K-TRON KSU-II/KCM Installation manual

PROGRAMMING
INSTRUCTIONS
Read this manual prior to operating
or servicing the equipment. This ma-
nual contains all safety labels and
warnings.
Original operating instructions
0590020601-EN Rev. 1.6.0
KCM LWF Programming
M
texttext
Software Version 2.0

Service
If you need assistance, please call your local service center or:
K-TRON (U.S.) Tel. [phone]
Rt 55 and Rt 553 Fax [phone]
Pitman, NJ 08071
K-TRON (Switzerland) Tel. [phone]
Industrie Lenzhard Fax [phone]
CH-5702 Niederlenz
Premier Pneumatics, Inc. Tel. [phone]
606 N. Front St. Fax [phone]
Salina, KS 67402-0017
Web: http://www.ktron.com
Before you call...
Do you have alarm displays? Can you eliminate their causes?
Have you modified part of the system, product or operating mode?
Have you tried to eliminate the fault in accordance with the operating
instructions?
Note down the project or job number. This can be foundat the machine
or in the project manual.
• Example: 0400545
Using the manual:
This arrow identifies an individual action.
1. Numbers identify a sequence of actions which have to be executed
step-by-step.
▲This symbol identifies a general safety note.
If an error or ommission is found, please contact:
[email protected].
Reference to another manual.
Important information.
This symbol indicates that tools are required for the following task.
Specifies where information or a situation must be checked.
Docu-No.: 0590020601-EN
Datum: 2011/Jan./03
Original: 0590020601-EN
“K-Tron assumes no responsibility for damages resulting from misuse of any equipment or negligence on the part of
operating personnel. Further, reference is made to the purchase order, acceptance or other document that contains
the express K-Tron disclaimer of warranties for a statement of the provisions limiting or disclaiming certain warranties
with respect to the Company's equipment. Except as otherwise expressly provided by K-Tron in any such document,
K-TRON MAKES NO WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, NOR
ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WITH RESPECT TO THE EQUIPMENT.”

Docu-No.: 0590020601-EN Rev. 1.6.0 Page3
Table of Contents
1 Programming Reference .....................................................................................................7
1.0.1 Additional programming information ......................................................................................7
1.0.2 Manual notation .....................................................................................................................8
1.0.3 Abbreviations and terminology ..............................................................................................9
1.0.4 Menu and sub-menu listing .................................................................................................10
1.1 Product change menu .........................................................................................................11
1.1.1 Product change parameters ................................................................................................11
1.2 Calibration ...........................................................................................................................16
1.2.1 Calibration sub-menu ..........................................................................................................16
1.2.2 Feedfactors sub-menu for motor driven feeders .................................................................19
1.2.3 Feedfactors sub-menu for vibratory feeders ........................................................................20
1.3 Alarm menu .........................................................................................................................21
1.3.1 Limits sub-menu ..................................................................................................................21
1.3.2 Alarm setup sub-menu ........................................................................................................23
1.4 Tuning menu ........................................................................................................................25
1.4.1 Tuning parameters ..............................................................................................................25
1.4.2 Method selection versus tuning parameters table ...............................................................27
1.5 Refill Menu ...........................................................................................................................28
1.6 Scale menu ..........................................................................................................................30
1.6.1 General sub-menu ...............................................................................................................30
1.6.2 SFT sub-menu .....................................................................................................................31
1.6.3 Manual addressing of SFTs .................................................................................................33
1.7 Machine setup menu ...........................................................................................................34
1.7.1 General sub-menu ...............................................................................................................34
1.7.2 Changing feeder control application type ............................................................................35
1.7.3 KSU-II/KCM screen saver description .................................................................................36
1.7.4 Motor sub-menu ..................................................................................................................37
1.7.5 Motor sub-menu for DC motor ............................................................................................37
1.7.6 Motor sub-menu for AC Interface drive ...............................................................................39
1.7.7 Motor sub-menu for vibratory drive ......................................................................................40
1.7.8 Motor sub-menu for universal stepper motor .......................................................................41
1.7.9 Motor sub-menu for HiPo, LoPo Stepper motor ..................................................................42
1.7.10 Stepper motor programming table .......................................................................................43
1.7.11 Service sub-menu ................................................................................................................44
1.7.12 Performance sub-menu .......................................................................................................45
1.7.13 Actiflow sub-menu ...............................................................................................................47
1.8 I/O Menu ..............................................................................................................................48
1.8.1 Digital input sub-menu .........................................................................................................49
1.8.2 Digital output sub-menu .......................................................................................................50
1.8.3 Setpoint input sub-menu ......................................................................................................51
1.8.4 Analog output sub-menu .....................................................................................................52
1.8.5 Modbus I-O sub-menu .........................................................................................................53
1.8.6 Adding External Modbus I-O, an example ...........................................................................54
1.9 Loader menu .......................................................................................................................55
1.9.1 Loader parameters ..............................................................................................................55

