Kaufman KM-25 User manual

NON-CONTACT THERMOMETER
MODEL:KM-25
0482

Visiomed - Kaufman KM-25 - V.2.3 -201012 2/21
TABLE OF CONTENTS
I. SAFETY INSTRUCTIONS ………………………………………………… 21
II. INTRODUCTION ………………………………………………… 22
III. PRECAUTIONS BEFORE USE ………………………………………………… 22
IV. OPERATING PRINCIPLES ………………………………………………… 23
DIFFERENT METHODS OF TEMPERATURE MEASUREMENT ………………………………………………… 23
NORMAL TEMPERATURES BY METHOD ………………………………………………… 24
ADVANTAGES OF USING TEMPORAL ARTERY (TA) ………………………………………………… 25
NORMAL TEMPERATURES BY AGE ………………………………………………… 25
PRACTICAL CONSIDERATIONS WHEN TAKING A TEMPERATURE ………………………………………………… 26
HOW TO TAKE A TEMPERATURE ………………………………………………… 26
FOR RELIABLE RESULTS ………………………………………………… 27
V. USING YOUR KAUFMAN KM-25 THERMOMETER ………………………………………………… 27
VI. DESCRIPTION OF THE KAUFMAN KM-25 THERMOMETER ………………………………………………… 28
VII. FUNCTIONS ………………………………………………… 29
VIII. SETUP &MENU FUNCTIONS ………………………………………………… 30
OPTION BUTTONS ………………………………………………… 30
SETTING UP THE KAUFMAN KM-25 THERMOMETER ………………………………………………… 31
1. TEMPERATURE UNITS ………………………………………………… 31
2. TEMPERATURE VARIATION ………………………………………………… 31
3. EXIT SETUP MODE ………………………………………………… 31
4. DATA MEMORY………………………………………………… 32
5. CHANGING BATTERIES ………………………………………………… 32
IX. TECHNICAL &PRECISION INFORMATION ………………………………………………… 33
X. ADVICE ………………………………………………… 34
XI. SUPPLIED ACCESSORIES ………………………………………………… 34
XII. TROUBLESHOOTING ………………………………………………… 34

Visiomed - Kaufman KM-25 - V.2.3 -201012 3/21
I. SAFETY INSTRUCTIONS
-Follow the maintenance instructions set out in this notice
-The device is intended for personal use at home or in medical practice. It is not recommended for heavy
use in a professional setting.
-The device should only be used for its intended purpose as described in this notice;
-The ambient temperature range for the thermometer is between 10 to 40 ° C.
-The unit must always be stored in a clean and dry place.
-Do not expose the thermometer to electric shocks.
-Do not expose the thermometer to extreme temperature conditions: > 50 ° C or <-20 ° C
-Do not use the device in relative humidity of above 85%
-The infrared sensor (lens) is the most fragile part of the thermometer.
-Do not touch the infrared lens with your fingers
-Clean the lens with a cotton swab moistened with rubbing alcohol (70% isopropyl alcohol).
-Do not expose the thermometer to sunlight or water.
-Do not use outdoors.
-Never drop the device
-In the event of problems with this device please contact your dealer Do not try to repair the device
yourself.
-
IMPORTANT WARNING
Ensure batteries are in the right way round. Incorrect polarity may cause damage and compromise the guarantee
for your device.
THE MANUFACTURER RESERVES THE RIGHT TO MODIFY THE PRODUCT SPECIFICATIONS WITHOUT NOTICE

Visiomed - Kaufman KM-25 - V.2.3 -201012 4/21
II. INTRODUCTION
The Kaufman KM-25 NON-CONTACT thermometer was developed using the latest infrared technology. This technology allows
a temporal artery (TA) temperature to be taken at a distance of about 5 cm from the forehead.
Accurate, Instant and Non-Contact, the Kaufman KM-25 thermometer is currently the best thermometer for taking
temperatures safely. It has been shown that this method of TA temperature measurement is more accurate than tympanic
thermometry and better tolerated than rectal thermometry (1).
However, as with other types of thermometer it is essential to use the Kaufman KM-25 thermometer correctly to obtain
reliable and stable results.
You are therefore advised to read the instruction manual and safety directions carefully before use.
(1) Greenes D, Fleisher G. Accuracy of a Noninvasive Temporal Artery Thermometer for Use in Infants. Arch Pediatr Adolesc Med 2001;155:376.
III. PRECAUTIONS BEFORE USE
The Kaufman KM-25 thermometer is pre-configured at the factory.
It is not necessary to calibrate the device before use.
To obtain reliable and stable results, following any significant change in the ambient temperature (± 10 ° C) the
thermometer should be left at room temperature for at least 15 minutes before use to allow automatic recalibration of the
device.
It is important to wait 1 minute between temperature measurements.

