Kenmore 318200449 User manual

Sears Canada Inc.,Toronto, Ontario, Canada, M5B 2B8
Visit our website: www.sears.ca

318200449 (0902) Rev. A
Electric Range
Use & Care Guide
ENGLISH

2
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS ................3-4
Installation Instructions............................................5-6
Setting Surface Controls .........................................6-9
Surface Cooking....................................................... 10
Before Setting Oven Controls................................... 11
Setting Oven Controls .............................................. 11
Cooking Informations ..........................................12-13
Printed in United States
Serial Plate Location
You will find the model and serial
number printed on the serial plate.
The serial plate is located as shown
below.
Product Record
In this space below, record the date of purchase, model and serial number of your
product.You will find the model and serial number printed on the serial plate.
Model No.______________________________________
Serial No.______________________________________
Date of purchase _______________________________
Save these instructions and your sales receipt for future reference.
Please carefully read and save these instructions
This Use & Care Manual contains general operating instructions for your appliance
and feature information for several models.Your product may not have all the
described features. The graphics shown are representative. The graphics on your
appliance may not look exactly like those shown. Common sense and caution must
be practiced when installing, operating and maintaining any appliance.
Adjusting your Oven Temperature............................ 13
General Care & Cleaning....................................14-19
Before you Call....................................................20-21
Notes ........................................................................ 22
Protection Agreements............................................. 23
Anti-Tip:
For the Anti-tip Installation Instructions, refer to the Anti-
Tip Kit located in a plastic bag in the oven.
Serial Plate
Location
Kenmore Limited Warranty
When installed, operated and maintained according to all instructions supplied with the product, if this appliance fails due to a
defect in material and workmanship within one year from the date of purchase, call 1-800-4-MY-HOME® to arrange for free
repair.
This warranty applies for only 90 days from the date of purchase if this appliance is ever used for other than private family
purposes.
This warranty covers only defects in material and workmanship. Sears will NOT pay for:
1. Cracks in a ceramic glass cooktop that are not a result of thermal shock.
2. Stains and scratches on a ceramic glass cooktop resulting from accident or improper operation or maintenance.
3. Expendable items that can wear out from normal use, including but not limited to filters, belts, light bulbs, and bags.
4. A service technician to instruct the user in correct product installation, operation or maintenance.
5. A service technician to clean or maintain this product.
6. Damage to or failure of this product if it is not installed, operated or maintained according to the all instructions
supplied with the product.
7. Damage to or failure of this product resulting from accident, abuse, misuse or use for other than its intended purpose.
8. Damage to or failure of this product caused by the use of detergents, cleaners, chemicals or utensils other than those
recommended in all instructions supplied with the product.
9. Damage to or failure of parts or systems resulting from unauthorized modifications made to this product.
Disclaimer of implied warranties; limitation of remedies
Customer’s sole and exclusive remedy under this limited warranty shall be product repair as provided herein. Implied
warranties, including warranties of merchantability or fitness for a particular purpose, are limited to one year or the
shortest period allowed by law. Sears shall not be liable for incidental or consequential damages. Some states and
provinces do not allow the exclusion or limitation of incidental or consequential damages, or limitation on the duration of
implied warranties of merchantability or fitness, so these exclusions or limitations may not apply to you.
This warranty applies only while this appliance is used in the United States or Canada.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., Hoffman Estates, IL 60179
Sears Canada Inc.,Toronto, Ontario, Canada M5B 2B8
Remember
to record the
serial number
for future
reference.

3
ENGLISH
•DONOTTOUCHSURFACEUNITS,AREASNEAR
THESE UNITS, OVEN HEATING ELEMENTS OR
INTERIOR SURFACES OF THE OVEN. Both surface
units and oven heating elements may be hot even
though they are dark in color. Areas near surface
units may become hot enough to cause burns. During
and after use, do not touch, or let clothing or other
flammable materials touch these areas until they have
had sufficient time to cool. Among these areas are the
cooktop, surfaces facing the cooktop, the oven vent
openings and surfaces near these openings, oven
door and window.
•WearProperApparel—Loose-ttingorhanging
garments should never be worn while using the
appliance. Do not let clothing or other flammable
materials contact hot surfaces.
Never use your appliance for warming
or heating the room.
•DoNotUseWaterorFlouronGreaseFires—
Smothertherewithapanlid,orusebakingsoda,
a dry chemical or foam-type extinguisher.
•Whenheatingfatorgrease,watchitclosely. Fat or
grease may catch fire if allowed to become too hot.
•UseOnlyDryPotholders—Moistordamp
potholders on hot surfaces may result in burns
from steam. Do not let the potholders touch hot
heating surface units or interior oven elements. Do not
use a towel or other bulky cloth instead of a potholder.
•DoNotHeatUnopenedFoodContainers—Build-
up of pressure may cause the container to burst
and result in injury.
•Removetheovendoorfromanyunusedrangeifit
is to be stored or discarded.
•IMPORTANT—Donotattempttooperatetheoven
during a power failure. If the power fails, always
turn the oven off. If the oven is not turned off and the
power resumes, the oven will begin to operate again.
Food left unattended could catch fire or spoil.
Electronic controllers can be damaged
by cold temperatures. When you use your range
forthersttime,orifithasbeenusedforalong
period of time, make sure that it has been exposed
to a temperature above 0°C/32°F for at least 3 hours
before connecting it to the power supply.
•Removealltapeandpackagingwrapbeforeusing
the range. Destroy the carton and plastic bags after
unpacking the range. Never allow children to play with
packaging material.
•ProperInstallation—Besureyourapplianceis
properlyinstalledandgroundedbyaqualied
technician in accordance with CSA C22.1 PART 1
—latesteditionandlocalcoderequirements. Install
only per installation instructions provided in the literature
package for this range.
• Incaseofanemergency,knowhowtodisconnect
the electrical power to the appliance at the circuit
breaker or fuse box.
• UserServicing.Donotrepairorreplaceanypartof
theapplianceunlessspecicallyrecommendedin
the product literature supplied with this appliance.
All other servicing should be done only by a qualified
technician to reduce the risk of personal injury and
damage to the appliance. Sears Parts & Repair is the
recommended repair service for this appliance.
•Nevermodifyoraltertheconstructionofarangeby
removing panels, wire covers or any other part of
the product.
Stepping, leaning or sitting on the door
or drawer of this range can result in serious injuries
and may also cause damage to the range. Do not allow
children to climb or play around the range. The weight
of a child on an open door may cause the range to tip,
resulting in serious burns or other injury.
Do not use the oven for storage.
•StorageinoronAppliance—Flammablematerials
should not be stored in an oven, near surface units
or in the storage drawer. This includes paper, plastic
and cloth items, such as cookbooks, plasticware and
towels, as well as flammable liquids. Do not store
explosives, such as aerosol cans, on or near the range.
Flammable materials may explode and result in fire or
property damage.
Do not store items of interest to
children in the cabinets above a range or on the
backguard of a range. Children climbing on the range to
reach items could be seriously injured.
•Donotleavechildrenalone.Childrenshouldnot
be left alone or unattended in the area where an
appliance is in use. They should never be allowed to
sit or stand on any part of the appliance.
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this appliance.
Save these instructions for future reference.
This guide contains important safety symbols and instructions. Please pay special attention to these symbols and follow all
instructions given. Here is a brief explanation of these symbols.
This symbol will help you to situations that may cause serious bodily harm, death or property damage.
This symbol will help you to situations that may cause bodily injury or property damage.

