Estufa a
_nge
as
Models, Mode{os 790. 7156"
* = color number, nQmero de color
www.sears.com Sears Roebuck and Co., Hoffman Estates, iL 60179 U.S.A. pin 316462441(0711)
Table of Contents
Free-Standing Range Warranty ........................................... 2
Product Record ................................................................... 2
IMPORTANT SAFETY INSTRUCTIONS .......................... 3-5
Protection Agreements ........................................................ 5
Range Features .................................................................. 6
Before Setting Oven Controls .............................................. 7
Setting Surface Controls ..................................................... 8
Oven Control Functions ....................................................... 9
Setting Oven Controls .................................................... 9-11
Select Self Cleaning ..................................................... 11-12
General Care & Cleaning .............................................. 13-15
Adjusting Your Oven Temperature ...................................... 15
Before You Make a Service Call ........................................ 16
Sears Service ...................................................... Back Page
Product Record
In this space below, record the date of purchase, model and
serial number of your product. You will find the model and
serial number printed on an identification plate. The serial
plate is located on the right side of the oven front frame in
the storage or warmer drawer compartment. See bottom of
this page for the serial plate location.
Model No. 790.
Serial No.
Date of Purchase
Save these instructions and your sales receipt for future
reference.
One Year Limited Warranty
When installed, operated and maintained according to all instructions supplied with the product, if this appliance fails due to a defect
in material and workmanship within one year from the date of purchase, call 1-800=4=MY-HOME® to arrange for free repair. If this
appliance is ever used for other than private family purposes, this warranty applies for only 90 days from the date of purchase.
This warranty covers only defects in material and workmanship. Sears will NOT pay for:
1. Cracks in a ceramic glass cooktop that are not a result of thermal shock.
2. Stains and scratches on a ceramic glass cooktop resulting from failure to maintain it properly according to all instructions supplied
with the product.
3. Expendable items that can wear out from normal use, including but not limited to filters, belts, light bulbs, and bags.
4. A service technician to instruct the user in correct product installation, operation or maintenance.
5. A service technician to clean or maintain this product.
6. Damage to or failure of this product if it is not installed, operated or maintained according to all instructions supplied with the product.
7. Damage to or failure of this product resulting from accident, abuse, misuse or use for other than its intended purpose.
8. Damage to or failure of this product caused by the use of detergents, cleaners, chemicals or utensils other than those recommended
in all instructions supplied with the product.
9. Damage to or failure of parts or systems resulting from unauthorized modifications made to this product.
Disclaimer of implied warranties; limitation of remedies
Customer's sole and exclusive remedy under this limited warranty shall be product repair as provided herein, implied warranties,
including warranties of merchantability or fitness for a particular purpose, are limited to one year or the shortest period allowed by law.
Sears shall not be liable for incidental or consequential damages. Some states and provinces do not allow the exclusion or limitation of
incidental or consequential damages, or limitation on the duration of implied warranties of merchantability or fitness, so these exclu-
sions or limitations may not apply to you.
This warranty applies only while this appliance is used in the United States or Canada.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., Hoffman Estates, IL 60179
Sears Canada Inc., Toronto, Ontario, Canada M5B 2
Grounding Instructions
Avoid fire hazard or electrical shock. Do not use an adapter plug, an
extension cord, or remove grounding prong from electrical power cord. Failure to follow this
warning can cause serious injury, fire or death.
This appliance is equipped with a 3-prong grounding plug for your protection
against shock hazard and should be plugged directly into a properly grounded receptacle.
DO NOT cut or remove the grounding prong from this plug.
For personal safety, the range must be properly grounded. For maximum safety, the power
cord must be plugged into an electrical outlet that is correctly polarized and properly
grounded.
Powersupply cord If a 2-prong wall receptacle is the only available outlet, it is the personal responsibility of the
with 3-prong consumer to have it replaced with a properly grounded 3-prong wall receptacle installed by a
grounding p_ug qualified electrician.
See the iNSTALLATiON iNSTRUCTiONS packaged with this range for complete installation and grounding instructions.
2
Grounding type
wall receptacle
YDo not, under any "_)
circumstance, cut,
remove, or bypass
the grounding prong. J
important Safety instructions
Read all instructions before using this appliance.
