KBT GRAND THRONE User manual

Squat for health. Squat for life.
G
r
a
n
d
T
h
r
o
n
e
75
100
15
4
65
0
100
0
GRAND THRONE
Instruction Manual
Assembly and instructions for your Grand Throne.
Gently lowering you down and then
lifting you back up again.
www.babythrone.co.za

Keep your vitality. A life without
health is like a river without water.
The Grand Throne was designed to meet a real need. Through
our work with the Baby Throne, we learned that there was a
real need for more independence, dignity and health in the
bathroom and around the home for all ages.
We discovered that there are times in our lives when moving
from a standing position to a sitting position, and back up
again, is a real challenge.
The Grand Throne offers secure help in gently lowering you
down into that optimal seated position and lifting you back
up to a standing position again.
We hoped that by creating the Grand Throne we would give
people of all ages access to that freedom and dignity in their
own homes. The Grand Throne can be used in the bathroom
(toilet and shower) and around the home.
Using the Grand Throne in the home as part of medical care
will not only give you privacy and dignity, it will also support
your colon health and comfort.
Zoë Durbach MSc MBA
Inventor, Engineer, Owner,
Mother and Daughter.
Introduction Contents
04 Uses
05 Health Facts
06 Key Parts
08 What’s in the Box
09 Assembly Instructions
11 Instructions: Using the Grand Throne Squat Seat
12 Instructions: Using the Standard-Sized Seat
13 Care and Safety
15 Guarantee
14 Important Information
Maxime Lagacé
Watch the video to see how to
assemble the Grand Throne.
Watch the video to see how to
use the Grand Throne.

Independence
Medical Care
Multiple Uses
04 05
Uses Health Facts
The Grand Throne frame provides both versatility and safety. The Grand Throne
supports the user from the back and the sides to ensure safety and stability, while the
handrails provide the option of additional support. The Grand Throne can be used
with either standard-sized toilet seat or with the Grand Throne Squat Seat (depending
on preference and comfort). The standard-sized toilet seat offers a 90 degree seated
angle whereas the Grand Throne Squat Seat offers an optimal seated position for
enhanced colon health. In cases of more complex needs, a medical professional can
advise you on what is appropriate for your individual medical needs.
The gas-lifts gently lower you down as you lean back into the toilet seat. These gas-lifts
also lift you back up again as you lean forward into a standing position. The amount
of lift required is a personal choice and generally depends upon the weight of the
individual. You can choose from the 3 models’, 100N (suitable for uses from 50kg to
60kg) or the 200N (suitable for users from 60kg to 90kg) or 300N (suitable for users from
90kg to 120kgs) individuals. The Grand Throne adds approximately 5 cm to the height
of a standard toilet. If this is too high for you simply use a step-up of your choice.
Sitting in the correct position is vital for colon health. Medical research shows that the
optimal squat position not only relaxes the puborectalis muscle (therefore triggering
the urge to push) but also enables the bowels to fully empty. The optimal squat
position prevents and eases constipation as it keeps the puborectalis muscle in a relaxed
position as the bowel empties.
Whether injured, frail or
convalescing, the Grand Throne
offers secure help in gently lowering
you down into that optimal seated
position and lifting you back up to a
standing position again.
In these images the Grand Throne is not fitted with a standard-sized toilet seat–or the
Throne Squat Seat–as it is easier to see how the Throne can be used for different purposes.