4
IMPORTANT SAFETY INSTRUCTIONS (continued)
IMPORTANT INSTRUCTIONS FOR USING
YOUR COOKTOP
•Knowwhichknobcontrolseachsurfaceheating
unit.
•UseProperPanSize— This appliance is equipped
with one or more surface units of different sizes. Select
utensils having flat bottoms large enough to cover the
surface unit. The use of undersized utensils will expose
a portion of the surface heating unit to direct contact
and may result in ignition of clothing. Proper relationship
of utensil to the surface unit will also improve efficiency.
•UtensilHandlesShouldBeTurnedInwardand
Should Not Extend Over Adjacent Surface Units
—To reduce the risk of burns, ignition of flammable
materials, and spillage due to unintentional contact with
the utensil.
•NeverLeaveSurfaceUnitsUnattended— Boilovers
cause smoking and greasy spillovers that may ignite, or
a pan that has boiled dry may melt.
•ProtectiveLiners— Do not use aluminum foil to line
oven bottom or any other part of the range. Only use
aluminum foil as recommended for baking if used as a
cover placed on the food. Any other use of protective
liners or aluminum foil may result in a risk of electric
shock or fire or a short circuit.
•GlazedCookingUtensils— Only certain types of
glass, glass/ceramic, ceramic, earthenware, or other
glazed utensils are suitable for rangetop service without
breaking due to the sudden change in temperature.
Check the manufacturer’s recommendations for
rangetop use.
FOR GLASS COOKTOPS ONLY
•DoNotCookonBrokenCooktop — If cooktop should
break, cleaning solutions and spillovers may penetrate
the broken cooktop and create a risk of electric shock.
Contact a qualified technician immediately.
•CleancooktopwithCaution— If a wet sponge or
cloth is used to wipe spills on a hot cooking area, be
careful to avoid a steam burn. Some cleaners can
produce harmful fumes if applied to a hot surface.
IMPORTANT INSTRUCTIONS FOR USING
YOUR OVEN
•UseCareWhenOpeningDoor — Stand to the side of
the range when opening the door of a hot oven. Let hot
air or steam escape before you remove or replace food
in the oven.
•KeepOvenVentDuctsUnobstructed. The oven
is vented between the cooktop and the backguard.
Touching the surfaces in this area when the oven is
operating may cause severe burns. Also, do not place
plastic or heat-sensitive items on or near the oven vent.
These items could melt or ignite.
•PlacementofOvenRacks. Always place oven racks
in desired location while oven is cool. Remove all
utensils from the rack before removing rack. If rack
must be moved while oven is hot, use extreme caution.
Use potholders and grasp the rack with both hands to
reposition. Do not let potholders contact the hot oven
element or interior of the oven.
•Donotuseyourbroilerpanwithoutitsinsert. Broiler
pan and grid allow dripping fat to drain and be kept
away from the high heat of the broiler.
•Donotcoverthebroilergridwithaluminumfoil.
Exposed fat and grease could ignite.
•Donottouchahotlightbulbwithadampcloth.
Doing so could cause the bulb to break. Disconnect
the range or turn off the power to the range before
removing and replacing light bulb.
IMPORTANT INSTRUCTIONS FOR
CLEANING YOUR RANGE
•Cleantherangeregularlytokeepallpartsfreeof
greasethatcouldcatchre. Exhaust fan ventilation
hoods and grease filters should be kept clean. Do not
allow grease to accumulate. Greasy deposits in the
fan could catch fire. Refer to the hood manufacturer’s
instructions for cleaning.
•Cleaners/Aerosols — Always follow the manufacturer’s
recommended directions for use. Be aware that excess
residue from cleaners and aerosols may ignite causing
damage and/or injury.
SELF-CLEANING OVENS:
•Cleanintheself-cleaningcycleonlythepartsofthe
oven listed in this owner’s guide. Before self-cleaning
the oven, remove all utensils stored in the oven.
•Donotcleantheovendoorgasket. Care should be
taken not to rub, damage or move the gasket.
•Donotuseovencleaners. No oven cleaner or oven
liner protective coating of any kind should be used in or
around any part of the oven.
•Removeovenracks. Oven racks color will change if
left in the oven during a self-cleaning cycle.
The health of some birds is extremely
sensitive to the fumes given off during the self-
clean cycle of any range. Move birds to another well
ventilated room.
SAVE THESE INSTRUCTIONS

5
ENGLISH
Installation Instructions
Clearances and Dimensions
A. Provide adequate clearances between the range and adjacent combustible surface (1.3cm (1/2”) to the cabinet side
walls and the rear wall).
B. Location—Check location where the range will be installed. Check for proper electrical supply and the stability of
floor.
C. Dimensions that are shown must be used. Given dimensions provide minimum clearance. Contact surface must be
solid and level.
Installationandservicemustbeperformedbyaqualiedtechnician.
IMPORTANT: Save for local electrical inspector’s use. Read and save these instructions for future reference.
45.7cm
(18”)
A
76.2cm (30”)
Minimum *
Minimum
to wall on
either side of
range.
91.4 cm
(36”)
B
SIDE
VIEW
FRONT
VIEW
Minimum to
cabinets on
either side of
range.
Maximum depth for
cabinets above
range top.
33cm
(13”)
1.3cm
(1/2”)
DIMENSIONS
A B
76.2cm (30”) 78.7cm (31”)
A66cm (26”)
91.4 ± 0.3cm
(36 ± 1/8”)
122cm (48”)
Maximum
114.3cm (45”)
Door Open
* 76.2cm (30”) minimum clearance between the top of the cooking surface and the bottom of an unprotected wood or
metal cabinet; or 61cm (24”) minimum when bottom of wood or metal cabinet is protected by not less than 0.64cm (¼”)
flame retardant millboard covered with not less than 0.038cm (0.015”) stainless steel, 0.061cm (0.024”) aluminum or
0.051cm (0.020”) copper. 1.3cm (½”) clearance is minimum for the rear and sides of the range. Follow all dimensions
requirements provided above to prevent property damage, potential fire hazard, and incorrect countertop and cabinet
cuts.
Toeliminatetheriskofburnsorrebyreachingoverheatedsurfaceunits,cabinetstoragespacelocatedabove
the surface units should be avoided. If cabinet storage is to be provided, the risk can be reduced by installing a
rangehoodthatprojectshorizontallyaminimumof12.7cm(5”)beyondthebottomofthecabinets.
Electrical Connection Requirements
Plug the range cable (4 conductors) into a 4 conductor range outlet. Outlet
must be properly grounded and in accordance with the Canadian Electrical
Code (CSA Standard (C22.1 Part 1 -- latest edition) -- and any local electrical
code requirements.
Location
Set your new range 1.3cm (½”) away from the rear wall and line it up with the kitchen counters. Make sure there is at
least 1.3cm (½”) of clearance between each side of the range and the kitchen counters. Allow 7.6cm (3”) min. clearance
between your range and the refrigerator, if they are side by side.

