1 Copyright and disclaimer
Uponor has prepared this installation and operation manual and all
the content included solely for information purposes. The contents of
the manual (including graphics, logos, icons, text, and images) are
copyrighted and protected by worldwide copyright laws and treaty
provisions. You agree to comply with all copyright laws worldwide in
your use of the manual. Modification or use of any of the contents of
the manual for any other purpose is a violation of Uponor’s copyright,
trademark and other proprietary rights.
The presumption for the manual is that the safety measures have
been fully complied with and, further, that Uponor Combi Port E
system, including any components that are part of such system,
covered by the manual:
• is selected, planned and installed and put into operation by a
licensed and competent planner and installer in compliance with
current (at the time of installation) installation instructions
provided by Uponor as well as in compliance with all applicable
building and plumbing codes and other requirements and
guidelines;
• has not been (temporarily or continuously) exposed to
temperatures, pressure and/or voltages that exceed the limits
printed on the products or stated in any instructions supplied by
Uponor;
• remain in its originally installed location and is not repaired,
replaced or interfered with, without prior written consent of
Uponor;
• is connected to potable water supplies or compatible plumbing,
heating and/or cooling products approved or specified by
Uponor;
• is not connected to or used with non-Uponor products, parts or
components except for those approved or specified by Uponor;
and
• does not show evidence of tampering, mishandling, insufficient
maintenance, improper storage, neglect or accidental damage
before installation and being put into operation.
While Uponor has made efforts to ensure that the manual is accurate,
Uponor does not guarantee or warrant the accuracy of the
information contained herein. Uponor reserves the right to modify the
specifications and features described herein, or discontinue
manufacture of the Uponor products described at any time without
prior notice or obligation. The manual is provided “as is” without
warranties of any kind, either expressed or implied. The information
should be independently verified before using it in any manner.
To the fullest extent permissible, Uponor disclaims all
warranties, expressed or implied, including, but not limited to,
the implied warranties of merchantability, fitness for particular
purpose and non-infringement.
This disclaimer applies to, but is not limited to, the accuracy, reliability
or correctness of the manual.
Under no circumstances shall Uponor be liable for any indirect,
special, incidental or consequential damages or loss that result
from the use of or the inability to use the materials or
information in the manual, or any claim attributable to errors,
omission or other inaccuracies in the manual, even if Uponor
has been advised of the possibility of such damages.
This disclaimer and any provisions in the manual do not limit
any statutory rights of consumers.
Combi Port E D | Installation and operation manual | 3

2 Preface
This installation and operation manual describes how to install and
operate the components of the system.
The manual shows an example of a Combi Port E connection variant.
Information about other variations, as well as further technical data
can be found in the "Combi Port E Technical Information".
2.1 Safety instructions
Warnings used in this manual
The following symbols are used in Uponor documentation to indicate
special precautions when installing and operating any Uponor
equipment:
Warning!
Risk of injury. Ignoring warnings can cause injury or
damage components.
Caution!
Ignoring cautions can cause malfunctions.
Note
Important information to the section in the manual.
Power
Warning!
Risk of electric shock if touching the components! The
unit operates with a 230 V AC voltage.
Warning!
Risk of electrical shock! Electrical installation and service
behind secured 230 V AC covers must be carried out
under the supervision of a qualified electrician.
Warning!
The Uponor system uses 50 Hz, 230 V AC power. In
case of emergency, immediately disconnect the power.
Warning!
Prior to any work on the controller or the components
connected to it, switch off the controller according to the
regulations.
Technical constraints
Caution!
To avoid interference, keep installation/data cables away
from power cables of more than 50 V.
Safety measures
Conform to the following measures when installing and operating any
Uponor equipment:
• Read and follow the instructions in the installation and operation
manual.
• Installation must be performed by a competent person in
accordance with local regulations.
• It is prohibited to make changes or modifications not specified in
this manual.
• All power supplies must be switched off before starting any
wiring work.
• Do not use water to clean Uponor components.
• Do not expose the Uponor components to flammable vapours or
gases.
Uponor cannot accept any responsibility for damage or breakdown
that can result from ignoring these instructions.
2.2 Standards and regulations
Note
The installation must be carried out in accordance with
current local standards and regulations!
Planning and designing of the heating system must be performed
in accordance with applicable global and country-specific standards
and guidelines
• Ensure that no aggressive substances, such as acids, lubricants,
bleach, flux, strong liquid cleaning agents, contact sprays or
concrete including its components, come into contact with the
stainless steel manifold and manifold components.
• A water analysis is recommended for each installation. In the
event of warranty claims, it is mandatory. It is essential that the
heating circuits are regulated on the water side so that a
sufficient hydraulic function of the individual heating circuits or
the entire underfloor heating system is guaranteed!
For Combi Ports with an assembled water meter, planning and
implementation of the drinking water system must be done in
accordance with the Infection Protection Ordinance.
A few points to be high-lighted:
• Flush and disinfect the system before commissioning and
handing over to the user.
• Provide the domestic hot water pipes with required thermal
insulation strength.
• Insulate the drinking cold water pipes to secure that no heating
in excess of the requirements takes place.
2.3 Correct disposal of this
product (Waste Electrical and
Electronic equipment)
Note
Applicable in the European Union and other European
countries with separate collection systems
This marking shown on the product or its literature indicates
that it should not be disposed with other household wasted at the end
of its working life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate this
from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
4 | Combi Port E D | Installation and operation manual

