Homeowners Guide
Michael Smith
Whirlpool Bath
Mproduct numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de Mcorresponden a México
(Ej. K-12345M)
Français, page “Français-1”
Español, página “Español-1”
P50035
1019455-5-B

Important Information
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRICAL SHOCK, OR INJURY TO PERSONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING: When using electrical products, basic precautions should always be followed,
including the following:
DANGER: Risk of personal injury. To reduce the risk of injury, do not permit children to use this
unit unless they are closely supervised at all times
WARNING: Risk of personal injury. To avoid injury, exercise care when entering or exiting the
whirlpool.
WARNING: Risk of electric shock. Do not permit electric appliances (such as a hair dryer, lamp,
telephone, radio, or television) within 5’ (1.5 m) of this whirlpool.
WARNING: Risk of hyperthermia. People using medications and/or having an adverse medical
history should consult a physician before using a whirlpool equipped with a heater.
An equipment grounding terminal is provided in the field wiring compartment. To reduce the risk of electric
shock, this terminal must be connected to the grounding means provided in the electric supply panel with a
conductor equivalent in size to the circuit conductors supplying this whirlpool.
A pressure wire connector is provided on the exterior of the pump or control within this unit to permit
connection of a bonding conductor between this unit and all other exposed metal in the vicinity, as needed to
comply with local requirements.
Use this whirlpool only for its intended purpose as described in this manual. Do not use attachments not
recommended by the manufacturer.
Never drop or insert any object into any opening.
Do not operate this unit without the guard (cover) over the suction fitting.
The whirlpool must be connected only to a supply circuit that is protected by a Ground-Fault
Circuit-Interrupter (GFCI) or Earth-Leakage Circuit-Breaker (ELCB). Such a GFCI or ELCB should be
provided by the installer and should be tested on a routine basis. To test the GFCI or ELCB, press the test
button. The GFCI or ELCB should interrupt power. Press the reset button. Power should be restored. If the
GFCI or ELCB fails to operate in this manner, the GFCI or ELCB is defective. If the GFCI or ELCB interrupts
power to the bath without the test button being pressed, a ground current is flowing, indicating the
possibility of an electric shock. Do not use this whirlpool bath. Disconnect the whirlpool and have the
problem corrected by a qualified service representative before using.
WARNING: The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia. Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs
when the internal temperature of the body reaches a level several degrees above the normal body
temperature of 98.6° F (37° C). The symptoms of hyperthermia include an increase in the internal
temperature of the body, dizziness, lethargy, drowsiness, and fainting. The effects of hyperthermia
include: (a) failure to perceive heat, (b) failure to recognize the need to exit the bath, (c) unawareness
of impending hazard, (d) fetal damage in pregnant women, (e) physical inability to exit the bath, and
(f) unconsciousness resulting in the danger of drowning.
IMPORTANT! Flush your whirlpool system twice a month or more depending upon usage, as described
in Care and Cleaning Instructions in this manual.
Do not allow the water temperature in the whirlpool to exceed 104° F (40° C).
Keep small objects such as bath toys and bathing accessories out of the whirlpool while the unit is running.
1019455-5-B 2 Kallista

