K-array K-CTRL User manual

USER MANUAL - English version
K-CTRL

// CONTENTS
1. INTRODUCTION 5
2. UNPACKING 5
3. INCLUDED ACCESSORIES 6
4. SYMBOLS 6
5. WARRANTY 7
6. GENERAL WARNINGS 7
7. SAFETY INSTRUCTION 7
8. VOLTAGE REQUIREMENTS 9
9. OPERATION 9
9.1 “A” MODE (auto) 9
FRONT PANEL 9
BACK PANEL 9
9.2 “C” Colour Mode 11
9.3 “SLA” DMX Slave Mode 11
9.4 “d” DMX Mode 12
9.5 “P” DMX Preset Mode 12
9.12 Switch on condition 15
9.13 DMX signal condition 15
10. MAINTENANCE 16
11.SERVICE 16
12.SPECIFICATIONS 17
13.STANDARDS 17
14. APPENDIXES 18
APPROVAL 19

5
PRELIMINARY
1.INTRODUCTION
2.UNPACKING
The K-CTRL DMX-controlled 3-Channel
power supply works as the power supply
and DMX function controller for the LED
component of the K-Array KTL22 series of
combined Speaker/Lighting  xtures.
Colourmix, intensity and program operation
mode can all be preset. The K-CTRL can
also operate using an internal microphone
for sound-to-light operation. Any settings
are maintained when power is off and will
return to the last setting when powered on
again. A number of KTL22 series  xtures
can be controlled from a single K-CTRL.
To take full advantage of all the functions
of the K-CTRL and for your own safety and
the safety of your environment, please
read these operating instructions carefully
before you start using the unit.
Each K-array device is built to the highest
standard and thoroughly inspected before
leaving the factory.
Carefully inspect the shipping carton,
then examine and test your new product.
If you  nd any damage immediately notify
the shipping company. Only the consignee
may institute a claim for damages incurred
in shipping. It is suggested that you
retain the original packaging so that the
system can be repacked at a future date
if necessary.
Please note that K-array and its distributors
cannot accept any responsibility for
damage to any returned product through
the use of non-approved packaging.
K-CTRL
RGB LED DMX-controlled
3-Channel power supply

6PRELIMINARY
K-CTRL
3.INCLUDEDACCESSORIES
4.SYMBOLS
MAIN PARTS:
1 pcs. PS020A main unit
1 pcs. mains cable
1 pcs. operation manual
ACCESSORIES PARTS:
1 pcs. Mounting cover
2 pcs. Mounting screw
1 pcs. connection cable to panel
This symbol, wherever it appears,
alerts you to important operating
and maintenance instructions in the
accompanying literature.
Read the manual!
Separate collection of electrical and
electronic devices. For information about
the disposal of Waste Electrical and
Electronic Equipment (WEEE), please
refer to the website at www.scanning.
datalogic.com
Warning! Dangerous voltages:
RISK of electric shock.
The item meets all the essential “Health
and Safety” requirements of the revelant
European Directives.
This device complies with Restriction of
Hazardous Substances Directive.
This symbol alerts the user to
recommendations about the
product’s use and maintenance.

7
PRELIMINARY
K-CTRL
5.WARRANTY
6.GENERALWARNINGS
K-array systems are warranted against manufacturing defects in materials or
craftsmanship as determined by the distributor. During the warranty period K-array will,
at it’s discretion, either repair or replace products which prove to be defective provided
that the product is returned in its original packaging, shipping prepaid, to an authorized
K-array service agent or distributor. K-array cannot be held responsible for defects caused
by unauthorized modications, improper use, negligence, exposure to inclement weather
conditions, act of God or accident, or any use of this product that is not in accordance with
the instructions provided by K-array. K-array is not liable for consequential damages. This
warranty is exclusive and no other warranty is expressed or implied. This warranty does
not affect your statutory rights.
7.SAFETYINSTRUCTION
• Do not connect the AC power plug to the
unit before assembly has been completed.
• Only connect this unit to a mains socket
outlet with protective earth connection,
ground-fault (earth-fault) protection and
overload protection.
• Do not install the power supply in wet or
humid locations without using weather
protection.
• Do not allow water or any foreign object to
get inside the device. Do not put objects
containing liquid on, or near, the unit.
• To reduce the risk of overheating the
device, avoid exposing it to direct sunlight.
Do not install the unit near heat emitting
appliances, such as a room heater or stove.
• No naked ame sources such as lighted
candles should be placed on the device.
• To pull the AC Cord out of the wall outlet or
the unit’s AC socket, never pull the cable
itself, but only the AC plug.
• Disconnect the unit from AC supply by
pulling the AC plug out of the wall outlet
or the unit’s AC socket before any kind
• Read this manual completely before using
the product.
• Keep this manual in your records for future
reference.
• Take care of enough distance between
this product and sources of hum and noise
like electric motors and transformers.
• Carry this product with greatest care. Being
dropped or subjected to heavy vibration
may damage this product mechanically.
• The manufacturer takes no responsibility
for injury or damage caused by not
following the safety precautions and
instructions printed in this manual.
• Follow all printed security advice on the
product itself. The lightning ash with
arrowhead within an equilateral triangle
makes you aware of non-insulated
AC mains voltage inside the unit. The
exclamation mark within an equilateral
triangle makes you aware of important
operating and maintenance instructions in
the literature attached to this product.

