K&S KS 2900 User manual

Gasoline generator
Dual fuel generator
K
S
&
Könner
K
S
&
&
S
ö
hnen
Instruction
Please, read this manual
before use!
ENG
KS 2900
KS 3000
KS 3000E
KS 7000
KS 7000E
KS 7000E-3
KS 7000E ATS
KS 2900G
KS 3000G
KS 3900E G
KS 5000E G
KS 7000E-3 ATS
KS 7000E 1/3
KS 10000E 1/3
KS 10000E
KS 10000E-3
KS 10000E ATS
KS 10000E-3 ATS
KS 7000E G
KS 9000E G
KS 10000E G

1
CONTENTS
1. INTRODUCTION 2
2. SAFETY INFORMATION 2
2.1. Working area 2
2.2. Electrical safety 3
2.3. Personal safety 3
2.4. Precautions when working with gasoline generator 4
2.5. Precautions when working with hybrid generator 4
3. SAFETY SYMBOLS DECRYPTION 6
3.1. Symbols description when working with generator 6
3.2. Safety symbols description when working with accumulator 6
4. DESCRIPTION OF GENERATOR INSCRIPTION 7
5. MAIN OVERVIEW 8
6. DUAL FUEL GENERATOR OVERVIEW 9
7. COMPONENTS OF SET 9
8. MODELS DESCRIPTION 10
9. CONTROL PANEL TYPES 17
9.1. Generator panel 17
9.2. Generator panel for models
KS 7000E ATS, KS 7000E-3 ATS, KS 10000E ATS, KS 10000E-3 ATS 17
9.3. Generator panel for models
KS 7000E 1/3, KS 10000E 1/3 17
10. Digital display of gasoline generators 19
11. COMMISSIONING 19
12. BEFORE STARTING 20
12.1. Check the fuel level 20
12.2. Check the oil level 20
13. CONNECTION OF GENERATORWITH BUILT-IN ATS 21
13.1. Scheme of connection of a single-phase generator 21
13.2. Connection scheme of the three-phase generator 21
14. ENGINE START 22
14.1. Gasoline generator engine start 22
14.2. Running generator on liqueed gas 23
14.3. Generator launch in ATS mode (for generators with ATS) 24
15. STOPPING THE ENGINE 25
15.1. To stop gasoline generator engine 25
15.2. To stop hybrid generator engine 25
16. TECHNICAL MAINTENANCE WORKS 25
17. MAINTENANCE SCHEDULE 26
18. RECOMMENDED OILS 27
19. AIR FILTER TECHNICAL MAINTENANCE 28
20. SPARK PLUGSTECHNICAL MAINTENANCE 28
21. BATTERY USE 29
22. STORAGE 29
23. GENERATOR TRANSPORTATION 30
24. POSSIBLE FAILURES AND SOLUTIONS 30
25. AVERAGE POWER USAGE 31
26. WARRANTY SERVICE TERMS 32
27. BATTERY AND GENERATOR DISPOSAL 32

2
1. INTRODUCTION
We are grateful to you for your purchase of  Könner & Söhnen series
gasoline
powered generator. This manual contains safe working recommendations,
operation and adjustment description of these generators and maintenance
instructions.
Manufacturer reserves the right to make alterations into the generators, which
may not be reected in this manual. Pictures and photos of the product may
vary from its actual appearance. At the end of this manual, You may nd contact
information which you are free to use in case of any issues occurrence.
All data, specied in this operation manual is the most up to date for the moment
of its publishing.The current list of service centers you can nd at the website of
ocial importer: www.ks-power.de/en
In order to provide equipment integrity and avoid any possible
injuries we strongly recommend You to carefully read this manual
before operating the generator.
ABBREVIATIONS MEANING:
KS Generator model
 Electro start
G Dual fuel type (LPG/gasoline)
ATS Automatic transfer switch
Read carefully these instructions. Pay special attention to information that
begins with these characters / words:
Failure to follow the recommendations marked with this sign may
lead to serious injury or death of the operator or third parties.
Useful information while operating the machine.
2. SAFETY INFORMATION
2.1. WORKING AREA
- As exhaust gases contain poisonous carbon dioxide (CO2) and carbon monoxide
(CO) gases which are dangerous for life, it is strictly forbidden to install the
generator in residential buildings, premises connected to residential buildings
by a common ventilation system, other rooms from which exhaust gases may
enter living premises.
- Do not use generator in the rain, snow and high humidity conditions, do not
touch the generator with wet hands. It’s prohibited to leave it in direct sunlight
in summer for a long time. It is recommended to store and use the generatir
under a canopy or in a well ventilated area.
! !
ATTENTION - DANGER!
! !
ATTENTION - DANGER!
! !
IMPORTANT!