Page 4 Docu-No.: 0590020601-EN Rev. 1.6.0
1.10 HCU / LSR loader set-up .....................................................................................................56
1.11 System setup (only KSU-II/KCM). .......................................................................................58
1.11.1 Communication sub-menu ...................................................................................................58
1.11.2 SW Version Submenu .........................................................................................................59
1.11.3 Drive type by displayed MDU# ...........................................................................................60
1.11.4 Parameter Backup sub-menu ..............................................................................................61
1.11.5 Changing the K-PROM password. .......................................................................................61
1.12 Security menu (only KSU-II/KCM) .......................................................................................62
1.12.1 Security parameters .............................................................................................................62
1.12.2 Function data lock out ..........................................................................................................63
2 Calibration ..........................................................................................................................64
3 Other Programming ...........................................................................................................65
3.1 Setting refill parameters .......................................................................................................65
3.1.1 Setting the Refill Max value .................................................................................................65
3.1.2 Setting the Refill Min value ..................................................................................................65
3.1.3 Setting the Post Refill Delay ................................................................................................65
3.1.4 Setting the Refill Timer ........................................................................................................66
3.2 Calibrating analog I-O ..........................................................................................................67
3.3 Using an external motor drive ..............................................................................................68
4 Alarm Messages- Cause and Remedy .............................................................................69
4.1 System alarms .....................................................................................................................69
4.2 LWF alarms .........................................................................................................................76
4.3 Display messages ................................................................................................................77
4.4 Feeder won’t start - displayed messages ............................................................................77
4.5 Feeder won’t run in GRAV ...................................................................................................77
4.6 Massflow variances in LWF feeding ....................................................................................78
5 Appendix ............................................................................................................................80
5.1 Special KCM LWF features .................................................................................................80
5.1.1 Automatic Gear Switching for LWF ......................................................................................80
5.1.2 SFT Addressing ...................................................................................................................82
5.1.3 LWF tuning for the KCM ......................................................................................................83
5.1.4 Pert values and control response ........................................................................................83
5.1.5 Tuning parameter descriptions ............................................................................................84
5.1.6 Refill Algorithms for the KCM ...............................................................................................85
5.1.7 Refill using the integrated loader function ............................................................................88
5.2 Programming the loader function .........................................................................................93
5.3 Programming parameters for HCU ......................................................................................94
5.4 Status tables ........................................................................................................................95
5.4.1 DC Drive hex status codes-1600/450 W drives ...................................................................95
5.4.2 Vibratory drive hex status codes ..........................................................................................96
5.4.3 Stepper drive hex status codes for all types ........................................................................97
5.4.4 AC drive interface hex status codes ....................................................................................98
5.4.5 SFT status table ...................................................................................................................99

Docu-No.: 0590020601-EN Rev. 1.6.0 Page5
5.4.6 Actiflow drive hex status codes .........................................................................................100
5.5 Loading language file ........................................................................................................101
5.6 Service variables ...............................................................................................................102
5.7 LWF PSR Map ...................................................................................................................104
5.8 LWF ASR Map ...................................................................................................................106
5.9 Parameter listing-LWF .......................................................................................................112

Page 6 Docu-No.: 0590020601-EN Rev. 1.6.0

Docu-No.: 0590020601-EN Rev. 1.6.0 Page7
ProgrammingReference 1
1 Programming Reference
1.0.1 Additional programming information
See instructions below for information on the following points::
• User interface operation; keypad and display function
• For feeder calibration
• General operation
• Technical specifications
See operating manual for operator instruction with safety notes
The following programming instructions covers LWF application
programming for the displays KSU-II/KCM, KSL, K-Vision, KSC.
This manual is only for skilled staff instructed by K-Tron.
The menu architecture for the application is the same for all displays.
The main differences between the displays are the navigation and the
short variable name for the KSU-II/KCM.
0490020611 = KCM-KD / KSU-II operation with calibration
procedures
1090020602 = KCM-GD operation with calibration procedures
0690020604 = K-Vision operation with calibration procedures
0490020602 = KSC operation with calibration procedures
0290020613 = KSL operation with calibration procedures
0490020614 = Smart Connex II Overview
0690020601 = KCM General PC Utilities
0490020605 = KCM Electronics
1090020601 = KCM GD Electronics

