K40 rd950 User manual

Portable All-Band Radar
and Laser Detector
RD950
Owner’s Manual

K40 Consult
Don’t l ke to read manuals?
Call our exper enced K40 Consultants.
We’ll expla n the whole th ng.
800.323.5608
K40 ELECTRONICS
600 Tollgate Rd., Su te A
Elg n, IL 60123
www.K40.com

Table of Contents
Mounting and Powering the RD950 . . . . . . . . . . . . . .4
Mounting Instructions . . . . . . . . . . . . . . . . . . . . 4
Power Connection. . . . . . . . . . . . . . . . . . . . . . . 4
Wake-Up Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Receiving Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Radar Alert Sequence . . . . . . . . . . . . . . . . . . . .6
Laser Alert Sequence . . . . . . . . . . . . . . . . . . . . .7
on-Police Alerts . . . . . . . . . . . . . . . . . . . . . . . .7
K-Band Filter . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Traffic Sensor Filter . . . . . . . . . . . . . . . . . . . . . .7
Re erence Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Special Features / Functions . . . . . . . . . . . . . . . . . 10-11
Dim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Filter (Sensitivity) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Menu / Customizable Settings . . . . . . . . . . . . . . . . . .12
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . .13
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Guarantees . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
3

Mounting and Powering the RD950
Mounting Instructions
To help ensure that your RD950 functions properly and
offers maximum protection, please follow these mounting
instructions:
1. Clean the area of the windshield where the RD950 will
be mounted.*
2. Attach the supplied Windshield Mounting Bracket to
your vehicle’s windshield by firmly pressing the suction
cups and the bracket to the windshield.
a. Mount the bracket as low as possible near
the center of the windshield.
b. Do not mount the RD950 behind wipers or any
metal obstructions.
c. Slide the RD950 unit onto the bracket until it clicks
to complete the mounting.
d. The bracket may need to be leveled by carefully
bending it once the RD950 is mounted.
*IMPOR AN NO E: Some windshields include a metallic coating that can
significantly affect eception of ada signals. Consult with you deale o
check you vehicle’s owne ‘s manual to dete mine if you windshield has
such a coating.
Power Connection
1. Plug the small end of the supplied Power Cord into the
Power Input Jack on the left side of the RD950.
2. Plug the large end of the Power Cord into your vehicle’s
12V outlet.
3. Switch on the RD950 by rotating the Power On / Volume
Control Wheel located on the left side of the unit.
No power? See Troubleshooting Guide on page 13.
4

Wake-Up Sequence
(using facto y default settings)
Once your K40 RD950 has been mounted and had the power
connected, you may begin use immediately by following
these steps:
1. Switch on the RD950 – Rotate the Power On / Volume
Control Wheel on the left side of the unit.
2. Listen for Wake-Up Sequence – The RD950 will an-
nounce (voice) and display (screen) K40 SCAN then go
through a “wake-up sequence” lasting approximately 5
seconds.
•You will hear and see all bands report.
3. You’re ready to drive! – The RD950 will now display
your Filter setting (Highway, City, or Filter), (page 10).
Want help programming your RD950?
Call 800.323.5608
5

Receiving Alerts
The K40 RD950 provides a combination of audio and visual
alerts to warn you when radar and laser signals are detected.
Radar Alert Sequence
The RD950 detects all orth American police radar signals
(X, K, and Ka-Band). When a radar signal is identified:
•A voice alerts which band was detected. (This assumes the
factory default “Voice On” setting has not been changed.)
•A series of beeps indicates the strength of the signal. Each
band has its own distinctive beep.
•The display will provide you band and strength information.
Radar Alert Examples:
You are driving and a weak K-Band signal is detected:
Visual Alert:
Audio Alert: Voice announces, “K-Band,” followed
by slow beeps.
As you approach the source, the signal becomes stronger:
Visual Alert:
Audio Alert: Beeping is faster due to stronger signal.
Radar source strength: weak medium strong
Display reading: 123 456 789
Audio alert beeps: slowly rapidly
6
K2
K8

Laser Alert Sequence
When the RD950 detects a laser signal:
•A voice alert announces, “Laser.” (This assumes the factory
default “Voice On” setting has not been changed.)
•You will then hear a distinctive audio tone.
•Display indicates laser has been detected.
•OTE: Unlike radar, signal strength from laser remains
constant.
Laser Alert Example:
You are driving and laser is detected:
Visual Alert: Laser
Audio Alert: Voice announces, “Laser,” followed by
distinctive audio tone.
Alerts from Non-Police Signals
Your RD950 is sensitive enough to detect signals generated
by non-police equipment, such as automatic doors. To learn
how to deal with these signals, please read about FILTER
options (page 10).
K-Band Filter
Your RD950 rejects alerts from vehicles on the road (including
your own) equipped with radar-based safety features, such as
collision avoidance. Police radar reception and detection
range is unaffected by this feature.
raffic Sensor Filter
Your RD950 will reject alerts from traffic flow sensors usually
encountered during highway driving. Enable this filter through
the menu (page 12). 7

8
RD950 Rada and Lase Detection
Reference Guide
Windshield Mounting Bracket
(with suction cups) – For proper
installation (page 4).
Power Input Jack – Insert
small end of power cord
here, and large end into
12V outlet (page 4).
Power On / Volume
Control Wheel – Turn on the
RD950 and adjust volume of
voice / tones (page 4).
MUTE Button – Press and release to
mute audio for 30 seconds or the
duration of the alert. Press and hold
for 3 seconds to engage a 5-minute
mute (page 11).

