K-array KZ12 User manual

KZ12 Ver. 2.2
KZ12
USER GUIDE
English

KZ12 Ver. 2.2
2
SYMBOLS ................................................................................ 3
1. INTRODUCTION ..................................................................... 4
2. KEY fEaTURES ...................................................................... 4
3. aPPLICaTIONS....................................................................... 4
4. SafETY INfORMaTION............................................................ 5
5. UNPaCKING ......................................................................... 6
6. PaCKaGING .......................................................................... 6
7. PRODUCT ............................................................................ 7
8. wIRING ................................................................................ 8
9. INSTaLLaTION....................................................................... 9
10. SERVICE ............................................................................10
11. TECHNICaL SPECIfICaTIONS................................................... 11
TaBLE Of CONTENTS

KZ12 Ver. 2.2
3
SYMBOLS
This symbol alerts the user to the presence of recommendations about
product’s use and maintenance.
This symbol alerts the user to the presence of recommendations about the
product’s use and maintenance.
K-array declares that this device is in compliance with applicable CE
standards and regulations. Before putting the device into operation, please
observe the respective country-specific regulations!
Waste Electrical and Electronic Equipment (WEEE)
Please dispose of this product at the end of its operational lifetime by bringing
it to your local collection point or recycling center for such equipment.
This device complies with the Restriction of Hazardous Substances Directive.
Warning: DANGEROUS VOLTAGE.
Terminals marked with this symbol carry a risk of electric shock, therefore
external wiring connected to these terminals requires installation by a
qualified professional or the use of ready-made leads or cords.

KZ12 Ver. 2.2
4
1. INTRODUCTION
2. KEY fEaTURES
3. aPPLICaTIONS
The KZ12 is a remarkable, ultra-micro line array designed for discreet use in a variety of situations, such
as restaurants, bars, and museums.
This rugged unit contains a line array of four 0.5” excursion, full-range drivers housed in a sleek case
built around a super strong chassis. The high efficiency drive units have Neodymium magnet structures
and suspensions engineered for maximum linear excursion and minimum residual transducer noise.
This miniature, slim column is a mere 1.2cm deep and delivers true crystal clear audio with an amazing
continuous output of 92dB which is remarkable from such a miniscule enclosure. The KZ12 weighs only
46g and measures 2.1 x 10.0 x 1.2cm (0.8”x 3.9”x 0.5”).
The system delivers long throw and coherent coverage making it ideal for use in space-constrained
situations. Up to four KZ12 units can be integrated with the KU36 sub bass, extending the frequency
range to 35Hz.
All the components are designed inhouse at our Florence-based R&D department. They are custom
manufactured to our exacting standards and quality control.
• Multiple 0.5” long excursion full range drivers
• Wide range frequency response
• Integrated connector
• Ultra-strong, aluminium frame
• High dynamic range capability
• Only 46g of weight
• Suitable for outdoor installations: IP54 water proof
• Background music systems in restaurants and clubs
• Exhibit audio for museum displays
• Space-sensitive fill for broadcast

KZ12 Ver. 2.2
5
4. SafETY INfORMaTION
Warning: Failure to follow these safety instructions could result in injury
or damage to the device or other property.
IMPORTANT SAFETY INSTRUCTIONS
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions and keep all warnings.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or
sold with the apparatus.
• When a cart is used, use caution when moving the cart/apparatus combination to avoid
injury from tipover.
• Avoiding hearing damage. Professional loudspeakers are capable of producing extremely high sound
levels and should be used carefully. Never stand close to loudspeakers driven at high volume. Set the
volume to a safe level. You can adapt to a higher volume of sound that over time may sound normal
but can be damaging to your hearing. Hearing loss worsens after exposure to a sound level of 90
dB or over for an extended period of time. If you experience ringing in your ears or muffled speech,
stop listening and have your hearing checked. The louder the volume, the less time is required before
your hearing could be affected.
• Choking Hazards. This device contains small parts, which may present a choking hazard to small
children. Keep the device and its accessories away from small children.
• Do not make repairs yourself. Never attempt to disassemble, repair or modify the system yourself.
Disassembling the unit may cause damage that is not covered by the warranty. The device contains
no user-serviceable parts. Repairs should only be performed by factory trained service personnel.
• Sound distortion. Do not operate speakers for an extended period of time with sound distortion. This
is an indication of malfunction, which in turn can generate heat and result in a fire.
• Carrying, handling and installing the device. The device contains sensitive components. Do not
drop, disassemble, open, crush, bend, deform, puncture, shred, incinerate or paint the device nor
insert foreign objects into it. If your device has been dropped or damaged, unplug the power cable
immediately.
• Setup. Set up your device on a stable, horizontal surface. If combined or mechanically connected with
other products, always verify the stability of the resulting system. Install the unit only in a location
that can structurally support the weight of the unit and far away from interference with the stability
of the system. Ensure the wind does not interfere with the system’s stability, using extra securities
such as chains, weights, ropes or any other certified anchoring systems. Otherwise a unit could fall,
causing property damage, personal injury or even death. The system should only be suspended by
qualified personnel following safe rigging practices. Securing fixtures to the building structure are
vital. To clarify any doubts, seek help from architects, structural engineers or other specialists.