8PRELIMINARY
K-CTRL
of cleaning on the product. Use smooth
and dry cloth only for cleaning. Check all
connection cables before reconnecting the
unit.
• Where the mains plug or an appliance
coupler is used as a dis-connect device,
the disconnect device shall remain readily
operable.
• Choose the position of the AC cord
according to the lowest risk of damage by
footsteps or from being squeezed. Take
specially care of the AC cord outlet on the
unit as well as the AC plug and wall outlet at
the other end of the cable.
• Do not open the unit for service. There are
no user-serviceable parts inside. Warranty
will be void in any case of unauthorized
service by the user or other non-authorized
persons.
• Maintain sufcient air convection in the
unit’s environment to avoid overheating,
especially when mounting in an enclosed
area. Make sure that the air convection slots
are not blocked. Do not operate this unit in
environmental temperatures exceeding 40
degrees Celsius.
• Do not operate the K-CTRL power supply
in any closed environment smaller than
10cbm, unless forced air convection is
provided.
• Do not operate the K-CTRL power supply
in any position inclined or reclined more
than 45 degrees from being upright with
the heatsink on top.
• Never use any accessories or modications
not authorized by the manufacturer of this
unit.
• Choose a location for operation where the
unit is protected from vibration and where a
xed mounting position is provided. In case
of overhead mounting, follow appropriate
rigging rules and your country’s regulations
for rigging safety. See appendixes if any.
• If uids have spilled into the unit or small
parts have intruded the unit, immediately
switch off the unit and hand it over to the
authorized service for a security check.
• Disconnect the unit from AC supply by
pulling the AC plug out of the wall outlet or
the unit’s AC socket during a thunder-storm
in order to avoid any damage on the unit
due to AC voltage peaks.
• In the event of malfunction of this unit or
damaged AC cord or other damaged parts,
pull immediately the AC plug out of the
wall outlet and hand the unit over to the
authorized service for a security check.
• To meet all aspects of functionality and
security during maintenance work to be
preformed on this unit, all parts should be
replaced by genuine spare parts. Ensure
that your dealer or maintenance company
is authorized by the manufacturer.
• Never use any accessories or modications
not authorized by the manufacturer of this
unit.
• Do not open the unit for service purpose,
as there are no user-serviceable parts
inside. Warranty will be void in any case of
unauthorized service by the user or other
not authorized persons.
• This unit produces and absorbs
electromagnetic radiation. The strength of
radiation and the sensitivity for disturbing
interference matches the CE and FCC
requirements. A corresponding sign is
printed on the back of the unit. Any change or
modication may affect the behavior of the
unit concerning electromagnetic radiation,
with the CE requirements eventually not to
be met any more. The manufacturer takes
no responsibility in this case.

