Miele SmartLine CS 7641 User manual

Operating and installation
instructions
SmartLine induction wok
To avoid the risk of accidents or damage to the appliance it is
essential to read these instructions before it is installed and used for
the first time.
en-AE, SA M.-Nr. 11 782 200


Contents
3
Warning and Safety instructions...................................................................... 5
Caring for the environment .............................................................................. 15
Guide to the appliance...................................................................................... 16
Wok ..................................................................................................................... 16
Controls and display ........................................................................................... 17
Cooking zones..................................................................................................... 18
Accessories supplied .......................................................................................... 19
How it works ...................................................................................................... 20
Pans .................................................................................................................... 21
Before using for the first time .......................................................................... 22
Cleaning the SmartLine element for the first time............................................... 22
Switching on the SmartLine element for the first time ........................................ 22
Setting ranges.................................................................................................... 23
Operation............................................................................................................ 24
Using the appliance............................................................................................. 24
Switching on the wok .......................................................................................... 25
Setting the power level........................................................................................ 25
Switching off........................................................................................................ 25
Residual heat indicator........................................................................................ 25
Power level setting - Extended setting range...................................................... 25
Auto heat-up ....................................................................................................... 26
Booster................................................................................................................ 27
Keeping warm ..................................................................................................... 28
Timer................................................................................................................... 29
Minute minder ..................................................................................................... 29
Auto switch off .................................................................................................... 30
Using both timer functions at the same time ...................................................... 31
Additional functions .......................................................................................... 32
Stop&Go............................................................................................................ 32
Recall................................................................................................................... 32
Wipe protection ................................................................................................... 33
Demonstration mode........................................................................................... 33
Displaying the SmartLine element data .............................................................. 33
Safety features................................................................................................... 34
System lock/safety lock ...................................................................................... 34
Safety switch-off ................................................................................................. 35

Contents
4
Overheating protection........................................................................................ 36
Programming ..................................................................................................... 37
Cleaning and care ............................................................................................. 40
Problem solving guide ...................................................................................... 42
Messages in the display...................................................................................... 42
Unexpected behaviour ........................................................................................ 44
General problems or technical faults................................................................... 45
Optional accessories ........................................................................................ 46
After sales service............................................................................................. 47
Contact in case of malfunction ........................................................................... 47
Data plate ............................................................................................................ 47
Guarantee............................................................................................................ 47
Installation.......................................................................................................... 48
Safety instructions for installation ....................................................................... 48
Safety distances.................................................................................................. 49
Installation notes – surface-mounted.................................................................. 53
Worktop cutout – surface-mounted .................................................................... 55
Spacer bars – surface-mounted.......................................................................... 58
Installation dimensions–Surface-mounted........................................................ 59
Installation – surface-mounted............................................................................ 60
Installation notes – flush-fit ................................................................................. 62
Worktop cutout – flush-fit.................................................................................... 64
Spacer bars – flush-fit ......................................................................................... 67
Installation dimensions–Flush-fit ....................................................................... 68
Installation – flush-fit ........................................................................................... 69
Electrical connection ........................................................................................... 71

Warning and Safety instructions
5
This wok complies with all current local and national safety
requirements. Inappropriate use can, however, lead to personal
injury and material damage.
Read the operating and installation instructions carefully before
using the wok. They contain important information on safety,
installation, use and maintenance. This prevents both personal
injury and damage to the wok.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
chapter on installing the wok as well as the safety instructions and
warnings.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these instructions in a safe place and pass them on to any
future owner.

Warning and Safety instructions
6
Correct application
This wok is designed for domestic use and for use in similar
environments.
This wok is not intended for outdoor use.
This wok is intended for domestic use only to cook food and keep
it warm. Any other use is not supported by the manufacturer and
could be dangerous.
This wok can only be used by people with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if
they are supervised whilst using it. They may only use it
unsupervised if they have been shown how to use it in a safe way
and understand the hazards involved.