3
- Please set the generator on a at hard horizontal surface. To reduce vibration
during operation and to avoid damage to the surface, where the generator is
installed, it is equipped with dampers.
- Please don’t use the generator near ammable gases, liquids or dust. When
using the generator exhaust system gets very hot. This may cause re or
explosion of these materials.
- Be sure to follow cleanliness and good lighting in the work area. Clutter and
poor lighting may cause an injury.
- Do not let the presence of unauthorized persons, children or animals when
working with generator. If necessary, make sure to fencing the working area.
- Please use safety shoes and protective gloves when working with generator.
2.2. ELECTRICAL SAFETY
- The generator produces electricity that may lead to an electric shock while
neglecting compliance regulations.
- In the high humidity level conditions generator exploit is prohibited. Keep the
generator in a dry place only.
- Avoid direct contact with grounded surfaces (pipes, radiators, etc.).
- Do not allow moisture in the generator. The water inside the device increases
the risk of an electric shock.
- Be careful when working with power cables. Immediately replace it in case of
damage, as damaged wire increases the risk of electric shock.
- All connecting the generator to the network must be made by certied
electrician in accordance with all electrical rules and regulations.
- Connect the generator to the protective ground before operation.
- Do not connect or disconnect a generator to electricity consumers, which are
placed in water on a wet or damp soil.
- Do not touch parts of the generator under voltage.
- Connect the generator to those customers only which meet the electrical
characteristics and the rated power of the generator.
- Store all electrical equipment dry and clean. Wires with damaged or spoiled
insulation should be replaced. You should also replace worn, damaged or rusty
contacts.
2.3. PERSONAL SAFETY
- Be careful. Do not operate the generator, if you are tired, under the inuence of
drugs or alcohol. Inattention may cause a serious injury.
- Do not wear loose clothing or jewelry when working. Long hair, jewelry or loose
clothing may get into the moving parts of the generator and cause an injury.
The device generates electricity. Follow safety precautions to avoid
electric shock.
! !
ATTENTION - DANGER!
! !
IMPORTANT!
Using device for other purposes deprives the right for free warranty.

4
! !
ATTENTION - DANGER!
Non compliance to these requirements may result in generator
combustion or explosion, as well as in electric wiring ignition inside
the structure.
-To avoid inhaling exhaust gas, the generator does not have to work in conditions
of poor ventilation. Exhaust gas contains poisonous carbon monoxide. Use and
maintenance of the generator.
- Before you start checks before operating, make sure that the generator is on a
at level surface and the engine switch is set to O.
- Keep the generator dry, well ventilated place if you are not using it.
- Check the connection of moving parts, no damaged parts that aect the
operation of the generator. If the generator is damaged, remove them before
using.
- For repair and maintenance use only recommended oil fuel. Using other
lubricants, spare parts and consumables deprives you of warranty apparatus.
- Labels and stickers on the generator and engine leave because they contain
important information.
- Servicing the generator should be carried out only by qualied personnel.
- When servicing the generator follow all instructions of this manual.
2.4. PRECAUTIONS WHEN WORKING WITH GASOLINE GENERATOR
- Do not start the generator operation upon presence of electric load. Disconnect
the load before you stop the engine.
- Generator installation is to be performed at minimum 1 meter safety distance
from ammable objects.
- Do not refuel the running generator.
- It is forbidden to smoke during generator refuelling operations.
- It is forbidden to run the generator during rainfall and in high-moisture level
conditions.
-The generator is to be mounted on at level surface to avoid petroleum leakage.
- Only unleaded gasoline is recommended for the generator. After lling the
tank, all excessive fuel spillage are to be removed from the surface. It is forbidden
to use kerosene or other fuel types.
- Observe the fuel tank relling. Do not allow overlling.
- All explosive and ammable materials or substances are to be kept away from
the generator, for its engine produces heat during operation.
- Avoid inadvertent start. Make sure to set the switch to O when you turn o
the generator.
- Make sure no outsider objects are on the generator when it is turned on. Do not
overload the generator, use it only for the purpose. Proper use of the generator
will do the job for which it is designed better and safer.
- Using device for other purposes deprives the right for free warranty. It is not
allowed to sit or stand on the generator.
- Always keep a stable position and balance when starting the generator.
- Use safety equipment. Always wear goggles, a mask, non-slip sole shoes,
protective helmet, headphones.

