Kele ASG User manual

KELE • www.kele.com • FAX [phone] USA 888-397-5353 • International 901-382-6084
1
HANDHELD-PORTABLE ANALOG
SIGNAL GENERATOR
MODEL ASG
TM
DESCRIPTION
The Model ASG is a handheld, battery- or plug-in power
supply powered, pocket-size analog signal generator. It
generates a 0-10 VDC signal in increments of 1V or a 0-
20 mA signal in increments of 2 mA. The LED bar graph
visually indicates analog signal level. The Model ASG can
also continuously ramp to user-defined minimum or maxi-
mum values with user- defined ramp-time settings.
FEATURES
• Powered by 9V battery or plug-in power supply
• Pocket size
• Bar graph LED for signal display
• 0-20 mA (2 mA increments)
• 0-10 VDC (1 VDC increments)
• Ramp function to minimum and maximum values
• Variable ramp function timing
• Low battery indication
• User-defined auto shutoff times for battery
conservation
• Separate milliamp and voltage output jacks
• 6' (1.83m) leads with alligator clips
• Up to 30 hours continuous use on a single battery
• Perfect for loop-powered circuits and externally
powered circuits
2.4
(6.1)
0.85
(2.2)
4.7
(11.9)
mA Source
Output
in
(cm)
Voltage
Output
Programming
Buttons
mA Two-Wire
Transmitter
Output
External
Power
Power 9V battery or 120 VAC plug-in
power supply
Impedance
Voltage 1000Ωmin
Current 300Ωmax
Resolution
Current 2 mA
Voltage 1 VDC
Accuracy (72°F)
Current ±0.5% FS or ±0.1 mA
Voltage ±0.5% FS or ±0.05 VDC
Operating temp 32° to 122°F (0° to 50°C)
Weight 14 oz (0.4 kg) with accessories
Dimensions 4.7"H x 2.40"W x 0.85"D
(11.9 x 6.1 x 2.2 cm)
Output 0-20 mA (2 mA increments)
0-10 VDC (1 VDC increments)
Ramping time intervals 2-20 sec (2-sec increments)
Auto shutoff times 2-20 min. (2-min. increments)
Accessories included 9V battery, 120 VAC plug-in
power supply, 6' (1.83m) wire
leads, carrying case
SPECIFICATIONS
APPLICATIONS
• Troubleshooting transmitters, transducers, and
actuators
• Calibrating transducers, LPIs, and other analog
signal devices
DIMENSIONS / WIRING
November 2004
Top view
ASG with Carrying Case

Press and Release Press and hold until
action has occurred Press either
highlighted button
KELE • www.kele.com • FAX [phone] USA 888-397-5353 • International 901-382-6084
2
Adjusting the ASG is accomplished through buttons 1 through 4 on the front and verified through the LEDs on the
top of the ASG.
Analog Outputs
The ASG has three individual outputs-mA source, two-wire transmitter, and voltage output. The voltage output oper-
ates over a 0-10 VDC range. The "mA Source Output" will source a 0-20 mA signal powered by the battery sup-
plied with the ASG. The output labeled "mA two wire xmitter" requires an external power supply and is intended for
loop powered circuits.
Display
The LEDs on the top of the ASG verify the progress of all adjustments and indicate status of various functions of the
ASG.
The "Status LED" indicates normal operation, low battery, and ramp mode. When this LED is in the off state, it indi-
cates that the ASG is working normally. If the "Status LED" is lit continuously during normal operation, the battery is
low. The "Status LED" will blink whenever the ASG is in a ramping mode.
The "mA Over Load LED" will light whenever the circuit exceeds 300Ω. Note: This "Over Load LED" will light if the
leads are not connected to a device due to an open circuit.
The "Output LEDs" indicate the analog signal level, ramp times duration and programming, and auto off times. The
"Signal Level LEDs" are read as either mA or voltage with the appropriate scale. During ramping mode calibration,
the mA scale is used to represent time in seconds. For instance, 2 represents 2 seconds and 20 represents 20 sec-
onds. During the auto-off change mode the mA scale represents time in minutes. (See Auto-Off Function on page 4)
OPERATION
LEGEND
ASG
ANALOG SIGNAL GENERATOR
mA 2-WIRE
XMTR
mA SOURCE
OUTPUT
VOLTS
OUTPUT
KEY
CONTROLS
TM
Programming
Buttons
AUTO-RAMP
STEP TIME
mA V
20 10
18 9
16 8
14 7
12 6
10 5
8 4
6 3
4 2
2 1
0 0
mAOVER
LOAD
STATUS
OFF - NORMAL
BLINK - RAMP
ON - LOW BATT
Voltage Scale
Output LEDs
Status LED
Normal Operation = OFF
Low Battery = ON
Ramp Mode = Blinking
mA Overload LED
(lights whenever circuit
exceeds 300)
EXTERNAL
POWER
VALUE
DOWN
VAL UE
UP
SET RAMP STEP TIME SET RAMP END POINTS
1 2-3
POWER
ON ALL 3 TOGETHER = POWER OFF
TOGGLE RAMP ON/OFF
mA, Auto Ramp
Step Time,
and Auto Shut
Off Times
1234
WIRING
ASG
TM
Load
ASG
TM
(red)
(black)
(red)
(black)
Load
(red)
(black)
24 VDC
Supply
ASG
TM
Load
mA Source
Output
mA Two-Wire
Transmitter
Output
mA Source
Output
mA Two-Wire
Transmitter
Output
mA Source Output
Voltage Output mA Two-Wire XMTR Output
Note: All time selection is set using the mA scale to represent time in seconds or minutes.

