K40 1000 User manual

Installation Instructions
Installation Instructions
& Recommended Procedures
WARNING & BI-COLOR LED(S)
(MODELS: K40-2000/1000)
1. Consult with vehicle owner about LED location. For best visibility, choose a mounting location as close to the vehicle
gauges as possible.
2. Check for proper clearance behind the area where the LED(s) will be installed (approximately 1”) and drill a 3/16” hole
in the chosen location for the LED(s). K40-2000 models require the mounting of a second LED for rear radar warnings
(see diagram A1).
3. If using the optional bi-color city/highway LED, choose a mounting location in the dashboard area that is below the
driver's line of sight.
4. Check for proper clearance behind the area (approximately 1”), and drill a 19/64” hole for the bi-color LED location.
Insert the LED into the drilled location and fasten it in place with the provided barrel fastener (see diagram A2).
5. Route all LED wires under the dash per diagram A3, and connect according to the separately enclosed block
wiring diagram.
DIAGRAM A1
2000/1000 MODELS
1"
1"
DIAGRAM A2
RED ALERT LED BI-COLOR LED
BARREL
FASTENER
FRONT
ALERT
REAR
ALERT
WHITE/COPPER
L.E.D. WIRES
BLACK/SILVER
L.E.D. WIRES WHITE/SILVER
L.E.D. WIRES
BI-COLOR
L.E.D.
GRAY/COPPER
GRAY/SILVER
BLACK
BLACK/COPPER
L.E.D. WIRES
PIEZO SPEAKERS
(MODELS: K40-2000/1000)
1. Use the provided double stick "O" ring tape to mount the piezo
speakers.
2. For maximum audio output and concealment, mount the front
piezo speaker in the driver's left air vent. Mount the rear piezo
speaker in the driver's right air vent.
3. Route the piezo speaker zip cord wires through or under the dash
and connect according to the separately enclosed block wiring
diagram (see diagram B1).
DIAGRAM A3
DIAGRAM B1
FRONT PIEZO
SPEAKER
REAR PIEZO
SPEAKER
LEFT AIR
VENT
RIGHT AIR
VENT
CLEAR/COPPER
WIRES
CLEAR/SILVER
WIRES
BROWN/SILVER
WIRES
BROWN/COPPER
WIRES

1. Consult with vehicle owner about Pod location. For best
visibility, choose a mounting location as close to the vehi-
cle's gauges as possible.
2. Before mounting the Warning Pod(s), clean both the Pod
surface and desired mounting location on the dash with
isopropyl alcohol.
3. Position the Warning Pod(s) on the dash with the provided
double stick "O" ring tape. K40-2000P models require the
mounting of a second Pod for rear radar warnings.
4. Route the black cables from the Warning Pod(s) through or
under the dash per diagram C1, and connect according to
the separately enclosed block wiring diagram.
FRONT
WARNING POD
BLACK/COPPER
DIAGRAM C1
REAR
WARNING POD
WHITE/COPPER
CLEAR/SILVER
BROWN/SILVER
BLACK/
SILVER
CLEAR/
COPPER
WHITE/
SILVER
BROWN/
COPPER
FRONT RADAR RECEIVER
(ALL MODELS)
All radar receivers can be mounted behind plastic, rubber, or fiberglass up to 1/4” thick. Do not mount
receivers behind metal, carbon fiber, or chromed plastic.
NOTE:
1. Choose a mounting location in
the front of the vehicle that is not
obstructed by any metal, carbon
fiber, or chromed plastic. The
radar receiver can be mounted
horizontally or vertically, provided
the arrows are pointing forward,
towards the road ahead.
2. Mount the radar receiver to the
vehicle's structure using the
supplied screws or wire tires
(see diagram D1).
3. Connect the radar receiver to the 10’ black radar re-
ceiver cable. Align slot on cable plug to the notch on
radar receiver socket, slide the locking ring forward over
the socket, and turn ring clockwise 1/4 turn to engage
safety lock (see diagram D2).
4. Route and affix the radar receiver cable along the inner
fender in the engine compartment to the firewall using
the provided wire straps.
5. Route the radar receiver cable through a factory rubber
grommet on the firewall and into the passenger com-
partment (see diagram D3). Connect wires according to
the separately enclosed block wiring diagram.
DIAGRAM D1
DIAGRAM D2 DIAGRAM D3
RADAR
RECEIVER
SELF-
TAPPING
SCREWS
METAL
SUPPORT
RADAR
RECEIVER
SELF-
TAPPING
SCREWS
FACTORY
GROMMET
FRONT
RADAR
RECEIVER
CABLE
WHITE
GREEN
BROWN
For added installation convenience, Warning Pods contain both a warning LED and piezo speaker.
NOTE:
WARNING POD(S)
(MODELS: K40-2000P/1000P)
LOCKING RIB
LOCKING
WINDOW
LOCKING
PIN
LOCKING
RING
KEY
GUIDE KEY WAY
LOCKING
PIN

