INSTRUCTION MANUAL
Compressor Wine Cooler
12-Bottle / 18-Bottle / 24-Bottle / 101-Cans
MODEL: KRC-12SS / KRC-18SS / KRC-24SS / KRC-6893
Please read carefully and follow all safety rules and operating instructions.

Content
Your Wine/Beverage Cooler ........................................................................ 1
Technical Data ............................................................................................. 2
Safety Precautions ...................................................................................... 3
Important Precautions ................................................................................. 4
Installation Instructions ................................................................................ 4
Operating Your Wine/Beverage Cooler ....................................................... 5
Care and Maintenance ................................................................................ 6
Trouble Shootings ........................................................................................ 7
Warranty ...................................................................................................... 8

1
Your Wine/Beverage Cooler
KRC-12SS KRC-18SS
KRC-24SS KRC-6893
1. Cabinet 6. Control Panel
2. Shelf 7. Glass Door
3. Retainer Bar 8. Handle
4. Foot 9. Bottom Hinge
5. Upper Door Hinge with Cover

2
Technical Data
Electrical Circuit Diagram
For KRC-12SS / KRC-18SS:
For KRC-24SS:
Model No. KRC-12SS KRC-18SS KRC-24SS KRC-6893
Capacity 12bottles 18bottles 24bottles 2.4cu.ft
Voltage 110-120V 110-120V 110-120V 110-120V
Rated Current 1.2A 1.2A 1.2A 1.2A
Frequency 60Hz 60Hz 60Hz 60Hz
Input Power 85W 85W 85W 85W
Temperature
Range
40~66ºF
(5~19ºC)
40~66ºF
(5~19ºC)
40~66ºF
(5~19ºC)
38~65ºF
(3~18ºC)
Net Weight 37.5lbs 43.0lbs 47.0lbs 47.0lbs
Gross Weight 41.9lbs 46.6lbs 52.9lbs 52.9lbs
Product Size 9.9x17.7x31.2 13.6x17.7x30.3 16.9x17.7x29.1 16.9x17.7x29.1
Packing Size 13.8x21.7x33.
5
17.5x21.7x32.3 20.7x21.5x31.5 20.7x21.5x31.5

3
For KRC-24SS / KRC-6893
Safety Precautions
 PLEASE READ all instructions before installing, operating, or servicing the
appliance.
 Danger and Warning: Failure to follow this safety statement will result in severe
personal injury or death, property, or equipment damage.
 RISK OF CHILD ENTRAPMENT. Before you throw away your old refrigerator or
freezer, take off the doors and leave shelves in place so children may not easily
climb inside. Keep children away from the wine cooler, avoid them put fingers in
air outlet on the kick plate.
 SHOCK HAZARD - Electrical Grounding required.
 Never attempt to repair or perform maintenance on the unit until the electricity
has been disconnected.
 Never remove the round grounding prong from the plug and never use a two-
prong grounding adaptor.
To reduce the risk of fire, electrical shock, or injury when
using your appliance, follows these basic precautions.

4
 Altering, cutting of power cord, removal of power cord, removal of power plug, or
direct wiring can cause serious injury, fire or loss of property and life, and will void
the warranty.
 Never use an extension cord to connect power to the unit.
 Always keep the working area dry.
Important Precautions
 Do not lift unit by door handle.
 Do keep the door closed before installing into cabinet.
 Be sure the kick-plate on the front bottom is free from obstruction. Obstructing
free airflow can cause the unit to malfunction and will void the warranty.
 Allow unit temperature to stabilize for 24 hours before use.
 Do not block any internal fans.
 Use only genuine supplier's replacement parts. Imitation parts can damage the
unit, affect its operation or performance, and may void the warranty.
Installation Instructions
Before using your wine cooler:
 Remove the exterior and interior packing.
 Before connecting the appliance to the power outlet, let it stand upright for
approximately 24 hours. This will reduce the possibility of malfunction in the
cooling system from handling during transportation.
 Clean the interior surface with lukewarm water using a soft cloth.
 Place your appliance on a floor that is strong enough to support the appliance
when it is fully loaded.
 To level your appliance, adjust the front legs at the bottom of the appliance.

