Kenmore 970-6871 Series User manual

ENGLISH
p/n316417238(0601)
Models, Modèles 970-6871*
* = color number, numéro de couleur
Electric Range
Use and Care Guide
Cuisinière électrique
Guide d’utilisation et d’entretien
FRANÇAIS
Sears Canada Inc.,Toronto,
Ontario, Canada, M5B 2B8
On the internet visit :www.sears.ca

2
In the space below record the date of purchase, model and
serial number of your product. You will find the model and
serialnumber printedon anidentification plate. Thisserial
plate is located on the right side of the oven front frame in
the storage or warmer drawer compartment. See bottom of
this page for the serial plate location.
Model No. _____________________________________
SerialNo. _____________________________________
DateofPurchase ________________________________
Savethese instructionsand yoursales receipt forfuture
reference.
Table of Contents
Free-StandingRangeWarranty ......................................... 2
ProductRecord ................................................................. 2
IMPORTANTSAFETYINSTRUCTIONS .........................3-4
ProtectionAgreements...................................................... 5
RangeFeatures ................................................................ 6
BeforeSettingOvenControls ..........................................7-8
SettingSurfaceControls ...............................................9-10
SurfaceCooking...............................................................11
OvenControlFunctions ....................................................12
SettingOvenControls .................................................13-28
SettingWarmerDrawer Controls .................................29-30
SelfCleaning...............................................................31-33
AdjustingYourOvenTemperature.....................................34
GeneralCare&Cleaning .............................................35-38
BeforeYou Make aService Call .......................................39
SlowCook Recipes ..........................................................40
SearsService..................................................... Back Page
Product Record
970-
Serial plate location; Open
the Warmer Drawer (some models)
or storage drawer (some models).
SerialPlateLocation
You will find the model and serial number printed on the serial plate. The
serial plate is located on the right side of the oven front frame in the
storageorwarmerdrawercompartment.
Remembertorecordtheserialnumberforfuturereference(Seetopof
pageunderProductRecord).
KenmoreAppliance Warranty
One Year Limited Warranty
When installed, operated and maintained according to all instructions supplied with the product, if this appliance fails due to a defect
in material or workmanship within one year from the date of purchase, call 1-800-4-MY-HOME ® to arrange for free repair. If this
appliance is used for other than private family purposes, this warranty applies for only 90 days from the date of purchase.
This warranty covers only defects in material and workmanship. Sears will NOT pay for:
1. Expendable items that can wear out from normal use, including but not limited to filters, belts, light bulbs, and bags.
2. A service technician to instruct the user in correct product installation, operation or maintenance.
3. A service technician to clean or maintain this product.
4. Damage to or failure of this product if it is not installed, operated or maintained according to all instructions supplied with the
product.
5. Damage to or failure of this product resulting from accident, abuse, misuse or use for other than its intended purpose.
6. Damage to or failure of this product caused by the use of detergents, cleaners, chemicals or utensils other than those
recommended in all instructions supplied with the product.
7. Damage to or failure of parts or systems resulting from unauthorized modifications made to this product.
Disclaimer of implied warranties; limitation of remedies
Customer’s sole and exclusive remedy under this limited warranty shall be product repair as provided herein. Implied warranties,
including warranties of merchantability or fitness for a particular purpose, are limited to one year or the shortest period allowed by
law. Sears shall not be liable for incidental or consequential damages. Some states and provinces do not allow the exclusion or
limitation of incidental or consequential damages, or limitations on the duration of implied warranties of merchantability or fitness,
so these exclusions or limitation may not apply to you.
This warranty applies only while this appliance is used in the United States and Canada.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., Dept. 817WA, Hoffman Estates, IL 60179
Sears Canada Inc., Toronto, Ontario, Canada M5B 2B8

ENGLISH
3
Read all instructions before using this appliance. Save these instructions for future reference.
This manual contains important safety symbols and instructions. Please pay attention to these symbols and follow all instructions given.
This symbol will help alert you to situations that may cause serious bodily harm, death or property damage.
This symbol will help alert you to situations that may cause bodily injury or property damage.
Important Safety Instructions
• Removeall tape and packaging before using therange.
Destroy the carton and plastic bags after unpacking the
range.Neverallowchildrentoplaywithpackagingmaterial.
• ProperInstallation—Besureyour applianceisproperly
installed and grounded by a qualified technician in
accordance with the National Electrical Code ANSI/
NFPA No. 70 latest edition and local electrical code
requirements.Installonlyperinstallationinstructionsprovided
in the literature package for this range.
Askyourdealertorecommendaqualifiedtechnicianandan
authorizedrepairservice.Knowhowtodisconnectthepower
to the range at the circuit breaker or fuse box in case of an
emergency.
• Userservicing—Donotrepairorreplaceanypartofthe
appliance unless specifically recommended in the
manuals. All other servicing should be done only by a
qualified technician. This may reduce the risk of personal
injuryand damage totherange.
• Never modify or alter the construction of a range by
removing leveling legs, panels, wire covers, anti-tip
brackets/screws, or any other part of the product.
Do not store items of interest tochildrenin
the cabinets above a range or on the backguard of a
range.Childrenclimbingontherangetoreachitemscouldbe
seriouslyinjured.
Stepping,leaningorsittingonthedoorsor
drawers of this range can result in serious injuries and
also cause damage to the range. Do not allow children to
climborplayaroundtherange.Theweightofachildonanopen
doormay causethe rangeto tip, resultingin seriousburns or
otherinjury.
Never Use Your Appliance for Warming
or Heating the Room.
• Storage in or on Appliance—Flammable materials
should not be stored in an oven, warmer drawer, near
surface units or in the storage drawer. This includes
paper,plasticandclothitems,suchascookbooks,plasticware
and towels, as well as flammable liquids. Do not store
explosives, such as aerosol cans, on or near the range.
• Do Not Leave Children Alone—Children should not be
left alone or unattended in the area where appliance is
in use. They should never be allowed to sit or stand on any
partoftheappliance.
• DONOTTOUCHSURFACEUNITS,AREASNEARTHESE
UNITS,HEATINGELEMENTSORINTERIORSURFACES
OFTHEOVEN.Bothsurfaceunitsandovenheatingelements
may be hot even though they are dark in color. Areas near
surfaceunitsmaybecomehotenoughtocauseburns.During
andafteruse,donottouch,orletclothingorotherflammable
materialstouchtheseareasuntiltheyhavehadsufficienttime
tocool.Amongtheseareasarethecooktop,surfacesfacing
thecooktop,theovenventopeningsandsurfacesnearthese
openings,ovendoorandwindow.
• WearProperApparel—Loose-fittingorhanginggarments
should never be worn while using the appliance. Donot
letclothingorotherflammablematerialscontacthotsurfaces.
• Do Not Use Water or Flour on Grease Fires—Smother
the fire with a pan lid, or use baking soda, a dry
chemical or foam-type extinguisher.
• When heating fat or grease, watch it closely. Fat or
grease may catch fire if allowed to become too hot.
• UseOnly DryPotholders-Moistordamppotholders on
hot surfaces may result in burns from steam. Do not let
potholderstouchhotheatingelements.Donotuseatowelor
other bulky cloth instead of a potholder.
• Do Not Heat Unopened Food Containers - Buildup of
pressure may cause container to burst and result in
injury.
• Remove the oven door from any unused range if it is to
be stored or discarded.
IMPORTANT—Donotattempttooperatetherangeduring
a power failure. If the power fails, always turn off the range.
Iftherangeisnotturnedoffandthepowerresumes,therange
willbegintooperateagain.Oncethepowerresumes,resetthe
clockandovenfunction.
Do not use the oven or warmer drawer
(if equipped) for storage.