1 Programming Reference
Page 8 Docu-No.: 0590020601-EN Rev. 1.6.0
1.0.2 Manual notation
The following is standard through out this manual.
• KSU-II / KCMParameter name shown as <PARAM NAME>
• KSL / KSC Parameter name shown as <Param Name>
• Parameter value shown as <Param Value>
• Menu name as <Menu NAME>
• Alarm message as <Alarm Message>
• Display indication or key action result as <INDICATION>.
• Dialog box indication as <Dialog>.
• Key or button as KEY
The first parameter name (in CAPs) is for KSU-II/KCM display. The
second parameter name below the first is for the KSL and KSC.
The BOLD PARAMETERS are command functions for the KSU-II/
KCM. For KSL and KSC functions keys are used instead of command
functions.

Docu-No.: 0590020601-EN Rev. 1.6.0 Page9
ProgrammingReference 1
1.0.3 Abbreviations and terminology
• Config port = diagnostic serial data port
• CPU = central processing unit, microprocessor
• Drive-MDU = Common representation of all types of drive boards
(450 / 1600 watt DC drive, AC drive interface, stepper motor drive,
vibratory drive)
• HCU = Hurricane pneumatic loader control
• Host Channel = serial data connection to remote host computer
• HSU = User interface for HCU
• HMI = human, machine interface, usually a PC utilizing a
commercial SCADA software package
• Internal Channel = serial data connection to SFTs/HCU and internal
motor drives
• KCM = K-Tron control module, the SmartConnex II integrated
feeder controller
• KCM = KCM with local keypad and display
• KCM-SD = KCM with status display only
• kgr = host communication file residing in KCM
• KSC = K-Tron Smart Commander, a PC based HMI system for use
with up to 30 controllers
• KSL = K-Tron line interface for up to 8 feeders
• K-Vision = K-Tron line interface for up to 16 feeders
• K-Net = KCM serial data connection to KSU-II, KSL, K-Vision or
KSC
• K-Port 1 and K-Port 2 = data port for a K-Tron specific
communication
• KSU-II = K-Tron single unit user interface for the KCM
• LWF = loss-in-weight feeder
• pcb = printed circuit board
• SCADA = supervisory, control and data acquisition system
• Smart Connex II = second version of SmartConnex architecture
• SFT = Smart Force Transducer

1 Programming Reference
Page 10 Docu-No.: 0590020601-EN Rev. 1.6.0
1.0.4 Menu and sub-menu listing
• Product Change menu
• Calibration menu
– Calibration sub-menu
– Feedfactor sub-menu
• Alarm menu
– Alarm limits sub-menu
– Alarm setup sub-menu
• Tuning menu
• Refill menu
• Scale menu
– General sub-menu
– SFT sub-menu
• Machine
– General sub-menu
– Motor sub-menu
– Service setup sub-menu
– Performance sub-menu
– Actiflow sub-menu -appears when a actiflow is connected to
KCM
• I-O Setup menu
– Digital Input sub-menu
– Digital Output sub-menu
– Setpoint Input sub-menu
– Analog Output sub-menu
– Modbus I/O sub-menu
• Loader menu-hidden if HCU or LSR is connected
• HCU Loader menu-appears when HCU is connected to KCM
• LSR Loader menu-appears when LSR is connected to KCM
•Systemmenu
– Communications sub-menu
– SW Versions sub-menu
– Parameter Backup sub-menu
• Security menu

Docu-No.: 0590020601-EN Rev. 1.6.0 Page11
ProgrammingReference 1
Productchangemenu 1.1
1.1 Product change menu
This menu allows easy product changeover. See section •for
manuals to be used specifically when calibrating the feeder.
1.1.1 Product change parameters
Parameter Definition
REFILL
Refill Enable
ENABLED Setting for automatic refill. The net weight alarm
limit is active.
DISABLED The feeder hopper can be emptied without refilling
being triggered. The net weight alarm limit is
disabled.
IF RUNNING Refill is enabled if the feeder runs, otherwise it is
disabled.
Default: DISABLED
REFILL MAX.
Refill Level Maximum
Input of the upper refilling limit at which refilling is stopped.
Warning:
Do not exceed the hopper capacity or scale capacity when entering
the top refilling limit. See section 3.1.1.
Input range: <0.95 x Gross scale range
Default: 0.06 kg
REFILL MIN
Refill Level Minimum
Input of the lower refilling limit at which refilling is started. See section
3.1.2.
Warning:
Feeding behavior can be affected if the refilling limit is set too low.
Do not uncover feeder horizontal agitator.
Input range: < Refill Maximum
Default: 0.05 kg
START REFILL NOW This command starts the refill when the net weight is less the
<REFILL MAX>.
Table page 1 of 5