Household users should contact either the retailer where they
purchased this product, or their local government office, for details of
where and how they can take this item for environmentally safe
recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product should not be mixed
with other commercial wastes of disposal.
Combi Port E D | Installation and operation manual | 5

3 System description Combi Port E D
3.1 Operating principle
Combi Port E D is available in two different versions:
1. Combi Port E D-UFH, for domestic water and direct heating.
This can be used in single or multi family houses.
2. Combi Port E D-X, for domestic water and indirect heating
(additional heat exchanger on the heating side). These are
intended for single family houses.
Direct heating, single or multi family houses
SD0000032
Indirect heating, single family house
SD0000062
3.2 Components
Note
The following illustrations show example set-ups for all
units. Individual modules may vary in appearances.
Combi Port E D consists of many individual components which are
described below. The unit can also be equipped with accessories like
heat meters and components from the Uponor room temperature
control system, both wired and as a flexible and convenient radio
solution.
Combi Port E D-UFH
CD0000365
PQ
LMNO
C
D
B
A
H
E
G
J
I
K
G
F
G
D
Item Description
A Venting screw
B Motor valve
C Differential pressure regulator
D Back flow preventer
E Heat meter distance piece
F Heating pump
G Strainer
H Combi Port E controller
I Domestic water heat exchanger
J Water hammer arrester
K Connection point for circulation line
L Heating supply (primary)
M Heating return (primary)
N Heating supply (secondary)
O Heating return (secondary)
P Domestic hot water to apartment (DHW)
Q Cold water from riser (CW)
6 | Combi Port E D | Installation and operation manual

Combi Port E D-X
CD0000366
C
B
A
H
G
L
I
M
G
FG
ST
OQR
J
E
K
A
N
D
P
Item Description
A Venting screw
B Motor valve
C Differential pressure regulator
D Back flow preventer
E Heat meter distance piece
F Heating pump
G Strainer
H Combi Port E controller
I Domestic water heat exchanger
J Heating heat exchanger
K Expansion vessel
L Water hammer arrester
M Connection point for circulation line
N Draining and filling valve
O Heating supply (primary)
P Heating return (primary)
Q Heating supply (secondary)
R Heating return (secondary)
S Domestic hot water to apartment (DHW)
T Cold water from riser (CW)
3.3 Accessories
Uponor offers a variety of accessories for use with the standard
portfolio.
The following accessories are optional. Their use completes the
product portfolio. The application is described in more detail in the
following chapters.
Port Base and pipe connection set
CD0000367
Port Base is a station prepared for connetion to the heat interface unit
by using the available pipe connection set.
Port Base consists of following components:
• Underfloor heating manifold
• Tap water manifold
• Primary connection pipes
• Pump group with regulating 3-way valve
• Room temperature control unit connected to manifold via
actuators
• Assembled on brackets
Further information about Port Base is given in the relevant technical
information.
Circulation line
CD0000368
A circulation line can be connected to Combi Port E D on demand.
Installation of the circulation line is described in the section
Install the circulation line (optional), Page 12
Combi Port E D | Installation and operation manual | 7

