IDEAL Touch User manual

THERMOSTAT & TRANSCEIVER COMBI
INSTALLATION GUIDE
CONTENTS
Class Vwhen used in isolation. Class VI when used with an outside sensor, Class VIII when used with more than 2 zones.
Contribution to seasonal space heating energy eciency 3% (Class V), 4% (Class VI), 5% (Class VIII).
A B C
EF
G H I
D
A. Touch Thermostat
B. Mounting Bracket Cover
C. Mounting Bracket
D. Desktop stand
E. Transceiver
F. Batteries (AA)
G. Screws & Plugs
H. Quick Start Guide
I. SAP Registration Label
8. Hold the thermostat
approximately 2
metres away from
the boiler and
“CONNECTING TO
BOILER” will be
displayed on your
screen.
9. After approximately
60 seconds “Set
System Time” will be
displayed on your
screen. Use up and
down arrows to set
the time. Once time is
set press “DONE”
10. “Set System Date” will
be displayed on your
screen. Use up and
down arrows to set
the date. Once date is
set press “DONE”.
QUICK START GUIDE
Logic Combi C / Vogue GEN2 Combi
In the unlikely event that commissioning is unsuccessful (e.g. central heating
will not switch on or will not switch o), electrically isolate the boiler,
remove 1 battery and repeat from step 6.



Blanking
Plate
Transceiver
Slot
INSTALLATION
For User & Installation Guide please visit www.idealboilers.com
1. Isolate electrical power to the
boiler.
2. Remove the blanking plate by
inserting flat blade screwdriver
into slot situated centrally at
bottom of blanking plate.
3. Remove link wire plug & keep in
a safe place.
4. Connect the transceiver
electrical plug.
5. Locate and push the transceiver
assembly into the boiler.
6. Insert only 3 batteries into the
Thermostat.
7. Turn electrical power back on
to the boiler and immediately
insert the fourth battery into the
Thermostat.
Model Name:
Model Qualifier:
Signed: Date:
UIN 217679 A01
Touch (Single Zone)
ErP Class V or ErP Class VI
IDEAL BOILERS LTD
I certify that this boiler is connected to a weather
compensation control as indicated:
Touch enhanced load compensator (Class V)
Touch enhanced load compensator & OS2 weather
compensator temperature sensor (Class VI)
These products are compatible with the boiler and
provide compensation control that has been
permanently enabled. The boiler has been
commissioned in accordance with the manufacturer
instructions which have been supplied to the
householder. The central heating temperature control
knob should normally be set in the mid-position.
June 2017
215407 A02

8. Hold the thermostat
approximately 2 metres
away from the boiler and
“CONNECTING TO BOILER” will
be displayed on your screen.
9. After approximately 60 seconds
“Set System Time” will be
displayed on your screen. Use up
and down arrows to set the time.
Once time is set press “DONE”
10. “Set System Date” will be
displayed on your screen. Use up
and down arrows to set the date.
Once date is set press “DONE”.



Blanking
Plate
Transceiver
Slot
INSTALLATION
In the unlikely event that commissioning is unsuccessful (e.g. central heating will not switch on or will not
switch o), electrically isolate the boiler, remove 1 battery and repeat from step 6.
1. Isolate electrical power to the boiler.
2. Remove the blanking plate by inserting flat
blade screwdriver into slot situated centrally at
bottom of blanking plate.
3. Remove link wire plug & keep in a safe place.
4. Connect the transceiver electrical plug.
5. Locate and push the transceiver assembly into the
boiler.
6. Insert only 3 batteries into the Thermostat
(noting correct polarity).
7. Turn electrical power back on to the boiler and
immediately insert the fourth battery into the
Thermostat.

LOCATION GUIDELINES
TO FIX THE THERMOSTAT
For correct wireless communication between your boiler and the Touch Thermostat there must be:
• Less than 20 metres
• No more than 2 walls and 1 ceiling
• No large metallic objects (e.g. American fridge/freezer)
• No large mirrors or windows
• No walls running along the RF path
The Thermostat must not be within 1 metre of a WiFi booster / router
To fix the Thermostat:
(a) Fix the wall bracket to the wall using appropriate fixings. Push
the wall bracket cover into place until it clicks.
Place the Thermostat onto the three lugs and slide the
Thermostat down until it clicks.
(b)
Alternatively, the Thermostat can be placed on the desktop stand
by placing it onto the three lugs and sliding it down until it
clicks.
click
(c) If applicable, complete the enclosed SAP Registration Label
and adhere it to the boiler in a position which will be visible for
future inspection.

Ideal Boilers Ltd. P.O. Box 103, National Avenue, Kingston upon Hull, HU5 4JN
TROUBLE SHOOTING
Consumer Helpline T: 01482 498660 Technical Helpline T: 01482 498663
For Installation & User Guides please visit www.idealboilers.com
1Press the Thermostat screen. If screen does not illuminate then replace
batteries.
Battery Replacement:
Un-clip the Thermostat from its cradle by sliding the Thermostat
upwards.
Using a flat bladed screwdriver pop o the rear cover.
Replace batteries.
Refit battery cover.
Batteries should operate for approximately 18 to 24 months.
Only good quality alkaline batteries are to be used.
2If warning triangle is shown then press it.
If “Zone 1 Fault” shown refer to Location Guidelines (overleaf).
If “Boiler Fault” shown, check boiler display and refer to boiler installation
manual.
3If Time / Day at top left of display is incorrect, change by pressing “Menu” >
“Help & Settings”.
4If Central Heating will not switch on check Target Room Temperature is at least
1°C greater than Actual Room Temperature. If not press radiator symbol at
bottom left of screen until “On” is highlighted then rotate outer ring clockwise.
If Central Heating will not switch o press radiator symbol until “O” is
highlighted.
5Check power to boiler is on (boiler display should be on).
6If boiler transceiver left hand RF light is o, refer to Location Guidelines
(opposite).
7
For Logic Combi C Boilers - ensure boiler Mode Knob is in Winter position.
For Vogue Gen2 Combi Boilers - ensure Central Heating knob is fully clockwise.
8 If the fault persists then isolate the boiler, remove 1 Thermostat battery and repeat
Quick Start Guide instructions from Step 6 (see “INSTALLATION”).
9If the Touch Thermostat replaced an existing thermostat, ensure that boiler
installer connection link wire is in place (see boiler manual).
WEEE DIRECTIVE 2012/19/EC
Waste Electrical and Electronic Equipment Directive
• At the end of the product life, dispose of the packaging and product in a
corresponding recycling centre.
• Do not dispose of the unit with the usual domestic refuse.
• Do not burn the product.
• Remove the batteries.
• Dispose of the batteries according to the local statutory requirements and not
with the usual domestic refuse.
