National Flooring Equipment ROGUE Instruction and safety manual

Read Manual Before Operating or Servicing Machine.
407170 Rev A
ROGUE™WALK-BEHIND SCRAPER
OPERATING & SERVICE MANUAL

Table of Contents
3407170_ROGUE_RevA
TABLE OF CONTENTS .................................................................................................................................................. 3
GENERAL INFORMATION............................................................................................................................................. 6
CONTACT INFORMATION.................................................................................................................................... 6
SERIAL NUMBER.................................................................................................................................................. 6
RESOURCES ........................................................................................................................................................ 6
INTENDED USE .................................................................................................................................................... 7
ALLOWED ENVIRONMENTAL CONDITIONS ...................................................................................................... 7
MACHINE SPECIFICATIONS ............................................................................................................................... 8
EXTENSION CORD SELECTION ......................................................................................................................... 8
GENERATOR SELECTION................................................................................................................................... 8
SAFETY ........................................................................................................................................................................ 10
SAFETY FIRST! .................................................................................................................................................. 10
BEFORE OPERATION ........................................................................................................................................ 10
ELECTRICAL CORDS..........................................................................................................................................11
OPERATING THE MACHINE .............................................................................................................................. 12
TRANSPORTING THE MACHINE ...................................................................................................................... 13
MAINTENANCE................................................................................................................................................... 14
SAFETY LABELS ................................................................................................................................................ 16
MACHINE OVERVIEW ................................................................................................................................................. 18
OPERATING CONTROLS ............................................................................................................................................ 19
INITIAL SETUP ............................................................................................................................................................. 20
INSTALLING THE POWER CORD...................................................................................................................... 20
INSTALLING THE BLADE HOLDER ................................................................................................................... 20
MACHINE OPERATION................................................................................................................................................ 21
ADJUSTING THE HANDLE................................................................................................................................. 21
ADJUSTING THE WHEEL SCRAPERS.............................................................................................................. 21
WEIGHTS ............................................................................................................................................................ 22
Removing Front Weight............................................................................................................................... 22
Removing Middle Weights........................................................................................................................... 23
Removing/Adjusting Slide Weights.............................................................................................................. 23
WHEEL MODES.................................................................................................................................................. 24
Disengaging Wheels.................................................................................................................................... 24
Engaging Wheels......................................................................................................................................... 24
JOBSITE EXPECTATIONS.................................................................................................................................. 24
PREPARING FOR OPERATION ......................................................................................................................... 25
STARTING THE MACHINE ................................................................................................................................. 25
STOPPING THE MACHINE................................................................................................................................. 25
AFTER OPERATION ........................................................................................................................................... 25
DRIVING THE MACHINE .................................................................................................................................... 26
Left-Hand Preference .................................................................................................................................. 26
Right-Hand Preference................................................................................................................................ 27
CHANGING THE BLADE HOLDER .................................................................................................................... 28
CHANGING THE BLADE .................................................................................................................................... 29
BLADES............................................................................................................................................................... 30
Blade Setup ................................................................................................................................................. 30
Self-Scoring Blades ..................................................................................................................................... 30
APPLICATIONS................................................................................................................................................... 31
VCT Tile ....................................................................................................................................................... 31