Ball valve set
CD0000369
The ball valves set consists of a range of valves with flow direction
marks required for connecting the pipes and the heat interface unit.
Connection of the ball valve set is described in the section
Connect the ball valve set, Page 10
Room temperature control
Note
Thermostats and remote control modules are not part of
the Combi Port delivery. They must be ordered
separately.
Uponor Smatrix
CD0000271
Uponor Smatrix Wave Pulse
Uponor Smatrix Base Pulse
Uponor Smatrix Base PRO
Uponor Smatrix is a fully equipped range of components for room
temperature control, optionally via radio or wired. The unique auto-
balancing technology eliminates the need for manual balancing of the
loops. The smart system accurately determines and controls the
exact energy needed for an optimal room temperature. The result is
highly comfortable underfloor heating and cooling with reduced
energy consumption.
Room control functions
This list shows available functions for the different systems.
Basic Functions Wave
Pulse
Base
Pulse
Base PRO
Autobalancing ✓ ✓ ✓
Cooling function ✓ ✓ ✓
Modularity ✓ ✓ ✓
Installation and configuration
functions
Wave
Pulse
Base
Pulse
Base PRO
Installation wizard ✓ ✓
Offline configuration ✓ ✓
Over-the-air updates ✓ ✓
Third-party remote support ✓ ✓
Comfort function Wave
Pulse
Base
Pulse
Base PRO
Mobile app ✓ ✓
Smart notifications ✓ ✓
Trend visualization ✓ ✓ ✓
Multi home control ✓ ✓
Smart home integration ✓ ✓
Comfort settings ✓ ✓ ✓
ECO profiles ✓ ✓ ✓
Electrical underfloor heating
control
✓ ✓
Ventilation integration ✓ ✓
Fan coil integration ✓
Technical function Wave
Pulse
Base
Pulse
Base PRO
Uponor cloud services ✓ ✓
Data storage ✓ ✓ ✓
Pump management ✓ ✓ ✓
System diagnostics ✓ ✓ ✓
HP integration ✓
Room bypass ✓ ✓ ✓
Room check ✓
BMS integration ✓
SMS module ✓
Uponor Base flexiboard
CD0000270
Uponor Base flexiboard is a 230 V control that enables individual
room control for 6 or 8 rooms. There are also 2 variants with
integrated pump logic available. This switches the circulating pump
on or off as required and enables an energy-efficient operation.
8 | Combi Port E D | Installation and operation manual

4 Installation
4.1 Installation example
D
E
SD0000063
B
C
A
F
Item Description
A Combi Port E D
B Room temperature controller
C Port Base
D Heating supply (primary)
E Heating return (primary)
F Cold water from riser (CW)
The above installation example shows a typical installation with
Combi Port E with tap water and underfloor heating manifolds.
A Uponor Smatrix controller for room temperature control is mounted
and connected to the manifold.
4.2 Heat interface unit view
Note
The insulation should never be removed from the unit!
SI00000398
The illustrations in the following installation steps describe the
process with Combi port E D-UFH unless nothing else is mentioned.
The insulation mounted in the unit is removed in the illustrations only
to show all components and increase the understanding.
The installation of Combi Port E D-X is performed in the same way.
4.3 Heat interface unit with UFH
manifold
Install the wall bracket
Note
See the dimensional drawings for measurements. Pay
attention to the horizontal alignment.
Note
Consider the height from the floor surface to ensure that
there is space left for the installation of underfloor heating
manifold.
SI0000318
A
B
Item Description
A Plug (4 pcs)
B Hexagon bolt (4 pcs)
1. Mark the hole positions on the wall and drill holes using a 6 mm
drill.
2. Insert the plugs in the drilled holes.
3. Attach the wall bracket to the wall using the hexagon bolts.
Combi Port E D | Installation and operation manual | 9

