KanexPro HDSP164K User manual

4K UHD 1x16 HDMI Distribution Amplifier with
EDID Management
User manual
V1.0

1
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference.
I. Introduction
The KanexPro HDSP164K is a one in, sixteen out distribution amplifier designed to split one high
res. 4K signal in to sixteen displays while maintaining the highest level of signal integrity.
It supports the latest HDMI 2.0 specifications with HDCP 2.2. The splitter support EDID control, so
that can force the source output definitions you want.
II. Features
1. Distribute 4K HDMI video and audio signals to up to 16 displays
2. Supports full HD 1080p (1920 x 1080@60Hz) & 4K UHD
3. Supported resolutions up to 4K*2K@30Hz@8bit(YCbCr4:4:4)；

2
4K*2K@60Hz@8bit(YCbCr4:2:0)
4. Support digital audio format, DTS-HD/Dolby-True HD /LPCM7.1/AC3/DTS/DSD
5. Support EDID selector
6. Front-panel LED’s for input/ output signal presence
7. 5VDC external power supply included
III. Package
1. 4K UHD HDMI 1x16 Splitter ----------------------------------------------------------------------- 1PC
2. 12V2.5A DC Power adapter ------------------------------------------------------------- 1PC
3. Operation Manual ------------------------------------------------------------------------- 1PC

3
IV. Specifications
1. Video Bandwidth 10.2Gbps
2. Input Ports 1 × HDMI (Female type)
3. Output Ports 16 × HDMI (Female type),
4. Input Resolutions
• 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz,
• 720p@50/60Hz, 1080i@50/60Hz, 1080p@24/30/50/60H,
• 4K@30Hz@8bit(YCbCr4: 4:4), 4K@60Hz@8bit(YCbCr4: 2:0);
5. Output Resolutions
• 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz,
• 720p@50/60Hz, 1080i@50/60Hz, 1080p@24/30/50/60H,
• 4K@30Hz@8bit(YCbCr4: 4:4), 4K@60Hz@8bit(YCbCr4: 2:0)

4
6. ESD Protection Human Body model: ±8 kV (air-gap discharge)
±4 kV (contact discharge)
8. Power Supply 12V/2.5A DC (US/EU standards, CE/FCC/UL certified)
9. Dimensions 115 mm (W)×270mm (D)×45 mm (H)
10. Weight 2.2 lbs. (1000g)
11. Chassis Material Metal
12. Silkscreen Color Silver
13. Operating Temperature 0 °C~40 °C/ 32 °F~104 °F
14. Storage Temperature −20 °C ~ 60 °C/−4 °F ~140 °F
15. Relative Humidity 20~90 % RH (non-condensing)
16. Power Consumption 30W (max)

5
V. Operation controls and Functions
Front Panel
1. ON/OFF: Power on/off switch.
2. POWER LED: This red LED illuminates when the device is connected with power supply.

6
3. INPUT LED: This red LED illuminates when the source plugs in corresponding HDMI input
Port
4. OUTPUT LED: These red LEDs illuminates when the TV plugs in corresponding HDMI
output Port.
5. EDID Selector: Select HDMI output signal format via EDID Selector.
Position
EDID Description
0 0 0 0
1080i, 2CH AUDIO
0 0 0 1
1080i, DOLBY/DTS 5.1
0 0 1 0
1080i, HD AUDIO
0 0 1 1
1080p, 2CH AUDIO
0 1 0 0
1080p, DOLBY/DTS 5.1
0 1 0 1
1080p, HD AUDIO
0 1 1 0
3D, 1080p, 2CH AUDIO

7
0 1 1 1
3D, 1080p,DOLBY/DTS 5.1
1 0 0 0
3D, 1080p, HD AUDIO
1 0 0 1
4Kx2K, 2CH AUDIO
1 0 1 0
4Kx2K, DOLBY/DTS 5.1
1 0 1 1
4Kx2K, HD AUDIO
1 1 0 0
RESERVE
1 1 0 1
RESERVE
1 1 1 0
RESERVE
1 1 1 1
COPY HDMI OUTPUT 1
6. UPDATE: Connected to computer via RS232 tool, and controlled via host-computer
software.
7.

8
Rear Panel
1. HDMI OUTPUT: These connector slots are where you connect the HDTV or monitor with
HDMI cable.
2. HDMI IN: This slot is where you connect the HDMI source output from DVD, HDMI based
PC or cable box.
3. DC 12V IN:Plug the 12V DC power supply into the unit and connect the adapter to AC wall
outlet.

9
VI. Application Example

10
The Product is warranted for full parts and labor for 2 years from the date of purchase for any
questions or problems, please try to get help from your local distributor or AV dealer first before
contacting KanexPro Support at 888-975-1368
Brea, California
KanexPro.com
MPN: HDSP164K
