K-array Redline KMT12 User manual

KMT12/KMT18
USER’S MANUAL
English

KMT12/KMT18
REV. A REV. A
2
KMT12/KMT18
3
CONTENTS
SYMBOLS 5
1. INTRODUCTION 7
2. APPLICATIONS 7
3. KEY FEATURES 7
4. UNPACKING 8
5. WARRANTY 8
6. SAFETY 8
7. PHYSICAL 9
8. AMPLIFIER 11
8.1 AC POWER CONNECTOR 11
8.2 VOLTAGE REQUIREMENT 11
8.3 CURRENT REQUIREMENT 11
8.4 REAR PANEL 12
8.5 Touch screen functions 14
8.6 AUDIO INPUT CONNECTOR WIRING 15
8.7 AMPLIFICATION AND PROTECTION CIRCUITRY 15
9. K-Framework 16
9.1 System requirements 16
9.2 Installation and set up 16
10. SERVICE 23
11. SPECIFICATIONS 24

KMT12/KMT18
REV. A REV. A
4
KMT12/KMT18
5
This symbol alerts the user to the presence of recommendations about product’s use and
maintenance.
This symbol, wherever it appears, alerts you to important operating and maintenance
instructions in the accompanying literature. Read the manual!
Warning! Dangerous voltages: RISK of electric shock.
K-array declares that this device is in compliance with the applicable CE standards and
regulations. Before putting the device into operation, please observe the respective
country-specic regulations!
WEEE
Please dispose of this product at the end of its operational lifetime by bringing it to your local
collection point or recycling centre for such equipment.
This device complies with Restriction of Hazardous Substances Directive.
SYMBOLS

KMT12/KMT18
REV. A REV. A
6
KMT12/KMT18
7
1. INTRODUCTION
The new K-array KMT12 and KMT18 are much more than standard powered subwoofers.
They are full-featured audio systems, with analog and digital multiple inputs and outputs, a powerful DSP on board
and a memory to store up to 40 congurations of settings.
An integrated touch screen provides intuitive managing and editing of the main DSP functions: input and output
levels, In/Out routing, speakon output delay (up to 12 ms.), subwoofer delay (up to 12 ms.) and overall system
delay (up to 330 ms.).
All DSP functions, including EQ can be controlled with remote managing software via USB or RS485, again
conveniently on a standard XLR.
The amplier mounted on board is class D, delivering 2 x 1050 W at 8Ω with a max THD of 1% (EIAJ test @ 1KHz).
One of the two amplifying channels is dedicated to an output Speakon to connect to many kinds of speaker
congurations, including single mid-high modules (KK52, KK102), multiple line arrays, or the passive version of
an additional subwoofer module (KMT12P or KMT18P).
The rear panel provides input for two balanced line signals and digital signals in AES/EBU protocol, also on an
XLR for ease of cabling.
There are 40 available DSP preset slots, 8 of them are specically made by K-array to optimize the system
performance of possible device congurations. In addition the user can also create, save, and store his/her own
personal presets in the remaining 32 slots on KMT module using the K-framework software.
The unique four-corner port conguration gives symmetrical back loading to the speaker for extended bass
response with very low distortion. This also gives incredible structural strength to the cabinet despite its light
weight.
Pocket handles and an M20 thread mount position for attaching mid-high speakers makes the KMT convenient to
use and ideal for medium throw applications in theaters, concert halls, and Audio/Video installations.
All KTM components are designed by the K-array R&D department and custom-made under the K-array quality
control system.
2. APPLICATIONS
• Theatrical sound reinforcement
• Concert halls, clubs, houses of worship
• Portable and installed audio-visual systems
• Cinema and special effects
• Optimized for KK102, KMT18P or KMT12P
3. KEY FEATURES
• Unique performance-to-size ratio
• Fitted with integral handles and castors
• Direct radiating, long excursion driver
• Ultra fast set-up and dismantling system
• Analog and digital AES-EBU inputs
• RS485 and USB connectivity for remote control