1 Programming Reference
1.1 Product change menu
Page 12 Docu-No.: 0590020601-EN Rev. 1.6.0
GEARSWITCH
Note:
Not used for vibratory feeders
Defines how the unit will change gear reductions on the K2 feeder
with motor reversing gear reduction switching. To activate, a digital
output must be set to <HILoGear>. Selections are:
High, Low, Auto Hi, Auto Lo
Notes:
• See more detail of operation section 5.1.1.
• To fix the reduction at either High or Low speed, select either High
or Low entries.
• This value is only displayed when internal KCM motor drives are
used.
• <Low> selects low speed/highest gear reduction.
• <High> selects high speed/lowest gear reduction.
• <Auto Hi> When entering a setpoint which will generate a drive
command of more than 50% and the GEARSWITCH is on Auto
Lo, the gear will switch to high and the GEARSWITCH parameter
changes to Auto Hi.
• <Auto Lo> When entering a setpoint which will generate a drive
command of less than 10% and the GEARSWITCH is on Auto Hi,
the gear will switch to low and the GEARSWITCH parameter
changes to Auto Lo.
AUTO TARE This command allows the current weight value to be entered into the
TARE memory when the product hopper is empty.
Switch of the automatic refill and then tare.
For KSU-II/KCM select parameter then press
For KSL press F5-MORE then
For KSC press
TARE
Tare Weight
Weight of the feeder and hopper with no material. This value will set
automatically when Auto Tare function is executed.
Input range: 0 to scale range [kg]
NET WEIGHT
Net Weight
Display of the current weight of the feeding material on the scale.
Net weight = Gross Weight - Tare
Range: Display only 0 to scale range [kg]
Parameter Definition
Table page 2 of 5

Docu-No.: 0590020601-EN Rev. 1.6.0 Page13
ProgrammingReference 1
Productchangemenu 1.1
AUTO FF CALIB This action permits easy feeder calibration. For this the program
parameter <CAL DC> and <CAL TIME> have to be entered. Material
is discharged for the value of <CAL TIME> and the starting feeding
factor is calculated.
Notes:
• Calibration can be canceled with STOP.
•PressingENTER instead of RUN as noted above will abort the
AUTOFFCALIB routine and return the user to the HOME menu.
• Performing an AUTOFFCALIB function on an already running
feeder will have no effect upon operation.
▲This command will start the feeder. Make sure that nobody is
working on the machine.
For KSU-II/KCM select this parameter, press ENTER twice
and then press RUN
For KSL press MORE-F5 then press then press RUN.
For KSC press then RUN.
Attention:
Refilling and feeding errors during calibration reset the program pa-
rameter FF INIT to <0> and activate the <FEEDFACTOR ERR>
alarm.
CALIB REMAIN [s] A count down timer for the auto calibrate cycle. It shows how many
seconds are left in the Calibration cycle.
INIT FF
Initial Feedfactor
Input of the starting feeding factor to determine the motor speed. The
Drive Command is calculated as follows:
DriveCommand(%) = 100 x (Setpoint/Initial Feedfactor)
The starting feed factor can also be calculated with the command
variable <AUTO FF CALIB>. Value of <0> will cause a Feedfactor
Alarm.
The feeder will not run with a Feedfactor of <0>.
Input range: 0 to 99999 Default: 100 kg/hr
Parameter Definition
Table page 3 of 5