4
Important Safety Instructions
IMPORTANTINSTRUCTIONSFORUSINGYOUR
COOKTOP
• Knowwhich knob controls each surfaceheating unit.Place a
pan of food on the unit before turning it on, and turn the unit off
before removing the pan.
• Use Proper Pan Size—This appliance is equipped with one or
more surface units of different sizes. Select utensils having flat
bottoms large enough to cover the surface unit heating element.
The use of undersized utensils will expose a portion of the
heating element to direct contact and may result in ignition of
clothing. Proper relationship of utensil to element will also
improve efficiency.
• UtensilHandlesShouldBeTurnedInwardandNotExtendOver
AdjacentSurfaceElements—Toreducetheriskofburns,ignition
of flammable materials, and spillage due to unintentional contact
with the utensil, the handle of the utensil should be positioned so
thatitisturnedinward,anddoes notextendoveradjacentsurface
units.
• Never Leave Surface Elements Unattended at High Heat
Settings—Boilovers cause smoking and greasy spillovers that
may ignite, or a pan that has boiled dry may melt.
• Do Not Immerse or Soak Removable Heating Elements—
Heating elements should never be immersed in water. Heating
elements clean themselves during normal operation.
• Glazed Cooking Utensils—Only certain types of glass, glass/
ceramic, ceramic, earthenware, or other glazed utensils are
suitable for cook top service without breaking due to the sudden
change in temperature. Check the manufacturer’s
recommendations for cook top use.
• Whenflamingfoodsunderaventilatinghood, turn the fan on.
IMPORTANTINSTRUCTIONSFORUSINGYOUR
OVEN
• Use Care When Opening Oven Door or Warmer Drawer (if
equipped)—Standtothesideoftherangewhenopeningthedoor
of a hot oven. Let hot air or steam escape before you remove or
replace food in the oven.
• Keep Oven Vent Ducts Unobstructed. The oven vent islocated
under the left rear surface element if your model is equipped with
coil elements. The oven vent is located below the backguard for
models equipped with ceramic-glass cook tops. Touching the
surfaces in this area when the oven is operating may cause
severe burns. Also, do not place plastic or heat-sensitive items
on or near the oven vent. These items could melt or ignite.
• Placement of Oven Racks. Always place oven racks in desired
location while oven is cool. If rack must be moved while oven is
hot use extreme caution. Use potholders and grasp the rack with
both hands to reposition. Do not let potholders contact the hot
heating elements in the oven. Remove all utensils from the rack
before moving.
• Donotusethebroilerpanwithoutitsinsert.Thebroilerpanand
itsinsertallowdrippingfat todrainandbekept awayfromthehigh
heat of the broiler.
• Donotcoverthebroilerinsertwithaluminumfoil.Exposedfat
and grease could ignite.
• Protective Liners—Do not use aluminum foil to line the oven
bottom. Only use aluminum foil as recommended in this manual.
Improper installation of these liners may result in risk of electric
shock, or fire.
SELF CLEANING OVENS
• Clean in the self-cleaning cycle only the parts listed in this Use & Care Manual. Before self cleaning the oven, remove the broiler
pan and any utensils or foods from the oven.
• Do Not Use Oven Cleaners—No commercial oven cleaner or oven liner protective coating of any kind should be used in or around
any part of the oven.
• DoNot Clean DoorGasket—Thedoorgasketisessentialforagoodseal. Careshouldbe takennotto rub,damageor movethegasket.
•The health of some birds is extremely sensitive to the fumes given off during the self-cleaning cycle of any range. Move birds to another
well-ventilated room.
IMPORTANT INSTRUCTIONS FOR CLEANING YOUR RANGE
• Clean the range regularly to keep all parts free of grease that could catch fire. Pay particular attentionto the areaunderneath each
surface element. Do not allow grease to accumulate.
• Kitchen cleaners and aerosols—Always follow the manufacturer’s recommended directions for use. Be aware that excess
residue from cleaners and aerosols may ignite causing damage and injury.
• Clean Ventilating Hoods Frequently—Grease should not be allowed to accumulate on the hood or filter. Follow manufacturer’s
instructions for cleaning.
FOR CERAMIC-GLASS COOK TOP MODELS
• Do Not Cook on Broken Cook Top—If cook top should break, cleaning solutions and spillovers may penetrate the broken cook top
and create a risk of electric shock. Contact a qualified technician immediately.
• Clean Cook Top with Caution—If a wet sponge or cloth is used to wipe spills on a hot cooking area, be careful to avoid a steam burn.
Some cleaners can produce noxious fumes if applied to a hot surface.
Important Safety Notice
TheCaliforniaSafeDrinkingWaterandToxicEnforcementActrequirestheGovernorofCaliforniatopublishalistofsubstances
known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to warn customers of
potential exposure to such substances.

