KAESER M26 User manual

SERVICE MANUAL
Screw Compressor
M26
No.: 9_9446 01 USE

1 Regarding this Document
1.1 Using the Document ......................................................................................................... 1
1.2 Further Documents .......................................................................................................... 1
1.3 Copyright .......................................................................................................................... 1
1.4 Symbols and Identification ............................................................................................... 1
1.4.1 Warnings ............................................................................................................. 1
1.4.2 Other instructions and symbols .......................................................................... 2
2Technical Data
2.1 Nameplate ........................................................................................................................ 3
2.2 Options ............................................................................................................................. 3
2.2.1 Tool lubricator ..................................................................................................... 4
2.2.2 Non-return function ............................................................................................. 4
2.2.3 Fuel filter with water trap ..................................................................................... 4
2.2.4 Low temperature equipment ............................................................................... 5
2.2.5 Equipment for fire hazard areas ......................................................................... 5
2.2.6 Sealed floor pan .................................................................................................. 5
2.2.7 Chassis ............................................................................................................... 5
2.2.8 Lighting ............................................................................................................... 6
2.2.9 Hose reel ............................................................................................................ 6
2.2.10 Anti-theft device .................................................................................................. 6
2.3 Machine (without options) ................................................................................................ 6
2.3.1 Sound emission ................................................................................................. 6
2.3.2 Torques ............................................................................................................... 7
2.3.3 Ambient conditions ............................................................................................. 7
2.3.4 Dimensions ......................................................................................................... 7
2.4 Chassis ........................................................................................................................... 8
2.4.1 Weights ............................................................................................................... 8
2.4.2 Tires .................................................................................................................... 8
2.4.3 Wheel fixing tightening torque ............................................................................ 8
2.5 Compressor ..................................................................................................................... 8
2.5.1 Working pressure and FAD ................................................................................ 8
2.5.2 Compressed air outlet ......................................................................................... 9
2.5.3 Pressure relief valve ........................................................................................... 9
2.5.4 Temperature ....................................................................................................... 9
2.5.5 Cooling oil recommendation ............................................................................... 9
2.5.6 Cooling oil charge ............................................................................................... 10
2.6 Engine ............................................................................................................................. 10
2.6.1 Engine specification ............................................................................................ 10
2.6.2 Oil recommendation ............................................................................................ 11
2.6.3 Engine coolant recommendation ........................................................................ 11
2.6.4 Fluid volumes ...................................................................................................... 11
2.6.5 Battery ................................................................................................................ 11
2.7 Options ............................................................................................................................ 12
2.7.1 Tool lubricator ..................................................................................................... 12
2.7.2 Low temperature equipment ............................................................................... 12
2.7.3 Air hose with hose reel ....................................................................................... 12
3 Safety and Responsibility
3.1 Basic Information ............................................................................................................. 14
3.2 Specified Use ................................................................................................................... 14
3.3 Improper Use ................................................................................................................... 14
3.4 User's Responsibilities ..................................................................................................... 14
3.4.1 Observe statutory and universally accepted regulations. ................................... 14
3.4.2 Defining personnel .............................................................................................. 15
Contents
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 i

