Kabola 65-005 User manual

MANUAL
ROOM THERMOSTAT KABOLA
WITH GSM MODULE
ALWAYS A WARM WELCOME ON BOARD

www.kabola.nl1
Backlit display
After you press any button, the display
is backlit automatically for at least 5 s.
CONTROLS
turning change of temperature setting
short press selection (entry) confirmation
quick change of required temperature or
program (see page 8);
viewing other information (see page 8)
long press step back (only in the CONST mode, (see page 5)
press opening the main menu or returning a step back
The GSM aerial is included in the
packing (can be replaced by an external
one with higher sensitivity).
1
2
4
678
9
10 12
13
14
15
16
17
3
5
11
18
Connector for external sensor
can be used with sensors CT04-10k
(order No. 0012), CT01-10k (order No.
0015) or CT02-10k (order No. 0013)
Connector for power supply No. 1
for the AD05-jack power supply
(included in the packing)
Connector for power supply No. 2
for power source installed in a wiring
box (not included in the packing)
SIM card holder
space for inserting the SIM card
(the SIM card is not included in the
packing)
Backup batteries room
to backup the time running, always
use rechargeable batteries of the AA/
R6 type (not included in the packing)
1. Current day (in the Prog mode,
selection of days to be
programmed)
2. Heating on indication
3. Current room temperature
4. Anti-freeze temperature
5. Modes for setting programs
(PROG) and constants (CONST)
(page 4 and 5)
6. Automatic mode (page 3)
7. Manual mode (page 3)
8. Clock setting mode (page 3)
9. Holiday mode (page 3)
10. Permanent shut-off (page 3)
11. Summer mode (page 6)
12. Boiler inspection indication
(page 8)
13. External sensor connection
indication (see page 7)
14. Current time
15. Current date (various
parameters in the CONST
mode; for details, (see page 5)
16. Status line, dynamically
changing according to the
process running
17. Key lock indication (page 8)
18. Low battery indication
Type AD05-jack
5V/ DC, 2.5 A
Open the SIM card
holder and insert
the SIM card in the
direction indicated;
then close the holder
again.
Type CT04-10k
silicone conductor, length
3 m for measurements
up to 99 °C, including
connector
GST type – external
9 dBm, SMA connector
(not included in the
packing); can be
purchased separately,
order No. 1330,
on www.elbock.cz.
Use the type:
5V / DC, 2,5 A (SELV)
MIND THE POLARITY!
0 V
+5V
A sophisticated thermostat which can be remotely controlled by
means of SMS messages from your mobile phone. The thermostat
includes two devices, temperature controller and GSM module,
which co-operate, thus increasing the comfort of the heating
system control. Simple control elements are used for setting;
intuitive navigation in the selected language (CZ/PL/EN/DE/RU/SVK).
Remote control is executed by means of brief SMS which enable
you, for example, to change the required temperature or turn off
the system. This unique thermostat with a big backlit display and
intelligent PID-control offers a wide variety of usage in residential
houses, offices as well as recreation areas.
DESCRIPTION
LCD DESCRIPTION

www.kabola.nl2
Simkaart code wijzigen. Nieuwe inlogcode aanmaken, (hiervoor geen 4 x 0 gebruiken). Hierna Simkaart plaatsen en activeren.
Nadat de THERMOSTAAT voor het eerst wordt ingeschakeld, verschijnt de volgende mededeling op het LCD-scherm;
volg de instructies voor de bijbehorende instellingen (PLAATS SIM-KAART VOORDAT DE VOEDING WORDT AANGESLOTEN):
MENU
Fig.1
Fig.2 Wiring diagram:
THERMOSTAT BOILER
*
*
potential-free
(voltage-free) contact
The thermostat terminals are
marked differently with every
boiler type; therefore, observe
the wiring recommended by
the boiler manufacturer!
connector for the
AD05 power source
connection
Fig.3
AA rechargeable
battery
AA rechargeable
battery
The thermostat enables backup of time in case
of power failure. You must use rechargeable
batteries 2x1,2 V, type AA/R6. After power
failure, the time remains current (approximate
service life: 2 years, according to the type of
batteries used). The advantage is recharging of
the batteries after the power supply is restored.
CAUTION: THE BATTERIES ARE NOT USED FOR
SUPPLYING THE THERMOSTAT, FOR WHICH THE
AD05-jack POWER SOURCE MUST BE USED (see
page 1).
COM NO
Install the thermostat at a suitable place where its operation will
not be affected by direct flow of hot air from a heating source, by
sunshine or other disturbing effects. Do not install it on an external
wall either. The installation height should be at least 1.5 m above
the ground. Locate the thermostat in the so-called reference room,
such as the living room (the heat source will be switched
according to the temperature in this room).