Warning and Safety instructions
7
Safety with children
Children under 8 years of age must be kept away from the wok
unless they are constantly supervised.
Children aged 8 and older may only use the wok without
supervision if they have been shown how to use it in a safe manner.
Children must be able to understand and recognise the possible
dangers caused by incorrect operation.
Children must not be allowed to clean the wok unsupervised.
Please supervise children in the vicinity of the wok and do not let
them play with it.
The wok gets hot when in use and remains hot for a while after
being switched off. Keep children well away from the appliance until
it has cooled down and there is no danger of burning.
Danger of burning!
Do not store anything which might arouse a child's interest in
storage areas above or behind the wok. Otherwise they could be
tempted into climbing onto the wok with the risk of burning
themselves.
Risk of burning and scalding. Place pots and pans on the cooking
zone in such a way that children cannot pull them down and burn
themselves.
Danger of suffocation. Packaging, e.g. plastic wrappings, must be
kept out of the reach of babies and children. Whilst playing, children
could become entangled in packaging or pull it over their head and
suffocate.
Activate the system lock to ensure that children cannot switch the
wok on by mistake. Use the safety lock when the wok is in use to
prevent children from altering the settings selected.

Warning and Safety instructions
8
Technical safety
Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and
repairs must only be carried out by your Miele dealer.
Damage to the wok can compromise your safety. Check the wok
for visible signs of damage. Do not use a damaged wok.
Temporary or permanent operation on an autonomous power
supply system or a power supply system that is not synchronised
with the mains power supply (e.g. island networks, back-up systems)
is possible. A prerequisite for operation is that the power supply
system complies with the specifications of EN50160 or an
equivalent standard.
The function and operation of the protective measures provided in
the domestic electrical installation and in this Miele product must
also be maintained in isolated operation or in operation that is not
synchronised with the mains power supply, or these measures must
be replaced by equivalent measures in the installation. As described,
for example, in the current version of BS OHSAS 18001–2 ISO
45001.
The electrical safety of this wok can only be guaranteed when
correctly earthed. It is essential that this standard safety requirement
is met. If in any doubt please have the electrical installation tested by
a qualified electrician.
Before connecting the wok to the mains supply, ensure that the
connection data on the data plate (voltage and frequency) match the
mains electricity supply.
This data must be checked before connecting the appliance. Consult
a qualified electrician if in any doubt.
Do not connect the wok to the mains electricity supply by a multi-
socket unit or an extension lead. These do not guarantee the
required safety of the appliance (fire hazard).

Warning and Safety instructions
9
For safety reasons, this wok may only be used after it has been
built in.
This wok must not be used in a non-stationary location (e.g. on a
ship).
Never open the casing of the wok.
Touching or tampering with electrical connections or components
and mechanical parts is highly dangerous to the user and can cause
operational faults.
While the wok is under warranty repairs should only be
undertaken by a Miele authorised technician. Otherwise the warranty
is invalidated.
Miele can only guarantee the safety of the appliance when
genuine original Miele replacement parts are used. Faulty
components must only be replaced by Miele spare parts.
The wok is not intended for use with an external timer switch or a
remote control system.
If the plug is removed from the connection cable or if the cable is
supplied without a plug, the wok must be connected to the electrical
supply by a suitably qualified electrician.
If the mains connection cable is damaged, it must be replaced
with a special mains connection cable by a qualified electrician (see
“Electrical connection” in the “Installation” chapter).

Warning and Safety instructions
10
During installation, maintenance and repair work, the wok must be
completely disconnected from the mains electricity supply. It is only
completely isolated from the electricity supply when:
- The mains fuse is disconnected.
- The screw-out fuse is removed (in countries where this is
applicable).
- The plug (if present) is removed from the socket. To do this, pull
the plug and not the mains connection cable.
Danger of electric shock!
Do not use the wok if it is faulty, or if the ceramic surface is cracked,
chipped or damaged in any way. If you detect a fault during use
switch it off immediately. Disconnect the wok from the electrical
supply. Contact your Miele dealer.
If the wok is built in behind a furniture front (e.g. a door), do not
close the furniture door while the wok is in use. Heat and moisture
can build up behind the closed furniture door. This can result in
damage to the wok, the housing unit and the floor. Do not close the
furniture door until the residual heat indicators have gone out.
In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and
its surroundings clean at all times. Any damage caused by
cockroaches or other vermin will not be covered by the warranty.