9
PRELIMINARY
K-CTRL
8.VOLTAGEREQUIREMENTS FRONTPANEL
BACKPANEL
9.OPERATION
9.1“A”MODE(auto)
K-CTRL operates safely and without audio
discontinuity if the AC voltage stays within
a operating window from 90 V to 260 V.
Check the voltage before connecting the
ampli er to the AC power.
A higher voltage could seriously damage
the device.
1. In A-Mode: Speed Control (except A1 = Mix Control)
In C-Mode: Level Control
2. Display showing the Mode, DMX-address, LOC-function etc.
3. Indicates presence of a DMX signal
4. Indicates the sound-activated mode (internal microphone)
5. MODE selection button
6. UP-button
7. DOWN-button
8. LED power output
9. Power-Input 90-250V AC
10. Power-Output 90-250V AC (max 19A)
11. Input audio signal selector (Internal Mic./ External line)
12. Input audio signal connector
13. Internal microphone
14. DMX Input connector
15. DMX Output connector
16. Switches on the termination for the last unit in the DMX-chain
17. Switching the display on or off (with delay)
18. Maintenance (not in use)
The K-CTRL DMX-controlled 3-Channel
power supply supplies the necessary
power to the LED elements in the KTL22
series product range, plus provides all
necessary functional control.
Upon the user’s choice, the unit can
work stand-alone or may be controlled by
external DMX-controllers.
Press the MODE button (5) until the  rst
digit on the display shows “A”, indicating
operation in “A” (AUTO) mode. Then
choose your desired pattern by using the
UP/DOWN buttons (6/7). (see list below).
Changing the setting becomes effective
1 second after the new setting is made
to allow stepping through presets without
previewing all intermediate presets.
NOTE: The “A” Mode is automatically
disabled and cannot be chosen when an
external DMX signal is received [DMX
indicator LED (3) is lit].
When in pattern A 1 (static scene), turning
knob (1) determines the mix, whereas
1
2
8 9
11
13
17
16
18
10
14 15
12
67
34
5

10 PRELIMINARY
K-CTRL
being in one of the other 26 patterns,
knob (1) controls the speed or selects the
sound-activated function (refer to pattern
list below). The sound-activated function
can be activated by setting the knob (1)
inside the rst 10 degrees of its travel from
left detent. In this setting it works from a
built-in microphone (8) which picks up
the environmental sound. Its activity is
shown by the ashing of the right dot (4)
in the display. The level for all patterns is
maximum.
Description FunctionofKnob(1)
A0 All off None
A1 Static scene Mix
A2 Soft fade Out1-Out2 Speed
A3 Soft fade Out2-Out3 Speed
A4 Soft fade Out1-Out3 Speed
A5 Soft fade Out1-MixA Speed
A6 Soft fade MixB-MixC Speed
A7 Soft fade MixD-MixE Speed
A8 Soft fade MixF-MixG Speed
A9 Soft fade Out1-Out2-Out3 (RGB) Speed
A10 Hard switch Out1-Out2 Sound-activation, Speed
A11 Hard switch Out2-Out3 Sound-activation, Speed
A12 Hard switch Out1-Out3 Sound-activation, Speed
A13 Hard switch Out1-MixA Sound-activation, Speed
A14 Hard switch MixB-MixC Sound-activation, Speed
A15 Hard switch MixD-MixE Sound-activation, Speed
A16 Hard switch MixF-MixG Sound-activation, Speed
A17 Hard switch Out1-Out2-Out3 Sound-activation, Speed
A18 Hard switch Out1-MixA-Out2-MixB-Out3-MixC Sound-activation, Speed
A19 Random speed Out1-MixA None
A20 Random speed Out2-Out3 None
A21 Random speed Out1-Out3 None
A22 Random speed Out1-Out2-Out3 None
A23 All outputs tacted Sound-activation, Speed
A24 Out1 tacted Sound-activation, Speed
A25 Out2 tacted Sound-activation, Speed
A26 Out3 tacted Sound-activation, Speed
A27 Out1-Out2-Out3 chaser tacted Sound-activation, Speed
In “A” mode, the unit does not receive any
values from the DMX input, but generates
related DMX values on the output
according to the selected pattern, so that
other similar units from the Multiform LS
series can show the same pattern if they
are connected by DMX signal cables and
set to Slave Mode “SLA”.
If you leave mode “A” for any reason and
come back later into mode “A”, the unit will
recall the last chosen pattern (even if the
unit was switched off in between).
Pattern list:

