Kampmann Venkon Assembly instructions

Venkon
►Assembly, installation and operating instructions
Keep these instructions in a safe place for future use!
Issue08/22CA_US
SAP No.1374923

3
Table of contents
1 General ................................................................................................................................. 5
1.1 About these instructions ......................................................................................................................... 5
1.2 Explanation of Symbols........................................................................................................................... 5
2 Safety.................................................................................................................................... 6
2.1 Correct use.............................................................................................................................................. 6
2.2 Limits of operation and use .................................................................................................................... 7
2.3 Risk from electrocution!.......................................................................................................................... 8
2.4 Personnel requirements - Qualifications ................................................................................................. 9
2.5 Personal Protective Equipment ............................................................................................................... 9
3 Transport, storage and packaging........................................................................................ 10
3.1 General transport instructions ................................................................................................................ 10
3.2 Scope of delivery..................................................................................................................................... 10
3.3 Storage ................................................................................................................................................... 11
3.4 Packaging ............................................................................................................................................... 11
4 Technical data....................................................................................................................... 12
5 Construction and function .................................................................................................... 14
5.1 Overview................................................................................................................................................. 14
5.2 Brief description...................................................................................................................................... 14
5.3 Wear parts list......................................................................................................................................... 15
6 Installation and wiring.......................................................................................................... 16
6.1 Definition of the connection side ............................................................................................................ 16
6.2 Requirements governing the installation site.......................................................................................... 17
6.3 Minimum clearances............................................................................................................................... 18
6.4 Installation.............................................................................................................................................. 19
6.4.1 Installation of basic unit............................................................................................................................ 20
6.4.2 Installation of casing ................................................................................................................................. 22
6.4.3 Installing the sheet steel accessories......................................................................................................... 25
6.5 Installation.............................................................................................................................................. 29
6.5.1 Connection to the pipe network................................................................................................................ 30
6.5.2 Sealing the pipework to the valve condensation tray................................................................................ 31
6.5.3 Overview of valve kits ............................................................................................................................... 33
6.5.4 Connection of 2-way valve kit................................................................................................................... 34
6.5.5 Connection of 3-way valve kit................................................................................................................... 35
6.5.6 Connection of differential pressure-dependent valve kit ........................................................................... 36
6.5.7 Connection, on-site pipework ................................................................................................................... 37

4
6.5.8 Condensation connection.......................................................................................................................... 37
7 Electrical wiring .................................................................................................................... 40
7.1 Maximum electrical rating values ........................................................................................................... 40
7.2 Electromechanical control, Venkon EC.................................................................................................... 41
7.2.1 Connection (U02M), Venkon EC................................................................................................................ 41
8 Pre-commissioning checks.................................................................................................... 42
9 Maintenance ......................................................................................................................... 44
9.1 Securing against reconnection................................................................................................................ 44
9.2 Maintenance Schedule:........................................................................................................................... 44
9.3 Maintenance work.................................................................................................................................. 45
9.3.1 Replacing the filter. ................................................................................................................................... 45
9.3.2 Visual checks............................................................................................................................................. 45
9.3.3 Cleaning the main condensation tray........................................................................................................ 47
9.3.4 Cleaning the valve condensation tray ....................................................................................................... 48
9.3.5 Cleaning the float switch .......................................................................................................................... 48
9.3.6 Clean the inside of the unit ....................................................................................................................... 49
10 Faults .................................................................................................................................... 50
10.1 Fault table............................................................................................................................................... 50
10.2 Start-up after rectification of fault .......................................................................................................... 51
11 Certificates............................................................................................................................ 52
11.1 Intertek Zertifikat Venkon.pdf................................................................................................................. 53
Table ..................................................................................................................................... 54

