KAR-TECH MCT245 User manual

MCT245
2.4GHz RECEIVER
OEM INSTALLATION AND OPERATION MANUAL
June 27, 2020
TH

MCT245 RECEIVER
1
INDEX
DESCRIPTION ........................................................................... 2
OPERATION .............................................................................. 2
INSTALLATION ......................................................................... 4
BEFORE APPLYING POWER! ...................................................... 5
TROUBLESHOOTING ................................................................. 6
TRANSCEIVER PICTORIAL ........................................................ 7
SPECIFICATIONS ...................................................................... 7
INSTRUCTION TO THE USER ..................................................... 8
INDUSTRY CANADA STATEMENTS ........................................... 10

MCT245 RECEIVER
2
DESCRIPTION
The MCT245 is a frequency
hopping spread spectrum
transceiver unit, designed to be
compatible with US (FCC Part
15.247), Canadian (RSS-210),
EU(EN 60950-1, EN 300 328, EN
301 489) and Australian()
regulations for license free use
in the 2.4 GHz ISM band. The
MCT245 is designed for mobile
applications in accordance to
Part 2.1091(b).
The MCT245 remote control
products are assembled by Kar-
Tech, at Kar-Tech. There are no
user serviceable parts on the
MCT245 transceiver.
The MCT245 is not designed for
multiple antenna applications
and should not be used to
transmit simultaneously with
any other transmitter.
OPERATION
The MCT245 is a radio
Receiver product for the 2.4
GHz ISM bands. The
Receiver microcontroller
includes a CPU, GPI/O, a
fully integrated frequency
synthesizer, a power amplifier,
a modulator and a receiver
unit. The data received from
antenna is sent to the
microcontroller for
processing. The MCT245
microcontroller monitors the
input data, received data
and controls outputs. The
system data is sent to the
RF processor and then to RF
circuit, and then to the
antenna. The microcontroller is
responsible for the control of
the entire communication.
The MCT245 transceiver
contains a DC regulator which
generates a constant 1.8 VDC
for the digital

MCT245 RECEIVER
3
circuitry. The RF section runs on
the 3.3V supply.
The MCT245 uses Frequency
Hopping Spread Spectrum
that uses 16 channels for
any hop mode, between
2.407GHZ and 2.470GHZ, with
1MHZ resolution.
The receivers are matched
to the transmitters to use the
same channels and sequence
as the transmitter’s signals.
The MCT245 controls
outputs which can operate
relays, hydraulic valves, lights,
or other similar load devices,
according to customer
requirements.
Where Used
Typical applications for
the MCT245 are to
controlling valves, relays and
lights on agricultural
equipment,
construction equipment, and
other similar equipment.

MCT245 RECEIVER
4
INSTALLATION
1) Attach the external harness
to the MCT245.
2) Assemble the MCT245
assembly into the
Enclosure.
3) Place a label on the outside
of the enclosure on the
side. On the label, include
the following: “FCC ID:
P4U- MCT245” and “IC:
4534A- MCT245, CE”

MCT245 RECEIVER
5
Application Requirements:
A) Power the MCT245 Receiver
with 9-30VDC nominal
voltage, with peak
current draw of 150mA.
B)Assemble the MCT245, into
a KAR-TECH Receiver
enclosure.
C) The MCT245 is to be
installed only in mobile
applications. See Part
2.1091 for definitions of
mobile and fixed
applications.
D) Do not operate the MCT245
without an antenna.
E) Documentations: In the
host’s User Manual
include the following:
a. That there are no user
serviceable parts in
the radio product.
They should not
remove or install radio
modules.
b. The “Instructions To
The User” section.
c. The “Industry Canada
Statement”.
d. Include in the manual,
“This device is granted
for use in Mobile only
configurations in
which the antennas
used for this
transmitter must be
installed to provide a
separation distance of
at least 20cm from all
person and not be co-
located with any other
transmitters except in
accordance with FCC
and Industry Canada
multi-transmitter
product procedures.”
BEFORE APPLYING
POWER!
Check power and ground for
proper polarity.

MCT245 RECEIVER
6
Read the rest of this manual.
TROUBLESHOOTING
There are no user serviceable
parts in the MCT245 Receiver.
Contact your KAR-TECH
representative for further
instructions or servicing.
PARTS LIST
PART NUMBER DESCRIPTION
022081A MCT245 RADIO TRANSCEIVER – REMOVEABLE
ANTENNA
There are no user-serviceable parts inside the transmitter or the
receiver. Return the units for service.
The information, specifications, and illustrations in this manual are those in effect at the time of
printing. We reserve the right to change specifications or design at any time without notice.