KZ12 Ver. 2.2
6
5. UNPaCKING
Each K-array speaker is built to the highest standard and thoroughly inspected before leaving the
factory. Upon arrival, carefully inspect the shipping carton, then examine and test your new amplifier.
If you find any damage, immediately notify the shipping company. Only the consignee may institute a
claim procedure regarding the system’s electronic equipment.
6. PaCKaGING
1 x KZ12 2 x steel wall brackets 1 x double-sided
reinformcement adhesive
4 x M3 inox screws 4 x M2 inox washers
4 x M2 nylon screws
2 x copper tabs

KZ12 Ver. 2.2
7
Weight
45.5 g (1.6 lbs)
7. PHYSICaL OVERVIEw
3,9in
100mm
0,5in
11,5mm
0,6in
16mm
0,8in
21mm

KZ12 Ver. 2.2
8
8. wIRING
There are two ways to connect a KZ12 to an amplifier’s output channel:
NOTE:
The KZ12’s impedance is 16Ω. An amplifier channel with an output impedance
of 4Ωcan drive up to 4 KZ12 wired in parallel.
You can solder the cables directly on
terminals IN+ and IN-
You can solder the cables on the provided
copper tabs and then fix them to the speaker
with the provided nylon screws.

KZ12 Ver. 2.2
9
9. INSTaLLaTION
The KZ12 can be mounted on the wall, to the ceiling or even on a table with the provided wall brackets.
Depending on the installation, you can choose beetween two mounting options:

KZ12 Ver. 2.2
10
10. SERVICE
To obtain service:
1) Contact the official K-array distributor in your country. Your local distributor will direct you to the
appropriate service center.
2) If you are calling for service, please have the serial number(s) of the unit(s) available for reference.
Ask for Customer Service and be prepared to describe the problem clearly and completely.
3) If the problem cannot be resolved over the phone, you may be required to send the unit in for
service. In this instance, you will be provided with an RA (Return Authorization) number which should
be included on all shipping documents and correspondence regarding the repair. Shipping charges are
the responsibility of the purchaser.
Any attempt to modify or replace components of the device will invalidate your warranty. Service must
be performed by an authorized K-array service center.
Cleaning:
Use only a soft, dry cloth to clean the device. Do not use any solvents, chemicals, or cleaning
solutions containing alcohol, ammonia, or abrasives. Do not use any sprays near the product or
allow liquids to spill into any openings.

KZ12 Ver. 2.2
11
11. TECHNICaL SPECIfICaTIONS
The contents of this manual are furnished for informational purposes only. K-array s.u.r.l. assumes no responsibility for any errors or inaccuracies that may
appear in this manual. K-array s.u.r.l. reserves the right to make modifications without prior notice.
ACOUSTICS
Power handling 8 W (AES)
Max power 15W (1)
Frequency range 250 Hz – 18 kHz +/- 3dB (2)
Impedance 16 Ω
SPL 1W/1mt 82 dB (3)
Maximum SPL 92 dB (cont.) – 98dB (peak) (4)
COVERAGE
Horizontal 140°
Vertical 20°
CROSSOVER
Type External Crossover required
Frequency 250 Hz, 24 dB/oct
suggested minimum
TRANSDUCERS
Full-range 4 x 0.5“ cone driver with 0.5“ voice coil
POWER AUDIO INPUT
Connector IN+ IN- (to be soldered or screwed)
RECOMMENDED AMPLIFIERS
Type KA24, KMT12 (up to 4 units per channel)
CERTIFICATION
IP 54
PHYSICAL
Dimensions 2.1 x 10.0 x 1.2 cm
(0.8”x 3.9”x 0.5”)
Weight 45.5 g (0.10 lbs)
Notes for data
1. Maximum RMS applicable power for a musical signal. The reference signal is the one proposed by EIAJ
standard
2. With dedicated preset
3. Measured @4m then scaled @ 1m
4. Measured with musical signal
New materials and designs are introduced into existing products without prior notice. Present systems may
differ in some respects from those presented in this catalogue.

KZ12 Ver. 2.2
12
12. CERTIfICaTION
K-array s.r.l. a socio unico società soggetta alla attività di direzione e coordinamento di HP Sound Equipment spa
P. IVA / VAT / CF 06206990480 -R.E.A. 609589 Cap. soc. i.v. € 100.000,00
Sede legale: via Paolina Romagnoli 50038 Scarperia e San Piero -Firenze -ITALYtel [phone] fax [phone] [e-mail] www.k-array.com
DECLARATION OF CONFORMITY
Manufacturer/Importer: K-array s.u.r.l.
Brand: K-ARRAY
Address: via Paolina Romagnoli 17 50038 Scarperia e S. Piero –Firenze -ITALY
Date of Issue: 20 /01 /2015
Model(s) Code: KZ10 –KZ10W –KZ12 –KZ12W
Declaration: Complies with safety essential requirements of Council Directive
2004/108/EC on the approximation of the Laws of the Member States relating to
electromagnetic compatibility.
2006/95/EC on the harmonisation of the laws of member state relating equipment
designed for the use within certain voltage limits
This declaration applies to all specimens manufactured in accordance with the attached
manufacturing drawings which form part of this declaration. Assessment of compliance
of the product with the requirements relating to electromagnetic compatibility and low
voltage directive was based on the following standards:
EMC:
EN 55103-1:2009
EN 55103-2:2009
EN 61000-3-2:2006+A1+A2
EN 61000-3-3:2008
Safety:
EN 60065:2002+A1+A11+A2+A12
Marking:
Applying Year: 2015
Applied by: K-array s.u.r.l.
Via Paolina Romagnoli 17
50038 Scarperia e S. Piero
Firenze -Italy
Tel. [phone]
Fax [phone]
Signed by: Franco Spataro
Technical Manager