1 Programming Reference
1.1 Product change menu
Page 14 Docu-No.: 0590020601-EN Rev. 1.6.0
BULKDENSITY
Bulk Density
If the variable <VOL RATE>, in the <SERVICE VARIABLE INDEX>,
is set any value other than <0>, this variable will be displayed.
As the feeder runs in gravimetric control, the Bulk Density value will
be updated by the calculation: BD = FF/VOL RATE
Note:
To use this variable, do the following:
1. Enter the bulk density (BD) of the material being fed.
2. Perform an Auto Feedfactor calibration. The result is the value
<VOL RATE>, calculated as the ratio of Feedfactor (FF) /
Entered Bulk Density. The value <VOL RATE> is found in the
Service Variable Index.
When the feeder runs in gravimetric control, the <BULKDENSITY>
parameter will reflect the current material bulk density.
EMPTY FDR Empty feeder function. When started, the feeder runs at a drive
command of 70%. The feeder stops automatically if no weight loss is
detected.
Note:
<Empty Drive Cmd> may be changed by the Service Variables.
▲This command will start the feeder. Make sure that nobody is
working on the machine.
For KSU-II/KCM select EMPTY FDR, then press ENTER
twice then RUN .
For KSL press MORE-F5- then press then press
RUN.
For KSC, press the then RUN.
Notes:
• The <EMPTY FDR> action can be halted with the STOP key.
• The Net Weight Low alarm is also generated when the Empty Fdr
cycle finishes.
Parameter Definition
Table page 4 of 5

Docu-No.: 0590020601-EN Rev. 1.6.0 Page15
ProgrammingReference 1
Productchangemenu 1.1
ACTIFLOW CALIB ActiFlow calibration function
1. Fill the feeder with material.
2. Set material characteristic “Easy, Medium, Hard or Manual“ in
the KCM ActiFlow menu.
3. Run the ActiFlow calibration.
Notes:
• This calibration routine will run a frequency sweep on the ActiFlow
to find the mechanical resonance point of the feeder. During the
calibration is no material fed.
• Its important to have the feeder filled with material to a normal
operating level before running this step, because the resonance
point is significantly affected by material.
SCREW FILL When started, the motor will run (At the Calib DC) until weight loss is
detected. Then the motor automatically stops.
Parameter Definition
Table page 5 of 5

1 Programming Reference
1.2 Calibration
Page 16 Docu-No.: 0590020601-EN Rev. 1.6.0
1.2 Calibration
Use the FF Calibration menu to perform feeder calibration.
If the VOL RATE function is activated in the Service Variable Index,
the volumetric rate will be calculated if a product bulk density is
entered in the PRODUCT CHANGE menu.
1.2.1 Calibration sub-menu
• Section 1.2.2 is for motor driven feeders
• Section 1.2.3 is for vibratory feeders
Parameter Definition
INIT FF
Initial Feedfactor
Input of the starting feeding factor to determine the motor speed. The
Drive Command is calculated as follows (not for vibratory feeders):
DriveCommand(%) = 100 x (Setpoint/Initial Feedfactor)
The starting feed factor can also be calculated with the command
variable <AUTO F.F. CALIB>. Value of <0> will cause an Feedfactor
Alarm see page 21. The feeder will not run with a Feedfactor of <0>.
Input range: 0 to 99999
Default: 100 kg/hr
AVG FF
Average Feedfactor
The value shows the estimated mass flow value expected at 100%
drive command and is calculated as (not for vibratory feeders):
AverageFeedfactor = 100 x (Massflow/DriveCommand(%)
Average Feedfactor represents the massflow capacity of the feeder
and is affected by bulk material characteristics and the current
feeder mechanical configuration.
Notes:
• The feeder will not run with a Feedfactor of <0>.
Input range: Display only
Table page 1 of 3

Docu-No.: 0590020601-EN Rev. 1.6.0 Page17
ProgrammingReference 1
Calibration 1.2
AUTO FF CALIB This action permits easy feeder calibration. For this the program
parameter <CAL DC> and <CAL TIME> have to be entered. Material
is discharged for the value of <CAL TIME> and the starting feeding
factor is calculated.
Notes:
• Calibration can be canceled with STOP.
•PressingENTER instead of RUN as noted above will abort the
AUTOFFCALIB routine and return the user to the HOME menu.
• Performing an AUTOFFCALIB function on an already running
feeder will have no effect upon operation.
▲This command will start the feeder. Make sure that nobody is
working on the machine.
For KSU-II/KCM select this parameter, press ENTER twice
and then press RUN
For KSL press MORE-F5 then press then press RUN.
For KSC press then press RUN.
Attention
Refilling and feeding errors during calibration reset the program pa-
rameter FF INIT to <0> and activate the <FEEDFACTOR ERR>
alarm.
CAL PROD FED
Calibrate Product Fed
Shows the amount of material discharged during calibration cycle as
calculated by the controller.
Input range: Display only in set units
ACT PROD FED
Actual Product Fed
After the Feedfactor test has been completed, enter the weight of the
actual delivered product in this variable. The <SPAN> in the
CALIBRATION Menu will be automatically calculated.
If you wish to calculate the <SPAN> manually, just ignore this entry
and proceed to the SCALE Menu, GENERAL SCALE Sub-menu and
enter the computed span there.
Parameter Definition
Table page 2 of 3