Save these instructions for future reference.
This manual contains important safety symbols and instructions. Please pay attention to these symbols and follow all instructions given.
This symbol will help alert You to Situations that may cause Serious bodily harm, death or property damage:
This symbol Wil! he!p alert you to Situati0ns that may cause bodily injury or property damagel
if the information in this manuaJ is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
FORYOURSAFETY:
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
-- WHAT TO DO IF YOU SMELL GAS:
*Do not try to light any appliance.
*Do not touch any electrical switch; do not use any
phone in your building.
*ImmediateJy cail your gas supplier from a
neighbor's phone. Follow the gas suppiier's
instructions.
*If you cannot reach your gas supplier, call the fire
department.
-- Installation and service must be performed by a
qualified installer, servicer or the gas supplier.
*Remove all tape and packaging before using the range. Destroy
the carton and plastic bags after unpacking the range. Never
allow children to play with packaging material.
*Proper Installation--Be sureyour appliance isproperly installed
and grounded by a qualified technician in accordance with the
National Fuel Gas CodeANSl Z223.- latest edition, or in Canada
CAN/CGA B149.1, and CAN/CGA B149.2, and the the National
Electrical Code ANSI/NFPA No.70=latest edition, or in Canada
CSA Standard C22.1, Canadian Electrical Code, Part 1, and
local code requirements. Install only per installation instructions
provided in the literature package for this range.
Ask your Sears dealer to recommend a qualified technician and
an authorized Sears repair service. Know how to disconnect the
power to the range at the circuit breaker or fuse box in case of an
emergency.
*User servicing--Do not repair or replace any part of the
appliance unless specifically recommended in the manuals.
All other servicing should be done only by a qualified technician,
This may reduce the risk of personal injury and damage to the
range.
*Never modify or alter the construction of a range by removing
leveling legs, panels, wire covers, anti=tip brackets/screws, or
any other part of the product.
*Air curtain or other overhead range hoods, which operate by
blowing a downward air flow on to a range, shall not be used
in conjunction with gas ranges other than when the hood and
range have been designed, tested and listed by an independent
test laboratory for use in combination with each other.
•All ranges can tip.
• Injury to persons could result,
,install anti-tip device packed with range.
•See Installation Instructions.
_To reduce the risk of
tipping, the rangemust be secured by
properly installed anti-tip bracket provided
with the range. To check if the bracket is
installed properly, visually check that rear
leveling leg is inserted into and fully
secured by the anti-tip bracket by
removing lower panel or storage drawer.
For models with a warmer drawer, grasp
the top rear edge of the range and
carefully attempt to tilt it forward, Refer to
the installation instructions for proper anti-
tip bracket installation.
NEVER use this appliance as a space
heater to heat or warm the room, Doing so may result in
carbon monoxide poisoning,
NEVER cover any slots, holes or passages in
the oven bottom or cover an entire rack with materials such as
aluminum foil. Doing so blocks air flow through the oven and
may cause carbon monoxide poisoning. Aluminum foil linings
may trap heat, causing a fire hazard,
Stepping, leaning or sitting on the doors or
drawers of this range can result in serious injuries and also
cause damage to the range. Do not allow children to climb or play
around the range. The weight of a child on an open door may cause
the range to tip, resulting in serious burns or other injury.
Do not use the oven or warmer drawer (if
equipped) for storage.
Do not store items of interest to children in the
cabinets above a range or on the backguard of a range. Children
climbing on the range to reach items could be seriously injured
Storage in or on Appliance--Flammable materials should not
be stored in an oven, warmer drawer, near surface burners or
in the storage drawer. This includes paper, plastic and cloth
items, such as cookbooks, plasticware and towels, as well as
flammable liquids. Do not store explosives, such as aerosol
cans, on or near the range.
important Safety instructions
, Do Not Leave Children Alone--Children should not be left alone
or unattended in the area where appliance is in use, They
should never be allowed to sit or stand on any part of the
appliance.