6
Lock
Unlock
Installation Instructions (continued)
Levelling
For good baking results, your range should be level. Screw type levelling legs are provided at each
corner of the range at the base. Remove the storage drawer to adjust the levelling legs. (Refer
to Storage Drawer section).
To level the range:
1. Use a 1¼” open end key or an adjustable wrench to equally
unscrew the four levelling legs two to three turns each.
2. Install an oven rack in the center of the oven.
3. Move the range to its final position, then put a spirit level on the
rack to check for levelness. Take two readings, one with the level placed diago-
nally first in one direction, and then the other.
4. Use the 1 ¼” key or wrench to adjust the levelling legs. Turn each one until the
range stands firm without wobbling.
5. Some models are supported by smooth glide rollers to facilitate moving.
1. Place the pan on the surface element.
2. Push in and turn the surface element control knob to desired setting.
3. The Element On indicator lights are located on the control panel between two element
control knobs, one on each side, and will glow when a surface element is turned ON.
A quick glance at this indicator light after cooking is an easy check to be sure ALL
surface controls are turned OFF. Always turn the element off before removing the
pan.
Note:Thesizeandtypeofutensilused,andtheamountandtypeoffoodbeing
cooked will influence the setting needed for best cooking results.
NOTE: All knobs shown in this owner’s Guide are typical only .
The suggested settings found in the chart above are based on cooking in medium thickness aluminum pans with lids. Settings
may vary when using other types of pans.
Do not place items such as salt and pepper shakers, spoon holders or plastic wrappings on top of
the cooktop when it is in use. These items could melt or ignite. Potholders, towels or wood could catch fire if placed too
close to the element.
DO NOT use the surface element in self-clean mode. During the self-clean cycle, the surface elements,
when used, are subjected to high heat. To ensure maximum element life, do not use the surface element during a self-
clean cycle.
If floor is flat and level, open the drawer and lower the front roller locking levers
(some models) to prevent the range from moving.
If floor is not flat or level or if this model has rollers without locking levers, use the 4
levelling legs to level, support and prevent the range from moving.
Circuit Protection
As a protection against surcharge, a 15 amp, 120 volt breaker is provided for each
of the electric outlet(s) (2 max.). It (they) is (are) located on top or underneath of the
control panel. Models with no electric outlet have no breaker.
Setting Surface Controls
Models with Coil Surface Elements (some models)
Locking the Front Rollers
(some of the 30” models only)
Setting Type of Cooking
HI (Max.) Start most foods, bring water to a boil, pan broiling.
5 (Med.) Maintain a slow boil, thicken sauces and gravies, steam vegetables.
2-4 (Med-Low) Keep food cooking, poach, stew.
LO (Min) Keep warm, melt, simmer.

7
ENGLISH
Setting Surface Controls
Models with Ceramic Glass Cooktop (Some models)
About the Ceramic Glass Cooktop
The ceramic cooktop has radiant surface elements located below the surface of the glass.The design of the ceramic cooktop
outlines the area of the surface element underneath. Be sure to match the pan size with the diameter of the element outline
on the cooktop. Heat is transferred up through the surface of the cooktop to the cookware. Only flat-bottomed cookware
should be used.
The type and size of cookware, the number of surface elements in use and their settings, are all factors that will affect the
amount of heat that will spread to areas beyond the surface elements. The areas surrounding the elements may become
hot enough to cause burns.
The cooktop should not be used as a cutting board or work surface.Dropping heavy or hard objects on the cooktop may crack
it.Pans with rough bottoms may scratch the cooktop surface.Placing foods directly on the smoothtop surface (without cooking
utensils) is not recommended as difficult cleaning will result and foods may smoke and cause a potential fire hazard.
Element On & Hot Surface Indicator Lights
Your model may be equipped with two different types of radiant surface
control indicator lights that will glow on your range— the ELEMENT ON
indicator light and the HOT SURFACE indicator lights (See illustration at left).
The Element On indicator lights are located on the control panel above and
between two element control knobs and will glow when a surface element
is turned ON. A quick glance at this indicator light after cooking is an easy
check to be sure ALL surface controls are turned OFF. The Hot Surface
indicator light located on the control panel above each control knob will glow
when the surface cooking area heats up and will REMAIN ON until the glass
cooktop has cooled to a MODERATE level.
If your model has only the Hot Surface Indicator light (one over each
control knob the light will glow when the element is turned ON and will
REMAIN ON until the glass cooktop has cooled to a MODERATE level even if
the element is turned OFF.
NOTE: Radiant elements have a limiter that allows the element to cycle ON
and OFF, even at the HI setting.This helps to prevent damage to the ceramic
smoothtop. Cycling at the HI setting is normal and will occur more often if the
cookware is too small for the radiant element or if the cookware bottom is not
flat.
NOTE: Please read detailed instructions for ceramic glass cooktop cleaning in the General Care & Cleaning and Before
You Call checklist sections of this Use & Care Guide.
NOTE: Radiant elements have a limiter that allows the element to cycle ON and OFF, even at the HI setting. This helps to
prevent damage to the ceramic smooth top. Cycling at the HI setting is normal and will occur more often if the cookware
is too small for the radiant element or if the cookware bottom is not flat.
NOTE: Due to the high intensity of heat generated by the surface elements, the glass surface will turn green when the
element will be turned off. This phenomenon is normal and the glass will come back to its original white color after it has
completely cooled down. (White glass cooktops only).
About the Radiant Surface Elements
Theelementtemperaturerises graduallyandevenly.
As the temperature rises, the element will glow
red. To maintain the selected setting, the element
will cycle on and off. The heating element retains
enough heat to provide a uniform and consistent
heat during the off cycle.
For efficient cooking, turn off the element several
minutes before cooking is complete.This will allow
residual heat to complete the cooking process.
Warmer Zone
Surface Control
(some models)
Single Radiant
Surface Control
(some models)
Dual Radiant
Surface Control
(some models)
NOTE: All knobs shown in this owner’s Guide are typical only .
ELEMENT ONHOT SURFACE
HOT SURFACE
INDICATOR LIGHT
ELEMENT ON
INDICATOR LIGHT