Table of Contents
4407170_ROGUE_RevA
Pure Vinyl Rubber Tile ................................................................................................................................. 31
Ceramic ....................................................................................................................................................... 31
Direct-Glued Carpet..................................................................................................................................... 31
Wood ........................................................................................................................................................... 31
Thin Coatings............................................................................................................................................... 31
Re-Scrape.................................................................................................................................................... 31
Suboor Surfaces ........................................................................................................................................ 31
Glued Hardwood Flooring ..................................................................................................................... 31
Wood..................................................................................................................................................... 31
Concrete................................................................................................................................................ 31
Gypcrete and Soft-Poured Flooring ...................................................................................................... 31
TRANSPORTING THE MACHINE................................................................................................................................ 32
TRANSPORT WHEELS....................................................................................................................................... 32
VEHICLE WITH POWER LIFTGATE................................................................................................................... 33
VEHICLE WITH RAMP........................................................................................................................................ 34
Ramp Loading ............................................................................................................................................. 34
Ramp Unloading.......................................................................................................................................... 34
HOISTING ........................................................................................................................................................... 35
MAINTENANCE............................................................................................................................................................ 36
MAINTENANCE SCHEDULE .............................................................................................................................. 36
REASSEMBLYING COMPONENTS ................................................................................................................... 36
REMOVING THE HOOD ..................................................................................................................................... 37
INSPECTING FOR DAMAGE.............................................................................................................................. 37
CLEANING DEBRIS BUILDUP ........................................................................................................................... 37
TESTING THE SAFETY CIRCUIT....................................................................................................................... 37
Emergency Stop Switch............................................................................................................................... 37
Lanyard Kill Switch ...................................................................................................................................... 37
TESTING THE GROUND FAULT CIRCUIT......................................................................................................... 38
INSPECTING THE PADS AND LINERS.............................................................................................................. 39
CLEANING THE COUPLING FLANGES............................................................................................................. 39
ISOLATORS AND CUTTING HEAD BEARING ................................................................................................... 40
Inspection .................................................................................................................................................... 40
Removal and Replacement ......................................................................................................................... 40
Removing/Replacing the Cutting Head Bearing.................................................................................... 40
Removing/Replacing the Isolators ........................................................................................................ 40
INSPECTING/GREASING THE BLADE ANGLE LINKAGE ................................................................................ 42
CLEARING JAMS................................................................................................................................................ 42
REMOVING/REPLACING THE WHEELS ........................................................................................................... 43
Removing Wheel ......................................................................................................................................... 43
Replacing Wheel.......................................................................................................................................... 43
REMOVING/REINSTALLING THE HANDLE....................................................................................................... 44
Removing Handle ........................................................................................................................................ 44
Reinstalling Handle...................................................................................................................................... 44
ADJUSTING HANDLE PIVOT ............................................................................................................................. 45
ADJUSTING HANDLE RELEASE LEVER .......................................................................................................... 45
ADJUSTING CONTROL HANDLE KNOBS......................................................................................................... 45
MANUAL OVERRIDE OF THE LINEAR ACTUATOR.......................................................................................... 46
RESETTING THE ONBOARD CIRCUIT BREAKER ........................................................................................... 46
LONG TERM STORAGE..................................................................................................................................... 46

Table of Contents
5407170_ROGUE_RevA
TROUBLESHOOTING.................................................................................................................................................. 47
TROUBLESHOOTING GUIDE ............................................................................................................................ 47
FAULT CODES .................................................................................................................................................... 49
PARTS LISTS ............................................................................................................................................................... 50
OVERALL MACHINE........................................................................................................................................... 50
POWER CORD 407141-XXXX............................................................................................................................ 51
SCRAPER BASE ASSEMBLY 405055-XXX........................................................................................................ 52
ORBITAL MOTOR ASSEMBLY 405057-XXX ...................................................................................................... 53
ECCENTRIC ASSEMBLY 407353 ....................................................................................................................... 54
CUTTING HEAD ASSEMBLY 405056 ................................................................................................................. 55
ACTUATOR/LINKAGE ASSEMBLY 407359........................................................................................................ 56
BRACKET ASSEMBLY 407364 ........................................................................................................................... 58
CUTTING HEAD PLATE 407363......................................................................................................................... 59
DUAL DRIVE MOTORS ASSEMBLY 405071-XXX ............................................................................................. 60
BOTTOM COVER 406687................................................................................................................................... 61
TAIL ASSEMBLY 405751..................................................................................................................................... 62
POWER DISTRIBUTION PANEL ASSEMBLY 405251........................................................................................ 64
LIFTING BAR 406684.......................................................................................................................................... 65
HANDLE ASSEMBLY 404863-XXX ..................................................................................................................... 66
HOOD 406685-X ................................................................................................................................................. 72
FRONT WEIGHT 405944-X................................................................................................................................. 73
MIDDLE WEIGHT 406090................................................................................................................................... 74
SLIDE WEIGHT 406062 ...................................................................................................................................... 74
WHEEL SCRAPERS 406686 .............................................................................................................................. 75
TRANSPORT WHEELS 406633.......................................................................................................................... 75
WIRING DIAGRAMS..................................................................................................................................................... 76
PRIMARY SYSTEMS (DIAGRAM 1) ................................................................................................................... 76
PRIMARY SYSTEMS (DIAGRAM 2) ................................................................................................................... 77
PRIMARY SYSTEMS (DIAGRAM 3) ................................................................................................................... 78
PAGE RESERVED FOR FUTURE USE.............................................................................................................. 79
CONTROL SYSTEMS (DIAGRAM 1).................................................................................................................. 80
CONTROL SYSTEMS (DIAGRAM 2).................................................................................................................. 81
CONTROL SYSTEMS (DIAGRAM 3).................................................................................................................. 82
CONTROL SYSTEMS (DIAGRAM 4).................................................................................................................. 83