The installation and battery replacement can only be done by
a person with adequate qualification! Before installation,
disconnect the power supply!
1. Switch off the main circuit breaker.
2. Remove the control part from the bottom cover of the device (Fig. 1).
3. Chip off the plastic piece in the middle of the bottom cover to lead in the conductors.
4. Run the conductors through the hole and connect them to the terminal board, see the wiring diagram.
5. Fasten the bottom cover to the wiring box by means of screws (Fig. 2).
6. Insert the activated SIM card into the SIM card holder at the back of the control part.
7. If you want to back up the time, install the fully charged rechargeable batteries (see Fig. 3).
8. Mount the control part onto the bottom cover (Fig. 2).
9. Connect the power supply to the connector No. 1 or No. 2 (see page 1).
ATTENTION THERMOSTAT MUST BE POWERED FROM ONE SOURCE!!
10. Switch on the main circuit breaker and test the thermostat for correct connection, see page 4 (TEST).
11. Upon the first start (or reset), the thermostat shows the “SET CLOCK”, “ENTER PIN” messages; set the current time and date
acc. to the instructions on page 3, enter the PIN acc. to page 7 and select language acc page 5.
TEST GSM SET TIME
ENTER PIN
SET TIME
CONSTANTS 13 ENTER PIN
SET HOUR
GSM module is
being checked.
Press the “MENU “, button twice;
choose the CLOCK mode by
turning the “ “ button and
make the settings acc. to page 3.
Press the “MENU “, button twice;
choose the CONST mode by
turning the “ “ button; move
on to set CONST13 acc. to page 7.
Change the simcard code. Make a new login code, (don‘t use 4 x 0). Place the simcard and activate it.
After you switch on THERMOSTAT first, the following message appears on the LCD; follow the instructions to make the corresponding
settings (INSERT SIM CARD BEFORE POWER CONNECTION):
INSTALLATION
FIRST SWITCH-ON

www.kabola.nl3
OPERATING MODES
Pressing any button first, you activate the display backlit. By another short press of the “ MENU “ button,
you open the main menu in which you can choose operating modes.
(the Pr3 weekly program set by default, see page 4)
AUTO
The thermostat works according to the weekly program settings (this program can be changed; for detailed
description, see PROG, page 4).
Press twice the “ MENU “, choose the AUTO mode by turning the “ “ and press the “ “ button to confirm.
SMS form: Auto
Change of the mode to AUTO. Thermostat will be work acc. last setting weekly program.
sms
(default temperature setting of 21°C)
MANU
The thermostat works according to the temperature setting until the next manual change.
Press twice the “ MENU “, choose the MANU mode by turning the “ “ and press the “ “ button to confirm“.
sms
SMS form: Manu
Change of the mode to MANU. Thermostat will be keep last setting temperature.
(the anti-freeze temperature of 3 °C is kept – cannot be changed)
OFF
The thermostat is permanently switched off until the next manual change of the mode.
Press twice the “ MENU “, choose the OFF mode by turning the “ “ and press the “ “ button to confirm.
SMS form: Off
Change of the mode to OFF. You can cancel the mode by the SMS: Temp xx or Auto or Manu
sms
HOLIDAY
The thermostat maintains the preset temperature until the preset date and selected time. After expiry of the
preset period, it automatically returns to the AUTO/ MANU mode last selected before the holiday.
Press twice the “ MENU “ button, choose the mode by turning the “ “ and press the “ “ button to
confirm. Step by step, set the temperature which the thermostat should keep during the holiday, date and time
of your return from the holiday. Change the values by turning the “ “ button and confirm each change by
pressing the “ “ button.
After making the settings, press the “ “ button to return to the basic screen.
Note: The holiday mode can be cancelled any time by selecting another AUTO or MANU mode.
CLOCK SETTING
Setting the current time and date.
Press twice the “ MENU “ button, choose the CLOCK mode by turning the “ “ button,
and press the “ “ button to confirm.
Change the values by turning the “ “ button and confirm each change by pressing the “ “ button
(the parameter modified is always flashing); pressing the “ “ button, you return to the menu).
PROG (PROGRAMMING)
You can set 9 weekly programs with 6 temperature changes per day. The Pr1 and Pr2 programs are empty;
Pr3 to Pr7 programs are set by default. The PrU and PrL are also set by default,
intended for the EVEN/ODD week option (for details, see pages 4 and 6).