Install the heat interface unit
SI0000319
C
A
B
Item Description
A Heat interface unit
B Hexagon nut (4 pcs)
C Fixed bolt (4 pcs)
1. Screw the heat interface unit to the wall bracket using the
hexagon bolts
Connect the ball valve set
Note
Check the flat gasket for damage.
SI0000320
A
Item Description
A Flat gasket
1. Place the flat seals on to the ball valves ¾" screw connection.
2. Tighten the ¾" swivel nuts.
Connect the primary supply pipes
Note
Install the pipes in accordance with planning
documentation.
Note
Ensure the use of supplied seals when connecting the
pipes!
Note
Ensure that pipe insulation and fixing is made in
accordance with EnEV.
SI0000321
1. Connect the supply pipes to the ball valves by using desired
fittings.
10 | Combi Port E D | Installation and operation manual

Connect the underfloor heating and tap water
pipes
Note
Install the pipes in accordance with planning
documentation.
Note
Ensure the use of supplied seals when connecting the
pipes!
Note
Ensure that pipe insulation and fixing is made in
accordance with EnEV.
2
1
1. Connect the tap water pipes to the tap water manifold by using
desired fittings.
2. Connect the underfloor heating pipes to the underfloor heating
manifold by using desired fittings.
Connect the compression fittings
SI0000324
12
1. Cut the pipe in required length.
2. Connect the pipe to the manifold with the compression fitting.
Install the room temperature control
Note
Visit the Uponor download centre for more information
regarding the installation and configuration of Uponor
Smatrix and Uponor Base flexiboard.
4.4 Heat interface unit with Port
Base
Install the heat interface unit
Install the wall bracket, heat interface unit and ball valve set by
following the same process as described in the section "Heat
interface unit with UFH manifold".
Install Port Base
Note
See the dimensional drawings for measurements. Pay
attention to the horizontal alignment.
SI0000325
1. Make the hole positions on the floor and drill holes.
2. Insert plugs in the drilled holes if necessary.
3. Screw the Port Base unit to the floor.
4. Connect Port Base and the heat interface unit by using the
supplied pipe connection set.
Combi Port E D | Installation and operation manual | 11

Connect the tap water and underfloor heating
pipes
Note
Install the pipes in accordance with planning
documentation.
Note
Ensure the use of supplied seals when connecting the
pipes!
Note
Ensure that pipe insulation and fixing is made in
accordance with EnEV.
SI0000323
2
1
1. Connect the tap water pipes to the tap water manifold by using
desired fittings.
2. Connect the underfloor heating pipes to the underfloor heating
manifold by using desired fittings.
Connect the compression fittings
SI0000324
12
1. Cut the pipe in required length.
2. Connect the pipe to the manifold with the compression fitting.
Install the circulation line (optional)
SI0000326
1. Connect the circulation line to the heat interface unit.
2. Connect the circulation pump to the power supply.
Note
Please read the installation manual from the pump
manufacturer.
12 | Combi Port E D | Installation and operation manual

5 Additional installation
5.1 Strainer
Caution!
Lock the unit and relieve the pressure before any work
with the strainer.
Note
To open the cold water/primary flow strainer, use internal
hexagon (6 mm).
CD0000389
The strainer collects dirt and its filter can be removed for inspection
and cleaning.
5.2 Differential pressure regulator
Note
Pay attention to the diagram "Differential pressure
regulator" in the chapter Technical data.
CD0000391
The differential pressure controller secures for constant pressure
difference in the system.
The setting is made by turning the spindle.
5.3 Combi Port E D-X
Expansion vessel
CD0000388
The heat interface unit Combi Port E D-X is equipped with an
expansion vessel.
The pre-set pressure is defined based on the calculated static height
from the expansion vessel to the highest point in the heating system.
DI0000023
The pressure in the vessel is pre-set to1.0 bar which normally fits
most systems.
Safety valve
Warning!
Never block the flushing pipe from the safety valve!
Note
Check the function of the safety valve at minimum once a
year.
The heat interface unit Combi Port E D-X is equipped with a safety
valve to protect the heating system from a rising pressure. The safety
valve is a part of the optional circulation line.
The opening pressure is pre-set to 3.0 bar.
Safety temperature limiter
The safety temperature limiter serves to limit the flow temperature of
the heating (secondary).
If the heating should be operated with a flow temperature higher than
58 °C, the safety temperature limiter must be disconnected in the
Combi Port E D | Installation and operation manual | 13