GENERAL INFORMATION
6407170_ROGUE_RevA
SERIAL NUMBER
When contacting NFE, always provide the serial number of
the machine. The serial number label is located on the back
of the machine.
RESOURCES
Scan the QR code to access the manual, warranty and oth-
er resources for the machine. The QR code label is located
on the back of the machine.
CONTACT INFORMATION
Contact National Flooring Equipment (NFE) for customer
support:
National Flooring Equipment, Inc.
9250 Xylon Avenue North
Minneapolis, MN 55445
Tel: [phone]
Fax: [phone]
nationalequipmentdirect.com
[email protected]
Serial number label
QR code label
National Flooring Equipment, Inc.
9250 Xylon Avenue North,
Minneapolis, MN 55445
Telephone: [phone]
Manufactured
in the U.S.A.
406994 Rev B
Model Number
Serial Number
Electrical Input
Rated Current
Weight
###V~, #Ph, ##Hz
##Amp
#### lbs (#### kg)
Ingress: IPX3 Working Grade: ###%
406110 Rev A
www.nationalequipmentdirect.com/resources
MANUALS
407221 RevA

INTENDED USE
The Rogue walk-behind scraper is used to remove existing material from the oor including linoleum, VCT, hardwood, ce-
ramic tile, rubber-backed carpet, glued-down carpet, coatings, plastic oor coverings, foam, plastic droppings, parquet ooring,
chewing gum, felt, accumulated grime, rubber and vinyl tile, epoxy, paint and adhesives. The machine is designed for indoor
use and conned spaces in residential and commercial environments.
The machine is not designed for use outdoors or in wet environments. The machine must not be run on an incorrect electrical
supply and must not be used outdoors, on a roof or as a ramming device.
Operators should have average mechanical abilities and the ability to lift 70 lbs. Maintenance personnel should be fully trained,
have above average mechanical abilities and the ability to lift 70 lbs. Trainees should be supervised, have above average me-
chanical abilities and the ability to lift 70 lbs. Operators, maintenance personnel and trainees should read and understand the
operating and service manual before operating or working on the machine.
ALLOWED ENVIRONMENTAL CONDITIONS
The machine should be run in temperatures between 40°F-120°F (4°C-49°C) with relative humidity not above 95% to ensure
correct operation.
Do not operate the machine in damp or wet locations, or in the presence of explosive or combustible atmospheres such as
gaseous fumes, flammable materials and saw dust.
The machine may be operated in dusty conditions. The operator and other personnel in the proximity of the machine must
wear adequate safety equipment including eye protection, ear protection, safety shoes, safety gloves, hard hat, high visibility
safety vest and dust mask.
GENERAL INFORMATION
7407170_ROGUE_RevA

GENERAL INFORMATION
8407170_ROGUE_RevA
ROGUE Scraper
AWidth (slide weights forward) 19.4” (49 cm)
BWidth (slide weights rearward) 22.1” (56 cm)
CLength (handle forward) 41.4” (105 cm)
DLength (handle back) 56.8” (144 cm)
EHeight (handle forward) 25.3” (64 cm)
FHeight (handle vertical) 45.3” (115 cm)
Weight* 477 lbs (216.4 kg)
Weight (machine only) 292 lbs (132.4 kg)
Forward Speed 3-150 ft/min (.9- 45.7 m/min)
Drive Motor Power (each) 1/3 HP (250W)
Orbital Motor Power 3/4 HP (550W)
Orbital Motor Speed 650-1900 rpm
Input Power 100-240V, 50/60 Hz
Amps 15A
Max. Hand-Arm Vibration (HAV) 12.844 ± 1.532 m/s2
Sound Power Level 85.5 dBA
Sound Pressure 79.7 dBA
Body Color Silver Vein
Input Power Recommended Extension Cord Size*
100-130V 12 AWG (4 mm2)
200-240V 14 AWG (2.5 mm2)
MACHINE SPECIFICATIONS
EXTENSION CORD SELECTION
GENERATOR SELECTION
*Includes removable weights and transport wheels.
Recommended Generator Rating*: 5 kW
*Rating is “Running Watts” or “Continuous Watts”—not “Peak Output”.
*Based on a maximum cord length of 150 ft (45 m), <10% voltage loss, data from the U.S. National Electrical Code Tables 400.5(A) & 400.5(B)
and typical resistances for copper wire.