11
PRELIMINARY
K-CTRL
9.2“C”ColourMode
9.3“SLA”DMXSlaveMode
Press the MODE button (5) until the rst
digit on the display shows “C”, indicating
operation in “C” mode. Then choose one
of the 19 presets as shown in the list below
by using the UP/DOWN buttons (6/7).
Changing the setting becomes effective
directly. Knob (1) determines the output
level.
In “C” mode, the unit does not receive any
values from the DMX input but generates
related DMX values on the output
according to the selected pattern, so that
Press the MODE button (5) until the
display shows “SLA”, indicating operation
in “SLA” (SLAVE) mode. In this mode the
unit is set to DMX-channel 001 in order
to receive the signals from a master unit
of the Multiform LS series being in mode
“A” or “C”. The unit interprets CH1 as
Out1 level, CH2 as Out2 level and CH3
as Out3 level. CH4 is not in use, and the
potentiometer (1) is disabled.
C0 all off C10 MixG
C1 Out1 C11 MixH
C2 Out2 C12 MixI
C3 Out3 C13 MixJ
C4 MixA C14 MixK
C5 MixB C15 MixL
C6 MixC C16 MixM
C7 MixD C17 MixN
C8 MixE C18 MixO
C9 MixF C19 All outputs full on
other similar units from the Multiform LS
series can show the same behaviour if
they are connected by DMX signal cables
and set to Slave Mode “SLA”.
NOTE: The “C” Mode is automatically
disabled and cannot be chosen when an
external DMX signal is received [DMX
indicator LED (3) is lit].
If you leave mode “C” for any reason and
come back later into mode “C”, the unit will
recall the last chosen mix (even if the unit
was switched off in between).
Available colour presets:
similar units from the Multiform LS series
can show the same behaviour if they are
connected by DMX signal cables and set
to Slave Mode “SLA”.
NOTE: The “C” Mode is automatically
disabled and cannot be chosen when an
external DMX signal is received [DMX
indicator LED (3) is lit].
If you leave mode “SLA” for any reason
and come back later into mode “C”, the

12 PRELIMINARY
K-CTRL
9.4“d”DMXMode
9.5“P”DMXPresetMode
Press the MODE button (5) until the
display shows “d”, indicating operation in
“d” (DMX) mode. Shortly after that, the
display shows the DMX starting address.
You can choose any DMX starting
address by simply using the UP/DOWN
buttons (6/7). The chosen DMX-address
comes effective approximately 3 seconds
later and will show up on the display (2) in
alternation to the “d”. This allows control
Addressing has to be done as follows:
001 rst device (CH 1-4) *factory default*
005 second device (CH 5-8)
009 third device (CH 9-12)
013 fourth device (CH 13-16) and so on.
DMXchannel ValueRange Function
CH1 000-255 Out1 level
CH2 000-255 Out2 level
CH3 000-255 Out3 level
CH4 000-127 Master level
128-227 Tact (128=slow / 227=max. speed 23 Hz)
228-255 Master level full on, Tact off
of the unit by any external DMX signal
sending on the chosen channel.
In this mode the potentiometer (1) is
disabled.
The unit receives DMX values on a packet
of four channels and mirrors the received
data on the DMX output (13). If a DMX
signal is present the DMX LED (3) will turn
on. The four channels control the unit as
follows:
If you want to run the pre-programmed
patterns and scenes by an external DMX-
controller you can use the DMX Preset
Mode. Press the MODE button (5) until
the display shows “P”, indicating operation
in “P” (DMX Preset) mode. Set the DMX
starting address by simply using the UP/
DOWN buttons (6/7). The chosen DMX-
unit will recall the last chosen mix (even if the unit was switched off in between).
This mode can also be used for remotely controlling the unit if no specic DMX address
is needed and channels 001-003 can serve as a default. To indicate that the unit is
controlled by an external DMX signal, the DMX LED (3) is lit.
This setting is stored even if the device is switched off.

13
PRELIMINARY
K-CTRL
DMX ValueRange Function
CH2 000-255 Level
CH3 050-255 Chase speed
CH4 000-049 Tact off
050-255 Tact (050=slow / 255=max. speed 23 Hz)
DMXchannel ValueRange Function
CH1 000-255 Output mix choice from presets (see “C” mode)
CH2 000-255 Master level
CH3 000-049 Static mix mode active
CH4 000-049 Tact off
050-255 Tact (050=slow / 255=max. speed 23 Hz)
If DMX value of channel 3 is equal or upper than 50the unit works in pattern mode:
Output mix presets can be activated by means of CH1 whilst the chosen mix can be
adjusted with CH2. If the value of CH4 is above 50 the unit is set to tact mode. The tact
speed for any xed output mix chosen on the rst channel can be adjusted from zero
(value <50) to 23 cycles per second (value 255).
CH1 Pattern CH1 Pattern
000-015 Soft fade Out1-Out2 136-150 Hard switch Out2-Out3
016-030 Soft fade Out2-Out3 151-165 Hard switch Out1-Out3
031-045 Soft fade Out1-Out3 166-180 Hard switch Out1-MixA
046-060 Soft fade Out1-MixA 181-195 Hard switch MixB-MixC
061-075 Soft fade MixB-MixC 196-210 Hard switch MixD-MixE
076-090 Soft fade MixD-MixE 211-225 Hard switch MixF-MixG
091-105 Soft fade MixF-MixG 226-240 Hard switch Out1-Out2-Out3
106-120 Soft fade Out1-Out2-Out3 241-255 Hard switch Out1-MixA-Out2
121-135 Hard switch Out1-Out2 -MixB-Out3-MixC
address comes effective approximately 3 seconds later and will show up on the display
(2) in alternation to the “P”.
The unit receives DMX values on a packet of four channels and mirrors the received data
on the DMX output (13). If a DMX signal is present the DMX LED (3) will turn on. The four
channels control the unit as follows:
If DMX-value of channel 3 is lower than 50 the unit works with static colours:

14 PRELIMINARY
K-CTRL
The pre-programmed soft fade or hard
switching patterns can be chosen by
means of CH1 whilst CH2 is used as a
level channel. CH3 allows to set the fade
time or pattern speed from slow (value
50) to very fast (value 255). If channel 4
reaches a DMX value of 50 or above a
tact function will be added to the chases.
The tact speed can be adjusted from slow
(value 50) to 23 pulses per second (value
255).
In this mode the potentiometer (1) is
disabled.
Note:
Whether the unit works in static mix
modeorpatternmodedependsonthe
value of channel 3. Set the value of
channel3below50tobeinstaticmix
mode.Otherwiseyouwillbeinpattern
mode.
Addressing has to be done as follows:
001 rst device (CH 1-4) *factory default*
005 second device (CH 5-8)
009 third device (CH 9-12)
013 fourth device (CH 13-16) and so on.
This setting is stored even if the device is
switched off.
9.6Displayon/off 9.10Keylock
If you wish the display to be lit only when
a change in operation is made, the DIP
switch (17) should be in the position off.
Now if any of the buttons is not pressed
for more than approximately 25 seconds
the display is switched off. As soon as
one of the buttons is pressed again, the
display switches on immediately. In this
case the rst touch of the button is ignored
in respect to the normal function of that
button.
Pressing the MODE button (5) for longer
than 3 seconds locks all the buttons (5-
7) and the potentiometer (1). The display
shows “LOC” in alteration to the mode
(changing every 2 seconds). Pressing
the MODE button again for more than
3 seconds unlocks the button and
potentiometer functions. Please note:
If the display is in OFF-mode it will take
approximately 25 seconds before the
display switches off. It will be switched on
again if any key is touched and will switch
off again after 25 seconds if the keys are
not unlocked by the procedure mentioned
above.

15
PRELIMINARY
K-CTRL
9.11Termination 9.12Switchoncondition
9.12Maintenance(bootloader)
9.13DMXsignalcondition
9.14DMXsignalcondition
To avoid interference the last unit of a DMX-
chain should be terminated. Therefore the
DIP switch (9) of the last unit in the DMX-
chain must be switched ON.
The unit always returns to the last mode
before it was switched off. In DMX Slave
“SLA” or DMX Mode “d” or DMX Preset
Mode “P” all DMX values are cleared if
power is switched off.
The Maintenance (boot loader) function
enables the unit to receive rmware
updates via the DMX connectors. For
further information refer to our website and
check “Download”.
The device will retain the status that it
was in before the DMX signal got lost, but
potential tact settings will be automatically
cleared.
MODE>
DMX A C P (CH3<50)
P
(CH3>50) D SLA
CH1 Out1 Out1 Mix Pattern Out1 Out1
CH2 Out2 Out2 Level Level Out2 Out2
CH3 Out3 Out3 0-49 Speed Out3 Out3
CH4 0 0 Tact Tact Level/Tact 0

16 PRELIMINARY
K-CTRL
Cleaning:
• Clean the product enclosures using a soft, dry cloth only.
• Do not use any solvents, chemicals, or cleaning solutions
containing alcohol, ammonia, or abrasives.
• Do not use any sprays near the product or allow liquids to
spill into any openings.
To obtain service:
1) Contact the ofcial K-array distributor
in your country. They will direct you to the
service centre.
2) If you are calling for service, have the
serial number(s) of the unit(s) at hand
for reference. Ask for Customer Service,
and be prepared to describe the problem
clearly and completely.
3) If the problem cannot be resolved over
the phone, you must return the unit for
service.
11.SERVICE
10.MAINTENANCE
This unit does not need regular
maintenance. The internal circuit is
protected by a 250V/2A slow-blow fuse
5x20mm fuse. IIf this fuse fails, this
usually indicates an internal fault requiring
servicing by a qualied engineer. The fuse
shall only be replaced by a fuse of the
same specication, and the replacement
has to be made by qualied personnel
obeying applicable safety rules.
4) You will be given an RA (Return
Authorization) number for job tracking.
Refer to this number on shipping materials
and in all correspondence concerning
the repair. Shipping charges are the
responsibility of the purchaser.
Any attempt to modify or replace
components of the device will
invalidateyourwarranty.Servicemust
beperformedbyanauthorizedK-array
servicecenter.