5
2.5. PRECAUTIONS WHEN WORKING WITH HYBRID GENERATOR
- You are allowed to connect all the power consuming supplies only after
generatorgotwarmedup.Ifyoustartgeneratorwith appliances beingconnected
the engine may work unstable due to the fuel remains in the carburetor.
- Disconnect the load before you stop the engine.
- Before usage make sure, that all the hoses are connected properly.
- In case of gas leakage, stop the gas ow from the source to generator and
switch o all the electric appliances connected as soon as possible.
- For stopping gas powered engine: disconnect all the connected devices rst,
then close the gas valve, then turn o the engine. After that set the starter
switch to OFF position and turn o the gas supply valve.
Do not allow sparks near gas powered generetor during its work
! !
ATTENTION - DANGER!
Fuel contaminates the land and groundwater. Do not allow the
leaking gasoline from the tank!
! !
ATTENTION - DANGER!
- It is forbidden to touch the exhaust system during the generator start and in
process of its running.
- It is forbidden to run the generator in cases when its exposure to rain, snow and
possibility of soakage exist. Do not touch the generator with moist hands
- Before running the generator, it is necessary to dene the place and means of
its emergency stop.

6
3.2. SAFETY SYMBOLS DESCRIPTION WHEN WORKING WITH ACCUMULATOR
pic 1
pic 2
pic 3
3. SAFETY SYMBOLS DECRYPTION
3.1. SYMBOLS DESCRIPTION WHEN WORKING WITH GENERATOR
a b c d
e f g h
a. Be careful when using the device! Follow
safety rules listed in manual.
b. Use the generator only in areas that
are well ventilated, or on open areas. The
exhaust gases contain CO2, which are
dangerous to life.
c. Do not use or store the device in high
humidity.
d. Do not smoke when using the
generator!
e. The device generates electricity. Follow
safety precautions to avoid electric shock.
f. Carefully read the manual before using
the device.
g. Do not touch the generator with wet or
dirty hands.
h. Follow re safety rules, do not use open
ames near the generator.
i. Please don’t touch! The muer heats up
when running the generator.
a b c
fed
a. Use protective rubber gloves while working
with battery. Battery contains acid electrolyte,
which is dangerous.If contact with skin or face
occured, rinse it o immediately with plenty
of water and consult a doctor.
b.Do not use open ames near the generator.
c. Do not allow children to be close to area
with generator.
d. Attention! During the process of
battery charging , hydrogen is released,
which is explosive! Follow the manual
recommendations!
e. Carefully read the manual before using
the device.
f. Use protective glasses when working
with generator.
1
2
i
3
1
3
2

7
4.DESCRIPTIONOFGENERATORINSCRIPTION
EXCEPT SAFETY SYMBOLS GENERATOR CONTAINS FOLLOWING INSCRIPTION:
Oil use recommendations
Carter volume
(dierent for dierent models)
Specication table. For dierent models this
table is dierent. All charachtetistics are
given in the «Specications».
Indicates the position of the fuel tap. Position «ON» -opened,
position «OFF» - closed.
Fuel level indicator. The icon on the left
indicates that the tank is full, the icon on
the right - that the tank is empty.
Maintenance information translated into the language of the country where
the generator is sold you may nd in «Maintenance».
Information on the required
level of oil in the crankcase Grounding
Note which direction you should open air
dampers.
Indicates the noise level. For dierent models this indicator is
dierent. All charachtetistics are given in the «Specications».