CONST (CONSTANTS)
Setting the control parameters. For a detailed description, see page 5.
Press twice the “ MENU “ button, choose the CONST mode by turning the “ “ button,
and press the “ “ button to confirm.
AUTO MOdE
MANU MOdE
OFF MOdE
HOLIdAY
SET TEMP
SET TIME
SET HOUR
PROGRAMMING
CONSTANTS

www.kabola.nl4
TEST
Testing the correct connection to boiler.
Press twice the “ MENU “, choose the TEST mode by turning the “ “ button, and press the “ “ button to
confirm (RELAY TEST is showed on LCD). Turn the “ “ button to start testing. The output relay will be
switched on/off several times (the ON/OFF messages appear on the LCD).
(PROGRAMMING)
PROG
You can set 9 weekly programs with 6 temperature changes per day. The Pr1 and Pr2 programs are empty;
Pr3 to Pr7 programs are set by default. The PrU and PrL are also set by default, intended for the EVEN/ODD week
option (for details, see page 6).
Change in the program settings:
Press twice the “ MENU “ button, choose the PROG mode by turning the “ “ button, and press the “ “ button
to confirm.
The selected program number is flashing on the display. Turning the “ “ button, choose the program which
you want to change and press the “ “ button to confirm. Turning the “ “ button, choose the number of
days to be programmed (you can program day-by-day or 1-5 = Mon-Fri, 6-7 = Sat-Sun, or 1-7 = Mon-Sun) and press
the “ “ button to confirm.
The 1st change time starts flashing; set the time by turning the “ “ button and press the “ “ button to
confirm. Set the temperature for this time by turning the “ “ button and press again the “ “button to
confirm. The 2nd change time appears on the display. Proceed in the same way as with the first change setting.
In this way, you can set up to 6 temperature changes per day. To return one step back,
shortly press the “ “ button; to return to the main menu, press the “ “ button long.
After changing the preset program, check whether all the changes made conform to your requirements!
It is not necessary to apply all six changes to one day!
Tables of temperature programs:
Even or odd week selection:
This setting is suitable, for example, for shift operation (the requirements on thermal comfort in the object
change every week). The PrU and PrL programs will alternate automatically. The programs can also be modified
according to your requirements.
Press twice the “ MENU “ button, choose the CONST mode by turning the “ “ button, and press
the “ “ button to confirm. Repeat pressing the“ “ button until the constant No. 9 appears on the LCD.
Set YES by turning the “ “ button, and press the “ “ button to confirm.
TEST MOdE
ON OFF
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.3 1 2 3 4 5 6
05/21
05/21
05/21
05/21
05/21
07/21
07/21
12/20
12/20
12/20
12/20
12/20
16/21
16/21
16/21
16/21
16/21
18/22
18/22
18/22
18/22
18/22
21/18
21/18
21/18
21/18
21/18
06/18
06/18
06/18
06/18
06/18
21/18
21/18
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.4
1 2 3 4 5 6
06/21
06/21
06/21
06/21
06/21
07/21
07/22
15/21
15/21
15/21
15/21
15/21
22/18
22/19
18/22
18/22
18/22
18/22
18/22
22/18
22/18
22/18
22/18
22/18
07/18
07/18
07/18
07/18
07/18
18/22
18/23
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.5 1 2 3 4 5 6
08/21
08/21
08/21
08/21
08/21
08/21
08/21
15/21
15/21
15/21
15/21
15/21
22/18
22/18
18/22
18/22
18/22
18/22
18/22
23/18
23/18
23/18
23/18
23/18
09/18
09/18
09/18
09/18
09/18
18/22
18/22
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.6
1 2 3 4 5 6
07/21
07/21
07/21
07/21
07/21
07/21
07/21
15/22
15/22
15/22
15/22
15/22
22/18
22/18
18/23
18/23
18/23
18/23
18/23
22/18
22/18
22/18
22/18
22/18
09/18
09/18
09/18
09/18
09/18
18/23
18/23
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.7
07/22
07/22
07/22
07/22
07/22
08/22
08/22
1 2 3 4 5 6
15/23
15/23
15/23
15/23
15/23
22/18
22/18
18/24
18/24
18/24
18/24
18/24
22/18
22/18
22/18
22/18
22/18
09/18
09/18
09/18
09/18
09/18
18/24
18/24
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.1
program No.2
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
1 2 3 4 5 6
1 2 3 4 5 6
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program No.1
program No.2
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
1 2 3 4 5 6
1 2 3 4 5 6
Note:
5/21 means that
the required
temperature at 5
o’clock is 21 °C
All the
indicated
programs
can be
changed!