KMT12/KMT18
REV. A REV. A
8
KMT12/KMT18
9
4. UNPACKING
Each K-array loudspeaker is built to the highest standard and thoroughly inspected before leaving the factory. Carefully
inspect the shipping carton, then examine and test your new loudspeaker. If you nd any damage, immediately notify the
shipping company. Only the consignee may institute a claim procedure regarding the system’s electronic equipment.
5. WARRANTY
K-array systems are warranted against manufacturing defects in materials or craftsmanship over a period of 2
years from the date of original purchase. During the warranty period K-array will, at its discretion, either repair or
replace products which prove to be defective provided that the product is returned in its original packaging, shipping
prepaid, to an authorized K-array service agent or distributor. K-array cannot be held responsible for defects caused
by unauthorized modications, improper use, negligence, exposure to inclement weather conditions, acts of God
or accidents, or any use of this product that is not in accordance with the instructions provided by K-array. K-array
is not liable for consequential damages. This warranty is exclusive and no other warranty is expressed or implied.
This warranty does not affect your statutory rights.
6. SAFETY
• It is important that loudspeaker systems are used
in a safe manner.
• Professional loudspeakers are capable of producing
extremely high sound levels and should be used
with care. Hearing loss is cumulative and can result
from levels above 90dB if people are exposed for
an extended period.
• Never stand close to loudspeakers driven at high
volume.
• Suspending the system should only be done by
qualied personnel following safe rigging practices.
Secure xings to the building structure are vital.
Seek help from architects, structural engineers or
other specialists if in any doubt.
• Do not operate the speaker for an extended period
of time with sound distortion. This is an indication
of malfunction, which in turn can generate heat and
result in a re.
• Only connect the power supply to an appropriate
power adapter.
• Do not install the speaker in wet or humid locations
without using weather protection.
• Do not allow water or any foreign object to get inside
the speaker. Do not put objects containing liquid on,
or near, the unit.
• To reduce the risk of overheating the amplier,
avoid exposing it to direct sunlight. Do not install the
unit near heat emitting appliances, such as a room
heater or stove.
• No naked ame sources such as lighted candles
should be placed near the device.
• The speaker should be placed so that its location
does not interfere with its proper cooling.
• Do not attempt to disassemble the unit. The unit
contains no user-serviceable parts. Repairs should
only be performed by factory trained service
personnel.
• Be sure that the adapter has the correct voltage
value.
WARNING
7. PHYSICAL
32.5 cm 43.5 cm
33.5 cm
12.91” 17.13”
13.19”
weight: ?? kg (?? lbs)
KMT12

KMT12/KMT18
REV. A REV. A
10
KMT12/KMT18
11
61 cm
46.5 cm
47.5 cm
24.02”
18.31”
18.70”
weight: 28 kg (61.73 lbs)
KMT18
8. AMPLIFIER
8.1 AC POWER CONNECTOR
8.2 VOLTAGE REQUIREMENT
8.3 CURRENT REQUIREMENT
The amplier module and the rest of the audio equipment connected to it (mixing consoles, processors, etc.)
must be connected to the AC power distribution in a proper way, preserving AC line polarity and connecting
earth ground such that all grounding points are connected to a single node or common point using the same
cable gauge as the neutral and line(s) cables. Bad grounding connections between speakers and the rest of
the audio system may produce noise, hum and/or serious damage to the input/output stages in the system’s
electronic equipment.
Before applying AC to any K-array self-powered speaker, be sure that the voltage
potential difference between neutral and earth ground is less than 5 VAC.
KMT12 and KMT18 operate safely and without audio discontinuity if the AC voltage stays within 85
and 135V or between 180 and 250V, at 50 or 60 Hz.
Verify that your mains connection is capable to satisfy the power ratings of the device.
CAUTION
Connecting the system to an AC power mains with a voltage exceeding 250V will
cause signicant damage to the device and create a serious risk for users!
KMT12 and KMT18 present a dynamic load to the AC mains, which causes the amount of current to uctuate
between quiet and loud operating levels. Since different cables and circuit breakers heat up at varying rates,
it is essential to understand the types of current ratings and how they correspond to circuit breaker and cable
specications. The maximum continuous RMS current is the maximum RMS current in a period of at least
ten seconds. It is used to calculate the temperature increase in cables, which is used to select cables that
conform to electrical code standards. It is also used to select the cable size and gauge, and the rating for
slow-reacting thermal breakers. The maximum burst RMS current is the maximum RMS current in a period of
approximately one second. It is used to select the rating for magnetic breakers. The maximum instantaneous
peak current during burst is used to select the rating for fast reacting magnetic breakers.
For best performance, the AC Cable voltage drop should not exceed 10% at 115V and 5% at 230V.

