KaVo SONICflex quick 2008 User manual

Instructions for use
SONICflex quick 2008 - REF 1.005.9311
SONICflex quick 2008 L - REF 1.005.9310

Distributed by:
KaVo Dental Corporation
11729 Fruehauf Drive
Charlotte, NC 28273 USA
Tel.: [phone]
Fax: [phone]
Manufacturer:
Kaltenbach & Voigt GmbH
Bismarckring 39
D-88400 Biberach
www.kavo.com

Contents
1 User instructions ............................................................................................................................................... 5
2 Safety ............................................................................................................................................................... 7
2.1 Description of safety instructions ............................................................................................................ 7
2.1.1 Description of safety instructions: Warning symbol ................................................................... 7
2.1.2 Description of safety instructions: Structure .............................................................................. 7
2.1.3 Description of safety instructions: Description of danger levels ................................................ 8
2.2 Safety instructions .................................................................................................................................. 9
2.2.1 Safety instructions: SONICflex tips ......................................................................................... 12
3 Product description ......................................................................................................................................... 15
3.1 Purpose – Intended use ....................................................................................................................... 17
3.2 Technical data ...................................................................................................................................... 19
3.3 Transportation and storage conditions ................................................................................................. 20
Contents 1

4 Start up and shut down .................................................................................................................................. 22
4.1 Checking the amount of water .............................................................................................................. 24
4.2 Connecting to devices .......................................................................................................................... 25
4.3 Mounting the MULTIflex (LUX) / MULTIflex LED coupling ................................................................... 25
4.4 Check O-rings ...................................................................................................................................... 26
4.5 Check pressures .................................................................................................................................. 27
5 Operation ........................................................................................................................................................ 28
5.1 Attaching SONICflex ............................................................................................................................ 28
5.2 Removing SONICflex ........................................................................................................................... 30
5.3 Inserting SONICflex tip ......................................................................................................................... 31
5.4 Removing SONICflex tip ...................................................................................................................... 33
5.5 Power setting ........................................................................................................................................ 34
5.6 Regulating spray .................................................................................................................................. 34
Contents 2

6 Preparation methods according to ISO 17664 ............................................................................................... 35
6.1 Preparations at the site of use .............................................................................................................. 35
6.2 Cleaning ............................................................................................................................................... 36
6.2.1 Cleaning: Manual cleaning - external ...................................................................................... 37
6.2.2 Cleaning: Automated external cleaning ................................................................................... 38
6.2.3 Cleaning: Manual cleaning of the inside .................................................................................. 39
6.2.4 Cleaning: Automated internal cleaning ................................................................................... 40
6.3 Disinfection ........................................................................................................................................... 41
6.3.1 Disinfection: Manual disinfection - external ............................................................................. 42
6.3.2 Disinfection: Manual disinfection - internal .............................................................................. 43
6.3.3 Disinfection: Machine disinfection - external and internal ....................................................... 43
6.4 Drying ................................................................................................................................................... 45
6.5 Care products and systems - Servicing ................................................................................................ 46
6.5.1 Care products and systems - Servicing: Torque wrench care ................................................. 47
Contents 3

6.5.2 Care products and systems - Servicing: Servicing with KaVo Spray ...................................... 49
6.5.3 Care products and systems - Servicing: Servicing with KaVo QUATTROcare 2104 /
2104A ...................................................................................................................................... 49
6.5.4 Care products and systems - Servicing: Servicing with KaVo QUATTROcare PLUS ............. 51
6.6 Packaging ............................................................................................................................................. 52
6.7 Sterilisation ........................................................................................................................................... 53
6.8 Storage ................................................................................................................................................. 56
7 Tools and consumables ................................................................................................................................. 57
8 Terms and conditions of warranty .................................................................................................................. 65
Contents 4

1 User instructions
Dear User
Congratulations on purchasing this KaVo quality product. By following the
instructions below you will be able to work smoothly, economically and
safely.
© Copyright by KaVo Dental GmbH
Symbols
Refer to the chapter on Safety/Warning symbol
Important information for users and service technicians
User instructions 5

Action request
CE mark (European Community). A product bearing this mark
meets the requirements of the applicable EC directive.
Can be steam-sterilised at 134 °C -1 °C / +4 °C (273 °F -1.6 °F /
+7.4 °F)
Thermodisinfectable
Target group
This document is intended for dentists and their assistants. The section
on starting up is also intended for service technicians.
User instructions 6