PROGRAMMING
SELECT dAY
TIME CHANGES
SELECT PROGRAM
U
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program
06/20
06/20
06/20
06/20
06/20
07/21
07/21
1 2 3 4 5 6
14/21
14/21
14/21
14/21
14/21
22/19
22/19
17/22
17/22
17/22
17/22
17/22
22/17
22/17
22/17
22/17
22/17
08/18
08/18
08/18
08/18
08/18
17/23
17/23
L
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
program
08/23
08/23
08/23
08/23
08/23
08/23
08/23
1 2 3 4 5 6
21/18
21/18
21/18
21/18
21/18
21/18
21/18
Odd-EVEN MOdE

www.kabola.nl5
CONST (CONSTANTS)
Setting the control parameters.
Press twice the “ MENU “ button, choose the CONST mode by turning the“ “ button,
and press the “ “ button to confirm.
1 ENGLISH (ENGLISH LANGUAGE SET BY DEFAULT)
Language selection (CZ/PL/EN/DE/RU/SVK).
Choose the language by turning the “ “ button and press the “ “ button to confirm.
2MINIMUM CONTROL TEMPERATURE (5 °C SET BY DEFAULT)
Setting the limit of the minimum temperature which can be set. If using the GSM module, you will be
informed by an SMS that the room temperature has dropped below this value (check CONST tEL nO,
page 7). Choose within the range from 3 °C to 10 °C (by 0.5 °C).
Set the value by turning the “ “ button and press the “ “ button to confirm.
3MAXIMUM CONTROL TEMPERATURE (39 °C SET BY DEFAULT)
Setting the limit of the maximum temperature which can be set. If using the GSM module, you will be informed
by an SMS that the room temperature has risen above this value (check CONST tEL nO, page 7).
Choose within the range from 15 °C to 39 °C (by 0.5 °C).
Set the value by turning the “ “ button and press the “ “ button to confirm.
4CONTROL TYPE (PID CONTROL SET BY DEFAULT)
Selection of the control type:
Choose the type of control by turning the “ “ button and press the “ “ button to confirm.
Note: The graphs are just tentative; the real control course differs according to current conditions in the measured object!
CAUTION! ONLY IN CASE OF LOCKING BY PASSWORD (see CONST19)
If the “ “ key symbol appears on the LCD, the constant selected cannot be modified and you must know the
PASSWORD (see CONST 19, page 8). You can change the constant after entering the password. After you exit the CONST
mode, the security lock of the constants related to the control will be activated automatically.
PID-CONTROL
PI-CONTROLHYSTERESIS
CONSTANTS
TEMP.
TEMP.
TYPE OF REGUL.
t
t
t
t
t
t
T
Topení
ON
požad.
teplota
T
Topení
ON
požad.
teplota
T
Topení
ON
požad.
teplota
hystereze
pásmo
proporcionality
t
t
t
t
t
t
T
Topení
ON
požad.
teplota
T
Topení
ON
požad.
teplota
T
Topení
ON
požad.
teplota
hystereze
pásmo
proporcionality
t
t
t
t
t
t
T
Topení
ON
požad.
teplota
T
Topení
ON
požad.
teplota
T
Topení
ON
požad.
teplota
hystereze
pásmo
proporcionality
TYPE OF REGUL.
PID = proportional-integral-derivative control
The PID-control principle consists in
continuous comparison of the current room
temperature with the desired temperature,
and automatic adaptation of the controller to
the given conditions.
This is the most perfect continuous control;
you can achieve not only short control time,
but also high accuracy without permanent
control deviation. The minimum switch-on
time is internally set to 2 minutes, the
proportional band is 2 °C, the time interval is
automatically recalculated according to
current temperature conditions.
Note: If the PID-control is selected, CONST 5 and CONST
6 are skipped automatically.
PI = proportional-integral control
The PI-control principle consists in comparison of
the current room temperature with the desired
temperature.
The PI-control aims at achieving and maintaining
the desired temperature without overshooting
(see the graph). For correct function of the
PI-control, set the control parameters according
to the type of the heating system with respect to
the room thermal inertia; see CONST 6.
Note: If the PI-control is selected, CONST 5 is skipped
automatically.
HS = Hysteresis
Difference between the desired and current
temperature.
If the hysteresis is 1 °C and the desired
temperature is 20 °C, the thermostat switches
off at 20 °C, and on at 19 °C (see the graph).
For correct hysteresis function, set the
parameters according to the heating system
type; see CONST 5.
Note: If hysteresis is selected, CONST 6 is skipped
automatically.