Important Information (cont.)
Repeated use of personal care products containing oils can damage plastic whirlpool components. Do not use
heavy, vegetable-based shampoos or bath oils.
Whirlpool hydro-massage action can cause even a small amount of bubble bath, bath soap, shampoo, or bath
oil to foam excessively. For this reason, please don’t use these products during whirlpool operation.
Table of Contents
Important Information .............................................................. 2
Thank You For Choosing Kallista ..................................................... 3
Your Kallista Whirlpool ............................................................. 3
User Keypad And Whirlpool Modes/Features ............................................ 4
Operating Your Whirlpool ........................................................... 4
Remote Control .................................................................. 5
FCC Compliance ................................................................. 5
Programming the Remote Control ..................................................... 5
Care and Cleaning Instructions ....................................................... 6
Cleaning Your Cast Iron Whirlpool .................................................. 6
Cleaning Your User Keypad and Remote Control ....................................... 6
Flushing Your Whirlpool System .................................................... 6
Limited Five-Year Warranty ......................................................... 6
Troubleshooting Procedures ......................................................... 8
Remove the Factory Installed Jets .................................................. 8
Reinstall the Jets ............................................................... 8
Troubleshooting Guide ........................................................... 8
Service Parts ................................................................... 11
Thank You For Choosing Kallista
Thank you for choosing Kallista for your whirlpool purchase. Your new whirlpool reflects Kallista’s
dedication to craftsmanship, quality, and attention to detail.
Please take a few minutes to study this Homeowners Guide before you use your whirlpool. Pay special
attention to the Care and Cleaning instructions in this manual.
All information in this manual is based upon the latest product information available at the time of
publication. At Kallista, we constantly strive to improve the quality of our products. We reserve the right to
make changes in product characteristics, packaging, or availability at any time without notice.
Your Kallista Whirlpool
Your new whirlpool is designed to stimulate, invigorate, and energize your body with comforting
hydro-massage therapy. The whirlpool consists of the following components:
Bath - acts as a reservoir for water, and provides a location for the hydro-massage action.
User Keypad - located within easy reach, the keypad allows you to turn the whirlpool and heater
on and off and regulate the water flow through the jets.
Pump Motor - provides quiet, variable speed power to circulate the water and create the soothing
hydro-massage action.
Adjustable Jets - positioned to optimize their hydro-massage effect, the jets allow you to adjust the
air and water flow and control the flow direction as you desire.
Heater - designed to automatically help maintain the temperature of the water up to 104° F (40° C)
to enhance your hydro-massage experience. The heater turns on automatically when the whirlpool
is operating, and turns off when the pump motor is turned off. The heater may be turned off,
through the keypad, at any time while the pump is operating.
Remote Control - submersible control that allows you to control the whirlpool functions from either
inside or outside the bath.
Kallista 3 1019455-5-B

User Keypad And Whirlpool Modes/Features
Power - Turns the whirlpool pump on and off.
Up Arrow - Increases the water flow.
Down Arrow - Decreases the water flow.
Heater - The heater automatically engages when the whirlpool is turned on. You may turn the
heater off by pressing the heater button. Press the button a second time to turn the heater back on.
Indicator Bar - Shows the water flow volume.
Operating Your Whirlpool
Turn the jet trim fully counterclockwise. Position the jet nozzles so they face down toward the basin.
NOTE: The water temperature in the whirlpool should never exceed 104° F (40° C). A built-in heater
automatically maintains the water temperature when the whirlpool is running, as long as the water
temperature does not exceed 104° F (40° C). The heater will disengage at higher temperatures.
Close the drain, and fill the whirlpool to a level at least 2” (5 cm) above the top of the highest jet.
Use your hand to test the water temperature for comfort and safety, then carefully enter the bath.
Press Power to turn on the whirlpool. The whirlpool will start at medium volume. The heater will
also turn on and the heater icon will illuminate.
Increase or decrease the water flow by pressing the up or down arrows on the keypad. An indicator
bar in the center of the keypad shows the water flow volume.
Adjust the jets for optimum air/water mixture. Turn the jet trim clockwise to reduce the flow, and
counterclockwise to increase the flow. Position the jet nozzles to direct the water flow as desired to
maximize your hydro-massage experience.
The heater automatically engages when the whirlpool is turned on. You may turn the heater off by
pressing the heater button on the keypad. Press the button a second time to turn the heater back on.
Press Power a second time to turn off the whirlpool.
NOTE: Your whirlpool will automatically stop after approximately 20 minutes of continuous operation.
You can restart the whirlpool, if you desire, by pressing Power.
Carefully exit the bath, and open the drain to empty the whirlpool.
NOTE: If the whirlpool does not function properly, please refer to Troubleshooting in this manual.
Heater
On/Off
Power
On/Off Decreases
Flow
Indicator Bar -
Shows water
flow volume
Increases
Flow
Heater Indicator Light
Lighted User Keypad
Turn the jet trim
clockwise to
decrease the flow
Turn the jet trim
counterclockwise to
increase the flow
1019455-5-B 4 Kallista

Remote Control
The remote control places the whirlpool functions at your fingertips to further enhance your bathing
experience. The functions of the remote are identical to the user keypad. You may turn the
whirlpool on and off, turn the heater on and off, and increase or decrease the water flow by the
press of a button.
The waterproof remote control is designed to be used in the bath and will float in the water.
Two AAA batteries are used in the remote control. To replace, simply unscrew the end cap and
insert the batteries, as shown above. Tighten the end cap securely, making sure the end cap makes
contact with the seal.
FCC Compliance
FCC ID : N82-KOHLER001
Canada ID : 4554A-KOHLER001
Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
Warning (Part 15.21)
Changes or modifications not expressly approved by the party responsible for compliance could void the
users authority to operate the equipment.
Programming the Remote Control
NOTE: Programming of the remote control is normally not required. If more than one device in your
home, or in the near vicinity of your home, uses a remote control, it may be necessary to program this
remote control to the user keypad. If you replace your remote control, or replace the pump control, it may
be necessary to program the remote control.
Turn the whirlpool power on.
Turn off all modes of operation. Wait approximately one minute until the keypad darkens
completely (sleep mode).
Power
Increases
Flow
Decreases
Flow
Heater
Kallista 5 1019455-5-B