06 07
Key Parts
Back Rest: Comfortable
and secure back rest that
prevents falling backwards.
Brake Handles: Once
seated, you can lock
the seat in the ‘down
position’ and when
you wish to stand
up again simply turn
outwards to release
the locks and lean
forward.
Gas Lifts:
Designed to
gently lower
you into the
seated position
and gently lift
you back up
into a standing
position.
Supporting Frame:
For both the
Grand Throne
Squat Seat or a
standard-sized
toilet seat.
Main Frame: The
brake handles
must be turned
outwards. This
indicates which is
the left side and
which is the right
side of the frame.
01
02
03
08
04
05
The greatest wealth is health.
01: Back Rest
02: Brake Handles
03: Gas Lifts
04: Supporting Frame for Grand Throne
Squat Seat or standard-sized toilet seat (seat frame)
05: Main Frame
06: Bolts
06a: 2 inch bolts and screws x4
06b: 4 inch bolts and screws x8
07: Foot Rest
08: Wheels
07
1. Back Rest: Comfortable and secure back rest that prevents falling
backwards
2. Brake Handles: Once seated you can lock the seat in the ‘down position’
and when you wish to stand up again, simply turn the brake handles
outwards to release and lean forward. Use the brake handles to know
which side of the frame is the left and which is the right side of the
frame. Handles must turn outwards.
3. Gas-Lifts: Designed to gently lower you into the seated position. Once
the brakes have been released and you lean forward; they gently lift you
back up into a standing position.
4. Supporting Frame for the Grand Throne Squat Seat or a standard-sized
toilet seat: This seat frame has standard fittings for any standard-sized
toilet seat. The 4 short bolts attach the supporting frame to the main
frame.
5. Main Frame: There is a left and a right side. The brake handles must turn
outwards to show which is the left side and which is the right side of the
frame.
6. Bolts: The 4 short bolts secure the seat frame onto the main frame of
the Grand Throne. The 8 long bolts secure the seat back rest to the main
frame and the foot rest to the main frame.
7. Foot Rest: Supports you while sitting. It is not for standing on!
8. Wheels: Designed to help move the Grand Throne. Simply lift the front
of the Grand Throne to activate the wheels.
The Poet - Virgil

08 09
Assembly InstructionsWhat’s in the Box
Although not essential, it is easier if two people assemble the
Grand Throne. One person to hold the sides of the frame, and the other
to fasten the 12 bolts. Assembly is very easy and assembly time
is approximately 15 minutes. Before you start the assembly decide if you
would like a standard-sized toilet seat or the Grand Throne Squat Seat and
secure this to the seat frame.
1. Hold the left and the right sides of the frame vertically. Ensure the brake
handles turn outwards.
2. Secure the back rest frame onto the two side frames, using 4 of the long bolts.
3. Secure the foot rest onto the side frames, using the remaining 4 long bolts.
4. Slide the back rest onto the back rest frame.
5. Secure the seat frame onto the Grand Throne frame, using the 4 small bolts.
Bolts
Tools:
01
03 >
02
Assembly for the normal seat and the Throne Squat Seat is the same.
01
02
03
04
05
06 07
08
09
10
1. Back Rest
2. Brake Handles
3. Gas-Lifts
4. Supporting Frame
for the Grand
Throne
5. Main Frame
6. Bolts
7. Foot Rest
8. Wheels
9. Standard-sized
toilet seat
10. Grand Throne
Squat Seat on
seat frame
Bolts: The 4 short bolts
(06a) secure the seat frame
onto the main frame of
the Grand Throne. The 8
long bolts (06b) secure the
seat back rest to the main
frame and the foot rest to
the main frame.
What you need: Spanner/wrench (size: 13)
and Allen Key (size: 5).
Step 1, 2 and 3 complete.
(06a)
(06b)

Instructions: Using the Squat Seat
The Grand Throne has been designed to be fitted with either the standard-
sized toilet seat or the Grand Throne Squat Seat and used over the toilet.
However, it can be used in the shower or elsewhere in the house.
Step 1: Gently lean back onto the seat while holding onto the supporting
bars of the frame. The seat will gently lower you into a seated or
squat position.
Step 2: Turn the brake handles inwards to lock the seat into position and
place your feet onto the foot rest for comfort.
Step 3: Once ready, turn the handles outwards to release the brake and
place feet onto the floor from the foot rest.
Step 4: Use the side bars to help you lean forward and lift yourself up
with the aid of the gas-lifts.
04
05
05
Allen Key Bolts: 4 in total
2 on each side to secure the
seat frame.
Assembly with the standard-sized toilet seat and the Grand Throne Squat Seat
is the same.
10 11
STEP 3
STEP 1
STEP 4
STEP 2
All steps completed. Lock on.
Lock off.

