent safety hazards, perform carefully and precisely
according to the following steps.
1) Connector part number : E03830-001
2) Required tool : Connector crimping tool of the proper type
which will not damage insulated parts.
3) Replacement procedure
(1) Remove the old connector by cutting the wires at a point
close to the connector.
Important : Do not reuse a connector (discard it).
Fig.7
cut close to connector
Fig.3
(2) Strip about 15 mm of the insulation from the ends of
the wires. If the wires are stranded, twist the strands to
avoid frayed conductors.
15 mm
Fig.4
(3) Align the lengths of the wires to be connected. Insert
the wires fully into the connector.
Connector
Metal sleeve
Fig.5
(4) As shown in Fig.6, use the crimping tool to crimp the
metal sleeve at the center position. Be sure to crimp fully
to the complete closure of the tool.
1
vPrecautions during Servicing
7. Observe that wires do not contact heat producing parts
(heatsinks, oxide metal film resistors, fusible resistors, etc.)
8. Check that replaced wires do not contact sharp edged or
pointed parts.
9. When a power cord has been replaced, check that 10-15 kg of
force in any direction will not loosen it.
1.25
2.0
5.5
Crimping tool
Fig.6
(5) Check the four points noted in Fig.7.
Not easily pulled free Crimped at approx. center
of metal sleeve
Conductors extended
Wire insulation recessed
more than 4 mm
S40888-01

v Safety Check after Servicing
Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts and wires have been
returned to original positions, Afterwards, perform the following tests and confirm the specified values in order to verify compli-
ance with safety standards.
1. Insulation resistance test
Confirm the specified insulation resistance or greater between power cord plug prongs and
externally exposed parts of the set (RF terminals, antenna terminals, video and audio input
and output terminals, microphone jacks, earphone jacks, etc.). See table 1 below.
2. Dielectric strength test
Confirm specified dielectric strength or greater between power cord plug prongs and exposed
accessible parts of the set (RF terminals, antenna terminals, video and audio input and output
terminals, microphone jacks, earphone jacks, etc.). See table 1 below.
3. Clearance distance
When replacing primary circuit components, confirm specified clearance distance (d), (d’) be-
tween soldered terminals, and between terminals and surrounding metallic parts. See table 1
below.
4. Leakage current test
Confirm specified or lower leakage current between earth ground/power cord plug prongs
and externally exposed accessible parts (RF terminals, antenna terminals, video and audio
input and output terminals, microphone jacks, earphone jacks, etc.).
Measuring Method : (Power ON)
Insert load Z between earth ground/power cord plug prongs and externally exposed accessi-
ble parts. Use an AC voltmeter to measure across both terminals of load Z. See figure 9 and
following table 2.
5. Grounding (Class 1 model only)
Confirm specified or lower grounding impedance between earth pin in AC inlet and externally exposed accessible parts (Video in,
Video out, Audio in, Audio out or Fixing screw etc.).
Measuring Method:
Connect milli ohm meter between earth pin in AC inlet and exposed accessible parts. See figure 10 and grounding specifications.