1 Programming Reference
1.2 Calibration
Page 18 Docu-No.: 0590020601-EN Rev. 1.6.0
SPAN
Weight Span
This is the weight span and it is automatically calculated when an
entry is made to the <ACT. PROD FED> variable. This is the value
that corrects for massflow inaccuracy. For feeding, the span must be
nearly 1.000 or there is a problem with the weighing system. This
value is ‘read only’.
If you wish to calculate the <SPAN> manually, just ignore this entry
and proceed to the SCALE Menu, GENERAL SCALE Sub-menu and
enter the computed span there.
Default: 1.000
CAL CORRELA-[%]
Calibrate Correlation
Note:
Not used for vibratory feeders
Will be automatically calculated during calibration. The value shows
the reliability of the calibration data. A value of 100% means that the
weight samples taken during calibration are extremely uniform
indicating smooth product discharge and no weight disturbances.
Input range: Display only [%]
CAL CORR LIM-[%]
Calibrate Corr Limit
Note:
Not used for vibratory feeders
If the <CALIB CORRELATION> is below this limit value the
feedfactor will be set to <0>, the calibration test aborted and a
Feedfactor Alarm will be generated.
Note:
This value self-adjusts after each completed calibration cycle.
Input range: 0 to 99.9% Default: 80%
CAL DC-[%]
Calibrate Drive Cmd
Note:
Not used for vibratory feeders
Drive command used during the auto calibration cycle.
Input range: 0 to 100% Default: 10%
CAL TIME-[sec]
Calibrate Time
Note:
Not used for vibratory feeders
Input of the duration of the automatic calibration cycle.
Input range: 15-999 seconds Default: 30 seconds
Parameter Definition
Table page 3 of 3

Docu-No.: 0590020601-EN Rev. 1.6.0 Page19
ProgrammingReference 1
Calibration 1.2
1.2.2 Feedfactors sub-menu for motor driven feeders
Parameter Definition
REFILL ARRAY
Feedfactor Array or
Density Array
ON Refilling feedfactor storage array is on. The feeding
factor values are stored in these registers when the
gravimetric mode is active. During refilling, the stored
feeding factor values in conjunction with setpoint are
used to establish proper drive command.
OFF The refilling feedfactor storage array is off. The last
average feedfactor just prior to refill is used in
conjunction with setpoint to control feeding during
refilling.
Input range: On or Off Default: Off
Notes:
• When <ON>, the Refill Array routine checks that the array FF
Empty and FF Full are within 0.5 to 2.0 times the current average
feed factor, otherwise the FF array is cleared.
• If the feed factor changes more than 15% (0.5 times the service
variable RefArr DevLim), the refill array is cleared.
FEED FACT 1, 5, 9
FF Hopper Full
FF Hopper Mid
FF Hopper Empty
Display of the feeding factor values in the refilling feedfactor array.
These factors are calculated in the gravimetric mode and used
during refilling in the volumetric mode when the refilling array
registers are activated.
Full(9) = 10% below the top refilling limit.
Middle(5) = 50% below the top refilling limit.
Empty(1)= 10% above the lower refilling limit.
Note:
Consistency of values indicate little variance in bulk material flow
properties. This is ideal. Rapidly changing bulk density can affect
feeder performance over the refill range. This would be evidenced by
widely varying values of feedfactor. If the values vary highly,
consider modifying refill levels, both maximum and minimum, to
achieve more consistent feedfactors over the refill range.
Input range: Display only [MF@100%DC]

1 Programming Reference
1.2 Calibration
Page 20 Docu-No.: 0590020601-EN Rev. 1.6.0
1.2.3 Feedfactors sub-menu for vibratory feeders
Parameter Definition
MF @ 8% DC
Vibratory FF 8%
MF @ 12% DC
Vibratory FF 12%
MF @ 17% DC
Vibratory FF 17%
MF @ 23% DC
Vibratory FF 23%
MF @ 33% DC
Vibratory FF 33%
MF @ 50% DC
Vibratory FF 50%
MF @ 70% DC
Vibratory FF 70%
MF @ 100% DC
Vibratory FF 100%
These individual values are calculated automatically by the function
<AUTO FF CALIB>.
When the setpoint change exceeds the <SEPT CHG LIM>, the
controller switches to using the appropriate MF value at the Drive
Command expected.
