Küppersbusch EGS 304.0 Quick setup guide

Instructions for use
and installation instructions
EGS 304.0
H31

2EGS 304.0
For your information...
You should carefully read the information in this manual before you use your
appliance. Here you will find important notes concerning safety and how to
use, look after and service your appliance so that it enjoys a long service life.
Should a fault arise, please first consult chapter “What to do if trouble occurs”.
You can often remedy minor faults yourself and thus save unnecessary service
costs.
Please keep this manual in a safe place and pass it on to new owners for their
information and safety.
The following symbols are used in this operating manual:
[The warning triangle draws your attention to risks to your health or
damage that might be caused to your appliance.
FHere you will find useful hints and information.
Contents
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Using the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Before using the first time
The grilling surface
Switching on the grilling zone
Grill levels
Switching off the grilling zone
Grilling
Grilling times
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Using a cleaning scraper
Cleaning the grilling surface
What to do if trouble occurs... . . . . . . . . . . . . . . . . . . . . . 4
Rating label
Installation instructions for fitter. . . . . . . . . . . . . . . . . . . . 5
General
Installation conditions
Electrical connection
Dimensions and distances
Installation
Special case: Installation in a stone worktop
Safety instructions
■ The grilling surfache must be built into a worktop opening! Do not use the
appliance if it has not been installed!
■ The appliances may only be installed and connected to the mains,
maintained and repaired by a qualified electrician according to valid safety
regulations. Work carried out incorrectly places your safety at risk.
■ Danger of burning! The grilling zone becomes hot
during operation. Therefore caution: Generally keep
little children away from the appliance.
■ The appliance is to be used only for the preparation of food in the home.
■ The glass ceramic surface is very tough and can easily stand light to
medium blows and loads distributed over large areas. You should, however,
avoid concentrated loads, such as containers for spices and herbs or bottles
falling onto the surface. Lumped impact loads may result in a breaking of
the grilling surface.
■ In case of cracks, fractures or breaches of the grilling surface immediately
put the appliance out of operation. Disconnect fuse, call customer service.
■ Never flambé under the cooker hood - the fat in the filter can ignite!
■ The connecting cable must not contact the hot grilling surface.
■ Caution: Overheated greases and oils may inflame themselves. Prepare
meals with greases and oils only under control. Never extinguish ignited fats
and oils with water!
■ The grilling surface must not be used as depositing place when hot.
■ Take care when working with attachments! The connecting cable must not
contact the hot grilling surface.
■ Do not put kitchen foil or plastic onto the grilling surface. Things that
may melt, e.g. plastics, foils or sugar, must be kept away from the grilling
surface. Melted parts must immediately be lifted off from the grilling
surface when still hot by means of the supplied cleaning scraper in order
to avoid damaging.
■ Avoid repeated burning of contaminations.
■ Lime deposits are harmful to the grilling surface.
■ Never use silicone-containing cleansing agents to clean the grilling surface!
Please observe the cleaning and servicing instructions.