Visiomed - Kaufman KM-25 - V.2.3 -201012 5/21
IV. OPERATING PRINCIPLE
All objects, solid, liquid or gas, radiate energy whose intensity varies in relation to its temperature. The
Kaufman KM-25 thermometer measures the temperature of a person based on the energy that they radiate.
A temperature measurement is taken by the external probe on the device which constantly analyses and
registers the ambient temperature. When the operator holds the thermometer near to the body and
activates the radiation sensor, the temperature is taken instantly by measuring the infrared heat radiated by
the arterial blood flow. The temperature of the person is therefore measured without interference from the
ambient temperature.
DIFFERENT METHODS OF TEMPERATURE MEASUREMENT
Core temperature
Measuring core temperature is the most accurate way to measure body temperature, and involves
measuring the temperature of the pulmonary artery by means of a catheter which is fitted with a
temperature sensor to measure the temperature in situ . Oesophageal temperature sensors work on the
same principle. However these invasive measurement methods require specialist equipment and skills.
Rectal thermometry
Rectal temperature adjusts slowly in relation to changes in the body’s core temperature. It has been shown
that the rectal temperature remains raised well after the core temperature of the patient has started to fall,
and vice-versa.
In addition to this, rectal perforations have been known to occur when using this method, and without
suitable sterilisation rectal thermometry can propagate contaminants often found in faeces.

Visiomed - Kaufman KM-25 - V.2.3 -201012 6/21
Oral thermometry
Oral temperature is easily affected by recent ingestion of food and drink and by breathing through the
mouth. To take temperature orally, the mouth needs to be closed and the tongue depressed for between
three and four minutes, this is a difficult task for young children.
Axillary thermometry
Axillary temperature is easy to take, but it has been found to be a poor indicator of a child’s body
temperature. To take a temperature measurement in this way the thermometer should be correctly placed
on the axillary artery. Despite its low sensitivity and weakness in detecting fever, axillary temperature is
recommended by the American Academy of Pediatrics as a screening test for fever in new-borns.
Tympanic thermometry
To obtain an accurate tympanic temperature it is crucial to use the correct technique. The thermometer
sensor should be placed close to the warmest part of the external auditory canal. Incorrect aim of the
sensor can result in an incorrect temperature reading.
NORMAL TEMPERATURES BY METHOD
MEASUREMENT METHOD NORMAL TEMP°
RECTAL 36.6°C –38°C
ORAL 35.5°C –37.5°C
AXILLARY 34.7°C –37.3°C
TYMPANIC (INNER EAR)35.8°C –38°C
FOREHEAD (THERMOMETER)35.8°C –37.8°C
The normal temperature measured over the temporal area is on average 0,5 °C lower to the temperature
measured rectally.

Visiomed - Kaufman KM-25 - V.2.3 -201012 7/21
ADVANTAGES OF USING TEMPORAL ARTERY (TA) TEMPERATURE
Infrared arterial temperature can be measured using a device placed on the forehead in the temporal artery
region. It has been shown that this relatively new method of measuring temperature is more accurate than
tympanic thermometry and better tolerated than rectal thermometry.
The Kaufman KM-25 thermometer is designed to produce an instant forehead temperature reading without
any contact with the temporal artery. This artery is close to the surface of this skin and therefore accessible
and allows accurate measurement of temperature given a permanent and regular blood flow. The temporal
artery is linked to the heart by the carotid artery which is directly linked to the aorta, and it forms part of
the main trunk of the arterial system. The efficiency, speed and comfort of taking a temperature reading
from this area make it ideal compared with other temperature measurements methods.
NORMAL TEMPERATURES BY AGE
Age
°C
°F
0-2 years
36.4-38.0
97.5-100.4
3-10 years
36.1-37.8
97.0-100.0
11-65 years
35.9-37.6
96.6-99.7
> 65 years
35.8-37.5
96.4-99.5