8
1. Fuel tank cap
2. Control panel
3. 12 V power battery
(electric start models only)
4. Oil-depth gage
5. Oil drain cap
6. Manual starter
7. Fuel valve
8. Air lter
9. Air ap switch
10. Fuel level indicator
11. Silencer
12. Alternator
13. Sparking plug
5. MAIN OVERVIEW
pic 4
Manufacturer reserves the right to make changes and/or improvements
in design, components set and technical attributes without notice
and without incurring obligation. The pictures in this manual are
schematical and may not match the parameters of original product
! !
IMPORTANT!
1
2
3
4
5
6
7
8
9
10
Könner
K
S
&
&
S
ö
hnen
K
S
&
13
11
12

9
6. DUAL FUEL GENERATOR OVERVIEW
Except the nodes, described in gasoline generator main overview (pic 5)
dual fuel generators are additionally equipped with LPG supply hose.
That allows the generator to work either on gasoline or on LPG.
pic 5
BE ADVISED! It is strongly forbidden to use gasoline and LPG
simultaneously! While using a gasoline source, the LPG supply should
be stopped. The same situation is with liquid gas powering.
! !
ATTENTION - DANGER!
7. COMPONENTS OF SET
1. Generator
2. Packaging
3. Operating Instructions
4. Key candle
5. Keys to run the generator
(for electrostart models)
Dual fuel generators additionally equipped with reductor for stable LPG supply.
1. Gas cylinder connection hose (1.5 m).
2. Built-in reducer.
3. Extra reducer on the hose that is mounted on the cylinder.
21
3

10
8. MODELS DESCRIPTION
To ensure the reliability of the generator and increase its lifespan, the peak capacities may be slightly limited
by circuit breakers.
The optimum operating conditions are ambient temperature of 17 – 25 °C, barometric pressure of 0.1 MPa
(760 mm Hg), and relative humidity of 50 – 60%. Under such ambient conditions, the generator can guarantee
maximum performance in terms of the stated specications. In case of deviations from the above ambient
values, the performance of the generator can be dierent.
Please note that in order to preserve the lifespan of the generator, continuous loads should not exceed 80%
of the rated power.
Model KS 2900 KS 2900G
Voltage, V 230 230
Max Power, kW 2,9 2,9
Nominal Power, kW 2,5 2,5
Frequency, Hz 50 50
Current max, A 12,5 12,5
Outlets 2*16A 2*16A
Fuel Tank Volume, l 15 15
50% power working time 15 15
LED display voltage, frequency,
working hours voltage, frequency, working hours
Noise level Lpa (7m)/Lwa, dB 68/93 68/93
Power output V/ 12/8,3 12/8,3
Engine model KS 200 KS 200
Engine type gasoline 4 stroke cycle
engine
LPG/gasoline
4 stroke cycle
engine
Engine power, hp 6,5 6,5
Crank case volume, cm30,6 0,6
Engine cylinder volume cm3196 196
Power output controller AVR AVR
Engine start manual manual
Power factor, cosφ 1 1
Dimensions (L*W*H), mm 610x455x485 610x455x485
Weight, kg 41,5 43
Protection class IP23M IP23M
Altitude (MAX), m 1000 1000
Relative humidity <95% <95%
*Acceptable deviation of a current is 5%