2 Safety
2.1.1 Description of safety instructions: Warning symbol
Warning symbol
2.1.2 Description of safety instructions: Structure
DANGER
The introduction describes the type and source of the hazard.
This section describes potential consequences of non-compliance.
▶The optional step includes necessary measures for hazard preven‐
tion.
Safety 7

2.1.3 Description of safety instructions: Description of danger levels
The safety instructions listed here, together with the three levels of
danger will help avert property damage and injury.
CAUTION
CAUTION
indicates a hazardous situation that can cause damage to property or
mild to moderate injuries.
WARNING
WARNING
indicates a hazardous situation that can lead to death or fatal injury.
Safety 8

DANGER
DANGER
indicates a maximal hazard due to a situation that can directly cause
death or fatal injury.
2.2 Safety instructions
WARNING
Hazard to the care provider and patient.
In case of damage, irregular noise during operation, excessive vibration,
atypical heating or when the tip cannot be firmly held.
▶Stop working and contact service support.
Safety 9

CAUTION
Premature wear and malfunctioning from improper storage during long
periods of nonuse.
Reduced product life.
▶The medical device should be cleaned, serviced and stored in a
dry location, according to instructions, before long periods of non‐
use.
Note
When the SONICflex is in the holder, the torque wrench should be
placed on the tip to protect against injury.
Safety 10

The following individuals are authorized to repair and service KaVo prod‐
ucts:
▪ Technicians at KaVo branches throughout the world
▪ Technicians specially trained by KaVo
To ensure proper function, the medical device must be set up according
to the reprocessing methods described in the KaVo Instructions for Use,
and the care products and care systems described therein must be used.
KaVo recommends specifying a service interval at the dental office for a
licensed shop to clean, service and check the functioning of the medical
device. This service interval depends on the frequency of use and should
be adjusted accordingly.
Service may only be carried out by KaVo-trained repair shops using origi‐
nal KaVo replacement parts.
Safety 11

2.2.1 Safety instructions: SONICflex tips
CAUTION
Risk of injury and infection when changing the SONICflex tips.
This can substantially endanger the user.
▶To test, use and remove the SONICflex tips, use a glove or other
finger protection.
Note
We recommend replacing the SONICflex tips every 9-12 months.
Safety 12

Note
Regularly check the wear of the tip with the tip test card
(Mat. no. 1.001.6958).
Safety 13

The tips may break from continuous stress or damage (such as being
dropped on the floor or being bent). Therefore, check the tip to see if it is
safe before each use by applying a slight amount of pressure with your
thumb or index finger.
▶ For an additional safety check, mechanically apply approx. 10 N (1
kg) to the tip without operating the device.
Safety 14

3 Product description
SONICflex quick 2008 (Mat. no. 1.005.9311)
SONICflex quick 2008 L (Mat. no. 1.005.9310)
Product description 15

The SONICflex is a dental handpiece in accordance with ISO 15606. The
vibrations are generated by a rotating steel sleeve. In combination with
the different KaVo tips, an oscillating elliptical tip motion is generated for
the respective application. The internal water cooling (spray cooling) pre‐
vents the treatment field from heating up, and keeps the treatment sur‐
face clean.
Note
The device should be operated with the described operating pressure.
After starting, the intensity can be regulated using the foot switch at
maximum drive pressure.
Product description 16

3.1 Purpose – Intended use
Purpose:
This medical device is
▪ Only intended for dental treatment. Any other type of use or altera‐
tion to the product is impermissible and can be hazardous.
The SONICflex can be used in conjunction with KaVo tips for plaque
removal, prophylaxis, endodontics, periodontology, surgery and con‐
servative dentistry.
▪ A medical device according to relevant national statutory regulations.
Product description 17

Proper use:
According to these regulations, this medical device may only be used for
the described application by a knowledgeable user. The following must
be observed:
▪ the applicable health and safety regulations
▪ the applicable accident prevention regulations
▪ these instructions for use
According to these regulations, it is the responsibility of the user to:
▪ only use equipment that is operating correctly,
▪ use the equipment for the proper purpose,
▪ protect him or herself, the patient and third parties from danger, and
▪ avoid contamination from the product.
Product description 18