, DO NOT TOUCH SURFACE BURNERS, AREAS NEAR THESE
BURNERS, OVEN BURNERS ORINTERIOR SURFACES OF THE
OVEN. Both surface and oven burners may be hot even though
flames are not visible. Areas near surface burners may become
hot enough to cause burns. During and after use, do not touch,
or let clothing or other flammable materials touch these areas
until they have had sufficient time to cool. Among these areas are
the cook top, surfaces facing the cook top, the oven vent openings
and surfaces near these openings, oven door and window.
, Wear Proper Apparel--Loose-fitting or hanging garments
should never be worn while using the appliance. Do not let
clothing or other flammable materials contact hot surfaces.
, Do Not Use Water or Flour on Grease Fires--Smother the fire
with a pan lid, or use baking soda, adry chemical or foam-type
extinguisher.
, When heating fat or grease, watch it closely. Fat or grease may
catch fire if allowed to become too hot.
, Use Only Dry Potholders--Moist or damp potholders on hot
surfaces may result in burns from steam. Do not let potholders
touch hot heating burners. Do not use a towel or other bulky cloth
instead of a potholder.
, Do Not Heat Unopened Food Containers--Buildup of pressure
may cause container to burst and result in injury.
, Remove the oven door from any unused range ifit isto be stored
or discarded.
IMPORTANT--ELECTRIC IGNITION MODELS ONLY: Do not
attempt to operate the oven during a power failure. If the power
fails, always turn off the oven. If the oven is not turned off and
the power resumes, the oven will begin to operate again. Once
the power resumes, reset the clock and oven function.
IMPORTANT INSTRUCTIONS FOR USING YOUR
COOKTOP
Use Proper Flame Size--Adjust flame size so it
does not extend beyond the edge of the utensil. The use of
undersized utensils will expose a portion of the burner flame to
direct contact and may result in ignition of clothing. Proper
relationship of utensil to flame will also improve efficiency.
, Know which knob controls each surface burner. Place a pan
of food on the burner before turning it on, and turn the burner off
before removing the pan.
,Always turn knob to the full LITE position when igniting top
burners. Visually check that burner has lit. Then adjust the flame
so it does not extend beyond the edge of the utensil.
, Utensil Handles Should Be Turned Inward and Not Extend Over
Adjacent Surface Burners--To reduce the risk of burns, ignition
of flammable materials, and spillage due to unintentional contact
with the utensil, the handle of the utensil should be positioned so
that it is turned inward, and does not extend over adjacent surface
burners.
, Never Leave Surface Burners Unattended at High Heat
Settings--Boilovers cause smoking and greasy spillovers that
may ignite, or a pan that has boiled dry may melt.
,Protective Liners--Do not use aluminum foil to line surface
burner pans, or oven bottom, except as suggested in this manual.
Improper installation of these liners may result in risk of electric
shock, or fire.
, Glazed Cooking Utensils--Only certain types of glass, glass/
ceramic, ceramic, earthenware, or other glazed utensils are
suitable for cooktop service without breaking due to sudden
change in temperatures. Check the manufacturer's
recommendations for cooktop use.
IMPORTANT INSTRUCTIONS FOR USING YOUR OVEN
, UseCareWhen Opening Oven Door orWarmer Drawer--Stand
to the side of the range when opening the door of a hot oven. Let
hot air or steam escape before you remove or replace food in the
oveR.
" Keep Oven Vent Ducts Unobstructed. The oven vent is located
below the backguard. Touching the surfaces in this area when
the oven is operating may cause severe burns. Also, do not place
plastic or heat-sensitive items on or near the oven vent. These
items could melt or ignite.
* Placement of Oven Racks. Always place oven racks in desired
location while oven is cool. If rack must be moved while oven is
hot use extreme caution. Use potholders and grasp the rack with
both hands to reposition. Do not let potholders contact the hot
heating elements in the oven. Remove all utensils from the rack
before moving.
, Do not use the broiler pan without its insert. The broiler pan and
its insert allow dripping fat to drain and be kept away from the high
heat of the broiler.
, Do not cover the broiler insertwith aluminum foil. Exposed fat
and grease could ignite.
-Cold temperatures can damage the electronic control. When
using the appliance for the first time, or when the appliance has
not been used for an extended period of time, be certain the unit
has been in temperatures above 32°F (0°C) for at least 3 hours
before turning on the power to the appliance.
