Kenco Multi-Lift User manual

Attachment Solutions
Multi-Lift®System
Operator’s Manual
Conforms to ASME B 30.20, BTH-1
Design Category B, Service Class 3

KENCO Multilift® Operation Manual
2
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
TABLE OF CONTENTS
Section I. General Information...................................................................................... 3
Section II. Safety........................................................................................................... 3
Section III. Identification of Major Components........................................................ 6
Section IV. Setup............................................................................................................ 7
Section V. Grip Adjustment. ....................................................................................... 7
Section VI. Opperation.................................................................................................. 9
Section VII.Maintenance.............................................................................................. 11
Section VIII. Inspection Criteria................................................................................ 12
Section IX. Parts/Drawings........................................................................................13
Section X. Warranty.....................................................................................................16
RECORD INFORMATION HERE
FOR REFERENCE
MODEL
ATTACHMENT
SERIAL NUMBER
BODY SERIAL
NUMBER
ATTACHMENT
ATTACHMENT
ATTACHMENT
SERIAL NUMBER
ATTACHMENT
SERIAL NUMBER
ATTACHMENT
ATTACHMENT
ATTACHMENT
SERIAL NUMBER
ATTACHMENT
SERIAL NUMBER
ATTACHMENT
SERIAL NUMBER
ATTACHMENT
ATTACHMENT

KENCO Multilift® Operation Manual
3
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
Section I. General Information
May we take this opportunity to thank you for purchasing the KENCO
Multilift®system. The Multilift®System provides the ultimate in below the hook
handling versatility and is quality engineered to provide years of trouble free, low
maintenance performance. Please read and fully understand this manual and
any additional attached documentation before attempting to setup, operate
or maintain the Multilift® system.
This manual should be made available to all persons who may use or
maintain the Multilift® system. For additional information, please feel free to
contact the service department at Kenco at 1-800-653-6069.
Section II. Safety
A. General
1. Safety practices described in this manual are intended as guidelines for safe
operation under most conditions and are supplementary to any and all rules
and/or laws governing any aspect of the KENCO Multilift® operation that are in
force in your area.
2. Before operating the KENCO Multilift®, you should have a clear understanding
of said laws and regulations to ensure compliance.
3. Throughout this manual there are parts tagged with one or more of the following
safety warnings. Particular care must be exercised with regard to these
statements.
This warning is used where there is a high probability
of death or serious injury if the instructions are not
followed correctly.
DANGER
!
This warning is used where there is a possibility of
injury to yourself or others if the instructions are not
followed correctly.
WARNING
!
This warning is used where there is a possibility of
damage to the machine if the instructions are not
followed correctly.
CAUTION
!

KENCO Multilift® Operation Manual
4
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
B. Personal Safety
1. Wear appropriate protective clothing and related safety equipment including
protective glasses, hardhat, gloves, protective shoes, hearing protection, and any
other equipment/devices dictated by job conditions.
2. Do not wear loose clothing, jewelry, or hairstyles that could become entangled in
the KENCO Multilift® or rigging hardware.
3. Keep hands, feet, and any other appendages clear of the Multilift® while in
operation
C. Operation Safety.
1. DO NOT ATTEMPT TO OPERATE OR PERFORM MAINTENANCE ON
THE MULTILIFT® UNTIL READING AND FULLY UNDERSTANDING
THIS MANUAL
2. MAINTAIN SAFE DISTANCE FROM LOAD - NEVER ALLOW
MULTILIFT® OR LOAD TO PASS OVER ANY PART OF A PERSON.
3. DO NOT USE A KENCO MULTILIFT® THAT HAS BEEN ALTERED
ACCIDENTALLY OR INTENTIONALLY, IN ANY WAY WITHOUT
INSPECTION BY QUALIFIED PERSONNEL.
4. DO NOT USE A KENCO MULTILIFT® FOR ANY TASK OTHER THAN
THE INTENDED PURPOSE OF THE DESIGN.

KENCO Multilift® Operation Manual
5
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
D. Pinch Points.
1. Due to the mechanical nature of the Multilift®, extreme care must be taken
to avoid placing hands, limbs, hair, or clothing on or near the lifter while in
operation.
2. Extreme care must be taken while adjusting the legs of the lifter. Keep
fingers, clothing, etc. clear of the gap(s) formed between the leg and core
structures.
3. AT NO TIME SHALL ANYTHING OTHER THAN THE HANDLES OF
THE LIFTER BE USED TO CONTROL THE ALIGNMENT, LOADED
OR UNLOADED, OF THE LIFTER.
4. USE ONLY THE HANDLES PROVIDED TO ADJUST THE LEGS OF
THE LIFTER.