3.4.3 Adherence to inspection schedules and accident prevention regulations .......... 15
3.5 Dangers ............................................................................................................................ 16
3.5.1 Safely dealing with sources of danger ................................................................ 16
3.5.2 Safe machine operation ...................................................................................... 18
3.5.3 Organizational Measures .................................................................................... 20
3.5.4 Danger areas ...................................................................................................... 20
3.6 Safety Devices ................................................................................................................. 21
3.7 Safety signs ...................................................................................................................... 21
3.8 In Emergency ................................................................................................................... 24
3.8.1 Correct fire fighting ............................................................................................. 24
3.8.2 Contact with operating materials ........................................................................ 24
3.9 Warranty ........................................................................................................................... 25
3.10 Environmental Protection ................................................................................................. 25
4 Design and Function
4.1 Bodywork ......................................................................................................................... 26
4.2 Component identification .................................................................................................. 27
4.3 Machine function .............................................................................................................. 28
4.4 Operating modes and control modes ............................................................................... 29
4.4.1 Operating modes ................................................................................................ 29
4.4.2 MODULATING control ........................................................................................ 30
4.5 Safety devices .................................................................................................................. 30
4.5.1 Monitoring functions with shutdown .................................................................... 30
4.5.2 Further safety devices ........................................................................................ 30
4.6 Options ............................................................................................................................. 30
4.6.1 Environmental protection equipment .................................................................. 30
4.6.2 Tool lubricator ..................................................................................................... 31
4.6.3 Low temperature equipment ............................................................................... 32
4.6.4 Option for operating in fire hazard areas ............................................................ 33
4.6.5 Fuel filter with water trap ..................................................................................... 34
4.6.6 Optional anti-theft device ................................................................................... 34
4.6.7 Transportation option .......................................................................................... 34
5 Installation and Operating Conditions
5.1 Safety ............................................................................................................................... 36
5.2 Installation conditions ....................................................................................................... 36
6 Installation
6.1 Safety ............................................................................................................................... 38
6.2 Reporting Transport Damage ........................................................................................... 38
6.3 Adjusting the chassis ....................................................................................................... 38
6.3.1 Adjusting the towbar height ................................................................................ 39
6.3.2 Adjusting the towbar height ................................................................................ 40
6.3.3 Changing the towing eye or coupling ................................................................. 42
7 Initial Start-up
7.1 Safety ............................................................................................................................... 49
7.2 Instructions to be observed before commissioning or recommissioning .......................... 49
7.3 Checking positioning and operating conditions ................................................................ 49
7.4 After storing the machine for a long period ...................................................................... 50
7.5 Low-temperature operation (winter) ................................................................................. 50
7.5.1 Starting assistance ............................................................................................. 51
7.5.2 Starting up low-temperature equipment .............................................................. 52
8 Operation
8.1 Starting and stopping ....................................................................................................... 54
8.1.1 Starting ............................................................................................................... 54
Contents
ii
SERVICE MANUAL Screw Compressor
M26 No.: 9_9446 01 USE

8.1.2 Allow the machine to run up to operating temperature ....................................... 55
8.1.3 Shutting down ..................................................................................................... 55
8.2 Operating the tool lubricator ............................................................................................. 56
8.3 Using the low-temperature equipment ............................................................................. 56
8.3.1 Using the frost protector ..................................................................................... 56
8.3.2 Coolant pre-heating ............................................................................................ 57
8.4 Using the hose reel .......................................................................................................... 58
8.4.1 Using the hose reel (EC version) ........................................................................ 58
9 Fault Recognition and Rectification
9.1 Basic instructions ............................................................................................................. 60
9.2 Engine faults and alarms .................................................................................................. 60
9.2.1 Engine refuses to start or comes to a stop ......................................................... 60
9.2.2 Engine does not reach full speed. ...................................................................... 61
9.2.3 Indicator lamp remains on .................................................................................. 61
9.3 Compressor faults and alarms ......................................................................................... 62
9.3.1 Working pressure too high .................................................................................. 62
9.3.2 Working pressure too low ................................................................................... 62
9.3.3 Pressure relief valve blowing off ......................................................................... 63
9.3.4 Machine overheating .......................................................................................... 63
9.3.5 Too much oil residue in the compressed air ....................................................... 64
9.3.6 Oil flows from the compressor air filter after shutdown ....................................... 64
10 Maintenance
10.1 Safety ............................................................................................................................... 65
10.2 Maintenance schedules ................................................................................................... 65
10.2.1 Logging maintenance work ................................................................................. 65
10.2.2 Maintenance tasks after commissioning ............................................................. 66
10.2.3 Regular maintenance tasks ................................................................................ 66
10.2.4 Maintenance schedule ........................................................................................ 67
10.2.5 Maintenance schedule for options ...................................................................... 69
10.3 Engine .............................................................................................................................. 70
10.3.1 Cooler maintenance ............................................................................................ 70
10.3.2 Air filter maintenance .......................................................................................... 73
10.3.3 Fuel system maintenance ................................................................................... 75
10.3.4 Changing the engine oil ...................................................................................... 80
10.3.5 Changing the engine oil filter .............................................................................. 83
10.3.6 Checking the drive belts ..................................................................................... 84
10.3.7 Battery maintenance ........................................................................................... 85
10.4 Compressor ...................................................................................................................... 88
10.4.1 Checking cooling oil level ................................................................................... 88
10.4.2 Topping up the cooling oil ................................................................................... 89
10.4.3 Changing the cooling oil ..................................................................................... 90
10.4.4 Changing the oil filter .......................................................................................... 92
10.4.5 Changing the oil separator cartridge ................................................................... 93
10.4.6 Air filter maintenance .......................................................................................... 96
10.4.7 Pressure relief valve checking ............................................................................ 97
10.4.8 Clean cooler/radiator .......................................................................................... 97
10.5 Chassis ........................................................................................................................... 99
10.5.1 Wheel checks ..................................................................................................... 99
10.5.2 Tow-bar maintenance ......................................................................................... 99
10.5.3 Overrun braking mechanism maintenance ......................................................... 99
10.5.4 Greasing the brake rods ..................................................................................... 100
10.5.5 Checking brake linings ........................................................................................ 100
10.5.6 Greasing the canopy hinges ............................................................................... 101
Contents
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 iii