EGS 304.0 3
Using the appliance
Before using the first time
– Before preparing the first meals clean the grilling surface by means of a
moist cloth and a bit washing-up liquid.
Afterwards wipe it dry with a non-fluffy cloth.
The grilling surface
■ The grilling surface is resistant against thermal shocks (coldness and heat)
and also very robust.
■ When switching on the grilling zone a short buzzing noise may be heard
from the heating. This is design-specific and has no influence on quality
and operation.
■ We would like to indicate that scratches on the grilling surface caused by
improper cleaning or cutting with knives do not have a negative influence
on the operation of the device. They merely impair the appearance of the
appliance.
The grilling zone is controlled by the grilling zone regulator.
Switching on the grilling zone
– Turn the regulator to the desired grill level.
Grill levels
9 grill levels are marked on the grilling zone
regulator. You can also select intermediate
settings.
Outline of the grill levels:
The barbecue only heats in order to reach or maintain the preset temperature
setting. This means that the barbecue – also in level 9 – does not permanently
heat with full power, but always switches off for a short time. This “cycling”
is absolutely okay and does in no way represent a fault.
Switching off the grilling zone
– Turn the regulator to the “0” position.
Grilling
[Please do not use olive oil for grilling. Burnt in residues of olive oil can
only be removed with great difficulties.
– Preheat the barbecue immediately before grilling for approx. 5 minutes in
grill level 9.
– Place the food directly on the grilling surface. Do not use aluminium foil or
similar.
– Grill the meat on both sides at grill level 9 until it can be taken off from the
grilling surface. In this way the meat juices remain in the grill goods.
– Then switch down, if required (e.g. level 6), and grill the meat until it is
done. Toss thick pieces of meat or sausages several times.
– Remove the grilling residuals by means of the cleaning scraper after every
grilling procedure.
FIf the barbecue has been operated at a low temperature setting,
preheat it at temperature setting 9 again before putting new meat
on it.
FDo not grease the grilling surface with oil. Lean meat can be greased
with oil.
FWhen grilling very fatty foods, carefully dab away the fat using a paper
kitchen towel.
FIn case of pickled meat, remove surplus grease and coarse spices (like
onions, leaves or thyme).
FPlease keep in mind that large quantities of meat and sausages need
longer grilling times than small quantities. We therefore recommend to
grill several smaller quantities one after the other.
Grilling times
0 Position “off”
1 - 4 Warming
5 - 7 Moderate grilling
8 - 9 Hot grilling
Grilling goods Total grilling times in min.
(Guidelines)
Sausages 6 - 10
Chops 10 - 16
Rump-steak 10 - 14
Fillet-steak 4 - 8
Rissoles 8 - 12
Trout 12 - 16
Toast 2 - 4
Grilled apple/banana slices 4 - 6

4EGS 304.0
Cleaning and Care
[Sugar and food containing sugar (e.g. marmalade) and melted plastic
must immediately be removed with the cleaning scraper from the hot
cooking surface otherwise the surface can be destroyed when cooling
down.
[Never use cleansers which contain silicon. These will leave a film on the
grill surface which could be absorbed by the food upon next use.
Therefore, follow the instructions of the manufacturer in this regard.
■ Clean the grilling surface after every use.
■ Use only the glass scraper provided for removing large food particles left
from grilling.
■ Never use abrasive materials such as steel wool or abrasive cleansers!
■ Make sure that no cleaning residuals remain on the grilling surface.
FResidues of cleaning agents can cause discolouring the next time you
switch it on. Cloths and sponges which are used for the cleaning of other
surfaces can cause discolouring.
■ We recommend you to rub down the grill surface with half a lemon or lemon
juice. Any slight dirt marks from protein, e.g. from meat, is removed and
the grill surface shines again.
Using a cleaning scraper
[Caution! Risk of cutting! The blade of the cleaning scraper is very sharp!
[Attention: When cleaning the grilling surface do not reach between
grilling surface and housing with the peak of the cleaning scraper!
Always keep the cleaning scraper flat on the
surface and push the caking away.
[Do not scratch the surface with the edge of
the scraper.
Cleaning the grilling surface
[Make sure that no cleaning residuals remain on the grilling surface.
– First of all remove all food residuals and fat splashes from the hot grilling
surface by means of the cleaning scraper.
– Clean the grilling surface with water and some detergent.
– Rewipe it with clear water and finally dry it.
FIn case there are still some soil particles left on the grilling surface after
cleaning, they can easily be removed by means of a special cleansing
agent, e.g. VSR O-FIX-C (available from the Küppersbusch Customer
service). Then wipe off the entire grilling surface with a wet and
afterwards with a dry cloth.
What to do if trouble occurs...
[Never unscrew the device! Repairs may only be carried out by a qualified
technician!
You can deal with some problems that occur yourself. First check whether
there has been any operating error. Repairs during the guarantee period are
not free of charge, when they are caused by operating errors or non-
observance of the following instructions:
Rating label
The type plate is located at the bottom side of the appliance and on the front
page of this manual.
Always indicate the data provided on the rating label when calling in customer
service or ordering spare parts.
Fault Possible cause Remedy
Grilling zone cannot be
switched off.
Regulator is
defective.
Disconnect fuse, call
customer service.
Grilling surface does not
heat up.
The grilling zone
regulator has not
been switched on?
Set the grilling zone
regulator.
Household fuse
defective?
Check and replace fuse, if
necessary.
Regulator or grilling
zone defective.
Disconnect fuse, call
customer service.