GENERAL INFORMATION
9407170_ROGUE_RevA
B
A
D
E
C
F
MACHINE SPECIFICATIONS (CONT’D)

407170_ROGUE_RevA
4. Dress properly and wear adequate safety equipment.
The operator and any other personnel in the proximity
of the machine must wear eye protection, ear protec-
tion, safety shoes, safety gloves, hard hat, high visibility
safety vest and dust mask. Do not wear loose clothing
as it could get caught in moving parts and cause injury.
SAFETY
1010
BEFORE OPERATION
1. Carefully read and understand this manual before op-
erating or servicing the machine. Keep the manual with
the machine at all times. If your manual is lost or dam-
aged, contact National Flooring Equipment (NFE) for a
replacement.
2. Do not allow anyone to use this machine until they have
been informed of the work to be done and they have
read and understood this manual. Know your equipment
and its limitations. Personnel must be properly trained
before operating or servicing this machine.
3. Safety labels carry important information. Obey the dan-
ger, warning and caution labels attached to the machine.
If unreadable or missing, contact NFE for a replacement.
Read and understand this safety section carefully be-
fore operating the machine.
Look for the safety alert symbol. This symbol is used throughout the manual and on the labels of the ma-
chine to warn of the possibility of personal injury. Read these instructions carefully. It is essential that you
read these instructions before you attempt to operate the machine.
Identies an immediate hazard which, if not avoided, will result in death or
serious injury.
Identies a potential hazard which, if not avoided, could result in death or
serious injury.
Identies a potential hazard which, if not avoided, could result in minor or
moderate injury and/or could result in damage to equipment.
Indicates equipment or property damage could result if instructions are not
followed.
Gives helpful information.
SAFETY FIRST!
CAUTION
DANGER
WARNING
IMPORTANT:
NOTE:

407170_ROGUE_RevA
SAFETY
1111
5. Do not operate the machine when tired, distracted or un-
der the inuence of drugs, alcohol or any medication that
may cause decreased control.
6. Scraping of concrete and other materials can generate
harmful dust which can cause serious injury or illness
such as respiratory disease. The operator and any by-
standers should always wear a safety mask.
7. Check the surrounding area before using the machine.
●Be aware of protrusions (stud anchors, rebar, thread-
ed rod, etc.), cracks and expansion joints.
●Check for buried pipes and cables.
●Observe location of electrical supplies and extension
cords. Do not allow cutting edge to come into contact
with any electrical supply or extension cord.
8. Keep work area tidy and well-lit. A cluttered or dark work
area could lead to accidents.
9. Keep cutting edges sharp and clean.
10.Make sure blades, blade holders and weights are se-
curely mounted.
11.Make sure the control handles are dry, clean and free of
oil and grease.
12.Make sure to use the proper electrical supply for the
machine requirements to avoid the possibility of electric
shock.
13.The electrical supply must be equipped with a proper cir-
cuit breaker.
14.Guard against electric shock.
●Prevent bodily contact with grounded surfaces such
as pipes, radiators, ranges and refrigerators.
●When scoring or making cuts, always check the work
area for hidden wires or pipes.
ELECTRICAL CORDS
Electrical cords can be hazardous. Misuse can result in re
or death by electrical shock. Read carefully and follow all
directions.
Always follow applicable electrical codes, standards and/
or regulations. Consult your local electrical authority or a
licensed electrician before attempting to modify an electri-
cal installation. Ensure that circuit and ground fault protec-
tion devices and all other safety equipment are functioning
properly.
1. Ensure the cord is suitable for the application and loca-
tion. If you are unsure about your cord type, consult a
qualied electrical professional or electrician.
2. Ground your equipment. The equipment must be
plugged into an appropriate outlet, one which is properly
installed and grounded in accordance with all codes and
ordinances. Do NOT modify the plug provided with the
equipment. Never remove the grounding prong from the
plug.
3. Do not remove, bend or modify any metal prongs or pins
of the plug. Modications to power cords and/or plugs
may result in injury and/or equipment damage.
4. Make sure both ends of the cord are fully seated.
5. Do not use excessive force to make connections.
6. Never unplug by pulling the cord from the outlet. Pull
plug rather than cord to reduce the risk of damage.
7. Regularly examine your extension cord and ensure it
is in good electrical condition. Never use a damaged
cord—either replace it or have it repaired by a qualied
person.
8. Protect your extension cords from sharp objects, exces-
sive heat and damp or wet areas. Keep the cord away
from oil, cutting edges and moving parts.
9. Do not drive, drag or place objects over cord.
10.Avoid overheating. Uncoil cord and do not cover it with
any material.
11.Avoid accidental starting. Be sure equipment is turned
o󰀨 before plugging in. Do not use equipment if the power
switch does not turn the equipment on and o󰀨.