10.5.7 Maintain rubber sealing strips ............................................................................. 102
10.6 Options ............................................................................................................................. 102
10.6.1 Tool lubricator maintenance ............................................................................... 102
10.6.2 Frost protector maintenance ............................................................................... 103
10.6.3 Spark arrestor cleaning ....................................................................................... 105
10.7 Document maintenance and service work. ...................................................................... 107
11 Spares, Operating Materials, Service
11.1 Note the nameplate .......................................................................................................... 108
11.2 Ordering consumable parts and operating fluids/materials .............................................. 108
11.3 KAESER AIR SERVICE .................................................................................................. 109
11.4 Service Addresses ........................................................................................................... 109
11.5 Spares for service and repair ........................................................................................... 109
12 Decommissioning, Storage and Transport
12.1 De-commissioning ............................................................................................................ 165
12.1.1 Temporary decommissioning .............................................................................. 165
12.1.2 Long-term decommissioning ............................................................................... 166
12.2 Transporting ..................................................................................................................... 167
12.2.1 Towing the compressor on the road ................................................................... 167
12.2.2 Parking the compressor ...................................................................................... 171
12.2.3 Transporting with a crane ................................................................................... 174
12.2.4 Transporting with a forklift truck .......................................................................... 174
12.2.5 Transporting as a load ........................................................................................ 175
12.3 Storage ............................................................................................................................. 176
12.4 Disposal ........................................................................................................................... 176
13 Annex
13.1 Marking ............................................................................................................................ 178
13.2 Pipeline and instrument flow diagram (P+I diagram) ....................................................... 178
13.3 Dimensional drawing ........................................................................................................ 182
13.3.1 Dimensional drawing - fixed height towbar without parking brake ...................... 182
13.3.2 Dimensional drawing - stationary machine with skids ........................................ 184
13.4 Electrical Diagram ............................................................................................................ 186
13.5 Lighting and signaling system connection ........................................................................ 195
13.6 Fuel circulation diagram ................................................................................................... 200
Contents
iv
SERVICE MANUAL Screw Compressor
M26 No.: 9_9446 01 USE

Fig. 1 Location of safety signs .............................................................................................................. 21
Fig. 2 Overview Bodywork .................................................................................................................... 26
Fig. 3 Side view (canopy removed) ...................................................................................................... 27
Fig. 4 General design ........................................................................................................................... 28
Fig. 5 Tool lubricator ............................................................................................................................. 31
Fig. 6 Frost protector ............................................................................................................................ 32
Fig. 7 Coolant pre-heating .................................................................................................................... 33
Fig. 8 Minimum distance from excavations/slopes and walls ............................................................... 36
Fig. 9 Height adjustable towbar sa ....................................................................................................... 39
Fig. 10 Towbar height adjustment sb ..................................................................................................... 41
Fig. 11 Change from eye to ball coupling (height adjustable towbar) .................................................... 43
Fig. 12 Change from eye to ball coupling (height adjustable towbar with overrun brake) ...................... 45
Fig. 13 Change from eye to ball coupling (fixed height towbar) ............................................................. 47
Fig. 14 Jumper cable connection diagram ............................................................................................. 51
Fig. 15 Instrument panel and «Control ON» switch ................................................................................ 54
Fig. 16 Warm-up period when ambient temperatures are below 14 °F .................................................. 55
Fig. 17 Setting the tool lubricator ............................................................................................................ 56
Fig. 18 Switching on the frost protector .................................................................................................. 57
Fig. 19 Hose reel (EC design) ................................................................................................................ 58
Fig. 20 Checking coolant level ............................................................................................................... 71
Fig. 21 Draining the coolant from the radiator ........................................................................................ 73
Fig. 22 Engine air filter maintenance ...................................................................................................... 74
Fig. 23 Bleeding the fuel system ............................................................................................................ 76
Fig. 24 Checking the securing strap ....................................................................................................... 78
Fig. 25 Fuel filter with water trap ............................................................................................................ 79
Fig. 26 Changing the engine oil .............................................................................................................. 81
Fig. 27 Detail oil drain valve ................................................................................................................... 81
Fig. 28 Changing the engine oil filter ...................................................................................................... 83
Fig. 29 Belt tension checking by hand .................................................................................................... 85
Fig. 30 Warning stickers on the battery .................................................................................................. 86
Fig. 31 Checking cooling oil level ........................................................................................................... 89
Fig. 32 Changing the cooling oil ............................................................................................................. 91
Fig. 33 Changing the oil filter .................................................................................................................. 92
Fig. 34 Changing the oil separator cartridge .......................................................................................... 94
Fig. 35 Oil separator tank dirt trap maintenance .................................................................................... 95
Fig. 36 Compressor air filter maintenance ............................................................................................. 96
Fig. 37 Clean cooler/radiator .................................................................................................................. 98
Fig. 38 Checking the brake lining thickness ........................................................................................... 101
Fig. 39 Lubricating the canopy hinges .................................................................................................... 101
Fig. 40 Tool lubricator maintenance ....................................................................................................... 103
Fig. 41 Filling the frost protector ............................................................................................................. 104
Fig. 42 Spark arrestor cleaning .............................................................................................................. 105
Fig. 43 Towing alignment ....................................................................................................................... 168
Fig. 44 Ball coupling function ................................................................................................................. 169
Fig. 45 Safety sign - secure the chocks ................................................................................................. 170
Fig. 46 Breakaway cable attachment ..................................................................................................... 171
Fig. 47 Injury can occur if the towbar is unsupported and allowed to fall. .............................................. 172
Fig. 48 Safety sign - secure the chocks ................................................................................................. 172
Fig. 49 Transport using a forklift truck .................................................................................................... 175
Fig. 50 Load secured by straps .............................................................................................................. 175
Fig. 51 Marking ....................................................................................................................................... 178
List of Illustrations
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 v