KENCO Multilift® Operation Manual
6
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
Section II. Identification of Major Components
LIFT BAIL
INNER
CORE
LIFT ARM
OUTER CORE(S)
BALL PAD
ADJ. HANDLE
GRIP
HANDLE
TOOTH BLOCK

KENCO Multilift® Operation Manual
7
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
Section IV. Setup.
A. Check the lifter for any signs of damage incurred during shipping.
B. Record model and serial #of assembly and components.
C. Check all bolts for snugness.
D. Attach Multilift® to hoist.
1. Use as few rigging components (shackles, slings, chain, etc.) as possible.
2. ALL RIGGING COMPONENTS MUST HAVE A WORKING LOAD
LIMIT THAT IS EQUAL TO OR GREATER THAN THE COMBINED
WEIGHT OF INTENDED LOAD PLUS THE KENLIFT®.
3. UNDER NO CIRCUMSTANCES SHOULD ANY COMPONENT USED
AS RIGGING TO THE MULTILIFT® BE OF A RATED CAPACITY
LESS THAN THAT OF THE KENLIFT®.
4. DO NOT RIG UNPROTECTED NYLON SLINGS OR WIRE ROPE
DIRECTLY THROUGH LIFT BAIL.
5. IF USING EQUIPMENT OTHER THAN A CRANE: USE RIGGING OF
SUFFICIENT LENGTH TO PREVENT CONTACT BETWEEN
MULTILIFT® AND EQUIPMENT.
Section V. Grip Adjustment
CAUTION: The procedures that follow are intended as guidelines. They are to be
carried out by qualified mechanics possessing knowledge of general procedures
and practices involved with the maintenance of heavy machinery.
IMPORTANT: Wear appropriate protective clothing and personal safety
equipment including safety glasses, hard hat, gloves, protective shoes, hearing
protection, and any special equipment called for by the job conditions.
WARNING: Failure to observe standard safety practices could result in personal
injury. Service personnel and operators must be fully conversant with the
maintenance and operating procedures.
A. Place Multilift® on object to be lifted to determine grip.
1. Pads should have a minimum of ½’’ and maximum of 3’’ clearance with
object.
!
!
!

KENCO Multilift® Operation Manual
8
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
B. Place Multilift® on an object narrower than grip and with sufficient height to
provide clearance for leg assemblies for adjustment. DO NOT ATTEMPT TO
ADJUST LEG ASSEMBLIES WHILE Multilift® IS HANGING.
1. Care must be taken to ensure that the lifter remains stable and
balanced during adjustment.
C. Leg assemblies are attached to the core using ADJ. HANDLE in the following
manner:
1. Outer Leg Assembly is latched to OUTER CORES.
2. Inner Leg Assembly is latched to INNER CORE.
D. Leg assemblies are referenced to their respective core member by the spacing of the
TOOTH BLOCKS inside the leg assembly. The leg referenced to the INNER
CORE has (1) TOOTH BLOCK indexed to contact INNER CORE, the leg
referenced to the OUTER CORES has two (2) TOOTH BLOCKS indexed to
OUTER CORES.
E. Adjust legs for a level pick.
F. Ensure that the lifter’s components (leg assemblies, lift core, and lift assembly)
do not bind and have travel remaining after adjustment.
G. Multiple Leg Configurations:
1. Legs can be reversed for inside-out gripping.
2. Legs can be used in multiples for open ended boxes. *
3. Lift assembly can be positioned to either side of the leg assemblies to handle “L’’
shaped objects.*
4. Custom leg and pad configurations available (extended legs, hardened points, ball
joint, etc).*
5. Custom core lengths available.*
*Required additional hardware not included with standard unit.

KENCO Multilift® Operation Manual
9
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
Inside-out Gripping
“L” Shaped Object Shortened Cores
(shown with additional counterweight)
Section VI. Operation.
Before attempting to use the Multilift® device ALWAYS perform
a test lift on the intended object(s) to confirm proper operation.
DO NOT use a Multilift® to handle objects beyond the rated
capacity or range.
DANGER
!
Manipulation of the Multilift® by ground personnel for the
purpose of alignment with load shall only be done with Multilift®
suspended above the wall. KEEP ALL HANDS AWAY FROM
MULTILIFT® DURING OPERATION.
DANGER
!
Surfaces of the load that come into contact with the gripping
surfaces must be free of any foreign material or coating that
could compromise the grip.
DANGER
!

