Kanguru Presenter Mouse Operating instructions

The Kanguru Presentation Mouse Quick Start Guide 1
Requirements:
• An available USB port
• Windows 98SE, Me, 2000, XP, or MAC 9.2 and above
Installation of the Kanguru Presentation Mouse is dependent on the
operating system. Please follow the instructions carefully to make sure
you are taking the appropriate steps for your operating system.
Windows 98/SE users must first install the Flash Driver (Steps 1
to 3 below). All other users do not need to install the Flash Driver.
Install the Flash Driver
(Windows 98 SE Only)
Step 1: Insert the Kanguru
Drivers and Manuals. Open
the “Kanguru Presentation
Mouse with Memory” folder,
and then open the “Drivers”
folder.
Step 2: Double click on the
Win98 Driver KPM file to
begin the installation. Follow
the installation wizard to
complete the installation.
Step 3: Reboot your system
and the installation is complete.
You should now find a new
Removable Disk icon under
My Computer.
If you are having problems with
the installation in Win98
please refer to the Kanguru
Presentation Mouse manual.
How to use the remote:
1. Insert the supplied battery into the RF remote.
2. Connect the RF Receiver to an available USB port.
3. Windows will detect the new hardware and install the
appropriate software using the New Hardware Wizard.
Please have your Windows System CD-ROM ready in case
the Wizard asks for it.
4. You are now ready to use the remote.
Using the Presentation Remote:
The remote has 2 modes, which are controlled via the Mode Button
(clear button). When the Mode Button is clear (not green), the remote
is in Standard mode. When the Mode Button is lit green, then the
remote is in Media mode. For details regarding these modes, please
see the next page of this quick start guide.
Using the Presentation Remote:
To turn on the Laser Pointer, hold down the Laser Button (red button)
AND the Mode button (clear button) simultaneously until the Mode
button flashed in red. Repeat this process to deactivate the laser.

The Kanguru Presentation Mouse Quick Start Guide 2
Changing the Remote’s ID:
If your remote is note working or you are experiencing interference
with another remote in the area, please follow these instructions:
1. Press and hold the Mode Button and the Composite
Switch simultaneously for at least 5 seconds. The Mode
Button will flash green to change to a new ID.
2. Use a paperclip to press the Receiver Reset Button on the
RF Receiver.
3. Push the Left or Right Mouse Buttons on the remote to
activate the new ID.
Additional Troubleshooting Notes:
1. If you remove or replace the battery and your Remote
doesn’t work, repeat steps 1-3 above to activate a new ID.
2. The Media Functions are currently not supported in the Mac
OS.
3. The Laser pointer will turn off automatically after 30 seconds
of non-use.
4. Media mode turns off after 10 minutes of non-use.
5. In Windows 98/98SE you need to install a driver to access
the Flash Memory in the RF receiver.
Tech Support:
If you experience any problems installing your Kanguru Presentation
Mouse or have any technical questions regarding any of our
products, please call our tech support department. Our tech support
is free and available Monday through Friday, 9am to 5pm EST.
Call 1-508-376-4245 or
Visit our website at http://www.kanguru.com