d'
d
Chassis
Power cord,
primary wire
Region
USA & Canada
Europe & Australia
Grounding Impedance (Z)
Z 0.1 ohm
Z 0.5 ohm
≤
≤
AC inlet
Earth pin
Exposed accessible part
Milli ohm meter
Grounding Specifications
Fig. 10
ab
c
V
Externally
exposed
accessible part
Z
Fig. 9
Fig. 8
Clearance Distance (d), (d')
d, d' 3 mm
d, d' 4 mm
d, d' 3.2 mm
1 MΩR 12 MΩ/500 V DC
Dielectric Strength
AC 1 kV 1 minute
AC 1.5 kV 1 miute
AC 1 kV 1 minute
AC Line Voltage
100 V
100 to 240 V
110 to 130 V
110 to 130 V
200 to 240 V
Japan
USA & Canada
Europe & Australia R 10 MΩ/500 V DC
Region
Insulation Resistance (R)
R 1 MΩ/500 V DC
≤
≤
≥≥
≤
≤
≤≤
≤
≤
AC 3 kV 1 minute
(Class 2)
AC 1.5 kV 1 minute
(Class 1)
d 4 mm
d' 8 mm (Power cord)
d' 6 mm (Primary wire)
Table 1 Specifications for each region
a, b, cLeakage Current (i)AC Line Voltage
100 V
110 to 130 V
110 to 130 V
220 to 240 V
Japan
USA & Canada
i 1 mA rms Exposed accessible parts
Exposed accessible parts
Antenna earth terminals
Other terminals
i 0.5 mA rms
i 0.7 mA peak
i 2 mA dc
i 0.7 mA peak
i 2 mA dc
Europe & Australia
Region Load Z
≤
≤
≤
≤
≤
≤
1 kΩ
2 kΩ
1.5 kΩ
0.15 µF
50 kΩ
Table 2 Leakage current specifications for each region
Note: These tables are unofficial and for reference only. Be sure to confirm the precise values for your particular country and locality.
2S40888-01

1-4
• The Contents of Examination
As all the IC that is applied to VCR is controlled by IIC, mutual communication, if Vcc of IC is short or open
with detecting ‘Acknowledge’ data of the specific IC according to each power(5V, 5VT) µ-COM gets unable to
detect ‘ACK’ data.
µ-COM regards this case as abnormal one and if it can’t detect ‘ACK’ data for a certain time(3.5 sec) the sig-
nal of ‘Power Control’ and ‘Timer Control’ are switched to ‘Low’. As a result POWER Switching TR is kept from
generating heat and fire.
• POWER for each IC
EF 5V POWER SECAM IC
Series 5VT POWER AVCP IC
Other 5V POWER Modulator
Series 5VT POWER AVCP IC
*Short protection off mode : DJ01 Diode in
PROPOSAL FOR APPLYING SHORT PROTECTION
IIC BUS
5VT SW POWER
CONTROL
MASTER
TIMER
CONTROL
5VT SW
SLAVE with 5V
SLAVE with 5V
5.3VA
Timer Control
AVCP IC
TUNER
Conception
BLOCK Diagram
5.2V 5.2VT
• IC to detect ‘ACK’ data is selected as below because IC is different in accordance to region and option
5.3VA
Power Control
Modulator
Hi-Fi IC
NICAM IC
SECAM IC

1-5
In case that defective EEPROM of PAL models is replaced, to operate these sets from the initial state MP KEY
must be repaired as well before delivering to the customer.
If MP KEY isn’t repaired the setting of RF OUT channel or LANGUAGE might be different from that for cus-
tormer’s country.
•MP KEY : In case of PAL VCR if holding the REC button on the front panel and the CLEAR button on the
remote control handset for 5 ~ 7 seconds with power being switch all and no tapes,
OK is displayed at FLD for FLD models and LED becomes on for LED CLOCK models.
This is the state that initializing EEPROM is finished.
(In case of PAL VCP if holding the REC button on the front panel and the MENU button on the
remote control handset for 5 ~ 7 seconds with power being off and no tapes, All the LED DOTs
become on. This is the state that initializing EEPROM is finished.)
•MP KEY's function : MP KEY sets EEPROM's data up to the initial state.