IMPORTANT INSTRUCTIONS FOR CLEANING
YOUR RANGE
,Clean the range regularly to keep all parts free of grease
that could catch fire. Pay particular attention to the area
underneath each surface element. Do not allow grease to
accumulate. Refer to the range manufacturer's instructions for
cleaning.
, Kitchen cleaners and aerosols--Always follow the
manufacturer's recommended directions for use. Be aware
that excess residue from cleaners and aerosols may ignite
causing damage and injury.
SELF=CLEANING OVENS
, Clean in the self=cleaning cycle only the parts listed in this
Use & Care Guide. Before self cleaning the oven, remove the
broiler pan and any utensils or foods from the oven.
, Do Not Use Oven Cleaners--No commercial oven cleaner or
oven liner protective coating of any kind should he used in or
around any part of the oven.
, Do Not Clean Door Gasket--The door gasket is essential for
a good seal. Care should he taken not to rub, damage or
move the gasket.
Important Safety Notice
The California Safe Drinking Water and Toxic Enforcement Act
requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth defects or
other reproductive harm, and requires businesses to warn
customers of potential exposure to such substances.
important Safety instructions
Conversion to Liquefied Petroleum Gas (or L.P. Gas)
The natural gas range is designed to allow for conversion to
Liquefied Petroleum (L.P.) Gas.
If L.P. conversion is needed, contact 1-800-4-MY-HOME® for
assistance. The L.P. Conversion Kit is provided with this range
and is located on the left lower REAR (back side) panel of the
range. Before installing the kit be sure to follow the L.P.
Installation Instructions carefully.
Personal injury or death from electrical
shock may occur if the range is not installed by a qualified
installer or electrician.
Any additions, changes or conversions
required in order for this appliance to satisfactorily meet the
application needs must be made by Sears Service.
Range Features
Your Gas Range Features Include:
1. Electronic Oven Control with Kitchen Timer.
2. Left Front Burner Valve & Knob.
3. Left Rear Burner Valve & Knob.
4. Right Rear Burner Valve & Knob.
5. Right Front Burner Valve & Knob.
6. Easy to clean Upswept Cooktop
7. Dishwasher safe Burner Grates with Center Grate (some
models).
8. Self-Clean Oven Door Latch.
9. Manual Oven Light Switch (some models).
10. Automatic Oven Door Light Switch (some models).
11. Oven interior Light with Shield (some models).
12. Self-Cleaning Oven interior.
13. Adjustable Oven Racks(s).
14. Large 1 piece Oven Door Handle.
15. Full width Oven Door (style vary with model).
16. Storage Drawer with Drawer Handle (some models) or lower
cover panel (some models).
17. 9,500 BTU Burner.
18. 9,500 BTU Burner.
19. 9,500 BTU Burner.
20. 9,500 BTU Burner.
21. Broil Pan (some models).
22. Broil Pan insert (some models).
23. Leveling Legs and Anti-tip Bracket (included).
NOTE: The features of your range may
vary according to model type & color.
Q i _ii_i_ii _i!ii_iii_ ii _ i_ _i
@
@
Protection Ag reements
Master Protection Agreements
Congratulations on making a smart purchase. Your new Kenmore ®
product is designed and manufactured for years of dependable operation.
But like all products, it may require preventive maintenance or repair from
time to time. That's when having a Master Protection Agreement can
save you money and aggravation.
The Master Protection Agreement also helps extend the life of your new
product. Here's what the Agreement* includes:
[] Parts and labor needed to help keep products operating properly
under normal use, not just defects. Our coverage goes well
beyond the product warranty. No deductibles, no functional failure
excluded from coverage - real protection.
[] Expert service by a force of more than 10,000 authorized Sears
service technicians, which means someone you can trust will be
working on your product.
[] Unlimited service calls and nationwide service, as often as you
want us, whenever you want us.
[] "No-lemon" guarantee - replacement of your covered product if
four or more product failures occur within twelve months.
[] Product replacement if your covered product can't be fixed.
[] Annual Preventive Maintenance Check at your request -no extra
charge.
[] Fast help by phone - we call it Rapid Resolution - phone support
from a Sears representative on all products. Think of us as a "talking
owner's manual".
[] Power surge protection against electrical damage due to power
fluctuations.