Venkon
Assembly, installation and operating instructions
5
1 General
1.1 About these instructions
These instructions ensure the safe and efficient handling of this equipment. These instructions form an integral part of the
equipment and have to be kept in the direct vicinity of the equipment and available to personnel at all times.
All personnel must have carefully read through these instructions prior to commencing all work on the equipment. A funda-
mental prerequisite for safe working is compliance with all the stated safety instructions and other instructions contained in
this manual.
In addition all local occupational health and safety at work regulations apply, as do general safety provisions governing the
use of the equipment.
Illustrations in this guide are intended to provide a basic understanding and may differ from the actual model.
Ongoing tests and further developments may result in small variations between the unit supplied and the instructions.
1.2 Explanation of Symbols
DANGER!
This combination of symbol and signal word indicates an immediately dangerous situation caused by elec-
trical power, which will cause death or serious injury if not avoided.
WARNING!
This combination of symbol and signal word indicates a possible hazardous situation.
IMPORTANT NOTE!
It represents a potentially hazardous situation, which could lead to damage to property or for a measure to
optimise workflows.
IMPORTANT NOTE!
This symbol highlights useful hints, recommendations and information for efficient and trouble-free opera-
tion.

Venkon
Assembly, installation and operating instructions
6
2 Safety
This section provides an overview of all important safety aspects to ensure optimum protection of personnel as well as safe
and trouble-free operation. In addition to the safety instructions in these operating instructions, the valid safety, accident pre-
vention and environmental protection regulations must be observed for the area of use of the unit. It is the duty of the oper-
ator to ensure that instructions relating to maintenance (e.g. relating to hygiene) are complied with.
2.1 Correct use
The units are only intended to be used for heating and cooling air in frost-free and dry rooms. Within the room, the unit
needs to be connected to the building's heating/cooling/ventilation system and to the building's waste water and power net-
work. The operating limits and limits of use described in Chapter 2.2 [}7] must be complied with.
IMPORTANT NOTE!
Only use the unique after completion of the complete building and system. Site heating is not deemed to be
correct and proper use.
Intended use of the unit also includes adherence to these instructions.
Information in accordance with EN60335-1
This unit can be used by children aged 8 years or more and also by people with reduced physical, sensory or mental cap-
abilities or a lack of experience and knowledge, if they are supervised or have been instructed in the safe use of the unit
and the resulting dangers. Do not allow children to play with the unit. Do not allow children to clean and maintain the
unit without supervision.
The unit is not intended for operation above 2,000 m.a. s.l.
This unit is not intended for permanent connection to the drinking water supply system.
This unit is intended for being accessible to the general public.
Any use beyond or other than the stated intended use is considered as misuse.
Any change to the unit or use of non-original spare parts will cause the expiry of the warranty and the manufacturer’s liabil-
ity.

Venkon
Assembly, installation and operating instructions
7
2.2 Limits of operation and use
Limits of operation
Min./max. water temperature °C/°F 40-90 / 104-194
Min./max. air intake temperature °C/°F 6-40 / 43-104
Min./max. air humidity % 15-75
Min. operating pressure bar/kPa -
Max. operating pressure bar/kPa/psi 10/1000/145
Min./max. glycol percentage % 25-50
Tab.1: Limits of operation
Operating voltage 115 V/ 60 Hz
Power/Current consumption On the type plate
Tab.2: Operating voltage
We would refer to VDI-2035 Sheets 1 & 2, DIN EN 14336 and DIN EN 14868 with regard to the properties of the medium
used to protect the equipment. The following values provide further guidance.
The water used should be free of contamination, such as suspended substances and reactive substances.
Water quality
pH value (at 20 °C / 68°F) 8-9
Conductivity (at 20 °C / 68°F)) μS/cm / ppm <700 / <350
Oxygen content (O2) mg/l / (lb/gal) <0.1 / (<0.00000083)
Hardness °dH / ppm CaCO34-8.5 / 0.224-0.476
Sulphur ions nicht messbar
Sodium ions (Na+) mg/l / (lb/gal) <100 / (<0.00083)
Iron ions (Fe2+) mg/l / (lb/gal) <0.1 / (<0.00000083)
Manganese ions (Mn2+) mg/l / (lb/gal) <0.05 / (<0.000000415)
Ammonia ions (NH4+) mg/l / (lb/gal) <0.1 / (<0.00000083)
Chlorine ions (CI) mg/l / (lb/gal) <100 / (<0.00083)
CO2<50
Sulfate ions (SO4
2-) mg/l / (lb/gal) <50 / (<0.000415)
Nitrite ions (NO2-) mg/l / (lb/gal) <50 / (<0.000415)
Nitrate ions (NO3-) mg/l / (lb/gal) <50 / (<0.000415)
Tab.3: Water quality