Programming the Remote Control (cont.)
On the user keypad, press the up arrow, down arrow and the “OK” button simultaneously. The
bottom LED, on the keypads indicator bar, will begin flashing.
While the LED is flashing, press the “OK” button on the keypad. A light sequence will illuminate
up and down the indicator bar.
While the indicator bar light sequence is active, press any button on the remote control. The
program will download and the user keypad will darken. The user keypad will now respond only
to this remote control.
Care and Cleaning Instructions
Cleaning Your Cast Iron Whirlpool
Rinse the whirlpool thoroughly after each use and use a soft cloth to wipe it dry. If the surface
becomes dirty, use a general purpose cleaner such as Scrub Free
®
Mildew Stain Remover, Clorox
Clean-Up
®
, Glass Plus
®
, Winde Original, Fantastic
®
All Purpose, Mr. Clean Top Job, Formula 409
®
All Purpose, Lysol
®
Basin, Tub and Tile Cleaner or Scrubbing Bubbles
®
Bathroom Cleaner.
IMPORTANT! Use water soluble cleaners (dissolve 100% in water). Cream-based cleaners may have a
tendency to build up, reducing the friction on slip-resistant surfaces.
Express Bathroom Cleaner may be used on the Safeguard surface of your whirlpool. It is not sold
commercially. Call 1-800-470-8337 to order. You may use a soft nylon brush on the Safeguard
surface.
Do not use steel wool, wire brushes or abrasive sponge pads. In the rare occurence of stubborn
stains, use abrasives or abrasive cleaners sparingly, but not on the Safeguard surface on the bottom
of the whirlpool.
For occasional rust removal you may use Whink
®
Rust and Iron Stain Remover or Muriatic Acid.
Cleaning Your User Keypad and Remote Control
Use a soft cloth to wipe the keypad and remote control after each use. If the surface becomes dirty,
use a non-abrasive soap and warm water to clean.
Flushing Your Whirlpool System
Flush your whirlpool system twice a month or more, depending upon usage. Use the following sequence:
Turn the jet trim rings fully clockwise to remove air induction.
Fill the whirlpool with warm water to a level at least 2″(5 cm) above the highest jets, or leave water
in the whirlpool after using.
Add 2 tablespoons (30 ml) of a low-foaming dishwasher detergent and 20 ounces (590 ml) of
household bleach (5% - 6% sodium hypochlorite) to the water.
Run the whirlpool for 5 to 10 minutes. Turn off the whirlpool and drain.
If desired, rinse the bath surfaces with water.
Rinse the surfaces of the jets, faucet, handrails, drain, etc. and wipe them dry with a soft cloth.
Limited Five-Year Warranty
Kallista warrants that its products conform to the relevant published specifications, and are free of defects in
workmanship or materials during normal residential use.
Kallista warrants, for a period of five years from the date of purchase from Kallista, that it will replace or
repair any product, with the exception of product within the Kallista Hampstead and Stafford Vitreous line,
1019455-5-B 6 Kallista

Limited Five-Year Warranty (cont.)
which, having been installed and maintained in accordance with Kallista’s instructions and with best
technical practices, fails to function or becomes defective through a fault in Kallista’s materials or
workmanship. Any damage to a product, even if not immediately apparent, due to misuse, abuse, accidents,
improper installation or improper maintenance, voids this warranty. [Please note that products installed in
coastal areas, or that are exposed to higher than normal levels of saltwater or residue, will require more
thorough and rigorous cleaning and maintenance.]
Kallista reserves the right to replace a faulty product which is no longer manufactured with an equivalent
product.
In the unlikely event of a claim under this warranty, the customer’s only obligation is to notify Kallista in
writing, stating the problem, the product, and giving proof of purchase. Neither Kallista nor its successors or
assigns, accept liability for loss, damages, or injuries relating to the product. To obtain warranty service,
contact Kallista by calling 1-800-4KALLISTA.
NOTE: To the extent permitted by law, implied warranties including that of merchantability and fitness
for a particular purpose are hereby disclaimed. Kallista, Inc. and its successors and assigns disclaims
any liability for special, incidental or consequential damages.
Some states do not allow limitations on how long an implied warranty lasts, nor the exclusion or limitation
of special, incidental or consequential damages, so this limitation and exclusion may not apply to you. This
warranty gives the buyer specific legal rights. The buyer may also have other rights which vary from state to
state.
This is our exclusive written warranty.
Kallista 7 1019455-5-B