ENGLISH
5
PROTECTION AGREEMENTS CONTRATS DE PROTECTION
Au Canada
Contrats d'entretien
Votre achataunevaleur supplémentaireparcequevous
pouvezcompter sur leHomeCentral®de Sears pourun
serviceaprès-vente.Avecplus de 2400spécialistes formés
àl'entretien et un accès àplus de 1 000 000 pièces et
accessoires, nous avons les outils, les pièces, le savoir et
letalent pour répondreàvotredemande :nousréparons ce
quenousvendons.
Votre produitKenmore®estconçu, fabriquéetessayépour
vousassurerdes années d'un fonctionnementfiable.
Cependant,comme tout appareilménager,ilpeut
nécessiter un entretien de temps àautre. Le contrat
d'entretienSearsvousoffreunremarquable programme de
serviceàunprix abordable.
Contrat d'entretien Sears :
•Estvotremanière d'acheter unservicepour demain au
prixd'aujourd'hui.
•Éliminefactures de réparationrésultantd'usurenormale.
•Fournitune assistance téléphoniqueparun technicien
Searspour lesproduitsnécessitant undépannageà
domicile.
•Mêmesivousn'avez pasbesoinderéparation, vous
fournituncontrôled'entretienpréventifannuelàvotre
demande,pourvous assurerquevotreproduit estenbon
état de marche.
Certaines limites s'appliquent. Pour de plus amples
renseignements sur les contrats d'Entret
ien Sears
Canada, composez le 1-800-361-6665.
Maintenance Agreements
Your purchasehas added valuebecauseyou candependon
SearsHomeCentral®for service.Withover2400 Service
Technicians and more than a million parts and accessories,
we have the tools, parts, knowledge and skills to ensure our
pledge: We Service What We Sell.
Your Kenmore®product is designed,manufacturedand
testedto provideyearsof dependableoperation. But likeall
products, it may require service from time to time. The
SearsMaintenanceAgreementoffersyou an outstanding
serviceprogram,affordablypriced.
The Sears Maintenance Agreement:
•Is your way to buy tomorrow’s service at today’s price.
•Eliminatesrepair bills resultingfrom normal wearand
tear.
•Providesphone support fromaSears technicianon
productsrequiring in-homerepair.
•Evenifyou don’tneed repairs,providesan annual
PreventativeMaintenance Check, atyourrequest, to
ensurethat yourproduct is inproper running condition.
Some limitations apply. For more information about
Sears Canada Maintenance Agreements,
call1-800-361-6665.
In Canada

6
Range Features
Your Electric Range Features Include:
1. Electronic Oven Control with Kitchen Timer.
2. Simmer Select Element Control (some models) or
Single Radiant Element Control (some models) or Single
Radiant Power Boil Control (some models).
3. Single Radiant Element Control.
4. Warm & Ready Drawer Control & Indicator Light (some
models).
5. Warm & Ready Zone & Surface Indicator Light (some models).
6. Single Radiant Element Control.
7. Single Radiant Element Control (some models) or Dual
Element Radiant Control (some models).
8. Simmer Select Push Button & Indicator Light (some models).
9. HOT SURFACE Indicator Lights.
10. “ELEMENT ON”Indicator Light.
11. Oven Interior Light with removable Cover.
12. Automatic Oven Door Light Switch (some models).
13. Self-Cleaning Oven interior.
14. Self-Clean Door Latch.
15. Adjustable Oven Rack(s).
16. Convection Fan & Cover.
17. Large 1 piece Oven Door Handle.
18. Full width Oven Door with Window.
19. Warm & Ready Drawer (some models) or Storage Drawer with
Drawer Handle.
20. Easy to clean upswept Cooktop.
21. Ceramic Smoothtop.
22. 6”Single Radiant Element(s).
23. 9”Single Radiant Element (some models).
24. 9”Single Radiant “Power Element”(some models).
9
5 6 7
9
99
4
83
2
NOTE:Thefeaturesofyourrangemay
vary according to model type & color.
10
12
15
13
14
11
25. 6-9”Dual Radiant Element (some
models).
26. 9-12”Dual Radiant Element (some
models).
27. Warm & Ready Zone Radiant
Element (some models).
28. Broil Pan (some models).
29. Broil Pan Insert (some models).
30. Roasting Rack.
31. Leveling Legs and Anti-tip Bracket
(included).
1
16
17
18
19
20
21
21
22 22
23
24
23
25
26
27
28
29
30
31

7
ENGLISH
Before Setting Oven Controls
Oven Vent Location
The oven vent is located under the left side of the control panel (See
Fig. 1). When the oven is on, warm air passes through the vent. This
ventingisnecessaryfor proper air circulationintheovenandgood baking
results.DO NOTBLOCK OVENVENT.
Arranging Oven Racks
ALWAYS ARRANGE OVEN RACKS WHEN THE OVEN IS COOL (PRIOR TO
OPERATING THE OVEN). Refer to Fig. 2. Always use oven mitts when using the oven.
Removing & Replacing Oven Racks
To remove, pull the rack forward until it stops. Lift up front of rack and
slide out. To replace, fit the rack onto the guides on the oven walls. Tilt
the front of the rack upward and slide the rack back into place.
Fig. 1
Fig. 2
Types of Oven Racks
Your range may be equipped with one or more of the oven rack types shown; Flat Rack (Fig. 3), Flat Handle Rack (Fig. 4)
and the Offset Rack (Fig. 5).
FlatOvenRack Offset Oven Rack
(some models)
Always use pot holders or oven mitts when adjusting the oven racks. Wait until the oven has completely
cooled if possible. Oven racks may be HOT and may cause burns.
Fig. 3 Fig. 4
Recommended Rack Positions for Broiling, Baking & Roasting:
Food RackPosition
Broilinghamburgers &steaks See Broil
Broiling meats, chicken or fish See Broil
Cookies, cakes, pies, biscuits & Muffins 3 or 4
Frozen pies, angel food cake, yeast, bread,
casseroles, small cuts of meat or poultry 1 or 2
Turkey,roastorham 1orRoastingShelf
For best air circulation and baking
results allow 2-4" (5-10 cm) around
thecookwareforproperaircirculation
andbesurepansandcookwaredonot
toucheachother,theovendoor,sides
orbackoftheovencavity.Thehotair
must be able to circulate around the
pans and cookware in the oven for
evenheattoreacharoundthefood.
Air Circulation in the Oven
Fig. 5
Fig. 6
Baking Layer Cakes with 1 or 2 Oven Racks
For best results when baking cakes using 2 oven racks, place cookware on rack positions 2 (Flat Oven Rack or Flat Handle
Oven Rack) & 5 with the Offset Oven Rack (some models; See Fig. 6). For best results when using a single oven rack,
place cookware on rack positions 3 or 4 (See Fig. 7).
FlatHandleOvenRack
Fig. 7
Roasting
Shelf
1
2
3
4
5
6