SERVICE NOTICE ON REPLACING EEPROM
TIMER
AM
REC
VCR
OK
• FLD MODEL:
MP KEY “OK”
• LED CLOCK MODEL:
MP KEY Switch all on a Light
• LED DOT MODEL:
MP KEY Switch all on a Light

1-6
SERVICE INFORMATION FOR EEPROM IC SETTING
MODEL NAME HEX BINARY
HR-V200EX OPTION1 02 00000000
OPTION2 C0 00000000
OPTION3 87 00000000
OPTION4 B1 00000000
OPTION5 30 00000000
OPTION6 08 00000000
HR-V200EY OPTION1 02 00000000
OPTION2 C0 00000000
OPTION3 87 00000000
OPTION4 B1 00000000
OPTION5 B0 00000000
OPTION6 08 00000000
HR-V200EL OPTION1 02 00000000
OPTION2 C0 00000000
OPTION3 87 00000000
OPTION4 B1 00000000
OPTION5 A0 00000000
OPTION6 08 00000000
HR-V205EX OPTION1 E2 00000000
OPTION2 C1 00000000
OPTION3 8F 00000000
OPTION4 B1 00000000
OPTION5 30 00000000
OPTION6 68 00000000
HR-V205EY OPTION1 E2 00000000
OPTION2 C1 00000000
OPTION3 8F 00000000
OPTION4 B1 00000000
OPTION5 B0 00000000
OPTION6 68 00000000
HR-V205EL OPTION1 E2 00000000
OPTION2 C1 00000000
OPTION3 8F 00000000
OPTION4 B1 00000000
OPTION5 A0 00000000
OPTION6 68 00000000
HR-V206EX OPTION1 E2 00000000
OPTION2 C1 00000000
OPTION3 8F 00000000
OPTION4 B1 00000000
OPTION5 30 00000000
OPTION6 68 00000000
MODEL NAME HEX BINARY
HR-V206EY OPTION1 E2 00000000
OPTION2 C1 00000000
OPTION3 8F 00000000
OPTION4 B1 00000000
OPTION5 B0 00000000
OPTION6 68 00000000
HR-V206EL OPTION1 E2 00000000
OPTION2 C1 00000000
OPTION3 8F 00000000
OPTION4 B1 00000000
OPTION5 A0 00000000
OPTION6 68 00000000
HR-V500EX OPTION1 0C 00000000
OPTION2 C0 00000000
OPTION3 83 00000000
OPTION4 B1 00000000
OPTION5 30 00000000
OPTION6 08 00000000
HR-V500EY OPTION1 0C 00000000
OPTION2 C0 00000000
OPTION3 83 00000000
OPTION4 B1 00000000
OPTION5 B0 00000000
OPTION6 08 00000000
1. DETECT NEW EEPROM (OPTION EDIT SCREEN)
- Eeprom EDIT screen automatically appears if replacing Eeprom.
• Setup option data using the cursor Up/Down key of a remote
control.
(Setup upon BOM depending on OPT1~OPT6 model)
• Since an initial remote control is set to LG for LG model, appro-
priately set optional data using the cursor Up/Down key.
2. EEPROM WRITED COMPLETE SCREEN
- Writes data on EEPROM by using REMOCON "OK".
- If completing the option data screen with a menu key, Powering
Off is automatically done and the option edit screen is arranged.
3. PG ADJUST
a) Insert the PAL SP Test Tape and play.
Note - Adjust the distance of X, pressing the Tracking(+) or
Tracking(-) when the “ATR” is blink after the PAL SP Test
Tape is inserted.
b) Press the Auto PG KEY on JIG Remocon(1’st) or Press “REC”
key on set and “CLEAR” key on Remocon.(Then check the blink
“TRK OK” on CLK/LED-TRK is a Initial)
c) Press the Auto PG Key on JIG Remocon again (2’nd) or press
“REC” key on set and “CLEAR” key on Remocon again.(Then
check the blink “PG NG > PG OK” on CLK/LED.)
4. EEPROM INITIAL
- SETUP is displayed in the field if pressing the FRONT REC KEY
with the remocon number "CLEAR" key pressed in the status of
powering Off.
- AUTO SEARCH is done since the initial screen of ACMS is ser-
viced if powering On.
- Check basic operation (PLAY/RECORD...)