17
PRELIMINARY
K-CTRL
12.SPECIFICATIONS
13.STANDARDS
Mains Input……………………………………………………………. AC90-250V~ 50/60Hz
Type………………………………………………………………..switch mode power supply
Power Consumption…………………………………………………………………max. 45W
Fuse………………………………………………….250V 2A T (slow blow, 5x20mm glass)
Sound control………………...…internal microphone with Automatic Gain Control (AGC)
DMX connections…………………………………………………3 pin XLR (Male / Female)
Modulation Type…………………….…………….Advanced Bit Angle Modulation (ABAM)
Control protocol.......................................................................................DMX 512 (1990)
Output....................................8-pole connector with 3 outputs 24V DC & 3 sensing lines
Max. Load..........................total 1600mA (Out 1: 450mA, Out 2: 570mA, Out 3: 580 mA)
Dimensions………………………………………………………..W 135 x H 109 x D 38 mm
Weight …………………………………………………………………………………….0,6 kg
This product complies with the following standards:
EU safety...........................................................................................EN 60065:2001 +A1
EU EMC..................................................................................................EN61204-3:2001
EU Harmonics ...................................................................................EN61000-3-2:2001
EU Flicker ………………………………………………………………….EN61000-3-3:1995
US safety ………….…………..………………………………………………………UL60065
US EMC………………………..…………………………………………………..FCC Part 15
This product meets both the EMC Directive 2004/108/EC and the Low Voltage Directive
2006/95/EC.

18 PRELIMINARY
K-CTRL
• The unit should be installed out of reach of people and outside areas where
persons may walk by or be seated.
• Make sure that the installation area can hold a minimum point load of 10 times the
device’s weight.
• In xed installations, x the unit with self-locking screws/nuts to the mounting point.
• When mounting the unit to truss be sure to secure an appropriately rated clamp to
the hanging yoke using a M10 screw tted through the center hole of the hanging yoke.
• Always use a certied safety cable that can hold 12 times the weight of the device
when installing the unit. This secondary safety attachment should be installed in a way
that no part of the installation can drop more than 20cm if the main attachment fails.
• Never stand directly below the device when mounting, removing, or servicing the
xture. Make sure the area below the installation place is free from unwanted persons
during rigging, de-rigging and servicing.
• The operator has to make sure that the safety-relating and machine-technical
installations are approved by an expert before using them for the rst time. The installations
should be inspected every year by a skilled person to be sure that safety is still granted.
A. Safety rules for overhead rigging:
14.APPENDIXES
 Risk of injury: Overhead mounting requires extensive
experience, including among others calculating working
load limits, good knowledge of the installation material
beingused,andperiodicsafetyinspectionofallinstallation
materialandtheunit.Ifyoulacksuchqualications,donot
attempttheinstallationyourself. Improperinstallation can
result in body injury. Be sure to complete all rigging and
installationproceduresbeforeapplyingpowertotheunit.

19
PRELIMINARY
K-CTRL
APPROVAL
WEEE
Please dispose of this product at the end of its operational lifetime
by bringing it to your local collection point or recycling centre for
such equipment.
K-array declares that this device is in compliance with the
applicable CE standards and regulations.
Before putting the device into operation, please observe the
respective country-specic regulations!
The contents of this manual are furnished for informational purpose only. Hp Sound
Equipment s.r.l. assumes no responsability for any errors or inaccuracies that may
appear in this manual.
Hp Sound Equipment s.r.l. reserves the right to make modications without prior notice.

UMC019ENA
*UMC019ENA*
UMC019AA01ENA
k-array is a brand of
HPSoundEquipments.r.l.
Viale Roma 7/i - 50037
San Piero a Sieve (Firenze) - Italy
tel. [phone] - fax. [phone]
e-mail: [e-mail]
www.k-array.com