11
MODELS DESCRIPTION
Model KS 3000 KS 3000 E KS 3000 G
Voltage, V 230 230 230
Max Power, kW 3,0 3,0 3,0
Nominal Power, kW 2,6 2,6 2,6
Frequency, Hz 50 50 50
Current max, A 13,04 13,04 13,04
Outlets 2*16  2*16  2*16 
Fuel Tank Volume, l 15 15 15
50% power working time 15 15 15
LED display voltage, frequency, working hours
Noise level Lpa (7m)/Lwa, dB 68/93 68/93 68/93
Power output V/ 12/8,3 12/8,3 12/8,3
Engine model KS 210 KS 210 KS 210
Engine type gasoline 4 stroke cycle
engine
gasoline
4 stroke cycle
engine
LPG/gasoline
4 stroke cycle
engine
Engine power, hp 7,0 7,0 7,0
Crank case volume, cm30,6 0,6 0,6
Engine cylinder volume cm3208 208 208
Power output controller AVR AVR AVR
Engine start manual manual/electro manual
Power factor, cosφ 1 1 1
Dimensions (L*W*H), mm 610x455x485 610x455x485 610x455x485
Weight, kg 41,53 46,19 45,4
Protection class IP23M IP23M IP23M
Altitude (MAX), m 1000 1000 1000
Relative humidity <95% <95% <95%
*Acceptable deviation of a current is 5%
To ensure the reliability of the generator and increase its lifespan, the peak capacities may be slightly limited
by circuit breakers.
The optimum operating conditions are ambient temperature of 17 – 25 °C, barometric pressure of 0.1 MPa
(760 mm Hg), and relative humidity of 50 – 60%. Under such ambient conditions, the generator can guarantee
maximum performance in terms of the stated specications. In case of deviations from the above ambient
values, the performance of the generator can be dierent.
Please note that in order to preserve the lifespan of the generator, continuous loads should not exceed 80%
of the rated power.

12
MODELS DESCRIPTION
Model KS 3900E G KS 5000E G KS 7000
Voltage, V 230 230 230
Max Power, kW 3,2 4,5 5,5
Nominal Power, kW 2,7 4,0 5,0
Frequency, Hz 50 50 50
Current max, A 14 19,5 23,91
Outlets 2*16A 2*16A 1*16 
1*32 A
Fuel Tank Volume, l 15 25 25
50% power working time 15 17 17
LED display voltage, frequency, working hours
Noise level Lpa (7m)/Lwa, dB 68/93 70/95 70/95
Power output V/ 12/8,3 12/8,3 12/8,3
Engine model KS 260 KS 390 KS 390
Engine type LPG/gasoline 4 stroke cycle
engine
LPG/gasoline
4 stroke cycle
engine
gasoline
4 stroke cycle
engine
Engine power, hp 7,5 13,0 13,0
Crank case volume, cm30,6 1,1 1,1
Engine cylinder volume cm3223 389 389
Power output controller AVR AVR AVR
Engine start manual/electro manual/electro manual
Power factor, cosφ 1 1 1
Dimensions (L*W*H), mm 610x455x485 700x545x590 700x545x590
Weight, kg 48,5 77 69,2
Protection class IP23M IP23M IP23M
Altitude (MAX), m 1000 1000 1000
Relative humidity <95% <95% <95%
*Acceptable deviation of a current is 5%
To ensure the reliability of the generator and increase its lifespan, the peak capacities may be slightly limited
by circuit breakers.
The optimum operating conditions are ambient temperature of 17 – 25 °C, barometric pressure of 0.1 MPa
(760 mm Hg), and relative humidity of 50 – 60%. Under such ambient conditions, the generator can guarantee
maximum performance in terms of the stated specications. In case of deviations from the above ambient
values, the performance of the generator can be dierent.
Please note that in order to preserve the lifespan of the generator, continuous loads should not exceed 80%
of the rated power.

