OWNER’S MANUAL
1000 LB
ENGINE SUPPORT BAR
KTI-62116A
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Capacity
1000 LB

2
INSTRUCTIONS FOR USE
We recommend using this machine after reading the instruction manual carefully, keeping to the
instructions provided therein.
1. Do not exceed 800 lb load
2. Use lifting accessories suitable for the load to be supported and complying with ASME standards
3. Use bolts equal to or higher than class 4.8
4. Tighten the bolts and make sure that the weight is suitably held
5. Make sure that the points of support are suitable for the weight to carry
6. Do not use while the engine is running
7. Check the state of the support before using it; replace it if irreparable damage has been caused
8. Do not modify the product; do not weld it in any way
9. Failure to follow the above rules may result in severe damage or injury
The tool is designed to support the engine, while removing its supports from the vehicle, using struts to carry
its weight.
We recommend not keeping the engine running or starting the engine with the mounted bracket.
Pack contents:
– 1 bracket
– 2 chains, 3.15 ft
– 2 supports with rubber guards
– 2 hooks that can be vertically adjusted through threaded nuts
Use:
Assemble the tool; place it on the vehicle, leaning the brackets with the rubber guards on the suspension
struts.
Connect the engine to the bracket, making sure that the chosen point can carry the weight, using the chains
supplied with the tool. If these should not be sufcient or adequate enough, use lifting accessories, including
hooks, eyebolts and eye nuts, certied for the load to be supported.

3
PARTS BREAKDOWN
PARTS LIST
Item Description
01 handle 2
02 small washer 2
03 beam 1
04 big washer 2
05 nut M10 4
06 support seat 2
07 bolt M10x40 4
08 bolt M12x40 2
09 rubber 4
10 suport rack 2
11 rubber handle 4
12 circumvolve handle 2
13 pothook 2
14 chain 2
15 spring washer 10 4
16 nut M12 2

WARRANTY
K-Tool International HD and XD service-related equipment 2 Year Limited Warranty.
K-Tool International warrants that all jacks and service-related equipment will be free from defects in material
and workmanship for a period of 2 years following the original date of purchase. This warranty is extended to
the original retail purchaser only. If any jack or service-related item proves to be defective during this period,
it will be replaced or repaired, at K-Tool International’s option, without charge. This warranty does not apply to
damage from accident, overload, misuse or abuse, nor does it apply to any equipment which has been altered
or used with special attachments other than those recommended.
www.ktoolinternational.com
Michigan
If you have any question about the use of this product, please contact
