K1EL K44-SPLT User manual

K1EL K44 Audio Splitter Board Kit K44-SPLT
Introduction
The K44 has a great CW reader but one thing that slows most folks down is connecting audio
from their receiver to the K44's audio input. K1E recommends using audio from the receiver's
audio line output jack which, in most cases, is located on the back of the radio. Usually it's in a
multi-pin DIN accessory connector, which is certainly not very convenient. The reason the line out
works so well is that it is a high impedance output, which matches the K44 audio input, and it is
unaffected by the radio's AF gain control. You can turn the AF gain control up and down and K44
copy is unaffected.
The next best option is to plug into the radio's external speaker jack. There are two problems with
this, the first is that it is a low impedance output, usually 8 ohms. The second is as soon as you
plug something into the external speaker jack, the radio's internal speaker is muted. Our
recommendation, up to now, has been to make up a Y cable but that doesn't solve the impedance
mismatch. To solve this once and for all, we designed an audio splitter board which takes the
place of a Y cable and also solves the impedance mismatch problem. Unfortunately, it doesn't
solve the AF gain adjustment issue but it's a good compromise.
The K44 Splitter board has three 1/8 inch jacks, one jack goes to your radio's external speaker
jack, a second one goes to you exernal speaker, and a third goes to the K44's audio input jack.
Use two of our 1/8 inch to 1/8 inch audio cables as shown below and you are all set.
Features
1/8 inch (3.5mm) audio input jack. Connect this to your radio's external speaker jack.
 1/8 inch (3.5mm) speaker audio output jack. Connect this to your external speaker.
 1/8 inch (3.5mm) Hi-Z audio output jack. Connect this to the K44's audio input jack.
 K44 audio is coupled through a low level impedance transformer
 4 - 16 ohm audio input, 4 - 16 ohm speaker output and 4.7K ohm output impedance to K44.
 Audio attenuator to prevent K44 audio overload.
 Negligible effect on external speaker volume or tone.
 All connectors are on board with no flying leads or components.
 External power is not required.
 Easy assembly with large through hole components.
Figure 1 – K44 Audio Splitter board
K44-SPLT Manual A.1 8/14/ 018 Page 1

K1EL K44 Audio Splitter Board Kit K44-SPLT
Construction
Building a K44-SP T kit is quite easy. All components are through hole and ¼ watt resistors are
used to make it easier to identify color codes. It will take about one half hour to build the kit,
previous soldering experience is suggested. Even if you are an experienced kit builder, please
review Appendices A, B, and C before starting.
Bill of materials
R1 – 4.7 K ¼ watt resistor (violet,yellow,red) C1 - .1 uF Ceramic capacitor
R2 – 2.7 K ¼ watt resistor (red,rellow,red) J1,J2,J3 – 1/8” phone jack
R3 – 22 ohm ¼ watt resistor (red,red,black) T1 – Audio transformer
Figure 2 – K44 Parts ocator
There are only four leaded components, install those first, solder, and then trim leads. We
recommend using an ohmmeter to identify the resistors. Color codes are listed in the Bill of
Materials.
Now install the three 1/8” phone jacks. The best way to do this is to first tack solder one pin
to hold the connector in place and then solder the remaining pins.
Finally install the audio transformer. This must be oriented correctly for it to work properly.
Note the GD marking on the top of the transformer. Rotate T1 so that the position of the GD
marker matches the picture above.
That completes the assembly, recheck your component placement and organize the cabling
arrangement. We ship a 1/8” to 1/* inch cable with the kit. This would be used to connect the
splitter to your radio's external speaker output. If your radio does not use an 1/8” inch connector
you will need to find an adapter. Contact us if you are having difficulty locating one. Your external
speaker will connect to J3. In most cases your speaker will have an 1/8” connector so just plug it
in. If not an adapter is required. You probably have an 1/8” to 1/8” cable that was supplied with
the K44. Attach this between J2 and the K44's Audio Input jack. A typical cabling example is
shown on the next page.
K44-SPLT Manual A.1 8/14/ 018 Page