EEPROM option code No. setting EEPROM option code No. setting procedure
NAME HEX BINARY
OPT1 00 00000000
OPT2 00 00000000
OPT3 00 00000000
OPT4 00 00000000
OPT5 00 00000000
OPT6 00 00000000
WR : OK I : EXIT MOVE : 8t
EDIT : 67E
MASKROM : R00
EEPROM : R00 LG CODE

1-7
MODEL NAME HEX BINARY
HR-V500EL OPTION1 0C 00000000
OPTION2 C0 00000000
OPTION3 83 00000000
OPTION4 B1 00000000
OPTION5 A0 00000000
OPTION6 08 00000000
HR-V505EX OPTION1 EC 00000000
OPTION2 C1 00000000
OPTION3 8B 00000000
OPTION4 B1 00000000
OPTION5 30 00000000
OPTION6 08 00000000
HR-V505EY OPTION1 EC 00000000
OPTION2 C1 00000000
OPTION3 8B 00000000
OPTION4 B1 00000000
OPTION5 B0 00000000
OPTION6 08 00000000
HR-V505EL OPTION1 EC 00000000
OPTION2 C1 00000000
OPTION3 8B 00000000
OPTION4 B1 00000000
OPTION5 A0 00000000
OPTION6 08 00000000
HR-V506EX OPTION1 EC 00000000
OPTION2 C1 00000000
OPTION3 8B 00000000
OPTION4 B1 00000000
OPTION5 30 00000000
OPTION6 08 00000000
HR-V506EY OPTION1 EC 00000000
OPTION2 C1 00000000
OPTION3 8B 00000000
OPTION4 B1 00000000
OPTION5 B0 00000000
OPTION6 08 00000000
HR-V506EL OPTION1 EC 00000000
OPTION2 C1 00000000
OPTION3 8B 00000000
OPTION4 B1 00000000
OPTION5 A0 00000000
OPTION6 08 00000000
HR-V507EX OPTION1 EC 00000000
OPTION2 C1 00000000
OPTION3 8B 00000000
OPTION4 B1 00000000
OPTION5 30 00000000
OPTION6 08 00000000
HR-V507EY OPTION1 EC 00000000
OPTION2 C1 00000000
OPTION3 8B 00000000
OPTION4 B1 00000000
OPTION5 B0 00000000
OPTION6 08 00000000
MODEL NAME HEX BINARY
HR-V507EL OPTION1 EC 00000000
OPTION2 C1 00000000
OPTION3 8B 00000000
OPTION4 B1 00000000
OPTION5 A0 00000000
OPTION6 08 00000000
HR-V200EZ OPTION1 02 00000000
OPTION2 C8 00000000
OPTION3 87 00000000
OPTION4 B7 00000000
OPTION5 00 00000000
OPTION6 30 00000000
HR-V500EZ OPTION1 0C 00000000
OPTION2 C8 00000000
OPTION3 83 00000000
OPTION4 B7 00000000
OPTION5 00 00000000
OPTION6 10 00000000
HR-V505EZ OPTION1 0C 00000000
OPTION2 C8 00000000
OPTION3 8B 00000000
OPTION4 B7 00000000
OPTION5 00 00000000
OPTION6 10 00000000
HR-V205EK OPTION1 02 00000000
OPTION2 C0 00000000
OPTION3 8B 00000000
OPTION4 A4 00000000
OPTION5 00 00000000
OPTION6 03 00000000
HR-V505EK OPTION1 2C 00000000
OPTION2 C0 00000000
OPTION3 8B 00000000
OPTION4 A4 00000000
OPTION5 00 00000000
OPTION6 03 00000000
HR-V205EF OPTION1 62 00000000
OPTION2 C0 00000000
OPTION3 0F 00000000
OPTION4 B0 00000000
OPTION5 62 00000000
OPTION6 00 00000000
HR-V505EF OPTION1 6C 00000000
OPTION2 C0 00000000
OPTION3 0B 00000000
OPTION4 B0 00000000
OPTION5 62 00000000
OPTION6 00 00000000
WR : OK I : EXIT MOVE :
EDIT : 67E
EEPROM option code No. setting EEPROM option code No. setting
8t