KELE • www.kele.com • FAX [phone] USA 888-397-5353 • International 901-382-6084
3
ACTION INSTRUCTION VERIFICATION
On Press button #1 down until "Output 0 mA/VDC LED will be
LEDs" ramp up and back full scale continuously lit
(Figure 1a)
Off Press buttons 2, 3, & 4 simultaneously All LEDs will turn off
(Figure 1b)
FIGURE 1a FIGURE 1b
Power On/Off
SET-UP INSTRUCTIONS
ACTION INSTRUCTION VERIFICATION
Increase Output Press button #4 "Output LED" will increase
(Figure 2) to the next output level
Decrease Output Press button #1 "Output LED" will decrease
(Figure 2) to the next output level
FIGURE 2
Selecting the Output Level
The Ramping Function
The ASG will continuously ramp between two user-defined endpoints for a user-specified interval time between
each incremental step. The ASG is preprogrammed to ramp between 4 mA (2 VDC) and 20 mA (10 VDC) in 10-
second increments; however, custom incremental times and end points can be temporarily programmed into the
ASG.
ACTION INSTRUCTION VERIFICATION
Set Starting Point Press buttons #1 or 4 to Appropriate "Output LED"
desired starting output level will light
(Figure 3a)
Start Ramping Press and hold buttons #2 & 3 "Status LED" and "Output
(Figure 3b) LED" will blink alternately
Stop Ramping Press buttons #2 & 3 "Status LED" will stop blinking &
(Figure 3c) turn off, "Output LED" will light
continuously
FIGURE 3a FIGURE 3b FIGURE 3c
Ramping Start and Stop
Press and Release Press and hold until
action has occurred Press either
highlighted button

Press and Release Press and hold until
action has occurred Press either
highlighted button
KELE • www.kele.com • FAX [phone] USA 901-937-4900 • International 901-382-6084
4
SET-UP INSTRUCTIONS (CONTINUED)
The Auto-Off Function
ORDERING INFORMATION
MODEL DESCRIPTION
MODEL ASG mA/VDC Pocket-Size Signal Generator with Accessories
Setting the Ramp Signal Limits
FIGURE 4a FIGURE 4b
ACTION INSTRUCTION VERIFICATION
Enter Programming Mode Press & hold buttons #1 & 2 "Output LED" blinks at the
(Figure 4a) 10 mA position
Set Time Interval* Press buttons #1 or 4 "Output LED" blinks at the
(Figure 4b) correct time interval position
Enter 1st End Point Mode Press buttons #1 & 2 "Output LED" blinks twice
(Figure 4c) in succession
Set 1st End Point Press buttons #1 or 4 "Output LED" blinks twice at
(Figure 4b) first end point position
Enter 2nd End Point Mode Press buttons #3 & 4 "Output LED" blinks 3 times
(Figure 4d) in succession
Set 2nd End Point Press buttons #1 or 4 "Output LED" blinks 3 times in
(Figure 4b) 2nd end point position
Exit Ramp Programming Mode Press buttons #3 & 4 "Output LED" stops blinking
(Figure 4d) and lights continuously
* The Interval Times are based on the mA scale. Each position is
interpreted in seconds. For example, 10 mA represents 10 seconds.
FIGURE 4c FIGURE 4d
ACTION INSTRUCTION VERIFICATION
Enter Programming Mode Press & hold buttons #1 & 3 "Output LED" blinks 4 times
(Figure 5a) in succession
Adjust Auto Off Time* Press buttons #1 or 4 "Output LED" blinks 4 times at
(Figure 5b) newly adjusted time position
Exit Programming Mode Press buttons #1 & 3 "Output LED" stops blinking
(Figure 5c) and lights continuously
FIGURE 5a FIGURE 5b FIGURE 5c
* Auto Off times are based on the mA scale. Each position is interpreted in
minutes. For example, 10 mA represents 10 minutes.