Visiomed - Kaufman KM-25 - V.2.3 -201012 8/21
PRACTICAL CONSIDERATIONS WHEN TAKING A TEMPERATURE
-To ensure a precise and accurate temperature measurement, it is important that the user has received
adequate training and information regarding the temperature measurement technique for the device.
-It is important to remember that although the actions required to take the temperature are simple, they
should not be trivialised.
-The temperature should be taken in a neutral context. The patient should not have undertaken vigorous
activity before temperature measurement and the room temperature should be moderate.
-Take note of physiological temperature variations which should be taken into account when reading the
results: temperature increases by 0.5C° between 6am and 3pm. On average women’s temperature is higher
by 0.2C°. Also, women’s temperature varies in relation to their ovarian cycle, it rises by 0.5C° in the second
half of the cycle and in the early stages of pregnancy.
-When sitting, temperature is lower by between 0.3 and 0.4C° than when standing.
HOW TO TAKE A TEMPERATURE
Aim the device at the FOREHEAD, over the temporal area from a
distance of 5 cm, press the thermometer’s measure button and the
temperature will be displayed instantly, the result is also read aloud (in voice
mode).
The temperature can be measured on other parts of the body but
the accuracy cannot be guaranteed.

Visiomed - Kaufman KM-25 - V.2.3 -201012 9/21
FOR RELIABLE RESULTS
Before taking a temperature reading and to ensure a stable and reliable result:
-Push aside hair from the forehead
-Wipe away any perspiration on the forehead
-Avoid drafts (e.g. nasal cannula, air conditioning etc.)
-Wait 1 minute between temperature readings
--Following any significant change in the ambient temperature (± 10°C) the thermometer should be left at
room temperature for at least 15 minutes before use to allow automatic recalibration of the device.
V. USING YOUR THERMOMETER
1. Install the batteries.
2. Before first use or when inserting new batteries, wait 10 minutes for the
device to warm up.
3. Aim towards the forehead (see the following diagram for how to position the
thermometer) from a distance of 5 cm, press the thermometer’s measure button
and the temperature will be displayed instantly (see layout of the LCD screen
below). Temperature can also be taken behind the ear lobe –on the jugular vein.
4. Before taking a temperature reading, take care to move hair and wipe
perspiration from the forehead.

Visiomed - Kaufman KM-25 - V.2.3 -201012 10/21
VI. DESCRIPTION OF THE KAUFMAN KM-25 THERMOMETER
Infrared sensor
LCD screen
Measure button
mesure
Battery compartment
Advanced configuration
buttons

Visiomed - Kaufman KM-25 - V.2.3 -201012 11/21
VII. FUNCTIONS
1. Designed to take body temperature readings.
2. Stable and reliable results due to advanced infrared system using automatic calibration.
3. Alarm sounds if temperature is exceeded.
4. Display of measurement results :
-Measurement range : from 32.9°C to 42.9°C (89.6°F to 109.2°F)
-"HI" is displayed for results above 42.9°C (109.2°F).
-"LO" is displayed for results below 32.9°C (89.6°F).
5. Memory for the last 32 temperature readings.
6. Measurement and display of ambient temperature: Variable effective measurement range of 10°C to 40°C (50.0°F to
104.0°F).
7. Temperature displayed in Celsius or Fahrenheit.
8. Automatic power off (power save).
OTHER APPLICATIONS :
In Surface mode the KM-25 can take the temperature of the bath, bottle etc.
In Room mode the KM-25 can also measure the ambient temperature of a room.
The results are read aloud in voice mode.
Note: The alarm threshold default value is 38°C (100.4°F).

Visiomed - Kaufman KM-25 - V.2.3 -201012 12/21
VIII. SETUP &MENU FUNCTIONS
OPTION BUTTONS
The KM-25 thermometer is specially designed to take the body temperature
of children or adults without touching the body. It can be used at home or by
health professionals. To take body temperature use the “BODY”function.
The thermometer can also be used to measure the surface temperature of an
object, food or liquids by pressing the “SURFACE”button.
Press the “ROOM”button to measure the ambient temperature of a room.
BODY BUTTON
Press to enable “BODY”mode.
BODY mode measurement range: from 32.9° C to 42.9° C
SURFACE BUTTON
Press to enable “SURFACE”mode.
SURFACE mode measurement range: from 0° C to 100° C.
ROOM BUTTON
Press to enable “ROOM”mode.
ROOM mode measurement range: from 0° C to 100° C.
IMPORTANT : surface temperature is
different to internal body temperature.
Internal body temperature should always be
taken using the BODY function.
Always use the BODY function to take
internal temperature and the SURFACE
function for external temperature (e.g.
baby’s bottle, bath, bedroom etc.).
Ambient
temperature
Surface Mode
Body Mode
Menu
Programming buttons