RS485 XLR link
USB Connection from a PC
RS485 XLR link RS485 XLR link RS485 XLR link
KMT12/KMT18
REV. A REV. A
12
KMT12/KMT18
13
The minimum electrical service amperage required by a K-array loudspeakers system is the sum of their
maximum continuous RMS current. We recommend allowing an additional 30% above the minimum amperage
to prevent peak voltage drops at the service entry.
410VA(>10 sec) - 2200VA (<1 sec)
KMT12/KMT18 max continuous apparent power (VA)
8.4 REAR PANEL
1
2
3
4
5
12
13
14
15
16
17
18
19
19
20
6
7
10
11
98
1) CH1 Line XLR input. This input ha a sensitivity of +4 dBu.
2) CH2 Mic/Line XLR input. The sensitivity of this input can be switched between -30 dBu (Mic mode) and +4 dBu
(Line mode).
3) CH1 XLR parallel out. This connector is physically linked to the CH1 input XLR socket. Its outputs the signal
entering CH1 before any processing and cannot be controlled via the K-Framework software in any way (see 1.).
4) Input Phantom Power switch. This button turns the phantom power (48V) on/off on CH1 and CH2 inputs.
5) Mic/Line switch. This button selects the input mode of CH2. Modes are Mic mode (sensitivity -30 dBu) and Line
mode (sensitivity +4 dBu).
6) Limiting LEDs. These LEDs blinks when the optical limiter is operating on the corresponding input to protect the
preamp circuit. Limiters operation threshold is +5 dBu.
7) DSP out. This is an auxiliary XLR balanced output controlled via the K-Framework software. User can select the
signal to route to this output and manage its amplitude and EQ individually (v. ..).
8) DSP out Phantom Power switch. This button turns the phantom power (48V) on and off on the DSP out line. The
phantom power on this line is needed to drive additional wireless signal transmitters/receivers.
9) AES/EBU XLR input. This input is for two channels of digital audio in AES/EBU signal format. It accepts all
sample rates between 32KHz and 96KHz.
10) AES/EBU XLR output. This connector is linked to the AES/EBU input XLR socket. It outputs the signal entering
AES/EBU before any processing and cannot be controlled via the K-Framework software in any way. Digital audio is
output as PCM at a sample rate of 48KHz in AES/EBU signal format.
11) RS485 XLR input. This input is for connecting a computer running the K-Framework software to remotely control
the KMT (K-USB usb to RS485 adapter is required).
12) RS485 XLR link. This output is for connecting another device to the K-framework network.
13) USB socket. This socket is for connecting a computer running the K-Framework software to remotely control the
KMT. This socket allows to manage a whole RS485 network of devices with just one PC connected to the USB of one
element of the network (see the picture below).
14) Speaker Out Speakon output. This power output can drive another passive speaker like a KP mid-high module
or a KMTp passive subwoofer, depending on the preset currently loaded on the KMT DSP.
15) Power switch. This switch turns the KMT system on and off.
16) AC Powercon input. This input is for mains power. See p. 11 for voltage and power requirements.
17) AC link Powercon ouput. This output is for sharing the mains power on with any other K-Array system with a
powercon AC input socket on board.
18) Extension Connector. Multi-pin connector for various extensions modules from K-Array, dedicated to wire less
control and audio transmission, memory extension, digital signal encoding and audio reproduction.
19) Power on LED. When this LED is on it indicates that the system is ON.
20) TOUCH SCREEN Control panel. Provides access to the main functions of the DSP on board (see the dedicated
section at page ...).
RS485 network