Troubleshooting Procedures
Remove the Factory Installed Jets
NOTE: A special tool is provided with the replacement jets that will allow you to remove the jets from the
whirlpool. This tool is also supplied with each trim kit.
Position the jet ball nozzle so it is pointing upward.
NOTE: The nozzle must remain pointed up or the tool will slip off.
Insert the removal tool, hooked end up, into the opening of the jet and hook the inside top of the
nozzle.
Grasp the tool firmly and place your thumb against the whirlpool wall. Pull steadily on the tool
until the jet assembly pulls free of the hole. Be careful not to lose the O-ring.
Reinstall the Jets
NOTE: The jet O-ring must be correctly positioned, must be lubricated, and must be in good condition to
permit easy rotation and proper operation of the jet.
Install the O-ring onto the first shoulder of the jet. Lubricate the O-ring with silicone lubricant to
prevent noisy operation of the jet.
Carefully insert the jet into the housing, and lightly push and rotate the jet until it snaps into
position. Do not force the jet.
NOTE: When installed correctly, the jet should turn smoothly both clockwise and counterclockwise.
Troubleshooting Guide
This troubleshooting guide is for general aid only. A qualified electrician should correct any electrical
problems. For warranty service, contact your dealer or wholesale distributor.
Troubleshooting the Whirlpool System
Symptoms Probable Causes Recommended Action
1. User keypad does not
illuminate when power button
is pressed or outer ring is
rotated.
A. No power to control. A. Check wiring and connect
power. If problem persists,
refer to installer/dealer.
B. GFCI or ELCB tripped. B. Reset GFCI or ELCB.
Remove the Jets
Insert the tool hook as shown and pull the jet out of the
housing. The jet should be facing up when this is done. Housing
Re-install the Jets
Slide the O-ring
onto the first
shoulder of the jet
Inspect and
lubricate th
e
O-ring
Insert the jet into the housing, and lightly
push and rotate until it snaps in position
1019455-5-B 8 Kallista

Troubleshooting Procedures (cont.)
Troubleshooting the Whirlpool System
Symptoms Probable Causes Recommended Action
C. Wiring harness from user
keypad to control is loose,
disconnected or damaged.
C. Check wiring for proper
connections Replace wiring
harness if necessary. Refer to
installer/dealer.
D. Keypad doesn’t work. D. Replace user keypad. Refer to
installer/dealer.
E. Control doesn’t work. E. Replace control. Refer to
installer/dealer.
2. Motor starts, but all jets are not
functioning. A. Jet is closed. A. Rotate jet trim ring
counterclockwise to open.
B. Jet not installed correctly. B. Reinstall jet; check for O-ring
damage.
C. Jets are blocked. C. Remove blockage.
3. User keypad is illuminated but
does not respond to buttons. A. Control program is locked. A. Reset GFCI or ELCB.
B. Wiring harness from user
keypad to control is loose,
disconnected or damaged.
B. Check wiring for proper
connections. Replace wiring
harness if necessary. Refer to
installer/dealer.
C. Keypad doesn’t work. C. Replace user keypad. Refer to
installer/dealer.
D. Control doesn’t work. D. Replace control. Refer to
installer/dealer.
4. User keypad indicator bar
keeps scanning at power-up. A. Control program is locked. A. Reset GFCI or ELCB.
B. Wiring harness from user
keypad to control is loose,
disconnected or damaged.
B. Check wiring for proper
connections. Replace wiring
harness if necessary. Refer to
installer/dealer.
C. Keypad doesn’t work. C. Replace user keypad. Refer to
installer/dealer.
D. Control doesn’t work. D. Replace control. Refer to
installer/dealer.
5. User keypad is illuminated, but
pump won’t start. A. Power cord from pump to
control is loose, disconnected
or damaged.
A. Check wiring for proper
connections. If problem
persists, refer to
installer/dealer.
B. Pump doesn’t work. B. Replace pump. Refer to
installer/dealer.
C. Control doesn’t work. C. Replace control. Refer to
installer/dealer.
6. Motor runs but pump won’t
prime (cavitates). A. Pump is shimmed too high. A. Lower pump/control to
subfloor level.
B. Small air leak at pump inlet. B. Securely tighten nuts(s) on
intake side of pump.
C. Motor/pump doesn’t work. C. Replace motor/pump. Refer to
installer/dealer.
D. Control doesn’t work. D. Replace control. Refer to
installer/dealer.
7. Pump stops before 18 minutes. A. GFCI or ELCB tripped. A. Identify source of fault, and
correct. Reset GFCI or ELCB.
B. Suction is blocked. B. Remove obstruction.
C. Jets are blocked. C. Remove blockage.
Kallista 9 1019455-5-B