MCT245 RECEIVER
7
SPECIFICATIONS
Equipment Class .............................. Part 15 Spread Spectrum Transmitter
FCC ID ............................................................................. P4U- MCT245
ICC (Industry Canada Certification) ID .............................. 4534A- MCT245
TRANSCEIVER
Power supply ......................................................................... 9-30VDC
Operating Current ........................................................................ 48mA
Operating temperature - Radio ....................................... -40˚C to +85˚C
Storage temperature ................................................... -40˚C to +100˚C
RF Frequency .................................................................... 2.4-2.48 GHz
RF Transmit power (EIRP) .......................................................... 100 mW
RF Receive Sensitivity ............................................................. -126 dBm

MCT245 RECEIVER
8
INSTRUCTION TO THE USER
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

9
MCT245 RECEIVER
FCC Radiation Exposure Statement
The product can be installed or integrated in mobile or fix devices only.
This product cannot be installed in any portable device, for example, USB
dongle like transmitters is forbidden.
This product complies with FCC RF radiation exposure limits set forth for
an uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
This product must be installed and operated with a minimum distance of
20 cm between the radiator and user body.
If the FCC identification number is not visible when the product is
installed inside another device, then the outside of the device into which
the product is installed must also display a label referring to the enclosed
product. This exterior label can use wording such as the following:
“Contains Transmitter product FCC ID: P4U-MCT245”
When the product is installed inside another device, the user manual of
this device must contain below warning statements;
1. This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
The devices must be installed and used in strict accordance with the
manufacturer's instructions as described in the user documentation that
comes with the product

MCT245 RECEIVER
10
INDUSTRY CANADA STATEMENTS
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.)
is not more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent
émetteur radio peut fonctionner avec une antenne d'un type et d'un
gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie
Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que la puissance isotrope
rayonnée quivalente (p.i.r.e.) ne dépassepas l'intensité nécessaire à
l'établissement d'une communication satisfaisante.

MCT245 RECEIVER
11
OEM Responsibilities to comply with FCC and Industry Canada
Regulations
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that
may cause undesired operation of the device.
Cet appareil est conforme aux CNR exemptes de licence d'Industrie
Canada . Son fonctionnement est soumis aux deux conditions suivantes :
( 1 ) Ce dispositif ne peut causer d'interférences ; et
( 2 ) Ce dispositif doit accepter toute interférence , y compris les
interférences qui peuvent causer un mauvais fonctionnement de
l'appareil.
IC Radiation Exposure Statement
The product can be installed or integrated in mobile or fix devices only.
This product cannot be installed in any portable device, for example,
USB dongle like transmitters is forbidden.
This product complies with IC RF radiation exposure limits set forth for
an uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
This product must be installed and operated with a minimum distance of
20 cm between the radiator and user body. Cette modulaire doit être
installé et utilisé à une distance minimum de 20 cm entre le radiateur et
le corps de l'utilisateur.
If the IC number is not visible when the product is installed inside
another device, then the outside of the device into which the product is
installed must also display a label referring to the enclosed product. This
exterior label can use wording such as the following:
“Contains IC: 4534A- MCT245”

MCT245 RECEIVER
12
When the product is installed inside another device, the user manual of
this device must contain below warning statements:
1. This device complies with Industry Canada’s license-exempt RSSs.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that
may cause undesired operation of the device.
2. Cet appareil est conforme aux CNR exemptes de licence d'Industrie
Canada . Son fonctionnement est soumis aux deux conditions suivantes :
( 1 ) Ce dispositif ne peut causer d'interférences ; et
( 2 ) Ce dispositif doit accepter toute interférence , y compris les
interférences qui peuvent causer un mauvais fonctionnement de
l'appareil.
The devices must be installed and used in strict accordance with the
manufacturer's instructions as described in the user documentation that
comes with the product.

MCT245 RECEIVER
13
EUROPE
CE NOTICE
This device has been tested and certified for use in the European
Union. See the Declaration of Conformity (DOC) for specifics.
If this device is used in a product, the OEM has the responsibility to
verify compliance of the final product to the EU standards. A
declaration of Conformity must be issued and kept on file as described
in the Radio and Telecommunications Terminal Equipment (R&TTE)
Directive.
The ‘CE’ mark must be placed on the OEM product per the labeling
requirements on the Directive.
Declaration of Conformity (DOC)
This DOC can be downloaded from the www.kar-tech.com.
The device complies with RF specifications when the device used at your
body.
Caution: Must use the original antenna. Other antennas are not allowed
to be used.
The device according to the regulation in Directive 1999/5/EC and
complies with standards as follow:
EMC (Article 3.1b) ETSI EN 301 489-1 V 1.9.2 Report No.: CTL1512313913-WE
ETSI EN 301 489-17 V2.2.1 (2012-09)
Radio (Article 3.2)
ETSI EN 300 328 V1.8.1 Report No.: CTL1512313913-WR
Safety (Ar
ticle 3.1a)
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 Report No.: CTL1512313913-WS
Health (Article 3.1a) EN 62479: 2010 Report No.: CTL1512313913-WH
[Titles, dates of publication of documents mentioned ]