www.kabola.nl6
5SETTING HYSTERESIS PARAMETERS
HYSTERESIS (factory setting of 0.5 °C)
Set from 0.1 to 6 °C. According to the value preset, the thermostat switches on at the temperature:
T switching = T required - HYSTERESIS
Set the hysteresis by turning the “ “ button, and confirm with the “ “ button.
MINIMUM SWITCH-ON TIME (factory setting of 2 min)
Here you can set the minimum switch-on time of the boiler in minutes at hysteresis. Select within the range
from 1 to 5 minutes according to the type of the heating system used (see the table).
Set the value by turning the “ “ button, and confirm with the “ “ button.
6SETTING PI-CONTROL PARAMETERS
PI-CONTROL INTERVAL factory setting of 10 min.)
Select according to the object’s thermal inertia. The optimum setting usually falls within the range of 10 to 15
min. The adjustable range is 5 min to 20 min (by 1 min).
Set the interval by turning the “ “ button, and confirm with the “ “ button.
MINIMUM SWITCH-ON TIME (factory setting of 2 min.)
Select within the range of 1 to 5 minutes. The setting is given by the
heating system type, and depends on the PI-control time period selection.
Setting according to the table is recommended.
Set the value by turning the “ “ button, and confirm with the “ “ button.
PI-CONTROL BAND (factory setting of 2 °C)
This value determines the temperature at which the PI-control starts functioning. For example, the desired tem-
perature is 22 °C, the proportional band is 1.5 °C. Up to 20.5 °C, the source heats fully. When this value is
reached, the PI-control starts. The PROPORTIONAL band can be set within the range of 0.5 to 3.0 °C (by 0.1 °C).
Set the PI band by turning the “ “ button, and confirm with the “ “ button.
7PRELIMINARY SWITCH-ON OF HEATING (NO SET BY DEFAULT)
This function guarantees you the required temperature at the required time. You need not consider when to
switch the heating on in order to be warm when getting up in the morning without heating unnecessarily long
in advance. You just program the time at which you want the desired temperature. Within two operating days,
the program ascertains the thermal constants of the room and then it switches the heating on in advance
sufficiently. The preliminary switch-on time is limited to 2 hours.
Set YES/NO by turning the “ “ button and press the “ “ button to confirm.
8SUMMER MODE (NO SET BY DEFAULT)
In this mode, you are not allowed to switch the heating on. It can particularly be used in the summer
period, when you need not heat. After you enable this mode, the “ “ symbol appears on the display.
Set YES/NO by turning the “ “ button and press the “ “ button to confirm.
Note: The anti-freeze protection (3 °C) is still enabled. In this mode, you cannot change the temperature or set
the holiday mode!
9EVEN-ODD WEEK SELECTION (NO SET BY DEFAULT)
If you choose “YES”, the PrU and PrL programs will alternate automatically according to the current week
(even/odd). This setting is suitable, for example, for shift operation (the requirements on thermal comfort in the
object change every week).
Set YES/NO by turning the “ “ button and press the “ “ button to confirm.
10 HEATING / COOLING SELECTION (HEAT SET BY DEFAULT)
Setting the thermostat function.
HEATING = the output relay (for heating systems) switches if the current temperature drops below
the desired value
COOLING = the output relay (for cooling systems) switches if the current temperature rises above
the desired value
Set HEAT/COOL by turning the “ “ button and press the “ “ button to confirm.
11 TEMPERATURE CORRECTION (0 °C SET BY DEFAULT)
This is used for correcting the temperature measured by the thermostat. The setting can only be done after 12
hours of operation, when the internal sensor temperature has settled. Measure the room
temperature with a thermometer; if it is different from the temperature on the thermostat,
set the correction within the range of -5 °C do +5 °C.
Set the correction by turning the “ “ button and press the “ “ button to confirm.
HYSTERESIS
MIN TIME ON
MIN TIME ON
PI ZONE
PRE SWITCH MOdE
SUMMER MOdE
Odd-EVEN MOdE
HEATING
TEMP CORRECT
Heating type Minimum source
switch-on time
Electric heating 1
Plate radiators 2 (3)
Cast iron radiators 4
Floor heating 5

www.kabola.nl7
12 EXTERNAL SENSOR SELECTION ( - - - SET BY DEFAULT)
If an external sensor is connected, the “ “ symbol appears on the LCD (to approx. 20 minutes).