[] $250 Food Loss Protection annually for any food spoilage that is
the result of mechanical failure of any covered refrigerator or
freezer.
[] Rental reimbursement if repair of your covered product takes
longer than promised.
[] 10% discount off the regular price of any non-covered repair
service and related installed parts.
Once you purchase the Agreement, a simple phone call is all that ittakes
for you to schedule service. You can call anytime day or night, or
schedule a service appointment online.
The Master Protection Agreement is a risk free purchase. If you cancel
for any reason during the product warranty period, we will provide a full
refund. Or, a prorated refund anytime after the product warranty period
expires. Purchase your Master Protection Agreement today!
Some limitations and exclusions apply. For prices and additional
information in the U.S.A. call 1-800-827-6655.
* Coverage in Canada varies on some items. For full details call
Sears Canada at 1-800-361-6665.
Sears Installation Service
For Sears professional installation of home appliances, garage door
openers, water heaters, and other major home items, in the U.S.A. or
Canada call 1-800-4-MY-HOME%
Acuerdos maestros de proteccion
Enhorabuena por haber hecho una compra inteligente. Su nuevo
producto Kenmore®est& diseSado y fabricado para bdndade ahos de
funcionamiento fiable. Pero, como cualquier producto, puede necesitar
mantenimiento preventivo o reparaciones peri6dicas. Es pot eso que
tenet un Acuerdo maestro de protecci6n podfia ahorrade dinero y
molestias.
El Acuerdo maestro de protecci6n tambi_n sirve para prolongar la
durabilidad de su nuevo producto. El acuerdo* incluye Io siguiente:
[] Piezas y mano de obra necesarias para contribuir a mantener el
funcionamiento adecuado de los productos utilizados en
condiciones normales de uso, no s61o en caso de defectos de los
productos. Nuestra cobertura va mucho m&s all& que la garantia
del producto. No se aplican deducibles ni exclusiones pot fallas del
funcionamiento: es decir, verdadera protecci6n.
[] Servicio t_cnico por expertos (mas de 10000 t_cnicos
autorizados de Sears), Io cual significa que quien repare o realice
el mantenimiento de su producto sera un profesional de confianza.
[] Servicio t_cnico a escala nacional y ntimero ilimitado de
Ilamadas de solicitud de servicio t_cnico: se puede poner en
contacto con nosotros cuantas veces Io desee y cuando Io desee.
[] Garantia "sin sorpresas": se reemplaza el producto cubierto por el
acuerdo si ocurren cuatro o m_ts fallas del producto en un periodo
de 12 meses.
[] Reemplazo del producto: en caso de que no se pueda reparar el
producto cubierto por el acuerdo.
[] Revisi6n anual preventiva de mantenimiento del producto:
puede solicitarla en cualquier momento, sin costo alguno.
[] R&pida asistencia telef6nica, la cual denominamos Soluci6n
r&pida: es decir, asistencia telef6nica a trav6s de cualquiera de
nuestros representantes de Sears, sobre cualquiera de nuestros
productos. Piense en nosotros como en un "manual parlante del
usuado".
[] Protecci6n contra fallas el_ctricas, contra daSos debidos a
fluctuaciones de la corriente el6ctrica.
[] $250 al a_o para cubrir cualquier posible deterioro de
alimentos que haya tenido que desechar debido a una falla
mec&nica de cualquiera de nuestros refdgeradores o congeladores
cubiertos por este acuerdo.
[] Devoluci6n de gastos de alquiler de electrodom_sticos si la
reparaci6n de su producto asegurado toma masque el tiempo
prometido.
[] 10% de descuento aplicable tanto a los costos del servicio de
reparaci6n, como de las piezas instaladas relacionadas que no
hayan quedado cubiertos pot este acuerdo.
Una vez que haya realizado el pago de este acuerdo, bastara una simple
Ilamada telef6nica para concertar una visita de servicio. Puede Ilamar a
cualquier hora del dia o de la noche, o bien concertar una visita de
servicio pot Internet.