KMT12/KMT18
REV. A REV. A
14
KMT12/KMT18
15
From the Output page users can manage the amplitude
of the signal routed to the Subwoofer module, to the
Speaker output and the XLR DSP output separately.
From the two preset pages users can load any preset
stored on board.
Using the arrow buttons on the top right corner of the
page users can alternatively access the Factory or the
User preset page to scroll the list of all the available
presets and select the one to load.
See the PRESET page (p. ??) for a description of
Factory and User Presets.
Inside the Info page users can nd all the information
about the software and rmware current version and
the Logical ID of the KMT module.
The Logical ID is a univocal number that is automatically
assigned to the unit when connected to a network.
From the Delay page users can manage the delay
amount to be applied to the speaker system (Subwoofer
and Speaker Out).
This delay is summed to the one from the Routing
pages of Subwoofer and Speaker Out.
The COARSE and FINE regulation bars allow users to
regulate the delay amount by bigger and smaller steps.
Notes: The delay regulation does not affect the XLR
DSP out. Delay regulation for this output line is only
managed through the K-Framework dedicated controls.
From the three routing pages users can manage the
routing of the four input channels to the three outputs
(Subwoofer, Speaker Out and XLR DSP Out) as well
as the output volume and the delay amount of each
output separately.
The delay amount set inside the Routing pages is summed
to the one globally assigned from the Delay page.
Using the arrow buttons on the top right corner of the
page users can alternatively access the Subwoofer, the
Speaker Out and the XLR DSP Out routing page.
Notes: The XLR DSP routing page does not provide
the management of delay for this output.
OUTPUT PAGE
PRESET PAGES
INFO PAGE
DELAY PAGE
ROUTING PAGES
8.6 AUDIO INPUT CONNECTOR WIRING
The Audio section includes a female balanced
XLR connector and a male XLR connector wired in
parallel. Thanks to these connectors it is possible
to feed a module and send the same signal to
another one through the LINK connector. It is
possible to connect up to 30 different modules in
parallel on the same balanced line (with a source
of 600 ohm output impedance). In order to create
your own signal cables, please use the following
wiring diagrams:
hot
XLR connector
grd
cold
hot
grd
cold
21
3
2
1
3
INPUT PARALLEL
OUTPUT
The KMT12 and KMT18 are powered by a 2-channel high power digital amplier feeding the connected
modules with a power output of 1050W in each channel (EIAJ test).
All the specic functions for the KMT12 or KMT18, such as crossovers, equalization, phase response, and
driver protection are controlled by a DSP processor installed inside the amplier.
The devices have two different types of audio signal limiter. The Clip limiter and the Average Power limiter
reduce the risk of damaging the components of the speakers.
A Peak Current Shut Down acts as output stage switching process inhibition that resets itself after 2 seconds.
The tripping point is at 35A.
A temperature protection limiter ensures the output stage gain stays below a temperature of 85° (approximate
temperature of output power device).
8.7 AMPLIFICATION AND PROTECTION CIRCUITRY
From the Input page users can manage the amplitude
of all the four input channels separately.
INPUT PAGE
HOME PAGE
8.5 Touch screen functions
To reach the Home page from any other page,
touch the Home button.
The main functions of the DSP on board can be
managed through the integrated touch screen.
Functions are grouped into six pages, as shown in the
Home page.

KMT12/KMT18
REV. A REV. A
16
KMT12/KMT18
17
9. K-Framework
9.1 System requirements
9.2 Installation and set up
SYSTEM REQUIREMENTS:
Operating System: Windows Xp / Vista / 7
CPU: Intel Pentium Dual Core
Memory: 2 Gb
REQUIRED COMPONENTS:
.NET Framework 4
http://www.microsoft.com/downloads/en/details.aspx?FamilyID=0a391abd-25c1-4fc0-919f-b21f31ab88b7
Microsoft Visual C++ 2010 Redistributable Package (x86)
http://www.microsoft.com/download/en/details.aspx?id=5555
Microsoft Visual C++ 2010 Redistributable Package (x64)
http://www.microsoft.com/download/en/details.aspx?id=14632
To download your free K-Framework license, please go to the “Software Download” page of the Blueline website (http://
www.kblueline.com).
Once the .zip file is decompressed, it will show a folder containing the file “K-Framework.setup”.
-Users of Windows Vista and 7 can install the software by simply opening the K-Framework.setup file.
-Users of Windows XP are required to follow the following simple procedure to install the necessary drivers, once the
K-Framework software has been installed:
1) Recall the “Manage” window from “Start Menu/My Computer”.
2) Select “Device Manager” from the menu on the left and expand the “USB controllers” sub-menu.
3) Right click on the upper “K-Array _Dsp01” object and select “Driver Update” to launch the “Hardware Update
Wizard”
4) When asked to allow the online search select the “Not now” option and click on “Next”.
5) When asked for the drivers’ location, select the “Install from a list or specific location” option.
6) In the search and installation options window, select the “Search for the best driver in this location” option and
check the “Include this location in the search” checkbox, then browse for the drivers’ containing folder. The path
should read:
C:\ProgramFiles\K-array\K-framework\drivers_rev02
Once you have inserted the right search path, click “Next”.
5
6
7) When warned about a failed “Windows Logo” test, please ignore the content of the warning and click “Next”.
8) The first part of driver installation is now complete, and the “unknown” K-Array _Dsp01 port has changed its
name to a univocal “K-Array_Dsp01 A”. Click on “Finish” and repeat exactly the same procedure for the still unknown
port.
9) Now you can see that inside the Device Manager Window both devices now have a univocal name and the alert
symbol is no longer associated with them. Now you are 100% ready to get started!