Visiomed - Kaufman KM-25 - V.2.3 -201012 13/21
SETTING UP THE KAUFMAN KM-25 THERMOMETER
1. TEMPERATURE UNITS
Press the PROG button for 3 seconds, the screen will show: C-F.
Press ‘-’ to choose Celsius, or ‘+’ for Fahrenheit.
Confirm selection by pressing the PROG button.
2. TOTAL TEMPERATURE VARIATION
TO ADJUST THE TOTAL TEMPERATURE VARIATION OF THE THERMOMETER
The total temperature variation can be set for each measurement mode.
To do this, select the temperature measurement mode (Body, Surface or Room).
Press the PROG button for 3 seconds, the screen will show: C-F.
Press the PROG button again and TOF will be displayed on the screen.
Press ‘+’ to increase variation by 0.1°C, ‘-’ to reduce by 0.1°C
Confirm selection by pressing the PROG button.
If you are not sure, it is recommended to leave the total variation as +0.0°C (default setting).
Following any significant change in the ambient temperature (± 10°C) the thermometer should be left at room
temperature for at least 15 minutes before use to allow automatic recalibration of the device.
3. EXIT SETUP MODE
Press the PROG button until the screen switches off.
Ambient
temperature
Surface Mode
Body Mode
Menu
Programming buttons

Visiomed - Kaufman KM-25 - V.2.3 -201012 14/21
b: Body Mode
S: Surface Mode
M : Memory
01-32 : Index
4. DATA MEMORY
To display the last saved temperature measurements
press the ‘-’button for 3 seconds.
This will display the last temperature measurement.
To scroll through saved measurements press the ‘+’
button.
The number shown at the top of the screen indicates the
measurement number.
Press the ‘-’ button to go back.
To exit the memory menu press the measure button.
The thermometer switches off after 5 seconds.
5. CHANGING BATTERIES
Display: When the LCD screen shows the icon, the battery is empty.
Action: Open the cover and replace the empty batteries taking care to observe the correct polarity. Incorrect
battery polarity could damage the device and invalidate the warranty.
Do not use rechargeable batteries, use single use batteries only.
Do not dispose of used batteries in household waste. Take your used batteries to a specialist collection.
If the device will not be used for an extended period, be sure to remove the batteries to ensure they do
not leak and damage the device.

Visiomed - Kaufman KM-25 - V.2.3 -201012 15/21
IX. TECHNICAL &PRECISION INFORMATION
1. Normal operating conditions :
Operating temperature:
Body temperature: 10°C ῀ 40°C
Surface temperature: 0°C to 50°C
Humidity : 10~93% RH
2. Power : DC 3V (2 AAA batteries)
3. Dimensions : 170 x 57 x 37 mm (L x W x H)
4. Weight : 105g (without batteries)
5. Display resolution : 0.1°C
6. Measurement range :
Body mode : 32.9°C - 42.9°C
Surface mode : 0°C - 100.0°C
Room mode : 0°C - 100.0°C
7. Consumption : ≤ 50mW
8. Precision :
Body mode:
In a normal environment: ≤ ±0.3°C
Surface mode:
From 22 to 42°C: ≤ ±0.3°C
Above these temperatures ≤ ±2°C
Room mode:
From 10 to 40°C : ≤ ± 0.5°C
above 40°C : ≤ ±2°C
9. Time taken per measurement : ≤ 0.8s
10. Time for repeat measurement : ≤ ±0.2s
11. Length of infrared waves : 5-14µm
12. Measurement distance : 5 cm –10 cm
13. Automatic power off: 20 seconds.
PRECISION OF THE KM-25
The Kaufman KM-25 thermometer can take
temperature readings below 32.9°C or above 42.9°C.
Precision is not guaranteed for readings in these
temperature ranges.
LONGEVITY OF USE
The Kaufman KM-25 thermometer is guaranteed to
last for 40,000 measurements.

Visiomed - Kaufman KM-25 - V.2.3 -201012 16/21
X. ADVICE
-The infrared sensor (lens) is the most important and most fragile part of the thermometer, please take care of it.
-Clean the lens with a cotton cloth, moistened with water or 70° rubbing alcohol.
-Only use recommended batteries, do not recharge non-rechargeable batteries and do not thrown in fire.
-Remove batteries when the thermometer will not be used for an extended period of time.
-Do not expose the thermometer to sunlight or water.
-Impacts can damage the device.
XI. SUPPLIED ACCESSORIES
User Manual
Quick user guide
Warranty Card
Protective case
Batteries (AAA)
XII. TROUBLESHOOTING
No response
Check the batteries (polarity, usage)
The icon is displayed
Change the batteries. Check that the polarity is correct when replacing. Incorrect polarity could damage the device.
Results are not read aloud
If the batteries are flat Voice mode will go into power save mode and will not read out the results.
Check the batteries.

