Kam Lighting LED Powercan Tri 54w User manual

Kam LED Powercan Tri 54w Instruction manual version 1.0
Features
3 or 7-channel DMX-512 tri-color LED Parcan
3-channel: RGB control / 7-channel: RGB, macros, run speed, strobe, automatic/sound, dimmer
7 Solid colors setting on menu board without DMX controller
User Mode allows setting R, G, B intensity from control board
Built-in automated programs via master/slave or DMX with variable speed
Built-in sound activated programs via master/slave or DMX
Tri-color LEDs for superior color mixing
Control Board
The Control Board offers several features: you can run the internal programs or set the starting address.
Browse through the main menu by pressing MODE. You can change the selection by pressing UP or DOWN, confirm
by ENTER. The functions provided are described in the following sections.
Setting Solid Colors
Press the MODE button to select the solid color mode. When the display shows C, you can select the desired solid
color via the UP or DOWN buttons and confirm by ENTER(see following graphic).
Mode:
Value:
Function:
C
C1
Red
C2
Green
C3
Blue
C4
Cyan
C5
Magenta
C6
Yellow
C7
White
Internal Programs, Sound Control
Press the MODE button to select the internal program mode. When the display shows P, you can select the desired
internal program, with or without sound control, via the UP or DOWN buttons then confirm by ENTER (see below).
Mode
Value
Function
P
P1
Endless loop in 7 colors, change every 3 seconds
P2
Endless loop in 7 colors, fade every 3 seconds
P3
Endless loop in 3 colors, change every 3 seconds
P4
Endless loop in 3 colors, fade every 3 seconds
P5
Endless loop in 7 colors, via sound control
P6
Endless loop in 3 colors, via sound control
Setting the Sound Sensitivity:
You can do without a controller as the device features a built-in microphone, which provides automatic sound control.
You can adjust the sensitivity with the rotary-control on the rear panel.
User Mode
In User Mode you can set intensity of R, G, B separately to get endless color mixing from the control board without
DMX controller. Press Mode till you see U, press ENTER, you can see r***, so you can set intensity of red color from
100-0 (100%-0), to complete setting of red color, press ENTER, then display g***, set intensity of green in same way,
and then to b***, set intensity of blue in same way.
DMX Mode
The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from which the
unit will respond to the controller.
Addressing
Press the MODE button until the display shows D. You can now set the desired address via the UP or DOWN buttons

then press ENTER to confirm.
Setting the DMX Start Address:
Mode
Value
D
001- 512
Controlling:
After having addressed the unit you may now start operating it via your lighting controller
Choosing a DMX Channel Mode with 3 or 7 Channal occupation
The device has 2 DMX-modes. The Control Board allows you to assign the DMX-Mode.
Setting DMX Mode
After setting the desired address via the UP or DOWN buttons, press the MODE button again and the display shows
7ch. In case you would rather select the 3-channel mode, press the DOWN button in order to choose the 3ch setting.
DMX-protocol
7 Channel Mode:
CHANNEL
VALUE
FUNCTION
1
000- 255
Red ( 0 -100% )
2
000- 255
Green ( 0 -100% )
3
000- 255
Blue ( 0 -100% )
4
000- 015
No Function
016- 255
Color Macro
5
000- 015
No Function
016- 255
Strobe (CH.6 @000 –031,RGB mode only)
Slow ~ Fast
Speed (CH.6 @ values 32-223)
Slow ~ Fast
6
000 - 031
No Function
032 - 063
White Fading 0 –100%
064 - 095
White Fading 100% –0
096 - 127
White Fading 0 –100% –0
128 - 159
7 Colors Fading 0 –100%
160 - 191
3 Colors Chasing
192 - 223
7 Colors Chasing
224 - 255
Sound active
7
000- 255
Dimmer 0 –100%
3 Channel Mode
CHANNEL
VALUE
FUNCTION
1
000- 255
Red ( 0 -100% )
2
000- 255
Green ( 0 -100% )
3
000- 255
Blue ( 0 -100% )
Master/Slave operation
The master/slave operation enables that several devices can be synchronized and controlled by one master device.
Set Master device via LC Display Mode : “C –1 ~ 7”, or “P -- 1 ~ 6” , the Slave device DMX address “001”
Technical specifications
Power supply: 230 V AC, 50 Hz ~ / Power consumption: 80 W
Number of DMX channels: 7 / DMX-512 connection: 3-pin XLR
Sound-control: via built-in microphone
Maximum ambient temperature Ta: 45° C / Maximum housing temperature TB: 60° C
Min. distance from flammable surfaces: 0.5 m / Min. distance to lighted object: 0.1 m
Number of TCL 3W LEDs: 18 / Beam angle: 22°
Fuse: F 2 A, 250V
Dimensions (LxWxH): 410 x 290 x 390 mm / Weight: 3 kg
For the latest manual updates and information on the entire Kam range please visit:
www.kam.co.uk
Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, UK LU6 3EJ
Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400
Email: [e-mail] • Web: www.lambaplc.com
Due to continuous product development, specifications and appearance are subject to change.

If this product is ever no longer functional please it take to a recycling plant for environmentally friendly disposal.