KMT12/KMT18
REV. A REV. A
18
KMT12/KMT18
19
img. A
A2
A4
A3
A1
A1) Connected Devices Indicator shows the quantity of detected connected devices. N.B.: at startup, the indicator
will show 0 devices even if one or more units are connected. To detect all connected devices, just click the “Connect”
button.
A2) Connect Button detects connected devices.
A3) Demo Mode Button activates the demo mode of K-Framework. In this mode, all devices that can be mangaed
with the K-Framework software appear in the Connected Devices Menu on the left, so that the user can navigate
through all the dedicated tabs and have a glimpse of the different functions available for each of them.
A4) Device List displays all devices presently connected to the network.
N.B.: at startup the List will look empty even if one or more units are connected. To detect all connected devices, just
click the “Connect” button.
A5) Account Button opens the Account Settings Window where users can insert User Name and Password to access
the K-Array Community and the shared preset database.
A6) Zoom Buttons zoom in (+) and out (-) of the window view.
Click the Connect Button to detect all presently connected devices.
Once a connected device is detected by K-Framework it will appear in the K-Array Device List as shown in the following
picture:
At startup K-Framework will show the following window:
A5
img. B
img. C
B1
B2
B3
B1) Connected Device Name.
B2) Device Menu Button shows and hides the device menu.
B3) Device Menu displays the basic information about the device and the shortcuts to open all available Editing
Tabs.
9.4 User Tabs:
HOME
From the Home window users can acccess the dedicated tabs, ordered according to the signal ow from input
stage to ouput stage.

KMT12/KMT18
REV. A REV. A
20
KMT12/KMT18
21
INPUT TAB
From this window users can manage the EQ and the gain of the four input channels separately.
img. D
D1
E1
F2F1 F3
D2 D3 D4
D1) Frequency response display. It shows the frequency response curve resulting from the filters set in the Input EQ window.
D2) Input EQ window button. It opens the Input EQ window, where users can set three parametric filters for each input
channel.
D3) Input Volume buttons. They regulate the amplitude of each input channel
D4) Input Volume display. It shows the gain or reduction currently applied to corresponding channel. User can directly write
the desired amount of gain inside the Input Volume display instead of using the Input Volume buttons.
D5) Frequency response display. It shows the frequency response curve resulting from the filters set in the Input EQ window.
D6) Input EQ window button. It opens the Input EQ window, where users can set three parametric filters for each input channel.
D7) Input Volume buttons. It regulates the amplitude of each input channel
D8) Input Volume display. It shows the gain or reduction currently applied to each channel.
Input EQ window
ROUTING TAB
DELAY TAB
E1) Routing switch button. When lighted, the signal coming from the corresponding input on the left
column is routed to the corresponding output on the top row.
img. E
img. F
From this window users can manage the EQ and the gain of the four input channels separately.
F1) Global Delay buttons. Regulate the amount of delay to be equally applied to the subwoofer and to the speakon
output (thus to a passive speaker, or an array of passive speakers, directly connected to the system, ie: mid-high
modules or an addictional bass module).
F2) Global Delay displays. Show the amount of delay cuirrently applied to the system (subwoofer + speakon ouput),
both in milliseconds and in meters. User can directly write the desired amount of delay inside the milliseconds or
meters display instead of using the Global Delay buttons.
F3) Dedicated Delays. Buttons and displays in this section have exactly the same functions as the ones in the
Overall delay section, but each set is dedicated exclusively to one output channel. From top to bottom: subwoofer
delay, speakon output delay, XLR DSP output delay.