Tab. 1 The levels of danger and their meaning ..................................................................................... 2
Tab. 2 Nameplate .................................................................................................................................. 3
Tab. 3 Combined label for coupling load and options fitted ................................................................... 4
Tab. 4 Tool lubricator ............................................................................................................................. 4
Tab. 5 Non-return function ..................................................................................................................... 4
Tab. 6 Fuel filter with water trap ............................................................................................................ 4
Tab. 7 Low temperature equipment ....................................................................................................... 5
Tab. 8 Equipment for fire hazard areas ................................................................................................. 5
Tab. 9 Sealed floor pan ......................................................................................................................... 5
Tab. 10 Chassis ....................................................................................................................................... 5
Tab. 11 Lighting ....................................................................................................................................... 6
Tab. 12 Hose reel .................................................................................................................................... 6
Tab. 13 Anti-theft device .......................................................................................................................... 6
Tab. 14 Sound emission .......................................................................................................................... 6
Tab. 15 Sound pressure level .................................................................................................................. 7
Tab. 16 Torques for hex-head screws ..................................................................................................... 7
Tab. 17 Ambient conditions ..................................................................................................................... 7
Tab. 18 Machine weights ......................................................................................................................... 8
Tab. 19 Tires ........................................................................................................................................... 8
Tab. 20 Wheel nut/bolt tightening torque ................................................................................................. 8
Tab. 21 Working pressure and FAD ........................................................................................................ 8
Tab. 22 Compressed air distributor ......................................................................................................... 9
Tab. 23 Relief valve activating pressure .................................................................................................. 9
Tab. 24 Airend discharge temperature .................................................................................................... 9
Tab. 25 Machine temperatures ................................................................................................................ 9
Tab. 26 Cooling oil recommendation ....................................................................................................... 9
Tab. 27 Cooling oil charge ....................................................................................................................... 10
Tab. 28 Engine specification ................................................................................................................... 10
Tab. 29 Engine oil recommendation ........................................................................................................ 11
Tab. 30 Engine fluid volumes .................................................................................................................. 11
Tab. 31 Battery ........................................................................................................................................ 11
Tab. 32 Road breaker lubricant recommendation ................................................................................... 12
Tab. 33 Ambient conditions ..................................................................................................................... 12
Tab. 34 Antifreeze recommendation ....................................................................................................... 12
Tab. 35 Coolant pre-heater ..................................................................................................................... 12
Tab. 36 Additional discharge valve for the compressed air hose ............................................................ 12
Tab. 37 Inspection intervals according to Ordinance on Industrial Safety and Health ............................ 16
Tab. 38 Danger areas .............................................................................................................................. 20
Tab. 39 Safety signs ................................................................................................................................ 21
Tab. 40 Chassis - overview ..................................................................................................................... 34
Tab. 41 Stationary machines ................................................................................................................... 35
Tab. 42 Height adjustable towbar ............................................................................................................ 38
Tab. 43 Choice of ball couplings ............................................................................................................. 42
Tab. 44 Positioning and operating conditions checklist ........................................................................... 49
Tab. 45 Measures for re-commissioning the compressor after a long period of storage ........................ 50
Tab. 46 Low-temperature equipment checklist ........................................................................................ 52
Tab. 47 Alarm: Engine refuses to start or comes to a stop. .................................................................... 60
Tab. 48 Alarm: Engine does not reach full speed. ................................................................................... 61
Tab. 49 Indicator lamp remains on .......................................................................................................... 61
Tab. 50 Fault: working pressure too high ................................................................................................ 62
Tab. 51 Fault: working pressure too low .................................................................................................. 62
Tab. 52 Fault: pressure relief valve blowing off ....................................................................................... 63
Tab. 53 Fault: machine overheating ........................................................................................................ 63
Tab. 54 Fault: too much oil residue in the compressed air ...................................................................... 64
List of Tables
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 vii

