HoldPeak HP2150 User manual

Non-con tac t in frared thermometer
Instru ction ma nual
9
V
DC IN
--01 --02 - -03
F
MODEL 200 TO 2150 392 TO 3902: ℃ ℃（ ）
1.Introduction:
Compact,rugged and easy to use.Just aim and push the
button,read current surface temperatrue in less than a
second.Safely measuere surface temperature of
hot,hazardous or hard-to-reach objects without contact.
2.How it works:
Infrared thermometer measures the surface temperature
of an object.The unit’s optics sense emitted,reflected,and
transmitted energy which is collect and focused onto a
detector.The unit/s electronics translate the information
into a temperature reading which is displayed on the unit.
For increased ease and accuracy the laser pointer makes
aiming even more precise.
3.Cautions:
Infrared thermometer should be protected for the following:
-EMF(electro-magnetic fields) from arc welders,induction-
heaters.
-Thermal shock(carse by large or abrupt ambient temperture
changes allow 30 minutes for unit to stabilize before use )
-Do not leave the unit on or near objects of high temperture.
-Static electricity.
4.Warning:
-Do not point laser directly at eye or indirectly off dflective
surfaces.
-The unit cannot measure through transparent surfaces such
as glass or plastic.It will measure the surface temperature of
these materials instead.
-Steam ,dust ,smoke,or other particles can prevent accurate
measurement by obstructing by the units optics.
Table of approximate emissivity:
Marterial Emissivity Marterial Emissivity
Aluminum 0.30 Iron 0.70
Asbestos 0.95 Lead 0.50
Asphalt 0.95 Limestone 0.98
Basalt 0.70 Oil 0.94
Brass 0.50 Paint 0.93
Brick 0.90 Paper 0.95
Carbon 0.85 Plastic 0.95
Ceramic 0.95 Rubber 0.95
Concrete 0.95 Sand 0.90
Copper 0.95 Skin 0.98
Dirt 0.94 Snow 0.90
Frozen food 0.90 Steel 0.80
Hot food 0.93 Textiles 0.94
Glass(plate) 0.85 Water 0.93
Ice 0.98 Wood 0.94
D:S=80:1 33mm@
2.6m
86mm@
6.8m
126mm@
10m
1.3"@
104 "
3.5"@
280" 5.0"@
400 "
D
S
(figure1)
A
B
C
DE
F
G
LOW HIG H
DATA
H
J
IK
5.Operation Instruction:s
-When take measurement ,point thermometer toward the
object to be measured and hold the yellow trigger.The object
under test should be larger than the spot size calculated by the
field of view diagram.
-Distance & spot size:As the distance from the object
increase,the spot size of measuring area becomes larger.
-Field of view:Make sure the target is larger than the unit’s
spot size. The smaller target the closer measure
distance.When accuracy is critical,make sure the target is at
least twice as large as large as the spot size.
-Emissivity:Most organic materials and painted or oxidized
surfaces have an emissivity of 0.95(pre-set in the
unit).Inaccurate readings will result from measuring shiny
or polished metal sur faces.To compensate for this,adjust
the units emissivity reading(see table below and 5.3
settings) or cover the surface to be measured with
masking tape or flat black paint.Measure the tape or
painted surface when the tape or painted reach the same
temperature as the material underneath.
6. Quick start instruction:
6.1 LCD display
A- measuring reading B- measuring unit
C- laser on icon D- back light on icon
E- battery power icon F- scanning icon
G-Hold data icon H- mode/emissivity indicator
I -data storge/read icon J- low temperature alarm icon

(figur e 2)
--04 - -05 - -06
9V
DC IN
(12)Laser
(9)-Battery Door
(11)-9V Batter y
(10)-Clesius Fahrenh eit
slide switch
/
FU NC
SET
SET
STO:data storage—when selected STO,lock & DATA & 1---
indicator will shown when press key once,one d
SGN:single data mode.
PLY: Data replay out.
EMS:Emissivity setup—press key for emissivity
settings press key or key to adjust
emissivity and press key save setup and back
to normal status.
(2)Laser/back light button:when back light turn on ,any
operations will remain back light for 10 sec.LCD
indicate on/off status.
(7) LCD (see 6.1)
(8) Battery door clip
(9) Battery door:When replace battery ,please press batter y
door clip,pull down and forward the batter y door.Then
install 9v battery correctly.