img. G
KMT12/KMT18
REV. A REV. A
22
KMT12/KMT18
23
10. SERVICE
To obtain service:
1) Contact the official K-array distributor in your country. They will direct you to the service centre.
2) If you are calling for service, have the serial number(s) of the unit(s) to hand for reference. Ask for Customer Service, and be
prepared to describe the problem clearly and completely.
3) If the problem cannot be resolved over the phone, you must return the unit for service. 4) You will be given an RA (Return
Authorization) number for job tracking. Refer to this number on shipping materials and in all correspondence concerning the
repair. Shipping charges are the responsibility of the purchaser.
Any attempt to modify or replace components of the device will invalidate your warranty. Service must be performed by an
authorized K-array service center.
Cleaning:
Clean the product enclosures using a soft, dry cloth only. Do not use any solvents, chemicals, or cleaning
solutions containing alcohol, ammonia, or abrasives. Do not use any sprays near the product or allow liquids
to spill into any openings.
OUTPUT TAB
G1 G2 G3 G4 G5 G6 G7
G1) Frequency response display. Show the frequency response curve resulting from the filters set in the Input EQ window.
G2) Output EQ window button. Open the Output EQ window, where users can set up to six parametric filters for each
output channel.
G3) Polarity inverter button. When lighted, the signal polarity of the corresponding channel is inverted (180° phase rotation).
G4) Output Volume buttons. Regulate the amplitude of each output channel.
G5) Output Volume display. Show the gain or reduction currently applied to each output channel. User can directly write the
desired amount of volume inside the Output Volume display instead of using the Output Volume buttons.
G6) Limiter threshold selection buttons. Use these buttons to select the different thresholds availables for each output channel.
G7) Limiter threshold display. Shows the threshold currently applied to the corresponding output channel. User can directly write
the desired amount of threshold inside the Limiter Threshold display instead of using the Limiter Threshold selection buttons.
From this window users can manage the EQ, polarity, gain and limiting threshold and of the three output
channels separately.
N.B.: The XLR DSP section of the Output tab does not provide the management of any limiter for this output.
Output EQ window
G8) Frequency response curve
G9) Filter type menu
G10) Filter frequency knob
G11) Filter gain knob
G12) Filter Q knob
G12G11G10G9G8