The external sensor can be used for:
1. control according to the room temperature - the sensor is located in the room ( - - - option)
2. control according to the floor temperature - the sensor is located in the floor (- - - option)
- - - If connected, the external sensor measures the temperature at the place of its installation
(suitable, for example, for places at which the thermostat cannot be located, yet you want to
control according to this room);
3, maximum floor temperature monitoring -  the sensor is located in the floor (selection of 15 to 99,5°C)
15…99,5°C If connected, the external sensor monitors the floor temperature; the maximum
temperature allowed for floor heating must be set (control according to the room
temperature, with simultaneous floor temperature monitoring).
If the preset limit temperature is exceeded, the thermostat is switched off irrespective of the room
temperature, and the “EXT SENS STOP” message appears on the LCD. The heating device is switched on again if
the external sensor temperature drops by 0.5 °C.
If the external sensor is unconnected or faulty, the “EXT SENS ERROR” message appears on the LCD.
Set the external sensor option by turning the “ “ button and press the “ “ button to confirm.
tEL nO PHONE NUMBER SETTING
Allows the following options:
1) TO SENDER SMS will be sent back to the telephone number from which the message was sent.
2) TO ANOTHER NR SMS will be sent back to the telephone number entered in the thermostat.
3) bOTH NUMBERS SMS will be sent back to both telephone numbers (combination options 1 and 2).
When choosing 2) and 3) option we enter a phone number n the international format (420123456789), to which
return SMS messages on the thermostat condition should be sent.
Is possible to enter a phone number min. 10-digit to 15-digit.
Turning the “ “ button, enter the phone number stepwise; confirm each setting with the “ “ button.
13 PIN CODE SETTING
Enter the PIN code of the SIM card inserted in the thermostat.
Turning the “ “ button, enter 4 digits stepwise; confirm each setting with the “ “ button.
14 GSM TEST
After setting the PIN code of the SIM card inserted in the thermostat is performed to test the GSM module and
PIN validation.
Turning the “ “ button to start test of GSM module and checking of PIN code.
The“ “ button displays the next constant,; pushing “ “ you return to the main menu.
15 REPLAY TEST
Testing the correct connection the thermostat to boiler (this function is identical with the TEST mode in the
main menu).
Start the test by turning the “ “ button. The output relay is switched on/off several times (the ON/OFF
messages appear on the LCD). The “ “ button displays the next constant; pushing “ “ you return to the main
menu.
Checking the
GSM module.
PIN entered
correctly.
ERROR PIN
Wrong PIN.
Reset THERMOSTAT
and enter PIN again.
13 ENTER PIN
14 GSM TEST
EXT SENSOR12
12 EXT SENSOR
EXT SENS STOP
INSERT SIM
SIM card not inserted.
Insert the SIM card,
disconnect power to
the 5 s,
make adjustment and
repeat test.
TO SENdER
TO ANOTHER NR
420000000000---
15 RELAY TEST
ON OFF

www.kabola.nl8
16 KEY LOCK (NO SET BY DEFAULT)
This is used for locking the controls as a protection against undesirable interference of a foreign person.
Set YES/NO by turning the “ “ button and press the “ “ button to confirm.
17 KEY CODE
This constant can be set if CONST 16 = YES. It is used for setting the code by which you will be able to activate the
controls. Set a four-digit combination (range from 0 to 9).
The keys will be locked within 1 minute (after opening the basic display). The “ ”
symbol appears on the LCD. If you press the “ “ or “ “ button, the LCD asks you to enter the key code; after
entering the correct code, you are able to make any changes (the controls are functional again). The controls will
automatically be locked again after you finish the setting (within approx. 1 min).
RECOMMENDATION: - Record the key code in the table
- You can cancel the code by setting CONST 16 to NO, or by restoring the default
settings of the thermostat (see CONST 20).
18 BOILER INSPECTION REMINDER (1.1.2032 SET BY DEFAULT)
Set the date on which you want to be informed about the necessity of the prescribed boiler service. At the
required time, the “MAINTENANCE NECESSARY” message and the “ ” symbol will appear on the bottom line of
the LCD (you can cancel the message by setting a new date for the next boiler maintenance!).
Gradually set the day, month and year by turning the“ “ button, confirm each setting with the “ “.
19 PASSWORD (NOT SET BY DEFAULT)
It is used for locking the constants related to the given control settings. Suitable for service technicians.
After a numerical code has been entered, the user cannot change constants No. 4, 5, 6 and 10.
If you open the CONST mode and browse the constants, the “ ” symbol appears next to the constants locked;
if you turn the “ “ button, the password is required! Unless you enter the password, the constants remain
locked. To try to unlock them again, you must exit the CONST mode and browse up the constant locked again.
Turning the “ “ button, gradually enter four digits and confirm each setting with the “ “.