controller. At this connection, a bridge must be installed by an
electrician.
5.4 Other components/devices
Outdoor temperature sensor
SI0000327
A
B
A
Item Description
A Outdoor temperature sensor
The outdoor temperature sensor serves as an input signal and
ensures perfect heating control.
Install the outdoor sensor at least 2 meters above the ground, on a
north-facing wall, protected from direct sunlight. Ensure that it is not
located near openings that may effect its operation, such as doors,
windows, vents etc.
BUS master
The BUS master is used in multi-family houses with large number of
apartments. It enables the control of up to 128 heat interface units
with one external sensor.
Room thermostat connection set
The room thermostat connection set is used to connect an external
room thermostat. This ensures perfect heating control especially
when no outdoor sensor is installed.
The room temperature signal can also be activated via the individual
room control (Uponor Smatrix or Uponor Base flexiboard).
5.5 Filling, flushing and venting
Note
Switch off the pump before filling and venting the system!
SI0000329
A
B
Item Description
A Venting screw
B Draining and filling valve
The filling and draining valve on the primary heating can be used for
filling and flushing of the heating system.
Filling and flushing the system
1. Open the draining and filling valve (B).
2. Fill and flush the system with heating water.
Venting the system
1. Open the venting valve (A).
2. Vent the heat interface unit.
Filling the secondary side
Warning!
Never exceed 2.5 bar when filling the system!
1. The safety valve has a opening pressure at 3 bar. Pay attention
to the pressure gauge when filling the secondary side.
2. Stop filling the system when the pressure is between 1.5 and 2
bar depending on application.
3. Vent the secondary side.
4. If necessary, fill with more water until the pressure rises to 1.5–2
bar.
14 | Combi Port E D | Installation and operation manual

6 Operation
6.1 Hydraulic balancing on the
manifold
Warning!
The pressure in the valves can cause personal injury.
Caution!
Never turn the valves counter clockwise more than five
(5) turns. When the cap is completely unscrewed, the
valves will shoot out of the thread.
Note
Pay attention to the diagram "Hydraulic balancing on the
manifold" in the chapter Technical data.
CLOSE
OPEN
0.25 x
12
34
SI0000330
1. Remove the cap from the fill/flush valve on the return manifold
bar. Turn it around until the square connector is down.
2. Close the valve.
3. Open the regulation valve 0.25 x.
4. Adjust the regulation valve according to the design calculation.
5. Consider the planning documentation.
6.2 Constant pressure pump
control
Note
Please read the installation manual from the pump
manufacturer.
CD0000392
The Combi Port E unit has an injection circuit. A non-return valve is
mounted in the screw connection of the by-pass.
Constant values Δp-c
UPM3 15-50, 5 m (option)
DI0000021
H [m]
5
4
3
2
1
0
0.0 0.2 1.0
0.4 2.0
0.6 3.0 Q [m3/h]
P [kPa]
0.8 1.2 1.4 1.6 1.8 2.2 2.4 2.6 2.8
50
40
30
20
10
0
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 Q [l/s]
UPM3 15-70, 7 m
DI0000022
H [m]
5
4
3
2
1
0
0.0 0.2 1.0
0.4 2.0
0.6 3.0 Q [m3/h]
P [kPa]
0.8 1.2 1.4 1.6 1.8 2.2 2.4 2.6 2.8
50
40
30
20
10
0
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 Q [l/s]
3.2 3.4 3.6
1.0
60
70
6
7
Combi Port E D | Installation and operation manual | 15