Venkon
Assembly, installation and operating instructions
8
IMPORTANT NOTE!
Danger of frost in cooling mode!
There is a risk of the heat exchanger freezing when used in unheated rooms.
Make sure that the unit is equipped with a frost protection sensor and/or thermostat in this case.
IMPORTANT NOTE!
Warning of misuse!
In the event of misuse, as itemised below, there is a danger of limited or failing operation of the unit. En-
sure that the airflow can circulate freely.
Never operate the unit in humid areas, such as swimming pools, wet areas etc.
Never operate the unit in rooms with an explosive atmosphere.
Never operate the unit in aggressive or corrosive atmospheres (e.g. sea air).
Never operate the unit above electrical equipment (such as switch cabinets, computers or other electrical
units, or contacts that are not drip-proof).
IMPORTANT NOTE!
Energy losses due to misuse!
Operating the unit with open windows (or other room openings) can result in significant energy losses.
Heating and cooling modes (particularly when operating different units) need to be coordinated with
each other.
2.3 Risk from electrocution!
DANGER!
Risk of fatal injury from electrocution!
Contact with live parts will lead to fatal injury from electrocution. Damage to the insulation or individual
components can lead to a fatal injury.
Only permit qualified electricians to work on the electrics.
Immediately disconnect the system and repair it in the event of damage to the insulation.
Keep live parts away from moisture. This can cause a short circuit.
Properly earth the unit.

Venkon
Assembly, installation and operating instructions
9
2.4 Personnel requirements - Qualifications
Specialist knowledge
The installation of this product requires specialist knowledge of heating, cooling, ventilation, installation and electrical engin-
eering. This knowledge, generally learned in vocational training in one of the fields mentioned above, is not described separ-
ately.
Damage caused by improper installation is the responsibility of the operator or installer. The installer of these units should
have adequate knowledge of the following gained from specialist vocational training
Safety and accident prevention regulations
Guidelines and recognised technical regulations, i.e. Association of German Electricians (VDE) regulations, DIN and EN
standards.
VDI 6022; Maintenance personnel must be trained to Category B (possibly Category C) to comply with hygiene require-
ments (if necessary).
The installation, operation and maintenance of this unit must comply with the applicable laws, standards, provisions and reg-
ulations in the respective country and the current state of the art!
2.5 Personal Protective Equipment
Personal protective equipment is used to protect people from impaired safety and health when working with the unit. The ap-
plicable accident prevention regulations at the place of use apply in all cases.
Personnel have to wear personal protective equipment during maintenance and troubleshooting on and with the unit.

Venkon
Assembly, installation and operating instructions
10
3 Transport, storage and packaging
3.1 General transport instructions
Check on delivery for completeness and transport damage.
Proceed as follows in the event of visible damage:
Do not accept delivery or only accept with reservations.
Record any transport damage on the transportation documents or on the transport company's delivery note.
Submit a complaint to the freight forwarder.
IMPORTANT NOTE!
Warranty claims can only be made within the applicable period for complaints. (More information is avail-
able in the T&Cs on the Kampmann website)
IMPORTANT NOTE!
2 people are needed to transport the unit. Wear personal protective clothing when transporting the unit.
Only lift the unit on both sides and not by the pipes / valves.
IMPORTANT NOTE!
Material damage caused by incorrect transport!
Units being transported can drop or topple over if transported wrongly. This can cause serious material
damage.
Proceed carefully when unloading the equipment on delivery and when transporting it on site and note
the symbols and instructions on the packaging.
Only use the holding points provided.
Only remove packaging shortly before assembling the unit
3.2 Scope of delivery
IMPORTANT NOTE!
Check the scope of delivery!
Check the delivery for damage.
Check that the articles and type numbers are correct.
Is the delivery and number of items delivered correct?