REAR RADAR RECEIVER
(MODELS: K40-2000/2000P)
1. Choose a mounting location in the rear of the vehicle that is not
obstructed by any metal, carbon fiber, or chromed plastic. The
radar receiver can be mounted horizontally or vertically, provided
the arrows are pointing to the rear, towards the road behind the
vehicle.
2. Mount the radar receiver to the vehicle's structure using the sup-
plied screws or wire tires (see diagram E1).
3. Connect the radar receiver to the 25’ black radar receiver cable.
Align slot on cable plug to the notch on radar receiver socket, slide
the locking ring forward over the socket, and turn ring clockwise
1/4 turn to engage safety lock (see diagram E2).
4. Route the rear radar receiver cable into the trunk through a
factory grommet.
5. If a factory grommet is not available, use the provided strain relief:
a. Choose a location in the trunk compartment as close to the
radar receiver as possible.
b. Drill a 1/2” hole into the chosen location for the strain relief.
c. Install the strain relief and tighten the mounting nut securely
(see diagram E3)
d. Route the rear radar receiver cable through the strain relief,
leaving a little slack in the receiver cable.
e. Tighten the waterproof gasket nut to create a water proof seal.
6. Route the rear radar receiver cable through the trunk, into the
passenger compartment along the driver's side, and under the
dash. Connect wires according separately enclosed block
wiring diagram.
All radar receivers can be mounted behind plastic, rubber, or fiberglass up to 1/4” thick. Do not mount
behind metal, carbon fiber, or chromed plastic.
NOTE:
METAL
SUPPORT
SCREWS
REAR RADAR RECEIVER
(BEHIND BUMPER COVER)
RECEIVER
DIAGRAM E1
DIAGRAM E2
VOLUME CONTROL MODULE
(all MODELS)
1. Choose a mounting location that's accessible to the driver in the dashboard area
or in the vehicle's center console that will not obstruct or block any moving parts.
Before drilling, make sure there is enough clearance for the
Volume Control Module behind the chosen mounting location
(approximately 3 1/4”).
CAUTION!
2. Drill a 5/16” hole.
3. Mount the Volume Control Module with the lock washer and nuts, and push the
filter and volume adjustment knobs onto the module shaft (see diagram F1).
4. Route the Volume Control Module cable under the dash and connect wires
according to the separately enclosed block wiring diagram.
ON-OFF/
FILTER
ADJUSTMENT
VOLUME
CONTROL
MODULE
MOUNTING
NUTS
ON-OFF/FILTER
ADJUSTMENT
KNOB
LOCK
WASHER
VOLUME
CONTROL
KNOB
DIAGRAM F1
DIAGRAM E3
ROUTE THROUGH VEHICLE
MOUNTING NUT
METAL
TRUNK
WATERPROOF
GASKET MATERIAL
TO RADAR DETECTOR
Do not drill into the trunk until you know
what is on both sides of the drilling area.
Watch for cables, spare tires, and gas tank.
CAUTION!
LOCKING RIB
LOCKING
WINDOW
LOCKING
PIN
LOCKING
RING
KEY
GUIDE KEY WAY
LOCKING
PIN

44506-1 7/07