Changing the pump settings
Note
It is recommended that the pump runs at constant
pressure when used for underfloor heating. The factory
setting of the pump is not set to constant pressure and
must therefore be changed
The pump (Grundfos UPM3) has to be set to the constant pressure
modus (Δp-c) to enable an optimal operation of the underfloor
heating system.
The settings are done on the pump house as described below.
Pump settings
Note
Leave the pump on the selected program. It goes back
into operation automatically and has saved the settings.
Enable
setting
Press
and
hold,
sec
Factory setting Underfloor
heating
constant
pressure
Step
4 2 x 1
4 3 x 2
4 4 x 3
Pump effect
EEI ≤ 0.20 Part 3 Value
Speed P1 [W]
Min. 2
Max. 33
Pump operation
Display view Operation settings
0 % ≼ P1 ≼ 25 %
25 % ≼ P1 ≼ 50 %
50 % ≼ P1 ≼ 75 %
75 % ≼ P1 ≼ 100 %
Pump alarms
Display view Alarm status
Blocked
Low voltage
Electrical fault
6.3 Combi Port E mobile
application
The Combi Port E controller has preset default settings and is only
operated via the app. Likewise, all settings for domestic water and
heating are made via the app.
Combi Port E app
PDF
SI0000301
1. Download the Combi Port E app. It is available both for iOS and
Android mobile devices.
2. Scan the QR code available on the Combi Port E controller.
3. Press the blue button in the middle of the Combi Port E
controller until it flashes. Continue in the App.
4. Helptexts and guidance is available in the app.
5. The app consists of three different user levels. Access is given
by activating the received code.
6. Fill in the code in menu "Settings".
7. Reconnect the controller to get the new level (push A, see
below).
App advantages
• Display with live update of values, e.g. flow, temperature etc
• Software updates available (customer service only)
• Daily evaluation directly to service
• Commissioning protocol (content of all set points and operating
modes)
App structure
Overview
CD0000321
Uponor Combi Port E
Standby
Hot water
Standby
Circulation
Standby
Supplier
Operation
Heating
System
Uponor Combi Port E
Standby
Hot water
Standby
Circulation
Standby
Supplier
Operation
Heating
System
Android iOS
C
D
E
F
G
Configuration
Settings
Special functions
B
A
B
16 | Combi Port E D | Installation and operation manual

Item Description
A Connection status
B Settings
C Hot water
D Circulation
E Supplier
F Heating
G System
A Connection status
CD0000322
A
Uponor Combi Port E
Uponor Combi Port E
Standby
Hot water
Standby
Circulation
Standby
Supplier
Operation
Heating
System
Android iOS
Not connected
Connection help
• Indication of successful connection
• Connection can be manually activated or deactivated
B Settings
Combi Port E
CD0000323
Uponor Combi Port E
Android iOS
B
Settings
Settings
Time and date
Automatically set the current time and date of the
controller when connecting.
Back
Background operation
Maintain connection when the application moves
into the background.
Does not work if the device is in energy-saving
mode!
Automatic reconnect
Connect when the application returns to the
foreground.
Polling interval
Interval in seconds in which displayed values are
updated. Increase value to consume less battery
charge.
Changes are applied when reconnecting.
1 s
Language
Time and date
Automatically set the current time and date of the
controller when connecting.
Background operation
Maintain connection when the application moves
into the background.
Does not work if the device is in energy-saving
mode!
Automatic reconnect
Connect when the application returns to the
foreground.
Polling interval
Interval in seconds in which displayed values are
updated. Increase value to consume less battery
charge.
Changes are applied when reconnecting.
1 s
Language
POSSIBLE SETTINGS
• Time/date
• Language
• Controller settings
• Load/save configuration
• Startup protocol
C Hot water
Combi Port E
CD0000324
Uponor Combi Port E
Android iOS
C
Hot water
Standby
Status
Hot water
No Comfort
Load detection
43.7°C
Hot water
11.3°C
Cold water
0 l/min
Hot water
CLOSING
Valve
0 kW
Power
Standby
Status
No Comfort
Load detection
43.7°C
Hot water
11.3°C
Cold water
0 l/min
Hot water
CLOSING
Valve
0 kW
Power
Back
POSSIBLE SETTINGS
• Hot water temperature
• Valve position
• Load detection
DISPLAYED VALUES
• Hot water temperature
• Hot water flow
• Cold water temperature
• Performance
D Circulation
Combi Port E
CD0000325
Uponor Combi Port E
Android iOS
D
Circulation
Standby
Status
Circulation
OFF
Permanent circulation
50°C
Supply setpoint
30°C
Return setpoint
0%
Pump
OFF
Tap recognition
11.3°C
Cold water
Standby
Status
OFF
Permanent circulation
50°C
Supply setpoint
30°C
Return setpoint
0%
Pump
OFF
Tap recognition
11.3°C
Cold water
Back
POSSIBLE SETTINGS
• Supply setpoint
• Return setpoint
• Follow-up time
• Permanent circulation
• Time program
DISPLAYED VALUES
• Pump status
Combi Port E D | Installation and operation manual | 17