Venkon
Assembly, installation and operating instructions
11
3.3 Storage
Store packaging under the following conditions:
Do not store outdoors.
Store in a dry and dust-free place.
Store in a frost-free place.
Do not expose to aggressive media.
Protect from direct sunlight.
Avoid mechanical vibrations and shocks.
IMPORTANT NOTE!
Under certain circumstances, packages can carry storage instructions that go beyond the requirements listed
here. Comply with these instructions accordingly.
3.4 Packaging
Handling packaging materials
IMPORTANT NOTE!
Dispose of packaging materials in line with the applicable statutory requirements and local regulations.
IMPORTANT NOTE!
The packaging is also use to protect the product from site dust and dirt. Only remove packaging shortly be-
fore assembling the unit

Venkon
Assembly, installation and operating instructions
12
4 Technical data
Unit Venkon EC
Unit Venkon EC
Model 61 63 66 67
1at LPHW 75 / 65°C, tL1 = 20°C
2at CHW 7/12°C, tL1=27°C, rel. humidity 50%
3at LPHW 120 / 100°F, tL1 =68°F
4at CPW 45/55 °F, tL1 = 75°F rel. humidity 50%
Model 61 63 66 67
Length of basic unit [mm] 625 925 1375 1725
Casing length [mm] 900 1200 1650 2000
Weight of basic unit [kg] 19 24.5 36.5 46.5
Air volume [l/s] 50 – 215 65 – 275 115 – 480 130 – 545
Internal volume of 2-pipe
system [l] 1.3 2.0 3.1 3.9
Internal volume of 4-pipe
system [l] heating 0.5 0.6 0.9 1.1
Internal volume of 4-pipe
system [l] cooling 1.0 1.6 2.4 2.9
MCA [A] 1.25 1.50 2.75 3.25
MOP [A] 15 15 15 15
Heat output [kW] 12.8 – 11.2 3.4 – 14.7 5.9 – 24.9 7.2 – 29.9
Cooling output [kW] 21.2 – 4.0 1.4 – 5.7 2.5 – 9.6 3.1 – 12.2
Sound power level [dB(A)] 35 – 68 29 – 60 36 – 69 32 – 63
Length of basic unit [inch] 24.6 36.4 54.1 69.9
Casing length [inch] 35.4 47.2 65 78.7
Weight of basic unit
[pound] 41.9 54 80.5 102.5
Air volume [cfm] 110-455 135-580 240-1020 275-1150
Internal volume of 2-pipe
system [US gal.] 0.29 0.30 0.31 0.32
Internal volume of 4-pipe
system [l] heating [US gal.] 0.29 0.30 0.31 0.32
Internal volume of 4-pipe
system [l] cooling [US gal.] 0.29 0.30 0.31 0.32
MCA [A] 1.25 1.50 2.75 3.25
MOP [A] 15 15 15 15
Heat output [MBH] 34.6-14.4 5.8-20.8 9.9-34.3 12.1-42.9
Cooling output [MBH] 43.1-8.3 3.6-12.7 6.4-21.1 7.7-27.5
Sound power level [dB(A)] 35-68 29-60 36-69 32-63

Venkon
Assembly, installation and operating instructions
13
typeplate sample model 61
Type 14861DUL210U02M
Voltage 115 V / 60 Hz
Amperage 1.0 A
Power 65 W
Max. operating pressure 10 psi
Max. operating temperature 90 °C/ 194 °F
Max. ambient temperature 40 °C/ 104 °F
Protection class IP 20
MCA 1,25 A
MOP 15 A
Serial no. KSN2100332343318
Article no. 14861DUL210U02M
ID 1162899
Kampmann GmbH& Co. KG / Friedrich-Ebert-Str. 128-130 / 49811 Lingen (Ems) / Germany
Tab.4: Fan Coil Venkon EC

Venkon
Assembly, installation and operating instructions
14
5 Construction and function
5.1 Overview
1
2
34
5
6
7
89
10
11
12
13
14
Fig.1: Venkon at a glance (example of ceiling model)
1Condensation pump 8AC or EC fan
2Pipework 9Condensation tray
3Valve condensation tray 10 Control in the electrical housing (e.g. C1 control)
4Water connections 11 Heat exchanger
5Actuator 12 Casing
6Float switch 13 Intake air grille
7Filter 14 Air outlet grille
5.2 Brief description
Venkons are decentralised units for heating, cooling and filtering air, for use in hotels, offices and business premises, among
others. Secondary air is drawn in filtered by the fan and passed through the copper/aluminium heat exchanger. Here the air is
either heated or cooling depending on the temperature of the water in the heat exchanger. The heated or cooled air is dis-
charged into the room through the air outlet grille.