Troubleshooting Procedures (cont.)
Troubleshooting the Whirlpool System
Symptoms Probable Causes Recommended Action
D. Motor overheated and
protection device activated. C. Check for blockage at suction
and/or jets. Remove blockage
and allow motor to cool.
8. Pump does not automatically
stop after 22 minutes. A. 20-minute timer inadvertently
disabled. A. See service manual.
9. Pump won’t turn off when the
power button on user keypad
is pressed.
A. Keypad doesn’t work. A. Replace user keypad. Refer to
installer/dealer.
B. Control doesn’t work. B. Replace control. Refer to
installer/dealer.
10. Pump operates but variable
speed feature does not work. A. Motor/pump doesn’t work. A. Replace motor/pump. Refer to
installer/dealer.
B. Control doesn’t work. B. Replace control. Refer to
installer/dealer.
11. Bath water cools while pump
is operating. A. Water temperature is above
104° F (40° C). A. Allow bath water to cool.
B. Heater is turned off on user
keypad. B. Turn heater on.
C. Wiring from heater to control is
loose, disconnected or
damaged.
C. Check wiring for proper
connections. Refer to
installer/dealer.
D. Heater doesn’t work. D. Replace heater. Refer to
installer/dealer.
E. Control doesn’t work. E. Replace control. Refer to
installer/dealer.
12. Noisy operation. A. Pump banding straps have not
been cut. A. Cut pump banding straps with
tin snips.
B. Dry or dislodged jet O-ring
(squeal). B. Remove jet, replace and
lubricate O-ring, and reinstall
jet.
13. Remote control (if equipped)
does not work. A. Batteries improperly installed
or dead. A. Replace batteries.
B. Antenna on wiring harness is
damaged. B. Replace wiring harness. Refer
to installer/dealer.
C. Remote control not
programmed correctly. C. See homeowners guide or
service manual.
D. Remote control doesn’t work. D. Replace remote control.
E. Control doesn’t work. E. Replace control. Refer to
installer/dealer.
1019455-5-B 10 Kallista

Service Parts
**Finish/color code must be specified when ordering.
Kallista 11 1019455-5-B

**Finish/color code must be specified when ordering.
96895**
77935** (Colored Finishes)
(Metal Finishes)
Suction Cover
93836
93838 (1/2")
(1")
93839
94853 (1-1/4")
(1-1/2")
Tube (w/Couplings)
65885
67668 (Acrylic)
(Cast Iron)
Gasket
65886
60050
93685
Housing
73518
Plug
96708
Flange
1003065
65054**
Screw
65226**
Suction Cover Plug
91967
Check Valve
67665
Plug
67429
Flange
34353
O-Ring
67889
Jet Housing
94469
Flange Removal Tool
(Acrylic)
(Cast Iron)
Gasket
Suction Flange
Removal Tool
P51001-00**
P51002-00** (8 ea.)
(6 ea.)
P51007-00** (5 ea.)
Jet (Suction cover
included with metal
finishes.)
1019455-5-B 12 Kallista

1016953
1.5 HP Pump 1016954
Motor
To Tee Heater
1010548
Volute
1010673
Seal
1010677
Screw
1010675
O-Ring
1013755
Impeller
1010676
Cover
1018660
Control
94821
O-Ring
61845-K
Copper Grounding Wire
1019719
Connector
1005363
Nut
60320
Screw
67065
Ground Lug
1015008
Wire Harness
1018964
Bracket
1019433
Carriage Bolt
1001794
Locknut
90153
Nut
1019446-A [1-3/4" (4.4 cm)]
1019446-C [3" (7.6 cm)]
1019446-G
Stud [3-1/4" (8.3 cm)]
1019444-A [3/4" (1.9 cm)]
1019444-C [2" (5.1 cm)]
1019444-G
Spacer [2-1/4" (5.7 cm)]
1019447-B
Isolation Mount
[1/2" (1.3 cm)]
93893
Cover
60320
Screw
93892-A
Electrical Box 67065
Ground Lug
61776
Lock Washer
1033678
Screw
93003
Strain Relief
1010029
Pump Tee
1013969
O-Ring
60980
O-Ring
1034673
Connector
1005363
Nut
1022495
Pump Nut Wrench
61776
Lock Washer
1019444-B [1-3/4" (4.4 cm)] 1019446-B [2-3/4" (7 cm)]
**Finish/color code must be specified when ordering.
Kallista 13 1019455-5-B

