equipment key 7
FRONT PANEL
1STANDBY/ON o Button
turns VCR on/off (loading a
cassette also turns power on).
2Cassette Load ng Slot is
where cassette is inserted;
door closes.
3PR+/- Buttons select a
preset position.
4D splay Panel provides
clear view of various displa s
and indicators.
5Infrared Beam Rece v ng
W ndow is where Remote
Control should be aimed when
in use.
6< Button rewinds
the tape; initiates reverse
picture search.
7> Button fast-
forwards  tape; initiates
forward picture search.
8T Button starts regular
recording (press once), Instant
Timer Recording (press twice);
sets duration of ITR.
9| Button stops tape
temporaril  during recording;
stops tape temporaril  during
pla back; pla s back frame b
frame with each additional
press.
SATc Button enables/
disables the Auto Satellite
Programme Recording mode.
10 § Button stops tape;
ejects tape during Stop mode.
11 . Button pla s back tape;
cancels Pause, Still, Slow,
Search modes.
REAR PANEL
1Ma ns Power Cord
supplies power to VCR.
2SAT CONTROL Connector
enables connection of the
Satellite Controller for timer
recording with a satellite
receiver.
3ANT. IN Connector enables
connection of aerial.
4L-2 IN/DECODER
Connector enables connection
of satellite receiver or second
recorder.
* DECODER function is not available in the
UK.
Diagram Key
REMOTE CONTROL
1TV STANDBY/ON o
Button turns TV on/off.
2TV/VCR Button switches
connected TV’s mode between
TV and AV.
3TV     Button switches TV
input terminal.
4START  + / –  Button
accesses Regular Program
screen; inputs programme
Start Time.
5STOP  + / –  Button inputs
programme Stop Time.
6PDC Button enables/
disables PDC recording.
* VPS (Video Progra e
Syste ) recording is not currently
available in the U.K. and not
possible with this VCR.
7 x Button cancels timer-
programme.
0000 Button resets
counter on the on-screen
displa  to ‘0:00:00’.
8PROG Button accesses
Timer Programming Set
screen.
9C Button accesses
Program screens/displa s to
check the programme that  ou
have programmed (next
programme’s information
screen appears each time
button is pressed).
10 < Button — same as
button on VCR.
11 T Button starts regular
recording (press . the same
time).
12 S Button stops tape.
13 TV PR +/– Buttons select
the connected JVC TV's
channel.
14 rButton
‘reviews’ timer-recorded
programme.
15  Button accesses
Menu screen.
16 STANDBY/ON o Button
— same as button on VCR.
17 AUDIO Button changes
output sound mode.
18 b(D splay) Button
switches displa  between
clock time and Preset
Position* (or Mode).
Preset Position (or Mode) is not
displayed during playback.
19 Number Keys are used in
preset position selection and
the VIDEO Plus+ Timer
Programming.
20 DATE  + / –  Button inputs
date of programme for timer
recording
21 DAILY Button enables
timer recording of dail
serials.
22 WEEKLY Button enables
timer recording of weekl
serials.
23 AUX Button selects VCR’s
auxiliar  input mode.
24 c Button engages timer-
standb  mode.
25 Auto Track ng Button
enables/disables auto
tracking mode during
pla back.
/ Button selects tape
speed.
26 3 Button
initiates a 30-second period of
fast-motion pla back.
27 . Button — same as
button on VCR.
28 > Button — same as
button on VCR.
29 | Button — same as
button on VCR.
30 PR
PR  Buttons are used
for selection in on-screen
menus.
PR  + / –  Buttons select a
preset position.
31 TV   +/– Buttons control
volume of connected JVC TV.
32 D E  Buttons initiate
functions such as Index
Search, variable-speed search,
frame b  frame pla back.
33  Button enters
selections made in on-screen
menus.
 Button — Shows
current VCR status on the TV
screen if O.S.D is set to ON.
6AUDIO OUT (L/R)
Connectors enable connection
of audio cassette recorder, TV
or second VCR for dubbing.
7RF. OUT Connector enables
connection to aerial terminal
of TV receiver.
VCR DISPLAY PANEL
1c Ind cator lights when
the c button has been
pressed to engage Timer
mode.
2Play Ind cator lights up
during pla back; blinks during
Repeat Pla back or when
using Next Function Memor
for pla back.
3Record Ind cator lights up
during recording; blinks
during Instant Timer
Recording.
4Channel D splay shows
preset position where the
station currentl  being
received is stored.
Mode shows external input
mode selected (L-1 or L-2).
Clock D splay shows
current time.
Preset Position* (or Mode)
and Clock Displa  appear
alternatel  when b is
pressed.
* Preset Position (or Mode) is
not displayed during playback.
5REVIEW Ind cator blinks
after timer-recording and
shows how man  programmes
have been timer-recorded.
6SATc Ind cator lights up
during Auto Satellite
Programme Recording
standb  mode; blinks when
Auto Satellite Programme
Recording is in progress.
7VCR Ind cator lights when
the VCR is in the video mode.
At this point, the TV automati-
call  enters AV mode.
5L-1 IN/OUT Connector
enables AV connection to TV
or second VCR.