8
Setting Surface Controls
Models with Ceramic Glass Cooktop (Some models)
To Operate a Single Radiant Element:
1. Place correctly sized cookware on the radiant surface element.
2. Push in and turn the surface control knob in either direction to the desired setting (See
Fig. 1). Start most cooking operations on a higher setting and then turn to a lower
setting to finish cooking. The surface control knobs do not have to be set exactly on a
particular mark. Use the marks as a guide and adjust the control knob as needed. Each
surface element provides a constant amount of heat at each setting. A glowing red
surface heating area extending beyond the bottom edge of the cookware indicates the
cookware is too small for the surface heating area.
3. When cooking is complete, turn the surface element OFF before removing the
cookware. Note: The ELEMENT ON indicator light will glow when one or more
elements are turned ON. A quick glance at this indicator light when cooking is finished
is an easy check to be sure all control knobs are turned OFF. The Hot Surface
indicator light will continue to glow AFTER the control knob is turned to the “OFF”
position and will glow until the heating surface area has cooled sufficiently.
Radiant surface elements may appear to have cooled after they have been turned off. The glass surface
may still be hot and burns may occur if the glass surface is touched before it has cooled sufficiently.
Do not place plastic items such as salt and pepper shakers, spoon holders or plastic wrappings on
top of the range when it is in use. These items could melt or ignite. Potholders, towels or wooden spoons could catch
fire if placed too close to the surface elements.
Fig. 1
To Operate Simmer Select Surface Element (some models)
The element control may be used as a normal element or as a simmer element. The “Simmer Select” feature heats the
element at a much lower temperature than when used as a normal surface element.You may switch between normal
cooking and the Simmer Select feature at any time during the cooking process. When using the element control for normal
cooking all of the settings on the control knob (LO to HI) function as normal.
To Start Simmer Select:
1. Place correctly sized cookware on the radiant surface element.
2. Push in the Simmer button located below the control knob at right.
3. Turn the surface control knob to the desired simmer setting within the dark band on the control knob (LO to 4). Use
the marks as a guide and adjust the control knob from LO to 4 as needed (see illustration below). The Simmer Select
indicator light will glow and remain ON while simmering (See Fig. 2).
4. To return to normal cooking, push in and release the “Simmer Select” button and the indicator light will turn OFF. When
cooking is complete, be sure to set the control knob to the OFF position.
Simmer Select Surface Control
shown in LO setting
Fig. 2
The suggested settings found in the table below are based on cooking in medium-
weight aluminum pans with lids. Settings may vary when using other types of pans.
STANDARD SETTING FOR SURFACE ELEMENTS
Setting Type of Cooking
High (HI) Start most foods, bring water to a boil, pan broiling.
Medium High (7 - 8) Continue a rapid boil, fry, deep fat fry.
Medium (5 - 6) Maintain a slow boil, thicken sauces and gravies, steam vegetables.
Medium Low (2 - 4) Keep foods cooking, poach, stew.
Low (LO) Keep warm, melt, simmer.
SIMMER SELECT SURFACE ELEMENT
Max. Simmer (4) Larger quantities of food, stews and soups.
Min. Simmer (LO) Smaller quantities of food, delicate foods, melting chocolate or
butter.
SIMMER
SELECT
ON/OFF

9
ENGLISH
Setting the Warmer (Warm & Ready™) Zone (some models)
The purpose of the Warmer Zone is to keep hot cooked foods at serving
temperature. Always start with hot food. It is not recommended to heat cold
food on the Warmer Zone.
All food placed on the Warmer Zone should be covered with a lid or
aluminum foil to maintain quality. For best results, when warming pastries or
breads, the cover should have an opening to allow moisture to escape. Do
not use plastic wrap to cover food. Plastic may melt onto the surface
andbeverydifculttoclean.
Use only dishware, utensils and cookware recommended for oven and
cooktop use on the Warmer Zone.
Unlike the surface elements, the Warmer Zone will not glow
red when it is hot.
Always use potholders or oven mitts when removing food from
the warm zone as cookware and plates will be hot.
Setting the Warmer (Warm & Ready™) Zone Control
1. To set the control, push in either direction and turn the knob (See Fig 2).
The temperatures are approximate, and are designated by HI, MED and
LO. However, the control can be set at any position between HI and LO
for different levels of heating.
2. When ready to serve, turn the control to OFF. The Warmer Zone will
remain warm until the indicator light goes OFF.
Temperature Selection - Refer to the chart at the side column for
recommended heating levels. If a particular food is not listed, start with the
medium level, and adjust as needed. Most foods can be kept at serving
temperatures by using the medium level.
Note: Use the Warmer Zone to keep cooked foods hot such as; vegetables,
gravies, casseroles, soups, stews, breads, pastries and oven-safe dinner
plates.
To Operate Dual Radiant Surface Element (some models)
The right front control knob offers flexibility for different sized cookware with
the Dual Radiant surface element. The inner element alone can be used for
smaller or both the inner and outer in combination for larger cookware.
To operate the Dual Radiant surface element push in the control knob and
turn on the left to operate the small inner coil or turn on the right to operate
both the inner and outer portions of the element together (See Fig 1).
Single setting Dual setting
Dual Radiant heating areas
on ceramic smooth top (shown in black)
Fig. 1
Fig. 2
Setting Surface Controls
Models with Ceramic Glass Cooktop (Some models)
SINGLE AND DUAL RADIANT SURFACE ELEMENTS
Setting Type of Cooking
High (Hi) Start most foods, bring water to a boil, pan broiling.
Medium High (7 - 8) Continue a rapid boil, fry, deep fat fry.
Medium (5 - 6) Maintain a slow boil, thicken sauces and gravies or
steam vegetables.
Medium Low (2 - 4) Keep foods cooking, poach, stew.
Low (LO) Keep warm, melt, simmer.
Note: The size and type of utensil used, and the amount and type of food
being cooked will influence the setting needed for best cooking results.
Warmer Zone Recommended Food
Settings Table
Food Item Heating
Level
Breads/Pastries LO
Casseroles LO
Dinner Plates with Food LO
Eggs LO
Gravies LO
Meats MED
Sauces MED
Soups (cream) MED
Stews MED
Vegetables MED
Fried Foods HI
Hot Beverages HI
Soups (liquid) HI
WA RMER ZONE

10
Surface Cooking
To Set the Cooktop Lockout Feature (some models)
The
Cooktop
Lockout
3
or
3
Cooktop Lock
Verrou Table
de Cuisson
pad is used to activate the Cooktop Lockout feature which will lock all surface elements from being
accidentally turned ON. This feature will only lock the cooktop.
To turn the Cooktop Lockout Feature ON:
1. BE SURE ALL surface element controls are set to the OFF position.
2. Press and hold
Cooktop
Lockout
3
or
3
Cooktop Lock
Verrou Table
de Cuisson
until one beep is heard (after 3 seconds; See Fig. 1). If a triple beep sounds instead, check
all surface elements and turn them to the OFF position and repeat this step. The Cooktop Locked indicator light will turn
ON and the cooktop controls and functions are locked out until the cooktop is unlocked.
To turn the Cooktop Lockout Feature OFF:
1. BE SURE ALL surface element controls are set to the OFF position.
2. Press and hold
Cooktop
Lockout
3
or
3
Cooktop Lock
Verrou Table
de Cuisson
until one beep is heard (after 3 seconds). If a triple beep sounds instead, check all surface
elements and turn them to the OFF position and repeat this step. The Cooktop Locked indicator light will turn OFF and
the cooktop may be used normally (See Fig. 2). Note: Starting a Self-Clean cycle will also turn ON the Cooktop Lockout
feature. The cooktop will remain locked until the Self-Clean cycle has completed and the oven door has unlocked. If a
power failure occurs after the Cooktop Lockout has been activated, you must turn OFF the Cooktop Lockout feature before
being able to use the cooktop features again.
Fig. 2
Fig. 1
Fig. 3
Figure 4
Selecting Surface Cooking Cookware
Cookware should have flat bottoms that make good contact with the
entire surface heating element. Check for flatness by rotating a ruler
across the bottom of the cookware (See Figure 5). Be sure to follow the
recommendations for using cookware as shown in Figure 4.
Note: The size and type of cookware used will influence the setting
needed for best cooking results.
Cookware Material types
The cookware material determines how evenly and quickly heat is
transferred from the surface element to the pan bottom. The most popular
materials available are:
ALUMINUM - Excellent heat conductor. Some types of food will cause
it to darken (Anodized aluminum cookware resists staining & pitting).
If aluminum pans slide across the ceramic glass cooktop, they may
leave metal marks which will resemble scratches. Remove these marks
Using Power Element (some models)
The “Power Element” feature uses a higher wattage surface radiant element
which can bring food items to boil much quicker. The radiant element will
be clearly marked if this feature is available on your range (See Fig. 3).
If equipped with the “Power Element” feature, place the cookware on the
surface element and follow the instructions “To Operate a Single Radiant
Element” in the Settings Surface Controls section.
Figure 5
immediately.
COPPER - Excellent heat conductor but discolors easily. May leave metal marks on ceramic
glass (see Aluminum above).
STAINLESS STEEL - Slow heat conductor with uneven cooking results. Is durable, easy to
clean and resists staining.
CAST IRON - A poor heat conductor however will retain heat very well. Cooks evenly once
cooking temperature is reached. Not recommended for use on ceramic cooktops.
PORCELAIN-ENAMEL on METAL - Heating characteristics will vary depending on base
material. Porcelain-enamel coating must be smooth to avoid scratching ceramic cooktops.
GLASS - Slow heat conductor. Not recommended for ceramic cooktop surfaces because it
may scratch the glass.