8
ELEMENT ON and Hot Surface Indicator Lights
Yourrangeisequippedwith two differenttypesofradiantsurfacecontrol
indicatorlights thatwill glow onyour range—theELEMENT ON
indicator light and the Hot Surface indicator lights (See illustration at
left).TheELEMENT ON locatedon the control panel and will glowwhen
a surface element is turned ON. A quick glance at this indicator light
after cooking is an easy check to be sure ALL surface controls are
turnedOFF.
The Hot Surface indicator lights located above each surface radiant
control knob will glow as the surface cooking area heats up and will
REMAIN ON until the glass cooktop has cooled to a MODERATE level.
About the Ceramic Glass Cooktop
The ceramic cooktop has radiant surface elements located below the surface of the glass. The design of the ceramic
cooktop outlines the area of the surface element underneath. Be sure to match the pan size with the diameter of the
element outline on the cooktop. Heat is transferred up through the surface of the cooktop to the cookware. Only flat-
bottomedcookwareshouldbeused.
The type and size of cookware, the number of surface elements in use and their settings, are all factors that will affect the
amountof heatthat willspread to areasbeyond thesurface elements.The areas surrounding the elementsmay become
hot enough to cause burns.
NOTE: Please read detailed instructions for ceramic glass cooktop cleaning in the General Care & Cleaning and Before
You Call checklist sections of this Use & Care Guide.
NOTE: Radiant elements have a limiter that allows the element to cycle ON and OFF, even at the HI setting. This helps to
prevent damage to the ceramic smooth top. Cycling at the HI setting is normal and will occur more often if the cookware
is too small for the radiant element or if the cookware bottom is not flat.
About the Radiant Surface Elements
Theelementtemperaturerisesgraduallyandevenly.
As the temperature rises, the element will glow red.
To maintain the selected setting, the element will
cycleon andoff. The heatingelement retains
enoughheattoprovideauniformandconsistent
heat during the off cycle.
Forefficientcooking,turnofftheelementseveral
minutes before cooking is complete. This will allow
residual heat to complete the cooking process.
Warmer Zone
Surface Control
(some models)
Single Radiant
Surface Control
(some models)
Single Radiant (some models)
Dual Radiant (some models)
Surface Control
Before Setting Oven Controls (cont’d)
Radiantsurfaceelementsmay appear tohavecooledaftertheyhavebeen turned off.Theglass surface
may still be hot and burns may occur if the glass surface is touched before it has cooled sufficiently.
Do not place plastic items such as salt and pepper shakers, spoon holders or plastic wrappings on
top of the range when it is in use. These items could melt or ignite. Potholders, towels or wooden spoons could catch
fire if placed too close to the surface elements.
Do not allow aluminum foil, empty glass/porcelain cookware or ANY material that can melt to
make contact with the ceramic cooktop. If these items melt on the cooktop they WILL damage the ceramic cooktop.

9
ENGLISH
To Operate a Single Radiant Element:
1. Place correctly sized cookware on the radiant surface element.
2. Push in and turn the surface control knob in either direction to the desired setting (See Fig.
1). Start most cooking operations on a higher setting and then turn to a lower setting to
finish cooking. The surface control knobs do not have to be set exactly on a particular mark.
Use the marks as a guide and adjust the control knob as needed. Each surface element
provides a constant amount of heat at each setting. A glowing red surface heating area
extending beyond the bottom edge of the cookware indicates the cookware is too small for
thesurfaceheatingarea.
3. Whencookingiscomplete,turnthesurface element OFFbeforeremovingthecookware.
Note:The ELEMENT ON indicatorlightwillglowwhen one ormoreelementsareturned ON.
A quick glance at this indicator light when cooking is finished is an easy check to be sure all
control knobs are turned OFF. The Hot Surface indicator light will continue to glow AFTER
the control knob is turned to the “OFF”position and will glow until the heating surface area
hascooledsufficiently.
Single Radiant Surface Elements (all models)
Setting Surface Controls
Thesuggestedsettings found inthetable below arebasedoncooking in medium-weight
aluminum pans with lids. Settings may vary when using other types of pans.
STANDARDSETTINGFORSURFACEELEMENTS
Setting TypeofCooking
HIGH (HI - 9) Start most foods, bring water to a boil, pan broiling
MEDIUM HIGH (7 - 8) Continue a rapid boil, fry, deep fat fry
MEDIUM (5 - 6) Maintain a slow boil, thicken sauces and gravies, steam vegetables
MEDIUM LOW (2 - 4) Keep foods cooking, poach, stew
LOW (LO - 1) Keep warm, melt, simmer
SIMMERSELECTSURFACEELEMENT
Max. Simmer (4) Larger quantities of food, stews and soups
Min. Simmer (LO) Smaller quanitites of food, delicate foods, melting chocolate or butter
Simmer Select Surface Element(some models)
The left front element control may be used as a normal element or as a simmer element. The “Simmer Select”feature heats
the element at a much lower temperature than when used as a normal surface element. You may switch between normal
cooking and the Simmer Select feature at any time during the cooking process. When using the element control for normal
cooking all of the settings on the control knob (LO to HI) function as normal.
To Start Simmer Select:
1. Place correctly sized cookware on the radiant surface element.
2. Push in the Simmer button located below the left front control knob.
3. Turn the surface control knob to the desired simmer setting within the dark band on the control knob (LO to 4). Use the
marks as a guide and adjust the control knob from LO to 4 as needed (see illustration below).The Simmer Select
indicator light will glow and remain ON while simmering (See Fig. 2).
4. To return to normal cooking, push in and release the “Simmer Select”button and the indicator light will turn OFF. When
cooking is complete, be sure to set the control knob to the OFF position.
Fig. 2
Fig. 1
Radiantsurfaceelementsmay appear tohavecooledaftertheyhavebeen turned off.Theglass surface
may still be hot and burns may occur if the glass surface is touched before it has cooled sufficiently.
Do not place plastic items such as salt and pepper shakers, spoon holders or plastic wrappings on
top of the range when it is in use. These items could melt or ignite. Potholders, towels or wooden spoons could catch
fire if placed too close to the surface elements.
Do not allow aluminum foil, empty glass/porcelain cookware or ANY material that can melt to
make contact with the ceramic cooktop. If these items melt on the cooktop they WILL damage the ceramic cooktop.