EGS 304.0 5
Installation instructions for fitter
General
FThe model EGS has an installation depth of 60 mm, thus the grilling
surface cannot be mounted above an oven.
■ Lift off the glass ceramic surface only laterally, never at the front panel!
■ Do not use a screw driver to lever the appliance out of the opening - This
will damage the frame of the appliance. When removing the appliance press
it from the bottom out of the opening.
Installation conditions
■ The plastic finish, or the veneer of built-in kitchen furniture must be have
been produced using a heat-resistant adhesive (100 °C).
■ The working surface must be installed absolutely horizontally and the opening
must be cleanly cut out.
■ No cross-bars may be in the area of the cut-out underneath. They have to
be reduced at least to the opening size.
■ Each time the appliance is removed from the worktop, replace the seals.
Electrical connection
■ Statutory regulations and the connection specifications issued by the local
power supply company must be strictly observed.
■ It must not be possible to touch components which are insulated under
operating conditions.
■ The appliance may be connected only to a properly installed conduit-box.
Installing a conduit-box or replacing the connection cable should only be
performed by an electrician and in observance of the relevant regulations.
■ The conduit-box must be provided with a contact opening of at least 3 mm.
■ The conduit-box can be mounted under the working top below the grilling
surface or in a side cupboard in the wall. Do not mount it above the grilling
surface!
Connection to a conduit-box (not supplied accessory!)
Total rating 1.63 kW,
Electrical connection
240 V, 60 Hz
Fuse current
16 A
Dimensions and distances
■ This appliance can be mounted with two sides to a wall or a cupboard side
with a distance of at least 40 mm. The third side may only be placed next
to an appliance of the same height at the most.
FFor technical reasons the distance to mounted cupboards should be at
least 300 mm.
■ Cooker hoods or wall cupboards mounted above the grilling surface must
be installed with a minimum distance of 650 mm to the grilling surface.
Installation
dimensions
■ When installing several hobs side by side please observe the minimum
distances between the worktop openings as shown in the drawings:
Installation
FWhen installing stone worktops the grilling surface cannot be fastened with
clips. See page „Special case: Installation in a stone worktop“ page 6.
Cutting-out the opening
– First neatly cut out the worktop opening.
The distances of the opening to the wall for front, back and side have to
be observed!
Seal the cut sections
– The cut sections should be sealed with a water-repellent protection paint.
Checking or replacing the sealing
– Check that the seal fits well and has no gaps.
With uneven worktops (for example tiles) you have to remove the sealing
strip and apply a temperature resistant and elastic sealant.
– Clean the surfaces according to the instructions, apply the sealant and press
the appliance into the opening.
– Remove excess sealant by cutting and clean the sealed surface immediately
with water.
Top view
Detail
Appliance
Worktop

6EGS 304.0
Drive in the clips
– Align the clips carefully and drive them in with a hammer.
Worktops with more than 30 mm thickness:
With worktops with 30 mm
thickness the clips have to be
screwed down with two screws
(not supplied)!
Inserting the grilling surface
– Position the grilling surface on
the left side (1), align it (2) and
insert the clips (3).
Be careful not to pinch the
connecting cable!
[The grilling surface must rest
evenly in the opening. If the
strain of the grilling surface is
too strong the appliance can
crack while heating up.
FIf the grilling surface is not fixed tightly in the
opening it is slightly too big. In this case
screw the clips with two screws down each
(not supplied) to raise the spring tension.
Connecting the connecting cable to the
conduit-box
– Connect the grilling surface to the conduit-box.
■ The exceeding cable has to be pulled out of the installation area.
Special case: Installation in a stone worktop
With a working surface made of marble, granite or similar material the grilling
surface has to be fixed from the bottom. Clips are not needed.
– Insert the grilling surface into the opening.
– Srew down the grilling surface with the tension elements starting from the
bottom.
Granite or
similar
Grilling
surface

KÜPPERSBUSCH HAUSGERÄTE AG
Postfach 10 01 32, D-45801 Gelsenkirchen, Küppersbuschstr. 16, D-45883 Gelsenkirchen
Telefon: [phone], Telefax: (02 09) 4 01-3 03
www.kueppersbusch.de
Küppersbusch Ges.m.b.H.
Eitnergasse 13, 1231 Wien, Telefon: 01 / 8 66 80-0, Telefax: 01 / 8 66 80 72
www.kueppersbusch.at ⋅e-Mail: [e-mail]