407170_ROGUE_RevA
SAFETY
1212
7. Blades are sharp, use extreme caution.
●Always wear safety gloves when handling blades.
●Never change blade holder or service the blade while
machine is running.
8. Beware of pinch point locations.
●Handle:
●Gap below handle hinge
●Between handle and machine with handle adjust-
ed all the way forward
●Between handle and transport wheels with handle
adjusted all the way back
●Between handle and machine while installing
handle
●Between weights and machine when removing and
installing weights
●Rear access cover while closing (both sides)
●Tooling holder at blade holder insertion location
●Between machine and oor while laying machine on
its side
9. Use care when handling the weights. Weights are very
heavy and create a crushing hazard.
OPERATING THE MACHINE
1. The machine is equipped with an emergency stop switch
(E-stop) and a lanyard kill switch. If either switch is acti-
vated, the machine will shut down and be inoperative.
2. Never remove or modify any of the safety features on
the machine.
●Carefully read the manual to understand the proper
use of the safety features.
●Make sure all safety features, including the emer-
gency stop switch, lanyard kill switch and protective
guards are in good operating condition. Repair or re-
place any inoperative or missing safety features.
3. Maintain control and stay alert. Keep proper footing and
balance and maintain a rm grip.
4. Vibration—Device exceeds 2.5 m/s2exposure level.
Consult local hand-arm vibration (HAV) guidelines for
recommended exposure limits.
5. Always stay clear of moving parts. Clothing, hands or
other body parts can become caught in moving parts of
the machine and cause personal injury.
6. Beware of hot surfaces such as blades and motor com-
ponents. Always wear safety gloves.
12.Make sure equipment is not running before disconnect-
ing cord.
13.Unplug equipment. When not in use and before chang-
ing accessories or performing maintenance, unplug the
machine.
407124 Rev A

407170_ROGUE_RevA
SAFETY
1313
21.Machine is only to be used indoors. Do not use in wet
environments.
●Do not operate near standing water.
●Do not use to scrape waterlogged carpet.
22.Do not block the machine’s air ow. Blocking ventilation
slots or air ow could result in damage to the machine.
Leave space for air to ow freely during operation.
23.If abnormal noise or vibration occurs, turn o󰀨 the ma-
chine immediately.
24.Do not force equipment. Equipment will perform best at
the rate for which it was designed. Excessive force only
causes operator fatigue, increased wear and reduced
control.
10.Always check the surrounding area for any possible con-
ditions that could create a dangerous situation.
●Operator should be aware of who is around them and
their proximity. Never allow people to approach the
vicinity of the machine while the machine is running.
●Bystanders should stay a minimum of 3 ft away from
the machine during operation.
●Keep children away from the machine and work area
at all times.
●Be aware of blind spots to the rear and always check
behind you before backing up.
●Provide barriers or shields as needed to protect oth-
ers in the work area from ying debris and machine
operation.
11.Electrical cords create a tripping hazard. Be careful not
to trip over the extension cord while operating the ma-
chine.
12.Never allow people to ride on the machine.
13.Never step on the debris deector during operation, as
loss of balance and personal injury could occur.
14.Avoid leaning forward over the handle during operation.
If machine is operated in reverse, drive wheel could roll
over operator’s foot causing possible injury.
15.Never lean on the handle. Putting weight onto machine
could damage the handle and cause operator to lose
balance.
16.Avoid driving the machine over any obstacles which
could cause a loss of control.
17.Use caution when operating the machine on inclines or
uneven surfaces.
●The weight of the machine may become distributed
di󰀨erently if on an uneven surface. Too much of an
angle could cause the machine to roll unexpectedly
or roll over.
●Max. working grade (scraping applications): 5%
●Max. transportation grade (ramp use): 36%
18.Do not use on largely uneven surfaces.
19.Use caution when operating on slippery surfaces.
20.Avoid use in dangerous environments. Do not use in the
presence of explosive atmospheres (gaseous fumes,
dust or ammable materials). Remove materials or de-
bris that may be ignited by sparks.
TRANSPORTING THE MACHINE
1. Dress properly and wear adequate safety equipment
when transporting the machine. All personnel in the
proximity of the machine must wear eye protection, ear
protection, safety shoes, safety gloves, hard hat, high
visibility safety vest and dust mask. Do not wear loose
clothing as it could get caught in moving parts and cause
injury.
2. The machine is very heavy! Machine weight is shown
in “MACHINE SPECIFICATIONS” section and on serial
number label.
3. Never attempt to manually lift the machine. Hands could
slip o󰀨 causing serious injury.
4. Never lift machine by the handle, weights, blade holder
or tooling holder. Weights and handle could detach caus-
ing injury. The machine could be damaged.
5. Use only proper lifting points and tie-down locations.
6. See “TRANSPORTING THE MACHINE” section for de-
tailed safety instructions.