Warning and Safety instructions
11
Correct use
The wok gets hot when in use and remains hot for some time after
being switched off. The risk of burning is present until the residual
heat indicators have gone out.
Overheated fat and oil can ignite and catch fire. Never leave the
wok unattended. Do not attempt to extinguish burning oil or fat with
water.
Switch the wok off and carefully smother the flames with a fire
blanket or a damp tea towel.
Do not leave the SmartLine element unattended whilst it is being
used. It should be continually monitored whilst boiling and flash
frying.
Flames could set the grease filters of a cooker hood on fire. Do
not flambé under a cooker hood.
Spray canisters, aerosols and other inflammable substances can
ignite when heated. Therefore do not store such items or substances
in a drawer under the wok. Cutlery inserts must be heat-resistant.
Do not heat an empty pan.
Do not heat up food in closed containers e.g. tins or sealed jars
on the wok, as pressure will build up in the container which could
cause it to explode.
Do not cover the wok, e.g. with a cover, a cloth or protective foil.
The material could catch fire, shatter or melt if the appliance is
switched on by mistake or if residual heat is still present.
When the wok is switched on either deliberately or by mistake, or
when there is residual heat present, there is the risk of any metal
items left on the wok heating up. Other materials can melt or catch
fire. Damp pan lids might adhere to the ceramic surface and be
difficult to dislodge. Do not use the wok as a resting place for
anything else. Always disconnect the wok from the power supply
when you have finished using it.

Warning and Safety instructions
12
You could burn yourself on the hot wok. Protect your hands with
heat-resistant pot holders or gloves when using a hot wok. Do not let
them get wet or damp. Heat transfers through damp and wet
material more quickly with the risk of scalding or burning yourself.
When using an electrical appliance, e.g. a hand-held food blender,
near the wok, ensure that the cable of the electrical appliance cannot
come into contact with the hot wok. The insulation on the cable
could become damaged.
Grains of salt, sugar and sand (e.g. from cleaning vegetables) can
cause scratches if they get under pan bases. Make sure that the
ceramic surface is clean before placing pans on it.
Even a light object can cause damage in certain circumstances.
Do not drop anything on the ceramic surface.
Placing hot pans on the sensors and indicators could damage the
electronics underneath. Do not place hot pans on the sensors or
indicators.
Do not allow solid or liquid sugar, or pieces of plastic or aluminium
foil to get onto the wok when it is hot, as they can damage the
ceramic surface when it cools down. If this should occur, switch off
the wok immediately and scrape off all residues straight away using
a scraper blade suitable for use on glass. Wear oven gloves when
doing this. Allow the ceramic surface to cool down and then clean it
with a suitable ceramic hob cleaning agent.
Do not allow the wok pan to boil dry as this this can damage the
ceramic glass. Do not leave the wok unattended whilst it is being
used.
Because induction heating works so quickly, the base of the pan
could heat up to the temperature at which oil or fat self-ignites within
a very short time. Do not leave the wok unattended whilst it is being
used.

Warning and Safety instructions
13
Heat oil or fat for a maximum of one minute. Never use the
Booster function to heat oil or fat.
For people fitted with a heart pacemaker: please note that the
area immediately surrounding the wok is electromagnetically
charged. It is very unlikely to affect a pacemaker. However, if in any
doubt, consult the manufacturer of the pacemaker or your doctor.
To prevent damage to items which are susceptible to
electromagnetic fields, e.g. credit cards, digital storage devices,
pocket calculators, etc, do not leave them in the immediate vicinity
of the wok.
Metal objects stored in a drawer under the wok can become hot if
the appliance is used intensively for a long time. Do not store any
metal objects in a drawer directly under the wok.
The wok is fitted with a cooling fan. If a drawer is fitted directly
underneath the built-in wok, ensure that there is sufficient space
between the drawer and its contents and the underside of the wok in
order to ensure sufficient ventilation for the wok. Do not store
pointed or small items or paper in the drawer. They could get in
through the ventilation slots or be sucked into the casing by the fan
and damage the fan or impair cooling.
Only use the wok pan supplied with the appliance. For safety
reasons, other wok pans must not be used. Danger of burning (see
“Induction - Pans”).