Tab. 55 Fault: oil flows from the compressor air filter after shutdown ..................................................... 64
Tab. 56 Maintenance tasks after commissioning .................................................................................... 66
Tab. 57 Maintenance intervals and regular maintenance tasks .............................................................. 66
Tab. 58 Regular maintenance tasks ........................................................................................................ 67
Tab. 59 Regular maintenance task options ............................................................................................. 69
Tab. 60 Coolant frost protection .............................................................................................................. 72
Tab. 61 Oil drain valve ............................................................................................................................. 81
Tab. 62 Overrun brake mechanism lubricating point ............................................................................... 100
Tab. 63 Logged maintenance tasks ........................................................................................................ 107
Tab. 64 Compressor consumables .......................................................................................................... 108
Tab. 65 Consumable engine parts .......................................................................................................... 108
Tab. 66 "Temporarily decommissioned" information notice .................................................................... 165
Tab. 67 Long-term decommissioning checklist ....................................................................................... 166
Tab. 68 "Long-term decommissioned" information notice ....................................................................... 167
List of Tables
viii
SERVICE MANUAL Screw Compressor
M26 No.: 9_9446 01 USE

1 Regarding this Document
1.1 Using the Document
The service manual is part of the machine.
➤Keep the service manual in a safe place throughout the life of the machine.
➤ Pass the manual on to the next owner/user of the machine.
➤ Ensure that all amendments received are entered in the manual.
➤ Enter details from the machine nameplate and individual items of equipment in the table in
chapter 2.
1.2 Further Documents
Included with this service manual are additional documents intended to assist in the safe operation
of the machine:
■ Certificate of acceptance / operating instructions for the pressure vessel
■ Manufacturer's declaration / declaration of conformity in accordance with applicable directives
■ Chassis maintenance instructions
■ Operating instructions from the chassis manufacturer
■ Engine documentation (not electric-motor-driven machines)
Missing documents can be requested from KAESER.
➤ Make sure all documents are complete and observe the instructions contained in them.
➤ Make sure you give the data from the nameplate when ordering documents.
1.3 Copyright
This service manual is copyright protected. Queries regarding use or duplication of the documenta‐
tion should be referred to KAESER. Correct use of information will be fully supported.
1.4 Symbols and Identification
1.4.1 Warnings
Warning notices indicate three levels of danger signified by the signal word.
■ DANGER
■ WARNING
■ CAUTION
1.
These show the kind of danger and its source!
The possible consequences of ignoring a warning are shown here.
The word "Danger" indicates that death or severe injury can result from ignoring the instruction.
➤ The measures required to protect yourself from danger are shown here.
1 Regarding this Document
1.1 Using the Document
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 1

