Sealey POWER TOOLS SA292 User manual

Thank you for purchasing a Sealey Product. Manufactured to a high standard this product will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS
AND CAUTIONS. USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE
TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP
INSTRUCTIONS SAFE FOR FUTURE USE.
SA292 & SA293 - 1 - 250203
2. INTRODUCTION & SPECIFICATIONS
Specifications SA292 SA293
Drive size . . . . . . . . . . . . . . . . . . . . . .1Sq . . . . . . . . . . . . . .1Sq
Working/max torque . . . . . . . .950/1200ft.lb . . . . . . . .950/1200ft.lb
Ultimate torque . . . . . . . . . . . . . . .1250ft.lb . . . . . . . . . . . .1250ft.lb
Air inlet size . . . . . . . . . . . . . . . . 3/8 BSP . . . . . . . . . . . 3/8 BSP
Operating pressure . . . . . . . . . . . . . .90psi . . . . . . . . . . . . . .90psi
Introduction
The SA292 and SA293 are heavy duty 1 air tools suitable for commercial and agricultural vehicle use. They have rocking-dog clutches, air/torque
adjustment with reverse action and are supplied with a side handle. The SA292 features a long anvil for applications with restricted access whilst
the SA293 features a stubby anvil.
1. SAFETY INSTRUCTIONS
3Follow all workshop safety rules, regulations, and conditions when using wrench.
pWARNING! Disconnect from air supply before changing accessories or servicing.
3Maintain the wrench in good condition and replace any damaged or worn parts. Use genuine parts only. Unauthorised parts
may be dangerous and will invalidate the warranty.
pWARNING! Check correct air pressure is maintained and not exceeded. We recommend 90psi.
3Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use and ensure that all connections are secure.
3Only use impact sockets which are specifically designed for use with an impact wrench.
3Wear approved safety eye/face shield, ear defenders, and hand protection.
pWARNING! Due to the possible presence of asbestos dust from brake linings, when working around vehicle brake systems we recommend you
wear suitable respiratory protection.
3Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
3Keep children and non essential persons away from the working area.
7DO NOT use the wrench for a task it is not designed to perform.
p p
WARNING! DO NOT use wrench if damaged or thought to be faulty. (Contact Service Agent).
7DO NOT use wrench unless you have been instructed in its use by a qualified person.
7DO NOT carry the wrench by the air hose, or yank the hose from the air supply.
7DO NOT operate wrench if you are tired or under the influence of alcohol, drugs or intoxicating medication.
7DO NOT carry wrench with your hand on the power trigger in order to avoid unintentional starting.
7DO NOT direct air from the air hose at yourself or others.
3When not in use disconnect from air supply and store in a safe, dry, childproof location.
INSTRUCTIONS FOR
1 SQUARE DRIVE AIR IMPACT
PISTOL WRENCHES
Models: SA292 & SA293
Specifications SA292 SA293
Weight . . . . . . . . . . . . . . . . . . . . . . 13.0kg . . . . . . . . . . . . . 11.0kg
Sound pressure . . . . . . . . . . . . . .102.5dB . . . . . . . . . . . .100.0dB
Sound power . . . . . . . . . . . . . . . .103.0dB . . . . . . . . . . . .100.5dB
Air consumption . . . . . . . . . . . . . . . 12cfm . . . . . . . . . . . . . 12cfm
Vibration level . . . . . . . . . . . . . . . .10m/s2 . . . . . . . . . . . . .10m/s2
3.1. Air Supply
3.1.1. Ensure wrench air valve (or trigger) is in the "off" position before connecting to the air supply.
3.1.2. You will require an air pressure of 90psi, and an air flow according to specification.
3.1.3. pWARNING! Ensure the air supply is clean and does not exceed 90 psi while operating the wrench. Too high an air pressure and unclean
air will shorten the product life due to excessive wear, and may be dangerous causing damage and/or personal injury.
3.1.4. Drain the air tank daily. Water in the air line will damage the wrench.
3.1.5. Clean air inlet filter weekly. Recommended hook-up procedure is shown in fig 1.
3.1.6. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum hose diameter should be
3/8 I.D. and fittings must have the same inside dimensions.
3.1.7. Keep hose away from heat, oil and sharp edges. Check hose for wear, and make certain that all connections are secure.
3.2. Couplings
Vibration may cause failure if a quick change coupling is connected directly to the wrench. To overcome this, connect a leader hose to the
wrench. A quick change coupling may then be used to connect the leader hose to the air line recoil hose. See fig 1 & 2.
3. PREPARING WRENCH FOR USE
fig 1
3.3. Assembly
Fit the side handle to the wrench using the bolts provided.
fig 2

4. OPERATING INSTRUCTIONS
p p
WARNING! Ensure you read, understand and apply safety instructions before use.
4.1. Only use impact sockets which are specifically designed for use with an impact wrench.
4.2. Connect the wrench to the air hose as in chapter 3.
4.3. Place the socket over the subject nut and depress the trigger to operate the wrench.
4.4. To change wrench direction turn the reverse lever on the left side of the handle .
4.5. The flow of air may be regulated by turning the regulator knob on the left side of the handle.
7DO NOT use any additional force upon the wrench in order to remove a nut.
7DO NOT allow wrench to free run for an extended period of time as this will shorten its life.
pWARNING! Disconnect wrench from air supply before changing accessories, servicing or performing maintenance. Replace or repair
damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
5.1. Lubricate the air wrench daily with a few drops of Sealey air tool oil dripped into the air inlet to prolong its life.
5.2. Clean the wrench after use. DO NOT use worn, or damaged sockets.
5.3. Loss of power or erratic action may be due to the following:
a) Excessive drain on the air line. Moisture or restriction in the air pipe. Incorrect size or type of hose connectors. To remedy check
the air supply and follow instructions in chapter 3.
b) Grit or gum deposits in the wrench may also reduce performance. If your model has an air strainer (located in the area of the air inlet), remove
the strainer and clean it. Flush the wrench out with gum solvent oil or an equal mixture of SAE No 10 oil and paraffin. Allow to dry before use.
5.4. For a full service contact your local Sealey service agent.
5.5. When not in use, disconnect from air supply, clean wrench and store in a safe, dry, childproof location.
5. MAINTENANCE
[e-mail]
01284 703534
Sole UK Distributor,
Sealey Group,
Bury St. Edmunds, Suffolk.
www.sealey.co.uk
email Web
01284 757500
We, the sole importer into the UK, declare that the products listed here are in conformity with the following EEC standards and directives. The
construction files for these products are held by the Manufacturer and may be inspected, by a national authority, upon request to Jack Sealey Ltd.
For Jack Sealey Ltd. Sole importer into the UK of Sealey Power Tools.
Air Impact Wrenches
Models: SA292 & SA293
98/37/EC Machinery Directive
93/68/EEC Marking Directive
25th February 2003
Declaration of Conformity
Signed by Mark Sweetman
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this equipment.
WARRANTY: Guarantee is 12 months from purchase date. proof of which will be required for any claim.