Warning and Safety instructions
14
Cleaning and care
Do not use a steam cleaning appliance to clean this wok.
The steam could reach electrical components and cause a short
circuit.
If the wok is built-in above a pyrolitic oven or cooker, do not use it
during a Pyrolytic cleaning programme as this could trigger the
overheating protection device on the wok (see “Safety features” –
“Overheating protection”).
Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the
discontinuation of your CombiSet.

Caring for the environment
15
Disposing of the packaging
material
The packaging material is used for
handling and protects the appliance
from transport damage. The packaging
material used is selected from materials
which are environmentally friendly for
disposal and can generally be recycled.
Recycling the packaging material
reduces the use of raw materials. Use
material-specific collection points for
valuable materials and take advantage
of return options. Your Miele dealer will
take the packaging material away.
Disposal of your old appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain materials which, if handled
or disposed of incorrectly, could be
potentially hazardous to human health
and to the environment. They are,
however, essential for the correct
functioning of your appliance. Please
do not therefore dispose of it with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre or contact your Miele dealer for
advice.
Ensure that it presents no danger to
children while being stored for disposal.

Guide to the appliance
16
Wok
aWok recess
bControls and indicators

Guide to the appliance
17
Controls and display
Sensor controls
aWok On/Off
bStop&Go
To stop/start a cooking process in progress
cWipe protection
To lock the sensor controls
dKeeping warm
To activate/deactivate the Keeping warm function
eNumerical display
– To set the power level
– To set the times
fAuto switch off
Switches the wok off automatically
gMinute minder

Guide to the appliance
18
Displays/indicator lights
hCooking zone allocation auto switch off
Auto switch off for the wok is activated
iResidual heat
jBooster function
Booster function is activated
kTimer display
: to
:
Time
System lock/safety lock is activated
Demo mode is activated
Cooking zones
Wok basin Øin cm* Rating in watts for 230V**
30.0 Normal
TwinBooster, level 1
TwinBooster, level 2
2400
2650
3000

Guide to the appliance
19
Accessories supplied
The accessories supplied with your
appliance as well as a range of optional
ones are available to order from your
Miele dealer (see „Optional
accessories“).
Wok pan CSWP 1450

How it works
20
An induction coil is located underneath
the induction wok. The coil creates a
magnetic field that reacts directly with
the base of the pan and heats it up. The
wok recess itself is heated up indirectly
by the heat given off by the wok pan.
Induction heating only works when the
wok pan supplied is used.
Risk of burning due to hot items.
When the wok is switched on either
deliberately or by mistake, or when
there is residual heat present, there
is the risk of any metal items left on
the wok heating up.
Do not use the wok as a resting
place for anything.
After use, switch the wok off with the
sensor control.
Noises
The following noises might occur in the
wok pan when the induction wok is in
operation:
Buzzing on the higher power settings.
This will decrease or cease altogether
when the power setting is reduced.
You might hear a clicking sound from
the electronic switches, especially on
lower settings.
A whirring sound, when the cooling fan
comes on. This switches on to protect
the electronics when the wok is being
used intensively. The cooling fan may
continue to run after the appliance has
been switched off.
Table of contents
Other Miele Kitchen Appliance manuals

Miele
Miele KM 402 User manual

Miele
Miele MLT4700 User instructions

Miele
Miele EBA 5470 MC User manual

Miele
Miele KWT 2601 SF User manual

Miele
Miele SmartLine CS 7612 FL User manual

Miele
Miele TepanYaki CS 1327 User manual

Miele
Miele KWT 2601 Vi User manual

Miele
Miele HUB 62-35 User manual

Miele
Miele EVS 7110 User manual

Miele
Miele KWT 2601 Vi User manual

Miele
Miele DGSB 1 User manual

Miele
Miele CT 400 P User manual

Miele
Miele PRI 210 User manual

Miele
Miele H 2265-1 B User manual

Miele
Miele HUB 5000-XL User manual

Miele
Miele KM 403 User manual

Miele
Miele KWT 6833 SG User manual

Miele
Miele ProLine Tepan Yaki User manual

Miele
Miele KWT 2671 ViS User manual

Miele
Miele H 4200 User manual