20 VERSION (RESTORING THE DEFAULT SETTINGS)
Firmware version, informative parameter only.
If you press the “ “ button long (for about 3 s), the RESET message appears shortly on the LCD and
the thermostat returns to the default settings!
USER TIPS
QUICK CHANGE OF REQUIRED TEMPERATURE / PROGRAM IN THE AUTO MODE
Press twice the “ “; the required temperature starts flashing on the display. Change the required temperature
by turning the “ “ button and press the “ “. The change will last until the next program change.
SMS form: Temp xx (where xx are only integers within the range of CONST2 and CONST3)
Change of the desired temperature; the change will last until the next temperature change
given by the program.
sms
Press thrice “ “, the setting programm starts flashing on the display. Change it by turning “ “ button and
press the “ “.
QUICK CHANGE OF REQUIRED TEMPERATURE IN THE MANU MODE
Press twice the “ “; the required temperature starts flashing on the display. Change the required temperature
by turning the “ “ button and press the “ “. The change will last until the next manual temperature change.
SMS form: Temp xx (where xx are only integers within the range of CONST2 and CONST3)
Change of the desired temperature; the change will be permanent.
sms
OPERATIONAL HOURS
Push the “ “ button four times. The boiler operating hours appear on the LCD. The figure on the picture
means 906 hours 43 minutes.
Resetting the counter: When operational hours are displayed, turn the “ “ button anti-clockwise.
EXTERNAL SENSOR TEMPERATURE
Push the “ “ button five times. The current temperature of the external sensor appears on the LCD; the value
is only informative, and appears only if the external sensor is monitoring the maximum floor temperature (see
CONST 12, page 7).
16 LOCK
17 KEYCOdE
18 SERVICE dAY
19 PASSWORd
YOUR CODE
20 VERSION
TEMP. IN AUTO
TEMP IN MANU
OPER HOURS H.C.
TEMP 2Nd SENS

www.kabola.nl9
Info Information on the heating system status
Auto Setting AUTO mode, thermostat will be work acc. last setting weekly program
Manu Setting MANU mode, thermostat will be keep last setting temperature
Off Heating system switched off permanently. ; to cancel the function, use the
Temp xx message, thermostat will automatically enter into the MANU mode with the given
temperature or SMS message Auto (for AUTO mode) or Manu (for MANU)
Temp xx Required temperature change (only integer numbers can be entered, they must fall within
the permitted range of maximum and minimum temperatures –CONST2 and CONST3).
Call Back call
xx = temperature value in °C (always a two-digit number, e.g. 05)
Any type of mobile phone can be used for sending and receiving back messages!
If you can set the font size (format) in your phone, always use the MEDIUM size when writing messages
(if there are three options), or the BIG size (if there are two options).
!
Requir: xx.x Temperature required (user set)
Act: xx.x Current room temperature
Set on
Set off
Heating system On
Heating system Off
AUTO
MANU
OFF
Thermostat in automatic AUTO mode
Thermostat in manual MANU mode
Thermostat in the OFF mode (permanently off)
Sig: x Signal strength at the place where the module is located; where x is the value within the
range of 0 to 5:
0..undeterminable or no signal detected
1..the worst strength
5..the best signal strength
Sens 2: xx.x Current temperature of the external sensor
Battery! Low batteries in the thermostat
Noakcept! Error indicated (wrong SMS format, etc.)
SIGNAL GSM X Determines the signal strength at the place where the thermostat is located;
where x is a value within the range from 0 to 5:
0..undeterminable or no signal detected
1..worst level
5..best level of signal
REQUIR TEMP Information on the desired temperature preset
PROGR 3 PERIOD 2 Information on the program preset (e.g., 3) and the time interval running (interval 2)
SMS RECEIVED Information the thermostat received new SMS
HOLIDAY IN 22.7 Only displayed in the holiday mode; informs on the end of holiday when the thermostat
restores the last selected AUTO/MANU mode.
T EXT SENS 25.0 Current temperature of the external sensor, displayed only if the sensor is connected
EXT SENS STOP If the preset limit temperature of the external sensor in the maximum floor temperature
monitoring function is exceeded (see page 7), the thermostat is switched off
xx.x = temperature value in °C
BACK MESSAGES ARE SENT WITHIN 3 MINUTES!
Note: If the minimum / maximum room temperature (preset CONST 2 and 3) is exceeded, the “WARNING” SMS is
automatically sent in a form similar to that in the „Info“ form (only if you enter phone number to the thermostat,
see CONST tEL nO).