E Supplier
Combi Port E
CD0000326
Uponor Combi Port E
Android iOS
E
Supplier
Standby
Status
Supplier
53.1°C
Supply
36.9°C
Return setpoint
0 l/h
Return flow
0 kW
Performance
50°C
Keep warm
Standby
Status
53.1°C
Supply
36.9°C
Return setpoint
0 l/h
Return flow
0 kW
Performance
50°C
Keep warm
Back
POSSIBLE SETTINGS
• Supply primary
• Return primary
• Keep warm temperature
DISPLAYED VALUES
• Flow primary
F Heating
Combi Port E
CD0000327
Uponor Combi Port E
Android iOS
F
Heating
Operation
Status
Heating
35.5°C
Supply
31.5°C
Return
35°C
Calculated setpoint
4°C
Outdoor sensor
STOP
Valve
Operation
Status
35.5°C
Supply
31.5°C
Return
35°C
Calculated setpoint
4°C
Outdoor sensor
STOP
Valve
Back
OFF
Room controller OFF
Room controller
POSSIBLE SETTINGS
• Operating mode
• Control mode
• Time program
• Heating curve (optional)
• ECO mode (heating)
DISPLAYED VALUES
• Supply secondary
• Return secondary
• Outdoor temperature (optional)
• Room temperature (optional)
• External input (optional)
G System
Combi Port E
CD0000328
Uponor Combi Port E
Android iOS
G
System
9
Controller type
System
-12
Software version
ON
Hot water
Mixed
Heating
ON
Circulation
ON
Outdoor sensor
OFF
Screed drying
9
Controller type
-12
Software version
ON
Hot water
Mixed
Heating
ON
Circulation
ON
Outdoor sensor
OFF
Screed drying
Back
POSSIBLE SETTINGS
• Module selection
• Screed drying program
• Start up, step by step
DISPLAYED VALUES
• Software version
• Controller type
6.4 Commissioning and hand over
1. Complete the acceptance/commissioning protocol via the App.
2. Hand over the documentation and protocol to the homeowner.
18 | Combi Port E D | Installation and operation manual