La adquisici6n del Acuerdo maestro de protecci6n es una inversi6n
exenta de desgos. Si por cualquier motivo decide cancelar dicho acuerdo
durante el periodo de garantia del producto, le haremos un reintegro total
del valor. O bien un importe proporcional si cancela el acuerdo en
cualquier otto momento posterior al vencimiento del periodo de garantia
del producto, iAdquiera hoy mismo su Acuerdo maestro de protecci6n!
Algunas limitaciones y exclusiones podrian aplicarse. Para solicitar
precios e informaci6n adicional, Ilame al 1-800-827-6655 (en los
EE.UU.).
* La cobertura en Canad& varia en el caso de algunos articulos. Para
obtener detalles completos al respecto, Ilame al 1-800-361-6665 de
Sears de Canad&.
Servicio de instalacion de Sears
Para solicitar la instalaciSn por profesionales de Sears de
electrodom6sticos, abridores de puertas de garaje, calentadores de agua
y otros articulos de uso prioritario en el hogar, Ilame al 1-800-4-MY-
HOME en los EE.UU. o CanadA.
Before Setting Oven Controls
OVEN VENT
Fig. ]
Fig. 2
Oven Vent Location
The oven vent islocated below the backguard (See Fig. 1). When the oven
ison, warm air is released through this vent. This venting is necessary for
proper air circulation in the oven and good baking results. DO NOT BLOCK THE
VENT.
Arranging Oven Racks
ALWAYS ARRANGE OVEN RACKS WHEN THE OVEN IS COOL (PRIOR TO
OPERATING THE OVEN). Always use oven mitts when using the oven.
Removing & Replacing Oven Racks
To remove, pull the rack forward until it stops. Lift up front of rack and
slide out. To replace, fit the rack onto the guides on the oven walls. Tilt
the front of the rack upward and slide the rack back into place.
Recommended Rack Positions for Broiling, Baking & Roasting:
Food
Broilinq hamburqers & steaks
Broiling meats, chicken or fish
Cookies, cakes, pies, biscuits & Muffins
Frozen pies, angel food cake,
yeast, bread, casseroles, small
cuts of meat or poultry
Turkey, roast or ham
Position
See Broil
See Broil
2or3
1 or Roasting Shelf
1 or Roasting Shelf
Types of Oven Racks
Your range may be equipped with one or more of the oven rack
types shown; Flat Rack, or Handle Rack.
Flat Handle
Oven Rack Oven Rack
Baking Layer Cakes with 1 or 2Oven Racks
For best results when baking cakes using 2 oven racks, place cookware on oven rack positions 1 & 4 (Refer to Figs. 2 & 3).
When using a single oven rack, place cookware on oven rack position 2 or 3 (Refer to Figs. 2 & 4).
Air Circulation in the Oven
For best air circulation and baking
results allow 2-4" (5-10 cm) around
the cookware for proper air circulation
and be sure pans and cookware do not
touch each other, the oven door, sides
or back of the oven cavity. The hot air
must be able to circulate around the
pans and cookware in the oven for
even heat to reach around the food.
Fig. 3 Fig. 4
Setting Surface Controls
Do not place plastic
items such as salt and pepper shakers,
spoon holders or plastic wrappings
on top of the range when it is in use.
These items could melt or ignite.
Potholders, towels or wood spoons could
catch fire if placed too close to a flame.
Inthe event of an electrical power outage,
the surface burners can be lit manually.
To light a surface burner, hold a lit match
to the burner head, then slowly turn the
surface control knob to LiTE. Afterburner
lights push in and turn knob to desired
setting. Use caution when lighting surface
burners manually.
Setting Surface Controls
Your range may be equipped with different sized surface burners. The ability to
heat food quicker and in larger volumes increases as the burner size increases.
The SIMMER burner (some models) isbest used for simmering delicate sauces,
etc.
The standard burners can be used for most surface cooking needs.
The POWER burner or burners (some models) are best used for bringing large
quantities of liquid to temperature and when preparing larger quantities of food.
Regardless of size, always select cookware that is suitable for the amount and
type of food being prepared. Select a bumerand flame size appropriate to the pan.
Never allow flames to extend beyond the outer edge of the pan.
Operating the Gas Surface Burners:
1. Place cooking utensil on surface burner.
2. Push the surface control knob in and turn counterclockwise out of the OFF
position.