Venkon
Assembly, installation and operating instructions
15
5.3 Wear parts list
Figure Article Properties Suitable for Art. no.
Replacement filter
with frame 1 no. Venkon AC and EC
Model 61: 14869BBB0101
Model 63: 14869BBB0301
Model 66: 14869BBB0601
Model 67: 14869BBB0701
Spare filter eP-
M10>50% (M5) 1 no. Venkon AC and EC
Model 61: 14869BBB0105
Model 63: 14869BBB0305
Model 66: 14869BBB0605
Model 67: 14869BBB0705
Spare filter eP-
M1>50% (F7) 1 no. Venkon AC and EC
Model 61: 14869BBB0107
Model 63: 14869BBB0307
Model 66: 14869BBB0607
Model 67: 14869BBB0707

Venkon
Assembly, installation and operating instructions
16
6 Installation and wiring
6.1 Definition of the connection side
Example of ceiling installation, connection on left
Example of ceiling installation, connection on right
Fig.2: Ceiling-mounted, connection on left and right
Example of wall installation, connection on left
Example of wall installation, connection on right
Fig.3: Wall-mounted, connection on left and right

Venkon
Assembly, installation and operating instructions
17
6.2 Requirements governing the installation site
Only install and assemble the unit if the following conditions are met:
Make sure that the wall/ceiling is sufficiently load-bearing to take the weight of the unit (Technical data [}12]).
Make sure that the ceiling is sufficiently load-bearing to take the weight of the unit (Technical data [}12]).
Make sure that the unit is securely suspended/standing.
Ensure that the airflow can circulate freely.
Provide adequate space for flow and return water connections on site (Connection to the pipe network [}30]).
There is a power supply on site (Maximum electrical rating values [}40]).
If need be, provide a condensation connection with a sufficient gradient on site.

Venkon
Assembly, installation and operating instructions
18
6.3 Minimum clearances
Air outlet area*
Air outlet area*
Example of basic unit, wall-hanging (without casing)
Example of unit, wall-hanging with casing
Example of basic unit, ceiling (without casing)
Example of unit, ceiling-mounted with casing
6.5
3.9
3.9
6.5
1 1
11
6.5
3.9
6.5
3.9
3.9
3.9
*The air outlet area needs to be
completely barrier-free to guarantee
the free circulation of air! There
needs to be a 50 mm freely
accessible clearance above the casing
to be able to remove the casing.
Fig.4: Minimum clearances

Venkon
Assembly, installation and operating instructions
19
6.4 Installation
2 people are needed to install the unit.
CAUTION!
Risk of injury from sharp metal housing!
The inner metal of the casing can have sharp edges.
Wear suitable protective gloves.
IMPORTANT NOTE!
Horizontal installation of units!
When installing the units, ensure that they are completely horizontal to ensure proper operation.
IMPORTANT NOTE!
Avoid draughts!
Consider the occupied zone when installing/suspending the units. Do not expose people to the direct air
flow. Position the unit accordingly and adjust the air outlet if required.

Venkon
Assembly, installation and operating instructions
20
6.4.1 Installation of basic unit
Example of basic unit EC, wall-mounted version, 4-pipe
Example of basic unit EC, ceiling-mounted version, 2-pipe
Keyhole detail
Keyhole detail
Dimensions in brackets = model with cassette filter ePM10>50% (M5) / ePM1> 50% (F7)
Dimensions in brackets = model with cassette filter ePM10>50% (M5) / ePM1> 50% (F7)
0.8
0.6 0.6
0.9 8.8
17.3
8.8
3.5
4
1.3
3.9
1.3 (2.3)
19.4 (20.4)
19.4 (20.4)
8.8
3.5
4
1.3
0.817.31.3 (2.3)
19.4 (20.4)
8.8
3.9
0.60.6
0.9
19.4 (20.4)
0.3
0.8
1.2
0.6
0.3
0.8
1.2
0.6
Fig.5: Suspension points for basic unit