13
MODELS DESCRIPTION
To ensure the reliability of the generator and increase its lifespan, the peak capacities may be slightly limited
by circuit breakers.
The optimum operating conditions are ambient temperature of 17 – 25 °C, barometric pressure of 0.1 MPa
(760 mm Hg), and relative humidity of 50 – 60%. Under such ambient conditions, the generator can guarantee
maximum performance in terms of the stated specications. In case of deviations from the above ambient
values, the performance of the generator can be dierent.
Please note that in order to preserve the lifespan of the generator, continuous loads should not exceed 80%
of the rated power.
Model KS 7000E KS 7000E G KS 7000E-3
Voltage, V 230 230 400
Max Power, kW 5,5 5,5 5,5
Nominal Power, kW 5,0 5,0 5,0
Frequency, Hz 50 50 50
Current max, A 23,91 23,91 9,93
Outlets 1*16 
1*32 A
1*16 
1*32 A
1*16 
1*16 A (3p)
Fuel Tank Volume, l 25 25 25
50% power working time 17 17 17
LED display voltage, frequency, working hours
Noise level Lpa (7m)/Lwa, dB 70/95 70/95 70/95
Power output V/ 12/8,3 12/8,3 12/8,3
Engine model KS 390 KS 390 KS 390
Engine type gasoline 4 stroke cycle
engine
LPG/gasoline
4 stroke cycle
engine
gasoline
4 stroke cycle
engine
Engine power, hp 13,0 13,0 13,0
Crank case volume, l 1,1 1,1 1,1
Engine cylinder volume cm3389 389 389
Power output controller AVR AVR AVR
Engine start manual/electro manual/electro manual/electro
Power factor, cosφ 1 1 0,8
Dimensions (L*W*H), mm 700x545x590 700x545x590 700x545x590
Weight, kg 76,2 77,2 80,8
Protection class IP23M IP23M IP23M
Altitude (MAX), m 1000 1000 1000
Relative humidity <95% <95% <95%
*Acceptable deviation of a current is 5%

14
MODELS DESCRIPTION
To ensure the reliability of the generator and increase its lifespan, the peak capacities may be slightly limited
by circuit breakers.
The optimum operating conditions are ambient temperature of 17 – 25 °C, barometric pressure of 0.1 MPa
(760 mm Hg), and relative humidity of 50 – 60%. Under such ambient conditions, the generator can guarantee
maximum performance in terms of the stated specications. In case of deviations from the above ambient
values, the performance of the generator can be dierent.
Please note that in order to preserve the lifespan of the generator, continuous loads should not exceed 80%
of the rated power.
Model KS 7000E ATS KS 7000E-3 ATS KS 9000E G
Voltage, V 230 400 230
Max Power, kW 5,5 5,5 6,5
Nominal Power, kW 5,0 5,0 6,0
Frequency, Hz 50 50 50
Current max, A 23,91 9,93 28,3
Outlets 1*16 
1*32 A
1*16 
1*16 A (3p) 1*16A, 1*32A
Fuel Tank Volume, l 25 25 25
50% power working time 17 17 15
LED display voltage, frequency, working hours
Noise level Lpa (7m)/Lwa, dB 70/95 70/95 71/96
Power output V/ 12/8,3 12/8,3 12/8,3
Engine model KS 390 KS 390 KS 420
Engine type gasoline 4 stroke cycle
engine
gasoline
4 stroke cycle
engine
LPG/gasoline
4 stroke cycle
engine
Engine power, hp 13,0 13,0 16,0
Crank case volume, l 1,1 1,1 1,1
Engine cylinder volume cm3389 389 420
Power output controller AVR AVR AVR
Engine start manual/electro/auto manual/electro
Power factor, cosφ 1 0,8 1
Dimensions (L*W*H), mm 700x545x590 700x545x590 700x545x590
Weight, kg 76,8 82,3 83
ATS built-in built-in absent
Protection class IP23M IP23M IP23M
Altitude (MAX), m 1000 1000 1000
Relative humidity <95% <95% <95%
*Acceptable deviation of a current is 5%

