JynxBox MINI User manual

1
www.jynxbox.me

2
www.jynxbox.me
JYNXBOX ANDROID MINI TV Stick User Manual
Introduction
JYNXBOX ANDROID MINI Android TV stick is an Android based stick connected to your TV via
an HDMI port that turns your TV to a multifunction smart TV. It is a revolutionary entertainment
device on your TV. It is also anAndroid HD Media player, a miniAndroid PC, and a DLNA
server, a photo viewer, a game player, a music player, a huge size screen e-book/ e-magazine/
e-newspaper reader that provides a very powerful smart TV experience.
Features
ARM Cortex™-A9 CPU, frequency is 1.2GHz
Embedded high-performance Open GL 3D GPU Mali-400
High Capability 1G DDR3 ROM
Built-in 802.11b/g/n Wi-Fi Module
HDMI 1.3 Digital Audio & Video Output
2.4G Wireless QWERTY Remote Control (or IR remote control)
Support USB or 2.4G wireless mouse and keyboard operation
Support flash player 10.2 hardware acceleration
Support up to Full HD 1080P video decoding
High Connectivity for File Sharing
Support Google play store
Support Google Chrome browser
Multi User Interface (optional)
Video format support:
DAT/MPEG/MPE/MPG/M2V/ISO/TS/VOB/AVI/MKV/MP4/MOV/3GP/3GPP/FLC/AVI/WMA/TS/M
2TS/M3TS/M4TS/M5TS/MTS/M4V/FLV/3G2.
Audio format support:
MP3/WMA/WAV/OGG/OGA/FLAC/ALAC/APE/AAC/M4A/AC-3/DTS/RM.

3
www.jynxbox.me
Remote control
Jynx IR remote
[01] Standby (No function currently)
[02] Menu
[03] Up
[04] VOL+
[05] VOL--
[06] Right
[07] Down
[08] Left
[09] OK
[10] Exit
[11] Notification

4
www.jynxbox.me
Start Up
1 Plug in the USB power cable and connect your Jynxbox Mini TV stick to TV via HDMI
port.
2 There are two screens that appear on start-up: the first screen is a robot logo, and the
second is an android text logo.

5
www.jynxbox.me
3. You will get a welcome screen which will prompt the first time user through the setup
steps

6
www.jynxbox.me

7
www.jynxbox.me

8
www.jynxbox.me

9
www.jynxbox.me
4. Click the FINISH button to complete the setup, after which, the main screen will be
displayed as below

10
www.jynxbox.me
5. Click the top right icon which will display all the APPs list

11
www.jynxbox.me
Settings
Settings provide individual preference setting functions.
1. Wi-Fi
It will scan available Wi-Fi networks automatically while clicked “ON” in Wi-Fi setting.
Choose one encrypted Wi-Fi network to connect

12
www.jynxbox.me
2. Data usage
Shows data usage information.

13
www.jynxbox.me
3. More
It includes VPN, Portable hotspot and Proxy settings.
Enable Portable hotspot

14
www.jynxbox.me
Configure Wi-Fi hotspot.
Choose a different security mode to share your network.
Please note that you need to disconnect from Wi-Fi and connect to Ethernet while using the
hotspot function. Wi-Fi and hotspot connections can’t be used simultaneously.
4. Sound
If you enable Touch sounds, you will hear the sound while moving the remote control.

15
www.jynxbox.me
5. Display
Sets wallpaper, output mode, display position and font size.
Output mode
The default resolution is 720P

16
www.jynxbox.me
Display position
Use the Direction keys and the Enter/Ok button on the remote control to adjust the display
position when the screen is not displayed as full screen on your TV.
Font size
Changes the font size of OSD.

17
www.jynxbox.me
6. Storage
Shows the storage used of the OS and SD card.
7. Apps
Lists all apps and their different status.

18
www.jynxbox.me
8. Accounts & sync
Click” ON” to enable accounts & sync.
9. Security
Enabling unknown sources will allow you to install non-market apps.

19
www.jynxbox.me
10.Language & input
Changes OSD language and input method.
The default input method is android standard keyboard.
If you are using our IR remote control, enter into “Default” option and switch to remote
controller input method.
11. Factory reset
Choosing factory reset will erase all user data of the box.

20
www.jynxbox.me
12. Date & Time
Sets the time of the box.
13. Developer options
The android debug bridge (ADB) is supported for android software developers. It can be
used on Ethernet or on Wi-Fi, but it is not enabled by default. The ADB can be turned on
by enabling the USB debugging option in the menu.
