10 inch FLAT SUBWOOFER
OWNERS MANUAL & INSTALLATION GUIDE
FLAT 10

Introduction:
Congratulations on your new purchase of Kaption Audio loudspeakers. These
loudspeakers are engineered to reproduce music that is so detailed; you will hear
music in a whole new dimension. State of the art technology, rigorous testing,
superior materials, innovative design and painstaking quality control; all of these
factors make for a truly superior product.
For the best performance we recommend you have an authorized Kaption Audio
dealer install your product.
KAPTION AUDIO LOUDSPEAKERS COME WITH A ONE-YEAR
PARTS AND LABOUR LIMITED WARRANTY.
Design Features:
-Heavy powder coated cast aluminum basket with machined edge
-Neodymium magnet structure
-3 1/8 inches Mounting depth
-3 inch 4-layer voice coil
- 4ohm nominal impedance
CAUTION:
Extended exposure to sound pressure levels over 100db may cause permanent
hearing loss.
Kaption Audio accepts no liability for any damaged or permanent hearing loss.
1

Limited Warranty Information:
Kaption Audio loudspeakers have a one-year limited warranty. This warranty
covers the original purchaser of a Kaption Audio speaker, purchased from an
authorized Kaption Audio dealer.
In order to receive service, proof of purchase is required stating the customers
name, dealer name, product purchased and date of purchase.
Products found to be defective during the warranty period will be repaired or
replaced with a product deemed to be equivalent at Kaption Audios discretion.
What is not covered
1. Any product not purchased from an authorized Kaption Audio dealer.
2. Any expense related to the removal, reinstallation or shipment of any
Kaption Audio products.
3. Any Kaption Audio product that has been defaced or altered.
4. Subsequent damage to other components.
5. Damage caused by accident, abuse, improper operation, water and theft.
How to obtain service
To obtain service on a Kaption Audio product, Please return product along with original receipt to
an authorized Kaption Audio dealer or call 1-866-KAPTION (527-8466)
2

Specifications
Speaker Size: 10 inches (254mm)
Sensitivity (1w/1m): 82dB
Power Handling (RMS/PEAK): 250/500
Impedance: 4 ohm
Voice Coil Diameter: 2.5 inches (63.5mm)
Mounting Diameter: 9 3/8 inches (238mm)
Mounting Depth: 3 1/8 inches (80mm)
Magnet Weight: 22oz Neodymium (1oz Neo = 10oz ceramic)
Driver Displacement: 0.045cu.ft
Thiele-Small Parameters
Fs: 27.7 Hz Dia: 210 mm
Qts: 0.574 Vas: 33.9 litres
Qms: 2.6 Mms: 164 grams
Qes: .735 Cms: 201.2 umN
Res: 3.15 ohms Bl: 10.94 T*m
Ls: 943 uH No: .0937 %
Lp: 1.54 mH Sensitivity: 82dB 1w/1m
Rp: 6.04 ohms Xmax: 10mm
Specifications subject to change without notice
3

Recommended Enclosures
This manual offers you two separate types of enclosures, sealed and ported. These
two types of enclosures will give you different types of performance to better suit
your application.
When building a sealed or ported enclosure, the most important thing to remember
is that the enclosure should be airtight. You can seal all the seams with glue or any
type of sealant. This should prevent any air leaks. The seams should also be nailed
with finishing nails to add extra durability. We recommend you use 3/4 inch MDF
(Medium Density Fiberboard) when building any enclosure.
Remember to account for all sources of volume displacements (i.e. speaker, braces
and/ or ports) when calculating box size.
Calculating Enclosure Volume
Height x Width x Depth (internal dimensions in inches)
1728 = Volume in cubic feet.
Box Recommendations
Sealed Enclosure
Size F3
SPL 0.5cu.ft 41.5Hz
Musical 0.8cu.ft 39Hz
Ported Enclosure
Size Port Size Fb
SPL 0.9cu.ft 3inches X 9inches 42Hz
Musical 1.25cu.ft 3inches X 16inches 29Hz
4

Kaption Audio
399 Four Valley Dr, Unit 26 & 27
Concord, Ontario, Canada
L4K 5Y7
1-866-KAPTION (527-8466)
3333 391 1
www.kaptionaudio.com