15
Model KS 7000E ATS KS 7000E-3 ATS KS 9000E G
Voltage, V 230 400 230
Max Power, kW 5,5 5,5 6,5
Nominal Power, kW 5,0 5,0 6,0
Frequency, Hz 50 50 50
Current max, A 23,91 9,93 28,3
Outlets 1*16 
1*32 A
1*16 
1*16 A (3p) 1*16A, 1*32A
Fuel Tank Volume, l 25 25 25
50% power working time 17 17 15
LED display voltage, frequency, working hours
Noise level Lpa (7m)/Lwa, dB 70/95 70/95 71/96
Power output V/ 12/8,3 12/8,3 12/8,3
Engine model KS 390 KS 390 KS 420
Engine type gasoline 4 stroke cycle
engine
gasoline
4 stroke cycle
engine
LPG/gasoline
4 stroke cycle
engine
Engine power, hp 13,0 13,0 16,0
Crank case volume, l 1,1 1,1 1,1
Engine cylinder volume cm3389 389 420
Power output controller AVR AVR AVR
Engine start manual/electro/auto manual/electro
Power factor, cosφ 1 0,8 1
Dimensions (L*W*H), mm 700x545x590 700x545x590 700x545x590
Weight, kg 76,8 82,3 83
ATS built-in built-in absent
Protection class IP23M IP23M IP23M
Altitude (MAX), m 1000 1000 1000
Relative humidity <95% <95% <95%
*Acceptable deviation of a current is 5%
Model KS 10000E KS 10000E G KS 10000E-3 KS 10000E ATS KS 10000E-3 ATS
Voltage, V 230 230 400 230 400
Max Power, kW 8,0 8,0 8,0 8,0 8,0
Nominal Power, kW 7,5 7,5 7,5 7,5 7,5
Frequency, Hz 50 50 50 50 50
Current max, A 34,78 34,78 14,45 34,78 14,45
Outlets 1*16
1*32A 1*16 1*32A 1*16 1*16A (3p) 1*16 1*32A 1*16 1*16A (3p)
Fuel Tank Volume, l 25 25 25 25 25
50% power working time 14 14 14 14 14
LED display voltage frequency
working hours
voltage
frequency
working hours
voltage
frequency
working hours
voltage
frequency
working hours
voltage
frequency
working hours
Noise level Lpa (7m)/Lwa, dB 71/96 71/96 71/96 71/96 71/96
Power output V/ 12/8,3 12/8,3 12/8,3 12/8,3 12/8,3
Engine model KS 440 KS 440 KS 440 KS 440 KS 440
Engine type
gasoline
4 stroke cycle
engine
LPG/gasoline
4 stroke cycle
engine
gasoline
4 stroke cycle
engine
gasoline
4 stroke cycle
engine
gasoline
4 stroke cycle
engine
Engine power, hp 18,0 18,0 18,0 18,0 18,0
Crank case volume, cm31,2 1,2 1,2 1,2 1,2
Engine cylinder volume cm3440 440 440 440 440
Power output controller AVR AVR AVR AVR AVR
Engine start manual/
electro manual/ electro manual/ electro manual/ electro/auto manual/ electro/auto
Power factor, cosφ 1 1 0,8 1 0,8
Dimensions (L*W*H), mm 700x545x590 700x545x590 700x545x590 700x545x590 700x545x590
Weight, kg 85,5 85,5 88 87,8 89,2
ATS absent absent absent built-in built-in
Protection class IP23M IP23M IP23M IP23M IP23M
Altitude (MAX), m 1000 1000 1000 1000 1000
Relative humidity <95% <95% <95% <95% <95%
*Acceptable deviation of a current is 5%
To ensure the reliability of the generator and increase its lifespan, the peak capacities may be slightly limited
by circuit breakers.
The optimum operating conditions are ambient temperature of 17 – 25 °C, barometric pressure of 0.1 MPa
(760 mm Hg), and relative humidity of 50 – 60%. Under such ambient conditions, the generator can guarantee
maximum performance in terms of the stated specications. In case of deviations from the above ambient
values, the performance of the generator can be dierent.
Please note that in order to preserve the lifespan of the generator, continuous loads should not exceed 80%
of the rated power.
MODELS DESCRIPTION