11
ENGLISH
Before Setting Oven Controls
Setting Oven Controls
Refer to the Electronic Oven Control Guide for oven settings.
4
3
2
1
Oven Vent Location
Models with Coil Elements- The oven is vented through the right rear coil
element.Models with Ceramic Glass Cooktop-The oven vent is located at right
rear of the surface cooktop.
When the oven is on, warm air is released through the vent. This venting is
necessary for proper air circulation in the oven and good baking results. DO
NOT block the vent. Doing so may cause cooking failures, fire or damage to the
appliance.
Removing and Replacing Oven Racks
To remove, pull the rack forward until it stops. Lift up front of rack and slide out. To
replace, fit the rack onto the guides on the oven walls.Tilt the front of the rack upward
and slide the rack back into place.
Arranging Oven Racks
ALWAYS ARRANGE OVEN RACKS WHEN THE OVEN IS COOL (PRIOR TO OPERATING THE OVEN). Always use oven
mitts when the oven is hot.
This range has a fan that will turn“ON”and “OFF” by itself to keep the electronics cool. It may continue
to run after the range has been turned “OFF”, but may also stop immediately and then turn “ON” after a while.
Rack
positions
Oven Vent Location
Oven Vent Location
For best air circulation and baking results allow 2-4» (5-10cm) around
the cookware for proper air circulation and be sure pans and cookware
do not touch each other, the oven door, sides or back of the oven
cavity. The hot air must circulate around the pans and cookware in the
oven for even heat to reach around the food.
Air Circulation in the Oven
1 Oven Rack
Multiple Oven Racks
RECOMMENDED RACK POSITIONS FOR
BROILING, BAKING & ROASTING
Food Rack position
Broiling meats, chicken or fish 3 or 4
Cookies, cakes, pies, biscuits &muffins
1 rack
Multiple racks 2 or 3
2 & 4
Frozen pies, angel food cake, yeast, bread,
casseroles, small cuts of meat or poultry 1 or 2
Turkey, roast or ham 1
Note: Always use caution when removing food.

12
Cooking Informations
Oven Baking
For best cooking results, heat the oven before baking cookies, breads, cakes, pies or pastries, etc. There is no need to
preheat the oven for roasting meat or baking casseroles.
The cooking times and temperatures needed to bake a product may vary slightly from your previously owned appliance.
Baking Problems and Solutions Chart
Baking Problems Causes Corrections
Cookies and
biscuits burn on
the bottom.
• Cookiesandbiscuitsputinto
the oven before the preheating
time is completed.
• Ovenrackovercrowded.
• Darkpanabsorbsheattoofast.
• Allowoventopreheattotheselectedtemperaturebefore
placing food in oven.
• Choosepansizesthatwillpermit5.1cmto10.2cm(2”to
4”) of air space on all sides when placed in the oven.
• Useamedium-weightaluminumbakingsheet.
Cakes too dark on
top or bottom.
• Cakesputintotheovenbefore
preheating time is completed.
• Rackpositiontoohighorlow.
• Oventoohot.
• Allowoventopreheattotheselectedtemperaturebefore
placing food in the oven.
• Useproperrackpositionforbakingneeds.
• Setoventemperature25°F/12°Clowerthan
recommended.
Cakes not done in
the center.
• Oventoohot.
• Incorrectpansize.
• Pannotcenteredinoven.
• Setoventemperature25°F/12°Clowerthan
recommended.
• Usepansizesuggestedinrecipe.
• Useproperrackpositionandplacepansothereis
5.1cm to 10.2cm (2” to 4”) of space on all sides of pan.
Cakes not level. • Rangenotlevel.
• Pantooclosetoovenwallor
rack overcrowded.
• Panwarped.
• Placeamarkedglassmeasuringcuplledwithwateron
the center of the oven rack. If the water level is uneven,
refer to the installation instructions for leveling the range.
• Besuretoallow5.1cmto10.2cm(2”to4”)ofclearance
on all sides of each pan in the oven.
• Donotusepansthataredentedorwarped.
Foods not done
when cooking time
is up.
• Oventoocool.
• Ovenovercrowded.
• Ovendooropenedtoo
frequently.
• Setoventemperature25°F/12°Chigherthansuggested
and bake for the recommended time.
• Besuretoremoveallpansfromtheovenexceptthe
ones to be used for baking.
• Openovendooronlyaftershortestrecommendedbaking
time.

13
ENGLISH
Always pull oven
rack out to the “stop”
position before turning
or removing food.
Open door
to the “Broil Stop”
position when broiling.
Cooking Informations
Broiling
Broiling is a method of cooking tender cuts of meat by direct heat under the broil element of the oven.
Preheating
Preheating is suggested when searing rare steaks. (Remove all utensils from the oven before preheating. Foods will
stick if placed on hot metal.) To preheat, set the oven control(s) to BROIL as instructed in the Electronic Oven Control
Guide. Wait for the element to become red-hot, usually about 2 minutes. Preheating is not necessary when broiling
meats well-done.
Adjusting Your Oven Temperature
For instructions on how to adjust the oven temperature refer to the electronic oven control guide.
Grid
(some models)
Broiler Pan
(some models)
To Broil
Broil on one side until the food is browned; turn and cook on the second side. Season
and serve. Always pull rack out to the “stop” position before turning or removing food.
Determining Broiling Times
Broiling times vary, so watch the food closely. Time not only depends on the distance
from the element, but on the thickness and aging of meat, fat content and doneness
preferred. The first side usually requires a few minutes longer than the second. Frozen
meats also require additional time.
Broiling Tips (some models)
Broiler pan and its grid allow dripping grease to drain and be kept away from the high
heat of the broiler.
DO NOT use the pan without its grid. DO NOT cover the grid with foil. The ex-
posed grease could ignite.
Should an oven fire occur, close the oven door and turn off the
oven. If the fire continues, throw baking soda on the fire or use a fire extin-
guisher. DO NOT put water or flour on the fire. Flour may be explosive.
Broiler Clean-Up Tips (some models):
• Tomakecleaningeasier,linethebottomofthebroilerpanwithaluminum
foil. DO NOT cover the broiler grid with foil.
• Topreventgreasefrombakingon,removethebroilerpanfromtheovenas
soon as cooking is completed. Use hot pads because the broiler pan is ex-
tremely hot. Pour off grease. Soak the pan in HOT, soapy water.
• Cleanthebroilerpanassoonaspossibleaftereachuse.Ifnecessary,use
soap-filled steel wool pads. Heavy scouring may scratch the grid.