Visiomed - Kaufman KM-25 - V.2.3 -201012 17/21
Result too high / too low
Check if the total variation has been modified (see page 13). Default setting is : 0.0
The thermometer can compensate for temperature differences due to changes in environment. Leave the thermometer in
the ambient temperature for at least 15 minutes before use, to allow auto recalibration of the device.
“Hi” is displayed on the screen (above 42.9°C (109.3°F))
The temperature reading is above the measurement range for the selected mode, over 42.9°C in BODY mode, 120°C in
SURFACE mode, or 100°C in ROOM mode.
“Lo” is displayed on the screen (result obtained is below 32.9°C or 89.6°F)
The temperature reading is below the measurement range for the selected mode: 32.9°C for BODY mode or 0°C in
SURFACE / ROOM mode
Cause of Lo Message
Advice
Temperature reading affected by hair, perspiration
etc.
Make sure that the forehead is clear before taking a
temperature reading.
Temperature reading affected by a draft.
Make sure there are no drafts as this could interfere with the
infrared system.
Temperature readings too close together, the
thermometer did not have the chance to reset itself.
Wait at least 15 seconds between readings –a 1 minute pause
is advised.
The measurement distance too far.
Ensure you use the device at a suitable distance (between 5
and 10 cm)

Visiomed - Kaufman KM-25 - V.2.3 -201012 18/21
GUARANTEE
KAUFMAN will repair or replace this product free of charge in the case of defective parts or manufacturing defects, in accordance with
the conditions mentioned below as follows:
DURATION: 24 MONTHS RETURN TO WORKSHOP
LIMITS AND EXCLUSIONS:
This guarantee concerns only the original final purchaser. A purchase invoice, or another proof of purchase, with this guarantee card
will be required to obtain an after-sales service, in accordance with this guarantee.
This guarantee card will not be extended to another person only the original final purchaser.
This guarantee becomes void if the serial numbers on the product are modified, replaced, illegible, absent, or if repair has been
carried out by a service not approved, including the user.
This guarantee covers only the defects of the material or parts, occurring during normal use of the product. It does not cover the
damage caused during the transport of the apparatus, causes due to repairs being carried out by the distributor, by any
modifications undertaken, any connection of equipment not approved by Kaufman, or causes contrary to those written in the user
manual or notice. Moreover, the present guarantee does not cover damage due to falls, bad handling, bad installations, damage by
fire, floods, lightning, or any other natural disaster.
This guarantee does not cover the packing of the material, the accessories, the defects caused by commercial exposure of the
product, show room, sale space, demonstration etc. normal maintenance, cleaning and the replacement of parts where wear is
normal, are not covered by the terms of this guarantee.
Kaufman and its representatives and agents will not in any case be held responsible for any damage and consecutive damages due
to the mishandling of this product
This guarantee is the only valid one at Kaufman, any other guarantee (commercial guarantee) except this one will not be taken into
account.
IMPORTANT:
During the guarantee period if you are dissatisfied with the repairs of this product, please contact the Kaufman customer service
IN CASE OF PROBLEMS, PLEASE CONTACT OUR CUSTOMERS SERVICE:
KAUFMAN CUSTOMERS SERVICE :French, English HOTLINE : [phone]
This warranty Card will not be re-emitted

Visiomed - Kaufman KM-25 - V.2.3 -201012 19/21
Purchase date:
Serial Number:
Retailer’s seal:
This warranty Card will not be re-emitted
SN : ………………………………….
Date : ….. / …… / ……..
Stamp:

Visiomed - Kaufman KM-25 - V.2.3 -201012 20/21
English
Disposal of Waste Equipment by Users in Private Households in the European Union
The symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your
responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic
equipment. The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources and ensure that
it is recycled in a manner that protects human health and the environment. For more information about where you can drop off your waste equipment for
recycling, please contact your local city office or your household waste disposal service.
French
Deutsch
Español
The thermometer Kaufman KM-25 meets the requirements of the European Directive (93/42/EEC) concerning medical devices and is CE0482
certified.
0482