KMT12/KMT18
REV. A REV. A
24
KMT12/KMT18
25
Notes for data
1. Maximum RMS applicable power for a musical signal, the reference signal is the one proposed by EIAJ standard.
2. Measured @4 mt then scaled @1 mt
3. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS voltage that the amplifier will produce
into the nominal load impedance.
New materials and design are introduced into existing products without previous notice. Present systems may differ in
some respects from those presented in this brochure.
KMT18
Acoustics
Speakers power
handling 800 w(EAS)
Maximum power 1400 w 1
Impedance 8Ω
Frequency range 30Hz - 150 Hz +/- 3dB (preset dependent)
SPL 1W/1mt 99 dB 2
Maximum SPL 130 dB continuous - 136 dB peak
Coverage
Omni
Crossover
Type DSP controlled
Frequency 150 Hz maximum (preset dependent)
Transducers
1 x 12” Neodymium speakers with 3”
voice coil
Audio Input
Analog
Connectors
2 male + 2 female 3-pin balanced XLR
Digital
Connectors
1 male + 1 female 3-pin XLR
Audio powered Output
Connector Female Speakon
Wiring Pin1+= CH1+ Pin1= CH1- Pin2+= N.C.
Pin2= N.C.
Remote control Input
Connectors 1 male + 1 female XLR parallel
1 USB B Jack serial converter
Power Input
Connectors 2 x PowerCon IN/OUT
Amplifiers
Type 1 modules class D - DSP controlled
Subwoofer power 1000 Watt 3 @8Ω
Speaker power
output 1000 Watt 3 @8Ω
Protection Dynamic limiter, over current, over temp,
short circuits
AC power
Operating range 100 - 120 Vac 60Hz / 210 - 240 Vac 50Hz
(Auto Switch)
I. nom 5.5 A / 115 Vac - 2.9 A / 230 Vac
Minimum
operation voltage 95 Vac - 195 Vac
Maximum
operation voltage 125 Vac - 205 Vac
Max continuos
and
burst current
Default 6A(>10 sec) - 12A (<1 sec)
Selectable 10A(>10 sec) - 20A (<1sec)
Physical
Dimensions 46.5 x 47.5 x 61 cm
(18.31”x 18.70” x 24.02”)
Weight 28 Kg (61.73 lbs)
11. SPECIFICATIONS
Notes for data
1. Maximum RMS applicable power for a musical signal, the reference signal is the one proposed by EIAJ standard.
2. Measured @4 mt then scaled @1 mt
3. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS voltage that the amplifier will produce
into the nominal load impedance.
New materials and design are introduced into existing products without previous notice. Present systems may differ in
some respects from those presented in this brochure.
KMT12
Acoustics
Speakers power
handling 700 w( EAS)
Maximum power 1200 w 1
Impedance 8Ω
Frequency range 40Hz - 150 Hz +/- 3dB (preset dependent)
SPL 1W/1mt 99 dB 2
Maximum SPL 128 dB continuous - 134 dB peak
Coverage
Omni
Crossover
Type DSP controlled
Frequency 150 Hz maximum (preset dependent)
Transducers
1 x 12” Neodymium speakers with 3”
voice coil
Audio Input
Analog
Connectors
2 male + 2 female 3-pin balanced XLR
Digital
Connectors
1 male + 1 female 3-pin XLR
Audio powered Output
Connector Female Speakon
Wiring Pin1+= CH1+ Pin1= CH1- Pin2+= N.C.
Pin2= N.C.
Remote control Input
Connectors 1 male + 1 female XLR parallel
1 USB B Jack serial converter
Power Input
Connectors 2 x PowerCon IN/OUT
Amplifiers
Type 1 modules class D - DSP controlled
Subwoofer power 1000 Watt 3 @8Ω
Speaker power
output 1000 Watt 3 @8Ω
Protection Dynamic limiter, over current, over temp,
short circuits
AC power
Operating range 100 - 120 Vac 60Hz / 210 - 240 Vac 50Hz
(Auto Switch)
I. nom 5.5 A / 115 Vac - 2.9 A / 230 Vac
Minimum
operation voltage 95 Vac - 195 Vac
Maximum
operation voltage 125 Vac - 205 Vac
Max continuos
and
burst current
Default 6A(>10 sec) - 12A (<1 sec)
Selectable 10A(>10 sec) - 20A (<1sec)
Physical
Dimensions 32.5 x 33.5 x 43.5 cm
(12.91” x 13.19” x 17.13”)
Weight ??

KMT12/KMT18
REV. A REV. A
26
KMT12/KMT18
27
The contents of this manual are furnished for informational purposes only. Hp Sound Equipment s.r.l. assumes no responsibility
for any errors or inaccuracies that may appear in this manual. Hp Sound Equipment s.r.l. reserves the right to make modifications
without prior notice.
Manufacturer/Importer: K-array srl unipersonale
Brand: K-ARRAY
Address: via Paolina Romagnoli - 50037 S. Piero a Sieve Firenze ITALY
Date of Issue: 10 / 01 / 2012
Model Code: KMT12 / KMT18
Declaration: Complies with essential protection requirements of Council Directive 89/336/EEC on
the approximation of the Lows of the Member States relating to electromagnetic compatibility. This
declaration applies to all specimens manufactured in accordance with the attached manufacturing
drawings which form part of this declaration. Assessment of compliance of the product with the
requirements relating to electromagnetic compatibility was based on the following standards:
Safety: EN60065 : 1998
EMC:
EN55103-1 1997 Emission (1)
EN55103-2 1997 Immunity (2)
1) This device may not cause harmful interference
2) This device must accept any interference received including interference that may cause
undesidered operation
Marking :
Applying Year: 1998
Applied by: K-array srl unipersonale
Via Paolina Romagnoli
50037 S. Piero a Sieve
Firenze Italy
Tel. [phone]
Fax [phone]
Signed by: Franco Spataro - Technical Manager
12. Declaration of conformity

REV. A
28
K-array s.r.l. unipersonale
Via Paolina Romagnoli - 50037
San Piero a Sieve (Firenze) - Italy
tel. [phone] - fax. [phone]
e-mail: [e-mail]
www.k-array.com
UMC031AA01ENA