7 Maintenance
7.1 General information
Important information
To ensure the correct and safe operation of the system, this
information must be read and followed.
Following these instructions will help avoid hazards and downtime
and increase the reliability and life of the system.
Function and energy savings
The heat interface unit is a compact station that can operate in a
system with several units or as a supplement to an existing heating
system. It is assigned to a residential unit and is used to measure
and control central heating and heating of the water.
The heat interface unit combines:
• water heating in the flow system via a plate heat exchanger
(water heating is controlled without auxiliary energy)
• the metering of the energy consumption for central heating and
hot water and, as an option, the amount of cold water
• heating control in the apartment with hydraulic balancing and
energy saving by ECO-mode.
Hot water is only prepared when needed. Service water is not stored.
This is one of the most convenient ways to heat fresh water. This
enables dispensing of large amounts of hot water. Restrictions are
only imposed by the central heating.
Water heating
Caution!
All water pipes are filled and pressurised.
The cold water supply for the apartment is provided via the central
house connection and distribution line.
The heat interface unit is equipped with a central shut-off ball valve
for cold water (F). As an option there is a shut-off ball valve for
installation purposes.
All ball valves should be exercised (open-close) at regular intervals
(about once per month).
The ball valves (E) and (F) should only be closed for assembly/
disassembly reasons.
Water hygiene
Although the water system follows the flow principle, which is the
most hygienic method of water heating, the water pipes should
always be flushed if not used for a longer period.
The tapping duration should then be around 1-2 minutes. The water
must be allowed to run at least every 7 days for about 1-2 minutes.
7.2 Turning off heat interface unit
Note
If droplets of water are detected, call a qualified service
personnel.
Ball valves must be closed in the event of malfunctions. A visual
inspection is required every 3 to 6 months.
CD0000393
E F
ABC D
Item Description
A Heating supply (primary)
B Heating return (primary)
C Heating supply (secondary)
D Heating return (secondary)
E Domestic hot water to apartment (DHW)
F Cold water from riser (CW)
If the system is to be shut down for a longer period:
• Close ball valves A, B and F. Close the cold water tap.
• Protect the heating unit against frost.
• Let the hot water run for about 5 minutes at restart.
• Switch off the controller (pull out the plug, settings remain
saved).
Combi Port E D | Installation and operation manual | 19

8 Troubleshooting
8.1 Fault description
Fault description Cause Solution
Hot water function
Hot water temperature too low or volatile Central heating
Buffer temperature too low Buffer temperature must be 5-10 K above hot
water setpoint
Heating circuit pump type not supported The following pump type is supported: Grundfos
UMP3
Setting for heating circuit pump is not correct Heating circuit pump setting: Constant pressure
Pump performance too low Check the pump performance
Setting for heating circuit control is not correct Check the heating circuit control setting
Heating circuit control faulty Check the heating control function
Air trapped in buffer storage Vent buffer storage tank
Cold water pressure too low/too high Cold water pressure at unit: Min. 2 bar, Max. 4 bar
Insufficient differential pressure Clean the capillary of the differential pressure
control, and check that the differential pressure
control is working
Heat interface unit
Strainer in heating supply (primary) dirty Clean the strainer in the heating supply (primary)
Air in the system Vent the system
Insufficient heating volume flow passes through
the heat exchanger
Check the volume flow
Heat meter type not supported Use heat meter type with Qn 1.5 ultrasound
Insufficient heating volume flow Increase differential pressure
Heat exchanger dirty Clean the heat exchanger
Hot water temperature limiter setting is not
correct
Check setpoints via the App, in the display
"Hotwater"
Check the controller setting Check setpoints via the App, in the display "Hot
water"
Waiting time for hot water is too long Check the pump setting in the central heating
system
Pump setting: Constant pressure
The temperature setting in the controller is too
low
Increase the temperature setting via the App in the
display "Supply" or in the line
Noise generation
Noise generated in the station Insulation is not closed or not present Fully close the insulation cover
Heating function
Heating system does not heat up General
Supply temperature too low at the heat source Check the supply temperature at the heat source
Volumetric flow rate is too low Check the fittings in the device
Check the heat meter type The heat meter type must be Qn 1.5
Check the pump setting Pump setting: Constant pressure
Air trapped in buffer storage Vent the buffer storage tank
Air in the system Vent the system
Setting for room thermostat is not correct Check the setting at the room thermostat
Strainer is dirty Clean the strainer
Check the controller setting Check the setpoints via the App, in the display
"Heating"
Heating system does not heat up Underfloor heating controlled by setpoint values
Pump not connected Check the pump connection
Strainer is dirty Clean the strainer
Pump setting is not correct Check the pump setting
Setpoint is not correct Check the setpoints via the App, in the display
"Heating"
Underfloor heating, weather compensated
Controller setting is not correct Check the setting via the App, in the display
"Heating"
Outdoor sensor faulty Replace the outdoor sensor
20 | Combi Port E D | Installation and operation manual