14
General Care & Cleaning
Cleaning Various Parts of Your Range
Before cleaning any part of the range, be sure all controls are turned OFF and the range is COOL. REMOVE SPILLOVERS
AND HEAVY SOILING AS SOON AS POSSIBLE. REGULAR CLEANING WILL REDUCE THE NUMBER OF MAJOR
CLEANING LATER.
Surfaces How to Clean
Aluminum & Vinyl Use hot, soapy water and a cloth. Dry with a clean cloth.
Painted and Plastic Control
Knobs, Body Parts, and
Decorative Trim
Using a soft cloth, clean with mild dish detergent and water or a 50/50 solution of
vinegar and water. Follow by rinsing the area with clean water; dry and polish with a soft
cloth. Glass cleaners may be used if sprayed on a soft cloth first. DO NOT spray liquids
directly on the control pad and display area. Do not use large amounts of water on the
control panel - excess water on the control area may cause damage to the appliance.
Do not use other liquid cleaners, abrasive cleaners, scouring pads, or paper towels -
they will damage the finish. To remove control knobs, turn to the OFF position; grasp
firmly and pull straight off the shaft. To replace knobs after cleaning, line up the flat sides
of both the knob and the shaft; then push the knob into place.
Stainless Steel (some
models) Oven Door &
Drawer Front Panel and
Decorative Trim
Stainless Steel (some models) Oven Door & Drawer Front Panel and Decorative Trim
Surface Elements and Drip
Bowls (some models) Surface elements can be unplugged and removed to make cleaning the drip bowls eas-
ier. The surface elements clean themselves when they are turned on. Food spilled on
a hot element will burn off. Food spilled on a cold element can be cleaned with a damp
cloth any remaining soil will burn off the next time element is used. NEVER IMMERSE
A SURFACE ELEMENT IN WATER. To remove surface element and drip bowls, follow
the instructions under General Cleaning.
To clean drip bowls, wash in hot, soapy water or in the dishwasher. Rinse and dry while
still warm. Hard-to-remove, burned-on soils can be removed by soaking the drip bowls
for about 20 minute in a slightly diluted liquid cleanser or solution made of equal parts
ammonia and water. A nylon scrubber may be used after soaking. DO NOT use abra-
sive cleanser or steel wool, as they will scratch the surface. Always rinse with clean
water and polish, and dry with a soft cloth. To replace drip bowls and surface elements,
follow the instructions under General Cleaning.
Porcelain Enamel
Broiler Pan and Insert (some
models), Cooktop, Surface
under Cooktop, Door Liner,
Body Parts and Warmer
Drawer and Drawer Cavity
Gentle scouring with a soapy scouring pad will remove most spots. Rinse with a 1:1
solution of clear water and ammonia. If necessary, cover difficult spots with an ammo-
nia-soaked paper towel for 30 to 40 minutes. Rinse with clean water and a damp cloth,
and then scrub with a soap-filled scouring pad. Rinse and wipe dry with a clean cloth.
Remove all cleaners or the porcelain may become damaged during future heating. DO
NOT use spray oven cleaners on the cooktop.
Oven Racks Oven racks should be removed, or else their finish will dull and their color turn slightly
blue. If they do go through the self-clean cycle, wait until the oven has cooled, then
remove the oven racks and rub their sides with wax paper or a cloth containing a small
amount of baby or salad oil; this will make the oven racks glide easier back in and out of
their positions.
Oven door
Do Not
Hand
Clean Seal
Do Hand
Clean Frame
Do Hand
Clean Door
To clean oven door, wash with hot, soapy water and a clean cloth. DO NOT immerse
the door in water.
DO NOT clean the oven door gasket. The oven door gasket is made of a woven mate-
rial, on self cleaning models, which is essential for a good seal. Care should be taken
not to rub, damage or remove the gasket.

15
ENGLISH
A rod swings up to support
the top for cleaning under-
neath.
Coil Surface Element (some models)
To Remove and Replace Surface Elements and Drip Bowls
ATTENTION: Never leave covers on the coil elements as they could be permanently
damaged if the coil is turned on by accident.
Prior to cleaning the coil elements make sure they are cold and that control knobs are
turned to OFF
Coil elements clean themselves when they are turned on.
Coil elements and drip bowls are removable and allow to clean the drip bowls.
To remove a coil element, push against the front edge and lift element up and out.
To clean by hand, wash the drip bowls in hot sudsy water. For hard to remove spots, use
nylon scrubber with soap. Rinse and dry will still warm.
Never immerse coil elements in water.
Be careful
not to bend terminal ends
when replacing elements
after cleaning.
To Raise the Cooktop for Cleaning
1. Grasp the sides and lift from the front. A lift-up rod will support the top in its raised
position. Only lift the top high enough to allow the support rod to rest in place under
the front of the cooktop.
2. Clean underneath using a clean cloth and hot, soapy water.
3. To lower the top, lift the top slightly and lower the rod. Lower the range top down into
the range frame.
When lowering the lift-up range top, grasp the sides with fingertips only. Be careful not to
pinch fingers. DO NOT drop or bend the range top when raising or lowering. This could
damage the surface.
Porcelain enamel cooktop cleaning instructions (some models)
Do not use a cooktop cleaner on a hot cooktop. The fumes can be hazardous to your health, and can
chemically damage the cooking surface.
Before cleaning the surface cooktop, be sure the controls are turned to OFF and the cooktop is cool.
DO NOT use commercial oven cleaners on the exterior surfaces including rangetop and door frame.
Correct and consistent cleaning is essential to maintaining your porcelain enamel cooktop. If food spills and grease
spatters are not removed, they may burn onto the surface of the cooktop and cause permanent discoloration.
Daily Cleaning
For normal soil:
1. Allow cooktop surface to cool.
2. Wipe off spills and spatters using a clean paper towel or a clean cloth with warm, soapy water.
3. If needed, use a soapy steel wool pad or other mild household cleaners.
4. Be sure to rinse off the cleaners or the porcelain may become damaged during future heating.
For heavy, burned-on soil:
1. Allow cooktop surface to cool.
2. Use a soap filled scouring pad with warm water or cover heavily soiled spots with a solution of clear water and
ammonia. Scour gently. Rinse and wipe dry with a clean cloth.
3. If any soil remains, apply a few drops of a recommended cooktop cleaning cream on the spots and rub gently using
a clean damp cloth or scouring pad. Buff with a dry cloth until all soil and cream are removed. Frequent cleaning with
the cooktop cleaning cream leaves a protective coating which helps in preventing scratches and abrasions.
For sugary spillovers:
Sugary spills can chemically damage your cooktop surface. Therefore, you must begin cleaning the spills while the
cooktop is still hot. Use caution when following the steps below.
1. Turn off all surface units and remove all pans immediately.
2. Wearing an oven mitt, wipe up carefully or move hot spills away from the element area with a clean damp cloth.
3. Allow the cooktop to cool. Follow the instructions above for heavy, burned-on soil.
General Care & Cleaning