2. Always read and comply with warning instructions.
Signal word Meaning Consequences of non-observance
DANGER Warns of an imminent threat of danger Death or serious injury may result
WARNING Warns of possible danger Death or serious injury are possible
CAUTION Warns of a possibly dangerous situa‐
tion
Light injuries or material damage are possible
Tab. 1 The levels of danger and their meaning
1.4.2 Other instructions and symbols
This symbol refers to particularly important information.
Material Here you will find details on special tools, operating materials or spare parts.
Precondition Here you will find conditional requirements necessary to carry out the task.
Here conditions relevant to safety are named that will help you to avoid dangerous situations.
➤ This bullet is is placed by lists of actions comprising one stage of a task.
In lists of actions with several stages the sequence of actions is numbered.
Information that refers to only one option is marked with an indicator (e.g.: H1 means that this
section is only valid for machines with adjustable machine mountings). Option indicators used
in this service manual are explained in chapter 2.2 .
Information referring to potential problems are identified by a question mark.
The cause is named in the help text ...
➤... and a remedy given.
This symbol refers to important information or measures concerning environmental protec‐
tion.
Further information Here, your attention is drawn to further topics.
1 Regarding this Document
1.4 Symbols and Identification
2
SERVICE MANUAL Screw Compressor
M26 No.: 9_9446 01 USE
Option H1

2 Technical Data
2.1 Nameplate
The machine's nameplate provides the model designation and important technical information.
The nameplate is located on the outside of the machine (see illustration in chapter 13.1).
➤ Enter here the nameplate data as a reference:
Feature Value
Vehicle identity no.
Permissible total weight
Permissible axle load
Permissible coupling load
Portable compressor
Material number
Serial number
Year of manufacture
Total weight
Lifting point load capacity
Rated motor power
Engine speed
Maximum working pressure
Tab. 2 Nameplate
2.2 Options
A list of the options fitted to your machine helps to relate the information in this service manual.
A list of options fitted is given as code letters on the right side of the coupling load / options label.
The nameplate is to be found:
■on the outside of the machine,
■ on the front (see chapter 13.1)
The following table lists all possible options.
Only the codes for those options fitted appear on the nameplate.
2 Technical Data
2.1 Nameplate
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 3

➤ Take a list of fitted options from the combined coupling load / options label.
M26 MATNo SERNo
Options fitted
Here is given the specified coupling load.
02-M0277-PE
sf tc
tb
ta sd sh
sc
sa sb
ba
oe
la
ha
ne
te
ea
ua
Tab. 3 Combined label for coupling load and options fitted
2.2.1 Option ea
Tool lubricator
➤ Enter the fitted option as a reference.
Option Option code Exists?
Tool lubricator ea
Tab. 4 Tool lubricator
2.2.2 Option ha
Non-return function
➤ Enter the fitted option as a reference in this overview:
Option Option code Available?
Check valve ha
Tab. 5 Non-return function
2.2.3 Option ne
Fuel filter with water trap
➤ Enter the fitted option as reference.
Option Option code Exists?
Fuel filter with water trap ne
Tab. 6 Fuel filter with water trap
2 Technical Data
2.2 Options
4
SERVICE MANUAL Screw Compressor
M26 No.: 9_9446 01 USE

2.2.4 Option ba
Low temperature equipment
➤ Enter the fitted option as reference.
Option Option code Exists?
Low temperature equipment ba
Tab. 7 Low temperature equipment
2.2.5 Option la
Equipment for fire hazard areas
➤ Enter the fitted option as a reference in this overview:
Option Option code Available?
Spark arrestor la
Tab. 8 Equipment for fire hazard areas
2.2.6 Option oe
Sealed floor pan
➤ Enter the fitted option as a reference in this overview:
Option Option code Available?
Sealed floor pan oe
Tab. 9 Sealed floor pan
2.2.7 Option sa, sb, sd, sh, sc
Chassis
➤ Enter the fitted option as a reference in this overview:
Option Option code Available?
EU chassis 01 sa
EU chassis 02 sb
EU chassis 03 sd
US chassis sh
Stationary skids sc
EU ≙ Europe, US ≙ United States of America
Tab. 10 Chassis
Further information For an exact description of the characteristics of the chassis and models, see chapter 4.6.7.
2 Technical Data
2.2 Options
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 5

2.2.8 Option ta, tb, tc, te
Lighting
➤ Enter the fitted option as a reference in this overview:
Option Option code Available?
None (stationary) ta
Reflective warning triangle tb
EU – 12 V (7-pin connector) tc
USA 12 V (DOT conformity) te
Tab. 11 Lighting
2.2.9 Option ua
Hose reel
➤ Enter the fitted option as reference.
Option Option code Exists?
Hose reel ua
Tab. 12 Hose reel
2.2.10 Option sf
Anti-theft device
➤ Enter the fitted option as reference.
Option Option code Exists?
Anti-theft device sf
Tab. 13 Anti-theft device
2.3 Machine (without options)
2.3.1 Sound emission
2.3.1.1 Sound emission
Measurement conditions
■Free-field measurement to directive 2000/14/EC
■ Measuring distance: d=1 m (3.28 ft)
■ Logarithmic surface ratio: Q2=16.2dB(A)
Sound emission M26
Guaranteed sound power level [dB(A)] 98
* Calculated from the guaranteed sound power level (2000/14/EG Directive, Basic Noise Emission
Standard ISO 3744) to EN ISO 11203:1995 number 6.2.3.d
2 Technical Data
2.3 Machine (without options)
6
SERVICE MANUAL Screw Compressor
M26 No.: 9_9446 01 USE