K1EL K44 Audio Splitter Board Kit K44-SPLT
Figure 3 – K44 Audio Splitter cabing example
Figure 4 – K44 Audio Splitter cabing closeup
Here we have connected the K44-SP T to an IC-7300's external speaker jack and are using a
Radio Shack external speaker. Note that the connection to the K44 is very simple, just one cable
from K44-SP T J2 to K44 Audio Input.
Revision History
Manual Rev A.1 - Initial Release
K44-SPLT Manual A.1 8/14/ 018 Page 3

K1EL K44 Audio Splitter Board Kit K44-SPLT
K44 CW Reader Settings, or how to get the best copy out of your CWR
1) The K44 CWR does not like noise. If you set the signal level properly, noise will be less of
an issue. Before trying to copy any stations, find a frequency where there is no activity. If
there is a lot of band noise, you may see the EDs respond to the noise and climb up two
or three EDs. This is a bad setup. Use the K44's gain adjustment (SHIFT+ENCODER
CCW) to reduce the gain until either the first ED never or just barely lights. A gain
setting of 3 is a typical high noise setting but it is highly dependent on the signal level you
feed into the K44. Once the gain is set correctly, you will find that the EDs will respond
accurately to CW signals and provide much better copy.
2) Find the optimal gain setting in quiet band conditions. Again find a quiet band spot and
adjust the CWR gain until the first ED just barely lights. If you encounter very strong
stations, you may have to reduce gain as described in the next paragraph.
3) Avoid overloading the K44's CW decoder. Too much gain can be just as bad as not
enough. In general, you should set maximum signal level to the point where the 5th ED
on the right just barely lights when a station is tuned in. This is the point where signal
clipping first occurs. While the K44 CWR handles overload pretty well, reducing the gain
gives you the narrowest filtering. If the signal increases beyond clipping, the 5th and 1st or
2nd EDs will light at the same time. This is an extreme overload condition and can
happen with very strong signals. You should back the CWR gain off to get the signal level
under control. In extreme cases you may need to reduce the receiver's RF gain setting.
4) The CWR's noise iltering setting does matter. This filter, adjusted by A T-ENCODER,
essentially controls the width of signal dropout correction. These dropouts are caused
mostly by fast burst noise such as static crashes. These dropouts are very short in
comparision to the width of a CW dit or dah and can be filtered out automatically. The
higher the filter setting, the more aggressively dropout reduction is employed. Not
surprisingly, very high settings will distort the CW integrity and will result in copy errors,
especially at higher CW speeds (25 WPM and above). Our recommendation is to leave
the filter at a low setting and use it only when there is a lot of atmospheric noise.
5) A receiver's automatic noise blanker does not help. Due to the way a noise blanker
works, it really confuses the CWR and for that reason we suggest not using it. In addition,
a fast AGC setting should also be avoided. Fast changes in signal level will also confuse
the CWR and affect copy. We suggest always using a slow attack AGC.
6) Narrow CW ilters are not always worth using. Narrow CW filters (200 and 400 Hz) do
ring and distort the detection timing of the CWR. If the detected element widths aren't
correct then the CWR will make incorrect decoding decisions and misdecode letters. The
CWR has a built-in 6 pole narrow bandpass filter and in most cases this is all you really
need. That said, a good 2.3 KHz SSB filter with steep skirts does a good job in filtering
out adjacent signals and in most cases that's all you will need.
The K44-SP T is fully warranted to the original purchaser against defects in materials and
workmanship for one year after purchase. This warranty does not cover damage caused by
accident, improper care, or lightning damage. Please contact us before returning your K44-SP T
for repair and we will issue an RMA.
Please submit support questions by e-mail to: [e-mail]
While every effort has been made to insure that the K44-SP T design is safe and the
documentation is clear and accurate, it is still possible to cause equipment damage or incur
personal injury if
a) K44-SP T is not used as intended
b) K44-SP T is connected incorrectly
c) K44-SP T is modified in any way
K1E Systems can not be held responsible in these or similar events.
K44-SPLT Manual A.1 8/14/ 018 Page 4