407170_ROGUE_RevA
SAFETY
1414
8. Make sure the work area is clear and safe. Be sure to
work on a rm, level surface with adequate lighting.
Work in a well-ventilated area if indoors. Make sure the
area is free from any potentially dangerous conditions
such as obstacles, slippery surfaces, etc.
9. Prohibit unauthorized persons from entering work area.
10.Make sure the machine is secured before beginning
maintenance work.
●Chock the wheels to prevent the machine from roll-
ing.
11.Be sure the machine is clean and free of debris before
performing any maintenance work.
12.Motors run at high temperatures under normal condi-
tions. Clean debris from motors more frequently when
working in severe conditions.
13.Never use a pressure washer or hose to clean the ma-
chine. Water can seep into the electrical components
causing an electrical shock hazard or malfunction of
controls.
14.Use caution when tilting back the machine to change the
blade holder:
●Before tilting back, position slide weights rearward to
make tilting easier.
●Always block the front of the machine to prevent the
machine from falling forward unexpectedly.
15.The machine has components that are at high tempera-
tures under normal operating conditions. The primary
source of high temperatures are the motors. The electri-
cal system, if damaged or incorrectly maintained, can be
a source of arcing or sparks. The following guidelines will
help keep the machine running e󰀩ciently and keep the
risk of re to a minimum.
●Clean accumulated ammable debris from hot com-
ponents. Clean more frequently when working in se-
vere conditions.
●Remove rags, tools, supplies, etc. from the machine
after maintenance is completed.
●Check electrical wiring and connectors frequently for
damage. Repair any wires that are loose or frayed
before operating the machine. Clean and tighten all
electrical connections as necessary.
MAINTENANCE
1. Dress properly and wear adequate safety equipment. All
personnel in the work area must wear eye protection,
ear protection, safety shoes, safety gloves, hard hat,
high visibility safety vest and dust mask. Do not wear
loose clothing as it could get caught in moving parts and
cause injury.
2. Maintenance should only be performed by qualied per-
sonnel.
3. Always turn o󰀨 machine, disconnect from power and dis-
charge stored energy before performing maintenance.
Variable frequency drives (VFDs) hold stored energy
and pose a serious electrical shock hazard. Always per-
form the following procedure before beginning any work
on machine:
A. Turn o󰀨 machine.
B. Leave power cord plugged in 5 minutes.
C. Disconnect power cord.
D. Wait an additional 5 minutes before performing any
service on the machine.
4. Allow the machine to cool down su󰀩ciently before per-
forming maintenance.
●Blade and motor may be very hot immediately after
the machine has been running. Allow these parts to
cool su󰀩ciently before touching.
5. Always stay clear of moving or rotating parts. Clothing,
hands or other body parts can become caught in moving
parts of the machine and cause personal injury.
6. Always attach a “DO NOT OPERATE” tag whenever
performing any kind of maintenance or repair.
7. Make sure you have the proper tools on hand. Do not
use defective or damaged tools. Always use tools that
are appropriate for the task to be done.

