Kantronics 8040-B User manual
PAGE
SPECIFICATIONS 2
FUNCTIONS 3,4
SCHEMATICDIAGRAM 6,7
HOW TO USE YOUR 8040-b
Grounding
Antennaconsiderations
Dialinformation
Batteryinstallation 8,9
TUNINGPROCEDURES 10
SERVICE INFORMATION 11
WARRANTY BACKCOVER
WARNING – Do not attempt to tune HFO
(High Frequency Oscillator) without proper equipment.
HFO is factory calibrated.
Specifications:
Frequency Coverage
80 meters, 3.65 to 3.75 MHz
40 meters, 7.05 to 7.15 MHz
Power Requirements
Two9volttransistorbatteries
Size
Approximately HWD 3” x 5” x 7”
Audio Output
Eight ohm speaker or optional eight ohm
monaural headphones Standard phono
plug
Sensitivity
One microvolt provides readable signal
Selectivity
1000 Hz @ 6 DB.
FORSERVICEINFORMATIONORREPAIRS:
Writeto:
KANTRONICS,INCORPORATED
ATTN:ServiceDepartmentAR
1202East23rdStreet
Lawrence,Kansas66044
FORREPAIRS,PLEASEPHONEBEFORERETURNING
(913)842‐7745
FORFURTHERINFORMATIONONAMATEURRADIO,WESUGGESTYOUWRITE:
TheAmericanRadioRelayLeague
225MainStreet
Newington,Connecticut06111
RL/RB:5:78:3