KENCO Multilift® Operation Manual
10
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
A. Operation:
1. Ensure that the Multilift®’s capacity and range are appropriate to
the object being handled.
2. Ensure pads are clean and free of debris or contamination.
3. Position Multilift® at or near center of object to be lifted while
keeping the pads parallel to the gripping surfaces.
4. Lower Multilift® onto object, taking care to minimize impact.
5. Ensure pads do not grip surfaces more than eleven degrees in any
direction from vertical.
6. Ensure that all persons are clear of Multilift® and object.
7. Release tension on lift cable.
8. Raise Multilift® and load in a smooth motion; do not “jerk”.
9. Deposit at desired location.
10. Release tension on lift cable. (Note: avoid undue slamming of the
Multilift® into open position to prolong actuator life.)
11. Remove Multilift® (Multilift® is latched in open position
automatically).
12. Refer to Kenco.com for videos and tutorials on usage of the
Multilift®.
B. AVOID JARRING, WEINGING, AND OTHERWISE
UNNECESSARY MANIPULATION OF THE LOAD.
C. DO NOT ALLOW PADS TO GRIP SURFACES ANGLED MORE THAN
ELEVEN DEGREES IN ANY DIRECTION FROM VERTICAL.
DAMAGE TO THE LIFTER MAY RESULT.
D. AVOID HANDLING OF LOADS OFF CENTER.
E. DO NOT USE THE MULTILIFT® TO PICK MULTIPLES OF ITEMS
IN A SINGLE PICK.
F. OBSERVE ALL SAFETY PRACTICES ASSOCIATED WITH
OPERATION OF HOIST MACHINERY.
G. DO NOT USE MULTILIFT® TO DRAG LOADS.
H. DO NOT ALLOW LOAD TO CONTACT ANY SURFACE/OBJECT
WHILE BEING HANDLED.
Tip: The majority of wear on the Multilift® will result from shock loading, impacting,
and poor alignment of the Multilift® with the load. Minimizing these incidents will
greatly extend the life of the Multilift® and consumables.

KENCO Multilift® Operation Manual
11
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
The Multilift® wall handling device produces grip proportional
to and dependent on the weight of the load. It is for this reason
that while in operation the Multilift® and wall NEVER be
allowed to contact other items.
Section VII. Maintenance
A. Daily:
1. Visually inspect Multilift® for signs of stress and wear.
2. Check that bolts and nuts are snug.
3. Ensure free movement of all components.
4. Ensure that all warning labels are present and readable.
5. Check that actuator mounting screws are snug and seated.
6. Lubricate all moving mechanisms with penetrating OIL.
7. LUBRICATE ACTUATOR WITH LIGHT PENETRATING OIL ONLY
(WD40™)
8. For Pads:
a.Check that all pad mounting bolts and nuts are tight.
b.Verify freedom of rotation for pad angle.
c.Ensure that pad material is sound, and not de-laminated from backing plates.
d.Ensure that pad mounting bolts heads are min.3/32’’ below the surface of the pad.
(see ill.)
e.Ensure pads are clean and free of any foreign material or substance.
DANGER
!
Min. 3/32’’
PAD
PAD MOUNTING
CHANNEL OR
ANGLE
BACKING PLATE

KENCO Multilift® Operation Manual
12
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
B. Annually*
1. Remove pivot bolts and washers, coat with grease.
2. Inspect holes, pins, bolts etc. for wear. See sect VII for criteria.
3. Remove actuator, clean and lubricate with light penetrating oil –check for signs
of wear, replace if necessary.
* Frequency depends on usage, environmental conditions, etc.
Section VIII. Inspection Criteria
THE MULTILIFT® UNIT AND ALL OF ITS ASSOCIATED COMPONENTS
SHALL BE REMOVED FROM SERVICE AND TAGGED APPROPRIATELY
UNTIL RECERTIFICATION BY A QUALIFIED INDIVIDUAL IN ANY OF
THE FOLLOWING CONDITIONS:
A. General
1. Cracking in any component or member.
2. Cracking in any weld.
3. Visible distortion in any member.
4. Visible distortion in any Bolt/Pin/Shaft.
B. Specific
1. Lift Bail
a.The lift bail shall be replaced if a 20%
loss in cross-sectional area
from the original member(s)
can be demonstrated. Note:
cross section of welds,
“mushroomed” wear faces,
and burrs are not accounted
for as cross-sectional area. (see
ill.)
2. Holes
a.Any members through which bolted or pinned connections pass shall be replaced if
a 10% loss in cross-sectional area from the original member(s) can be
demonstrated. Note: cross section of welds, “mushroomed” wear faces, and
burrs are not accounted for as cross-sectional area.
3. Pins/Bolts
a.Any visible deformation of a pin, shaft or bolt shall require replacement of that
part.

