KAMEHA KA054 User manual

Connection instruction:
1）Connect HDMI input with HDMI output of source device.
2) Connect RJ45 port with RJ45 input port of HDMI extender RX.
3) Connect HDMI output of HDMI extender RX to HDMI input of HDTV
and set the TV source input to correct HDMI input channel.
4) Power on the device and it works.
8、 Specification
Specification
HDMI Signal HDMI 1.3，HDCP1.2
Input Port 8 x HDMI
Support Resolution 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz,
720p@50/60Hz,1080i@50/60Hz, 1080p@50/60Hz
Transmission
Distance
Up to 120meters transmission distance for 1080p full HD
over single CAT6
Working
Temperature 0℃～60℃
Item
Power supply
Power
Consumption
Dimension
Color
AC100-240V
483(L) x 240.5(W) x 133(H) mm
Black
Weight
Output Port 8 x RJ45
Transport Protocol HDbitT
8×8 HDbitT HDMI Matrix
User Manual
The product name and brand name may be registered trademark of related
manufacturers.TM and ® may be omitted on the user manual. The pictures
on the user manual are just for reference,and there may be some slight
difference with the real products.
We reserve the rights to make changes without further notice to a product
or system described herein to improve reliability, function or design.
Disclaimer

4、 Installation
1. Source device (like PS3, top box, PC etc. With HDMI output interface)
2、Display device (like TV, project etc. With HDMI input interface)
3、Receiver (HDMI extender receiver compatible with HDbitT transport protocol)
4、Cable (UTP/STP cat5/5e/6 cables comply according IEEE-568B, and the
suggested length of each type cable is:CAT5 80m, CAT5e 100m, CAT6 120m )
5、 Panel Instruction
5.1 Front Panel
1、LCD monitor : Display the input and output signal channel
2、Signal-channel Set buttons Guidelines for setting signal channel
with the buttons
----Function of the buttons
(1) “ALL” : For choosing all of the display devices which connect with
the 1-8 HDbitT outputs.
(2)“LOCK”: For locking the status of all buttons, the LED will light
on under the locking-status. Press it again for unlock
(2)“ENTER” : For confirming the channel setting
(3) ’1-8’number buttons: For choosing different connected source
device(INPUT) or display device(OUTPUT) in need. And the LCD will
show the number of the chosen signal channel
----Setting guidelines
LCD monitor
ALL
锁定按钮 ENTER
This product is HDbitT 8×8 HDMI matrix, supports 8 HDMI signal
input and 8 HDbitT signal output. All inputs and output with board
design, make the installation,operation and change inputs/outputs
very convenient for customer.This matrix with a LCD monitor, and
can extend signal up to 120 meters by cat6 network cable. It supports
IR remote control, RS232 control, ethernet control and button set
control. This matrix is perfect for exhibition center and digital
monitoring system, multimedia conference, school multimedia
education, etc.
Matrix user manual
3、 Package Contents
Power cable remote controller
2、 Features
5.2 Back Panel
1 2 3 4 5 6 7 8
INPU T
HDMI input board HDbitT output board
Ethernet cable port
Rs232 port
Power switch
Power cable
5.3 Remote Controller
ALL
12
3 4
56
7 8
OUTPUT
Enter
12
3 4
56
7 8
INPUT
2. Connection
1. Network cable
Follow the standard of IEEE-568B:
1- Orange/white 2- Orange 3- Green/white
4- Blue 5- Blue/white 6- Green
7- Brown/white 8- Brown
6、 Connection and Operation
HDMI MATRIX
RX (RECEIVER)
TV TV
HDMI MATRIX TX(SENDER)
DVD
TV TV TV TV TV TV
DVD
DVD
DVD
DVD
DVD
DVD
DVD
1 2 3 4 5 6 7 8
INP UT
1、 Product Introduction
1. Support 8 HDMI signal input and 8 HDbitT signal output
2. Extend 1080p@60Hz signal resolution up to 120 meters via CAT6 cable
3. Suppor t HDMI extender receivers which compatible with HDbitT
transport protocol
4. Support IR pass back
5. Support RS232 signal control
6. Support Ethernet control
7. Compliant to HDMI1.3 and HDCP1.2
8. Metal housing and mountable design
Example: Choose number 1 input signal displays on TVs of number
1 to 4 , and choose number 2 input signal displays on TVs of number 5 to 8
Follow the SETTING STEPS:
(1) Press number 1,2,3,4 in OUTPUT area in turn
(2) Press number 1 in INPUT area
(3) Press “ENTER”
(4) Press number 5,6,7,8 in OUTPUT area in turn
(5) Press number 2 in INPUT area
(6) Press “ENTER”
【NOTES】The setting becomes effective after pressing “ENTER” only
1-8’number buttons
’
On/Off
Menu
Right/Left/up/down
Back
This remote controller is used for choosing and setting the input and
output signal channel, button"ALL" is for choosing all of the output
signal channel, and button"ENTER" is for confirming the set
All Enter