1018710
Tee Heater
94821
O-Ring
1012977
Adapter
1012916
Nut w/Screws
1011679
Gasket
1012977
Adapter
94821
O-Ring
1012653
Adapter
1012653
Adapter
1012916
Nut w/Screws
1022408
In-line Heater
94821
O-Ring
**Finish/color code must be specified when ordering.
94821
O-Ring
1032545
Housing
1019455-5-B 14 Kallista

1013460
Housing
59588
Screw
94110
O-Ring
1013459-B
Decal
1013469**
Trim Ring
1020679-B
Cover/CircuitBoard
**Finish/color code must be specified when ordering.
65157
Nut
1020677
Gasket
Kallista 15 1019455-5-B

1023091**
Cap
1013471**
Stand
1013464-C
Decal
1022253-C**
Remote
1013822-C**
Remote w/Stand
**Finish/color code must be specified when ordering.
1019455-5-B 16 Kallista

Guide du propriétaire
Baignoire à hydromassage
Renseignements Importants
LIRE ET SUIVRE LES INSTRUCTIONS
VEUILLEZ GARDER CETTE NOTICE
CONSIGNES RELATIVES AUX RISQUES
D’INCENDIE, D’ÉLECTROCUTION OU DE
BLESSURES CORPORELLES
AVERTISSEMENT : Toutes les précautions de base devront être observées pour l’installation des
équipements électriques, incluant ce qui suit :
DANGER : Risques de blessure corporelle. Afin de réduire les risques de blessures, ne jamais
permettre à un enfant d’utiliser cet appareil sans surveillance.
AVERTISSEMENT : Risques de blessure corporelle. Pour éviter les blessures corporelles, entrer et
sortir avec prudence de la baignoire.
AVERTISSEMENT : Risque d’électrocution. Ne pas connecter d’appareils électriques (tel que
sèche-cheveux, lampe, téléphone, radio ou télévisions) à moins de 5″(1,5 m) de cette baignoire à
hydromassage.
AVERTISSEMENT : Risque d’hyperthermie. Les personnes sous médicaments ou qui sont sous
observation médicale doivent consulter leur médecin avant d’utiliser des baignoires équipées d’eau
chaude.
Une borne de mise à la terre est incluse dans le boîtier du câblage. Afin de réduire les risques d’une
électrocution, raccorder la borne de mise à la terre du panneau du service électrique, avec un câble ayant le
même calibre que celui du circuit de contrôle qui alimente votre appareil.
Un connecteur à pression par câble est prévu à l’extérieur de la pompe ou du contrôle de cet appareil afin de
permettre la connexion entre l’appareil et toutes autres surfaces de métal avoisinantes, tel que requis par les
normes locales.
N’utiliser seulement cet appareil que pour un usage tel que décrit dans ce manuel. Ne pas utiliser des
fixations non recommandées par le fabricant.
Ne pas faire tomber ni insérer un objet dans les ouvertures.
Ne pas utiliser cet appareil sans ses protecteurs (couvercles) sur les raccords d’aspiration.
La baignoire à hydromassage doit être uniquement accordée à un Disjoncteur Différentiel (GFCI) ou un
Disjoncteur de Mise à la Terre (ELCB) : L’installateur doit fournir les GFCI ou ELCB, lesquels devraient être
vérifiés régulièrement. Appuyez sur le bouton de Test pour tester les disjoncteurs GFCI ou ELCB. Les
disjoncteurs GFCI ou ELCB de mise à la terre devraient couper l’alimentation. Enfoncez le bouton de remise
en circuit. L’alimentation devrait être restituée. Si les disjoncteurs GFCI or ELCB ne fonctionnent pas de cette
façon, ils sont donc défectueux. Si les disjoncteurs GFCI ou ELCB stoppent l’alimentation électrique à la
baignoire à hydromassage sans que le bouton test soit utilisé, il y a donc un court circuit. Danger
d’électrocution. Ne pas utiliser cette baignoire à hydromassage. Débrancher la baignoire à hydromassage et la
faire réviser par un technicien qualifié.
Kallista Français-1 1019455-5-B