Sound emission M26
Emission sound pressure level* [dB(A)] 82.0
* Calculated from the guaranteed sound power level (2000/14/EG Directive, Basic Noise Emission
Standard ISO 3744) to EN ISO 11203:1995 number 6.2.3.d
Tab. 14 Sound emission
2.3.1.2 Sound pressure level
The sound pressure level conforms to the US EPA Standard.
Measuring distance: 23 ft
Sound pressure level M26
Guaranties sound pressure level [dB (A)] 76
Tab. 15 Sound pressure level
2.3.2 Torques
Recommended values for hexagonal bolts of strength category 8.8
Hex-head screws
Thread M6 M8 M10 M12 M14 M16 M18
Torque [lbf in] 85 204 407 708 1124 1726 2478
Tab. 16 Torques for hex-head screws
2.3.3 Ambient conditions
Installation Limit value
Maximum altitude AMSL* [ft.] 3000
Minimum ambient temperature [°F] +14
Maximum ambient temperature [°F] +113
* Higher altitudes are permissible only after consultation with the manufacturer.
Tab. 17 Ambient conditions
2.3.4 Dimensions
For specifications according to the machine's operating licence, such as:
■dimensions,
■ track width,
■ footprint,
see the dimensional drawings in chapter 13.3.
2 Technical Data
2.3 Machine (without options)
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 7

2.4 Chassis
2.4.1 Weights
Maximum weights are shown. Actual weights of individual machines are dependent on equip‐
ment fitted (see machine nameplate).
Feature 01 02 03 04 05
Chassis type EU
chassis
EU
chassis
EU
chassis
US
chassis
Stationary
Height-adjustable towbar x x − − −
Fixed height towbar − − x x −
Parking brake − x x − −
Service brake − x − − −
Actual total weight [lb]*
Permissible axle load [lb] 1323 1323 1323 1323 −
x ≙ available, − ≙ not available
EU ≙ Europe, US ≙ United States of America
* Enter here the actual overall weight from the nameplate as reference,
Tab. 18 Machine weights
2.4.2 Tires
Characteristic/marking
Tire size 145/80 R 13
Maximum and recommended tire pressure [psig] 39
Wheel bolts M 12 x 1.5
Tab. 19 Tires
2.4.3 Wheel fixing tightening torque
Fixing medium Thread Wrench size Torque [lbf in]
Wheel bolt M 12 x 1.5 13/16” 800
Tab. 20 Wheel nut/bolt tightening torque
2.5 Compressor
2.5.1 Working pressure and FAD
Maximum working pressure [psig] 100
SIGMA airend 145
Free air delivery [cfm] 92
Tab. 21 Working pressure and FAD
2 Technical Data
2.4 Chassis
8
SERVICE MANUAL Screw Compressor
M26 No.: 9_9446 01 USE

2.5.2 Compressed air outlet
Discharge valve ["] No.
G 3/4 2
Tab. 22 Compressed air distributor
2.5.3 Pressure relief valve
Further information Maximum working pressure: see nameplate
Maximum working pressure [psig] 100
Relief valve activating pressure* [psig] 130
*The pressure relief valve is fitted to the oil separator tank.
Tab. 23 Relief valve activating pressure
2.5.4 Temperature
An automatic combination valve governs the temperature level of the machine depending on the
ambient temperature:
Temperatures Values
Airend compressed air outlet [°F] +194 +140
Ambient [°F] +50 +77
Tab. 24 Airend discharge temperature
Machine temperatures Values
Recommended airend discharge temperature for
switching to load [°F]
86
Typical airend discharge temperature during opera‐
tion [°F]
167 – 212
Maximum airend discharge temperature (automatic
safety shut-down) [°F]
239
Tab. 25 Machine temperatures
2.5.5 Cooling oil recommendation
A sticker showing the type of oil used is located near the oil separator tank filler.
Information on ordering cooling oil is found in chapter 11.
Characteristic SIGMA FLUID
Oil grade S–460 MOL
Classification Silicone-free,
synthetic oil
Mineral oil
2 Technical Data
2.5 Compressor
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 9