16
General Care & Cleaning
Ceramic Glass Cooktop Cleaning & Maintenance (some models)
Consistent and proper cleaning is essential to maintaining your Ceramic glass cooktop
Prior to using your cooktop for the first time, apply the recommended CookTop® Cleaning Creme to the ceramic sur-
face. Buff with a non-abrasive cloth or no-scratch cleaning pad. This will make cleaning easier when soiled from cook-
ing. The special cooktop cleaning cream leaves a protective finish on the glass to help prevent scratches and abrasions.
Sliding aluminum or copper clad bottom pans on the cooktop can cause metal
markings on the cooktop surface. These marks should be removed immediately
after the cooktop has cooled using the cooktop cleaning cream. Metal marks can
become permanent if not removed prior to future use.
Cookware (cast iron, metal, ceramic or glass) with rough bottoms can mark or
scratch the cooktop surface. Do not slide anything metal or glass across the
cooktop. Do not use your cooktop as a cutting board or work surface in the kitchen.
Do not cook foods directly on the cooktop surface without a pan. Do not drop
heavy or hard objects on the glass cooktop, because they may cause it to crack.
Before cleaning the cooktop, be sure the controls are turned to OFF and the cooktop is COOL.
DO NOT use a cooktop cleaner on a hot cooktop. The fumes can be hazardous to your health, and
can chemically damage the ceramic glass surface.
Cleaning Recommendations for the Ceramic Glass Cooktop
For light to moderate soil:
Apply a few drops of CookTop® Cleaning Creme directly to the cooktop. Use a paper towel or use a non-abrasive plastic
type no-scratch cleaning pad to clean the entire cooktop surface. Make sure the cooktop is cleaned thoroughly, leaving
no residue.
For heavy, burned on soil:
Apply a few drops of CookTop® Cleaning Creme directly to the soiled area. Rub the soiled area using a non-abrasive
plastic type no-scratch cleaning pad, applying pressure as needed. Do not use the pad you use to clean the cooktop for
any other purpose.
If soils remain, carefully scrape soils with a metal razor blade scraper, holding scraper at a
30 degree angle to the surface. Remove loosened soils with cooktop cleaning cream and buff
surface clean.
IMPORTANT NOTE: Damage to the ceramic glass cooktop may occur if you use an abrasive
type scratch pad. Only use cleaning products that have been specifically designed for ceramic
glass cooktop.
Plastic or foods with a high sugar content:
These types of soils need be removed immediately if spilled or melted onto the ceramic
cooktop surface. Permanent damage (such as pitting of the cooktop surface) may occur if not removed immediately.
After turning the surface elements OFF, use a razor blade scraper or a metal spatula with a mitt and scrape the soil from
the hot surface (as illustrated). Allow the cooktop to cool, and use the same method for heavy or burned on soils.
Do not use the following on the ceramic glass cooktop:
• Donotuseabrasivecleanersandscouringpads,suchasmetalandsomenylon
pads.Theymayscratchthecooktop,makingitmoredifculttoclean.
• Donotuseharshcleaners,suchaschlorinebleach,ammoniaorovencleaners,as
they may etch or discolor the cooktop.
• Donotusedirtysponges,clothsorpapertowels,astheycanleavesoilorlinton
the cooktop which can burn and cause discoloration.
Special Caution for Aluminum Foil and Aluminum Cooking Utensils
• Aluminumfoil:Use of aluminum foil will damage the cooktop. Do not use under any
circumstances.
• Aluminumutensils: Since the melting point of aluminum is much lower than that of
other metals, care must be taken when aluminum pots or pans are used. Pans that boil
dry may permanently damage cooktop by breaking, fusing to, or marking it.

17
ENGLISH
Oven Cleaning
Cleaning the Manual Clean Oven (non self-clean oven, some models)
Make sure the oven is cool and that all control knobs are et OFF position. Cleaning the
oven is a lot easier when the door is removed.
1. Remove the oven door; see under To Remove and Replace the Oven Door section.
2. Empty the oven including the racks.
3. You can wash the racks in the kitchen sink.
4. Clean oven lining thoroughly with soap and a wet cloth and wipe with a dry cloth.
To remove burned-on fat on oven walls, moisten soiled parts with household ammonia,
using a wet cloth. Follow suggested manufacturer’s cleaning method. (Do not remove the
oven door when using ammonia.)
Complete cleaning with a damp cloth and use a fine steel wool scouring agent if necessary.
The lower element can be moved up for cleaning purposes.
5. Replace racks in the oven. Reinstall oven door.
Care and Cleaning of Stainless Steel (Some Models)
Some models are equipped with stainless steel exterior parts. Special care and cleaning are required for maintaining the
appearance of stainless parts. Please refer to the table provided at the beginning of the General Care & Cleaning section
in this Use & Care Guide.
Cleaning the Self-Clean Oven (some models)
Adhere to the following cleaning precautions:
- Allow the oven to cool before cleaning.
- Wear rubber gloves when cleaning any exterior parts of the oven manually.
During the self-clean cycle, the outside of the wall oven can become very hot to the touch. DO NOT
leave small children unattended near the appliance.
The health of some birds is extremely sensitive to the fumes given off during the self-cleaning cycle of
any range. Move birds to another well ventilated room.
Before cleaning any part of the oven, be sure the electronic oven control is turned off or else push
CANCEL pad. Wait until the oven is cool.
DO NOT use commercial oven cleaners or oven protective coatings in or around any art of the self-cleaning oven. DO
NOT clean the oven door gasket. The gasket on the oven door is essential for a good seal. Care should be taken not to
rub, damage or move the gasket. DO NOT use any cleaning materials on the gasket. Doing so could damage it.
DO NOT use aluminum foil to line the oven bottom. This may affect cooking or foil could melt and damage the oven
surface.
A self-cleaning oven cleans itself with high temperatures (well above cooking temperatures) which eliminate soil
completely or reduce it to a fin powdered ash you can which away with damp cloth.
Preparing the Oven for Self-Cleaning
1. Remove all excess spillovers in the oven cavity before starting the self-cleaning cycle. To clean, use hot soapy water
and a cloth. Large spillovers can cause heavy smoke or fire when subjected to high temperatures. DO NOT allow
food spills with a high sugar or acid content (such as tomatoes, sauerkraut, fruit juices or pie filling) to remain on the
surface as they may cause a dull spot even after cleaning.
2. Clean any soil from the oven frame and the door liner (see illustration). These
areas heat sufficiently during self-cleaning cycle to burn soil on. Clean with soap
and water.
3. Remove all utensils and any foil from the oven. These items do not withstand high
cleaning temperatures
4. Oven racks may be left in the oven or may be removed. If they go through the
clean cycle, their color will turn slightly dull. After the cycle is completed and the
oven has cooled, rub the sides of the racks with wax paper or a cloth containing a
small amount of baby oil or salad oil. This will make the racks glide easier.
Do Not
Hand
Clean Seal
Do Hand
Clean Frame
Do Hand
Clean Door
General Care & Cleaning