10
Setting the Warmer (Warm & Ready™) Zone (some models)
The purpose of the Warmer Zone is to keep hot cooked foods at serving
temperature. Always start with hot food. It is not recommended to heat cold
foodontheWarmerZone.
Allfood placedon theWarmer Zoneshould becovered with a lid oraluminum
foil to maintain quality. For best results, when warming pastries or breads, the
cover should have anopening to allow moisture to escape. Do not use plastic
wrap to cover food. Plastic may melt onto the surface and be very
difficult to clean.
Useonlydishware,utensilsandcookwarerecommendedforovenandcooktop
useontheWarmerZone.
Unlike the surface elements, the Warmer Zone will not glow red
when it is hot.
Alwaysusepotholdersorovenmittswhenremovingfoodfrom
the warm zone as cookware and plates will be hot.
Setting the Warmer (Warm & Ready™) Zone Control
1. To set the control, push in either direction and turn the knob (See Fig 2).
Thetemperaturesareapproximate,andaredesignatedbyHI,MEDand
LO. However, the control can be set at any position between HI and LO for
differentlevelsofheating.
2. When ready to serve, turn the control to OFF. The Warmer Zone will remain
warm until the indicator light goes OFF.
Temperature Selection - Refer to the chart at the side column for
recommended heating levels. If a particular food is not listed, start with the
medium level, and adjust as needed. Most foods can be kept at serving
temperaturesbyusingthemediumlevel.
Setting Surface Controls (cont’d)
Note: Use the Warmer Zone to keep cooked foods hot such as; vegetables,
gravies,casseroles,soups,stews,breads,pastriesandoven-safedinner
plates.
Warmer Zone Recommended Food
SettingsTable
FoodItem Heating
Level
Breads/Pastries LO
Casseroles LO
Dinner Plates with Food LO
Eggs LO
Gravies LO
Meats MED
Sauces MED
Soups (cream) MED
Stews MED
Vegetables MED
Fried Foods HI
Hot Beverages HI
Soups (liquid) HI
To Operate Dual Radiant Surface Element (some models)
Therightfrontcontrolknoboffersflexibiltyfordifferentsizedcookware with the
DualRadiantsurfaceelement.Theinnerelementalonecanbeused for smaller
orboththeinnerandouter in combination forlargercookware.
Tooperate theDual Radiant surfaceelement pushin the controlknob andturn
counterclockwise to operate the small inner coil or turn clockwise to operate
boththe innerand outerportions ofthe elementtogether (See Fig 1).
SINGLEANDDUALRADIANTSURFACEELEMENTS
Setting Type of Cooking
HIGH(HI - 9) Start most foods, bring water to a boil, pan broiling
MEDIUMHIGH(7-8) Continue a rapid boil, fry, deep fat fry
MEDIUM(5-6) Maintain a slow boil, thicken sauces and gravies or
steam vegetables
MEDIUMLOW(2 - 4) Keep foods cooking, poach, stew
LOW (LO - 1) Keep warm, melt, simmer
Note: The size and type of utensil used, and the amount and type of food being
cooked will influence the setting needed for best cooking results.
Single setting Dual setting
Dual Radiant heating areas
on ceramic smooth top (shown in black)
Fig. 1
Fig. 2

ENGLISH
11
Cookware Material Types
The cookware material determines how evenly and quickly heat is
transferred from the surface element to the pan bottom. The most
popular materials available are:
ALUMINUM - Excellent heat conductor. Some types of food will cause it
to darken (Anodized aluminum cookware resists staining & pitting). If
aluminum pans slide across the ceramic cooktop, they may leave metal
marks which will resemble scratches. Remove these marks immediately.
COPPER - Excellent heat conductor but discolors easily. May leave
metal marks on ceramic glass (see Aluminum above).
STAINLESS STEEL - Slow heat conductor with uneven cooking results.
Is durable, easy to clean and resists staining.
CAST IRON - A poor heat conductor however will retain heat very well.
Cooks evenly once cooking temperature is reached. Not recommended
for use on ceramic cooktops.
PORCELAIN-ENAMEL on METAL - Heating characteristics will vary
depending on base material. Porcelain-enamel coating must be smooth
to avoid scratching ceramic cooktops.
GLASS - Slow heat conductor. Not recommended for ceramic cooktop
surfaces because it may scratch the glass.
Using proper cookware
Using Power Element (some models)
The “Power Element”feature uses a higher wattage surface radiant element which can bring
food items to boil much quicker. The left front radiant element will be clearly marked if this
feature is available on your range (See Fig. 3). If equipped with the “Power Element”feature,
place the cookware on the left front surface element and follow the instructions “To Operate a
Single Radiant Element”in the Settings Surface Controls section.
To Set the Cooktop Lockout Feature
The pad is used to activate the Cooktop Lockout feature which will lock all surface elements from being accidentally
turned ON. This feature will only lock the cooktop.
To turn the Cooktop Lockout Feature ON:
1. BE SURE ALL surface element controls are set to the OFF position.
2. Press and hold until one beep is heard (after 3 seconds; See Fig. 1). If a triple beep sounds instead, check all
surface elements and turn them to the OFF position and repeat this step. The Cooktop Locked indicator light will turn ON
and the cooktop controls and functions are locked out until the cooktop is unlocked.
To turn the Cooktop Lockout Feature OFF:
1. BE SURE ALL surface element controls are set to the OFF position.
2. Press and hold until one beep is heard (after 3 seconds). If a triple beep sounds instead, check all surface
elements and turn them to the OFF position and repeat this step. The Cooktop Locked indicator light will turn OFF and the
cooktop may be used normally (See Fig. 2). Note: Starting a Self-Clean cycle will also turn ON the Cooktop Lockout
feature. The cooktop will remain locked until the Self-Clean cycle has completed and the oven door has unlocked. If a
power failure occurs after the Cooktop Lockout has been activated, you must turn OFF the Cooktop Lockout feature before
being able to use the cooktop features again.
Surface Cooking
The size and type of cookware used will influence the setting needed for
best cooking results. Cookware should have flat bottoms that make good
contact with the entire surface heating element (See Figs. 4). Check for
flatness by rotating a ruler across the bottom of the cookware (See
Fig.5).
Be sure to follow the
recommendations for using
proper cookware as
illustrated in Figs. 4 & 5. For
more information about the
ceramic cooktop see
“Cooktop Cleaning &
Maintenance”in the General
Care & Cleaning section.
Fig. 3
Fig. 4
Fig. 5
Fig. 2
Fig. 1
Important Note: DO NOT place EMPTY aluminum, glass or porcelain-enamel coated cookware on the ceramic
cooktop! The melting point of cookware made with these materials may be reached quickly especially if left empty &
they may bond to the ceramic cooktop. If the cookware melts it WILL damage the cooktop! BE SURE to follow ALL the
cookwaremanufacturer’s suggestionswhen usingANY type of cookware onthe ceramiccooktop.