Renseignements Importants (cont.)
AVERTISSEMENT : L’alcool, les drogues ou les médicaments peuvent augmenter considérablement
le risque d’hyperthermie.Une immersion prolongée dans l’eau chaude peut provoquer l’hyperthermie.
L’hyperthermie se passe lorsque la température corporelle interne atteint plusieurs degrés au dessus de
la température normal de 98.6°F (37°C). Les symptômes d’hyperthermie comprennent la hausse de la
température corporelle, l’étourdissement, la léthargie, la somnolence et l’évanouissement. Les effets
d’hyperthermie comprennent : (a) défaut de percevoir la chaleur, (b) défaut de s’apercevoir du besoin
de sortir de la baignoire, (c) incapacité de reconnaître le danger, (d) souffrance foetale dans le cas des
femmes enceinte, (e) incapacité physique de sortir de la baignoire et (f) l’inconscience subséquente à la
noyade.
IMPORTANT ! Rincer la baignoire à hydromassage deux fois par mois ou plus souvent, ou selon la
fréquence d’usage, et tel que décrit dans la partie Entretien et Nettoyage.
Ne pas laisser la température de la baignoire à hydromassage excéder 104°F (40°C).
Ne pas laisser de petits objets ou des jouets pour le bain dans la baignoire à hydromassage lorsque celle-ci
est en marche.
L’utilisation régulière de produits d’hygiène et de beauté contenant des huiles peut endommager les
revêtements en plastique de votre baignoire à hydromassage. Ne pas utiliser de shampoings ou d’huiles de
bains à bases végétales.
L’action de la baignoire à hydromassage peut faire mousser une très petite quantité de produit moussant, de
savon, de shampoing ou d’huile pour le bain. Pour cette raison, nous vous conseillons de ne pas utiliser ces
produits dans votre baignoire à hydromassage.
Sommaire
Renseignements Importants ......................................................... 1
Merci d’avoir choisi Kallista ......................................................... 2
Votre baignoire à hydromassage Kallista ................................................ 3
Clavier de l’utilisateur et modes/fonctions de la baignoire à hydromassage ...................... 4
Fonctionnement de votre baignoire à hydromassage ....................................... 4
Télécommande .................................................................. 6
Conformité FCC .................................................................. 6
Programmer la télécommande ....................................................... 6
Instructions d’entretien et de nettoyage ................................................. 7
Nettoyage de votre baignoire à hydromassage en fonte .................................. 7
Nettoyer votre clavier et votre télécommande .......................................... 7
Purge du système de hydromassage ................................................ 7
Garantie limitée de cinq ans ......................................................... 8
Procédures de dépannage .......................................................... 9
Retirer les jets installés en usine ................................................... 9
Réinstaller les Jets .............................................................. 9
Guide de Dépannage ............................................................ 9
Pièces de rechange .............................................................. 12
Merci d’avoir choisi Kallista
Merci d’avoir choisi Kallista pour l’achat de votre baignoire à hydromassage. Votre nouvelle baignoire à
hydromassage Kallista reflète la dévotion de nos artisans, la qualité, et l’attention au détail.
Veuillez prendre quelques minutes et consulter votre Guide du Propriétaire avant d’utiliser votre baignoire à
hydromassage. Porter une attention toute particulière aux instructions d’Entretien et de Nettoyage de ce
guide.
Tous les renseignements contenus dans ce guide ont été revus et corrigés avant sa publication. Chez Kallista,
nous améliorons toujours nos produits. Nous nous réservons donc le droit d’apporter toutes modifications
aux caractéristiques, conditionnements et disponibilités des produits, et ceci à tout moment et sans préavis.
1019455-5-B Français-2 Kallista

Votre baignoire à hydromassage Kallista
Votre nouvelle baignoire à hydromassage vous relaxera, stimulera, revigorera et tonifiera votre corps. La
baignoire à hydromassage est composée des éléments suivants :
La baignoire - agit comme un réservoir d’eau, et permet l’action de massage.
Clavier de l’utilisateur - localisé à la porté de votre main, il vous permet d’arrêter ou de démarrer
le chauffage, et de régulariser le débit des jets des buses.
Moteur de la pompe - silencieux et à vitesses variables, il fournit l’alimentation en eau et crée
l’action de massage.
Les jets réglables - positionnés de manière stratégique pour créer un effet de massage optimal, ils
permettent d’ajuster le débit d’air et d’eau, ainsi que la direction du jet.
Chauffage - conçu pour aider à maintenir automatiquement la température de l’eau jusqu’à 104ºF
(40ºC) et pour améliorer votre expérience de bain à hydromassage. Le chauffage s’active
automatiquement lorsque la baignoire à jets d’air est en service, puis il s’éteint de lui même lorsque
le moteur de la pompe est arrêté. Le chauffage peut être arrêté par le clavier de commande et à tout
moment quand la pompe est en fonction.
Télécommande - ce contrôle peut être immergé ce qui vous permet de contrôler les fonctions de la
baignoire à hydromassage par l’intérieur ou l’extérieur de la baignoire.
Kallista Français-3 1019455-5-B