5
Operating Your Wine/Beverage Cooler
 It is recommended that the wine Cooler be installed in an area where the ambient
temperature is between 41-90ºF (5-32ºC).
 CONTROL PANEL
 SETTING THE TEMPERATURE CONTROL
 Your Cooler is equipped with a control panel lock feature which will lock itself
automatically 30 seconds after the last time a button is pressed.
 Press the button to unlock the control panel.
 You can manually adjust the temperature inside Cooler by pressing the
buttons on the display panel. The two buttons on the panel and
adjust the temperature in increments of 1ºC or 1ºF.
 You can select the temperature to display in Fahrenheit or Celsius by
pressing the button for 3 seconds.
 You can turn the interior light on or off by pressing the button.
 Note
 If the unit is unplugged, the power is lost or turned off, you must wait 3 to 5
minutes before restarting the unit if you attempt to restart before this time
delay, the Cooler will not start.
 When you use the Cooler for the first time or restart the Cooler after having
been shut off for a long time, there could be a few degrees variance between

6
the temperature you select and the one indicated on the LED readout. This
is normal and it is due to the length of the activation time. Once the Cooler
is running for a few hours everything will be back to normal.
Care and Maintenance
Cleaning your wine cooler
 Unplug the wine cooler and remove the bottles.
 Wash the inside with warm water or baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
 The outside of wine cooler should be cleaned with mild detergent or warm water.
Moving your wine cooler
 Remove all the bottles.
 Securely tape down all loose items inside your wine cooler.
 Turn the leveling legs up to the base to avoid damage.
 Tape the door.
 Be sure the wine cooler stays in the upright position during transportation.

7
Trouble Shootings
You can solve many common wine cooler problems easily. Try the suggestion below to
see if you can solve the problem before contacting the service center.
PROBLEM POSSIBLE CAUSE
Wine cooler do not
operate.
Not plugged in using different voltage. The circuit
breaker tripped or a blown fuse.
Wine cooler is not cold
enough.
Check the temperature control setting.
The door is open too often.
The door is not closed completely.
The door seal does not seal properly.
The wine cooler does not have the correct clearance.
The light does not work. Main control board does not work.
PCB Problem.
There is some problem with the plug.
Vibrations. Check to assure that the wine cooler is leveled.
The wine cooler seems to
make too much noise
The wine cooler is not leveled.
Check the fan.
The door will not close
properly.
The wine cooler is not leveled.
The doors were reversed and not properly installed.
The seal is weak.
The shaves out of position.
LED could not display. Main control board does not work.
PCB Problem.
There is some problem with the plug.
LED display error. Weak quality of display.
Temperature point is out off.
Buttons are not functional. Temperature controller panel is damaged.

8
Warranty
KALAMERA LIMITED WARRANTY
Limited One Year Warranty
Warranty Terms:
The manufacture warrants to the original purchaser of this product that the product will
be free from manufacturing defects in workmanship and material for a period of 1 year
from the date of original purchase when this major appliance is operated and maintained
according to instructions attached to or furnished with the product.
The purchaser must contact the manufacture Customer Service Department and provide
a description of the defective part, including digital pictures if requested, with buying
channel, serial number, order ID and the original purchase documentation as validation
of warranty coverage date.
Once confirmed that your appliance is eligible for the warranty service, KALAMERA
Customer Service Department will contact you by mail or phone about the maintenance
solution. Replacement parts and/or units will be new, re-manufactured or refurbished and
is subject to the manufacturer’s discretion. KALAMERA is not responsible for damage
resulting from shipper mishandling or improper packing. Do not return a defective
product to the place of purchase. Product received without a return authorization number
will be refused.
After receiving the unit, please do not remove, altered original model/serial number, that
will influence the after-sale service. Please carefully keep the user manual and warranty
card for future reference.
If you need service, first see the “Troubleshooting” section of the User Manual. After
checking, you may find additional help by mailing or calling us.
Write down the following information about your product to better help you obtain

9
assistance or service if you ever need. You can find this information on the model and
serial number located on the product.
Dealer name
Model number
Serial number
Purchase date
Warranty Exclusions:
The warranty will not apply if damage is caused by any of the following:
1. Damage to the product due to misuse, mishandling and abuse.
2. Product not assembled or installed according to manufacturer’s instruction.
3. Repairs by unauthorized persons or service centers with unauthorized spare parts.
4. Failure to provide reasonable and necessary maintenance.
5. Improper power supply such as low voltage, defective household wiring or inadequate
fuses.
6. Accident, alteration, misuse, or abuse of the appliance such as using non-approved
accessories, inadequate air circulation in the room or abnormal operating conditions,
such as extreme temperatures.
7. Damage in transit or when moving the appliance.
8. Use of force or damage caused by external influences.
9. Store improper things.
10. Normal wear and tear.
11. Cosmetic damage, including scratches, dents, chips, or other damage to the finish of
your product, unless such damage results from defects in materials or workmanship and
is reported to us within 30 days from the date of purchase.
12. Fire, water damage, theft, war, riot, hostility or acts of God such as hurricanes, floods,
etc. In addition to consequential damage and incidental damages, such as damage to
person or property are not coverable under this warranty.
13. Partially or completely dismantled appliances.

10
To obtain service or information, please send email to
[e-mail]
Product contents and specifications may change without notice.