12
Oven Control Functions
READTHEINSTRUCTIONSCAREFULLYBEFOREUSINGTHEOVEN. For
satisfactoryuseofyouroven, become familiarwiththevariousfeaturesand
functions of the oven as described below. Detailed instructions for each feature
and function follow later in this Use & Care Guide.
0 THRU 9
NUMBERPADS—
Use to enter
temperature and
times.
TIMERSET/
OFF—Use
to set or
cancel the
Kitchen
Timer (See
page 14).
BROIL—Use to select
variable Broil feature (See
page 21).
CONVBAKE—Useto
select the Convection Bake
feature (See page 22).
BAKE—Use to enter the
normal Bake feature.
(See page 18).
DELAYSTART—
Use with BAKE,
COOK TIME,
and CLEAN to
program a
Delayed Timed
Bake or Delay
Self-Cleaning
cycle start time.
FLEX
CLEAN—Use
to select the
Self-Cleaning
feature (See
page 30).
STOP/CLEAR—
Use to cancel
any oven mode
previously
entered except
the Oven
Lockout, Time of
Day and Minute
Timer. Press
STOP/CLEARto
stop cooking.
CLOCK—
Use to
set the
time of
day (See
page 13).
START—
Use to
start all
oven
features
(not used
with Oven
Light).
COOKTOP
LOCKOUT—
Use to
enable or
disable all
cooktop
features
(See page
11).
OVEN
LIGHT—
Use to
turn the
oven light
ON and
OFF (See
page 28).
COOK
TIME—Use
to enter the
length of the
baking time.
PREHEAT—Use topre-
condition the oven
temperature See page 17).
Minimum & Maximum Control Pad Settings
Allof the featureslisted have
minimum and maximum time or
temperature settings that may be
entered into the control. An ENTRY
acceptancebeep will soundeach
time a control pad is touched (the
Oven Lockout pad is delayed by 3
seconds).
AnENTRY ERROR tone(3short
beeps) will sound if the entry of the
temperature or time is below the
minimumorabovethemaximum
settingsfor the feature.
FEATURE
PREHEATTEMP.
BAKE TEMP.
BROILTEMP.
KITCHENTIMER
CLOCKTIME
COOKTIME
STARTTIME
CLEANTIME
CONVECTIONBAKE
MIN. TEMP. /TIME
170°F/77°C
170°F/77°C
400°F/205°C
0:01 Min.
0:01 Min.
1:00 Hr./ Min.
0:00 Hr./ Min.
0:01 Min.
0:01 Min.
1:00 Hr./ Min.
0:00 Hr./ Min.
2hours
325°F/149°C
MAX. TEMP. /TIME
550°F/288°C
550°F/288°C
550°F/288°C
11:59 Hr./ Min.
11:59 Hr./ Min.
12:59 Hr./ Min.
23:59 Hr./ Min.
11:59 Hr./ Min.
23:59 Hr./ Min.
12:59 Hr./ Min.
23:59 Hr./ Min.
4hours
550°F/288°C
12Hr.
24Hr.
12Hr.
24Hr.
12Hr.
24Hr.
12Hr.
24Hr.
CONV ROAST—Use to
select the Convection
Roast feature (See page
23).
CONVCONVERT—
Use to select the
Convection Convert
feature (See page 24).
ADD1
MINUTE—
Use to
select Add
1 Minute
feature
(See page
24).
SLOW COOK—Use to Slow
Cook feature (See page 26).
WARM & HOLD—Use to
select the Warm & Hold
feature (See page 28).
RECIPE
RECALL-
Use recall
stored
recipes
(See page
25).

ENGLISH
13
Setting Oven Controls
•Setting the Clock
•Changingbetween12 or24hour
display
Setting the Clock
The CLOCK pad is used to set the clock. The clock may be
set for 12 or 24 hour time of day operation. The clock has been
preset at the factory for the 12 hour operation. When the range is
first plugged in, or when the power supply to the range has been
interrupted, the timer in the display will flash with power failure "PF"
(See Fig. 1).
To set the clock (example below for 1:30):
1. Press ."CLO" will appear in the display (Fig. 2).
2. Press pads to set the time of day to 1:30 (Fig. 3).
"CLO" will appear in the display. Press . "CLO" will
disappear and the clock will start (Fig. 4).
Changing between 12 or 24 hour time of day display:
1. Press and hold for 6 seconds (Fig. 3). While holding the
pad down the current time of day will remain and "CLO" will
disappearfromthedisplay(Fig.4).CONTINUEholdingthepad
until a beep is heard.
2. Thedisplay willshoweither"12Hr"(Fig.5)or"24Hr"(Fig.6).
3. Press to switch between the 12 and 24 hour time of day
display.Thedisplay willshoweither"12Hr" (Fig. 5)or"24Hr"
(Fig. 6).
4. Press to accept the desired change or press to
rejectthechange.
5. Reset the correct time as described in To set the Clock above.
Please note that if the 24 hour time of day mode was chosen,
the clock will now display time from 0:00 through 23:59 hours.
for6seconds
INSTRUCTIONS PRESS DISPLAY
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
or

Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Setting Kitchen Timer
The TIMER SET/OFF pad controls the Kitchen Timer feature. The Kitchen Timer serves as an extra timer in the
kitchen that will beep when the set time has run out. It does not start or stop cooking. The Kitchen Timer feature can be
used during any of the other oven control functions. Refer to "Minumum & Maximum Control Pad Settings" on page 12 for
time amount settings.
To set the Kitchen Timer (example for 5 minutes):
1. Press . "0:00" will appear and "TIMER" will flash in the
display (Fig. 5).
2. Press the number pads to set the desired time in the display
(example ). Press . The time will count down with
"5:00" and "TIMER" will show in the display (Fig. 6).
Note: If is not pressed the timer will return to the time of
day.
3. When the set time has run out, "End" and "TIMER" will show in
the display (Fig. 7). The clock will sound with 3 beeps every 15
seconds until is pressed.
To cancel the Kitchen Timer before the set time has
run out:
Press . The display will return to the time of day.
for 6 seconds
or
Setting Continuous Bake or 12 Hour Energy Saving
TheTIMER SET/OFF andFLEX CLEAN padscontrol the ContinuousBakeor 12 HourEnergySaving features.
Theoven control hasa factory presetbuilt-in12 HourEnergySaving feature thatwill shut offtheoven iftheoven control is
leftonformorethan11hoursand59minutes.TheovencanbeprogrammedtooverridethisfeatureforContinuousBaking.
To set the control for Continuous Bake or 12 Hour
Energy Saving features:
1. Press and hold for 6 seconds (Fig.1). "12:Hr" or "- -:Hr"
will appear in the display and the control will beep once.
2. Press to switch between the 12 Hour Energy Saving and
continuous bake features. Note: "12 Hr" (Fig. 2) in the display
indicatesthe controlis setfor 12Hour EnergySaving feature
and "- - Hr" (Fig. 3) indicates the control is set for the
ContinuousBakefeature.
3. Press to accept the change (Fig. 4; display will return to
time of day) or press to reject the change.
Setting Oven Controls
•ContinuousBakeorTwelveHourEnergySavingMode
•KitchenTimer
INSTRUCTIONS PRESS DISPLAY
INSTRUCTIONS PRESS DISPLAY
14

Fig. 1
Fig. 2
Setting Oven Lockout Feature
The padcontrolstheOvenLockoutfeature.TheOvenLockoutfeatureautomaticallylockstheovendoor,preventsthe
Warmer Drawer and most oven controls from being turned ON. It does not disable the clock, Kitchen Timer or the interior
ovenlight.
for 3 seconds
for 3 seconds
for 7seconds
To activate the Oven Lockout feature:
1. Press and hold for 3 seconds (Fig. 1).
2. After 3 seconds a beep will sound, LOC & "DOOR LOCKED"
will flash in the display. Once the oven door is locked the
"DOORLOCKED"indicatorwillstopflashing.
To reactivate normal oven operation:
1. Press and hold for 3 seconds. A beep will sound. LOC will
clear.The "DOOR LOCKED" willcontinue to flashuntil the oven
door has completely unlocked (See Fig. 2).
2. Theovenisagainfullyoperational.
Setting Oven Controls
•OvenLockout
•TemperatureDisplay
Setting Temperature Display —Fahrenheit or Celsius
The BROIL andCLEAN pads control theFahrenheit orCelsius temperature displaymodes. Theoven control can
be programmed to display temperatures in Fahrenheit or Celsius. The oven has been preset at the factory to display in
Fahrenheit.
To change display from Fahrenheit to Celsius or
Celsius to Fahrenheit:
1. To tell if the display is set for Fahrenheit or Celsius press
(Fig. 3) and hold for 7 seconds; "550°"will first appear in the
display and then a beep will sound. If "F" appears, the display
is set to show temperatures in Fahrenheit (Fig. 4). If "C"
appears, the display is set to show temperatures in Celsius
(Fig. 5).
2. Press to switch between Fahrenheit or Celsius display
modes. The display will show either "F" (Fig. 4) or "C"(Fig. 5).
3. Press to accept the change or press to reject the
change.
or
INSTRUCTIONS PRESS DISPLAY
INSTRUCTIONS PRESS DISPLAY
Fig. 3
Fig. 4
Fig. 5
ENGLISH
15

16
Setting Oven Controls
•SilentControlOperation
Setting Silent Control Operation
TheDELAYSTART andFLEXCLEAN padscontroltheSilentControloperationfeature.TheSilentControl
operationfeatureallowstheovencontroltobeoperatedwithoutsoundsorbeepswhenevernecessary.Ifdesiredthecontrol
canbeprogrammed for silentoperationand later returnedtooperatingwith allthenormalsounds and beeps.
for7seconds
To change control from normal sound operation to
silent control operation:
1. To tell if your range is set for normal or silent operation press
andhold for7seconds. "0:00"will appearand"DELAY"will
flash in the display (Fig. 1).
2. Press to switch between normal sound operation and silent
operation mode. The display will show either ":SP" (Fig. 2) or ":--
"(Fig. 3).
If ":SP" appears (Fig. 2), the control will operate with normal
sounds and beeps. If ":- -" appears (Fig.3), the control is in the
silentoperationmode.
3. Press to accept the change or press to reject the
change.
or
INSTRUCTIONS PRESS DISPLAY
Fig. 1
Fig. 2
Fig. 3

ENGLISH
17
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Fig. 8
Setting Oven Controls
•PreheatforElectricRanges
To set the Preheat temperature for 350°F:
1. Arrangetheinteriorovenracks.
2. Press . "- - - °" and "BAKE" will appear in the display (See
Fig.1).
3. Press . "350°" will appear in the display (See Fig.
2).
4. Press . "PRE" and "BAKE" will appear in the display as
theovenheats and reaches350°F(Fig 3).
Note:Aftertheovenhasreached thedesiredtemperature(this
example, 350°F) the control will sound a long beep, the "PRE" light
willturn offand oven temperaturewill bedisplayed (Fig. 4). Ifthe
beep was missed, a quick glance at the display with oven
temperature showing in the oven display is a good way to check
thattheovenhasalreadyreachedthepreheattemperature.Once
theovenhaspreheated,PLACEFOOD INTHEOVEN. The"BAKE"
light will stay on.
Press when baking is complete or to cancel the Preheat
feature.
To change Preheat temperature while oven is
preheating (example changing from 350 to 425°F):
Ifit isnecessary to changethe preheattemperature while theoven
ispreheatingtotheoriginaltemperature:
1. While preheating, press . "- - -°" and "BAKE" will appear in
the display (Fig. 5)
2. Enter the new preheat temperature. Press .
"425°" and "BAKE" will appear in the display (Fig. 6).
3. Press . "PRE" and "BAKE" will appear in the display as
the oven heats to 425°F (Fig. 7). A long beep will sound once
theoventemperaturereaches425°Fandthedisplaywillshow
"425°"and"BAKE"(SeeFig.8).
4. When baking is complete press .
INSTRUCTIONS PRESS DISPLAY
Setting Preheat
For the best baking performance use the PREHEAT feature.The Preheatfeature willbring theoven upto theset
baking temperature and then indicate when to place the food in the oven. Use this feature in combination with the Bake pad
whenrecipes call forpreheating. Preheating isnot necessary whenroasting or cookingcasseroles. The ovencan be
programmedtopreheatatanytemperaturebetween170°Fto550°F.