16
Model KS 7000E 1/3 KS 10000E 1/3
Voltage, V 230 400 230 400
Max Power, kW 5,5 5,5 8,0 8,0
Nominal Power, kW 5,0 5,0 7,5 7,5
Frequency, Hz 50 50
Current max, A 23,91 9,93 34,78 14,45
Outlets 1*16A/400V,
1*32A/230V 1*16A/400V, 1*32A/230V
Fuel Tank Volume, l 25 25
50% power working time 17 15
LED display voltage, frequency,
working hours voltage, frequency, working hours
Noise level Lpa (7m)/Lwa, dB 70/95 71/96
Power output V/ 12/8,3 12/8,3
Engine model KS 390 KS 440
Engine type gasoline 4 stroke cycle
engine gasoline 4 stroke cycle engine
Engine power, hp 13 18
Crank case volume, cm31,1 1,2
Engine cylinder volume cm3389 440
Power output controller AVR AVR
Engine start manual/electro manual/electro
Power factor, cosφ 1/0,8 1/0,8
Dimensions (L*W*H), mm 700545590 700545590
Weight, kg 81,8 95
Protection class IP23M IP23M
Altitude (MAX), m 1000 1000
Relative humidity <95% <95%
*Acceptable deviation of a current is 5%
To ensure the reliability of the generator and increase its lifespan, the peak capacities may be slightly limited
by circuit breakers.
The optimum operating conditions are ambient temperature of 17 – 25 °C, barometric pressure of 0.1 MPa
(760 mm Hg), and relative humidity of 50 – 60%. Under such ambient conditions, the generator can guarantee
maximum performance in terms of the stated specications. In case of deviations from the above ambient
values, the performance of the generator can be dierent.
Please note that in order to preserve the lifespan of the generator, continuous loads should not exceed 80%
of the rated power.
MODELS DESCRIPTION

17
9. CONTROL PANEL TYPES
9.1. GENERATOR PANEL
pic 6
1. LED display
2. Emergency circuit breaker
3. Sockets
4. Start/electrostart
5. Direct current sockets 12V
6. Grounding
123
654
9.2. GENERATOR PANEL FOR MODELS: KS 7000E ATS, KS 7000E-3 ATS,
KS 10000E ATS, KS 10000E-3 ATS pic 7
1. LED display
2. Emergency circuit breaker
3. Sockets
4. Engine start key (ON/OFF)
5. Direct current sockets 12V
6. Grounding
7. ATS switch
8. ATS indicator
9. ATS connectors
123
98 654 7

18
FOR THREEPHASE DIESEL GENERATOR
Three-phase diesel generator load must be distributed on all three phases, and
the load on all phases must be balanced.The load on 1 phase should not exceed
1/3 of the total generator capacity. Maximum permissible imbalance is 20%.
Only 1 or 2 phase load leads to the generator breakage.The total load and total
current on all three phases should not exceed nominal load and current of the
generator.
CONNECTING DEVICES
After starting the engine, make sure the voltmeter readings correspond to
the nominal (at 50 Hz 230V ±10% for single-phase units and 400 ±10% for
threephase).
1. LED display
2. Emergency circuit breaker
3. Sockets
4. Grounding
5. 3 phase / 1 phase mode switch
(position 1 - 400V, position 0 - o,
position 2 - 230V)
6. Direct current sockets 12V
7. Engine start key
9.3. GENERATOR PANEL FOR MODELS: KS 7000E 1/3, KS 10000E 1/3

19
10. DIGITAL DISPLAY OF GASOLINE
GENERATORS
The choice of indicators occurs by pressing a button on the display, selection of
indicators is cyclic.
In this mode, the display shows the voltage,
in volts.
In this mode, the display shows the current
frequency, in hertz.
This mode displays the generator’s running time
from the moment it starts, in minutes.
In this mode, the display shows the total
number of hours worked by the generator.
The generator is o.
11. COMMISSIONING
The generator is supplied without fuel. Before the operation please ll the fuel.
Guidelines for lling are below. Generators are supplied without motor oil.
The generator casing may contain residues of oil after tests conducted during
production.
Before starting to use the generator, be sure to pour oil. Recommendations on
oil and it’s lling process are below. Follow maintenance recommendations
during the rst month or twenty hours (whichever occurs rst) contained in
the «Maintenance» section. For commissioning models with elektrostart please
charge the battery. Please use additional battery charger (not included) to
charge the battery or let the generator work at least one hour at 50% load at
the rst start.
It is recommended to ground the generator before operating it for the rst time.
GROUND TERMINAL
The ground terminal forms a ground line to prevent electric shock. If the electrical
appliance is grounded, the generator must also be grounded.