KENCO Multilift® Operation Manual
13
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
Section IX. Parts/Drawings

KENCO Multilift® Operation Manual
14
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
NOTE: MODEL AND SERIAL NUMBER OF LIFTER MUST ACCOMPANY PART
ORDERS.
PN
Qty.
Description
1
1
Lift Bail
2
1
Outer Arm Assembly
3
1
Inner Arm Assembly
4
1
Inner Leg Assembly
5
1
Outer Leg Assembly
6
1
1.25’’ x 9’’ GR8 Bolt
7
4
1.25’’ x 7.5’’ GR8 Bolt
8
6
1.25’’ NYLOCK Nut
9
1
Med. Actuator Assy.
10
2
½’’ x 2’’ GR 8 Bolt
11
4
½’’ NYLOCK Nut
12
2
Outer Core Member
13
1
Inner Core Member
14
1
Outer Core Leg Assy.
15
1
Inner Core Leg Assy.
16
2
Ball Pad
17
2
Adj. Handle Assy.
18
4
Shoe Spring
19
2
Pad Spring
20
2
0.3125’’ x 3.125’’ GR 8 BOLT
21
8
0.3125’’ NYLOCK Nut
22
2
Ball Cup
23
1
Labels and Decals*
24
1
Center Core Shoe Assy.
25
1
Outer Core Shoe Assy.
26
1
1.125’’x6’’ GR8 Bolt
27
4
1’’x5.5’’ GR8 Bolt
28
20
1.25’’ Flat Washer
29
2
1’’ NYLOCK Nut
30
2
1.125’’ NYLOCK Nut
31
2
Pipe Spacer
32
1
½’’ x 2.25’’ Inner Support Pin
33
2
0.5’’x 3.5’’ GR8 Bolt
34
4
0.1875’’ Shoe Spacer
*Due to the modular nature of the ML series lifters the
decals are listed on the next page and should be located in
high visibility areas on the lifter.

KENCO Multilift® Operation Manual
15
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
KENCO CORPORATION
877-4ATTACH
MODEL
USAGE
CAPACITY
SERIAL NO.
WT.
THIS LIFTER IS DESIGNED TO ASME BTH-1
DESIGN CATEGORY SERVICE CLASS
DANGER
DO NOT STAND UNDER OR NEAR
WHILE MACHINE IS OPERATING
DO NOT exceed the rated load capacity of
the lifter.
DO NOT attempt to operate a malfunctioning
or damaged unit.
DO NOT allow unit or load to pass over any
part of a person.
DO NOT leave a suspended load unattended.
DO NOT remove or obscure any labels or
markings.
DO NOT operate or service without first
having read and understood the
operating manual.
DO NOT lift loads higher than necessary.
DO NOT alter or modify this equipment.
DO NOT use lifter for other than designated
purposes.
DO NOT lift unbalanced loads.
DO NOT allow load to contact other objects
while suspended.
INSPECT LIFTER PRIOR TO EACH USE.
WARNING
!
Read and understand
operator’s manual before
using this equipment.
Failure to follow operating
and maintenance procedures
could result in death or
serious injury.
WARNING
!

KENCO Multilift® Operation Manual
16
170 State Route 271
Ligonier, PA 15658
1-800-653-6069
Section X. Warranty
A. Policy
1. KENCO Corporation (KENCO) warrants the KENCO Pipe Lift™ lifting device (not
including pads or consumable items) sold by KENCO to be free from proven defects in
material and workmanship for a period of six (6) months from the delivery date to the
original customer.
2. Warranty is limited to replacement of parts and/or assemblies, which upon inspection by
KENCO are deemed to be defective in material, workmanship, or both.
3. Warranty shall not extend to products that have been altered or repaired in any way
without the express written consent of KENCO.
4. Warranty shall not extend to any product that has been misused, abused, or improperly
applied or any defect resulting thereof.
5. Defects and corrosion that are the result of improper storage and/or maintenance are not
warrantable.
6. Wear items such as Pads, Pins or Lifting bails etc. are not considered for warranty claims.
B. Disclaimer
1. THIS WARRANTY IS EXCLUSIVE AND IN LIEW OF ALL OTHER
REPRESENTATIONS AND WARRANTIES EXPRESSED OR IMPLIED, AND
KENCO EXPLICITLY DISCLAIMS AND EXCLUDES ANY IMPLIED WARRANTY
OF MERCHANTABILITY FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL
THE END USER BE ENTITLED TO ANY CONSEQUENTIAL, INCIDENTAL OR
CONTINGENT DAMAGES OF ANY KIND ARISING OUT OF BREACH OF
CONTRACT, WARRANTY (INCLUDING NEGLIGENCE AND STRICT
LIABILITY) OR OTHER THEORIES OF LAW, WITH RESPECT TO PRODUCTS
SOLD OR SERVICES RENDERED BY KENCO, OR ANY UNDERTAKINGS, ACTS
OR OMISSIONS RELATING THERETO.