Characteristic SIGMA FLUID
Oil grade S–460 MOL
Application Standard oil for all applications except in
connection with foodstuffs.
Particularly suitable for machines with a
high duty cycle.
Standard oil for all applications
except in connection with food‐
stuffs.
Particularly suitable for machines
with a low duty cycle.
Approval — —
Viscosity at 104 °F 45 mm2/s
(D 445; ASTM test)
44 mm2/s
(DIN 51562–1)
Viscosity at
212 °F
7.2 mm2/s
(D 445; ASTM test)
6.8 mm2/s
(DIN 51562–1)
Flash point 460 °F
(D 92; ASTM test)
428 °F
(ISO 2592)
Density at 59 °F 864 kg/m3
(ISO 12185)
–
Pour point -50.8 °F
(D 97; ASTM test)
-27.4 °F
(ISO 3016)
Demulsibility at 29 °F 40/40/0/10 min
(D 1401; ASTM test)
–
Tab. 26 Cooling oil recommendation
2.5.6 Cooling oil charge
Fluid volume Value
Total charge [qt] 4.6
Tab. 27 Cooling oil charge
2.6 Engine
2.6.1 Engine specification
Characteristic Specified
Make/Model Kubota D1105-E3B
Rated power [hp] 24.8
Speed under full load [rpm] 2850
Idling speed [rpm] 2100
Type of fuel Diesel
Fuel consumption under full load [gal/hr] 1.4
Oil consumption related to fuel consumption [%] approx. 0.2
Tab. 28 Engine specification
2 Technical Data
2.6 Engine
10
SERVICE MANUAL Screw Compressor
M26 No.: 9_9446 01 USE

2.6.2 Oil recommendation
The engine oil must meet the following classification:
■ACEA, class E4, E7
■ API, class CF, CI-4
The engine is filled initially with engine oil of viscosity class SAE 10 W / 40.
Ambient temperature [°F] Viscosity class
14 – 122 SAE 15 W / 40
−4 – 86 SAE 5 W / 30
−4 – 122 SAE 10 W / 40
Tab. 29 Engine oil recommendation
2.6.3 Engine coolant recommendation
The engine coolant must meet the requirements of specification ASTM D4985.
Do not use a common coolant / antifreeze that meets only the requirements of ASTM D3306.
Such coolants are intended only for light use in vehicles and could shorten the useful life of
the engine.
The engine service manual gives further information on coolant application.
2.6.4 Fluid volumes
Name Fluid volume [qt]
Engine oil 5.4
Fuel 31.7
Engine coolant 5.3
Tab. 30 Engine fluid volumes
2.6.5 Battery
Feature Value
Voltage [V] 12
Capacity [Ah] 44
PTC testing current [A]
(according to EN 50342)
360
Tab. 31 Battery
Further information Depending on machine equipment, a higher capacity battery may be required. See chapter 2.7.2
for low temperature equipment.
2 Technical Data
2.6 Engine
No.: 9_9446 01 USE
SERVICE MANUAL Screw Compressor
M26 11

2.7 Options
2.7.1 Option ea
Tool lubricator
Name Temperature range [°F] Fluid volume [qt]
Special road breaker lubricant −13 – 122 2.6
Tab. 32 Road breaker lubricant recommendation
2.7.2 Option ba
Low temperature equipment
2.7.2.1 Ambient conditions
Positioning Limit value
Maximum altitude AMSL* [ft] 3000
Minimum ambient temperature [°F] −13
Maximum ambient temperature [°F] +113
* Higher altitudes are permissible only after consultation with the manufacturer.
Tab. 33 Ambient conditions
2.7.2.2 Air lines frost protection
Antifreeze Fluid volume [qt]
Wabcothyl 0.3
Tab. 34 Antifreeze recommendation
2.7.2.3 Coolant pre-heating
Coolant pre-heater Value
Model DEFA A411235
Voltage [V] 230
Power [W] 550
Tab. 35 Coolant pre-heater
2.7.3 Option ua
Air hose with hose reel
The machine is equipped with an additional discharge valve for the Option "Air hose with hose
reel".
Name Discharge valve Compressed air hose
Size ["] G 3/4 −
Number 1 −
2 Technical Data
2.7 Options
12
SERVICE MANUAL Screw Compressor
M26 No.: 9_9446 01 USE