Clavier de l’utilisateur et modes/fonctions de la baignoire à hydromassage
Marche - Met les pompes de la baignoire à hydromassage en marche/arrêt.
Flèche vers le haut - Augmente le débit de l’eau.
Flèche vers le bas - Diminue le débit de l’eau.
Chauffage - Le chauffage s’active automatiquement lorsque la baignoire à hydromassage est mise en
service. Vous pouvez arrêtez le chauffage en appuyant sur le bouton du chauffage. Appuyer une
deuxième fois pour redémarrer le chauffage.
Barre d’indication - Elle indique le volume du débit de l’eau.
Fonctionnement de votre baignoire à hydromassage
Tourner la bague du jet dans le sens contraire des aiguilles d’une montre. Orienter le jet vers le fond
de la baignoire.
REMARQUE : La température de la baignoire à hydromassage ne doit pas excéder 104°F (40°C). Un
chauffage encastré aide à maintenir la température de l’eau automatiquement quand la baignoire à
hydromassage fonctionne, et tant que la température de l’eau ne dépasse pas 104°F (40°C). Le chauffage
s’arrêtera si la température est trop forte.
Remplir la baignoire à au moins 2″(5 cm) au-dessus de la buse la plus élevée. Tester la température
de l’eau avec la main pour votre confort, puis entrez dans la baignoire doucement.
Appuyer sur le bouton de marche pour démarrer votre baignoire à hydromassage. La baignoire à
hydromassage commencera à opérer avec un débit moyen. Le chauffage démarrera et son voyant
lumineux s’illuminera.
Augmenter ou diminuer le débit de l’eau en pressant sur les flèches du clavier. Une barre indicatrice
située au centre du clavier indique le volume du débit d’eau.
Ajuster les jets pour un mélange optimal d’eau et d’air. Tourner la bague du jet vers la droite pour
réduire le débit, ou vers la gauche pour l’augmenter. Orienter les jets vers les directions désirées et
pour optimiser l’action de votre baignoire à hydromassage.
Le chauffage s’active automatiquement lorsque la baignoire à hydromassage est mise en service.
Vous pouvez arrêtez le chauffage en appuyant sur le bouton du clavier. Appuyez une deuxième fois
pour redémarrer le chauffage.
Appuyer une deuxième fois pour arrêter la baignoire à hydromassage.
REMARQUE : Votre baignoire à hydromassage s’arrêtera automatiquement après environ 20 minutes de
fonctionnement. Vous pouvez redémarrer votre baignoire à hydromassage, si vous le désirez, en appuyant
sur le bouton de Marche.
Chauffage
Marche/Arrêt
Marche/Arrêt Réduit le Débit
Barre d'Indication -
Montrant le volume
du débit de l'eau
Augmente le Débit
Voyant Lumineux du
Chauffage
Clavier de l'Utilisateur Illuminé
Tourner la bague du jet vers la
droite pour diminuer le débit
de l'eau.
Tourner la bague du jet vers la
gauche pour augmenter le
débit de l'eau.
1019455-5-B Français-4 Kallista
Other manuals for P50035
1
Table of contents
Languages:
Other Kallista Bathtub manuals
Popular Bathtub manuals by other brands

Empava
Empava EMPV-67AIS10 manual

Mastella Design
Mastella Design AKI FREESTANDING installation instructions

banos 10
banos 10 b10 installation manual

Access
Access ROYALE Installation & operating instructions

Woodbridge
Woodbridge WB1028 Installation and care guide

A&E
A&E Italia Owner's manual and installation guide

STROMBERG
STROMBERG LAGO BTW Assembly & Operating Instruction

Kohler
Kohler Eternity K-1522-ET installation manual

American Standard
American Standard Heritage 6' Whirlpool 2806.018WC Specifications

VIGOUR
VIGOUR derby Installation and operating instructions

Kohler
Kohler K-892 Homeowner's guide

Kohler
Kohler Stargaze K-24019-GH manual