407170_ROGUE_RevA
SAFETY
1515
19.Always carefully check the machine after performing any
maintenance or repairs. Remove all traces of cleaning
uids from the machine.
20.Use proper cleaning agents. Ensure that all cleaning
rags are ber-free. Do not use any aggressive cleaning
products.
21.Waste material
●Consult local regulations and codes when dispos-
ing of potentially harmful and hazardous materials
or substances. Dispose of waste material properly to
avoid pollution and contamination of the environment.
16.Do not permanently remove a guard or other safety de-
vice when performing maintenance on the machine.
17.Check for loose or damaged parts, misalignment, im-
proper mounting, binding of moving parts, and any other
conditions that may a󰀨ect operation.
●Retighten all loose parts. Replace damaged parts im-
mediately. Use only NFE parts.
●Do not use damaged equipment until repaired.
●Use only NFE-approved or recommended parts and
accessories. Using any that are not recommended
may be hazardous and will void factory warranty.
18.Do not modify the machine without written authorization
from NFE.

407170_ROGUE_RevA
SAFETY LABELS
SAFETY
1616
407125 Rev A
31kg/68.3lb
407151 Rev A
406110 Rev A
407124 Rev A
Airborne
Contaminants
Hot Blade, Pinch Point, Sharp Blade
Team Lift, Do Not Stand
Eye Protection, Ear Protection, Hard Hat,
Safety Shoes, Safety Gloves, Dust Mask,
High Visibility Safety Vest, Read Manual
Electrical HazardPinch Point
Team Lift
406603 406110
407124
407125
407151406581
406574
406581 Rev A

407170_ROGUE_RevA
SAFETY
1717
THIS PAGE INTENTIONALLY LEFT BLANK

407170_ROGUE_RevA
(1) Tooling holder
(2) Debris deector
(3) Front weight
(4) Middle weight
(5) Slide weight
(6) Lifting eyes
(7) Drive wheel
(8) Coupling ange
(9) Wheel cleaner
(10) Handle
(11) Control panel
(12) Left control handle
(13) Right control handle
(14) Hood (Body panel weldment)
(15) Kickplate
MACHINE OVERVIEW
1818
5
6
6
7
8
9
10
3
2
1
4
11
14
15
1213

407170_ROGUE_RevA
OPERATING CONTROLS
1919
6
7 8
9
10
2
1
3
4
5
11
12 13
[6] System Indicator
Indicates system status:
●Amber indicates startup mode.
●Pulsating green indicates machine is ready to operate.
●Flashing red indicates a system fault. Reference “TROU-
BLESHOOTING” section for fault codes.
[7] Drive Speed Control
Sets the maximum drive speed of the machine.
[8] Orbital Motor Speed Control
Adjusts the oscillation rate of the tooling holder.
[9] Blade Angle Control
Adjusts the angle of the blade.
[10] Hour Meter
Displays operating hours.
[11] Left/Right-Hand Preference Switch
Determines functionality of the control handles based on
operator preference.
[12] [13] Left and Right Control Handles
The control handles are used to control the travel direction,
turning and drive speed of the machine. Reference the “MA-
CHINE OPERATION” section for detailed information.
[1] Emergency Stop Switch (E-Stop)
Push to immediately shut down the machine in case of
emergency.
●Reset Procedure
If engaged, must be reset before the machine can be
restarted. To reset, twist red button clockwise to release.
[2] Lanyard Kill Switch
Operator presence control (OPC) that immediately shuts
down the machine if the operator gets separated from the
machine’s controls. The switch is held open by a key at-
tached to a lanyard that is tethered to the operator. If the
operator moves too far from the switch, the lanyard pulls the
key from the switch shutting down the machine.
●Reset Procedure
If engaged, must be reset before the machine can be
restarted. To reset, reinsert the key into the kill switch.
[3] Power Indicator
The power indicator illuminates when the machine is con-
nected to power.
[4] ON Button
Push the green “ON” button to turn on the controls. The sys-
tem indicator will pulsate green.
[5] OFF Button
Push the red “OFF” button to disable the controls.

407170_ROGUE_RevA
INITIAL SETUP
2020
INSTALLING THE POWER CORD
1. Remove the two cable clamps on handle.
2. Route power cord (packaged with machine) through
clamps.
3. Reinstall clamps. Use of threadlocker on bolt threads is
recommended.
NOTE:
●Make sure there is no excess slack in the power cord.
Installed power cord
Power cord should NOT have excess slack.
INSTALLING THE BLADE HOLDER
See “CHANGING THE BLADE HOLDER” section for instal-
lation process.