3. Release the knob and rotate to the LITE position. Note: All four electronic
surface ignitorswill spark at the same time. However, only the burner you are
turning on will ignite.
3. Visually check that the burner has lit.
4. Push the control knob inand tum counterclockwise to the desired flame size.
The control knobs do not have to be set at a particular setting. Use the guides
and adjust the flame as needed. DO NOT cook with the surface control knob
in the LITE position. (The electronic ignitor will continue to spark ifthe knob
is left in the LITE position.)
CORRECT
Setting Proper Surface Burner Flame Size
Formost cooking, start on the highest control setting and then turn to a lower
one to complete the process. Use the recommendations below as a guide for
determining proper flame size for various types of cooking. The size and type
of utensil used and the amount of food being cooked will influence the setting
needed forcooking.
iNCORRECT
*Flame Size
High Flame
Medium Flame
Low Flame
Type of Cooking
Start most foods; bring water to a boil; pan broiling.
Maintain a slow boil; thicken sauces, gravies; steaming.
Keep foods cooking; poach; stewing.
Never extend the flame beyond the outer]
edge ofthe utensil. A higher flame simply /
wastes heat and energy, and increases /
your risk of being burned by the flame. J
For deep fat frying, use a thermometer and adjust the surface control knob
accordingly, if the fat is too cool, the food will absorb the fat and be greasy, if
the fat is too hot, the food will brown so quickly that the center will be
undercooked. Do not attempt to deep fat fry too much food at once as the food
will neither brown nor cook properly.
*These settings are based on using medium=weight metal or aluminum pans with lids. Settings may vary when using
other types of pans. The color of the flame isthe key to proper burner adjustment. A good flame isclear, blue and hardly visible
in a well-lighted room. Each cone of flame should be steady and sharp. Adjust or clean burner ifflame is yellow-orange.
Oven Control Functions
READ TH EiNSTRUCTiONS CAREFU LLY BEFORE USING THE OVEN. Forsatisfactory use ofyour oven, become familiar with
the various pad functions of the oven as described below.
BROIL PAD Used to
select the variable broil
function.
CLOCK SET
PAD Used
to set the
time of da,.
TIMER ON/OFF
PAD-- Used lo se_
or cancel me minute
timer. The minute
1:liner does not slarl
or SlOP COOKing.
Also
TIMER ON/OFF oaa
s used to sel tile
Continuous Bake
feature.
UP and DOWN ARROW PADS Used along
with the function pads to select oven
temperature, time of day, clean time and
minutetimer, use.
® ®
0
®
Q
SELECT SELF-CLEAN
PAD-- Used to select the
Self-Cleaning cycle. A 2,
3 or 4 hour Self-Clean
time may be selected.
FEATUREINDICATOR
LIGHTS-- These light to
show which feature is in
BAKE PAD--Used to
select the bake function.
P
/
OVEN, PREHEAT & DOOR LOCKED LIGHTS* -- The "OVEN" light
will glow each time the oven turns on to maintain the set oven
temperature. The "PREHEAT" light will glow when the oven is first
set to operate, or if the desired temperature is reset higher than the
actual oven temperature. The "DOOR LOCKED" light will flash
when the oven door locks and unlocks or when using the Self-
Clean cycle or the oven door lockout is activated. The indicator light
will glow constantly after the door locks.
*Note;The OVEN indicator light on the electronic display
will turn ON and OFF when using the Bake feature and
during preheat. This is normal and indicates that the oven
is cycling to maintain the selected baking temperature.
When the preheat indicator !ight turns OFF, your oven is
ready.
Temperature conversion
The electronic oven control isset to operate in °F
(Fahrenheit) when shipped from the factory. The oven can
be programmed for any temperature from 170°F to 550°F
(77°C to 287°C).
STOP/CLEAR PAD--
Used to clear any
function previously
entered except the time
of day and minute timer.
Press STOP/CLEAR to
stop cooking. Also the
STOP/CLEAR pad is
used to activate Oven
Lockout setting.
To change the temperature to °C (Celsius) or from °C to
°F (control should not be in a Bake or Clean mode):
f_
1. Press B,o_.... appears in the display.
2. Press and hold the Jk until "HI" appears in the
display.