9
ME U Button – Press and release
to enter ME U mode (page 12).
Dot Matrix Display – Provides alert
information via alphanumeric text.
Speaker – Alerts delivered via voice
and tones.
FILTER Button – Press and release
to select level of alert sensitivity
(page 10).
To Set Preferences – Both ME U and MUTE buttons
are used to change settings (page 12).
DIM Button – Press and release to
adjust display brightness (page 10).

10
Special Features / Functions
DIM
•Press and release DIM button to adjust display brightness
to accommodate various driving environments. Your setting
will automatically be saved with the exception of “Off.” The
“Off” setting will revert to “Auto” upon RD950 wake-up.
he 5 options include:
1. “Day” (B ight)
2. “Dusk” (Medium / facto y default)
3. “Night” (Dim)
4. “Auto” (Display adjusts automatically f om 5 seconds in
“Day,” 5 seconds in “Dusk,” and the du ation of
the ale t in “Night”)
5. “Off” (No display, still eceive full audio ale ts)
FIL ER
(i.e. signal sensitivity)
The FILTER button offers three levels of sensitivity settings
to accommodate various driving situations. To change the
level at any time, press and release FILTER button.
Settings Sensitivity Recommended Use
1. Highway Detects all orth American police For highway travel or in any
(facto y default radar signals (X, K, and Ka-Band) area in which you are unfam-
at full sensitivity. iliar with the types of radar
used.
2. City 50% reduction in X-Band sensi- When traveling in an urban
tivity (the most common source area with minimal non-police
of non-police radar). radar signals.
3. Filter X-Band off. 50% reduction in When traveling in a congested
K and Ka-Band sensitivity. traffic area with a high concen-
tration of non-police radar
signals.
setting)

11
MU E
Using the MUTE button, the RD950 provides you two ways
to mute audio alerts (both voice and tones):
•Press and release MUTE button to mute audio for 30
seconds or the duration of the alert. Voice will announce,
“Mute On,” and the display will show Mute On.
•Press and hold MUTE button for 3 seconds to mute
audio for 5 minutes or the duration of the alert. Voice will
announce, “Extended Mute On,” and the display will
show Ext Mute.
OTE: You will only receive new alerts as visual indications
on the display while this feature is engaged.

12
Menu / Customizable Settings
The RD950 comes with factory default settings on certain
features that we’ve learned are desirable for our customers.
o access and change any of the 10 selectable preferences:
•Press and release ME U button to scroll through the
preferences until you reach the option to be changed.
•To change setting, press and release MUTE button. Both
the display and voice will announce the change.
•Press and release ME U button to continue scrolling to
another preference.
1 Voice Type Female Choose male or female voice for audio alerts.
2 Audible Voice On For all initial audio alerts: “Voice On” uses
voice; “Voice Off” uses tones only.
3 Wake-Up Wake- Controls length of startup sequence after
Up powering on the RD950. “Wake-Up Long”
Long is a 5-second sequence. “Wake-Up Short”
uses an abbreviated sequence.
4 Traffic Sensor Off Enables filtration of K-Band radar signals
Filter from traffic flow sensors.
5 Automute Off Automatically reduces volume by 50% after
5 seconds.
6 X-Band On Enables the detection of X-Band radar.
7 K-Band On Enables the detection of K-Band radar.
8 Ka-Band On Enables the detection of Ka-Band radar.
9 Laser On Enables the detection of laser.
10 Factory Reset RESET Original factory default for all settings.
Default
Setti g
Me u Optio s
(in o de displayed) Descriptio
•The display will show Exit and the voice will announce,
“Exit.”

13
Troubleshooting Guide
Problem Possible Cause Solution
Plug not inserted properly. Reinsert plug and rotate.
Blown fuse in power cord. Replace fuse with 2 amp
250 Volt F2AL fuse.
12V outlet not clean or Consult your dealer or auto
negatively grounded. mechanic.
Defective fuse or electrical Consult your dealer or auto
wiring for 12V outlet. mechanic.
Partially blocked antenna or Reposition the RD950 to
lens opening. ensure unobstructed view of
the road ahead.
Radar / laser signals unable Determine if your vehicle has
to pass through windshield. a heated windshield or is
covered with a metallic tint.
Check your vehicle’s owner’s
manual or consult with your
dealer.
High concentration of non- Use Filter Mode
police radar sources. (see page 10).
No visual
display or
audio (RD950
ot receivi g
power)
Weak or o
detectio
ra ge
Erratic or
freque t alerts
If you have any questions, please call one
of our experienced K40 Consultants
toll-free at 800.323.5608
Warranty
K40 Electronics offers a one-year “repair or replace” product
warranty if your RD950 fails to work properly. To ensure you
are covered by our warranty, please register your
RD950 online today by visiting K40.com.

Register your K40 RD950 today to
activate your guarantees:
Guaranteed immunity rom speeding tickets
If you get a radar or laser speeding ticket within one year of
purchase, we’ll reimburse you for the full cost of the ticket.*
Guaranteed per ormance
If your K40 RD950 does not outperform any other radar
detector you’ve owned, return it within 30 days for a full
product credit.
One-year warranty
K40 offers a one-year “repair or replace” product warranty if
your RD950 fails to work properly.
*Offer not valid for speeding ticket violations incurred in school or
construction zones, or connected with a DUI or DWI.
Register your RD950 online today by visiting K40.com.
14

FCC ID: W75-RD950
This device co plies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device ay not cause har ful interference,
and (2) this device ust accept any interference
received, including interference that ay cause
undesired operation.
In addition, any changes or odifications to this
product, which are not expressly approved by K40
Electronics in writing, could void the user’s authority
to operate this product.
Product subject to o e or more of the followi g pate ts:
U.S. Pate ts 5,001,777
RE39,038
RE40,653
RE41,905
Other pate ts pe di g
Learn more at K40.com ©K40 Electro ics

44817-1 4/16