18
What to Expect During Cleaning
While the oven is in operation, the oven heats to temperatures much higher than those used in normal cooking. Sounds
of metal expansion and contraction are normal. Odor is also normal as the food soil is being removed. Smoke may appear
through the oven vent, located on the top of the control panel.
If heavy spillovers are not wiped up before cleaning, they may flame and cause more smoke and odor than usual. This is
normal and safe and should not cause alarm. If available, use an exhaust fan during the self-cleaning cycle.
NOTE: A smoke eliminator in the oven vent converts most of the soil into a colorless vapor.
Setting the Controls for Self-Clean Cycle
For the setting of the clean cycle, refer to Timer or Electronic Oven Control Guide.
Oven Cleaning (Continued)
Cleaning the Self-Clean Oven (some models, Continued)
General Care & Cleaning
Fig. 3
Oven door
Hinge
Removing and Replacing the Lift-Off Oven Door
The door is heavy. For safe, temporary storage, lay the door flat
with the inside of the door facing down.
To Remove Oven Door:
1. Open oven door completely (horizontal with floor - See Fig. 1).
2. Pull the door hinge locks on both left and right door hinges down from the
oven frame completely towards the oven door (See Fig. 2). A tool such as a
small flat-blade screwdriver may be required.
3. Firmly grasp both sides of oven door along the door sides (Do not use the
oven door handle - See Fig. 3).
4. Close the door to the broil stop position (the oven door will stop into this
position just before fully closing).
5. With the oven door in the broil stop position, lift the oven door hinge arms
over the roller pins located on each side of the oven frame (See Fig. 4).
To Replace Oven Door:
1. Firmly grasp both sides of oven door along the door sides (Do not use the
oven door handle - See Fig. 3).
2. Holding the oven door at the same angle as the removal position, seat the
hook of the hinge arm over the roller pins located on each side of the oven
door frame (See Fig. 4). The hook of the hinge arms must be fully seated
onto the roller pins.
3. Fully open the oven door (horizontal with floor - See Fig. 1).
4. Push the door hinge locks up towards and into the oven frame on both left
and right oven door hinges (See Fig. 2) to the locked position.
5. Close the oven door.
Special Door Care Instructions - Most oven doors contain glass that can break.
Read the following recommendations:
1. Do not close the oven door until all the oven racks are fully in place.
2. Do not hit the glass with pots, pans, or any other object.
3. Scratching, hitting, jarring or stressing the glass may weaken its structure
causing an increased risk of breakage at a later time.
Door Hinge
locations
with oven door
fully open
Fig. 1
Fig. 2
Fig. 4
Roller pin
Hinge arm
hook
Around

19
ENGLISH
Storage Drawer with extensible glides (some models)
To remove drawer with extensible glides:
1. Open the drawer to the fully opened position.
2. Locate the latches on both sides of the warmer drawer. (See Fig. 1)
3. Pull up on the left glide latch and push down on the right glide latch. (See Fig. 1)
4. Pull the drawer away from the range.
5. To clean warmer drawer, gently scour with a soapy scouring pad, this will remove
most spots. Rinse with a 1:1 solution of clear water and ammonia. If necessary,
cover difficult spots with an ammonia-soaked paper towel for 30 to 40 minutes.
Rinse with clean water and a damp cloth. Remove all cleaners or the porcelain
may become damaged during future heating. DO NOT use spray oven cleaners
on the cooktop.
To replace drawer with extensible glides:
1. Align the glide latches on both sides of the drawer with the slots on the drawer.
2. Push the drawer back into the range.
General Care & Cleaning
Stopper
Front Frame
Storage Drawer (some models)
Use the storage drawer for storing cooking utensils. The
drawer can de removed to facilitate cleaning under the
range. Use care when handling the drawer.
Removing and Replacing Storage Drawer
To remove the drawer:
1. Pull empty drawer out to the stopper position.
2. Tilt the drawer up and pull it out over the upper guide.
To replace the drawer:
1. Insert the rear end of the drawer into the opening.
2. Fit the drawer guide onto the lower channel.
3. Push the drawer in until it stops, then lift to allow the
rollers to clear the roller guide stop, and push in.
Latch
Latch
Left Glide
Right Glide
Pull up latch
with finger
Pull down latch
with finger Fig. 1
To Remove the «Hidden Bake» Cover (some models)
1. In order to remove the «hidden bake» cover, pull the back edge with one
hand about 1/2» inch and lift up the «hidden bake» cover with both hands.
(See picture)
2. When reinstalling the «hidden bake» cover, be sure to put it all the way to
the back of the oven and lay it down on the 2 shoulder screws. Then push
the front edge of the cover in its place below the front bracket.
To have easier access to the «hidden bake» cover, you can remove the oven
door by following the instructions on previous page.
IMPORTANT: Always replace the «hidden bake» cover before the next use.
Roller Guide
Roller Storage Drawer
Fig. 2

20
General Care & Cleaning
DO NOT
turn the oven light on
during the self-clean-
ing cycle. High tem-
perature will reduce
lamp life.
Changing the Surface Light (some models)
Be sure all surface element control knobs are turned off and ele-
ments are cool.
Use switch located on or underneath the control panel to turn the surface light ON/
OFF.
Replace the surface light, if after repeated attempts to turn it on you are not successful.
To remove and replace the fluorescent light:
It is recommended to place a pocket mirror on the cooktop in middle at back. This will help you to
replace the fluorescent tube.
1. Place your fingers under the tube located underneath and in the middle of the control panel.
2. Toremove,turnthetube90°thenpullitdownandoutofitssockets.
3. To replace the tube, engage the new tube into the sockets, then rotate and snap the tube in
place. Turn on the surface light to make sure it will lit.
Oven Light
On some models an interior oven light will turn on automatically when the oven door is
opened.
The oven light may be turned on when the door is closed by using the oven light switch lo-
cated on or underneath the control panel.
On a self clean oven the lamp is covered with a glass shield held in place by a wire holder.
THIS GLASS SHIELD MUST BE IN PLACE WHENEVER THE OVEN IS IN USE.
To replace the light bulb:
BE SURE OVEN IS COOL.
1. Turn the power off at the main source.
2. Wear a leather-faced glove for protection against possible broken glass.
3. Replace bulb with a 40 watt appliance bulb only.
4. For self-cleaning oven, press wire holder to one side to release glass shield, change bulb
and be sure to replace glass shield.