3. Press and hold B,,, until °F or °C appears in the display.
4. Press the J%. or V to change °F to °C or °C to °F.
5. Press any control pad to return to normal operating
mode.
Setting Oven Controls
NOte: The time of day must firSt beset in 0rder t0 operate
theoven.
To Set the Clock
When the range isfirst plugged in, or when the power
supply to the range has been interrupted, the display will
flash "12:00".
,Press the A to increase the time in one minute
increments. Press and hold the _ to increase the
time in 10 minute increments. The timer can be set for
any amount of time from 1 minute to 11 hours and 59
minutes.
1. Press _ once (do not hold pad down).
2. Within 5 seconds, press and hold the _ or V until 3.
the correct time of day appears in the display.
Note: The clock cannot be changed during a Self-Clean
cycle. 4.
To Set the Minute Timer:
1. Press @.
Note: If the V pad is pressed first, the timer will
advance to 11 hours and 59 minutes.
The display shows the timer countdown in minutes until
1 minute remains. Then the display will countdown in
seconds.
When the set time has run out, the timer will beep 3
times and will continue to beep 3 times every 60
seconds until @ is pressed.
_;:,igi:i_
Setting Oven Controls (cont'd)
Note: The indicator light located above the _ pad will glow
while the minute timer is active.
Note: The minute timer does not start or stop cooking. It
serves as an extra timer in the kitchen that will beep when
the set time has run out. The minute timer can be used
alone or during any of the other oven functions. When the
minute timer is in use with any other function, the minute
timer will be shown in the display. To view other functions,
press the pad for that function.
To Change the Minute Timer while it is in use:
While the timer is active and shows in the display, press
and hold the iN, or V to increase or decrease the time.
To Cancel the Minute Timer before the set time has run
out: Press @.
Note: To turn the time of day display OFF or ON in the
_-_ and hold for 15 seconds (the controldisplay press v
will beep once) and then release. This feature does not
remove the set time of day from the memory of the
control. When the display is turned OFF the time of day
will re-appear for a few seconds any time the _{_ pad is
touched.
To Set or Change the Temperature for Baking
The oven can be programmed to bake at any temperature
from 170°F to 550°F (77°C to 287°C).
To Set the Controls for Baking:
1. Press e,k_. " "appears in the display.
,Within 5 seconds, press the J_, or V. The display
will show"350°F (177°C). '' By pressing and holding
the A or V, the temperature can then be adjusted
in 5°F increments (1°C if the control is set to display
Celsius).
3. As soon as the A or V pad is released, the oven will
begin heating to the selected temperature. When the
displayed temperature reaches the desired baking
temperature, the preheat indicator light will turn OFF and
the control will beep 3 times.
4. To cancel baking, press _.
displayed.
2. Press the/N, or V pad to increase or decrease the
settemperature.
To Set Control for Continuous Bake or 12
Hour Energy Saving
The oven control has a built-in 12 Hour Energy Saving
feature that will shut off the oven if the control is left on for
more than 11 hours and 59 minutes. The oven can be
programmed to override this feature for continuous baking.
To set control for continuous baking:
1. Press and hold @ down for 5 seconds until tone is
heard, "-- -- hr" will appear in display for continuous
cooking. The current time of day will return to the
display.
2. To cancel the Continuous Bake function, press
and hold for 5 seconds until tone is heard. "12hr" will
appear in display indicating that the control has
returned to the 12 Hour Energy Saving feature.
To Set Control for Oven Lockout Oven
Lockout
The control can be programmed to lock the oven door and
lockout the oven control pads.
To set Control for Oven Lockout feature:
1. Press _ and hold for 3 seconds. "Loc" will appear in
display, the "Door Locked" indicator light will flash and
the motor driven door lock will begin to close
automatically. DO NOT open oven door while the
indicator light isflashing. Allow about 15 seconds for
the oven door to lock. Once the oven door is locked, the
current time of day will appear in the display.
2. To cancel the Oven Lockout feature, press _ and
hold for 3 seconds. The control will unlock the oven
door and resume normal operation.
Note: a.yContropad pressedwh,e theOven
Lockout mode, "Loc" will appear inthe display until
the control pad is released.
To Change the Oven Temperature after Baking has
Started:
1. Press Bakeand make sure the bake temperature is
10