18
Fig. 3
Fig. 5
Fig. 6
Fig. 1
Fig. 2
Fig. 4
Setting Oven Controls
•Bake
To set the Bake Temperature to 350°F:
1. Arrangeinteriorovenracksandplacefoodinoven.
2. Press , "- - - °" will appear in the display (Fig. 1).
3. Press (Fig. 2)."BAKE" will flash and "350°"will
appearin thedisplay.
4. Press . A long beep will sound once the oven temperature
reaches350°F and thedisplay willshow "350°" and"BAKE"
(Fig. 3).
Pressing will cancel the Bake feature at any time.
To change the Bake Temperature (example changing
from 350°to 425°F):
1. After the oven has already been set to bake at 350°F and the
oventemperatureneeds to bechangedto425°F,press
(Fig. 4) and "- - - °"will show in the display.
2. Press (Fig. 5). "BAKE" flashes and "425°" will
appearin thedisplay.
3. Press . "BAKE" and "425°" will appear in the display (See
Fig.6).
INSTRUCTIONS PRESS DISPLAY
Setting Bake
TheBAKE pad controls normalbaking.If preheating isnecessary,referto the PREHEAT feature forinstructions.
Theovencanbeprogrammedtobakeatanytemperaturefrom170°Fto550°F(Thesampleshownbelowisfor350°F).

ENGLISH
19
Fig. 1
Fig. 2
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Fig. 3
Setting Timed Bake
TheBAKE and COOK TIME pads controlthe TimedBake feature. The automatic timer of the Timed Bake feature
will turn the oven OFF after cooking for the desired amount of time you selected.
Setting Oven Controls
•TimedBake
To program the oven to begin baking immediately
and to shut off automatically: (example below to
bake at 350°F for 50 minutes):
1. Be sure the clock is set for the correct time of day.
2. Arrangeinteriorovenrack(s)andplacethefoodintheoven.
3. Press , "- - - °" will appear in the display (Fig. 1).
4. Press (Fig. 2)."BAKE" will flash and "350°"will
appearin thedisplay.
5. Press . "BAKE" and"350°"willappear inthe display
(See Fig. 3).
6. Press . "TIMED" will flash; "BAKE", "0:00" and "350°"
will appear in the display (Fig.4).
7. Enter the desired baking time by pressing . "TIMED"
will flash and "BAKE", "50:00" and "350°" will appear in the
display (Fig. 5). Note: Baking time can be set for any amount of
time between 1 minute to 11 hours and 59 minutes.
8. Press . Both "TIMED" and "BAKE" will remain on in the
display (Fig. 6). Once the Timed Bake feature has started, the
current time of day will appear in the display.
Note: After the Timed Bake feature has activated, press to
display the bake time remaining in the Timed Bake mode. Once
Timed Bake has started baking, a long beep will sound when the
oventemperaturereachesthesettemperature.
Press when baking has finished or at any time to cancel the
TimedBakefeature.
When the Timed Bake finishes:
1. "End" and the time of day will show in the display. The oven will
shut off automatically (Fig. 7).
2. The control will beep 3 times. The control will continue to beep 3
times every 30 seconds until is pressed.
Usecaution with theTIMEDBAKEor DELAY START (DelayedTimedBake)features. Use theautomatic
timer when cooking cured or frozen meats and most fruits and vegetables. Foods that can easily spoil such as milk, eggs,
fish, meat or poultry, should be chilled in the refrigerator first. Even when chilled, they should not stand in the oven for more
than1hour beforecookingbegins,and should beremovedpromptly when cookingiscompleted. Eating spoiledfoodcan
result in sickness from food poisoning.
INSTRUCTIONS PRESS DISPLAY

20
Fig. 6
Fig. 7
Fig. 8
Fig. 5
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 9
Setting Delay Start
The BAKE ,COOK TIME andDELAY START pads control theDelayed Timed Bakefeature. Theautomatic
timer of the Delayed Timed Bake will turn the oven ON and OFF at the time you select in advance.
Setting Oven Controls
•SettingDelay Start(Delayed Timed Bake)
1. Be sure that the clock is set with the correct time of day.
2. Arrangeinteriorovenrack(s)andplacethefoodintheoven.
3. Press . "- - -°"will appear in the display (Fig. 1).
4. Press (Fig. 2). "BAKE" will flash and "350°" will
appearin thedisplay.
5. Press ."BAKE" and"350°"willappear in thedisplay(See
Fig.3).
6. Press . "TIMED" will flash; "BAKE", "0:00" and "350°" will
appearin thedisplay (Fig.4).
7. Enter the desired baking time using the number pads by pressing
. "TIMED" will flash; "BAKE", "50:00" and "350°" will
appear in the display (Fig. 5). Note: Baking time can be set for any
amount of time from 1 minute to 11 hours and 59 minutes.
8 Press . "TIMED", "BAKE" and "350°" will be displayed (Fig.
6).
9. Press . Enter the desired start time using the number pads
(Fig. 7).
10. Press . When Delay Start starts, the set oven temperature
willdisappear,"TIMED","DELAY","BAKE"andthe current timeof
time of day will appear in the display (Fig. 8).
Note: Once Delay Start has started, press to display the bake
time remaining. Once the Delayed Timed Bake has started baking, a
longbeepwillsoundwhentheoventemperaturereaches the set
temperature.
Press when baking has finished or at any time to cancel the Delay
Start(DelayedTimedBake)feature.
When the set bake time runs out:
1. "End" and the time of day will show in the display. The oven will
shut off automatically (Fig. 9).
2. The control will beep 3 times. The control will continue to beep 3
times every 30 seconds until is pressed.
INSTRUCTIONS PRESS DISPLAY
To program the oven for a Delay Start (Delayed Timed
Bake) and to shut off automatically (example for
baking at 350°F for 50 minutes and starting at 5:30):
NOTE: If your clock is set for normal 12 hour display mode the Delay Start (Delayed Timed Bake) feature can never be set
to start more than 12 hours in advance. To set the Delay Start 12-24 hours in advance see page 13 for instructions to set
the control for the 24 hour time of day display mode.