(10) Clesius/Fahrenheit switch :Please open battery and push
the slide switch for convertsion
(11)9V batter y.
(12)Laser modul.
ata
stored memor y.Press key 1 second,it contuine store
the data.
CLR:Data clear mode ,press key 2 seconds to clear
all data in the mem or y.
Data recall:
a. In “PLY” mode :press key to replay data in
the memor y.
b. Press key and key for quick look the
memoryes data.And then output the data to PC.
Lock & unlock:IN measure mode,Press the
(1)key(Trigger)and press key once that lock &
unlock function convert.LCD display” -lock ; -
unlock “.
6.2 Locating a hot/cold spot:To find a hot/cold spot ,aim the
thermometer outside the area of interest,then scan
across with up and down motion until you locate the
hot/cold spot.See figure 2.
Measure ranges:
Measure accuracy
80:1
Repeatability 1% of reading or 1℃
Response time
200 392 F to 450 842 F 2 or 2
450 842 F to 1100 2012 F) 3 or 3
1100 2012 F) to 2150 3902 F) 4 or
3 whichever is greater
℃( ) ℃( ) ± ℃ ± %
℃( ) ℃( ± ℃ ± %
℃( ℃( ± ℃
± %
200 to 2150 392 to 3902 F℃( )
Spectral response
150mSec,95% response
Emissivity
900-1700nm
Ambient operating range
0.1 to 1.00 adjustable(pre-set 0.95)
Relative humidity
0 to 40 32 to 104 F℃( )
Storage temperature
10-80% RH noncondensing
Weight/Dimensions
-20 to 60 85%RH ,without battery ℃, ≤
Power
480g; 220*134*60mm
Battery life(Alkaline)
9v Alkaline or NICd battery or 9v 500mA adpter
Dis tance to Spot Size
Laser Models:10hrs
Model HP2150
9V
DC IN
9V
DC I N
(figur e 3)
(8)
LOG
UPDOWN
LOG
DC IN PUT interface(DIA.=1. 3mm)
RS-232 input inter face
To thermometer scoket
To PC RS232 scoket
11.Specifications:
9.Maintenance:
10.Note:
--Lens cleaning:Blow off lose particles using clean
compressed air ,Gently brush remaining debris away
with a moist cotton cloth.
--Case cleaning:Clean the case with a damp sponge cloth
and mild soap.
--Do not use solvent to clean lens.
--Do not submerge the unit in water.
--Do not use/place the unit in high temperature or moist
environment,that might inflect the units performance.
--Do not change circuity of the unit ,that possibly will
destruct the unit/endanger.
--When icon display, means low battery power .Please
replace new batter y to prevent inaccurate measuring.
--If unit not being use for long period,please unload the
battery.
8.RS-232 & DC IN PUT interface:
When connected this unit with PC, DATA will display on
LCD.During taking real time measurment,AUT will blink on
LCD.
7.Diagram description:(See figure 3 and figure 4)
(1)Trigger:When turn on LCD display VERXX software version
for 1 sec.And turn to display reading with SCAN icon.
Release the trigger,display reading with HOLD icon.Built
in auto power off in 30 sec.
(2)-(6) key functions:
press key ,LCD subdisplay blinks MAX –MIN –DIF
–AVG –HAL –LAL -STO segment(only
main display means normal measuring mode) press
key to enter.
MAX: measuring maximum temperature
MIN: measuring minimum temperature
DIF:Basic on the reading before press 4 key,compute the
difference of current reading
AVG:measuring average temperature
HAL:high temperature alarm—when selected HAL,press 5
keys to set high temperature alarm trigger an
dconfirmed by pressing 4 key,When reading over
trigger ,LCD display HI icon with BiBi audio sounds.
LAL:low temperature alarm-when selected LAL,press 5
keys to set low temperature alarm trigger and
confirmed by pressing 4 key.When reading over
trigger,LCD display LOW icon with BiBi audio sounds
SGN EMS PLY-CLR- -
(1)
(7)
(5)
(5)
(4)
(6)
(3)
HOLD
SET
UP
DO WN
FUNC
(figure 4)
--For software installation and intructions,please read the
User Guide on CD.
--DC input:For saving battery consumption,please use 9V
200mA adapter on long period measurement.(Polarity
show on scoket label)
UPDOWN
UPDOWN