Care and Safety
The Grand Throne is not a toy. It is designed to help adults move from
a standing position to a seated position and back up again to a standing
position. To avoid injury ensure that the bolts are always secure as with any
moving parts it is possible for the bolts to become loose over time. Check
the bolts regularly. After use in the shower, wipe down your Throne with
a soft cloth. With good care the surface will not rust. Take care of your
Throne and it will take care of you!
We have taken great pride and care in creating the Grand Throne. All
parts are guaranteed for a year. The Grand Throne must only be used
for intended purposes; it is designed for adults’ use (children must be
supervised). It is essential that all foreign objects, fingers and materials
are kept away from any moving parts on the Grand Throne. Please follow
instructions carefully. Any issues, please contact us immediately.
Instructions: Using the Standard Seat
The Grand Throne (fitted with either the standard-sized toilet seat or
the Throne’s Squat Seat) has been designed to be used over the toilet.
However, it can be used in the shower or elsewhere in the house.
Step 1: Gently lean back onto the seat holding onto the supporting bars
of the frame. The seat will gently lower you into a seated or
squat position.
Step 2: Turn the brake handles inwards to lock the seat into position.
Place your feet onto the foot rest if you wish to raise your knees
further.
Step 3: Once ready, turn the handles outwards to release the brake and
ensure your feet are placed firmly on the floor.
Step 4: Use the side bars to help you lean forward and lift yourself up
with the aid of the gas-lifts.
STEP 3
STEP 1
STEP 4
STEP 2: - Note the angle of the knees when
feet are on the floor and when feet are on
the foot rest.
12 13
Lock on.
Lock off.

Important Information: Guarantee:
As with all of Knight’s Baby Training products the Grand Throne must be
used for intended purposes only. The Grand Throne is designed to be used
over the toilet and can also be used in the shower or elsewhere in the
house. It has been designed for adult use (children must be supervised).
Knight’s Baby Training (PTY) Ltd cannot be held responsible for incorrect
following of assembly instructions for any of their products or personal
injury as a result of misuse or lack of care.
In purchasing or using any products from Knight’s Baby Training (PTY) Ltd
you agree that under no circumstances we, and/or our offices, employees,
successors, shareholders, joint venture partners or anyone else working
with us shall be liable for any direct, indirect, incidental, consequential,
equitable, special, punitive, exemplary or any other damages resulting
from your use of our website including, but not limited to, all the content,
information, products, services and graphics presented on our website or
within our manuals.
Users of all items produced by Knight’s Baby Training (PTY) Ltd assume any
and all such risks associated with their use. All users must further agree
to not sue Knight’s Baby Training (PTY) Ltd, the Board of Directors, its
members individually, its officers, agents or employees for any claim for
damages arising or growing out of voluntary use of Knight’s Baby Training
(PTY) Ltd products.
If you encounter any problems whilst ordering from Knight’s Baby Training
(PTY) Ltd please do not hesitate to contact us through email:
[email protected]
Our warranty does not cover items used outside of the SA mainland and
does not include the cost of the hire of a replacement product(s). For
items purchased outside of mainland SA, we can provide a return to base
warranty at our discretion and at your cost.
Our warranties only provide coverage if you maintain or use the product
as directed. For example, our warranty covers only personal use - as
opposed to business use - of the product. If there are multiple users of
the product then we would not cover any product faults. Please note that
if you have made any modifications to the product then this invalidates
the manufacturer’s warranty and the Knight’s Baby Training (PTY) Ltd
guarantee.
It is our legal duty to supply products that are fit for purpose and meet
satisfactory quality requirements.
As a customer, it is your legal right to receive either a refund, repair or
replacement for products that are either faulty or not what you expected
as per the Consumer Rights Act.
We will offer resolutions based on the timelines outlined in the Consumer
Rights Act 2015 for products purchased from 1st October 2015 onwards.
1. If a fault has been confirmed with your new product within 30 days of delivery, you
can return it in exchange for a full refund.
2. If you find a fault with your product after the 30 day cut off (but within 6 months
of owning it) we have the choice to either repair or replace it for you. If this is not
possible we have the right to offer a partial refund or you can return the product
and receive a full refund.
3. If you find a fault after 6 months of owning the product and you can prove the
defect was present when we delivered it, we will follow the same processes that are
outlined in Point 2.
4. You can get advice regarding your legal rights from your local Citizens Advice Bureau
or Trading Standards Office. Nothing in these terms will affect your legal rights.
5. The manufacturers will supply a warranty in addition to your rights under the Sale of
Goods Act. You will receive a 1 year warranty which covers parts and labour.
6. Please also note that our warranties only cover domestic use; items for use in
commercial properties might not be covered.
14 15