Info: If using a credit card, you must make a paid call once in 3 months. This call is executed automatically (in 80 days,
between 4 and 9 PM) to the phone number entered in the thermostat (CONST tEL nO); after 20 s, the call is termina-
ted automatically. You can execute this function earlier by means of the “Call” SMS message.
INFORMATION IN THE LCD DYNAMIC LINE
FORMS OF MASSAGES SENT
FORMS OF BACK MASSAGES FROM THE THERMOSTAT

www.kabola.nl10
EXTERNAL SENSOR:
POWER SOURCE:
Pb
LEAD FREE
in compliance with RoHS
CERTIFICATE OF GUARANTEE
(guarantee period for the product amounts to 2 years)
product No.: date of sale:
stamp of shop:
examined by:
In case of guarantee or post-guarantee service,
send the thermostat including proof of purchase to the
manufacturer’s address. The guarantee does not cover faults resulting from incompetent installation or
interference in the device design.
not included in the
packing type CT04-10k,
CYXY 2 x 0.5 mm,
10 kW, lenght 3 m,
plastic case PVC
(CT01-10k and CT02-10k
sensors can also be used)
DIMENSIONS:
136.5 28.5
83
TECHNICAL PARAMETERS
Power supply 5 V/ DC, 2.5 A, type AD05 - Jack
GSM module SIM 900
Aerial direct 1dB
Number of adjustable temp. 6 different temp. per every day
Hysteresis 0.1 to 6°C
Minimum program. time 10 minutes
Adjustable temperature range +3°C to 39°C
Temperature setting by 0.5°C
Minimum indication step 0.1°C
Measurement accuracy ± 0,5°C
Protection IP20
Protection class II
Output max.5 A (potential-free contacts)
Working temperature 0°C to +40°C
Properties:
•control by means of a mobile phone
•9 weekly programs
•6 temperature changes per day
•programming by 10 minutes and 0.5 °C
•programming “day-by-day” or Mon-Fri, Sat-Sun or Mon-Sun
•big backlit graphic display
•selection from three types of control: PID, PI or HYSTERESIS
•preliminary heating start function
•short-term change in the required temp.
•manual mode (MANU)
•permanent switch-off (OFF)
•HOLIDAY mode
•summer mode
•even-odd week selection
•heating / cooling mode selection
•possibility of connecting an external sensor
•current temperature correction
•key lock
•boiler operating hours total
•boiler maintenance indication
•service safeguard by a password
•anti-freeze protection (3 °C)
•TEST function
•automatic SUMMER / WINTER time change
•clock backup in case of power failure, approx.
7 days if rechargeable batteries are used
(not included in the packing)
included in the
packing
type AD05-Jack,
5V/ DC, 2.5 A
Example of using THERMOSTAT:
The thermostat is located in a room where anti-freeze temperature must be maintained (e.g., 7 °C).
1. Connect the THERMOSTAT strictly according to the instructions.
2. Choose the MANU mode.
3. Press the “ “ button and set the temperature of 7 °C by turning the “ “ button.
4. Before arriving at the object, write an SMS in your mobile with the wording: Temp 23; then send the SMS to the number of the SIM card
inserted in your thermostat.
After receiving the message, the thermostat automatically switches on the heating system until the desired temperature is
reached. Then the thermostat automatically sends the “BACK SMS message” informing you about the temperature change made.
After arriving at the object, you can change the temperature according to your needs on the thermostat directly.
KABOLA HEATING SYSTEMS B.V.
Placotiweg 1E
4131 NL Vianen
The Netherlands
[phone]
[email protected]

www.kabola.nl
KABOLA HEATING SYSTEMS B.V.
Placotiweg 1E
4131 NL Vianen
The Netherlands
[phone]
[email protected]
KABOLA DEALERS (INTERNATIONAL)
MarineTec US, Anacortes, WA United States
Kuranda, Whaley Bridge United Kingdom
Marineworks w, Gdansk Poland
Standarte, Moscow Russia
Thermoprodukter Kalmar Sweden
Gertsen & Olufsen, Copenhagen Denmark
Farco AS, Oslo Norway
Nautikulma Oy, Turku Finland
Groothandel Francois, Antwerp Belgium
PK Fluvial, Paris France
Stal Elektronik Slovenia and Croatia
Baltic Marine Group AS, Tallinn Estonia
Scheer, Wöhrden Germany, Switzerland
and Austria
In addition to Kabola's own sales and customer-service team,
Kabola also works together with many certified installation and
maintenance professionals. For an up-to-date overview of these
professionals, visit www.kabola.nl.
HETELUCHTVERWARMING
VLOERVERWARMING
WARM WATER
AIRCONDITIONING
